Page 1
CBCX68 SERIES NPN
CBCX69 SERIES PNP
SURFACE MOUNT
COMPLEMENTARY SILICON
SMALL SIGNAL TRANSISTORS
DESCRIPTION:
The CENTRAL SEMICONDUCTOR CBCX68 and
CBCX69 series types are complementary silicon
www.centralsemi.com
transistors manufactured by the epitaxial planar
process, epoxy molded in a surface mount package,
designed for applications requiring high current
capability.
MARKING: FULL PART NUMBER
SOT-89 CASE
MAXIMUM RATINGS: (TA=25°C) SYMBOL UNITS
Collector-Emitter Voltage V
Collector-Emitter Voltage V
Emitter-Base Voltage V
Continous Collector Current IC 1.0 A
Peak Collector Current ICM 2.0 A
Continuous Base Current IB 100 mA
Peak Base Current IBM 200 mA
Power Dissipation PD 1.2 W
Operating and Storage Junction Temperature TJ, T
Thermal Resistance ΘJA 104 °C/W
25 V
CES
20 V
CEO
5.0 V
EBO
-65 to +150 °C
stg
ELECTRICAL CHARACTERISTICS: (TA=25°C unless otherwise noted)
SYMBOL TEST CONDITIONS MIN TYP MAX UNITS
I
V
CBO
I
V
CBO
I
V
EBO
BV
IC=10µA 25 V
CBO
BV
IC=10mA 20 V
CEO
BV
IE=1.0µA 5.0 V
EBO
V
CE(SAT)
V
BE(ON)
V
BE(ON)
hFE V
hFE V
hFE V
hFE V
hFE V
fT V
IC=1.0A, IB=100mA 0.5 V
VCE=10V, IC=5.0mA 0.6 V
VCE=1.0V, IC=1.0A 1.0 V
=25V 100 nA
CB
=25V, TA=150°C 10 µA
CB
=5.0V 10 µA
EB
=10V, I
CE
=1.0V, IC=500mA (CBCX68, CBCX69) 85 375
CE
=1.0V, IC=500mA (CBCX68-16, CBCX69-16) 100 250
CE
=1.0V, IC=500mA (CBCX68-25, CBCX69-25) 160 400
CE
=1.0V, IC=1.0A 60
CE
=5.0V, IC=10mA, f=20MHz 65 MHz
CE
=5.0mA 50
C
R10 (4-January 2010)
Page 2
CBCX68 SERIES NPN
CBCX69 SERIES PNP
SURFACE MOUNT
COMPLEMENTARY SILICON
SMALL SIGNAL TRANSISTORS
SOT-89 CASE - MECHANICAL OUTLINE
www.centralsemi.com
(BOTTOM VIEW)
LEAD CODE:
1) EMITTER
2) COLLECTOR
3) BASE
MARKING:
FULL PART NUMBER
R10 (4-January 2010)
