Digital PAL/NTSC Video Encoder

with Six DACs (10 Bits), Color Control

a

FEATURES

1

ITU-R

BT601/656 YCrCb to PAL/NTSC Video Encoder
Six High Quality 10-Bit Video DACs
SSAF™ (Super Sub-Alias Filter)
Advanced Power Management Features

PC’98-Compliant (TV Detect with Polling and Auto

Shutdown to Save On Power Consumption)
Low Power DAC Mode
Individual DAC ON/OFF Control
Variable DAC Output Current (5 mA–36 mA)
Ultralow Sleep Mode Current

Hue, Brightness, Contrast and Saturation Controls
CGMS (Copy Generation Management System)
WSS (Wide Screen Signalling)
NTSC-M, PAL-M/N, PAL-B/D/G/H/I, PAL-60
YUV Betacam, MII and SMPTE Output Levels
Single 27 MHz Clock Required (ⴛ2 Oversampling)
80 dB Video SNR
32-Bit Direct Digital Synthesizer for Color Subcarrier
Multistandard Video Output Support:

Composite (CVBS)
Component S-Video (Y/C)
Component YUV
EuroSCART RGB
Component YUV + CHROMA + LUMA + CVBS
EuroSCART Output RGB + CHROMA + LUMA + CVBS

Programmable Clamping Output Signal
Advanced Programmable Power-On Reset Sequencing
Video Input Data Port Supports:

CCIR-656 4:2:2 8-Bit Parallel Input Format
SMPTE 170M NTSC-Compatible Composite Video
ITU-R BT.470 PAL-Compatible Composite Video

Luma Sharpness Control
Programmable Luma Filters (Low-Pass [PAL/NTSC],

Notch [PAL/NTSC], Extended [SSAF], CIF and QCIF)

Programmable Chroma Filters (Low-Pass [0.65 MHz,

1.0 MHz, 1.2 MHz and 2.0 MHz], CIF and QCIF)

Programmable VBI (Vertical Blanking Interval)
Programmable Subcarrier Frequency and Phase
Programmable LUMA Delay
CCIR and Square Pixel Operation
Integrated Subcarrier Locking to External Video Source

and Enhanced Power Management

ADV7172/ADV7173*

Color Signal Control/Burst Signal Control
Interlaced/Noninterlaced Operation
Complete On-Chip Video Timing Generator
Programmable Multimode Master/Slave Operation
Macrovision AntiTaping Rev 7.01 (ADV7172 Only)
Closed Captioning Support
Teletext Insertion Port (PAL-WST)
On-Board Color Bar Generation
On-Board Voltage Reference
2-Wire Serial MPU Interface (I
Single Supply +5 V or +3.3 V Operation
Small 48-Lead LQFP Package

APPLICATIONS
High Performance DVD Playback Systems, Portable

Video Equipment including Digital Still Cameras and
Laptop PCs, Video Games, PC Video/Multimedia and
Digital Satellite/Cable Systems (Set-Top Boxes/IRD)

GENERAL DESCRIPTION

The ADV7172/ADV7173 is an integrated Digital Video En­coder that converts digital CCIR-601 4:2:2 8-bit component
video data into a standard analog baseband television signal
compatible with world wide standards.

There are six DACs available on the ADV7172/ADV7173. In
addition to the Composite output signal there is the facility to
output S-VHS Y/C Video, RGB Video and YUV Video.

The on-board SSAF (Super Sub-Alias Filter), with extended
luminance frequency response and sharp stopband attenuation,
enables studio quality video playback on modern TVs, giving
optimal horizontal line resolution. An additional sharpness
control feature allows extra luminance boost on the frequency
response.

An advanced power management circuit enables optimal control
of power consumption in both normal operating modes and
power down or sleep modes. A PC’98-Compliant autodetect
feature has been added to allow the user to determine whether
or not the DACs are correctly terminated. If not, the ADV7172/
ADV7173 flags that they are not connected through the Status
bit and provides the option of automatically powering them
down, thereby reducing power consumption.

2C®

Compatible and Fast I2C)

2

NOTES
*This device is protected by U.S. Patent Numbers 4,631,603, 4,577,216, 4,819,098 and other intellectual property rights.

1

ITU-R and CCIR are used interchangeably in this document (ITU-R has replaced CCIR recommendations).

2

The Macrovision anticopy process is licensed for noncommercial home use only, which is its sole intended use in the device. Please contact sales office for latest

Macrovision version available.
SSAF is a trademark of Analog Devices, Inc.
I2C is a registered trademark of Philips Corporation.

REV. A

Information furnished by Analog Devices is believed to be accurate and
reliable. However, no responsibility is assumed by Analog Devices for its
use, nor for any infringements of patents or other rights of third parties
which may result from its use. No license is granted by implication or
otherwise under any patent or patent rights of Analog Devices.

One Technology Way, P.O. Box 9106, Norwood, MA 02062-9106, U.S.A.
Tel: [phone] World Wide Web Site: http://www.analog.com
Fax: [phone] © Analog Devices, Inc., 1999

ADV7172/ADV7173

FUNCTIONAL BLOCK DIAGRAM

HSYNC

FIELD/

VSYNC

BLANK

RESET

TTX

TTXREQ

V

COLOR

DATA

CLOCK CSO_HSO VSO

PAL NTSC

VIDEO TIMING

GENERATOR

TELETEXT

INSERTION BLOCK

AA

8

P0

4:2:2 TO

INTER-

POLATOR

P7

4:4:4

8

MATRIX

8

ADV7172/ADV7173

YCrCb

TO

YUV

CLAMP

CONTRAST CONTROL

Y

8

U

V

SATURATION CONTROL

8
8

SCLOCK SDATA

I2C MPU PORT

BRIGHTNESS AND

+

ADD SYNC

+

INTERPOLATOR

+

ADD BURST

+

INTERPOLATOR

CONTROL CIRCUIT

SCRESET/RTC

REAL-TIME

ALSB

PROGRAMMABLE

10

SHARPNESS

10

PROGRAMMABLE

10

The ADV7172/ADV7173 also supports both PAL and NTSC
square pixel operation. The parts also incorporate WSS and
CGMS-A data control generation.

The ADV7172/ADV7173 is designed with four color controls
(hue, contrast, brightness and saturation). All YUV formats
(SMPTE, MII and Betacam) are supported in both PAL and
NTSC.

The output video frames are synchronized with the incoming
data Timing Reference Codes. Optionally the encoder accepts
(and can generate) HSYNC , VSYNC and FIELD timing
signals. These timing signals can be adjusted to change pulse­width and position while the part is in the master mode. The
Encoder requires a single two times pixel rate (27 MHz) clock
for standard operation. Alternatively the Encoder requires a

24.54 MHz clock for NTSC or 29.5 MHz clock for PAL square
pixel mode operation. All internal timing is generated on-chip.

HSO/CSO and VSO TTL outputs, synchronous to the analog
output video, are also available. A programmable CLAMP
output signal is also available to enable clamping in either the
front or back porch of the video signal.

A separate teletext port enables the user to directly input tele­text data during the vertical blanking interval.

The ADV7172/ADV7173 modes are set up over a two wire
serial bidirectional port (I

2

C-Compatible) with two slave ad­dresses. Functionally the ADV7173 and ADV7172 are the same
with the exception that the ADV7172 can output the Macrovi­sion anticopy algorithm.

The ADV7172/ADV7173 is packaged in a 48-lead LQFP pack­age (1.4 mm thickness).

DATA PATH DESCRIPTION

For PAL B, D, G, H, I, M, N and NTSC M, N modes, YCrCb
4:2:2 Data is input via the CCIR-656-Compatible Pixel Port at
a 27 MHz Data Rate. The Pixel Data is demultiplexed to form
three data paths. Y typically has a range of 16 to 235, Cr and

M

10

10

U

L
T

I
P
L
E
X
E

R

M
U
L
T

I

P
L
E
X
E
R

10-BIT

10

10-BIT

10

10-BIT

DAC

CONTROL

BLOCK

10

10-BIT

10

10-BIT

10

10-BIT

DAC

CONTROL

BLOCK

DAC

DAC

DAC

DAC

DAC

DAC

DAC A

DAC B

DAC C

V

REF

R

SET2

COMP2

DAC E

DAC F

DAC D

R

SET1

COMP1

LUMA

FILTER

+

FILTER

CHROMA

FILTER

GND

YUV TO

RBG

MATRIX

+

YUV

LEVEL

CONTROL

BLOCK

MODULATOR

+

HUE

CONTROL

10 10

SIN/COS

DDS BLOCK

10

10

10

10

10

Cb typically have a range of 128 ± 112; however, it is possible

to input data from 1 to 254 on both Y, Cb and Cr. The ADV7172/
ADV7173 supports PAL (B, D, G, H, I, N, M) and NTSC
(with and without pedestal) standards. The Y data is then ma­nipulated by being scaled for contrast control and a setup level
is added for brightness control. The Cr, Cb data is also scaled
and saturation control is added. The appropriate Sync, Blank
and Burst levels are then added to the YCrCb data. Macrovi­sion AntiTaping (ADV7172 only), Closed-Captioning and
Teletext levels are also added to Y, and the resultant data is
interpolated to a rate of 27 MHz. The interpolated data is fil­tered and scaled by three digital FIR Filters.

The U and V Signals are modulated by the appropriate sub­carrier sine/cosine phases and a phase offset may be added onto
the color subcarrier during active video to allow hue adjustment.
The resulting U and V signals are then added together to make
up the chrominance signal. The luma (Y) signal can be delayed
1–3 luma cycles (each cycle is 74 ns) with respect to the chroma
signal. The luma and chroma signals are then added together to
make up the composite video signal. All edges are slew rate
limited.

The YCrCb data is also used to generate RGB data with appro­priate Sync and Blank levels. The YUV levels are also scaled to
output the suitable SMPTE or Betacam levels.

There are six DACs on the ADV7172/ADV7173. Three of these
DACs are capable of providing 34.66 mA of current. The other
three DACs provide 8.66 mA each.

The six l0-bit DACs can be used to output:

1. Composite Video + RGB Video + LUMA + CHROMA.

2. Composite Video + YUV Video + LUMA + CHROMA.

Alternatively, each DAC can be individually powered off if not
required. A complete description of DAC output configurations
is given in Appendix 8.

Video output levels are illustrated in Appendix 6.

(continued on page 11)

–2– REV. A

SPECIFICATIONS

(VAA = +5 V ⴞ 5%1, V

5 V SPECIFICATIONS

unless otherwise noted)

Parameter Test Conditions

= 1.235 V, R

REF

= 600 ⍀ unless otherwise noted. All specifications T

SET1,2

1

Min Typ Max Units

ADV7172/ADV7173

STATIC PERFORMANCE

Resolution (Each DAC) 10 Bits
Accuracy (Each DAC)
Integral Nonlinearity
Differential Nonlinearity

3

3

Guaranteed Monotonic ±1.0 LSB

±1.0 LSB

DIGITAL INPUTS

Input High Voltage, V
Input Low Voltage, V
Input Current, I
Input Capacitance, C

INL

IN

IN

INH

V

= 0.4 V or 2.4 V ±1 µA

IN

2V

0.8 V

10 pF

DIGITAL OUTPUTS

Output High Voltage, V
Output Low Voltage, V

OL

OH

I
I

= 400 µA 2.4 V

SOURCE

= 3.2 mA 0.4 V

SINK

Three-State Leakage Current 10 µA

Three-State Output Capacitance 10 pF

ANALOG OUTPUTS

Output Current (DACs A, B, C)
Output Current (DACs A, B, C)
Output Current (DACs D, E, F)
Output Current (DACs D, E, F)
DAC-to-DAC Matching (DACs A, B, C)
DAC-to-DAC Matching (DACs D, E, F)
Output Compliance, V
Output Impedance, R
Output Capacitance, C

OC

OUT

OUT

4

5

6

5

R

= 150 Ω, RL = 37.5 Ω 33 34.7 37 mA

SET1

R

= 1041 Ω, RL = 262.5 Ω 5mA

SET1

R

= 600 Ω, RL = 150 Ω 8.25 8.66 9.25 mA

SET2

R

= 1041 Ω, RL = 262.5 Ω 5mA

SET2

7

7

1 4.0 %
1 4.0 %

0 +1.4 V

30 kΩ

I

= 0 mA 30 pF

OUT

VOLTAGE REFERENCE

Reference Range, V

REF

I

VREFOUT

= 20 µA 1.112 1.235 1.359 V

POWER REQUIREMENTS

V

AA

Normal Power Mode

I

DAC

I

DAC

I

CCT

Low Power Mode

I

DAC

I

DAC

I

CCT

Sleep Mode

I

DAC

I

CCT

(max)
(min)

10

(max)
(min)

10

12

13

8, 9

8, 9

11

11

R

= 600 Ω 59 65 mA

SET1,2

R

= 1041 Ω 30 mA

SET1,2

R

= 150 Ω 64 mA

SET1

4.75 5.0 5.25 V

78 90 mA

15 mA
78 90 mA

0.1 µA

0.1 µA

Power Supply Rejection Ratio COMP = 0.1 µF 0.01 0.5 %/%

NOTES

1

The max/min specifications are guaranteed over this range. The max/min values are typical over 4.75 V to 5.25 V.

2

Temperature range T

3

Characterized by design.

4

Full

drive into 75 Ω doubly terminated load.

5

Minimum drive current (used with buffered/scaled output load).

6

Full drive into 150 Ω load.

7

Specification guaranteed by characterization.

8

I

is the total current (“min” corresponds to 5 mA output per DAC, “max” corresponds to 8.66 mA output per DAC ) to drive DACs A, B, C, D, E, F. Turning off

DAC

individual DACs reduces I

9

All six DACs on (DAC A, B, C, D, E, F).

10

I

(Circuit Current) is the continuous current required to drive the device.

CCT

11

Only large DACs (DACs A, B, C) on per low power mode.

12

Total DAC current in Sleep Mode.

13

Total continuous current during Sleep Mode.

Specifications subject to change without notice.

to T

MIN

: 0°C to +70°C.

MAX

correspondingly, also DACs A, B, C can be configured to output a max current of 37 mA but DAC D, E, F must be turned off.

DAC

MIN

to T

MAX

2

–3–REV. A

ADV7172/ADV7173–SPECIFICATIONS

(VAA = +3.0 V–3.6 V1, V

3.3 V SPECIFICATIONS

unless otherwise noted)

Parameter Test Conditions

STATIC PERFORMANCE

3

Resolution (Each DAC) 10 Bits
Accuracy (Each DAC)
Integral Nonlinearity 1.0 LSB
Differential Nonlinearity Guaranteed Monotonic 1.0 LSB

DIGITAL INPUTS

Input High Voltage, V
Input Low Voltage, V
Input Current, I
Input Capacitance, C

DIGITAL OUTPUTS

Output High Voltage, V
Output Low Voltage, V

3

INH

INL

IN

IN

3

OH

OL

V

I
I

Three-State Leakage Current 10 µA

Three-State Output Capacitance 10 pF

8

8, 9

3

OC

OUT

OUT

3, 7

4

5

6

5

R
R
R
R

3

3

I

R
R

ANALOG OUTPUTS

Output Current (DACs A, B, C)
Output Current (DACs A, B, C)
Output Current (DACs D, E, F)
Output Current (DACs D, E, F)
DAC-to-DAC Matching (DACs A, B, C)
DAC-to-DAC Matching (DACs D, E, F)
Output Compliance, V
Output Impedance, R
Output Capacitance, C

POWER REQUIREMENTS

V

AA

Normal Power Mode

(max)

I

DAC

(min)

I

DAC

10

I

CCT

Sleep Mode

11

I

DAC

12

I

CCT

Power Supply Rejection Ratio COMP = 0.1 µF 0.01 %/%

NOTES

1

The max/min specifications are guaranteed over this range. The max/min values are typical over 3.0 V to 3.6 V.

2

Temperature range T

3

Guaranteed by characterization.

4

Full

drive into 75␣ Ω doubly terminated load.

5

Minimum drive current (used with buffered/scaled output load).

6

Full Drive into 150 Ω load.

7

Power measurements are taken with Clock Frequency = 27 MHz. Max T

8

I

is the total current (“min” corresponds to 5 mA output per DAC, “max” corresponds to 8.66 mA output per DAC ) to drive DACs A, B, C, D, E, F. Turning off

DAC

individual DACs reduces I

9

DACs A, B, C can output 35 mA typically at 3.3 V (R

R

= 75 Ω).

L

10

I

(Circuit Current) is the continuous current required to drive the device.

CCT

11

Total DAC current in Sleep Mode.

12

Total continuous current during Sleep Mode.

Specifications subject to change without notice.

to T

MIN

: 0°C to +70°C.

MAX

correspondingly, also DACs A, B, C can be configured to output a max current of 37 mA.

DAC

= 150 Ω and RL = 37.5 Ω), optimum performance obtained at 18 mA DAC Current (R

SET

= 1.235 V, R

REF

= 600 ⍀ unless otherwise noted. All specifications T

SET1,2

1

Min Typ Max Units

2V

0.8 V

= 0.4 V or 2.4 V ±1 µA

IN

10 pF

= 400 µA 2.4 V

SOURCE

= 3.2 mA 0.4 V

SINK

= 150 Ω, RL = 37.5 Ω 34.7 mA

SET1

= 1041 Ω, RL = 262.5 Ω 5mA

SET1

= 600 Ω, RL = 150 Ω 8.66 mA

SET2

= 1041 Ω, RL = 262.5 Ω 5mA

SET2

1 4.0 %
1 4.0 %

+1.4 V

30 kΩ

= 0 mA 30 pF

OUT

3.0 3.3 3.6 V

= 600 Ω 58 65 mA

SET1,2

= 1041 Ω 30 mA

SET1,2

40 mA

0.1 µA

0.1 µA

= 110°C.

J

= 300 Ω and

SET

MIN

to T

MAX

2

–4– REV. A

ADV7172/ADV7173

(VAA = +5 V ⴞ 5%1, V

5 V DYNAMIC SPECIFICATIONS

Parameter Conditions

3, 4

3, 4

3, 4

3, 4

3, 4

MIN

3, 4

3, 4

3, 4

3, 4

to T

3, 4

3, 4

3, 4

3, 4

3, 4

: 0°C to +70°C.

MAX

Differential Gain
Differential Phase
Differential Gain
Differential Phase

3, 4

(Pedestal) RMS 75 dB rms

SNR

3, 4

(Pedestal) Peak Periodic 66 dB p-p

SNR

3, 4

(Ramp) RMS 60 dB rms

SNR

3, 4

(Ramp) Peak Periodic 58 dB p-p

SNR
Hue Accuracy
Color Saturation Accuracy
Chroma Nonlinear Gain
Chroma Nonlinear Phase
Chroma/Luma Intermod
Chroma/Luma Gain Inequality
Chroma/Luma Delay Inequality
Luminance Nonlinearity
Chroma AM Noise
Chroma PM Noise

NOTES

1

The max/min specifications are guaranteed over this range. The max/min values are typical over 4.75 V to 5.25 V range.

2

Temperature range T

3

These specifications are for the low-pass filter only and guaranteed by design.

4

Guaranteed by characterization.

Specifications subject to change without notice.

specifications T

1

Normal Power Mode 0.3 0.7 %
Normal Power Mode 0.4 0.7 Degrees
Lower Power Mode 0.5 1.0 %
Lower Power Mode 2.0 3.0 Degrees

Referenced to 40 IRE 1.2 ±%

MIN

to T

= 1.235 V, R

REF

2

unless otherwise noted.)

MAX

SET1,2

Min Typ Max Units

79 82 dB
79 80 dB

= 600 ⍀ unless otherwise noted. All

0.7 Degrees

0.9 %

0.3 0.5 ±Degrees

0.2 0.4 ±%

1.0 ±%

0.5 ns

1.0 1.7 ±%

(VAA = +3.0 V – 3.6 V1, V

3.3 V DYNAMIC SPECIFICATIONS

Parameter Conditions

Differential Gain
Differential Phase
Differential Gain
Differential Phase

3

(Pedestal) RMS 75 dB rms

SNR

3

(Pedestal) Peak Periodic 70 dB p-p

SNR

3

(Ramp) RMS 60 dB rms

SNR

3

(Ramp) Peak Periodic 58 dB p-p

SNR
Hue Accuracy
Color Saturation Accuracy
Luminance Nonlinearity
Chroma AM Noise
Chroma PM Noise
Chroma Nonlinear Gain
Chroma Nonlinear Phase
Chroma/Luma Intermod

NOTES

1

The max/min specification are guaranteed over this range. The max with values are typical over a 3.0 V to 3.6 V range.

2

Temperature range T

3

Guaranteed by characterization.

4

These specifications are for the low-pass filter only and guaranteed by design.

Specifications subject to change without notice.

3

3

3

3

3

3

3

3

3

3, 4

3, 4

3, 4

to T

MIN

: 0°C to +70°C.

MAX

specifications T

1

MIN

Normal Power Mode 0.6 %
Normal Power Mode 0.5 Degrees
Lower Power Mode 1.0 %
Lower Power Mode 0.5 Degrees

Referenced to 40 IRE 1.2 ±%

to T

= 1.235 V, R

REF

2

unless otherwise noted.)

MAX

SET1,2

Min Typ Max Units

= 600 ⍀ unless otherwise noted. All

1.0 Degrees

1.0 %

1.1 ±%

83 dB
79 dB

0.3 ±Degrees

0.2 ±%

–5–REV. A

ADV7172/ADV7173

5 V TIMING SPECIFICATIONS

(VAA = +5 V ⴞ 5%1, V
T

MIN

2

to T

unless otherwise noted.)

MAX

= 1.235 V, R

REF

= 600 ⍀ unless otherwise noted. All specifications

SET1

Parameter Conditions Min Typ Max Units

MPU PORT

3, 4

SCLOCK Frequency 0 400 kHz
SCLOCK High Pulsewidth, t
SCLOCK Low Pulsewidth, t
Hold Time (Start Condition), t
Setup Time (Start Condition), t
Data Setup Time, t

5

SDATA, SCLOCK Rise Time, t
SDATA, SCLOCK Fall Time, t
Setup Time (Stop Condition), t

ANALOG OUTPUTS

3, 5

1

2

After this period the 1st clock is generated 0.6 µs

3

relevant for repeated Start Condition. 0.6 µs

4

6

7

8

0.6 µs

1.3 µs

100 ns

300 ns
300 ns

0.6 µs

Analog Output Delay 7ns
DAC Analog Output Skew 0 ns

CLOCK CONTROL AND
PIXEL PORT

f

CLOCK

Clock High Time, t
Clock Low Time, t
Data Setup Time, t
Data Hold Time, t
Control Setup Time, t
Control Hold Time, t
Digital Output Access Time, t
Digital Output Hold Time, t
Pipeline Delay, t

TELETEXT PORT

Digital Output Access Time, t
Data Setup Time, t
Data Hold Time, t

RESET CONTROL

5, 6

27 MHz

9

10

11

12

11

12

13

14

15

3, 7

16

17

18

3

8ns
8ns

4.0 ns

5.0 ns
4ns
3ns

15 24 ns
10 ns
37 Clock Cycles

20 ns
2ns
6ns

RESET Low Time 3ns

NOTES

1

The max/min specifications are guaranteed over this range. The max/min values are typical over 4.75 V to 5.25 V range.

2

Temperature range T

3

TTL input values are 0 to 3 volts, with input rise/fall times ≤ 3 ns, measured between the 10% and 90% points. Timing reference points at 50% for inputs and
outputs. Analog output load ≤ 10 pF.

4

Guaranteed by characterization.

5

Output delay measured from the 50% point of the rising edge of CLOCK to the 50% point of full-scale transition.

6

Pixel Port consists of the following:
Pixel Inputs: P7–P0
Pixel Controls: HSYNC, FIELD/VSYNC, BLANK, VSO, CSO_HSO, CLAMP
Clock Input: CLOCK

7

Teletext Port consists of the following:
Teletext Output: TTXREQ
Teletext Input: TTX

Specifications subject to change without notice.

MIN

to T

: 0°C to +70°C.

MAX

–6– REV. A

ADV7172/ADV7173

to T

MAX

2

unless

3.3 V TIMING SPECIFICATIONS

(VAA = +3.0 V–3.6 V1, V
otherwise noted.)

= 1.235 V, R

REF

= 600 ⍀. All specifications T

SET1,2

MIN

Parameter Conditions Min Typ Max Units

MPU PORT

3, 4

SCLOCK Frequency 0 400 kHz
SCLOCK High Pulsewidth, t
SCLOCK Low Pulsewidth, t
Hold Time (Start Condition), t
Setup Time (Start Condition), t
Data Setup Time, t

5

SDATA, SCLOCK Rise Time, t
SDATA, SCLOCK Fall Time, t
Setup Time (Stop Condition), t

ANALOG OUTPUTS

3, 5

1

2

3

After this period the 1st clock is generated 0.6 µs
relevant for repeated Start Condition. 0.6 µs

4

6

7

8

0.6 µs

1.3 µs

100 ns

300 ns
300 ns

0.6 µs

Analog Output Delay 7ns
DAC Analog Output Skew 0 ns

CLOCK CONTROL AND
PIXEL PORT

f

CLOCK

Clock High Time, t
Clock Low Time, t
Data Setup Time, t
Data Hold Time, t
Control Setup Time, t
Control Hold Time, t
Digital Output Access Time, t
Digital Output Hold Time, t
Pipeline Delay, t

TELETEXT PORT

Digital Output Access Time, t
Data Setup Time, t
Data Hold Time, t

RESET CONTROL

4, 5, 6

15

9

10

11

12

3, 4, 7

17

18

3, 4

27 MHz
8ns
8ns

4.0 ns
5ns

11

12

13

14

5ns
3ns

20 ns

12 ns

37 Clock Cycles

16

23 ns

2ns

6ns

RESET Low Time 3ns

NOTES

1

The max/min specifications are guaranteed over this range. The max/min values are typical over 3.0 V to 3.6 V range.

2

Temperature range T

3

TTL input values are 0 to 3 volts, with input rise/fall times ≤ 3 ns, measured between the 10% and 90% points. Timing reference points at 50% for inputs and

outputs. Analog output load ≤ 10 pF.

4

Guaranteed by characterization.

5

Output delay measured from the 50% point of the rising edge of CLOCK to the 50% point of full-scale transition.

6

Pixel Port consists of the following:

Pixel Inputs: P7–P0
Pixel Controls: HSYNC, FIELD/VSYNC, BLANK, VSO, CSO_HSO, CLAMP
Clock Input: CLOCK

7

Teletext Port consists of the following:

Teletext Output: TTXREQ
Teletext Input: TTX

Specifications subject to change without notice.

MIN

to T

: 0°C to +70°C.

MAX

–7–REV. A

ADV7172/ADV7173

SDATA

SCLOCK

CLOCK

t

t

3

t

6

t

2

5

t

1

t

7

Figure 1. MPU Port Timing Diagram

t

3

t

4 t

8

TXTREQ

CLOCK

TXT

CONTROL

CONTROL

t

16

t

12

t

11

t

13

t

14

I/PS

O/PS

HSYNC,

FIELD/VSYNC,

BLANK

PIXEL INPUT

DATA

HSYNC,

FIELD/VSYNC,

BLANK,

CSO_HSO,

VSO, CLAMP

t

t

9

10

Cb Y Cr Y Cb Y

Figure 2. Pixel and Control Data Timing Diagram

t

17

t

18

4 CLOCK

CYCLES

4 CLOCK

CYCLES

4 CLOCK

CYCLES

3 CLOCK

CYCLES

4 CLOCK

CYCLES

Figure 3. Teletext Timing Diagram

DAC Average Current Consumption

DAC D, E, F: The average current consumed by each DAC is the DAC output current as determined by R

SET2/VREF

DAC A, B, C: In normal power mode the average current consumed by each DAC is the DAC output current as determined by R

(see Appendix 8).

SET1

(see Appendix 8).

In Low Power Mode the average current consumed by each DAC is approximately half the DAC output current as determined by R

SET1.

Table I. Allowable Operating Configurations

Average Average
DACs Output DAC Current DACs Output DAC Current Power
A, B, C Current Consumption D, E, F Current Consumption Mode 5 V? 3 V?

3 DACs ON 37 mA See Above 3 DACs ON 8.66 mA See Above Normal No Yes
3 DACs ON 37 mA 18.5 mA (See Above) 3 DACs ON 8.66 mA See Above Low Power No Yes
3 DACs ON 37 mA 18.5 mA (See Above) 3 DACs OFF See Above Low Power Yes Yes
3 DACs ON 8.66 mA See Above 3 DACs ON 8.66 mA See Above Normal Yes Yes
3 DACs ON 4.33 mA See Above 3 DACs ON 4.33 mA See Above Normal Yes Yes

–8– REV. A

ADV7172/ADV7173

WARNING!

ESD SENSITIVE DEVICE

ABSOLUTE MAXIMUM RATINGS

1

VAA to GND . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 V

Voltage on Any Digital Input Pin . GND – 0.5 V to V
Storage Temperature (T
Junction Temperature (T

Lead Temperature (Soldering, 10 sec) . . . . . . . . . . . . +260°C

Analog Outputs to GND

NOTES

1

Stresses above those listed under Absolute Maximum Ratings may cause permanent

damage to the device. This is a stress rating only; functional operation of the device
at these or any other conditions above those listed in the operational sections of this
specification is not implied. Exposure to absolute maximum rating conditions for
extended periods may affect device reliability.

2

Analog output short circuit to any power supply or common can be of an indefinite

duration.

) . . . . . . . . . . . . . . –65°C to +150°C

S

) . . . . . . . . . . . . . . . . . . . . . +150°C

J

2

␣ . . . . . . . . . . . GND – 0.5 V to V

+ 0.5 V

AA

AA

PIN CONFIGURATION

NTSC

SET1

R

SCRESET/RTC

TTXREQ

SET2

R

SDATA

COMP2

REF

V

36
35
34
33
32
31
30
29
28
27
26
25

DAC F

COMP1
DAC A
V

AA

DAC B
V

AA

GND
V

AA

DAC C
DAC D
V

AA

GND
DAC E

CSO

V

HSO

V

GND

AA

CLOCK

GND

RESET

V

48 47 46 45 44 39 38 3743 42 41 40

1

AA

2

P0

3

P1

4

P2

5

P3

6

P4

7

P5

8

P6

9

P7

10
11

AA

12

13 14 15 16 17 18 19 20 21 22 23 24

VSO

PIN 1
IDENTIFIER

ADV7172/ADV7173

TOP VIEW

(Not to Scale)

GND

HSYNC

FIELD/VSYNC

ALSB

BLANK

PAL

GND

CLAMP

TTX

AA

V

SCLOCK

PACKAGE THERMAL PERFORMANCE

The 48-lead LQFP package is used for this device. The junction-

to-ambient (θ

) thermal resistance in still air on a four layer

JA

PCB is +54.6°C/W. The junction-to-case thermal resistance

) is +16.7°C.

(θ

JC

To reduce power consumption when using this part the user is
advised to run the part on a 3.3 V supply, turn off any unused
DACs. However, if 5 V operation is required the user can enable
Low Power mode by setting MR16 to a Logic 1. Another alter­native way to further reduce power is to use external buffers that
dramatically reduce the DAC currents, the current can be low­ered to as low as 5 mA (see Appendix 8 for more details) from a
nominal value of 36 mA.

The user must at all times stay below the maximum junction

temperature of +110°C. The following equation shows how to

calculate this junction temperature:

J

unction Temperature = [VAA (I

DAC

+ I

CCT

) × θJA ] +70°C

where

= 10 mA + (sum of the average currents consumed by each

I

DAC

powered-on DAC).

ORDERING GUIDE

Temperature Package Package

Model Range Description Option

ADV7172KST 0°C to +70°C Plastic Thin ST-48

Quad Flatpack

ADV7173KST 0°C to +70°C Plastic Thin ST-48

Quad Flatpack

CAUTION

ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily
accumulate on the human body and test equipment and can discharge without detection.
Although the ADV7172/ADV7173 features proprietary ESD protection circuitry, permanent
damage may occur on devices subjected to high energy electrostatic discharges. Therefore,
proper ESD precautions are recommended to avoid performance degradation or loss of
functionality.

–9–REV. A

ADV7172/ADV7173

PIN FUNCTION DESCRIPTION

Mnemonic Input/Output Function

P7–P0 I 8-Bit 4:2:2 Multiplexed YCrCb Pixel Port (P7-P0) P0 represents the LSB.
CLOCK I TTL Clock Input. Requires a stable 27 MHz reference clock for standard operation. Alter-

natively, a 24.52 MHz (NTSC) or 29.5 MHz (PAL) can be used for square pixel operation.

HSYNC I/O HSYNC (Modes 1 and 2) Control Signal. This pin may be configured to output (Master

Mode) or as an input and accept (Slave Mode) Sync signals.

FIELD/VSYNC I/O Dual Function FIELD (Mode 1) and VSYNC (Mode 2) Control Signal. This pin may be

configured to output (Master Mode) or as an input (Slave Mode) and accept these control
signals.

BLANK I/O Video Blanking Control Signal. The pixel inputs are ignored when this is logic level “0.”

This signal is optional.

SCRESET/RTC I This pin can be configured as an input by setting MR42 and MR41 of Mode Register 4. It

can be configured as a subcarrier reset pin, in which case a high to low transition on this
pin will reset the subcarrier phase to Field 0. Alternatively it may be configured as a Real­Time Control (RTC) Input.

V

REF

R

SET1

R

SET2

COMP1 O Compensation Pin for DACs A, B and C. Connect a 0.1 µF Capacitor from COMP to V

COMP2 O Compensation Pin for DACs D, E and F. Connect a 0.1 µF Capacitor from COMP to V

DAC A O GREEN/Composite/Y Analog Output. This DAC is capable of providing 34.66 mA output.
DAC B O BLUE/S-Video Y/U Analog Output. This DAC is capable of providing 34.66 mA output.
DAC C O RED/S-Video C/V Analog Output. This DAC is capable of providing 34.66 mA output.
DAC D O GREEN/Composite/Y Analog Output. This DAC is capable of providing 8.66 mA output.
DAC E O BLUE/S-Video Y/U Analog Output. This DAC is capable of providing 8.66 mA output.
DAC F O RED/S-Video C/V Analog Output. This DAC is capable of providing 8.66 mA output.
SCLOCK I MPU Port Serial Interface Clock Input.
SDATA I/O MPU Port Serial Data Input/Output.
CLAMP O TTL Output Signal to external circuitry to enable clamping of all video signals.
PAL_NTSC I Input signal to select PAL or NTSC mode of operation, pin set to Logic “1” selects PAL.

VSO O VSO TTL Output Sync Signal.
CSO_HSO O Dual function CSO or HSO TTL Output Sync Signal.

ALSB I TTL Address Input. This signal sets up the LSB of the MPU address.
RESET I The input resets the on-chip timing generator and sets the ADV7172/ADV7173 into de-

TTX I Teletext Data Input Pin.
TTXREQ O Teletext Data Request output signal used to control teletext data transfer.
V

AA

GND G Ground Pin.

I/O Voltage Reference Input for DACs or Voltage Reference Output (1.235 V).

I A 150 Ω resistor connected from this pin to GND is used to control full-scale amplitudes of

the Video Signals from DACs A, B and C (the “large” DACs).

I A 600 Ω resistor connected from this pin to GND is used to control full-scale amplitudes of

the Video Signals from DACs D, E and F (the “small” DACs).

.

AA

For Optimum Dynamic Performance in Low Power Mode, the value of the COMP1
capacitor can be lowered to as low as 2.2 nF.

.

AA

fault mode. This is NTSC operation, Timing Slave Mode 0, DACs A, B and C powered
OFF, DACs D, E and F powered ON, Composite and S-Video out.

P Power Supply (+3 V to +5 V).

–10– REV. A

FREQUENCY – MHz

0

0122

MAGNITUDE – dB

46810

–10

–20

–30

–50

–60

–40

–70

(continued from page 2)

INTERNAL FILTER RESPONSE

The Y Filter supports several different frequency responses,
including two low-pass responses, two notch responses, an Ex­tended (SSAF) response with or without gain boost/attenuation, a
CIF response and a QCIF response. The UV Filter supports
several different frequency responses, including four low-pass
responses, a CIF response and a QCIF response. These can be
seen in Figures 4 to 18.

ADV7172/ADV7173

In Extended Mode there is the option of twelve responses in the
range from –4 dB to +4 dB. The desired response can be
chosen by the user by programming the correct value via the

2

C. The variation of frequency responses can be seen in

I
Figures 19 to 21.

–10

–20

FILTER TYPE FILTER SELECTION

MR04

MR03

0

LOW-PASS (NTSC)
LOW-PASS (PAL)
NOTCH (NTSC)
NOTCH (PAL)
EXTENDED (SSAF)
CIF
QCIF

0

0

0

0

1

0

1

1

0

1

0

1

1

PASSBAND RIPPLE

MR02

0
1
0
1
0
1
0

(dB)

0.091

0.15

0.015

0.095

0.051

0.018
MONOTONIC

3 dB BANDWIDTH

(MHz)

4.157

4.74

6.54

6.24

6.217

3.0

1.5

STOPBAND

CUTOFF (MHz)

7.37

7.96

8.3

8.0

8.0

7.06

7.15

STOPBAND

ATTENUATION (dB)

–56
–64
–68
–66
–61
–61
–50

Figure 4. Luminance Internal Filter Specifications

FILTER TYPE FILTER SELECTION

MR07

MR06

0

1.3 MHz LOW PASS

0.65 MHz LOW PASS

1.0 MHz LOW PASS

2.0 MHz LOW PASS
RESERVED
CIF
QCIF

0

0

0

0

1

0

1

1

0

1

0

1

1

PASSBAND RIPPLE

MR05

0
1
0
1
0
1
0

(dB)

0.084
MONOTONIC
MONOTONIC

0.0645

0.084
MONOTONIC

3 dB BANDWIDTH

(MHz)

1.395

0.65

1.0

2.2

0.7

0.5

STOPBAND

CUTOFF (MHz)

3.01

3.64

3.73

5.0

3.01

4.08

STOPBAND

ATTENUATION (dB)

–45
–58.5
–49
–40

–45
–50

Figure 5. Chrominance Internal Filter Specifications

0

–30

–40

MAGNITUDE – dB

–50

–60

–70

0122

46810

FREQUENCY – MHz

Figure 6. NTSC Low-Pass Luma Filter

Figure 7. PAL Low-Pass Luma Filter

–11–REV. A

ADV7172/ADV7173

FREQUENCY – MHz

0

0122

MAGNITUDE – dB

46810

–10

–20

–30

–50

–60

–40

–70

14

FREQUENCY – MHz

0

0122

MAGNITUDE – dB

46810

–10

–20

–30

–50

–60

–40

–70

14

FREQUENCY – MHz

0

0122

MAGNITUDE – dB

46810

–10

–20

–30

–50

–60

–40

–70

14

0

–10

–20

–30

–40

MAGNITUDE – dB

–50

–60

–70

0122

46810

FREQUENCY – MHz

Figure 8. NTSC Notch Luma Filter

0

–10

–20

–30

–40

MAGNITUDE – dB

–50

–60

–70

0122

46810

FREQUENCY – MHz

Figure 9. PAL Notch Luma Filter

0

14

Figure 11. CIF Luma Filter

14

Figure 12. QCIF Luma Filter

–10

–20

–30

–40

MAGNITUDE – dB

–50

–60

–70

0122

46810

FREQUENCY – MHz

Figure 10. Extended Mode (SSAF) Luma Filter

14

Figure 13. 1.3 MHz Low-Pass Chroma Filter

–12– REV. A

0

FREQUENCY – MHz

0

0122

MAGNITUDE – dB

46810

–10

–20

–30

–50

–60

–40

–70

14

FREQUENCY – MHz

0

0122

MAGNITUDE – dB

46810

–10

–20

–30

–50

–60

–40

–70

14

FREQUENCY – MHz

612345

8

7

0

MAGNITUDE – dB

–5

–15

–20

–10

–25

0

–10

–20

–30

–40

MAGNITUDE – dB

–50

–60

ADV7172/ADV7173

–70

0122

46810

FREQUENCY – MHz

Figure 14. 0.65 MHz Low-Pass Chroma Filter

0

–10

–20

–30

–40

MAGNITUDE – dB

–50

–60

–70

0122

46810

FREQUENCY – MHz

Figure 15. 1.0 MHz Low-Pass Chroma Filter

0

14

Figure 17. CIF Chroma Filter

14

Figure 18. QCIF Chroma Filter

–10

–20

–30

–40

MAGNITUDE – dB

–50

–60

–70

0122

46810

FREQUENCY – MHz

Figure 16. 2.0 MHz Low-Pass Chroma Filter

14

Figure 19. Extended Mode Luma Filter with Programmable
Gain, Negative Response

–13–REV. A

ADV7172/ADV7173

4

3

2

1

0

AMPLITUDE – dB

–1

–2

–3

0

FREQUENCY – MHz

Figure 20. Extended Mode Luma Filter with Programmable
Gain, Positive Response

7

612345

4

2

0

–2

–4

–6

MAGNITUDE – dB

–8

–10

–12

2345

FREQUENCY – MHz

61

Figure 21. Extended Mode Luma Filter with Programmable
Gain, Combined Response

COLOR BAR GENERATION

The ADV7172/ADV7173 can be configured to generate 75%
amplitude, 75% saturation (75/7.5/75/7.5) for NTSC or 75%
amplitude, 100% saturation (100/0/75/0) for PAL color bars.
These are enabled by setting MR46 of Mode Register 4 to
Logic “1.”

SQUARE PIXEL MODE

The ADV7172/ADV7173 can be used to operate in square pixel
mode. For NTSC operation, an input clock of 24.5454 MHz
is required. Alternatively, for PAL operation, an input clock of

29.5 MHz is required. The internal timing logic adjusts ac­cordingly for square pixel mode operation.

COLOR SIGNAL CONTROL

The color information can be switched on and off the video
output using Bit MR44 of Mode Register 4.

BURST SIGNAL CONTROL

The burst information can be switched on and off the video
output using Bit MR45 of Mode Register 4.

NTSC PEDESTAL CONTROL

The pedestal on both odd and even fields can be controlled on
a line-by-line basis using the NTSC Pedestal Control Regis­ters. This allows the pedestals to be controlled during the
Vertical Blanking Interval (lines 10 to 25 and lines 273 to 288).

COLOR CONTROLS

The ADV7172/ADV7173 allows the user the advantage of con­trolling the brightness, contrast, hue and saturation of the color.

Contrast Control

Contrast adjustment is achieved by scaling the Y input data
by a factor programmed by the user into the Contrast Control
Register Bits 5–0. This factor allows the data to be scaled
between 75% and 125%.

Brightness Control

The brightness is controlled by adding a programmable setup
level onto the scaled Y data. This brightness level may be added

onto the Y data in PAL mode, NTSC mode without pedestal or
NTSC mode with pedestal, in which case it is added directly
onto the 7.5 IRE pedestal already present.

The level added is programmed by the user into the Brightness
Control Register (Bits 4–0) and the user is capable of adding
from 0 IRE to a maximum of 14 IRE in 32 (2

5

) steps. Because
of different gains in the datapath for each mode, different values
may need to be programmed to obtain the same IRE setup level
in each mode. Maximum brightness is achieved when 31 is
programmed into the Brightness Control Register. Table II
illustrates the maximum setup/brightness amplitudes available in
the various modes. Note that if a level of less than 7.5 IRE is
required on the Y data in NTSC mode, then NTSC without
pedestal must be the mode selected.

Table II. Maximum Brightness Levels Available

Brightness Control

Mode Register Setup

NTSC No Pedestal 00011111 14 IRE
NTSC Pedestal 00011111 13 IRE
PAL 00011111 99 mV

Color Saturation Control

Color adjustment is achieved by scaling the Cr and Cb input
data by a factor programmed by the user into the Color Control
Registers 1 and 2, Bits 5–0. This factor allows the data to be
scaled between 75% and 125%.

Hue Control

The hue adjustment is achieved on the composite and chroma
outputs by adding a phase offset onto the color subcarrier in the
active video but leaving the color burst unmodified, i.e., only
the phase between the video and the color burst is modified
and hence the hue is shifted. Hue adjustment is under the con­trol of the Hue Control Register. The ADV7172/ADV7173

provides a range of ±22° change in increments of 0.17578125°.

–14– REV. A

ADV7172/ADV7173

YUV LEVELS

This functionality is under the control of Mode Register 5, Bits
2–0. Bit 0 (MR50) allows the ADV7172/ADV7173 to output
SMPTE levels on the Y output when configured in NTSC mode,
and Betacam levels on the Y output when configured in PAL
mode and vice-versa.

Video Sync

Betacam 286 mV 714 mV
SMPTE 300 mV 700 mV

As the datapath is branched at the output of the filters, the
luma signal relating to the CVBS or S-Video Y/C output is
unaltered. Only the Y output of the YUV outputs is scaled.
Bits 2–1 (MR52–MR51) allow UV levels to have a peak-peak
amplitude of 700 mV or 1000 mV, or the default values of
934 mV in NTSC and 700 mV in PAL.

AUTODETECT CONTROL

The ADV7172/ADV7173 provides the option of automatically
powering down the DACs A, B and C if they are not correctly

terminated (i.e., the 75 Ω cable is not connected to the DAC).

The voltage at the output of DACs A and B are compared to
a selected reference level. This reference voltage (MR64) will

depend on whether the user terminates with 37.5 Ω (75 Ω con­nected on the DAC end and 75 Ω connected at TV end of cable,
i.e., combined load of 37.5 Ω) or 75 Ω. It cannot operate in a

DAC buffering configuration. There are two modes of auto­detect operation provided by the ADV7172/ADV7173:

(1) Mode 0: The state of termination of the DAC may be read
by reading the status bits in Mode Register 6. MR67 status bit
indicates whether or not the composite DAC is terminated,
MR66 status bit indicates whether or not the luma DAC is
terminated. The user may then decide whether or not to power
down the DACs using MR15–MR0.

(2) Mode 1: The state of the DACs may be read as in Mode 0.
If either of the DACs is unterminated, they are automatically
powered down. If the luma DAC, DAC B is powered down then
DAC C, the chroma DAC, will also be powered down. The
state of termination of the DAC is checked each frame to decide
whether or not it is to be powered up or down.

Mode Register 6, Bits 3–2, indicates which mode of operation is
used. Note that Mode Register 1, Bits 5-3, must be enabled
(“1”) for autodetect functionality to work. (DACs A, B, C are
enabled.)

Vertical Blanking Data Insertion

It is possible to allow encoding of incoming YCbCr data on
those lines of VBI that do not have line sync or pre-/post­equalization pulses (see Figures 24 to 25). This mode of opera­tion is called “Partial Blanking” and is selected by setting MR32
to “1.” It allows the insertion of any VBI data (Opened VBI)
into the encoded output waveform. This data is present in digi­tized incoming YCbCr data stream (e.g., WSS data, CGMS,
VPS etc.). Alternatively the entire VBI may be blanked (no VBI
data inserted) on these lines by setting MR32 to “0.”

The complete VBI comprises of the following lines:
525/60 systems, Lines 525 to 21 for Field 1 and Lines 262 to
Line 284 for Field 2.

625/50 systems, Lines 624 to Line 22 and lines 311 to 335.

The “Opened VBI” consists of:
525/60 systems, Lines 10 to 21 for Field 1 and second half of
Line 273 to Line 284 for Field 2.

625/50 systems, Line 7 to Line 22 and Lines 319 to 335.

SUBCARRIER RESET

Together with the SCRESET/RTC PIN and Bits MR42 and
MR41 of Mode Register 4, the ADV7172/ADV7173 can be
used in subcarrier reset mode. The subcarrier phase will reset
to Field 0 at the start of the following field when a low to high
transition occurs on this input pin.

REAL-TIME CONTROL

Together with the SCRESET/RTC PIN and Bits MR42 and
MR41 of Mode Register 4, the ADV7172/ADV7173 can be
used to lock to an external video source. The real-time control
mode allows the ADV7172/ADV7173 to automatically alter the
subcarrier frequency to compensate for line length variation.
When the part is connected to a device that outputs a digital
data stream in the RTC format (such as a ADV7185 video
decoder, see Figure 22), the part will automatically change to
the compensated subcarrier frequency on a line-by-line basis.
This digital data stream is 67 bits wide and the subcarrier is
contained in Bits 0 to 21. Each bit is two clock cycles long.
00Hex should be written into all four subcarrier frequency
registers when using this mode.

VIDEO TIMING DESCRIPTION

The ADV7172/ADV7173 is intended to interface to off-the­shelf MPEG1 and MPEG2 Decoders. As a consequence, the
ADV7172/ADV7173 accepts 4:2:2 YCrCb Pixel Data via a
CCIR-656 pixel port and has several video timing modes of
operation that allow it to be configured as either system master
video timing generator or a slave to the system video timing
generator. The ADV7172/ADV7173 generates all of the re­quired horizontal and vertical timing periods and levels for the
analog video outputs.

The ADV7172/ADV7173 calculates the width and placement
of analog sync pulses, blanking levels and color burst envelopes.
Color bursts are disabled on appropriate lines and serration and
equalization pulses are inserted where required.

In addition, the ADV7172/ADV7173 supports a PAL or NTSC
square pixel operation in slave mode. The part requires an
input pixel clock of 24.5454 MHz for NTSC and an input pixel
clock of 29.5 MHz for PAL. The internal horizontal line counters
place the various video waveform sections in the correct loca­tion for the new clock frequencies.

The ADV7172/ADV7173 has four distinct master and four
distinct slave timing configurations. Timing control is estab­lished with the bidirectional SYNC, BLANK and FIELD/
VSYNC pins. Timing Mode Register 1 can also be used to
vary the timing pulsewidths and where they occur in relation to
each other.

–15–REV. A

ADV7172/ADV7173

COMPOSITE

OR CABLE

H/LTRANSITION

COUNT START

128

RTC

TIME SLOT: 01

NOTES:

1

FSC PLL INCREMENT IS 22 BITS LONG, VALUE LOADED INTO ADV7172/ADV7173 FSC DDS REGISTER IS FSC PLL INCREMENT BITS 21:0 PLUS BITS 0:9
OF SUBCARRIER FREQUENCY REGISTERS. ALL ZEROS SHOULD BE WRITTEN TO THE SUBCARRIER FREQUENCY REGISTERS OF THE
ADV7172/ADV7173.

2

SEQUENCE BIT
PAL: 0 = LINE NORMAL, 1 = LINE INVERTED
NTSC: 0 = NO CHANGE

3

RESET BIT
RESET ADV7172/ADV7173’s DDS

VIDEO

e.g., VCR

LOW

VIDEO

DECODER

(e.g., ADV7185)

MPEG

DECODER

14 BITS

RESERVED

NOT USED IN

ADV7172/ADV7173

14

4 BITS

RESERVED

013

CLOCK

GREEN/COMPOSITE/Y

BLUE/LUMA/U

RED/CHROMA/V

GREEN/COMPOSITE/Y

BLUE/LUMA/U

RED/CHROMA/V

M
U
X

SCRESET/RTC

P7–P0

HSYNC

FIELD/VSYNC

ADV7172/ADV7173

SEQUENCE

2

BIT

RESET

3

5 BITS

21

19

FSCPLL INCREMENT

VALID

SAMPLE

SAMPLE

1

INVALID

RESERVED

0

8/LLC

BIT

RESERVED

67 68

Figure 22. RTC Timing and Connections

Mode 0 (CCIR–656): Slave Option

(Timing Register 0 TR0 = X X X X X 0 0 0)

The ADV7172/ADV7173 is controlled by the SAV (Start Active Video) and EAV (End Active Video) Time Codes in the Pixel Data.
All timing information is transmitted using a 4-byte Synchronization Pattern. A synchronization pattern is sent immediately before
and after each line during active picture and retrace. Mode 0 is illustrated in Figure 23. The HSYNC, FIELD/VSYNC and BLANK
(if not used) pins should be tied high during this mode.

ANALOG

VIDEO

INPUT PIXELS

NTSC/PAL M SYSTEM

(525 LlNES/60Hz)

PAL SYSTEM

(625 LINES/50Hz)

EAV CODE

000

C

F

Y

Y

r

F

4 CLOCK

4 CLOCK

END OF ACTIVE

VIDEO LINE

10801

XY8

0

0

0

FF00FFABABA

ANCILLARY DATA

268 CLOCK

280 CLOCK

B

(HANC)

801

0

SAV CODE
10FF0

8
0

C

X

0

Y

0

b

VIDEO LINE

Y

0

4 CLOCK

4 CLOCK

START OF ACTIVE

C

C

Y

Y

b

r

1440 CLOCK

1440 CLOCK

C

C

Y

b

r

Figure 23. Timing Mode 0 (Slave Mode)

–16– REV. A

ADV7172/ADV7173

Mode 0 (CCIR–656): Master Option

(Timing Register 0 TR0 = X X X X X 0 0 1)

The ADV7172/ADV7173 generates H, V and F signals required for the SAV (Start Active Video) and EAV (End Active Video)
Time Codes in the CCIR656 standard. The H bit is output on the HSYNC pin, the V bit is output on the BLANK pin and the F bit
is output on the FIELD/VSYNC pin. Mode 0 is illustrated in Figure 24 (NTSC) and Figure 25 (PAL). The H, V and F transitions
relative to the video waveform are illustrated in Figure 26.

DISPLAY DISPLAY

VERTICAL BLANK

522 523 524 525 1 2 3 4

5

67

9

8

H

V

F

DISPLAY

260 261 262 263 264 265 266 267 268 269 270 271 272 273 274

EVEN FIELD

ODD FIELD

VERTICAL BLANK

H

V

F

ODD FIELD

EVEN FIELD

Figure 24. Timing Mode 0 (NTSC Master Mode)

DISPLAY

VERTICAL BLANK

10 11 20 21 22

DISPLAY

283

DISPLAY

284

285

622 623 624 625 1 2 3 4

H

V

F

DISPLAY

309 310 311 312 314 315 316 317

ODD FIELDEVEN FIELD

313

H

V

F

ODD FIELD EVEN FIELD

Figure 25. Timing Mode 0 (PAL Master Mode)

5

VERTICAL BLANK

–17–REV. A

67

318

319 320

22 23

21

DISPLAY

335 336

334

ADV7172/ADV7173

ANALOG

VIDEO

H

F

V

Figure 26. Timing Mode 0 Data Transitions (Master Mode)

Mode 1: Slave Option HSYNC, BLANK, FIELD

(Timing Register 0 TR0 = X X X X X 0 1 0)

In this mode the ADV7172/ADV7173 accepts horizontal SYNC and Odd/ Even FIELD signals. A transition of the FIELD input
when HSYNC is low indicates a new frame, i.e., Vertical Retrace. The BLANK signal is optional. When the BLANK input is dis-
abled, the ADV7172/ADV7173 automatically blanks all normally blank lines as per CCIR-624. Mode 1 is illustrated in Figure 27
(NTSC) and Figure 28 (PAL).

HSYNC

BLANK

FIELD

HSYNC

BLANK

FIELD

284

DISPLAY

285

DISPLAY

522 523 524 525

DISPLAY DISPLAY

260 261 262 263 264 265 266 267 268 269 270 271 272 273 274

1234

ODD FIELDEVEN FIELD

ODD FIELD EVEN FIELD

VERTICAL BLANK

678

5

VERTICAL BLANK

10 11

9

20 21 22

283

Figure 27. Timing Mode 1 (NTSC)

–18– REV. A

ADV7172/ADV7173

HSYNC

BLANK

FIELD

HSYNC

BLANK

FIELD

DISPLAY

622 623 624 625 1 2 3 4

ODD FIELDEVEN FIELD

DISPLAY

309 310 311 312 313 314 315 316

ODD FIELD EVEN FIELD

VERTICAL BLANK

VERTICAL BLANK

5

317

67

318 319

21 22 23

320

DISPLAY

DISPLAY

334 335 336

Figure 28. Timing Mode 1 (PAL)

Mode 1: Master Option HSYNC , BLANK, FIELD

(Timing Register 0 TR0 = X X X X X 0 1 1)

In this mode the ADV7172/ADV7173 can generate horizontal SYNC and Odd/Even FIELD signals. A transition of the FIELD
input when HSYNC is low indicates a new frame, i.e., vertical retrace. The BLANK signal is optional. When the BLANK input is
disabled, the ADV7172/ADV7173 automatically blanks all normally blank lines as per CCIR-624. Pixel data is latched on the rising
clock edge following the timing signal transitions. Mode 1 is illustrated in Figure 27 (NTSC) and Figure 28 (PAL). Figure 29 illus­trates the HSYNC, BLANK and FIELD for an odd-or-even field transition relative to the pixel data.

HSYNC

FIELD

PAL = 12 * CLOCK/2

BLANK

PIXEL
DATA

NTSC = 16 * CLOCK/2

PAL = 132 * CLOCK/2
NTSC = 122 * CLOCK/2

Figure 29. Timing Mode 1 Odd/Even Field Transitions Master/Slave

Cb Y

Cr Y

–19–REV. A

ADV7172/ADV7173

Mode 2: Slave Option HSYNC, VSYNC, BLANK

(Timing Register 0 TR0 = X X X X X 1 0 0)
In this mode the ADV7172/ADV7173 accepts horizontal and vertical SYNC signals. A coincident low transition of both HSYNC

and VSYNC inputs indicates the start of an odd field. A VSYNC low transition when HSYNC is high indicates the start of an Even
Field. The BLANK signal is optional. When the BLANK input is disabled, the ADV7172/ADV7173 automatically blanks all nor­mally blank lines as per CCIR-624. Mode 2 is illustrated in Figure 30 (NTSC) and Figure 31 (PAL).

HSYNC

BLANK

VSYNC

HSYNC

BLANK

VSYNC

DISPLAY

522 523 524 525

DISPLAY

260 261 262 263 264 265 266 267 268 269 270 271 272 273 274

1234

ODD FIELD EVEN FIELD

VERTICAL BLANK

678

5

ODD FIELDEVEN FIELD

VERTICAL BLANK

9

10 11

Figure 30. Timing Mode 2 (NTSC)

DISPLAY

VERTICAL BLANK

20 21 22

DISPLAY

283

284

DISPLAY

DISPLAY

285

HSYNC

BLANK

VSYNC

HSYNC

BLANK

VSYNC

6226236246251234

ODD FIELDEVEN FIELD

DISPLAY

309 310 311 312 313 314 315 316

ODD FIELD EVEN FIELD

VERTICAL BLANK

Figure 31. Timing Mode 2 (PAL)

–20– REV. A

5

317

67

318 319

320

21 22 23

DISPLAY

334 335 336

ADV7172/ADV7173

Mode 2: Master Option HSYNC , VSYNC, BLANK

(Timing Register 0 TR0 = X X X X X 1 0 1)

In this mode the ADV7172/ADV7173 can generate horizontal and vertical SYNC signals. A coincident low transition of both
HSYNC and VSYNC inputs indicates the start of an odd field. A VSYNC low transition when HSYNC is high indicates the start of
an even field. The BLANK signal is optional. When the BLANK input is disabled, the ADV7172/ADV7173 automatically blanks all
normally blank lines as per CCIR-624. Mode 2 is illustrated in Figure 30 (NTSC) and Figure 31 (PAL). Figure 32 illustrates the

HSYNC, BLANK and VSYNC for an even-to-odd field transition relative to the pixel data. Figure 33 illustrates the HSYNC,
BLANK and VSYNC for an odd-to-even field transition relative to the pixel data.

HSYNC

VSYNC

BLANK

PIXEL
DATA

HSYNC

VSYNC

BLANK

PIXEL
DATA

PAL = 12 * CLOCK/2
NTSC = 16 * CLOCK/2

Cb Y Cr Y

PAL = 132 * CLOCK/2
NTSC = 122 * CLOCK/2

Figure 32. Timing Mode 2 Even-to-Odd Field Transition Master/Slave

PAL = 864 * CLOCK/2

PAL = 12 * CLOCK/2
NTSC = 16 * CLOCK/2

PAL = 132 * CLOCK/2
NTSC = 122 * CLOCK/2

NTSC = 858 * CLOCK/2

Cb Y Cr Y Cb

Figure 33. Timing Mode 2 Odd-to-Even Field Transition Master/Slave

–21–REV. A

ADV7172/ADV7173

Mode 3: Master/Slave Option HSYNC, BLANK, FIELD

(Timing Register 0 TR0 = X X X X X 1 1 0 or X X X X X 1 1 1)

In this mode the ADV7172/ADV7173 accepts or generates horizontal SYNC and Odd/Even FIELD signals. A transition of the
FIELD input when HSYNC is high indicates a new frame, i.e., vertical retrace. The BLANK signal is optional. When the BLANK
input is disabled, the ADV7172/ADV7173 automatically blanks all normally blank lines as per CCIR-624. Mode 3 is illustrated in
Figure 34 (NTSC) and Figure 35 (PAL).

HSYNC

BLANK

FIELD

HSYNC

BLANK

FIELD

DISPLAY

522 523 524 525

DISPLAY

260 261 262 263 264 265 266 267 268 269 270 271 272 273 274

1234

ODD FIELDEVEN FIELD

ODD FIELD EVEN FIELD

VERTICAL BLANK

678

5

VERTICAL BLANK

9

10 11

Figure 34. Timing Mode 3 (NTSC)

DISPLAY

20 21 22

DISPLAY

283

284

285

HSYNC

BLANK

FIELD

HSYNC

BLANK

FIELD

DISPLAY

6226236246251234567

ODD FIELDEVEN FIELD

DISPLAY

309 310 311 312 313 314 315 316

ODD FIELD EVEN FIELD

VERTICAL BLANK

VERTICAL BLANK

317

318 319

Figure 35. Timing Mode 3 (PAL)

320

DISPLAY

21 22 23

DISPLAY

334 335 336

–22– REV. A

ADV7172/ADV7173

OUTPUT VIDEO TIMING

The video timing generator generates the appropriate sync,
blank and burst sequence that controls the output analog wave­forms. These sequences are summarized below. In slave modes,
the following sequences are synchronized with the input timing
control signals. In master modes, the timing generator free runs
and generates the following sequences in addition to the output
timing control signals.

NTSC–Interlaced: Scan Lines 1–9 and 264–272 are always
blanked and vertical sync pulses are included. Scan Lines 525,
10–21 and 262, 263, 273-284 are also blanked and can be used
for closed captioning data. Burst is disabled on Lines 1–6, 261–
269 and 523–525.

NTSC–Noninterlaced: Scan Lines 1–9 are always blanked
and vertical sync pulses are included. Scan Lines 10–21 are also
blanked and can be used for closed captioning data. Burst is
disabled on Lines 1–6, 261–262.

PAL–Interlaced: Scan Lines 1–6, 311–318 and 624–625 are
always blanked and vertical sync pulses are included in Fields 1,
2, 5 and 6. Scan Lines 1–5, 311–319 and 624–625 are always
blanked and vertical sync pulses are included in Fields 3, 4, 7
and 8. The remaining scan lines in the vertical blanking interval
are also blanked and can be used for teletext data. Burst is dis­abled on Lines 1–6, 311–318 and 623–625 in Fields 1, 2, 5 and

6. Burst is disabled on Lines 1–5, 311–319 and 623–625 in
Fields 3, 4, 7 and 8.

PAL–Noninterlaced: Scan Lines 1–6 and 311–312 are always
blanked and vertical sync pulses are included. The remaining
scan lines in the vertical blanking interval are also blanked and
can be used for teletext data. Burst is disabled on Lines 1–5,
310–312.

POWER-ON RESET

After power-up, it is necessary to execute a reset operation. A
reset occurs on the falling edge of a high-to-low transition on
the RESET pin. This initializes the pixel port such that the pixel
inputs P7–P0 are not selected. After reset, the ADV7172/
ADV7173 is automatically set up to operate in NTSC/PAL
mode, depending on the PAL_NTSC pin. The subcarrier fre­quency registers are automatically loaded with the correct values
for PAL or NTSC. All other registers, with the exception of
Mode Registers 1 and 2, are set to 00H. Mode Register 1 is set
to 07H. This is to ensure DACs D, E and F are ON after
power-up. All bits of Mode Register 2 are set to “0,” with the
exception of Bit 3 (i.e., Mode Register 2 reads 08H). Bit MR23
of Mode Register 2 is set to Logic “1.” This enables the 7.5 IRE
pedestal.

RESET SEQUENCE

When RESET becomes active, the ADV7172/ADV7173 reverts
to the default output configuration. DACs A, B, C are off and
DACs D, E, F are powered on and output composite, luma and
chroma signals respectively. Mode Register 2, Bit 6 (MR26),
resets to “0.” The ADV7172/ADV7173 internal timing is under
the control of the logic level on the NTSC_PAL pin.

When RESET is released Y, Cr, Cb values corresponding to a
black screen are input to the ADV7172/ADV7173. Output
timing signals are still suppressed at this stage.

When the user requires valid data, MR26 is set to “1” to allow
the valid pixel data to pass through the encoder. Digital output
timing signals become active and the encoder timing is now
under the control of the timing registers. If, at this stage, the
user wishes to select a video standard different from that on
the NTSC_PAL pin, Mode Register 2, Bit 5 (MR25) is set
(“1”) and the video standard required is selected by program­ming Mode Register 0. Figure 36 illustrates the reset sequence
timing.

COMPOSITE/Y

PIXEL

DATA VALID

DIGITAL TIMING

RESET

CHROMA

MR26

XXXXXXX

XXXXXXX

XXXXXXX

XXXXXXX DIGITAL TIMING SIGNALS SUPPRESSED

0

512

0

Figure 36.

BLACK VALUE WITH SYNC VALID VIDEO

RESET

Sequence Timing Diagram

BLACK VALUE

–23–REV. A

VALID VIDEO

1

TIMING ACTIVE

ADV7172/ADV7173

EXAMPLE: NTSC

OUTPUT

VIDEO

5251234567891011-19

CSO

HSO

VSO

Figure 37. CSO, HSO, VSO Timing Diagram

SLEEP MODE

If after reset the SCRESET/RTC and NTSC_PAL pins are
both set to high, the part ADV7172/ADV7173 will power-up
in sleep mode to facilitate low power consumption before all
registers have been initialized. If Mode Register 6, Bit 0 (MR60) is
then set to (“1”) sleep mode control passes to Mode Register 2,
Bit 7 (i.e., control via I

2

C).

SCH PHASE MODE

The SCH phase is configured in default mode to reset every
four (NTSC) or eight (PAL) fields to avoid an accumulation of
SCH phase error over time. In an ideal system, zero SCH phase
error would be maintained forever, but in reality, this is impos­sible to achieve due to clock frequency variations. This effect is
reduced by the use of a 32-bit DDS, which generates this SCH.

Resetting the SCH phase every four or eight fields avoids the
accumulation of SCH phase error, and results in very minor
SCH phase jumps at the start of the four or eight field sequence.

Resetting the SCH phase should not be done if the video source
does not have stable timing or the ADV7172/ADV7173 is con­figured in RTC mode (MR41 = “1” and MR42 = “1”). Under
these conditions (unstable video) the subcarrier phase reset should
be enabled (MR42 = “0” and MR41 = “1”) but no reset applied.
In this configuration the SCH phase will never be reset, which
that the output video will now track the unstable input video.

The subcarrier phase reset when applied will reset the SCH
phase to Field 0 at the start of the next field (e.g., subcarrier
phase reset applied in Field 5 (PAL) on the start of the next
field SCH phase will be reset to Field 0).

CSO, HSO AND VSO OUTPUTS

The ADV7172/ADV7173 supports three timing signals, CSO
(composite sync signal), HSO (horizontal sync signal) and VSO
(vertical sync signal). These output TTL signals are aligned
with the analog video outputs. HSO and CSO are shared on Pin

10. Mode Register 7, Bit MR75 can be used to configure this
output pin. See Figure 37 for an example of these waveforms.

CLAMP OUTPUT

The ADV7172/ADV7173 has a programmable clamp TTL
output signal. The clamp signal is programmable to the front
and back porch. Mode Register 5, Bit MR57 can be used to
control the porch position. Also the position of the clamp signal
can be varied by 1–3 clock cycles in a positive and negative
direction from the default position. Mode Register 5, Bits MR56,
MR55 and MR54 control this position.

0H

MR57 = 1

MR57 = 0

Figure 38. Clamp Output Timing

MPU PORT DESCRIPTION

The ADV7172 and ADV7173 support a two wire serial (I2C
Compatible) microprocessor bus driving multiple peripherals.
Two inputs serial data (SDATA) and serial clock (SCLOCK)
carry information between any device connected to the bus.
Each slave device is recognized by a unique address. The
ADV7172 and ADV7173 each have four possible slave ad­dresses for both read and write operations. These are unique
addresses for each device and are illustrated in Figure 39 and
Figure 40. The LSB sets either a read or write operation.
Logic Level “1” corresponds to a read operation while Logic
Level “0” corresponds to a write operation. A1 is set by setting
the ALSB pin of the ADV7172/ADV7173 to Logic Level “0”
or Logic Level “1.” When ALSB is set to “0,” there is greater
bandwidth on the I
fers on this bus. When ALSB is set to “1,” there is reduced
input bandwidth on the I
less than 50 ns will not pass into the I

2

C lines, which allows high speed data trans-

2

C lines which means that impulses of

2

C internal controller.

This mode is recommended for noisy systems.

1

1

1 0

0

1

ADDRESS
CONTROL

SET UP BY

A1 X

ALSB

READ/WRITE

0 WRITE
1 READ

CONTROL

Figure 39. ADV7172 Slave Address

–24– REV. A

ADV7172/ADV7173

0

1

1 0 1 A1

0

ADDRESS
CONTROL

SET UP BY

ALSB

X

READ/WRITE

CONTROL

0 WRITE
1 READ

Figure 40. ADV7173 Slave Address

To control the various devices on the bus the following protocol
must be followed. First the master initiates a data transfer by
establishing a start condition, defined by a high-to-low transition
on SDATA while SCLOCK remains high. This indicates that
an address/data stream will follow. All peripherals respond to
the Start condition and shift the next eight bits (7-bit address +
R/W bit). The bits are transferred from MSB down to LSB. The
peripheral that recognizes the transmitted address responds by
pulling the data line low during the ninth clock pulse. This is
known as an acknowledge bit. All other devices withdraw from
the bus at this point and maintain an idle condition. The idle
condition is where the device monitors the SDATA and SCLOCK
lines waiting for the Start condition and the correct transmitted
address. The R/W bit determines the direction of the data. A
Logic “0” on the LSB of the first byte means that the master
will write information to the peripheral. A Logic “1” on the LSB
of the first byte means that the master will read information
from the peripheral.

The ADV7172/ADV7173 acts as a standard slave device on the
bus. The data on the SDATA pin is eight bits long, supporting
the 7-bit addresses plus the R/W bit. It interprets the first byte
as the device address and the second byte as the starting sub­address. The subaddresses auto increment allows data to be
written to or read from the starting subaddress. A data transfer
is always terminated by a stop condition. The user can also
access any unique subaddress register on a one-by-one basis
without having to update all the registers. There is one excep­tion. The subcarrier frequency registers should be updated in
sequence, starting with Subcarrier Frequency Register 0. The
auto increment function should then be used to increment and
access Subcarrier Frequency Registers 1, 2 and 3. The subcarrier
frequency registers should not be accessed independently.

Stop and Start conditions can be detected at any stage during
the data transfer. If these conditions are asserted out of sequence
with normal read and write operations, then these cause an
immediate jump to the idle condition. During a given SCLOCK
high period the user should only issue one start condition, one
stop condition or a single stop condition followed by a single

start condition. If an invalid subaddress is issued by the user,
the ADV7172/ADV7173 will not issue an acknowledge and will
return to the idle condition. If, in autoincrement mode, the user
exceeds the highest subaddress the following action will be
taken:

1. In Read Mode the highest subaddress register contents will
continue to be output until the master device issues a no­acknowledge. This indicates the end of a read. A no­acknowledge condition is where the SDATA line is not
pulled low on the ninth pulse.

2. In Write Mode, the data for the invalid byte will not be loaded
into any subaddress register, a no-acknowledge will be issued
by the ADV7172/ADV7173 and the part will return to the
idle condition.

Figure 41 illustrates an example of data transfer for a read
sequence and the Start and Stop conditions.

SDATA

SCLOCK

1-7 8 9 1-7 8 9 1-7 8 9 PS

START ADDR

R/W

SUBADDRESS ACK DATA ACK

ACK

STOP

Figure 41. Bus Data Transfer

Figure 42 shows bus write and read sequences.

REGISTER ACCESSES

The MPU can write to or read from all of the registers of the
ADV7172/ADV7173 except the Subaddress Register, which is a
write-only register. The Subaddress Register determines which
register the next read or write operation accesses. All communi­cations with the part through the bus start with an access to the
Subaddress Register. A read/write operation is then performed
from/to the target address, which then increments to the next
address until a Stop command on the bus is performed.

REGISTER PROGRAMMING

The following section describes each register, including subaddress
register, mode registers, subcarrier frequency registers, subcar­rier phase register, timing registers, closed captioning extended
data registers, closed captioning data registers, NTSC pedestal
Control/PAL teletext control registers, CGMS/WSS registers,
contrast register, U- or V-scale registers, hue adjust register,
brightness control register and sharpness response register in
terms of its configuration. All registers can be read from as well
as written to.

WRITE

SEQUENCE

READ

SEQUENCE

LSB = 0

S

SLAVE ADDR A(S) SUB ADDR

S = START BIT
P = STOP BIT

A(S) = ACKNOWLEDGE BY SLAVE
A(M) = ACKNOWLEDGE BY MASTER

DATA A(S)S SLAVE ADDR A(S) SUB ADDR A(S)

LSB = 1

S

A(S)

SLAVE ADDR A(S) DATA

A(S) = NO-ACKNOWLEDGE BY SLAVE
A(M) = NO-ACKNOWLEDGE BY MASTER

Figure 42. Write and Read Sequences

–25–REV. A

DATA

A(M)

A(S)

P

DATA P

A(M)

ADV7172/ADV7173

Subaddress Register (SR7–SR0)

The communications register is an 8-bit write-only register.
After the part has been accessed over the bus and a read/write
operation is selected, the subaddress is set up. The subaddress
register determines to/from which register the operation takes
place.

SR4 SR3 SR2

ZERO SHOULD BE WRITTEN

SR6 SR5 SR4 SR3 SR2 SR1 SR0

0000000MODE REGISTER 0
0000001MODE REGISTER 1
0000010MODE REGISTER 2
0000011MODE REGISTER 3
0000100MODE REGISTER 4
0000101MODE REGISTER 5
0000110MODE REGISTER 6
0000111MODE REGISTER 7
0001000RESERVED
0001001 RESERVED
0001010 TIMING MODE REGISTER 0
0001011TIMING MODE REGISTER 1
0001100 SUBCARRIER FREQUENCY REGISTER 0
0001101SUBCARRIER FREQUENCY REGISTER 1
0001110SUBCARRIER FREQUENCY REGISTER 2
0001111 SUBCARRIER FREQUENCY REGISTER 3
0010000 SUBCARRIER PHASE REGISTER
0010001CLOSED CAPTIONING EXTENDED DATA-BYTE 0
0010010CLOSED CAPTIONING EXTENDED DATA-BYTE 1
0010011 CLOSED CAPTIONING DATA-BYTE 0
0010100CLOSED CAPTIONING DATA-BYTE 1
0010101 NTSC PEDESTAL CONTROL REG 0
0010110NTSC PEDESTAL CONTROL REG 1
0010111NTSC PEDESTAL CONTROL REG 2
0011000NTSC PEDESTAL CONTROL REG 3
0011001 CGMS
0011010CGMS
0011011CGMS
0011100TELETEXT REQUEST POSITION
0011101CONTRAST REGISTER
0011110U-SCALE REGISTER
0011111V-SCALE REGISTER
0100000HUE ADJUST REGISTER
0100001BRIGHTNESS REGISTER
0100010SHARPNESS RESPONSE

SR7

HERE

ADV7173 SUBADDRESS REGISTER

WSS 0
WSS 1
WSS 2

Figure 43 shows the various operations under the control of the
subaddress register. “0” should always be written to SR7.

Register Select (SR6–SR0)

These bits are set up to point to the required starting address.

SR1

SR5 SR5 SR4 SR3 SR2 SR1 SR0

0 0 0 0 0 0 0 MODE REGISTER 0
0 0 0 0 0 0 1 MODE REGISTER 1
0 0 0 0 0 1 0 MODE REGISTER 2
0 0 0 0 0 1 1 MODE REGISTER 3
0 0 0 0 1 0 0 MODE REGISTER 4
0 0 0 0 1 0 1 MODE REGISTER 5
0 0 0 0 1 1 0 MODE REGISTER 6
0 0 0 0 1 1 1 MODE REGISTER 7
0 0 0 1 0 0 0 RESERVED
0 0 0 1 0 0 1 RESERVED
0 0 0 1 0 1 0 TIMING MODE REGISTER 0
0 0 0 1 0 1 1 TIMING MODE REGISTER 1
0 0 0 1 1 0 0 SUB CARRIER FREQUENCY REGISTER 0
0 0 0 1 1 0 1 SUB CARRIER FREQUENCY REGISTER 1
0 0 0 1 1 1 0 SUB CARRIER FREQUENCY REGISTER 2
0 0 0 1 1 1 1 SUB CARRIER FREQUENCY REGISTER 3
0 0 1 0 0 0 0 SUB CARRIER PHASE REGISTER
0 0 1 0 0 0 1 CLOSED CAPTIONING EXT. DATA-BYTE 0
0 0 1 0 0 1 0 CLOSED CAPTIONING EXT. DATA-BYTE 1
0 0 1 0 0 1 1 CLOSED CAPTIONING DATA-BYTE 0
0 0 1 0 1 0 0 CLOSED CAPTIONING DATA-BYTE 1
0 0 1 0 1 0 1 NTSC PEDESTAL CONTROL REG 0
0 0 1 0 1 1 0 NTSC PEDESTAL CONTROL REG 1
0 0 1 0 1 1 1 NTSC PEDESTAL CONTROL REG 2
0 0 1 1 0 0 0 NTSC PEDESTAL CONTROL REG 3
0 0 1 1 0 0 1 CGMS
0 0 1 1 0 1 0 CGMS
0 0 1 1 0 1 1 CGMS
0 0 1 1 1 0 0 TELETEXT REQUEST POSITION
0 0 1 1 1 0 1 CONTRAST REGISTER
0 0 1 1 1 1 0 U-SCALE REGISTER
0 0 1 1 1 1 1 V-SCALE REGISTER
0 1 0 0 0 0 0 HUE ADJUST REGISTER
0 1 0 0 0 0 1 BRIGHTNESS REGISTER
0 1 0 0 0 1 0 SHARPNESS RESPONSE
0 1 0 0 0 1 1 RESERVED

0 1 1 1 0 0 1 RESERVED
0 1 1 1 0 1 1 MACROVISION REGISTERS
0 1 1 1 1 0 0 MACROVISION REGISTERS
0 1 1 1 1 0 1 MACROVISION REGISTERS
0 1 1 1 1 1 0 MACROVISION REGISTERS
0 1 1 1 1 1 1 MACROVISION REGISTERS
1 0 0 0 0 0 0 MACROVISION REGISTERS
1 0 0 0 0 0 1 MACROVISION REGISTERS
1 0 0 0 0 1 0 MACROVISION REGISTERS
1 0 0 0 0 1 1 MACROVISION REGISTERS
1 0 0 0 1 0 0 MACROVISION REGISTERS
1 0 0 0 1 0 1 MACROVISION REGISTERS
1 0 0 0 1 1 0 MACROVISION REGISTERS
1 0 0 0 1 1 1 MACROVISION REGISTERS
1 0 0 1 0 0 0 MACROVISION REGISTERS
1 0 0 1 0 0 1 MACROVISION REGISTERS
1 0 0 1 0 1 0 MACROVISION REGISTERS
1 0 0 1 0 1 1 MACROVISION REGISTERS

SR0SR7 SR6 SR5

ADV7172 SUBADDRESS REGISTER

WSS 0
WSS 1
WSS 2

Figure 43. Subaddress Register

–26– REV. A

ADV7172/ADV7173

MODE REGISTER 0 MR0 (MR07–MR00)
(Address (SR4–SR0) = 00H)

Figure 44 shows the various operations under the control of
Mode Register 0.

MR0 BIT DESCRIPTION
Encode Mode Control (MR01–MR00)

These bits are used to set up the encoder mode. The ADV7172/
ADV7173 can be set up to output NTSC, PAL (B, D, G, H, I),
PAL M or PAL N standard video.

Luminance Filter Control (MR02–MR04)

These bits specify which luma filter is to be selected. The filter
selection is made independent of whether PAL or NTSC is
selected.

Chrominance Filter Control (MR05–MR07)

These bits select the chrominance filter. A low-pass filter can be
selected with a choice of cutoff frequencies, (0.65 MHz, 1.0 MHz,

1.3 MHz or 2 MHz) along with a choice of CIF or QCIF filters.

MR07

CHROMA FILTER SELECT

MR06

0 0 0 1.3 MHz LOW-PASS FILTER
0 0 1 0.65 MHz LOW-PASS FILTER
0 1 0 1.0 MHz LOW-PASS FILTER
0 1 1 2.0 MHz LOW-PASS FILTER
1 0 0 RESERVED
1 0 1 CIF
1 1 0 QCIF
1 1 1 RESERVED

MR05

MR04 MR03

0 0 0 LOW-PASS FILTER (NTSC)
0 0 1 LOW-PASS FILTER (PAL)
0 1 0 NOTCH FILTER (NTSC)
0 0 1 NOTCH FILTER (PAL)
1 0 0 EXTENDED MODE
1 0 1 CIF
1 1 0 QCIF
1 1 1 RESERVED

LUMA FILTER SELECT
MR02

MODE REGISTER 1 MR1 (MR17–MR10)
(Address (SR4–SR0) = 01H)

Figure 45 shows the various operations under the control of
Mode Register 1.

MR1 BIT DESCRIPTION
DAC Control (MR15–MR10)

MR15–MR10 bits can be used to power down the DACs. This
can be used to reduce the power consumption of the ADV7172/
ADV7173 if any of the DACs are not required in the application.

Low Power Control (MR16)

This bit enables the lower power mode of the ADV7172/
ADV7173. This will reduce by approximately 50% the average
supply current consumed by each large DAC which is powered
on. For each DAC in low power mode, the relationship between
R

SET1/VREF

and the output current is unchanged by this (see
Appendix 8). This bit is only relevant to the larger DACs,
DACs A, B and C. DACs D, E and F are not affected by this low
power mode.

Reserved (MR17)

A Logic “0” must be written to this bit.

MR01 MR00MR07 MR02MR03MR05MR06 MR04

OUTPUT VIDEO

STANDARD SELECTION

MR01

MR00

0 0 NTSC
0 1 PAL (B, D, G, H, I)
1 0 PAL (M)
1 1 PAL (N)

LOW POWER MODE

MR16

0 DISABLE
1 ENABLE

MR17

(0)

ZERO SHOULD BE

WRITTEN TO

THIS BIT

CONTROL

Figure 44. Mode Register 0 (MR0)

DAC B

DAC C CONTROL

MR14

0 POWER-DOWN
1 NORMAL

DAC A

DAC C CONTROL

MR15

0 POWER-DOWN
1 NORMAL

DAC C CONTROL

MR13

0 POWER-DOWN
1 NORMAL

MR12

DAC C

Figure 45. Mode Register 1 (MR1)

–27–REV. A

MR11 MR10MR17 MR12MR13MR15MR16 MR14

DAC D

DAC C CONTROL

0 POWER-DOWN
1 NORMAL

DAC C CONTROL

MR11

0 POWER-DOWN
1 NORMAL

DAC C CONTROL

MR10

0 POWER-DOWN
1 NORMAL

DAC E

DAC F

ADV7172/ADV7173

MODE REGISTER 2 MR2 (MR27–MR20)
(Address (SR4–SR0) = 02H)

Mode Register 2 is an 8-bit-wide register.

Figure 46 shows the various operations under the control of
Mode Register 2.

MR2 BIT DESCRIPTION
RGB/YUV Control (MR20)

This bit enables the output from the small or large DACs to be
set to YUV or RGB output video standard.

Large DACs Control (MR21)

This bit controls the output from DACs A, B and C. When this
bit is set to “1,” composite, luma and chroma signals are output
from DACs A, B and C (respectively). When this bit is set to
“0,” RGB or YUV may be output from these DACs.

DAC Switching Control (MR22)

This bit is used to switch the DAC outputs from SCART to a
EuroSCART configuration. A complete table of all DAC output
configurations is shown in Table III.

Pedestal Control (MR23)

This bit specifies whether a pedestal is to be generated on the
NTSC composite video signal. This bit is invalid if the ADV7172/
ADV7173 is configured in PAL mode.

Square Pixel Mode Control (MR24)

This bit is used to set up square pixel mode. This is available in
slave mode only. For NTSC, a 24.54 MHz clock must be
supplied. For PAL, a 29.5 MHz clock must be supplied.

Standard I2C Control (MR25)

This bit controls the video standard used by the ADV7172/
ADV7173. When this bit is set to “1,” the video standard bits
programmed in Mode Register 0, Bits 0–1, indicate the video
standard. When this bit is set to “0,” the ADV7172/ADV7173
is forced into the standard selected by the NTSC_PAL pin.

Pixel Data Valid Control (MR26)

After reset, this bit has the value “0” and the pixel data input to
the encoder is blanked such that a black screen is output from
the DACs. The ADV7172/ADV7173 will be set to master mode
timing. When this bit is set to “1” by the user (via the I

2

C),
pixel data passes to the pins and the encoder reverts to the
timing mode defined by Timing Mode Register 0.

Sleep Mode Enable Bit (MR27)

When this bit is set (“1”), sleep mode is enabled. With this
mode enabled the ADV7172/ADV7173 power consumption is

reduced to less than 20 µA. The I

2

C registers can be written to
and read from when the ADV7172/ADV7173 is in sleep mode.
If “0” is written to MR27 when the device is in sleep mode, the
ADV7172/ADV7173 will come out of sleep mode and resume
normal operation. Also, if the reset signal is applied during
sleep mode, the ADV7172/ADV7173 will come out of sleep
mode and resume normal operation. This mode will only oper­ate when MR60 is set to a Logic “1,” otherwise sleep mode is
controlled by the PAL_NTSC and SCRESET/RTC pin.

MR27 MR22MR23MR26 MR25 MR24 MR20

SLEEP MODE

CONTROL

MR27

0 DISABLE
1 ENABLE

PIXEL DATA VALID

CONTROL

MR26

0 DISABLE
1 ENABLE

MR25

STANDARD I2C

0 DISABLE
1 ENABLE

CONTROL

SQUARE PIXEL

CONTROL

MR24

0 DISABLE
1 ENABLE

MR22

PEDESTAL

CONTROL

MR23

0 PEDESTAL ON
1 PEDESTAL OFF

SCART ENABLE

CONTROL

0 DISABLE
1 ENABLE

MR21

RGB/YUV

CONTROL

MR20

0 RGB OUTPUT
1 YUV OUTPUT

LARGE DACs

CONTROL

MR21

0 RGB/YUV/COMP
1 COMP/LUMA/CHROMA

Figure 46. Mode Register 2 (MR2)

Table III. DAC Output Configuration Matrix

MR22 MR21 MR20 DAC A DAC B DAC C DAC D DAC E DAC F

0 0 0 G B R CVBS LUMA CHROMA
0 0 1 Y U V CVBS LUMA CHROMA
0 1 0 CVBS LUMA CHROMA G B R
0 1 1 CVBS LUMA CHROMA Y U V
1 0 0 CVBS B R G LUMA CHROMA
1 0 1 CVBS U V Y LUMA CHROMA
1 1 0 CVBS LUMA CHROMA G B R
1 1 1 CVBS LUMA CHROMA Y U V

–28– REV. A

ADV7172/ADV7173

MODE REGISTER 3 MR3 (MR37–MR30)
(Address (SR4–SR0) = 03H)

Mode Register 3 is an 8-bit-wide register. Figure 47 shows the
various operations under the control of Mode Register 3.

MR3 BIT DESCRIPTION
Revision Code (MR31–MR30)

This bit is read-only and indicates the revision of the device.

VBI Pass-Through Control (MR32)

This bit determines whether or not data in the vertical blanking
interval (VBI) is output to the analog outputs or blanked. Note
that this condition is also valid in timing slave mode 0.

Teletext Enable (MR33)

This bit must be set to “1” to enable teletext data insertion on
the TTX pin.

MR37

ACTIVE VIDEO

FILTER CONTROL

MR37

0 ENABLE
1 DISABLE

MR36 MR35

0 0 NO DATA OUT
0 1 ODD FIELD ONLY
1 0 EVEN FIELD ONLY
1 1 DATA OUT

CLOSED CAPTIONING

FIELD SELECTION

(BOTH FIELDS)

TTX BIT REQUEST

MODE CONTROL

MR34

0 DISABLE
1 ENABLE

Teletext Mode Control (MR34)

This bit enables switching of the teletext request signal from a
continuous high signal (MR34 = “0”) to a bit wise request
signal (MR34 = “1”).

Closed Captioning Field Control (MR36–MR35)

These bits control the fields that closed captioning data is dis­played on. Closed captioning information can be displayed on
an odd field, even field or both fields.

Active Video Filter Switching (MR37)

This bit, controls the filter mode applied outside the active
video portion of the line. This filter ensures that the sync rise
and fall times are always on spec regardless of which luma filter
is selected.

MR31

RESERVED FOR
REVISION CODE

MR30

MR31
MR30

TELETEXT

CONTROL

MR33

0 DISABLE
1 ENABLE

MR32MR34 MR33MR35MR36

VBI OPEN

MR32

0 DISABLE
1 ENABLE

Figure 47. Mode Register 3 (MR3)

–29–REV. A

ADV7172/ADV7173

MODE REGISTER 4 MR4 (MR47–MR40)
(Address (SR4–SR0) = 04H)

Mode Register 4 is a 8-bit wide register. Figure 48 shows the
various operations under the control of Mode Register 4.

MR4 BIT DESCRIPTION
VSYNC_3H Control (MR40)

When this bit is enabled (“1”) in slave mode, it is possible to
drive the VSYNC active low input for 2.5 lines in PAL mode
and 3 lines in NTSC mode. When this bit is enabled in master
mode, the ADV7172/ADV7173 outputs an active low VSYNC
signal for 3 lines in NTSC mode and 2.5 lines in PAL mode.

Genlock Control (MR42–MR41)

These bits control the genlock feature of the ADV7172/ADV7173.
Setting MR41 to Logic “0” disables the SCRESET/RTC pin
and allows the ADV7172/ADV7173 to operate in normal mode.
By setting MR41 to “1,” one of two operations may be enabled:

1. If MR42 is set to “0,” the SCRESET/RTC pin is configured
as a subcarrier reset input and the subcarrier phase will reset
to Field 0 whenever a high-to-low field transition is detected
on the SCRESET/RTC pin.

2. If MR42 is set to “1,” the SCRESET/RTC pin is configured
as a real-time control input and the ADV7172/ADV7173 can
be used to lock to an external video source.

Active Video Line Width Control (MR43)

This bit switches between two active video line durations. A
“0” selects ITU-R BT.470 (720 pixels PAL/NTSC) and a “1”
selects ITU-R/SMPTE “analog” standard for active video dura­tion (710 pixels NTSC, 702 pixels PAL).

Chrominance Control (MR44)

This bit enables the color information to be switched on and off
the video output.

Burst Control (MR45)

This bit enables the color burst information to be switched on
and off the video output.

Color Bar Control (MR46)

This bit can be used to generate and output an internal color
bar test pattern. The color bar configuration is 100/7.5/75/7.5
for NTSC and 100/0/75/0 for PAL. It is important to note that
when color bars are enabled the ADV7172/ADV7173 is config­ured in a master timing mode. The output pins VSYNC/FIELD,
HSYNC and BLANK are three-state during color bar mode.

Interlaced Mode Control (MR47)

This bit is used to setup the output to interlaced or noninter­laced mode.

INTERLACE

CONTROL

MR47

0 INTERLACED
1 NONINTERLACED

COLOR BAR

CONTROL

MR46

0 DISABLE
1 ENABLE

CHROMINANCE

MR44

0 ENABLE COLOR
1 DISABLE COLOR

BURST

CONTROL

MR45

0 ENABLE BURST
1 DISABLE BURST

CONTROL

MR43

0 CCIR 624 OUTPUT
1 CCIR 601 OUTPUT

MR42 MR41

CCIR 624/CCIR 601

CONTROL

Figure 48. Mode Register 4 (MR4)

MR41 MR40MR47 MR42MR44 MR43MR45MR46

GENLOCK SELECTION

x 0 DISABLE GENLOCK
0 1 ENABLE SUBCARRIER

1 1 ENABLE RTC PIN

RESET PIN

MR40

VSYNC 3H

0 DISABLE
1 ENABLE

–30– REV. A

ADV7172/ADV7173

MODE REGISTER 5 MR5 (MR57–MR50)
(Address (SR4-SR0) = 05H)

Mode Register 5 is an 8-bit-wide register. Figure 49 shows the
various operations under the control of Mode Register 5.

MR5 BIT DESCRIPTION
Y-Level Control (MR50)

This bit controls the Y output level on the ADV7172/ADV7173.
If this bit is set (“0”), the encoder outputs SMPTE levels when
configured in PAL mode and Betacam levels when configured in
NTSC mode. If this bit is set (“1”), the encoder outputs Beta­cam levels when configured in PAL mode and SMPTE levels
when configured in NTSC mode.

UV-Levels Control (MR52–MR51)

These bits control the U and V output levels on the ADV7172/
ADV7173. It is possible to have UV levels with a peak-peak
amplitude of either 700 mV (MR52 + MR51 = “01”) or 1000 mV
(MR52 + MR51 = “10”) in NTSC and PAL. It is also possible
to have default values of 934 mV for NTSC and 700 mV for
PAL (MR52 + MR51 = “00”).

MR57

CLAMP POSITION

MR57

0 FRONT PORCH
1 BACK PORCH

CLAMP DELAY

MR55 MR54

0 0 NO DELAY
011 3 PCLK
102 3 PCLK
113 3 PCLK

RGB Sync (MR53)

This bit is used to set up the RGB outputs with the sync infor­mation encoded on all RGB outputs.

Clamp Delay Value (MR55–MR54)

These bits control the delay or advance of the CLAMP signal in
the front or back porch of the ADV7172/ADV7173. It is pos­sible to delay or advance the pulse by 0, 1, 2 or 3 clock cycles.

Clamp Delay Direction (MR56)

This bit controls a positive or negative delay in the CLAMP
signal. If this bit is set (“1”), the delay is negative. If it is not set
(“0”), the delay is positive.

Clamp Position (MR57)

This bit controls the position of the CLAMP signal. If this bit is
set (“1”), the CLAMP signal is located in the back porch posi­tion. If this bit is set to (“0”), the CLAMP signal is located in
the front porch position.

MR52MR54 MR53MR55MR56

UV LEVEL CONTROL

MR52 MR51

0 0 DEFAULT LEVELS
0 1 700 mV
1 0 1000 mV
1 1 RESERVED

MR51

MR50

CLAMP DELAY

DIRECTION

MR56

0 POSITIVE
1 NEGATIVE

RGB

SYNC

MR53

0 DISABLE
1 ENABLE

Figure 49. Mode Register 5 (MR5)

Y LEVEL

CONTROL

MR50

0 DISABLE
1 ENABLE

–31–REV. A

ADV7172/ADV7173

MODE REGISTER 6 MR6 (MR67–MR60)
(Address (SR4–SR0) = 06H)

Mode Register 6 is an 8-bit-wide register. Figure 50 shows the
various operations under the control of Mode Register 6.

MR6 BIT DESCRIPTION
Power Up Sleep Mode Control (MR60)

After reset this bit is set to “0,” if both SCRESET/RTC and
NTSC_PAL pins are tied high, the part will power-up in sleep
mode (to facilitate low power consumption before the I
initialized). When this bit is set to “1” (via the I

2

2

C is

C), sleep mode

control passes to Mode Register 2, Bit 7.

Reserved (MR61)

A Logic “0” must be written to this bit.

Luma Autodetect Control (MR62)

This bit controls which mode of autodetect operation is being
used on the luma DAC (DAC B) on the ADV7172/ADV7173.
If this bit is set (“0”), Mode 0 is on; if this bit is set (“1”), then
Mode 1 is being used.

Composite Autodetect Control (MR63)

This bit controls which mode of autodetect operation is being
used on the composite DAC (DAC A) on the ADV7172/
ADV7173. If this bit is set (“0”), Mode 0 is on; if this bit is set
(“1”), then Mode 1 is being used.

DAC Termination Control Bit (MR64)

This bit controls the load termination resistance detected by the
autodetect functionality. If this bit is set (“0”), the autodetect

feature is used to determine if a 75 Ω termination is present. If

this bit is set to (“1”), the autodetect feature is used to indicate

if a 150 Ω termination is present.

Reserved (MR65)

A Logic “0” must be written to this bit.

Luma DAC Status Bit (MR66)

This bit is a read-only status bit for the autodetect feature of
the ADV7172/ADV7173 and may be read to check whether
or not the composite DAC is terminated. If this bit is set (“1”),
there is no termination; if this bit is set (“0”), the composite DAC
is terminated.

Composite DAC Status Bit (MR67)

This bit is a read only status bit for the autodetect feature of the
ADV7172/ADV7173 and may be read to check whether or not
the luma DAC is terminated. If this bit is set (“1”), there is no
termination. If this bit is set (“0”), the luma DAC is terminated.

MR67

COMPOSITE

AUTODETECT STATUS

MR67

0 NOT TERMINATED
1 TERMINATED

AUTODETECT STATUS

MR66

0 NOT TERMINATED
1 TERMINATED

COMP AUTODETECT

MODE CONTROL

MR63

0 MODE 0
1 MODE 1

LUMA

MR65 (0)

ZERO SHOULD

BE WRITTEN TO

THIS BIT

DAC TERMINATION

MODE CONTROL

MR64

01 3 MODE
12 3 MODE

Figure 50. Mode Register 6 (MR6)

MR62MR64 MR63MR65MR66

ZERO SHOULD

BE WRITTEN TO

LUMA AUTODETECT

MODE CONTROL

MR62

0 MODE 0
1 MODE 1

MR61

MR61 (0)

THIS BIT

POWER-UP SLEEP

MODE CONTROL

MR60

0 ENABLE
1 DISABLE

MR60

–32– REV. A

ADV7172/ADV7173

MODE REGISTER 7 MR7 (MR77–MR70)
(Address (SR4–SR0) = 07H)

Mode Register 7 is an 8-bit-wide register. Figure 51 shows the
various operations under the control of Mode Register 7.

MR7 BIT DESCRIPTION
Color Control Enable Bit (MR70)

This bit is used to enable control of contrast and saturation of
color. If this bit is set (“1”), color controls are enabled; if this
bit is set (“0”), the color control features are disabled.

Luma Saturation Control (MR71)

When this bit is set (“1”), the luma signal will be clipped if it
reaches a limit that corresponds to an input luma value of
255 after scaling by the contrast control. This prevents the
chrominance component of the composite video signal being
clipped if the amplitude of the luma is too high. When this bit is
set (“0”), this control is disabled.

Hue Adjust Enable Bit (MR72)

This bit is used to enable hue adjustment on the composite and
chroma output signals of the ADV7172/ADV7173. When this
bit is set (“1”), the hue of the color is adjusted by the phase
offset described in the Hue Adjust Control Register. When this
bit is set (“0”) hue adjustment is disabled.

Brightness Enable Bit (MR73)

This bit is used to enable brightness control on the ADV7172/
ADV7173 by enabling the programmable “setup level” or ped­estal described in the Brightness Control Register to be added to
the scaled Y data. When this bit is set (“1”), brightness control
is enabled. When this bit is set (“0”) brightness control is disabled.

Sharpness Response Enable Bit (MR74)

This bit is used to enable the sharpness of the luminance signal
on the ADV7172/ADV7173 (MR04–MR02 = 100). The various
responses of the filter are determined by the Sharpness Response
Register. When this bit is set (“1”) the luma response is altered
by the amount described in the Sharpness Response Register.
When this bit is set (“0”), the sharpness control is disabled (see
Figures 19, 20 and 21 for luma signal responses).

HSO–CSO Output Select (MR75)

This bit is used to determine whether HSO or CSO TTL out­put signal is output at the CSO_HSO pin. If this bit is set (“1”),
then the CSO TTL signal is output. If this bit is set (“0”), then
the HSO TTL signal is output.

Reserved (MR77–MR76)

A Logic “0” must be written to these bits.

MR71 MR70MR77 MR72MR74 MR73MR75MR76

OUTPUT CONTROL
MR75

0 HSO OUT
1 CSO OUT

ZERO SHOULD

BE WRITTEN TO

THESE BITS

MR77 MR76 (0)

CSO/HSO

RESPONSE ENABLE

MR74

SHARPNESS

0 DISABLE
1 ENABLE

BRIGHTNESS

ENABLE CONTROL

MR73

0 DISABLE
1 ENABLE

HUE ADJUST

MR72

LUMA SATURATION

ENABLE

0 DISABLE
1 ENABLE

Figure 51. Mode Register 7 (MR7)

CONTROL

MR71

0 DISABLE
1 ENABLE

COLOR CONTROL

ENABLE

MR70

0 DISABLE
1 ENABLE

–33–REV. A

ADV7172/ADV7173

TIMING REGISTER 0 (TR07–TR00)
(Address (SR4–SR0) = 07H)

Figure 52 shows the various operations under the control of
Timing Register 0. This register can be read from as well as
written to.

TR0 BIT DESCRIPTION
Master/Slave Control (TR00)

This bit controls whether the ADV7172/ADV7173 is in master
or slave mode.

Timing Mode Control (TR02–TR01)

These bits control the timing mode of the ADV7172/ADV7173.
These modes are described in more detail in the Timing and
Control section of the data sheet.

BLANK Control (TR03)

This bit controls whether the BLANK input is used when the
part is in slave mode or whether BLANK is internally generated.

TIMING

REGISTER RESET

TR07

BLANK INPUT

CONTROL

TR03

0 ENABLE
1 DISABLE

Luma Delay Control (TR05–TR04)

These bits control the addition of a delay to the luminance with
respect to the chrominance. Each bit represents a delay of 74 ns.

Min Luminance Value (TR06)

The bit is used to control the minimum luma value output by
the ADV7172/ADV7173. When this bit is set to (“1”), the luma
is limited to 7.5 IRE below the blank level. When this bit is set
to (“0”), the luma value can be as low as the sync bottom level.

Timing Register Reset (TR07)

Toggling TR07 from low to high and low again resets the inter­nal timing counters. This bit should be toggled after power-up,
reset or changed to a new timing mode.

TR02TR03TR05TR06 TR04

TR01

MASTER/SLAVE

CONTROL

TR00

0 SLAVE TIMING
1 MASTER TIMING

TR00TR07

MIN LUMA CONTROL

TR06

0 LUMA MIN =

SYNC BOTTOM

1 LUMA MIN =

BLANK –7.5 IRE

LUMA DELAY

TR05 TR04

0 0 0ns DELAY
0 1 74ns DELAY
1 0 148ns DELAY
1 1 222ns DELAY

TR02 TR01

0 0 MODE 0
0 1 MODE 1
1 0 MODE 2
1 1 MODE 3

Figure 52. Timing Register 0

TIMING MODE

SELECTION

–34– REV. A

ADV7172/ADV7173

TIMING REGISTER 1 (TR17–TR10)
(Address (SR4–SR0) = 0BH)

Timing Register 1 is an 8-bit-wide register.

Figure 53 shows the various operations under the control of
Timing Register 1. This register can be read from as well writ­ten to. This register can be used to adjust the width and posi­tion of the master mode timing signals.

TR1 BIT DESCRIPTION
HSYNC Width (TR11–TR10)

These bits adjust the HSYNC pulsewidth.

HSYNC to FIELD/VSYNC Delay Control (TR13–TR12)

These bits adjust the position of the HSYNC output relative to
the FIELD/VSYNC output.

HSYNC TO PIXEL

DATA ADJUSTMENT

TR17 TR16

000 3 T
011 3 T
102 3 T
113 3 T

TIMING MODE 1 (MASTER/PAL)

FIELD/VSYNC

PCLK
PCLK
PCLK
PCLK

HSYNC

HSYNC TO FIELD

RISING EDGE DELAY

(MODE 1 ONLY)

TR15 TR14

x0T
x1TB + 32ms

VSYNC WIDTH

(MODE 2 ONLY)

TR15 TR14

001 3 T
014 3 T
1 0 16 3 T
1 1 128 3 T

T

A

T

B

T

C

B

PCLK
PCLK

PCLK

PCLK

HSYNC to FIELD Delay Control (TR15–TR14)

When the ADV7172/ADV7173 is in Timing Mode 1, these bits
adjust the position of the HSYNC output relative to the FIELD
output rising edge.

VSYNC Width (TR15–TR14)

When the ADV7172/ADV7173 is configured in Timing Mode
2, these bits adjust the VSYNC pulsewidth.

HSYNC to Pixel Data Adjust (TR17–TR16)

This enables the HSYNC to be adjusted with respect to the
pixel data. This allows the Cr and Cb components to be
swapped. This adjustment is available in both master and slave
timing modes.

T

B

PCLK
PCLK
PCLK

PCLK

TR11

LINE 313 LINE 314LINE 1

T

C

TR10TR17

HSYNC WIDTH

TR11 TR10

001 3 T
014 3 T
1 0 16 3 T
1 1 128 3 T

T

A

PCLK
PCLK

PCLK

PCLK

TR12TR13TR15TR16 TR14

HSYNC TO

FIELD/VSYNC DELAY

TR13 TR12

000 3 T
014 3 T
108 3 T
1 1 16 3 T

Figure 53. Timing Register 1

–35–REV. A

ADV7172/ADV7173

FIELD 1/3

LINE 17 LINE 16 LINE 15 LINE 14 LINE 13 LINE 12 LINE 11 LINE 10

PCO6

PCO5 PCO3 PCO1PCO4 PCO0PCO7 PCO2

FIELD 1/3

LINE 25 LINE 24 LINE 23 LINE 22 LINE 21 LINE 20 LINE 19 LINE 18

PCO14

PCO13 PCO11 PCO9PCO12 PCO8PCO15 PCO10

FIELD 2/4

LINE 17 LINE 16 LINE 15 LINE 14 LINE 13 LINE 12 LINE 11 LINE 10

PCE6

PCE5 PCE3 PCE1PCE4 PCE0PCE7 PCE2

FIELD 2/4

LINE 25 LINE 24 LINE 23 LINE 22 LINE 21 LINE 20 LINE 19 LINE 18

PCE14

PCE13 PCE11 PCE9PCE12 PCE8PCE15 PCE10

FIELD 2/4

LINE 22 LINE 21 LINE 20 LINE 19 LINE 18 LINE 17 LINE 16 LINE 15

TXE14 TXE13 TXE11 TXE9TXE12 TXE8TXE15 TXE10

FIELD 1/3

LINE 14 LINE 13 LINE 12 LINE 11 LINE 10 LINE 9 LINE 8 LINE 7

TXO6 TXO5 TXO3 TXO1TXO4 TXO0TXO7 TXO2

FIELD 1/3

LINE 22 LINE 21 LINE 20 LINE 19 LINE 18 LINE 17 LINE 16 LINE 15

TXO14 TXO13 TXO11 TXO9TXO12 TXO8TXO15 TXO10

FIELD 2/4

LINE 14 LINE 13 LINE 12 LINE 11 LINE 10 LINE 9 LINE 8 LINE 7

TXE6 TXE5 TXE3 TXE1TXE4 TXE0TXE7 TXE2

SUBCARRIER FREQUENCY REGISTERS 3–0
(FSC3–FSC0)
(Address (SR4–SR0) = 0CH–0FH)

These 8-bit-wide registers are used to set up the subcarrier
frequency. The value of these registers is calculated by using the
following equation:

Subcarrier Frequency gister

Example: NTSC Mode,

= 27 MHz,

f

CLK

= 3.5795454 MHz

f

SCF

Subcarrier FrequencyValue =

Re =

2

27 10

32

2

–1

f

×

f

32

–.1

××

6

×

SCF

CLK

3 579454 10

6

= 21F07C16 HEX

Figure 54 shows how the frequency is set up by the four
registers.

SUBCARRIER PHASE REGISTER (FP7–FP0)
(Address (SR4–SR0) = 10H)

This 8-bit-wide register is used to set up the subcarrier phase.

Each bit represents 1.41°. For normal operation this register is

set to 00Hex.

SUBCARRIER

FREQUENCY

REG 3

SUBCARRIER

FREQUENCY

REG 2

SUBCARRIER

FREQUENCY

REG 1

SUBCARRIER

FREQUENCY

REG 0

FSC30

FSC29 FSC27 FSC25FSC28 FSC24FSC31 FSC26

FSC22 FSC21 FSC19 FSC17FSC20 FSC16FSC23 FSC18

FSC13 FSC11 FSC9FSC12 FSC8FSC15 FSC10

FSC14

FSC6 FSC5 FSC3 FSC1FSC4 FSC0FSC7 FSC2

CLOSED CAPTIONING ODD FIELD
DATA REGISTER 1–0 (CCD15–CCD00)
(Subaddress (SR4–SR0) = 13–14H)

These 8-bit-wide registers are used to set up the closed captioning
data bytes on odd fields. Figure 56 shows how the high and low
bytes are set up in the registers.

BYTE 1

BYTE 0

CCD13 CCD11 CCD9CCD12 CCD8CCD15 CCD10

CCD14

CCD6 CCD5 CCD3 CCD1CCD4 CCD0CCD7 CCD2

Figure 56. Closed Captioning Data Register

NTSC PEDESTAL/PAL TELETEXT CONTROL
REGISTERS 3–0 (PCE15–0, PCO15–0)/(TXE15–0, TXO15–0)
(Subaddress (SR4–SR0) = 15–18H)

These 8-bit-wide registers are used to enable the NTSC pedes­tal/PAL Teletext on a line-by-line basis in the vertical blanking
interval for both odd and even fields. Figures 57 and 58 show
the four control registers. A Logic “1” in any of the bits of
these registers has the effect of turning the Pedestal OFF on
the equivalent line when used in NTSC. A Logic “1” in any of
the bits of these registers has the effect of turning Teletext ON
on the equivalent line when used in PAL.

Figure 54. Subcarrier Frequency Registers

CLOSED CAPTIONING EVEN FIELD
DATA REGISTER 1–0 (CED15–CED00)
(Address (SR4–SR0) = 11–12H)

These 8-bit wide registers are used to set up the closed captioning
extended data bytes on even fields. Figure 55 shows how the
high and low bytes are set up in the registers.

BYTE 1

BYTE 0

CED14

CED13 CED11 CED9CED12 CED8CED15 CED10

CED6

CED5 CED3 CED1CED4 CED0CED7 CED2

Figure 55. Closed Captioning Extended Data Register

Figure 57. Pedestal Control Registers

Figure 58. Teletext Control Registers

–36– REV. A

ADV7172/ADV7173

TELETEXT CONTROL REGISTER TC07 (TC07–TC00)
(ADDRESS (SR4–SR0) = 1CH)

Teletext Control Register is an 8-bit-wide register. See Figure

59.

TTXREQ Rising Edge Control (TC07–TC04)

These bits control the position of the rising edge of TTXREQ.
It can be programmed from zero CLOCK cycles to a max of 15
CLOCK cycles.

TTXREQ Falling Edge Control (TC03–TC00)

These bits control the position of the falling edge of TTXREQ.
It can be programmed from zero CLOCK cycles to a max of 15
CLOCK cycles. This controls the active window for Teletext
data. Increasing this value reduces the amount of Teletext Bits
below the default of 360. If Bits TC03–TC00 are 00Hex when
Bits TC07–TC04 are changed, then the falling edge of TTREQ
will track that of the rising edge (i.e., the time between the
falling and rising edge remains constant).

CGMS_WSS REGISTER 0 C/W0 (C/W07–C/W00)
(ADDRESS (SR4–SR0) = 19H)

CGMS_WSS Register 0 is an 8-bit-wide register. Figure 60
shows the operations under control of this register.

TC07

C/W BIT DESCRIPTION
CGMS Data Bits (C/W03–C/W00)

These four data bits are the final four bits of CGMS data output
stream. Note it is CGMS data ONLY in these bit positions i.e.,
WSS data does not share this location.

CGMS CRC Check Control (C/W04)

When this bit is enabled (“1”), the last six bits of the CGMS
data, i.e., the CRC check sequence, are calculated internally by
the ADV7172/ADV7173. If this bit is disabled (“0”), the CRC
values in the register are output to the CGMS data stream.

CGMS Odd Field Control (C/W05)

When this bit is set (“1”), CGMS is enabled for odd fields.
Note that this is only valid in NTSC mode.

CGMS Even Field Control (C/W06)

When this bit is set (“1”), CGMS is enabled for even fields.
Note that this is only valid in NTSC mode.

WSS Control (C/W07)

When this bit is set (“1”), wide screen signalling is enabled.
Note that this is only valid in PAL mode.

TC02TC04 TC03TC05TC06

TC01 TC00

TTXREQ RISING EDGE CONTROL

TC07 TC06 TC05 TC04

0 0 0 0 0 PCLK
0 0 0 1 1 PCLK
" " " " " PCLK
1 1 1 0 14 PCLK
1 1 1 1 15 PCLK

C/W07 C/W06 C/W05 C/W04 C/W03 C/W02 C/W01 C/W00

WIDE SCREEN SIGNAL

CONTROL

C/W07

0 DISABLE
1 ENABLE

CGMS EVEN FIELD

C/W06

0 DISABLE
1 ENABLE

TTXREQ FALLING EDGE CONTROL

TC03 TC02 TC01 TC00

0 0 0 0 0 PCLK
0 0 0 1 1 PCLK
" " " " " PCLK
1 1 1 0 14 PCLK
1 1 1 1 15 PCLK

Figure 59. Teletext Control Register

CGMS ODD FIELD

CONTROL

C/W05

0 DISABLE
1 ENABLE

CONTROL

CGMS CRC CHECK

CONTROL

C/W04

0 DISABLE
1 ENABLE

Figure 60. CGMS_WSS Register 0

C/W03–C/W00

CGMS DATA BITS

–37–REV. A

ADV7172/ADV7173

CGMS_WSS REGISTER 1 C/W1 (C/W17–C/W10)
(Address (SR4–SR0) = 1AH)

CGMS_WSS Register 1 is an 8-bit-wide register. Figure 61 shows
the operations under control of this register.

C/W1 BIT DESCRIPTION
CGMS/WSS Data Bits (C/W15–C/W10)

These bit locations are shared by CGMS data and WSS data. In
NTSC mode these bits are CGMS data. In PAL mode these
bits are WSS data.

CGMS Data Bits (C/W17–C/W16)

These bits are CGMS data bits only.

CGMS_WSS REGISTER 2 C/W1(C/W27–C/W20)
(Address (SR4-SR0) = 1BH)

CGMS_WSS Register 2 is an 8-bit-wide register. Figure 62
shows the operations under control of this register.

C/S BIT DESCRIPTION
CGMS/WSS Data Bits (C/W27–C/W20)

These bit locations are shared by CGMS data and WSS data. In
NTSC mode these bits are CGMS data. In PAL mode these
bits are WSS data.

C/W17 C/W16 C/W15 C/W14 C/W13 C/W12 C/W11 C/W10

CONTRAST CONTROL REGISTER (CC07–CC00)
(Address (SR4–SR0) = 1DH)

The contrast control register is an 8-bit-wide register used to
scale the Y output levels. Figure 63 shows the operation under
control of this register.

CC0 BIT DESCRIPTION
Reserved (CC07–CC06)

A Logic “0” must be written to these bits.

Y Scalar Value (CC05–CC00)

These six bits represent the value required to scale the Y pixel
data from 0.75 to 1.25 of its initial level. The value of these six
bits is calculated using the following equation:

Contrast Control Register = (X –0.785) × 128

where X = Scaling factor for Y
e.g., Scale Y by 0.9

Contrast Control Register = (0.9–0.75) × 128 = 19.2 = 010011

(rounded to the nearest integer)

Actual scaling factor = 0.898.

C/W17 C/W16

CGMS DATA ONLY

C/W15–C/W10

CGMS/WSS DATA

Figure 61. CGMS_WSS Register 1

C/W27 C/W26 C/W25 C/W24 C/W23 C/W22 C/W21 C/W20

C/W27–C/W20

CGMS/WSS DATA

Figure 62. CGMS_WSS Register 2

CC07 CC06 CC05 CC04 CC03 CC02 CC01 CC00

CC07 CC06

ZERO SHOULD

BE WRITTEN

TO THESE BITS

CC05–CC00

Y SCALAR VALUE

Figure 63. Contrast Control Register

–38– REV. A

ADV7172/ADV7173

COLOR CONTROL REGISTERS 2–1 (CC2–CC1)
(Address (SR4–SR0) = 1EH–1FH)

The color control registers are 8-bit-wide registers used to scale
the U and V output levels. Figure 64 shows the operations un­der control of these registers.

CC1 BIT DESCRIPTION
Reserved (CC17–CC16)

A Logic “0” must be written to these bits.

U Scalar Value (CC15–CC10)

These six bits represent the value required to scale the U level
from 0.75 to 1.25 of its initial level. The value of these six bits is
calculated using the following equation:

Color Control Register 1 = (X – 0.75) × 128

where X = Scaling factor for U
e.g., Scale U by 0.8

Color Control Register 1 = (0.8 – 0.75) × 128 = 6.4 = 000110

(rounded to the nearest integer)

CC2 BIT DESCRIPTION
Reserved (CC27–CC26)

A Logic “0” must be written to these bits.

V Scalar Value (CC25–CC20)

These six bits represent the value required to scale the V pixel
data from 0.75 to 1.25 of its initial level. The value of these six
bits is calculated using the following equation:

Color Control Register 2 = (X – 0.75) × 128

where X = Scaling factor for V
e.g., Scale V by 1.2

Color Control Register 2 = (1.2 – 0.75) × 128 = 57.6 = 111001

(rounded to the nearest integer)

HUE CONTROL REGISTERS (HCR)
(Address (SR5–SR0) = 20H)

The hue control register is an 8-bit-wide register used to adjust
the hue on the composite and chroma outputs. Figure 65 shows
the operation under control of this register.

HCR BIT DESCRIPTION
Hue Control Value (HCR7–HCR0)

These eight bits represent the value required to vary the hue of
the video data, i.e., the variance in phase of the subcarrier with
respect to the phase of the subcarrier during the color burst.

The ADV7172/ADV7173 provides a range of ±22° in incre­ments of 0.17578125°. For normal operation (zero adjustment)

this register is set to 80 Hex. FFHex and 00Hex represent the
upper and lower limit (respectively) of adjustment attainable.

Hue Adjust = (0.17568125 × [HCR7 – HCR0 – 128]).

CC17 CC16 CC15 CC14

CC17 CC16

ZERO SHOULD

BE WRITTEN

TO THESE BITS

CC27 CC26 CC25 CC24 CC23 CC22 CC21 CC20

CC27 CC26

ZERO SHOULD

BE WRITTEN

TO THESE BITS

CC13

U SCALAR VALUE

V SCALAR VALUE

CC12 CC11 CC10

CC15–CC10

CC25–CC20

Figure 64. Color Control Registers

HCR7 HCR6 HCR5 HCR4 HCR3 HCR2 HCR1 HCR0

HCR7–HCR0

HUE ADJUST VALUE

Figure 65. Hue Control Register

–39–REV. A

ADV7172/ADV7173

BRIGHTNESS CONTROL REGISTERS (SCR)
(Address (SR5–SR0) = 21H)

The brightness control register is an 8-bit-wide register which
allows brightness control. Figure 66 shows the operation under
control of this register.

SCR BIT DESCRIPTION
Reserved (SCR7–SCR5)

A Logic “0” must be written to these bits.

Brightness Control Value (SCR4–SCR0)

These five bits represent the value required to vary the “brightness
level” or pedestal added to the luma data. The available range is
from 0 IRE to 7.5 IRE in 18 steps. A value of 18 (10010) corre­sponds to 7.5 IRE setup level added onto the pixel data. This
brightness control is possible in both PAL and NTSC.

SCR7 SCR6 SCR5 SCR4 SCR3 SCR2 SCR1 SCR0

SCR7–SCR5

ZERO SHOULD

BE WRITTEN

TO THESE BITS

Figure 66. Brightness Control Register

SHARPNESS RESPONSE REGISTER (PR)
(Address (SR5-SR0) = 22H)

The sharpness response register is an 8-bit-wide register. The
four MSBs are set to “0.” The four LSBs are written to in order
to select a desired filter response. Figure 67 shows the operation
under control of this register.

PR BIT DESCRIPTION
Reserved (PR7–PR4)

A Logic “0” must be written to these bits.

Sharpness Response Select Value (PR3–PR0)

These four bits are used to select the desired luma filter re­sponse. The option of twelve responses is given supporting a
gain boost/attenuation in the range –4 dB to +4 dB. The value
12 (1100) written to these four bits corresponds to a boost of
+4 dB while the value 0 (0000) corresponds to –4 dB. For nor­mal operation these four bits are set to 6 (0110).

SCR4–SCR0

BRIGHTNESS VALUE

PR7 PR6 PR5 PR4

PR7–PR4

ZERO SHOULD

BE WRITTEN

TO THESE BITS

Figure 67. Sharpness Response Register

PR3 PR2 PR1 PR0

PR3–PR0

SHARPNESS RESPONSE

SELECT

–40– REV. A

APPENDIX 1

BOARD DESIGN AND LAYOUT CONSIDERATIONS

ADV7172/ADV7173

The ADV7172/ADV7173 is a highly integrated circuit containing
both precision analog and high speed digital circuitry. It has
been designed to minimize interference effects on the integrity
of the analog circuitry by the high speed digital circuitry. It is
imperative that these same design and layout techniques be
applied to the system level design so that high speed, accurate
performance is achieved. The Recommended Analog Circuit
Layout shows the analog interface between the device and
monitor.

The layout should be optimized for lowest noise on the ADV7172/
ADV7173 power and ground lines by shielding the digital inputs
and providing good decoupling. The lead length between groups

and GND pins should by minimized to minimize induc-

of V

AA

tive ringing.

Ground Planes

The ground plane should encompass all ADV7172/ADV7173
ground pins, voltage reference circuitry, power supply bypass
circuitry for the ADV7172/ADV7173, the analog output traces,
and all the digital signal traces leading up to the ADV7172/
ADV7173. The ground plane is the board’s common ground
plane.

This should be as substantial as possible to maximize heat
spreading and power dissipation on the board.

Power Planes

The ADV7172/ADV7173, and any associated analog circuitry,
should have its own power plane, referred to as the analog
power plane (V
the regular PCB power plane (V

). This power plane should be connected to

AA

) at a single point through a

CC

ferrite bead. This bead should be located within three inches of
the ADV7172/ADV7173.

The metallization gap separating device power plane and board
power plane should be as narrow as possible to minimize the
obstruction to the flow of heat from the device into the general
board.

The PCB power plane should provide power to all digital logic
on the PC board, and the analog power plane should provide
power to all ADV7172/ADV7173 power pins and voltage refer­ence circuitry.

Plane-to-plane noise coupling can be reduced by ensuring that
portions of the regular PCB power and ground planes do not
overlay portions of the analog power plane unless they can be
arranged so that the plane-to-plane noise is common-mode.

Supply Decoupling

For optimum performance, bypass capacitors should be in­stalled using the shortest leads possible, consistent with reliable
operation, to reduce the lead inductance. Best performance is

obtained with 0.1 µF ceramic capacitor decoupling. Each group

pins on the ADV7172/ADV7173 must have at least one

of V

AA

0.1 µF decoupling capacitor to GND. These capacitors should

be placed as close to the device as possible.

It is important to note that while the ADV7172/ADV7173 con­tains circuitry to reject power supply noise, this rejection de­creases with frequency. If a high frequency switching power
supply is used, the designer should pay close attention to reduc­ing power supply noise and consider using a three-terminal voltage
regulator for supplying power to the analog power plane.

Digital Signal Interconnect

The digital inputs to the ADV7172/ADV7173 should be iso­lated as much as possible from the analog outputs and other
analog circuitry. Also, these input signals should not overlay the
analog power plane.

Due to the high clock rates involved, long clock lines to the
ADV7172/ADV7173 should be avoided to reduce noise pickup.

Any active termination resistors for the digital inputs should be
connected to the regular PCB power plane (V

) and not the

CC

analog power plane.

Analog Signal Interconnect

The ADV7172/ADV7173 should be located as close to the
output connectors as possible to minimize noise pickup and
reflections due to impedance mismatch.

The video output signals should overlay the ground plane, not
the analog power plane, to maximize the high frequency power
supply rejection.

Digital inputs, especially pixel data inputs and clocking signals,
should never overlay any of the analog signal circuitry and
should be kept as far away as possible.

For best performance, the outputs should each have a 75 Ω load

resistor connected to GND. These resistors should be placed
as close as possible to the ADV7172/ADV7173 to minimize
reflections.

The ADV7172/ADV7173 should have no inputs left floating.
Any inputs that are not required should be tied to ground.

–41–REV. A

ADV7172/ADV7173

+5V (VAA)

+5V (VAA)

4kV

RESET

TTX

TTXREQ

4.7mF

+5V (VAA)

10kV

(SAME CLOCK AS

27MHz CLOCK

USED BY MPEG2

+5V (V

0.1mF

“UNUSED
INPUTS
SHOULD BE
GROUNDED”

DECODER)

AA

0.1mF

)

+5V (V

+5V (VAA)

)

AA

0.1mF

36
23
37

10
45
42
43
39
14
15
16
44

41
40

48

10kV

2
9

COMP1

COMP2
V

REF

P0

ADV7172/
ADV7173

P7

CSO_HSO

VSO

CLAMP

PAL_NTSC

SCRESET/RTC

HSYNC
FIELD/VSYNC

BLANK

RESET

TTX
TTXREQ

CLOCK

ALSB

17

POWER SUPPLY DECOUPLING
FOR EACH POWER SUPPLY GROUP

0.1mF 0.01mF

1, 11, 19, 27, 30, 32, 34, 46

V

AA

DAC A

35

75V

33

DAC B

DAC C

DAC D

DAC E

DAC F

SCLOCK

SDATA

SET2

R

SET1

GND

12, 13, 18, 26, 31, 47

75V

29

75V

28

300V

25

300V

24

300V

20

21
22R
38

100V

150V

100V

600V

+5V (VAA)

+5V (VCC)

(FERRITE BEAD)

10mF 33mF

+5V (VCC)

4kV

4kV

L1

MPU BUS

+5V
(V
GND

)

CC

Figure 68. Recommended Analog Circuit Layout

–42– REV. A

APPENDIX 2

CLOSED CAPTIONING

ADV7172/ADV7173

The ADV7172/ADV7173 supports closed captioning, conform­ing to the standard television synchronizing waveform for color
transmission. Closed captioning is transmitted during the
blanked active line time of Line 21 of the odd fields and Line
284 of even fields.

Closed captioning consists of a 7-cycle sinusoidal burst that is
frequency and phase locked to the caption data. After the clock
run-in signal, the blanking level is held for two data bits and is
followed by a Logic Level “1” start bit. 16 bits of data follow
the start bit. These consist of two 8-bit bytes, seven data bits
and one odd parity bit. The data for these bytes is stored in
closed captioning Data Registers 0 and 1.

The ADV7172/ADV7173 also supports the extended closed
captioning operation, which is active during even fields, and is
encoded on scan Line 284. The data for this operation is stored
in closed captioning extended Data Registers 0 and 1.

All clock run-in signals, and timing to support closed caption­ing on Lines 21 and 284, are automatically generated by the
ADV7172/ADV7173. All pixels inputs are ignored during
Lines 21 and 284. Closed captioning is enabled.

10.5 6 0.25ms

12.91ms

7 CYCLES

OF 0.5035 MHz

(CLOCK RUN-IN)

FCC Code of Federal Regulations (CFR) 47 Section 15.119
and EIA608 describe the closed captioning information for
Lines 21 and 284.

The ADV7172/ADV7173 uses a single buffering method. This
means that the closed captioning buffer is only one byte deep,
therefore there will be no frame delay in outputting the closed
captioning data, unlike other 2-byte deep buffering systems.
The data must be loaded at least one line before (Line 20 or
Line 283) it is outputted on Line 21 and Line 284. A typical
implementation of this method is to use VSYNC to interrupt a
microprocessor, which will in turn load the new data (two bytes)
every field. If no new data is required for transmission, zeros must
be inserted in both data registers; this is called NULLING. It is
also important to load “control codes,” all of which are double
bytes, on Line 21, or a TV will not recognize them. If there is a
message like “Hello World,” which has an odd number of char­acters, it is important to pad it out to an even number to get
“end of caption” 2-byte control code to land in the same field.

TWO 7-BIT + PARITY

ASCII CHARACTERS

(DATA)

50 IRE

40 IRE

REFERENCE COLOR BURST

FREQUENCY = F
AMPLITUDE = 40 IRE

(9 CYCLES)

10.003ms

= 3.579545MHz

SC

Figure 69. Closed Captioning Waveform (NTSC)

27.382ms

S
T

D0–D6

A
R

T

BYTE 0

P
A
R

I
T
Y

33.764ms

D0–D6

BYTE 1

P
A
R

I
T
Y

–43–REV. A

ADV7172/ADV7173

APPENDIX 3

COPY GENERATION MANAGEMENT SYSTEM (CGMS)

The ADV7172/ADV7173 supports Copy Generation Management System (CGMS) conforming to the standard. CGMS data is
transmitted on Line 20 of the odd fields and Line 283 of even fields. Bits C/W05 and C/W06 control whether or not CGMS data
is output on ODD and EVEN fields. CGMS data can only be transmitted when the ADV7172/ADV7173 is configured in NTSC
mode. The CGMS data is 20 bits long, the function of each of these bits is as shown below. The CGMS data is preceded by a refer­ence pulse of the same amplitude and duration as a CGMS bit (see Figure 70). These bits are output from the configuration registers
in the following order: C/W00 = C16, C/W01 = C17, C/W02 = C18, C/W03 = C19, C/W10 = C8, C/W11 = C9, C/W12 = C10,
C/W13 = C11, C/W14 = C12, C/W15 = C13, C/W16 = C14, C/W17 = C15, C/W20 = C0, C/W21 = C1, C/W22 = C2, C/W23 = C3,
C/W24 = C4, C/W25 = C5, C/W26 = C6, C/W27 = C7. If the Bit C/W04 is set to a Logic “1,” the last six bits, C19–C14, which
comprise the 6-bit CRC check sequence, are calculated automatically on the ADV7172/ADV7173 based on the lower 14 bits
(C0–C13) of the data in the data registers and output with the remaining 14 bits to form the complete 20 bits of the CGMS data.
The calculation of the CRC sequence is based on the polynomial X
Logic “0,” all 20 bits (C0–C19) are directly output from the CGMS registers (no CRC calculated, must be calculated by the user).

Function of CGMS Bits

Word 0 – 6 Bits
Word 1 – 4 Bits
Word 2 – 6 Bits
CRC – 6 Bits CRC Polynomial = X

6

+ X + 1 (Preset to 111111)

Word 0 1 0
B1 Aspect Ratio 16:9 4:3
B2 Display Format Letterbox Normal
B3 Undefined

Word 0
B4, B5, B6 Identification information about video and other signals (e.g., audio)

Word 1
B7, B8, B9, B10 Identification signal incidental to Word 0

Word 2
B11, B12, B13, B14 Identification signal and information incidental to Word 0

6

+ X + 1 with a preset value of 111111. If C/W04 is set to a

100 IRE

70 IRE

0 IRE

–40 IRE

11.2ms

REF

C0 C1 C2 C3 C4 C5 C6 C7 C8 C9 C10 C11 C12

49.1ms 6 0.5ms

2.235ms 6 20ns

Figure 70. CGMS Waveform Diagram

CRC SEQUENCE

C13 C14 C15 C16

C17 C18 C19

–44– REV. A

ADV7172/ADV7173

APPENDIX 4

WIDE SCREEN SIGNALING

The ADV7172/ADV7173 supports Wide Screen Signaling (WSS) conforming to the standard. WSS data is transmitted on Line 23.
WSS data can only be transmitted when the ADV7172/ADV7173 is configured in PAL mode. The WSS data is 14 bits long, the
function of each of these bits is as shown below. The WSS data is preceded by a run-in sequence and a Start Code (see Figure 71).
The bits are output from the configuration registers in the following order: C/W20 = W0, C/W21 = W1, C/W22 = W2, C/W23 = W3,
C/W24 = W4, C/W25 = W5, C/W26 = W6, C/W27 = W7, C/W10 = W8, C/W11 = W9, C/W12 = W10, C/W13 = W11, C/W14 = W12,
C/W15 = W13. If the Bit C/W07 is set to a Logic “1” it enables the WSS data to be transmitted on Line 23. The latter portion of

Line 23 (42.5 µs from the falling edge of HSYNC) is available for the insertion of video.

Function of CGMS Bits

Bit 0–Bit 2 Aspect Ratio/Format/Position

Bit 3 is odd parity check of Bit 0–Bit 2

B0 B1 B2 B3 Aspect Ratio Format Position
0001 4:3 Full Format Nonapplicable
1000 14:9 Letterbox Center
0100 14:9 Letterbox Top
1101 16:9 Letterbox Center
0010 16:9 Letterbox Top
1011 >16:9 Letterbox Center
0111 14:9 Full Format Center
1110 16:9 Nonapplicable Nonapplicable

B4
0 Camera Mode
1 Film Mode

B5
0 Standard Coding
1 Motion Adaptive Color Plus

B6
0 No Helper
1 Modulated Helper

B7 RESERVED

500mV

11.0ms

RUN-IN

SEQUENCE

START

CODE

B9 B10
0 0 No Open Subtitles
1 0 Subtitles In Active Image Area
0 1 Subtitles Out of Active Image Area
1 1 Reserved

B11
0 No Surround Sound Information
1 Surround Sound Mode

B12 RESERVED
B13 RESERVED

W0 W1 W2 W3 W4 W5 W6 W7 W8 W9 W10 W11 W12 W13

38.4ms

42.5ms

Figure 71. WSS Waveform Diagram

ACTIVE

VIDEO

–45–REV. A

ADV7172/ADV7173

APPENDIX 5

TELETEXT INSERTION

Time, t
puts, such that it appears t

is the time needed by the ADV7172/ADV7173 to interpolate input data on TTX and insert it onto the CVBS or Y out-

PD,

SYNTXTOUT

= 10.2 µs after the leading edge of the horizontal signal. Time, TXT

, is the pipeline delay

DEL

time by the source that is gated by the TTREQ signal in order to deliver TTX data.

With the programmability offered with TTXREQ signal on the Rising/Falling edges, the TTX data is always inserted at the correct

position of 10.2 µs after the leading edge of horizontal sync pulse, thus enabling a source interface with variable pipeline delays.

The width of the TTXREQ signal must always be maintained such that it allows the insertion of 360 (in order to comply with the
Teletext Standard “PAL-WST”) teletext bits at a text data rate of 6.9375 Mbits/s. This is achieved by setting TC03–TC00 to “0.”
The insertion window is not open if the Teletex Enable bit (MR34) is set to “0.”

Teletext Protocol

The relationship between the TTX bit clock (6.9375 MHz) and the system CLOCK (27 MHz) for 50 Hz is given as follows:

(27 MHz/4) = 6.75 MHz

(6.9375 × 10

6

/6.75 × 10

6

) = 1.027777

Thus 37 TTX bits correspond to 144 clocks (27 MHz) and each bit has a width of almost four clock cycles. The ADV7172/ADV7173
uses an internal sequencer and variable phase interpolation filter to minimize the phase jitter and thus generate a bandlimited signal
that can be outputted on the CVBS and Y outputs.

At the TTX input the bit duration scheme repeats after every 37 TTX bits or 144 clock cycles. The protocol requires that TTX Bits
10, 19, 28, 37 are carried by three clock cycles, all other bits by four clock cycles. After 37 TTX bits, the next bits with three clock
cycles are 47, 56, 65 and 74. This scheme holds for all following cycles of 37 TTX bits, until all 360 TTX bits are completed. All
teletext lines are implemented in the same way. Individual control of teletext lines is controlled by Teletext Setup Registers.

45 BYTES (360 BITS) – PAL

TELETEXT VBI LINE

RUN-IN CLOCK

ADDRESS & DATA

CVBS/Y

HSYNC

TXT

DATA

TXTREQ

Figure 72. Teletext VBI Line

t

SYNTXTOUT

t

PD

t

PD

10.2ms

TXT

DEL

TXT

t

SYNTXTOUT

t

= PIPELINE DELAY THROUGH ADV7172/ADV7173

PD

TXT

= TTXREQ TO TTX (PROGRAMMABLE RANGE = 4 BITS [0–15 CLOCK CYCLES])

DEL

ST

= 10.2ms

PROGRAMMABLE PULSE EDGES

Figure 73. Teletext Functionality Diagram

–46– REV. A

APPENDIX 6

NTSC WAVEFORMS (WITH PEDESTAL)

ADV7172/ADV7173

130.8 IRE

100 IRE

7.5 IRE
0 IRE

–40 IRE

100 IRE

7.5 IRE
0 IRE

–40 IRE

1067.7mV

650mV

286mV (pk-pk)

714.2mV

Figure 74. NTSC Composite Video Levels

714.2mV

Figure 75. NTSC Luma Video Levels

835mV (pk-pk)

PEAK COMPOSITE

REF WHITE

BLACK LEVEL
BLANK LEVEL

SYNC LEVEL

REF WHITE

BLACK LEVEL
BLANK LEVEL

SYNC LEVEL

PEAK CHROMA

BLANK/BLACK LEVEL

1268.1mV

1048.4mV

387.6mV

334.2mV

48.3mV

1048.4mV

387.6mV

334.2mV

48.3mV

232.2mV

0mV

100 IRE

7.5 IRE
0 IRE

–40 IRE

Figure 76. NTSC Chroma Video Levels

720.8mV

Figure 77. NTSC RGB Video Levels

PEAK CHROMA

REF WHITE

BLACK LEVEL
BLANK LEVEL

SYNC LEVEL

1052.2mV

387.5mV

331.4mV

45.9mV

–47–REV. A

ADV7172/ADV7173

NTSC WAVEFORMS (WITHOUT PEDESTAL)

130.8 IRE

100 IRE

0 IRE

–40 IRE

100 IRE

0 IRE

–40 IRE

1101.6mV

650mV

307mV (pk-pk)

714.2mV

BLANK/BLACK LEVEL

Figure 78. NTSC Composite Video Levels

714.2mV

BLANK/BLACK LEVEL

Figure 79. NTSC Luma Video Levels

903.2mV (pk-pk)

PEAK COMPOSITE

REF WHITE

SYNC LEVEL

REF WHITE

SYNC LEVEL

PEAK CHROMA

BLANK/BLACK LEVEL

1289.8mV

1052.2mV

338mV

52.1mV

1052.2mV

338mV

52.1mV

198.4mV

0mV

100 IRE

0 IRE

–40 IRE

Figure 80. NTSC Chroma Video Levels

715.7mV

Figure 81. NTSC RGB Video Levels

PEAK CHROMA

REF WHITE

BLANK/BLACK LEVEL

SYNC LEVEL

1052.2mV

336.5mV

51mV

–48– REV. A

PAL WAVEFORMS

ADV7172/ADV7173

1092.5mV

650mV

1284.2mV

1047.1mV

350.7mV

50.8mV

1047mV

350.7mV

50.8mV

300mV (pk-pk)

PEAK COMPOSITE

REF WHITE

696.4mV

BLANK/BLACK LEVEL

SYNC LEVEL

Figure 82. PAL Composite Video Levels

REF WHITE

696.4mV

BLANK/BLACK LEVEL

SYNC LEVEL

Figure 83. PAL Luma Video Levels

PEAK CHROMA

885mV (pk-pk)

BLANK/BLACK LEVEL

207.5mV

0mV

1050.2mV

351.8mV

51mV

PEAK CHROMA

Figure 84. PAL Chroma Video Levels

REF WHITE

698.4mV

BLANK/BLACK LEVEL

SYNC LEVEL

Figure 85. PAL RGB Video Levels

–49–REV. A

ADV7172/ADV7173

BETACAM LEVEL

0mV

82mV

423mV

505mV

0mV

–82mV

–505mV

–423mV

WHITE

YELLOW

CYAN

GREEN

MAGENTA

RED

BLUE

BLACK

SMPTE LEVEL

0mV

57mV

293mV

350mV

0mV

–57mV

–350mV

–293mV

WHITE

YELLOW

CYAN

GREEN

MAGENTA

RED

BLUE

BLACK

WHITE

YELLOW

CYAN

GREEN

334mV

MAGENTA

RED

BLUE

505mV

UV WAVEFORMS

BLACK

BETACAM LEVEL

0mV

171mV

0mV

2171mV

2334mV

2505mV

Figure 86. NTSC 100% Color Bars, No Pedestal U Levels

WHITE

YELLOW

CYAN

GREEN

MAGENTA

RED

BLUE

BLACK

467mV

309mV

BETACAM LEVEL

0mV

158mV

0mV

–158mV

Figure 89. NTSC 100% Color Bars, No Pedestal V Levels

WHITE

YELLOW

CYAN

GREEN

MAGENTA

RED

BLUE

BLACK

0mV

–76mV

BETACAM LEVEL

0mV

467mV

391mV

76mV

Figure 87. NTSC 100% Color Bars with Pedestal U Levels

–309mV

–467mV

WHITE

YELLOW

CYAN

GREEN

MAGENTA

RED

BLUE

350mV

SMPTE LEVEL

0mV

–350mV

118mV

Figure 88. PAL 100% Color Bars, U Levels

–232mV

232mV

–118mV

–391mV

–467mV

Figure 90. NTSC 100% Color Bars with Pedestal V Levels

BLACK

0mV

Figure 91. PAL 100% Color Bars, V Levels

–50– REV. A

APPENDIX 7

V

OUT

= I

OUT

× R

LOAD

I

OUT

=

V

REF

× K

()

R

SET

K = 4.2146 constant ,V

REF

=1.235 V

300V

75V

OUTPUT TO
OUTPUT FILTER/
TV MONITOR

1kV

INPUT

+V

CC

AD847

–V

CC

1kV

OPTIONAL OUTPUT FILTER

ADV7172/ADV7173

If an output filter is required for the CVBS, Y, UV, Chroma
and RGB outputs of the ADV7172/ADV7173, the filter shown
below can be used. The plot of the filter characteristics is
shown in Figure 93. An Output Filter is not required if the
outputs of the ADV7172/ADV7173 are connected to most
analog monitors or analog TVs; however, if the output signals
are applied to a system where sampling is used (e.g., Digital
TVs), then a filter is required to prevent aliasing.

22pF

2.2mH

FILTER I/P FILTER O/P

270pF

330pF

Figure 92. Output Filter Used with Output Buffer

APPENDIX 8

OPTIONAL DAC BUFFERING

0

–5

–10
–15
–20
–25
–30
–35
–40

DECIBELS

–45
–50
–55
–60
–65

–70

VdB – OP

10k 100M100k 1M 10M

FREQUENCY – Hz

Figure 93. Output Filter Plot

When external buffering is needed of the ADV7172/ADV7173
DAC outputs, the configuration in Figure 94 is recommended.
This configuration shows the DAC outputs, A, B, C, running at
half (18 mA) their full current (36 mA) capability. This will
allow the ADV7172/ADV7173 to dissipate less power; the analog
current is reduced by 50% with a R

600 Ω and an R

3.3 V operation as optimum performance is obtained from the

300V

PIXEL

PORT

600V

R

Figure 94. Output DAC Buffering Configuration

of 75 Ω. This mode is recommended for

LOAD

ADV7172/ADV7173

V

REF

R

SET1

DIGITAL

CORE

SET2

= 300 Ω and R

SET1

V

AA

DAC A CVBS

DAC B

DAC C

DAC D

DAC E

DAC F

OUTPUT
BUFFER

OUTPUT
BUFFER

OUTPUT
BUFFER

OUTPUT
BUFFER

OUTPUT
BUFFER

OUTPUT
BUFFER

SET2

LUMA

CHROMA

G

B

R

DAC outputs at 18 mA with a V

of 3.3 V. This buffer also

AA

adds extra isolation on the video outputs (see buffer circuit in
Figure 95). Note that DACs D, E and F will always require
buffering as the full-scale output current from these DACs is
limited to 8.66 mA. With DACs A, B and C, buffering is op-

=

tional, based on the user requirements for performance and power
consumption.

When calculating absolute output full-scale current and voltage,
use the following equations:

Figure 95. Recommended Output DAC Buffer

–51–REV. A

ADV7172/ADV7173

APPENDIX 9

RECOMMENDED REGISTER VALUES

The ADV7172/ADV7173 registers can be set depending on the
user standard required.

The following examples give the various register formats for
several video standards.

In each case the output is set to composite/luma/chroma outputs
with DACs D, E and F powered up to provide 8.66 mA and
with the BLANK input control disabled. Additionally, the burst
and color information are enabled on the output and the inter­nal color bar generator is switched off. In the examples shown,
the timing mode is set to Mode 0 in slave format. TR02–TR00
of the Timing Register 0 control the timing modes. For a de­tailed explanation of each bit in the command registers, please
turn to the Register Programming section of the data sheet.
TR07 should be toggled after setting up a new timing mode.
Timing Register 1 provides additional control over the position
and duration of the timing signals. In the examples this register
is programmed in default mode.

NTSC (FSC = 3.5795454 MHz)
Address Data

00Hex Mode Register 0 10Hex
01Hex Mode Register 1 07Hex
02Hex Mode Register 2 68Hex
03Hex Mode Register 3 00Hex
04Hex Mode Register 4 00Hex
05Hex Mode Register 5 00Hex
06Hex Mode Register 6 00Hex
07Hex Mode Register 7 00Hex
0AHex Timing Register 0 00Hex
0BHex Timing Register 1 00Hex
0CHex Subcarrier Frequency Register 0 16Hex
0DHex Subcarrier Frequency Register 1 7CHex
0EHex Subcarrier Frequency Register 2 F0Hex
0FHex Subcarrier Frequency Register 3 21Hex
10Hex Subcarrier Phase Register 00Hex
11Hex Closed Captioning Ext Register 0 00Hex
12Hex Closed Captioning Ext Register 1 00Hex
13Hex Closed Captioning Register 0 00Hex
14Hex Closed Captioning Register 1 00Hex
15Hex Pedestal Control Register 0 00Hex
16Hex Pedestal Control Register 1 00Hex
17Hex Pedestal Control Register 2 00Hex
18Hex Pedestal Control Register 3 00Hex
19Hex CGMS_WSS Reg 0 00Hex
1AHex CGMS_WSS Reg 1 00Hex
1BHex CGMS_WSS Reg 2 00Hex
1CHex Teletext Control Register 00Hex
1DHex Contrast Control Register 00Hex
1EHex Color Control Register 1 00Hex
1FHex Color Control Register 2 00Hex
20Hex Hue Control Register 00Hex
21Hex Brightness Control Register 00Hex
22Hex Sharpness Response Register 00Hex

PAL B, D, G, H, I (FSC = 4.43361875 MHz)
Address Data

00Hex Mode Register 0 11Hex
01Hex Mode Register 1 07Hex
02Hex Mode Register 2 68Hex
03Hex Mode Register 3 00Hex
04Hex Mode Register 4 00Hex
05Hex Mode Register 5 00Hex
06Hex Mode Register 6 01Hex
07Hex Mode Register 7 00Hex
0AHex Timing Register 0 00Hex
0BHex Timing Register 1 00Hex
0CHex Subcarrier Frequency Register 0 CBHex
0DHex Subcarrier Frequency Register 1 8AHex
0EHex Subcarrier Frequency Register 2 09Hex
0FHex Subcarrier Frequency Register 3 2AHex
10Hex Subcarrier Phase Register 00Hex
11Hex Closed Captioning Ext Register 0 00Hex
12Hex Closed Captioning Ext Register 1 00Hex
13Hex Closed Captioning Register 0 00Hex
14Hex Closed Captioning Register 1 00Hex
15Hex Pedestal Control Register 0 00Hex
16Hex Pedestal Control Register 1 00Hex
17Hex Pedestal Control Register 2 00Hex
18Hex Pedestal Control Register 3 00Hex
19Hex CGMS_WSS Reg 0 00Hex
1AHex CGMS_WSS Reg 1 00Hex
1BHex CGMS_WSS Reg 2 00Hex
1CHex TeleText Control Register 00Hex
1DHex Contrast Control Register 00Hex
1EHex Color Control Register 1 00Hex
1FHex Color Control Register 2 00Hex
20Hex Hue Control Register 00Hex
21Hex Brightness Control Register 00Hex
22Hex Sharpness Response Register 00Hex

PAL M (FSC = 3.57561149 MHz)
Address Data

00Hex Mode Register 0 12Hex
01Hex Mode Register 1 07Hex
02Hex Mode Register 2 68Hex
03Hex Mode Register 3 00Hex
04Hex Mode Register 4 00Hex
05Hex Mode Register 5 00Hex
06Hex Mode Register 6 00Hex
07Hex Mode Register 7 00Hex
0AHex Timing Register 0 00Hex
0BHex Timing Register 1 00Hex
0CHex Subcarrier Frequency Register 0 A3Hex
0DHex Subcarrier Frequency Register 1 EFHex
0EHex Subcarrier Frequency Register 2 E6Hex
0FHex Subcarrier Frequency Register 3 21Hex
10Hex Subcarrier Phase Register 00Hex
11Hex Closed Captioning Ext Register 0 00Hex

–52– REV. A

ADV7172/ADV7173

PAL M (Continued) (FSC = 3.57561149 MHz)
Address Data

12Hex Closed Captioning Ext Register 1 00Hex
13Hex Closed Captioning Register 0 00Hex
14Hex Closed Captioning Register 1 00Hex
15Hex Pedestal Control Register 0 00Hex
16Hex Pedestal Control Register 1 00Hex
17Hex Pedestal Control Register 2 00Hex
18Hex Pedestal Control Register 3 00Hex
19Hex CGMS_WSS Reg 0 00Hex
1AHex CGMS_WSS Reg 1 00Hex
1BHex CGMS_WSS Reg 2 00Hex
1CHex TeleText Control Register 00Hex
1DHex Contrast Control Register 00Hex
1EHex Color Control Register 1 00Hex
1FHex Color Control Register 2 00Hex
20Hex Hue Control Register 00Hex
21Hex Brightness Control Register 00Hex
22Hex Sharpness Response Register 00Hex

PAL N (FSC = 4.43361875 MHz)
Address Data

00Hex Mode Register 0 13Hex
01Hex Mode Register 1 07Hex
02Hex Mode Register 2 68Hex
03Hex Mode Register 3 00Hex
04Hex Mode Register 4 00Hex
05Hex Mode Register 5 00Hex
06Hex Mode Register 6 00Hex
07Hex Mode Register 7 00Hex
0AHex Timing Register 0 00Hex
0BHex Timing Register 1 00Hex
0CHex Subcarrier Frequency Register 0 CBHex
0DHex Subcarrier Frequency Register 1 8AHex
0EHex Subcarrier Frequency Register 2 09Hex
0FHex Subcarrier Frequency Register 3 2AHex
10Hex Subcarrier Phase Register 00Hex
11Hex Closed Captioning Ext Register 0 00Hex
12Hex Closed Captioning Ext Register 1 00Hex
13Hex Closed Captioning Register 0 00Hex
14Hex Closed Captioning Register 1 00Hex
15Hex Pedestal Control Register 0 00Hex
16Hex Pedestal Control Register 1 00Hex
17Hex Pedestal Control Register 2 00Hex
18Hex Pedestal Control Register 3 00Hex
19Hex CGMS_WSS Reg 0 00Hex

1AHex CGMS_WSS Reg 1 00Hex
1BHex CGMS_WSS Reg 2 00Hex
1CHex Teletext Control Register 2 00Hex
1DHex Contrast Control Register 00Hex
1EHex Color Control Register 1 00Hex
1FHex Color Control Register 2 00Hex
20Hex Hue Control Register 00Hex
21Hex Brightness Control Register 00Hex
22Hex Sharpness Response Register 00Hex

PAL-60 (FSC = 4.43361875 MHz)
Address Data

00Hex Mode Register 0 12Hex
01Hex Mode Register 1 07Hex
02Hex Mode Register 2 68Hex
03Hex Mode Register 3 00Hex
04Hex Mode Register 4 00Hex
05Hex Mode Register 5 00Hex
06Hex Mode Register 6 00Hex
07Hex Mode Register 7 00Hex
0AHex Timing Register 0 00Hex
0BHex Timing Register 1 00Hex
0CHex Subcarrier Frequency Register 0 CBHex
0DHex Subcarrier Frequency Register 1 8AHex
0EHex Subcarrier Frequency Register 2 09Hex
0FHex Subcarrier Frequency Register 3 2AHex
10Hex Subcarrier Phase Register 00Hex
11Hex Closed Captioning Ext Register 0 00Hex
12Hex Closed Captioning Ext Register 1 00Hex
13Hex Closed Captioning Register 0 00Hex
14Hex Closed Captioning Register 1 00Hex
15Hex Pedestal Control Register 0 00Hex
16Hex Pedestal Control Register 1 00Hex
17Hex Pedestal Control Register 2 00Hex
18Hex Pedestal Control Register 3 00Hex
19Hex CGMS_WSS Reg 0 00Hex
1AHex CGMS_WSS Reg 1 00Hex
1BHex CGMS_WSS Reg 2 00Hex
1CHex TeleText Control Register 00Hex
1DHex Contrast Control Register 00Hex
1EHex Color Control Register 1 00Hex
1FHex Color Control Register 2 00Hex
20Hex Hue Control Register 00Hex
21Hex Brightness Control Register 00Hex
22Hex Sharpness Response Register 00Hex

–53–REV. A

ADV7172/ADV7173

POWER ON RESET REG VALUES
(PAL_NTSC = 0, NTSC Selected)

Address Data

00Hex Mode Register 0 00Hex
01Hex Mode Register 1 07Hex
02Hex Mode Register 2 08Hex
03Hex Mode Register 3 00Hex
04Hex Mode Register 4 00Hex
05Hex Mode Register 5 00Hex
06Hex Mode Register 6 00Hex
07Hex Mode Register 7 00Hex
0AHex Timing Register 0 00Hex
0BHex Timing Register 1 00Hex
0CHex Subcarrier Frequency Register 0 16Hex
0DHex Subcarrier Frequency Register 1 7CHex
0EHex Subcarrier Frequency Register 2 F0Hex
0FHex Subcarrier Frequency Register 3 21Hex
10Hex Subcarrier Phase Register 00Hex
11Hex Closed Captioning Ext Register 0 00Hex
12Hex Closed Captioning Ext Register 1 00Hex
13Hex Closed Captioning Register 0 00Hex
14Hex Closed Captioning Register 1 00Hex
15Hex Pedestal Control Register 0 00Hex
16Hex Pedestal Control Register 1 00Hex
17Hex Pedestal Control Register 2 00Hex
18Hex Pedestal Control Register 3 00Hex
19Hex CGMS_WSS Reg 0 00Hex
1AHex CGMS_WSS Reg 1 00Hex
1BHex CGMS_WSS Reg 2 00Hex
1CHex Teletext Control Register 00Hex
1DHex Contrast Control Register 00Hex
1EHex Color Control Register 1 00Hex
1FHex Color Control Register 2 00Hex
20Hex Hue Control Register 00Hex
21Hex Brightness Control Register 00Hex
22Hex Sharpness Response Register 00Hex

POWER ON RESET REG VALUES
(PAL_NTSC = 1, PAL Selected)

Address Data

00Hex Mode Register 0 00Hex
01Hex Mode Register 1 07Hex
02Hex Mode Register 2 08Hex
03Hex Mode Register 3 00Hex
04Hex Mode Register 4 00Hex
05Hex Mode Register 5 00Hex
06Hex Mode Register 6 00Hex
07Hex Mode Register 7 00Hex
0AHex Timing Register 0 00Hex
0BHex Timing Register 1 00Hex
0CHex Subcarrier Frequency Register 0 CBHex
0DHex Subcarrier Frequency Register 1 8AHex
0EHex Subcarrier Frequency Register 2 09Hex
0FHex Subcarrier Frequency Register 3 2AHex
10Hex Subcarrier Phase Register 00Hex
11Hex Closed Captioning Ext Register 0 00Hex
12Hex Closed Captioning Ext Register 1 00Hex
13Hex Closed Captioning Register 0 00Hex
14Hex Closed Captioning Register 1 00Hex
15Hex Pedestal Control Register 0 00Hex
16Hex Pedestal Control Register 1 00Hex
17Hex Pedestal Control Register 2 00Hex
18Hex Pedestal Control Register 3 00Hex
19Hex CGMS_WSS Reg 0 00Hex
1AHex CGMS_WSS Reg 1 00Hex
1BHex CGMS_WSS Reg 2 00Hex
1CHex Teletext Control Register 00Hex
1DHex Contrast Control Register 00Hex
1EHex Color Control Register 1 00Hex
1FHex Color Control Register 2 00Hex
20Hex Hue Control Register 00Hex
21Hex Brightness Control Register 00Hex
22Hex Sharpness Response Register 00Hex

–54– REV. A

0.6

0.4

VOLTS

0.2

0.0

ADV7172/ADV7173

APPENDIX 10

OPTIONAL DAC BUFFERING

20.2

0.0 10.0 20.0 30.0 40.0 50.0 60.0

NOISE REDUCTION: 0.00 dB
APL = 39.1% PRECISION MODE OFF SOUND-IN-SYNC OFF
625 LINE PAL NO FILTERING SYNCHRONOUS SYNC = SOURCE
SLOW CLAMP TO 0.00 V AT 6.72 ms FRAMES SELECTED: 1 2 3 4

L608

MICROSECONDS

Figure 96. 100%/75% PAL Color Bars

0.5

VOLTS

0.0

L575

0.0 10.0 20.0 30.0 40.0 50.0 60.0 70.0

APL NEEDS SYNC = SOURCE! PRECISION MODE OFF SOUND-IN-SYNC OFF
625 LINE PAL NO FILTERING SYNCHRONOUS SYNC = A

SLOW CLAMP TO 0.00 V AT 6.72 ms FRAMES SELECTED: 1

MICROSECONDS

Figure 97. 100%/75% PAL Color Bars Luminance

–55–REV. A

ADV7172/ADV7173

0.5

0.0

VOLTS

–0.5

APL NEEDS SYNC = SOURCE! PRECISION MODE OFF SOUND-IN-SYNC OFF
625 LINE PAL NO FILTERING SYNCHRONOUS SYNC = A

SLOW CLAMP TO 0.00 V AT 6.72 ms FRAMES SELECTED: 1

L575

10.0 30.0 40.0 50.0 60.020.0
MICROSECONDS

NO BRUCH SIGNAL

Figure 98. 100%/75% PAL Color Bars Chrominance

100.0

0.5

50.0

VOLTS

0.0

IRE:FLT

0.0

F1

–50.0

L76

0.0 10.0 20.0 30.0 40.0 50.0 60.0

APL = 44.6% PRECISION MODE OFF
525 LINE NTSC NO FILTERING SYNCHRONOUS SYNC = A

SLOW CLAMP TO 0.00 V AT 6.72 ms FRAMES SELECTED: 1 2

MICROSECONDS

Figure 99. 100%/75% NTSC Color Bars

–56– REV. A

0.6

ADV7172/ADV7173

0.4

VOLTS

0.2

0.0

–0.2

NOISE REDUCTION: 15.05dB
APL = 44.7% PRECISION MODE OFF
525 LINE NTSC NO FILTERING SYNCHRONOUS SYNC = SOURCE
SLOW CLAMP TO 0.00 V AT 6.72 ms FRAMES SELECTED: 1 2

50.0

IRE:FLT

0.0

F2
L238

10.0 20.0 30.0 40.0 50.0 60.0
MICROSECONDS

Figure 100. NTSC Color Bars Luminance

0.4

50.0

0.2

VOLTS

–0.2

–0.4

NOISE REDUCTION: 15.05dB
APL NEEDS SYNC = SOURCE! PRECISION MODE OFF

525 LINE NTSC NO FILTERING SYNCHRONOUS SYNC = B
SLOW CLAMP TO 0.00 V AT 6.72 ms FRAMES SELECTED: 1 2

IRE:FLT

0.0

–50.0

F1
L76

0.0 10.0 20.0 30.0 40.0 50.0 60.0
MICROSECONDS

Figure 101. 100%/75% NTSC Color Bars Chrominance

–57–REV. A

ADV7172/ADV7173

APL = 39.6%

V

SYSTEM LINE L608
ANGLE (DEG) 0.0

cy

75%

R

M
g

100%

Cy

r

m
g

g

YI

yl

G

GAIN 3 1.000 0.000dB
625 LINE PAL
BURST FROM SOURCE
DISPLAY +V & –V

b

B

U

SOUND IN SYNC OFF

APL = 45.1%

YI

–Q

Figure 102. PAL Vector Plot

R-Y

SYSTEM LINE L76F1
ANGLE (DEG) 0.0

I

R

100%

75%

G

cy

M
g

Cy

GAIN 3 1.000 0.000dB
525 LINE NTSC
BURST FROM SOURCE

Q

b

B

B-Y

SETUP 7.5%

–I

Figure 103. NTSC Vector Plot

–58– REV. A

OUTLINE DIMENSIONS

Dimensions shown in inches and (mm).

48-Lead LQFP

(ST-48)

ADV7172/ADV7173

0.030 (0.75)

0.018 (0.45)

SEATING

PLANE

0.006 (0.15)

0.002 (0.05)
0° – 7°

0.063 (1.60) MAX

0.030 (0.75)

0.057 (1.45)

0.018 (0.45)

0.053 (1.35)

0° MIN

0.007 (0.18)

0.004 (0.09)

0.354 (9.00) BSC

0.276 (7.0) BSC

48

1

TOP VIEW

(PINS DOWN)

12

13

0.019 (0.5)
BSC

37

36

25

24

0.011 (0.27)

0.006 (0.17)

0.276 (7.0) BSC

0.354 (9.00) BSC

C3441a–1–6/99

PRINTED IN U.S.A.

–59–REV. A
