Page 1
LITHIUM CELL/BATTERY TEST SUMMARY
CR2450 Lithium Manganese Dioxide Battery
Ansmann AG
Industriestr. 10, 97959 Assamstadt
+49 6294 4204-0
www.ansmann.de
Guangzhou MCM Certification and Testing Co., LTD
1F No.13, Zhong San Section, ShiGuang Road; Panyu District, Guangzhou City, Guangdong Province,
0086-20-34777662, 0086-20-34777663, 0086-20-34777665-609
http://www.mcmtek.com
LJKJ20180405Z01
26.04.2018
6.7
0.165
button cell, diameter 24mm, height 5.0mm; nom. voltage 3.0V
IN ACCORDANCE WITH SUB-SECTION 38.3
OF MANUAL OF TESTS AND CRITERIA
1. Name of cell / battery
2. Manufacturer of cell / battery / product
Name
Address
Phone
Email
Website
3. Test laboratory of cell / battery / product
N/A = Not Applicable
Name
Address
Phone
Email
Website
4. ID-number and date
Unique test report identification number Date of test report
DESCRIPTION OF CELL / BATTERY
5. Mark the type of cell/battery with an ”•”
Lithium ion cell Lithium metal cell
Lithium ion battery Lithium metal battery
6. Parameters Cell Battery
Mass in gram (g):
Lithium ion: Indicate watt-hour rating (Wh):
Lithium metal: Indicate lithium metal content in gram (g):
7. Physical description of cell / battery
Version 1/2019
Page 1
Page 2
LITHIUM CELL/BATTERY TEST SUMMARY
CR2450 Lithium Manganese Dioxide Battery
CR2450
ST/SG/AC.10/11/Rev.6 section 38.3
Assamstadt, 12.02.2020
Technician, Gramlich, Timo
Timo Gramlich
Digital unterschrieben von Timo
Gramlich
Datum: 2020.02.24 10:38:44
+01'00'
IN ACCORDANCE WITH SUB-SECTION 38.3
OF MANUAL OF TESTS AND CRITERIA
Name of cell/battery (taken from field 1)
8. Model numbers
TESTS AND RESULTS
9. List of tests conducted and results - Mark N/A, pass or fail with an ”•” N/A pass fail
T1 - Altitude simulation
T2 - Thermal Test
T3 - Vibration
T4 - Shock
T5 - External Short Circuit
T6 - Impact / Crush
T7 - Overcharge
T8 - Forced Discharge
10. Reference to assembled battery testing requirements
N/A
11. Reference to the revised edition of the Manual of Tests and Criteria used and to amendments thereto
12. The manufacture of the cell / battery is in accordance with the documented quality management
system as required by the regulations.
13. Place, Date 14. Title, Surname, First name 15. Company stamp and signature
Version 1/2019
Page 2
