Datasheet CYG2031, CYG2030, CYG2021, CYG2020, CYG2011 Datasheet (CPCLA)

1

www.clare.com

CYG20XX

DS-CYG20XX-R1

The CYG2000/2001/2010/2011/2020/2021/2030/2031
are Data Access Arrangement (DAA) modules featuring
a 350V, 120mA, 15Ω relay used for hookswitch, optocou­pler with minimum CTR of 33% for ring detection, and a
low distortion transformer with 28.8kbps capabilities.

• Modems

• Fax machines

• Remote data acquisition

• Security systems

• Voice mail systems

• PC motherboard

• Computer telephony

• Process control

• Medical

• PBX

• Direct broadcast satellite

• UL recognized file #: E174201

• Low distortion transformer signal coupling

(0.01% max)

• Complete ring detector circuit

• Low power hookswitch

• Electronic inductor/gyrator circuit

• Surge protection

• Transient protection zeners

• Half- (20X0) or Full- (20X1) Wave Detection

• V.32 bis /V.34 compatible

• FCC Compatible

• Compatible with U.S. and Canadian dial up

phone lines

• Supports leased-line operation

• PC board mountable

Applications

Features

Description

Approvals

Cybergate

TM

Ordering Information

Part # Description

CYG2000 DAAModule, Half Wave Ring Detection
CYG2001 DAA Module, Full Wave Ring Detection
CYG2010 DAAModule, Half Wave Ring Detection,

Loop Current Detection

CYG2011 DAA Module, Full Wave Ring Detection

Loop Current Detection

CYG2020 DAAModule, Half Wave Ring Detection,

CID

CYG2021 DAAModule, Full Wave Ring Detection,

CID

CYG2030 DAAModule, Half Wave Ring Detection,

CID and Loop Current Detection

CYG2031 DAAModule, Full Wave Ring Detection,

CID and Loop Current Detection

Block Diagrams

8

7

9

RING

OH

LOOPI

1
2

17

18

11

10

HOOKSWITCH

LINE 2

LINE 1

RING

GND

V

CC

GND

470Ω

V

CC

TIP
RING

GYRATOR

V

CC

RING

V

CC

V

CC

2.2k

47k

LOOP

CURRENT

DETECT

RING

DETEC-

TION

SURGE

PROTEC-

TION

CYG2010/CYG2011

R_LIM

R_LIM

8
9

RING

OH

1
2

17

18

11

10

14
13

HOOKSWITCH

LINE 2

LINE 1

RING

GND

V

CC

V

CC

TIP
RING

GYRATOR/
CALLER ID

RING

R_LIM

R_LIM

V

CC

47k

RING

DETEC-

TION

SURGE

PROTEC-

TION

CID1
CID2

CYG2020/CYG2021

470Ω

8

7

9

RING

OH

LOOPI

1
2

17

18

11

10

14
13

HOOKSWITCH

LINE 2

LINE 1

RING

GND

V

CC

V

CC

TIP
RING

GYRATOR/
CALLER ID

V

CC

RING

R_LIM

R_LIM

V

CC

2.2k
47k

LOOP

CURRENT

DETECT

RING

DETEC-

TION

SURGE

PROTEC-

TION

CID1
CID2

CYG2030/CYG2031

470Ω

Handling and Assembly Recommendations

The CYG20XX products are not hermetically sealed and should not be exposed to any liquid-based rinsing processes. Clare recommends two (2) approaches. The
modem should either use a no clean soldering flux that would mostly evaporate during the normal wave soldering processes, or be soldered in by hand after the
rest of the card is wave soldered.

www.clare.com

CYG20XX

Rev. 1

Electrical Characteristics

Absolute Maximum Ratings are stress ratings. Stresses in
excess of these ratings can cause permanent damage to
the device. Functional operation of the device at these or
any other conditions beyond those indicated in the opera­tional sections of this data sheet is not implied. Exposure
of the device to the absolute maximum ratings for an
extended period may degrade the device and effect its
reliability .

Absolute Maximum Ratings (@ 25˚ C)

2

Parameter Conditions Min Typ Max Unit

DC Electrical Characteristics

On-Hook Impedance @100VDC across pins 10 - - MΩ

10,11 (R,T), per FCC 68.312

Off-Hook Line Leakage Current @100VDC across pins - - 10 µA

10,11 (R,T), per FCC 68.312
Hookswitch Resistance - - - 15 Ω
Off-Hook Supply Current @+5V, V

CC

789mA
Hookswitch Power Source, Pin 8 - 4.75 5.0 20 V
DC Loop Current - 20 - 120 mA

AC Signal Path Electrical Characteristics

Return Loss 300-3500Hz 18 25 - dB
Insertion Loss 300-3500Hz

Transmit Test Circuit 1 - - 7 dB

Receive Test Circuit 2 - - 7 dB
Frequency Response 300-3500Hz -0.25 - +0.25 dB
Longitudinal Balance

On-Hook Per FCC 68.310 60 - - dB

Off-Hook Per FCC 68.310 40 - - dB
DC Loop Current - 20 - 120 mA
Total Harmonic Distortion @600Hz and -10dBm - - 0.01 %
Secondary Load Impedance Line 1 and Line 2 - 294 - Ω
Primary Source Impedance Tip and Ring - 600 - Ω

Ring Detection Circuit Characteristics

Ringing Voltage Detection Range - 20 - 150 Vrms
Ringing Frequency Detection Range - 15 - 70 Hz
Ringer Equivalence Number - - 0.8B ­RING (Pin 9) Output Voltage (Pulsed) V

CC

@+5V
Logic ‘0’, Ring present - - 0.8 V
Logic ‘1’, Ring not present - - Vcc V

Parameter Min Typ Max Units

Isolation Voltage - - 1000 V

RMS

Operational Temperature 0 - 70 °C
Storage Temperature 0 - 70 °C
Relative Humidity

(Non-Condensing) 10 - 85 %
Soldering Temperature - - 260 °C
Tip/Ring (5, 6) Load

current (continuous) - - 120 mA
Hookswitch LED

Drive Current - - 50 mA
Hookswitch LED

Reverse Voltage - - 5 V
Ring Detect

Phototransistor Voltage V

CC

--20V

CYG20XX

www.clare.com

Rev. 1

3

Electrical Characteristics (Continued)

Parameter Conditions Min Typ Max Unit

Surge, Transient, and

Isolation Characteristics

Surge Protection Voltage Tip and Ring - - - 300 V

(Pins 11,10)
Transient Voltage Protection on

Line 1 and Line 2 (Pins 1,2) - -5 - +5 V
Isolation Voltage

(Pins 1,2,7,8,9,17,18 to10,11,13,14) Per FCC 68.302 - - 1000 V

RMS

Loop Detection Characteristics

(CYG2010/CYG2011/CYG2030/CYG2031)

Loop Current Detection Threshold Internal optocoupler with 9 10 11 mA

2.2K Pull-up resistor

Test Circuits

LINE1

LINE2

+V

BATT

-V

BATT

OH

RING

10H

600Ω

10H

TIP

RING

V

CC

GND
CID1

CID2

V

R

+5V

V

LR

I

LOOP

G

Log

V

V

RC

R

LR

=

20

Receive Insertion Loss =

2. CYG20XX Receive Insertion Loss

AC

Source

Rm

294Ω

LINE1

LINE2

+5V

+V

BATT

-V

BATT

OH

RING

10H

600Ω

10H

TIP

RING

V

CC

GND
CID1

CID2

LOOP

Rm

294Ω

V

T

V

LT

I

LOOP

G Log

V

V

TR

LT

T

= 20

Transmit Insertion Loss =

1. CYG20XX Transmit Insertion Loss

1
2

4

6

VCC

µP Control

(Active Low)

CID1

CID2

CYG2020/2021/2030/2031

Caller ID Connections

Pins 13 & 14 should be connected to a 1-Form-A solid state relay (Clare LCA110), as follows:

www.clare.com

4

CYG20XX

Rev. 1

Package Pinouts

Top View

18
17

1
2

8

7
9

11
10

V

CC

GND

TIP
RING

LINE 1
LINE 2

DO NOT USE

OH

RING

CYG2000/CYG2001

Top View

18
17

1
2

8
9

11

10

V

CC

GND

TIP
RING

14

13

CID1
CID2

LINE 1
LINE 2

OH

RING

CYG2020/CYG2021

Top View

18
17

1
2

8

7
9

11
10

V

CC

GND

TIP
RING

LINE 1
LINE 2

LOOPI

OH

RING

CYG2010/CYG2011

Top View

18
17

1
2

8

7
9

11

10

V

CC

GND

TIP
RING

14

13

CID1
CID2

LINE 1
LINE 2

LOOPI

OH

RING

CYG2030/CYG2031

CYG20XX Pinouts & Definitions

PIN# I/O Name Function

1 I/O LINE1 Transformer isolated audio signal coupling path for the telephone line.
2 I/O LINE2 Transformer isolated audio signal coupling path for the telephone line.
7 I LOOPI When system is off-hook (OH driven LOW) LOOPI is driven LOW continuously

on CYG2010/2011/2030/2031 devices.

N/C Keying pin for CYG2000/CYG2001, do not use.

8 I OH Driving this pin LOW asserts the off-hook condition. The hookswitch LED is cur-

rent limited by an internal 470Ω resistor.

9 O RING Active LOW indicates an incoming ring signal. This is pulsed LOW by the AC

ring signal at the ring frequency from 15-40Hz.
10 I/O RING Connection to telephone line Ring conductor.
11 I/O TIP Connection to telephone line Tip conductor.
13 O CID2 Caller ID connection on CYG2020/2021/2030/2031. CID1/CID2 connect to an

external 1-Form-Asolid state relay (CP Clare LCA110). When the SSR is closed

(connecting CID1 to CID2) Caller ID information is presented to LINE1/LINE2

after the first telephone ring burst.
14 O CID1 Caller ID connection. See CID2 above.
17 I GND Connected to host system ground.
18 I V

CC

Provides power to the hookswitch LED. Typically +5V for ≈ 8mA LED current.

LED is current limited by an internal 470Ω resistor. VCCshould not exceed 20V.

CYG20XX

www.clare.com 5

Rev. 1

HYBRID

CIRCUIT

8

9

RING

OH

294Ω

1

2

10

+5V

18

11

17

TO TELEPHONE LINE

GYRATOR

SURGE

PROTECTOR

RING

DETECT

NETWORK

V

CC

V

CC

470Ω

56kΩ

HOOKSWITCH

V

CC

LINE 2

LINE 1

RING

GND

GND

V

CC

TX1

TX2

RX

OH RELAY

RING

TIP

CYG2000/CYG2001

T ypical Application

CLARE LOCATIONS

Clare Headquarters
78 Cherry Hill Drive
Beverly, MA 01915
Tel: [phone]
Fax: [phone]
Toll Free: 1-800-27-CLARE

Clare Micronix Division
145 Columbia
Aliso Viejo, CA 92656-1490
Tel: [phone]
Fax: [phone]

SALES OFFICES
AMERICAS

Americas Headquarters

Clare
78 Cherry Hill Drive
Beverly, MA 01915
Tel: [phone]
Fax: [phone]
Toll Free: 1-800-27-CLARE

Eastern Region

Clare
P.O. Box 856
Mahwah, NJ 07430
Tel: [phone]
Fax: [phone]
Toll Free: 1-800-27-CLARE

Central Region

Clare Canada Ltd.
3425 Harvester Road, Suite 202
Burlington, Ontario L7N 3N1
Tel: [phone]
Fax: [phone]

Western Region

Clare
1852 West 11th Street, #348
Tracy, CA 95376
Tel: [phone]
Fax: [phone]
Toll Free: 1-800-27-CLARE

Canada

Clare Canada Ltd.
3425 Harvester Road, Suite 202
Burlington, Ontario L7N 3N1
Tel: [phone]
Fax: [phone]

EUROPE

European Headquarters

CP Clare nv
Bampslaan 17
B-3500 Hasselt (Belgium)
Tel: [phone]
Fax: [phone]

France

Clare France Sales
Lead Rep
99 route de Versailles
91160 Champlan
France
Tel: [phone]
Fax: [phone]

Germany

Clare Germany Sales
ActiveComp Electronic GmbH
Mitterstrasse 12
85077 Manching
Germany
Tel: [phone]
Fax: [phone]

Italy

C.L.A.R.E.s.a.s.
Via C. Colombo 10/A
I-20066 Melzo (Milano)
Tel: [phone]
Fax: [phone]

Sweden

Clare Sales
Comptronic AB
Box 167
S-16329 Spånga
Tel: [phone]
Fax: [phone]

United Kingdom

Clare UK Sales
Marco Polo House
Cook Way
Bindon Road
Taunton
UK-Somerset TA2 6BG
Tel: [phone]
Fax: [phone]

ASIA/PACIFIC

Asian Headquarters

Clare
Room N1016, Chia-Hsin,
Bldg II,10F, No. 96, Sec. 2
Chung Shan North Road
Taipei, Taiwan R.O.C.
Tel: [phone]
Fax: [phone]

http://www.clare.com

Worldwide Sales Offices

Specification: DS-CYG20XX-R1
©Copyright 2000, Clare, Inc.
CybergateTMis a trademark of Clare, Inc.
All rights reserved. Printed in USA.
1/12/01

Clare cannot assume responsibility for use of any circuitry other
than circuitry entirely embodied in this Clare product. No circuit
patent licenses nor indemnity are expressed or implied. Clare
reserves the right to change the specification and circuitry, with­out notice at any time. The products described in this document
are not intended for use in medical implantation or other direct life
support applications where malfunction may result in direct phys­ical harm, injury or death to a person.
