AS8201

Austria Mikro Systeme International AG

TTP/C-C1 Communications
Controller

Data Sheet

TTP/C-C1 Communications Controller Data Sheet

Austria Mikro Systeme International AG

Boot ROM

RAM_ADDRESS[10:0]

RAM_CEB

RAM_OEB

RAM_READYB

TIME_OVERFLOW

TIME_SIGNAL

TIME_TICK

XENA0

XIN0

XOUT0

RESETB

ROM_ADDRESS[16:0]

ROM_DATA[15:0]

ROM_RESETB

ROM_CEB

ROM_OEB

ROM_WEB

ROM_READY

Quarz or

Oscillator

base

Host

processor

AS8201

Key Features

• First dedicated controller supporting TTP/C (time triggered protocol class C)

• Device for building up TTP/C nodes in a TTP/C local area networks (clusters).

• Suited for dependable distributed real-time systems with guaranteed response time

• application examples:

automotive: braking, steering, vehicle dynamics control, drive train control
industry: air plane flap control, rail way points

• Bit data rate 2 Mbits/s @ clock 20 MHz, 5.0V

• Fabricated in 0.6u CMOS process, automotive temperature range of -40 to 125deg C

• 1k x 16 RAM message, status and control area

• RAM for instruction code and configuration data

• 16 bit non-multiplexed host CPU interface

• 16 bit RISC architecture

• external firmware (FLASH memory) conforming the TTP/C specification

• automatic booting after power on

• software tools, design-in support, development boards available ( http://www.tttech.com)

• 120 pin PQFP Package

Description

The TTP/C-C1 communications controller is the first integrated device supporting serial
communication according to the TTP/C specification (time triggered protocol class C). It
performs all communications tasks such as reception and transmission of messages in a
TTP/C cluster without interaction of the host CPU.
TTP/C provides mechanisms that allow the deployment in high-dependability distributed real­time systems. It provides the following services:

• predictable transmission of messages with minimal jitter

• fault-tolerant distributed clock synchronisation

• consistent membership service with small delay

• masking of single faults

Interface

RAM_DATA[15:0]

RAM_WEB

MICROTICK

Controller

network

interface

(CNI)

Reset &

Time

TTP/C-C1

protocol

processor core

Receiver

Bus

guardian

Transmitter

RXD[1:0]

BDE[1:0]
XENA1
XIN1
XOUT1

TXD[1:0]
CTS[1:0]
OE[1:0]

TTP/C
bus ­Meadia
Drivers

Interface

Instruction

memory

Network

configuration

memory

(MEDL)

TEST_SE
FTEST
FTEST_IEN
LED[7:0]

Test
Inter­face

Figure 1 Block Diagramm

Rev. NC, October 1999 Page 2 of 13

TTP/C-C1 Communications Controller Data Sheet

Austria Mikro Systeme International AG

AS8201

The CNI (controller network interface) forms a temporal firewall. It decouples the controller
network from the host subsystem by use of a dual ported RAM. This prevents the propagation
of control errors. The interface to the host CPU is implemented as 16 bit wide non-multiplexed
asynchronous bus interface.

TTP/C follows a conflict-free media access strategy called time-division-multiple access
(TDMA). This means, TTP/C deploys a time slot technique based on a global time which is
permanently synchronised. Each node is assigned a time slot in which it is allowed to perform
transmit operation. The sequence of time slots is called TDMA round, a set of TDMA rounds
forms a cluster cycle. After one cluster cycle the operation of the network repeats. The
sequence of interactions forming the cluster cycle is defined in a static time schedule, called
message-descriptor-list (MEDL). The definition of the MEDL in conjunction with the global time
determines the response time for a service request.
The membership of all nodes in the network is evaluated by the communication controller. This
information is presented in a consistent fashion to all correct cluster members. During
operation, the status of every other node is propagated within one TDMA round. The MEDL is
loaded into the configuration memory before run time when the system starts up.

Package and Pin Assignment

Type: PQFP 120, plastic quad flat package

TTP/C-C1

Communications

Controller

(TOP VIEW)

Figure 1 PQFP 120 pin package and pin assignment

Rev. NC, October 1999 Page 3 of 13

TTP/C-C1 Communications Controller Data Sheet

Austria Mikro Systeme International AG

AS8201

Pin Description

PinNr. Pin Name Dir Description
1 VDD P positive power supply
2 VSS P negative power supply
3-18 RAM_DATA[0:15] I/O DPRAM data bus, tristate
19 VDD P positive power supply
20 VSS P negative power supply
21 RAM_OEB I DPRAM output enable, active low
22 RAM_WEB I DPRAM write enable, active low
23 RAM_READYB O DPRAM ready, active low, indicates read/write operation finished
24 TIME_OVERFLOW O CNI control signal, overflow of global time
25 TIME_SIGNAL O CNI control signal, CNI time signal
26 TIME_TICK O CNI clock signal, macrotick, typically about 1us at 20 MHz clock.
27 MICROTICK O output of main clock, inverted to signal applied at pin XOUT0.
28 XENA0 I oscillator 0 (main clock) enable, active low.
29 VDD P positive power supply
30 VSS P negative power supply
31 XIN0 A analog pad from oscillator / use as input when providing external

clock

32 XOUT0 A analog pad from oscillator / leave open when providing external

clock
33 VSS P positive power supply
34 VDD P negative power supply
35 OE[0] I channel [0]: transmitter output enable
36 RXD[0] IPUchannel [0]: receiver input
37 TXD[0] O channel [0]: transmit data
38 CTS[0] O channel [0]: transmitter clear to send
39 BDE[0] O channel [0]: bus driver enable
40 RESETB I (1) main reset input signal, active low. When connected the in-

ternal power-on reset function is overridden

(2) if unconnected: an internal reset is generated after power-on.

Reset pulse duration typically 24 us.
41 TEST_SE IPDtest input: scan enable, active high
42 FTEST IPDtest input: functional test mode, active high
43 FTEST_IEN IPDtest input: instruction insertion enable, active high
44-50 LED[0:6] O test outputs:

(1) in production test used as scan chain outputs

(2) in operation: can be used as generic output port, e.g. to drive

LEDs
51 OE[1] I channel [1]: transmitter output enable
52 RXD[1] IPUchannel [1]: receiver input
53 TXD[1] O channel [1]: transmit data
54 CTS[1] O channel [1]: transmitter clear to send
55 BDE[1] O channel [1]: bus driver enable
56 XENA1 I oscillator 1 (bus guardian) enable, active low.
57 VDD P positive power supply
58 VSS P negative power supply
59 XIN1 A analog pad from oscillator / use as input when providing external

clock
60 XOUT1 A analog pad from oscillator / leave open when providing external

clock
61 VSS P positive power supply
62 VDD P negative power supply

Rev. NC, October 1999 Page 4 of 13

TTP/C-C1 Communications Controller Data Sheet

Austria Mikro Systeme International AG

AS8201

63-79 ROM_ADDRESS[0:16] O ROM address bus, range = 2^17 = 128k
80 ROM_RESETB O ROM reset line, active low
81 ROM_CEB O ROM chip enable, active low
82 ROM_OEB O ROM output enable, active low
83 ROM_WEB O ROM write enable, active low; “read” if high.
84 ROM_READY IPUROM ready, signals read operation ready, leave open when un-

used
85 VDD P positive power supply
86 VSS P negative power supply
87-94 ROM_DATA[0:7] I/O ROM data bus (lower byte)
95 VDD P positive power supply
96 VSS P negative power supply
97-

ROM_DATA[8:15] I/O ROM data bus (higher byte)
104
105 VDD P positive power supply

106 VSS P negative power supply
107-

RAM_ADDRESS[0:10] I DPRAM address bus, range = 2^11 = 2048
117
118 RAM_CEB I DPRAM chip enable, active low

119 VDD P positive power supply
120 VSS P negative power supply

I Input CMOS
I

PU

I

PD

O Output CMOS
I/O Input/Output CMOS tristate
P Power Pin
A Analog Pin

Input CMOS with pull up
Input CMOS with pull down

Electrical Specifications

Absolute Maximum Ratings ( Non Operating)

SYMBOL PARAMETER MIN MAX NOTE
VDD DC Supply Voltage -0.3 V 7.0 V
V

in

I

in

T

strg

T

sold

t

sold

H Humidity 5 % 85 %
ESD Electrostatic Discharge 1000 V

1) 300

Note: Stresses above those listed under “Absolute Maximum Ratings” may cause permanent
damage to the device. This is a stress rating only and functional operation of the device at
these or any other conditions above those indicated in the operational sections of this
specification is not implied. Exposure to absolute maximum rating conditions for extended
periods may effect device reliability (e.g. hot carrier degradation).

Input Voltage on any Pin - 0.3 V VDD + 0.3 V
Input Current on any Pin -100 mA 100 mA 25°C
Storage Temperature

Soldering Temperature

-55 oC 150 oC
260 oC

1)

Soldering Time 10 sec Reflow and Wave

HBM: R = 1.5 kΩ, C = 100 pF

o

C all ceramic packages and DIL plastic packages, 260 oC for surface mounting plastic packages

Rev. NC, October 1999 Page 5 of 13

TTP/C-C1 Communications Controller Data Sheet

Austria Mikro Systeme International AG

AS8201

Recommended Operating Conditions

PARAMETER SYMBOL MIN TYP MAX NOTE
DC Supply Voltage VDD 4.5 V 5.0 V 5.5 V

1)

Circuit Ground VSS 0.0 V 0.0 V 0.0 V
Static Supply Current IDDS ----

Operating Supply

IDD ---- 110 mA 160 mA fCLK = 20 MHz, VDD = 5.5 V

40 µA 100 µA

2)

3)

Current
Main clock frequency CLK 5 MHz 20 MHz oscillator pins XIN0, XOUT0
Bus Guardian clock
frequency
Ambient Temperature T

1) The input and output parameter values in this table are directly related to ambient temperature and DC supply
voltage. A temperature range other Ta
affect these values and must be evaluated extra.

2) Static supply current IDDS is exclusive of input/output drive requirements and is measured at maximum VDD
with the clocks stopped and all inputs tied to VDD or VSS, configured to draw minimum current.

3) Operating current is exclusive of input/output drive requirements and is measured at maximum VDD and maxi­mum clock frequency 20 MHz.

CLK2 4 MHz 16 MHz oscillatpr pins XIN1, XOUT1

a -40 oC +125 oC

min

to Ta

or a supply voltage range other than VDD

max

1)

to VDD

min

max

will

DC Characteristics and Voltage Levels

CMOS I/O levels for specified voltage and temperature range unless otherwise noted.

Inputs Pins

Pin Name Vil Vih Iil (1) Iih(2) NOTE

max min min max min max
All inputs and IO pins
(except: ROM_READY,

30%

VDD

70%
VDD

NA -1.0 µANA 1.0

µA

CMOS input (3)

RXD[0], RXD[1], FTEST,
FTEST_IEN, TEST_SE)
ROM_READY, RXD[0],
RXD[1]
FTEST, FTEST_IEN,
TEST_SE

Notes:

1) Iil ist tested at VDDmax and Vin = 0

2) Iih ist tested at VDDmax and Vin = VDDmax

3) CMOS input levels are in percentage of VDD

4)

30%

VDD

30%

VDD

70%
VDD
70%
VDD

-50

µA

-160 µANA NA CMOS with pull

NA NA 30

µA

160

µA

up (3)
CMOS with pull
down (3)

Output Pins

Pin Name Vol Voh Iol (1) Ioh(2) Ioz(3) NOTE

V V mA mA

All output pins

0.4 4.0 4.0 -4.0 NA CMOS output
(except XOUT0,XOUT1)
All I/O pins 0.4 4.0 4.0 -4.0 +/-10 CMOS output, Tristate

1) Vol, Iol is tested at VDD = 4.5V

2) Voh, Ioh is tested at VDD = 4.5V

3) Ioz is tested at VDD = 5.5V

µA

Rev. NC, October 1999 Page 6 of 13

TTP/C-C1 Communications Controller Data Sheet

Austria Mikro Systeme International AG

AS8201

AC Characteristics

Clock applied at XOUT0, resp. XOUT1.

PARAMETER SYMBOL PIN MIN MAX NOTE
data in setup
time
data output
valid

t

setup

all IN,
all IO

tdav all OUT,

all IO

20 ns vs. Falling edge of clk @XOUT0, XOUT1

35 ns vs. rising edge of clk @ XOUT0, XOUT1

Application Information

ROM Interface

Pin name mode width comment

ROM_DATA inout (tri) 16 ROM data bus
ROM_ADDRESS out 17 ROM address bus
ROM_CEB out 1 ROM chip enable
ROM_WEB out 1 ROM write enable
ROM_OEB out 1 ROM output enable
ROM_READY in 1 ROM ready
ROM_RESETB out 1 external reset line

Table 1 ROM Interface Ports

The timing and behaviour of the ROM Interface is designed to operate with the AM29F200
Flash EPROM or compatible devices. For detailed timing information see [AM29F200] 1. Figure
2 shows the connection between TTP/C-C1 controller and the AM29F200 Flash. The contents
of the Flash memory is loaded into the instruction memory by a boot sequencer automatically
after power on.

AM29F200

DQ0-DQ15

16

rom_resetb rom_web rom_ceb rom_oeb rom_address

CE

OE A0-A16

17

RY/BYRESET WE

rom_readyrom_data

BYTE

VCC

TTA-C1

Figure 2 ROM Interface

Host CPU Interface

The host CPU interface also referred as CNI (controller network interface) connects the
application circuitry to the TTP/C network. As shown in Table 2 all RAM_-lines provide
asynchronous read/write access to a dual ported RAM. There are no setup/hold constraints
referred to the microtick (main clock “clk”). The signals have to be applied for certain duration
according to Table 3. So, the applied signals get synchronised with the microtick. The TIME_-

1

[AMD96] Advanced Micro Devices, "Flash Memory Products - 1996 Data Book/Handbook", Advanced Micro Devices Inc., 1996.

2

The label TTA-C1 stands for TTP/C-C1 in the following diagrams

2

Rev. NC, October 1999 Page 7 of 13

TTP/C-C1 Communications Controller Data Sheet

Austria Mikro Systeme International AG

AS8201

lines signal to host CPU the global synchronous time of the TTP network and determine when
to deliver, resp. to fetch data from the host interface. One of the lines may be connected to a
interrupt inputs of the host CPU.

Pin Name mode width comment

RAM_ADDRESS in 11 DPRAM address bus, 11 bit
RAM_DATA inout (tri) 16 DPRAM data bus, 16 bit
RAM_CEB in 1 DPRAM chip enable
RAM_WEB in 1 DPRAM write enable
RAM_OEB in 1 DPRAM output enable
RAM_READYB out 1 DPRAM ready
TIME_OVERFLOW out 1 overflow of global time
TIME_SIGNAL out 1 CNI time signal
TIME_TICK out 1 macrotick

Table 2 Host Interface Ports

t

ct

microtick

t

rwct

t

ram_ceb

ce

ram_web

t

a

ram_address XXX

ram_data

address stable

XXX

t

dv

Figure 3: Read Cycle Timing

Addresses and RAM_WEB have to be stable before the falling edge of RAM_CEB. RAM_CEB
has to be applied for 2 microticks. Addresses and RAM_WEB have to be applied for 3
microticks. Data can be read from RAM_DATA after 6 microticks. RAM_OEB drives the result
of the (last) read operation to the RAM_DATA bus.

Rev. NC, October 1999 Page 8 of 13

TTP/C-C1 Communications Controller Data Sheet

Austria Mikro Systeme International AG

t

AS8201

ct

microtick

t

ce

ram_ceb

ram_web

t

a

ram_address XXX

ram_data

address stable

data stable

XXXX

t

rwct

Figure 4: Write Cycle Timing

Addresses, data and RAM_WEB have to be stable before the falling edge of RAM_CEB.
RAM_CEB has to be applied for 2 microticks. Addresses, data, and RAM_WEB have to be
applied for 3 microticks.

Parameter Symbol Min Typ Max

controller cycle time t
duration of chip enable t
address time t
data valid time t
read write cycle time t

Table 3: Host Interface Timing

ct
ce
a
dv
rwct

87.5ns 100ns 112.5ns

137.5ns 150ns 162.5ns

50ns

300ns
300ns

Reset and Oscillator

Pin Name mode width Comment

XIN0 in 1 controller oscillator input
XENA0 in 1 controller clock enable
XOUT0 out 1 controller oscillator output
XIN1 in 1 bus guardian oscillator input
XOUT1 out 1 bus guardian oscillator output
XENA1 in 1 bus guardian clock enable
RESETB in 1 external reset
MICROTICK out 1 controller clock (inverted)

Table 4: Reset and Oscillator Ports

External Reset Signal

To issue a reset of the chip the RESETB port has to be driven low for at least 200µs. After
power-up the reset must overlap the build-up time of the oscillator circuit.

Rev. NC, October 1999 Page 9 of 13

TTP/C-C1 Communications Controller Data Sheet

Austria Mikro Systeme International AG

AS8201

Integrated Power-On Reset

An internal Power-On Reset generator is integrated. When The supply voltage ramps up, the
internal reset signal is kept active (low) for about 24 us typical. To activate this function the
RESETB must be left unconnected.

Parameter Symbol Min Typ Max Unit

supply voltage slope dV/dt 250 - - kV/s
power on reset active time after VDD >

t

pon_res

16 24 34 us
1,2V
external reset low to internal high t
external reset high to internal low t

res_fall
reset_rise

81 118 173 ns

130 129 104 ns

Oscillator circuitry

The internal oscillator cell requires an external quartz or an external oscillator respectively
(Figure 5, Figure 6). The internal controller clock is available at the port MICROTICK (inverted
to clock signal applied at XOUT0).

VSS

20Mhz

XOUT0XENA0

XIN0

TTA-C1

VSS

XENA1

XIN1

16Mhz

XOUT1

XIN0

20Mhz

OSC

XOUT0XENA0

VSS

XENA0 XOUT0 XIN0 XENA1 XOUT1 XIN1

TTA-C1

Figure 5: Quartz Circuit Figure 6: Oscillator Circuit

TTP/C Bus Interface

Pin Name mode width comment
CTS out 2 transmitter clear to send
OE in 2 transmitter output enable
TXD out 2 transmit data
RXD in 2 receiver input
BDE out 2 bus driver enable

Table 5: TTP/C Bus Interface Ports

VSS

XENA1

XIN1

16Mhz

OSC

XOUT1

The controller can be connected to transceivers with recessive state and to transceivers with
three-state outputs, respectively. For safe operation of the device the bus driver enable signal
BDE must be connected with output enable OE. To deactivate the bus guardian the OE signal
has to be tied to VCC. Applications with recessive state transceivers do not use the CTS
signal.

Rev. NC, October 1999 Page 10 of 13

TTP/C-C1 Communications Controller Data Sheet

Austria Mikro Systeme International AG

AS8201

BUS0 BUS1

CL CH

PCA82C250

TXD RXD

OE[0] CTS[0]TXD[0] RXD[0]BDE[0]

TTA-C1

CL CH

PCA82C250

TXD RXD

OE[1] CTS[1]TXD[1] RXD[1]BDE[1]

BUS0

CL CH

MAX1487

DI DO

OE[0] CTS[0]TXD[0] RXD[0]BDE[0]

BUS1

DERE

OE[1] CTS[1]TXD[1] RXD[1]BDE[1]

TTA-C1

CL CH

MAX1487

DI DO

Figure 7: Transceivers with Recessive State Figure 8: Transceivers with Three-State Output

Test Interface

Pin Name mode width comment

FTEST in (pull down) 1 functional test mode
FTEST_EIN in (pull down) 1 instruction insertion enable
LED out 7 LED vector
TEST_SE in (pull down) 1 scan enable

Table 6: Test Interface Ports

DERE

The ports of the test interface support the manufacturing test of the chip. In the application
environment FTEST, FTEST_IEN, and TEST_SE are not connected. The LED bus can be
used as a universal output port. The driver strength of the LED ports is 4mA.

Rev. NC, October 1999 Page 11 of 13

TTP/C-C1 Communications Controller Data Sheet

Austria Mikro Systeme International AG

Quartz

MAX1487

Bus0

Bus1

AS8201

Principles of Operation

The next 2 figures show a typical TTP/C node as it is to be deployed in a TTP/C
communication cluster. The circuit example uses the MAX1487 as driver, the host CPU may
be selected by the user and a 29F200 Flash memory. For detailed information the protocol on
application programming refer to the manuals provided by TTTech Computer Technik GmbH.

Sensor / Actor interface

Host CPU

Controller network interface (CNI)

Boot ROM

(external)

TTP/C-C1

controller chip

TTP/C bus

TTP/C

Protocol

processor

Bus guardian - Rx / Tx

Media Divers

Instruction

memory

Configuration

memory
(MEDL)

Figure 9 Typical node in a TTP/C cluster using the TTP/C-C1

RAM_DATA[15:0]
RAM_ADDRESS[10:0]

Host
CPU

20 MHz
Quartz

Flash

EPROM

29F200

RAM_CEB
RAM_OEB
RAM_WEB
RAM_READYB
TIME_OVERFLOW
TIME_SIGNAL
TIME_TICK

MICROTICK
XENA0
XIN0
XOUT0

RESETB
ROM_ADDRESS[16:0]

ROM_DATA[15:0]
ROM_RESETB
ROM_CEB
ROM_OEB
ROM_WEB
ROM_READY

TTP/C-C1

controller

TEST_SE

FTEST_IEN

TXD[0]

RXD[0]

CTS[0]

BDE[0]

OE[0]

TXD[1]

RXD[1]

CTS[1]

BDE[1]

OE[1]

XENA1

XIN1

XOUT1

FTEST

LED[7:0]

RE
DI CL

DO CH
DE

MAX1487

RE
DI CL

DO CH
DE

16 MHz

Figure 10 Typical application circuit

Rev. NC, October 1999 Page 12 of 13

TTP/C-C1 Communications Controller Data Sheet

Austria Mikro Systeme International AG

AS8201

Ordering Information

Part Number: AS8201
Part Name: TTP/C-C1 Communications Controller
Package: PQFP 120

Support

Software tools, hardware development boards, evaluation systems and extensive support on
TTP/C system integration as well as consulting is provided by

TTTech Computertechnik GmbH
Time-Triggered Technology

Schönbrunnerstraße 7
A-1040 Vienna
Austria

Voice: [phone] - 0
Fax: [phone] - 90
email: [e-mail]
web: http://www.tttech.com

TTP is a trademark of FTS Computertechnik Ges.m.b.H.
TTTech is a trademark of TTTech Computertechnik GmbH.

(c) 1999 Austria Mikro Systeme International AG and TTTech Computertechnik GmbH.
All rights reserved.

Copyright  1999, Austria Mikro Systeme International AG, Schloß Premstätten, 8141 Unterpremstätten, Austria.
Telefon [phone], Telefax [phone], E-Mail [e-mail]
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any
means, without the prior permission in writing by the copyright holder. To the best of its knowledge, Austria Mikro Systeme International
asserts that the information contained in this publication is accurate and correct.

Rev. NC, October 1999 Page 13 of 13
