Page 1
CBCP68 NPN
CBCP69 PNP
SURFACE MOUNT
COMPLEMENTARY
SMALL SIGNAL SILICON
TRANSISTORS
DESCRIPTION:
The CENTRAL SEMICONDUCTOR CBCP68 and
CBCP69 types are complementary silicon transistors
www.centralsemi.com
manufactured by the epitaxial planar process, epoxy
molded in a surface mount package, designed for
applications requiring high current capability.
MARKING: FULL PART NUMBER
SOT-223 CASE
MAXIMUM RATINGS: (TA=25°C) SYMBOL UNITS
Collector-Emitter Voltage V
Collector-Emitter Voltage V
Emitter-Base Voltage V
Continuous Collector Current IC 1.0 A
Peak Collector Current ICM 2.0 A
Continuous Base Current IB 100 mA
Peak Base Current IBM 200 mA
Power Dissipation PD 2.0 W
Operating and Storage Junction Temperature TJ, T
Thermal Resistance ΘJA 62.5 °C/W
ELECTRICAL CHARACTERISTICS: (TA=25°C unless otherwise noted)
SYMBOL TEST CONDITIONS MIN TYP MAX UNITS
I
V
CBO
I
V
CBO
I
V
EBO
BV
IC=10µA 25 V
CBO
BV
IC=10mA 20 V
CEO
BV
IE=1.0µA 5.0 V
EBO
V
CE(SAT)
V
BE(ON)
V
BE(ON)
hFE V
hFE V
hFE V
fT V
C
ob
IC=1.0A, IB=100mA 0.5 V
VCE=10V, IC=5.0mA 0.6 V
VCE=1.0V, IC=1.0A 1.0 V
=25V 10 µA
CB
=25V, TA=150°C 1.0 mA
CB
=5.0V 10 µA
EB
=10V, IC=5.0mA 50
CE
=1.0V, IC=500mA 85 375
CE
=1.0V, IC=1.0A 60
CE
=5.0V, IC=10mA, f=20MHz 65 MHz
CE
VCB=5.0V, IE=0, f=450kHz 25 pF
25 V
CES
20 V
CEO
5.0 V
EBO
-65 to +150 °C
stg
R5 (4-January 2010)
Page 2
CBCP68 NPN
CBCP69 PNP
SURFACE MOUNT
COMPLEMENTARY
SMALL SIGNAL SILICON
TRANSISTORS
SOT-223 CASE - MECHANICAL OUTLINE
LEAD CODE:
1) BASE
2) COLLECTOR
3) EMITTER
4) COLLECTOR
MARKING:
FULL PART NUMBER
www.centralsemi.com
R5 (4-January 2010)
