Datasheet D22-25-10-RO Specification

D22-25

Outline type code: DO-4

See package details for further information

Diode

KKD2225, February 2014 version

Diode type D22 are design for use in power rectifying circuits under normal operating conditions.

KEY PARAMETERS

U

up to 1400 V

RRM

I

25 A

F(AV)

I

275 A

FSM

FEATURES

all diffused design

high current capabilities
high surge current capabilities
compact size and small weight
tested according to IEC standards

APPLICATION

Medium Voltage Power Supplies

Motor Control
Battery Chargers
Free Wheeling Diode
Resistance Welding

KUBARA LAMINA SA Tel.: [phone]
Puławska 34 Tel.: [phone]
PL-05-500 Piaseczno Fax: [phone]
POLAND e-mail: [e-mail]
www.kubara-lamina.com

1/5

D22-25

Voltage class
