Datasheet DE375-102N10A Datasheet (DEI)

Page 1
An
IXYS
Directed Energy, Inc.
Company
DE375-102N10A
RF Power MOSFET
N-Channel Enhancement Mode Avalanche Rated Low Qg and Rg High dv/dt Nanosecond Switching
Symbol Test Conditions Maximum Ratings V
DSS
V
DGR
V
GS
V
GSM
I
D25
I
DM
I
AR
E
AR
dv/dt
P
DHS
P
DAMB
T
J
T
JM
T
stg
T
L
Weight
TJ = 25°C to 150°C
TJ = 25°C to 150°C; R
Continuous
Transient
Tc = 25°C
Tc = 25°C, pulse width limited by TJM
Tc = 25°C
Tc = 25°C
I
≤ IDM, di/dt ≤ 100A/µs, VDD ≤ V
S
≤ 150°C, RG = 0.2Ω
T
j
IS = 0
Tc = 25°C Derate 4.4W/°C above 25°C
Tc = 25°C
1.6mm (0.063 in) from case for 10 s
= 1 MΩ
GS
DSS
,
3 g
Symbol Test Conditions Characteristic Values
TJ = 25°C unless otherwise specified
V V I I
R
g
GSS
DSS
DSS
GS(th)
DS(on)
fs
VGS = 0 V, ID = 3 ma
VDS = VGS, ID = 4 ma
VGS = ±20 VDC, VDS = 0
VDS = 0.8 V V
GS
VGS = 15 V, ID = 0.5I
Pulse test, t ≤ 300µS, duty cycle d ≤ 2%
VDS = 15 V, ID = 0.5I
DSS TJ
= 0 TJ = 125°C
= 25°C
D25
, pulse test
D25
min. typ. max.
1000 V
2.5 5.5 V
±100 nA
6 18 S
1000 V
1000 V
±20 V
±30 V
10 A
60 A
10 A
30 mJ
5 V/ns
>200 V/ns
550 W
4.5 W
-55…+150 °C
150 °C
-55…+150 °C
300 °C
50
1.2
1
µA
mA
Ω
Preliminary Data Sheet
DSS
I
D25
R
DS(on)
DHS
= 1000 V = 10 A = = 550 W
GATE
SG1 SG2
Features
•
Isolated Substrate
−
high isolation voltage (>2500V)
−
excellent thermal transfer
−
Increased temperature and power cycling capability
•
IXYS advanced low Qg process
•
Low gate charge and capacitances
−
easier to drive
−
faster switching
•
Low R
•
Very low insertion inductance (<2nH)
•
No beryllium oxide (BeO) or other hazardous materials
Advantages
•
Optimized for RF and high speed switching at frequencies to 50MHz
•
Easy to mount—no insulators needed
•
High power density
DS(on)
1.2 ΩΩΩΩ
DRAIN
SD1 SD2
Page 2
Directed Energy, Inc.
An
IXYS
Symbol Test Conditions Characteristic Values
Company
TJ = 25°C unless otherwise specified)
(
DE375-102N10A
RF Power MOSFET
R C C
C T
T T T Q Q
Q R
G
iss
oss
rss
d(on)
on
d(off)
off
g(on)
gs
gd
thJHS
2900 pF
VGS = 0 V, VDS = 0.8 V f = 1 MHz
VGS = 15 V, VDS = 0.8 V ID = 0.5 IDM R
= 0.2 Ω (External)
G
VGS = 10 V, VDS = 0.5 V ID = 0.5 I
D25
DSS(max)
DSS
DSS
,
min. typ. max.
0.3
100 pF
25 pF
5 ns
3 ns
5 ns
8 ns
90 nC
30 nC
40 nC
0.23 K/W
Source-Drain Diode Characteristic Values
TJ = 25°C unless otherwise specified)
(
Ω
Symbol Test Conditions min. typ. max. I
S
I
SM
V
SD
T
rr
Q
RM
I
RM
Directed Energy, Inc. reserves the right to change limits, test conditions and dimensions.
DEI MOSFETS are covered by one or more of the following U.S. patents:
4,835,592 4,850,072 4,881,106 4,891,686 4,931,844 5,017,508
5,034,796 5,049,961 5,063,307 5,187,117 5,237,481 5,486,715
5,381,025 5,640,045
VGS = 0 V
Repetitive; pulse width limited by T
IF = IS, VGS = 0 V,
Pulse test, t ≤ 300 µs, duty cycle ≤ 2%
IF = I
, -di/dt = 100A/µs,
S
V
= 100V
R
JM
7 A
10 A
80 A
1.5 V
200 ns
0.6
µC
Page 3
An
IXYS
Directed Energy, Inc.
Company
DE375-102N10A
RF Power MOSFET
102N10A DE-SERIES SPICE Model
The DE-SERIES SPICE Model is illustrated in Figure 1. The model is an expan­sion of the SPICE level 3 MOSFET model. It includes the stray inductive terms L
, LS and LD. Rd is the R
G
The output capacitance, C eled with reversed biased diodes. This provides a varactor type response nec­essary for a high power device model. The turn on delay and the turn off delay are adjusted via Ron and Roff.
of the device, Rds is the resistive leakage term.
DS(ON)
, and reverse transfer capacitance, C
OSS
RSS
are mod-
Figure 1 DE-SERIES SPICE Model
This SPICE model may be downloaded as a text file from the DEI web site at www.directedenergy.com/spice.htm
Net List: .SUBCKT 102N10A 10 20 30 * TERMINALS: D G S * 1000 Volt 10 Amp 1.2 ohm N-Channel Power MOSFET * REV.A 05-23-00 M1 1 2 3 3 DMOS L=1U W=1U RON 5 6 0.5 DON 6 2 D1 ROF 5 7 .1 DOF 2 7 D1 D1CRS 2 8 D2 D2CRS 1 8 D2 CGS 2 3 3.0N RD 4 1 1.5 DCOS 3 1 D3 RDS 1 3 5.0MEG LS 3 30 .5N LD 10 4 1N LG 20 5 1N .MODEL DMOS NMOS (LEVEL=3 VTO=3.0 KP=3.8) .MODEL D1 D (IS=.5F CJO=1P BV=100 M=.5 VJ=.6 TT=1N) .MODEL D2 D (IS=.5F CJO=400P BV=1000 M=.4 VJ=.6 TT=400N RS=10M) .MODEL D3 D (IS=.5F CJO=900P BV=1000 M=.3 VJ=.4 TT=400N RS=10M) .ENDS
Doc #9200-0223 Rev 2 © 2001 Directed Energy, Inc.
Directed Energy, Inc.
An
2401 Research Blvd., Suite 108 Fort Collins, CO USA 80526 970-493-1901 Fax: 970-493-1903 Email: [email protected] Web: http://www.directedenergy.com
