Analog Master Slice
AN9D, AN9E, AN9F Series
Analog master slice IC series
■ Overview
The AN9D, AN9E and AN9F series are master slice ICs of bipolar process, which enables you to integrate an analog
circuit easily onto a single chip. A custom IC can be made by placing a wired pattern designed in line with the customer's
analog circuit onto a master slice.
Starting from a wafer on which a most part of IC diffusion processes are already finished, you can shorten an IC pilot
fabrication considerably. Further, placement of elements and inter-element wiring are done automatically by a computer, which results in short period of pattern designing and thereby developing a custom IC in a short period.
■ Features
• High design flexibility
• Easy circuit constant design because of setting resistance or capacitance to an arbitrary value.
• Free setting of contacts between a substrate and GND wiring prevents from operation error to be caused by floating
of substrate potential.
• Usable for multi power source because a resistor island potential can be set for each unit.
• Builds in a lateral type PNP transistor of high reverse breakdown voltage between base and emitter, or a collector
wall type NPN transistor of excellent saturation characteristics. (AN9DA00, AN9DB00, AN9DF00)
• Short development period
• Due to a full automatic layout design, a sample is available in one month from a completion of a circuit diagram.
• Applicable to a small quantity production item
• Possible to develop a custom IC for small quantity production due to a low development cost.
■ Development Flow
Matsushita side
Customer side
System design
Full automatic
layout
Circuit design
Mask layout
EWS
Fabricated wafer
Check
Test specification, etc.
for small quantity production
Full
custom
Master
slice
1week 3weeks
Wiring, assembly
Wired mask only
Drastic shrinkage of TAT
Layout
8weeks
1 000 elements in case
of general-use process
Diffusion,
assembly
6weeks
Selection
Chip Evaluation
1
Page 2
AN9D, AN9E, AN9F Series Analog Master Slice
■ Product Mix
Series name
Supply
voltage
f
T(max)
AN9D series to 12 V 2.6 GHz 14.4 V 100 to 250 1.0 GHz 14.4 V 66 to 200 For low power dissipation/
AN9E series
to 12 V 3.5 GHz 14.4 V 80 to 250 1.5 GHz 14.4 V 50 to 130 For Bi-CMOS IC
AN9F series to 30 V 300 MHz 30 V 80 to 250 9 MHz 30 V 80 to 350 For high breakdown
■ Basic Block Configuration (AN9DA00, AN9DB00, AN9DF00)
Element characteristics
NPN transistor PNP transistor Remarks
BV
CEO
h
FE
f
T(max)
BV
CEO
h
FE
high speed operation IC
voltage IC
SP2 resistor
(variable)
SP resistor
(fixed)
PNP transistor
(lateral type)
PNP transistor
(vertical type)
NPN transistor
(collector wall type)
SP resistor
(fixed)
Capacitance
SP2 resistor
(variable)
2
Page 3
Analog Master Slice AN9D, AN9E, AN9F Series
• AN9D series (VCC = to 12 V, f
T(max)
= 2.6 GHz)
• High speed low power dissipation process
• Constant-variable resistor and capacitor elements built in
• Large current transistor built in (AN9DA00, AN9DB00, AN9DF00)
• Optimal for a control-system application due to built-in collector wall type NPN transistors and lateral PNP transistors (AN9DA00, AN9DB00, AN9DF00)
• Optimal for signal processing application due to built-in high speed NPN transistors and vertical PNP transistors
(AN9DC00, AN9DD00, AN9DE00)
• IIL element built-in (AN9DF00)
Product name AN9DA00 AN9DB00 AN9DC00 AN9DE00 AN9DD00
*
AN9DF00 Remarks
Pad count 28 36 55 64 75 32
Total element count 1 287 2 42 4 3 854 5 106 6 60 2 1 607
Transistor count 306 600 920 1 288 1 610 306
A11 320 448 560 Basic size
A21 160 224 280 Double size
NPN
A62P 8 8 8 62 times size
B11 126 252 126 Basic size (CW winding)
LA1 84 168 84 Basic size (Lateral type)
LA4S 4 4 4 8 times size (Lateral type)
PNP
V11 84 168 320 448 560 84 Basic size (Vertical type)
V21 120 168 210 Double size (Vertical type)
Gate countIIL 320
Resistor count 969 1 800 2 854 3 706 4 852 969
5 kΩ 474 888 1 408 1 728 2 440 474
SP
10 kΩ 198 336 480 640 800 198
SP2 2.5 kΩ 297 576 966 1 338 1 612 297 Resistance variable
Capacitor count 5 pF 12 24 80 112 140 12
Note)*: Under development
3
Page 4
AN9D, AN9E, AN9F Series Analog Master Slice
• AN9E series (VCC = to 12 V, f
T(max)
= 3.5 GHz)
• Bi-CMOS process adopted
• Constant-variable resistor and capacitor elements built in
• Gate array and standard cell built in
• Zener zap elements built in
Product name AN9EA00*AN9EB00
*
Pad count 40 55
Total element count 8 830 14 033
Transistor count 900 1 402
N21 420 588 Double size
NPN N54 20 34 40 times size
A42G 20 96
P21 420 588 Double size (Vertical type)
PNP
V42G 20 96
Resistor count 5 016 7 138
40 kΩ 90 160
SP 10 kΩ 1 440 2 016
5 kΩ 1 680 2 352
5 kΩ 1 086 1 602 Resistance variable
PS
2 kΩ 720 1 0 0 8 Resistance variable
Capacitor count 5 pF 60 84
Diode count 30 42
ZD1 30 42 Zener zap element
MOS count 12 32
N-MOS 6 16 60/2
P-MOS 6 16 30/2
Gate array count 2 800 5 400
LOGIC 2 800 5 400 Use rate 35% or less
Standard cell count 12 19
Analog SW 6 12
Analog SW 4 4
8-bit DAC 1 1
Oscillation circuit 1 2
Note)*: Under development
Remarks
4
Page 5
Analog Master Slice AN9D, AN9E, AN9F Series
• AN9F series (V
= to 30 V, f
CC
= 300 MHz)
T(max)
• High voltage process adopted
• Constant-variable resistor and capacitor elements built in
• Built-in Zener diode for simplified reference voltage
• Output-circuit-exclusive three blocks are built in
• ZAP-adopted reference-voltage-exclusive one block is built in
Product name AN9FA00 Remarks
Pad count 36
Total element count 1 655
Transistor count 308
N11X 72 Basic size
NPN W11X 72 Basic size (surrounded with DN)
N100X 8 100 times size
YA1 144 Basic size (Lateral type)
PNP
YX1DP 12 Emitter and collector are surrounded with DN
Resistor count 1 308
2 kΩ 1 068 Resistance variable
SP
5 kΩ 48 Resistance variable
10 kΩ 136
PW
50 kΩ 56
Capacitor count 7.5 pF 24 Capacitance variable
Diode count ZD ZB2 15 Bulk Zener diode
Special block Output circuit 3 250 times size transistor built-in
Reference power supply circuit 1 2.5 V reference power supply circuit
■ Circuit Library
General-use basic circuits are available as libraries.
Circuit name Contents Features Remarks
Op-amp.1 General-use Wide output D-range: 0.2 V to V
Single power supply operational amp. Low power consumption: ICC = 0.5 mA
Op-amp.2 High speed High speed : Cutoff frequency = 20 MHz AN9D series
Highly stable operational amp. : Slew rate = 100 V/µs
Op-amp.3 General-use Low power consumption: I
Single power supply operational amp.
Op-amp.4 General-use High gain: Voltage gain = 107 dB AN9D series
Single power supply operational amp. High stability: Phase margin = 43°
Comp1 Low power consumption Low power consumption: I
Single power supply comparator High speed: tr / tf = 0.15 µs/0.3 µs
Comp2 Single power supply High speed: t
= 0.015 µs AN9D series
d
High speed comparator
Reg1 General-use High temp. stability: 150 ppm/degree or less AN9D series
Stabilized power supply Wide output voltage range: 1.3 V to VCC − 0.5 V
− 0.5 V AN9D series
CC
= 0.15 mA AN9D series
CC
= 0.1 mA AN9D series
CC
5
Page 6
AN9D, AN9E, AN9F Series Analog Master Slice
■ Package Table
Series name AN9DX00 series AN9EX00 series AN9FX00
Master name
Package Pin count
DIL
SDIL 28 ●● ● ●●●
SO
QPF 48 ●●●
QFN
AN9DA00 AN9DB00 AN9DC00AN9DD00 AN9DE00 AN9DF00 AN9EA00 AN9EB00 AN9FA00
16 ●
18
20
22 ●● ●
24 ●
28 ●● ●
20 ●●
22 ●●
24 ●● ●
30 ●● ●
42 ●● ●
52 ●● ●●
18
20 ●● ●
22
24 ●●
28 ●●● ●●●●●
36 ●● ● ●
32 ●●
44 ●
64 ●●●● ●●
80 ●●
24 ●
44 ●●● ●●●●
