Dual/Quad Input Network Clock

FEATURES

Supports Stratum 2 stability in holdover mode Supports reference switchover with phase build-out Supports hitless reference switchover Automatic/manual holdover and reference switchover 2 pairs of reference input pins, with each pair configurable

as a single differential input or as 2 independent single-

ended inputs Input reference frequencies from 1 kHz to 750 MHz Reference validation and frequency monitoring (1 ppm) Programmable input reference switchover priority 30-bit programmable input reference divider 2 pairs of clock output pins, with each pair configurable as

a single differential LVDS/LVPECL output or as 2 single-

ended CMOS outputs Output frequencies up to 450 MHz 20-bit integer and 10-bit fractional programmable feedback

divider Programmable digital loop filter covering loop bandwidths

from 0.001 Hz to 100 kHz Optional low noise LC-VCO system clock multiplier Optional crystal resonator for system clock input On-chip EEPROM to store multiple power-up profiles Software controlled power-down 64-lead LFCSP package

Generator/Synchronizer

AD9547

APPLICATIONS

Network synchronization Cleanup of reference clock jitter SONET/SDH clocks up to OC-192, including FEC Stratum 2 holdover, jitter cleanup, and phase transient

control Stratum 3E and Stratum 3 reference clocks Wireless base stations, controllers Cable infrastructure Data communications

GENERAL DESCRIPTION

The AD9547 provides synchronization for many systems, including synchronous optical networks (SONET/SDH). The AD9547 generates an output clock that is synchronized to one of two differential or four single-ended external input references. The digital PLL allows for reduction of input time jitter or phase noise associated with the external references. The AD9547 continuously generates a clean (low jitter), valid output clock, even when all references fail, by means of digitally controlled loop and holdover circuitry.

The AD9547 operates over an industrial temperature range of

−40°C to +85°C.

FUNCTIONAL BLOCK DIAGRAM

STABLE

SOURCE

CLOCK

MULTIPLIER

DIGITAL

REFERE NC E INPUT S

AND

MONITOR MUX

Rev. B

Information furnished by Analog Devices is believed to be accurate and reliable. However, no responsibility is assumed by Analog Devices for its use, nor for any infringements of patents or other rights of third parties that may result from its use. Specifications subject to change without notice. No license is granted by implication or otherwise under any patent or patent rights of Analog Devices. Trademarks and registered trademarks are the property of their respective owners.

PLL

SERIAL CONTROL INT ERFACE

(SPI or I

AD9547

DAC

Figure 1.

ANALOG

FILTER

CLOCK DIST RIBUTION

CHANNEL 0

DIVIDER

CHANNEL 1

DIVIDER

SYNC

EEPROM

STATUS AND

CONTROL P INS

08300-001

Page 2

AD9547

Features .............................................................................................. 1

Applications ....................................................................................... 1 

General Description ......................................................................... 1

Functional Block Diagram .............................................................. 1

Revision History ............................................................................... 3

Specifications ..................................................................................... 4

Supply Voltage ............................................................................... 4

Supply Current .............................................................................. 4

Power Dissipation ......................................................................... 4

Logic Inputs (M0 to M7, RESET) ............................................... 5

Logic Outputs (M0 to M7, IRQ) ................................................ 5

System Clock Inputs (SYSCLKP, SYSCLKN)............................ 5

Distribution Clock Inputs (CLKINP, CLKINN) ...................... 6

Reference Inputs (REFA/REFAA, REFB/REFBB) .................... 7

Reference Monitors ...................................................................... 7

Reference Switchover Specifications .......................................... 8

Distribution Clock Outputs (OUT0, OUT1) ........................... 8

DAC Output Characteristics (DACOUTP, DACOUTN) ....... 9

Time Duration of Digital Functions ........................................ 10

Digital PLL .................................................................................. 10

Digital PLL Lock Detection ...................................................... 10

Holdover Specifications ............................................................. 10

Serial Port Specifications—SPI Mode ...................................... 11

Serial Port Specifications—I2C Mode ...................................... 12

Jitter Generation ......................................................................... 13

Absolute Maximum Ratings .......................................................... 14

ESD Caution ................................................................................ 14

Pin Configuration and Function Descriptions ........................... 15

Typical Performance Characteristics ........................................... 18

Input/Output Termination Recommendations .......................... 23

Getting Started ................................................................................ 24

Power-On Reset .......................................................................... 24

Initial M0 to M7 Pin Programming ......................................... 24

Device Register Programming .................................................. 24

Theory of Operation ...................................................................... 26

Overview ...................................................................................... 26

Reference Clock Inputs .............................................................. 27

Reference Monitors .................................................................... 27

Reference Profiles ....................................................................... 28

Reference Switchover ................................................................. 30

Rev. B | Page 2 of 104

Digital Phase-Locked Loop (DPLL) Core ............................... 32

Direct Digital Synthesizer (DDS) ............................................. 34

Tuning Word Processing ........................................................... 35

Loop Control State Machine ..................................................... 36

System Clock Inputs ................................................................... 37

SYSCLK PLL Multiplier ............................................................. 38

Clock Distribution ..................................................................... 40

Status and Control .......................................................................... 44

Multifunction Pins (M0 to M7) ............................................... 44

IRQ Pin ........................................................................................ 45

Watchdog Timer ......................................................................... 45

EEPROM ..................................................................................... 46

Serial Control Port ......................................................................... 50

SPI/I2C Port Selection ................................................................ 50

SPI Serial Port Operation .......................................................... 50

IC Serial Port Operation .......................................................... 54

I/O Programming Registers .......................................................... 57

Buffered/Active Registers .......................................................... 57

Autoclearing Registers ............................................................... 57

Serial Port Configuration and Part Identification (Register

0x0000 to Register 0x0005) ....................................................... 67

System Clock (SYSCLK) (Register 0x0100 to Register 0x0108)

....................................................................................................... 68

General Configuration (Register 0x0200 to Register 0x0214)

....................................................................................................... 69

DPLL Configuration (Register 0x0300 to Register 0x031B) 72

Clock Distribution Output Configuration (Register 0x0400 to

Reference Input Configuration (Register 0x0500 to Register

0x0507) ......................................................................................... 76

Profile Registers (Register 0x0600 to Register 0x07FF) ........ 78

Operational Controls (Register 0x0A00 to Register 0x0A10)

....................................................................................................... 88

Status Readback (Register 0x0D00 to Register 0x0D19) ...... 92

Nonvolatile Memory (EEPROM) Control (Register 0x0E00 to

EEPROM Storage Sequence (Register 0x0E10 to Register

0x0E3F) ........................................................................................ 95

Applications Information .............................................................. 98



Page 3

AD9547

Power Supply Partitions ............................................................. 98

Thermal Performance ................................................................. 98

Calculating the Digital Filter Coefficients ............................... 99

REVISION HISTORY

11/10—Rev. A to Rev. B

Changes to Pulse Width High, t SCLK to Valid SDIO and SDO, t Changes to Addr 0x0002, Def Column, Table 36 and Addr

0x0003, Def Column, Table 36 ...................................................... 58

Changes to Addr 0x0632, Table 36 ............................................... 61

Changes to Addr 0x0680, Table 36 ............................................... 62

Changes to Addr 0x06B2, Table 36 ............................................... 63

Changes to Address 0x0002, Description, Table 39 .................... 67

Changes to Bit 7 and Bit 6, Table 78 ............................................. 78

Changes to Address 0x629 and Address 0x62A, Table 87, and

Bit 7 and Bit 6, Table 88 .................................................................. 80

Changes to Address 0x65B and Address 0x65C, Table 97, and

Bit 7 and Bit 6, Table 98 .................................................................. 82

Changes to Address 0x6A9 and Address 0x6AA, Table 107 ..... 84

Changes to Bit 7 and Bit 6, Table 108 ........................................... 85

Changes to Address 0x6DB and Address 0x6DC, Table 117 ..... 87

Parameter, Table 17 and

HIGH

Parameter, Table 17 ............ 11

Outline Dimensions ...................................................................... 102

Ordering Guide ......................................................................... 102

9/10—Rev. 0 to Rev. A

Change to Frequency Range (CMOS), Single-Ended Operation

Parameter, Table 8 ............................................................................. 7

Added Low Loop Bandwidth Applications Using a TCXO/OCXO Section and Choosing the System Clock

Oscillator Frequency Section ......................................................... 37

Moved System Clock Period Section ............................................ 39

7/09—Revision 0: Initial Version

Rev. B | Page 3 of 104

Page 4

AD9547

SPECIFICATIONS

Minimum and maximum values apply for the full range of supply voltage and operating temperature variation. Typical values apply for AVDD3 = DVDD3 = 3.3 V, AVDD = DVDD

SUPPLY VOLTAGE

Table 1.

Parameter Min Typ Max Unit Test Conditions/Comments

DVDD3 3.135 3.30 3.465 V Pin 7, Pin 58 DVDD 1.71 1.80 1.89 V Pin 1, Pin 6, Pin 8, Pin 10, Pin 11, Pin 53, Pin 59, Pin 64 AVDD3 3.135 3.30 3.465 V Pin 16, Pin 33, Pin 43, Pin 49

3.3 V Supply (Typical) 3.135 3.30 3.465 V Pin 25, Pin 31

1.8 V Supply (Alternative) 1.71 1.80 1.89 V Pin 25, Pin 31

AVDD 1.71 1.80 1.89 V Pin 17, Pin 18, Pin 23, Pin 28, Pin 32, Pin 36, Pin 39, Pin 42, Pin 46, Pin 50

SUPPLY CURRENT

The test conditions for the maximum supply current are the same as the test conditions for the All Blocks Running section of Tab le 3 . The test conditions for the typical supply current are the same as the test conditions for the Typical Configuration section of Tabl e 3.

Table 2.

Parameter Min Typ Max Unit Test Conditions/Comments

1.5 3 mA Pin 7, Pin 58

DVDD3

190 215 mA Pin 1, Pin 6, Pin 8, Pin 10, Pin 11, Pin 53, Pin 59, Pin 64

DVDD

52 70 mA Pin 16, Pin 33, Pin 43, Pin 49

AVDD3

3.3 V Supply (Typical) 24 55 mA Pin 25, Pin 31

1.8 V Supply (Alternative) 24 55 mA Pin 25, Pin 31

135 150 mA Pin 17, Pin 18, Pin 23, Pin 28, Pin 32, Pin 36, Pin 39, Pin 42, Pin 46, Pin 50

AVDD

= 1.8 V, TA = 25°C, I

= 20 mA (full scale), unless otherwise noted.

DAC

POWER DISSIPATION

Table 3.

Parameter Min Typ Max Unit Test Conditions/Comments

TYPICAL CONFIGURATION 800 1100 mW

ALL BLOCKS RUNNING 900 1250 mW

FULL POWER-DOWN 13 mW

INCREMENTAL POWER DISSIPATION

SYSCLK PLL Off −105 mW f Input Reference On

Differential 7 mW Single-Ended 13 mW

Output Distribution Driver On

LVDS 70 mW LVPECL 75 mW CMOS 65 mW Single 3.3 V CMOS output with a 10 pF load

is the frequency at the SYSCLKP and SYSCLKN pins.

SYSCLK

fS is the sample rate of the output DAC.

is the output frequency of the DDS.

DDS

= 20 MHz1; fS = 1 GHz2; f

SYSCLK

DDS

distribution output running at 122.88 MHz (all others powered down); one input reference running at 100 MHz (all others powered down)

= 20 MHz1; fS = 1 GHz2; f

SYSCLK

= 399 MHz3; all clock distribution

DDS

outputs configured as LVPECL at 399 MHz; all input references configured as differential at 100 MHz; fractional-N active (R = 10, S = 39, U = 9, V = 10)

Conditions = typical configuration; no external pull-up or pulldown resistors

Conditions = typical configuration; table values show the change in power due to the indicated operation

= 1 GHz1; high frequency direct input mode

SYSCLK

= 122.88 MHz3; one LVPECL clock

Rev. B | Page 4 of 104

Page 5

AD9547

LOGIC INPUTS (M0 TO M7, RESET)

Table 4.

Parameter Min Typ Max Unit Test Conditions/Comments

INPUT VOLTAGE

Input High Voltage (VIH) 2.1 V

Input Low Voltage (VIL) 0.8 V INPUT CURRENT (I INPUT CAPACITANCE (CIN) 3 pF

LOGIC OUTPUTS (M0 TO M7, IRQ)

Table 5.

Parameter Min Typ Max Unit Test Conditions/Comments

OUTPUT VOLTAGE

Output High Voltage (VOH) 2.7 V IOH = 1 mA

Output Low Voltage (VOL) 0.4 V IOL = 1 mA IRQ LEAKAGE CURRENT Open-drain mode

Active Low Output Mode 1 µA VOH = 3.3 V

Active High Output Mode 1 µA VOL = 0 V

SYSTEM CLOCK INPUTS (SYSCLKP, SYSCLKN)

, I

) ±80 ±200 µA

INH

INL

Table 6.

Parameter Min Typ Max Unit Test Conditions/Comments

SYSTEM CLOCK PLL BYPASSED

Input Frequency Range 500 1000 MHz

Minimum Input Slew Rate 1000 V/µs Minimum limit imposed for jitter performance

Duty Cycle 40 60 %

Common-Mode Voltage 1.2 V Internally generated

Differential Input Voltage Sensitivity 100 mV p-p

Input Capacitance 2 pF Single-ended, each pin

Input Resistance 2.5 kΩ SYSTEM CLOCK PLL ENABLED

PLL Output Frequency Range 900 1000 MHz

Phase Frequency Detector (PFD) Rate 150 MHz

Frequency Multiplication Range 6 255 Assumes valid system clock and PFD rates

VCO Gain 70 MHz/V

High Frequency Path

Input Frequency Range 100.1 500 MHz Minimum Input Slew Rate 200 V/µs Minimum limit imposed for jitter performance Frequency Divider Range 1 8 Binary steps (M = 1, 2, 4, 8) Common-Mode Voltage Differential Input Voltage Sensitivity 100 mV p-p

Input Capacitance 3 pF Single-ended, each pin Input Resistance 2.5 kΩ

1 V Internally generated

Minimum voltage across pins is required to ensure switching between logic states; the instantaneous voltage on either pin must not exceed the supply rails; ac ground the unused input to accommodate singleended operation

This is the minimum voltage required across the pins to ensure switching between logic states; the instantaneous voltage on either pin must not exceed the supply rails; ac ground the unused input to accommodate single-ended operation

Rev. B | Page 5 of 104

Page 6

AD9547

Parameter Min Typ Max Unit Test Conditions/Comments

Low Frequency Path

Input Frequency Range 3.5 100 MHz Minimum Input Slew Rate 50 V/µs Minimum limit imposed for jitter performance Common-Mode Voltage 1.2 V Internally generated Differential Input Voltage Sensitivity 100 mV p-p

Input Capacitance 3 pF Single-ended, each pin Input Resistance 4 kΩ

Crystal Resonator Path

Crystal Resonator Frequency Range 10 50 MHz Fundamental mode, AT cut Maximum Crystal Motional

Resistance

100 Ω See the System Clock Inputs section for recommendations

DISTRIBUTION CLOCK INPUTS (CLKINP, CLKINN)

Table 7.

Parameter Min Typ Max Unit Test Conditions/Comments

INPUT FREQUENCY RANGE 62.5 500 MHz MINIMUM SLEW RATE 75 V/µs Minimum limit imposed for jitter performance COMMON-MODE VOLTAGE 700 mV Internally generated DIFFERENTIAL INPUT VOLTAGE SENSITIVITY 100 mV p-p

DIFFERENTIAL INPUT POWER SENSITIVITY −15 dBm

INPUT CAPACITANCE 3 pF INPUT RESISTANCE 5 kΩ Each pin has a 2.5 kΩ internal dc bias resistance

Capacitive coupling required; ac ground the unused input to accommodate single-ended operation; the instantaneous voltage on either pin must not exceed the supply rails

Same as voltage sensitivity but specified as power into a 50 Ω load

Rev. B | Page 6 of 104

Page 7

AD9547

REFERENCE INPUTS (REFA/REFAA, REFB/REFBB)

Table 8.

Parameter Min Typ Max Unit Test Conditions/Comments

DIFFERENTIAL OPERATION

Frequency Range

Sinusoidal Input 10 750 MHz LVPECL Input 0.001 750 MHz

LVDS Input 0.001 750 MHz Minimum Input Slew Rate 40 V/µs Minimum limit imposed for jitter performance Common-Mode Input Voltage 2 V Internally generated Differential Input Voltage

Sensitivity

Input Resistance 25 kΩ Input Capacitance 3 pF Minimum Pulse Width High 620 ps Minimum Pulse Width Low 620 ps

SINGLE-ENDED OPERATION

Frequency Range (CMOS) 0.001 250 MHz Minimum Input Slew Rate 40 V/µs Minimum limit imposed for jitter performance Input Voltage High (VIH)

1.2 V to 1.5 V Threshold Setting 0.9 V

1.8 V to 2.5 V Threshold Setting 1.2 V

3.0 V to 3.3 V Threshold Setting 1.9 V

Input Voltage Low (VIL)

1.2 V to 1.5 V Threshold Setting 0.27 V

1.8 V to 2.5 V Threshold Setting 0.5 V

3.0 V to 3.3 V Threshold Setting 1.0 V Input Resistance 45 kΩ Input Capacitance 3 pF Minimum Pulse Width High 1.5 ns Minimum Pulse Width Low 1.5 ns

±65 mV

This is the minimum voltage required across the pins to ensure switching between logic states; the instantaneous voltage on either pin must not exceed the supply rails

REFERENCE MONITORS

Table 9.

Parameter Min Typ Max Unit Test Conditions/Comments

REFERENCE MONITOR

Loss of Reference Detection Time 1.2 NPDP NPDP = nominal phase detector period (NPDP = f Frequency Out-of-Range Limits 9.54 × 10−7 0.1 ∆f/f

Programmable (lower bound subject to quality of SYSCLK)

REF

TIMERS

Validation Timer 0.001 65.535 sec Programmable in 1 ms increments Redetect Timer 0.001 65.535 sec Programmable in 1 ms increments

is the frequency of the active reference; R is the frequency division factor determined by the R divider.

REF

Rev. B | Page 7 of 104

REF

/R)1

Page 8

AD9547

REFERENCE SWITCHOVER SPECIFICATIONS

Table 10.

Parameter Min Typ Max Unit Test Conditions/Comments

MAXIMUM OUTPUT PHASE

PERTURBATION (PHASE BUILD-OUT SWITCHOVER)

MAXIMUM TIME/TIME SLOPE

(HITLESS SWITCHOVER)

TIME REQUIRED TO SWITCH TO A NEW

REFERENCE Hitless Switchover 5 NPDP

Phase Build-Out Switchover 3 NPDP

is the frequency of the active reference; R is the frequency division factor determined by the R divider.

REF

DISTRIBUTION CLOCK OUTPUTS (OUT0, OUT1)

Table 11.

Parameter Min Typ Max Unit Test Conditions/Comments

LVPECL MODE

Maximum Output Frequency 725 MHz Rise/Fall Time1 (20% to 80%) 180 315 ps 100 Ω termination across output pins Duty Cycle 45 55 % Differential Output Voltage Swing

Common-Mode Output Voltage AVDD3 − 1.5 AVDD3 − 1.3 AVDD3 − 1.05 V Output driver static

LVDS MODE

Maximum Output Frequency 725 MHz Rise/Fall Time1 (20% to 80%) 200 350 ps 100 Ω termination across the output pins Duty Cycle 40 60 % Differential Output Voltage Swing

Balanced (VOD) 247 454 mV

Unbalanced (∆VOD) 50 mV

Offset Voltage

Common Mode (VOS) 1.125 1.375 V Output driver static Common-Mode Difference (∆VOS) 50 mV

Short-Circuit Output Current 13 24 mA Output driver static

CMOS MODE

Maximum Output Frequency

3.3 V Supply 10 pF load Strong Drive Strength Setting 250 MHz Weak Drive Strength Setting 25 MHz

1.8 V Supply 150 MHz

40 200 ps

Assumes a jitter-free reference; satisfies Telcordia GR-1244-CORE requirements

315 65,535 ns/sec

Minimum/maximum values are programmable upper bounds; a minimum value ensures <10% error; satisfies Telcordia GR-1244-CORE requirements

NPDP = nominal phase detector period (NPDP = f

Using internal current setting resistor (nominal 3.12 kΩ)

630 770 910 mV

Magnitude of voltage across pins; output driver static

Using internal current setting resistor (nominal 3.12 kΩ)

Voltage swing between output pins; output driver static

Absolute difference between voltage swing of normal pin and inverted pin; output driver static

Voltage difference between pins; output driver static

Weak drive option not supported for operating the CMOS drivers using a 1.8 V supply

REF

/R)1

Rev. B | Page 8 of 104

Page 9

AD9547

Parameter Min Typ Max Unit Test Conditions/Comments

Rise/Fall Time1 (20% to 80%) 10 pF load

3.3 V Supply Strong Drive Strength Setting 0.5 2 ns Weak Drive Strength Setting 8 14.5 ns

1.8 V Supply 1.5 2.5 ns

Duty Cycle 40 60 % 10 pF load Output Voltage High (VOH)

AVDD3 = 3.3 V, IOH = 10 mA 2.6 V AVDD3 = 3.3 V, IOH = 1 mA 2.9 V AVDD3 = 1.8 V, IOH = 1 mA 1.5 V

Output Voltage Low (VOL)

AVDD3 = 3.3 V, IOL = 10 mA 0.3 V AVDD3 = 3.3 V, IOL = 1 mA 0.1 V AVDD3 = 1.8 V, IOL = 1 mA 0.1 V

OUTPUT TIMING SKEW 10 pF load

Between LVPECL Outputs 14 125 ps Rising edge only; any divide value Between LVDS Outputs 13 138 ps Rising edge only; any divide value Between CMOS (3.3 V) Outputs

Strong Drive Strength Setting 23 240 ps

Weak Drive Strength Setting 24 ps Between CMOS (1.8 V) Outputs 40 ps Weak drive option not supported at 1.8 V Between LVPECL Outputs and LVDS

Outputs Between LVPECL Outputs and

CMOS Outputs

ZERO-DELAY TIMING SKEW ±5 ns

The listed values are for the slower edge (rising or falling).

14 140 ps

19 ps

Output driver static; strong drive strength setting

Output relative to active input reference; output distribution synchronization to active reference feature enabled; assumes manual phase offset compensation of deterministic latency

DAC OUTPUT CHARACTERISTICS (DACOUTP, DACOUTN)

Table 12.

Parameter Min Typ Max Unit Test Conditions/Comments

FREQUENCY RANGE 62.5 450 MHz OUTPUT OFFSET VOLTAGE 15 mV

VOLTAGE COMPLIANCE RANGE VSS − 0.5 0.5 VSS + 0.5 V OUTPUT RESISTANCE 50 Ω

OUTPUT CAPACITANCE 5 pF FULL-SCALE OUTPUT CURRENT 20 mA

GAIN ERROR −12 +12 % FS

Rev. B | Page 9 of 104

This is the single-ended voltage at either DAC output pin (no external load) when the internal DAC code is such that no current is delivered to that pin

Single-ended; each pin has an internal 50 Ω termination to VSS

Programmable (8 mA to 31 mA; see the DAC Output section)

Page 10

AD9547

TIME DURATION OF DIGITAL FUNCTIONS

Table 13.

Parameter Min Typ Max Unit Test Conditions/Comments

EEPROM-TO-REGISTER DOWNLOAD TIME 25 ms

MINIMUM POWER-DOWN EXIT TIME 10.5 µs Dependent on loop filter bandwidth MAXIMUM TIME FROM ASSERTION OF THE RESET PIN

45 ns TO THE M0 TO M7 PINS ENTERING HIGH IMPEDANCE STATE

DIGITAL PLL

Table 14.

Parameter Min Typ Max Unit Test Conditions/Comments

PHASE FREQUENCY DETECTOR (PFD) INPUT

FREQUENCY RANGE

LOOP BANDWIDTH 0.001 1 × 105 Hz

PHASE MARGIN 30 89 Degrees Programmable design parameter REFERENCE INPUT (R) DIVISION FACTOR 1 230 1, 2, …1,073,741,824 INTEGER FEEDBACK (S) DIVISION FACTOR 8 220 8, 9, …1,048,576 FRACTIONAL FEEDBACK DIVIDE RATIO 0 0.999 Maximum value = 1022/1023

is the frequency at the input to the phase-frequency detector.

PFD

fS is the sample rate of the output DAC.

is the frequency of the active reference; R is the frequency division factor determined by the R divider.

REF

0.001 10 MHz Maximum f

Using default EEPROM storage sequence (see Register 0x0E10 to Register 0x0E3F)

Using default EEPROM storage sequence (see Register 0x0E10 to Register 0x0E3F

= fS/100

PFD

1, 2

Programmable design parameter; maximum f

LOOP

= f

/(20R)3

REF

DIGITAL PLL LOCK DETECTION

Table 15.

Parameter Min Typ Max Unit Test Conditions/Comments

PHASE LOCK DETECTOR

Threshold Programming Range 0.001 65.5 ns Threshold Resolution 1 ps

FREQUENCY LOCK DETECTOR

Threshold Programming Range 0.001 16,700 ns Reference-to-feedback period difference Threshold Resolution 1 ps

HOLDOVER SPECIFICATIONS

Table 16.

Parameter Min Typ Max Unit Test Conditions/Comments

FREQUENCY ACCURACY <0.01 ppm

Excludes frequency drift of SYSCLK source; excludes frequency drift of input reference prior to entering holdover

Rev. B | Page 10 of 104

Page 11

AD9547

SERIAL PORT SPECIFICATIONS—SPI MODE

Table 17.

Parameter Min Typ Max Unit Test Conditions/Comments

Input Logic 1 Voltage 2.0 V Input Logic 0 Voltage 0.8 V Input Logic 1 Current 30 µA Input Logic 0 Current 110 µA Input Capacitance 2 pF

SCLK Internal 30 kΩ pull-down resistor

Input Logic 1 Voltage 2.0 V Input Logic 0 Voltage 0.8 V Input Logic 1 Current 1 µA Input Logic 0 Current 1 µA Input Capacitance 2 pF

SDIO

As an Input

Input Logic 1 Voltage 2.0 V Input Logic 0 Voltage 0.8 V Input Logic 1 Current 1 µA Input Logic 0 Current 1 µA Input Capacitance 2 pF

As an Output

Output Logic 1 Voltage 2.7 V 1 mA load current Output Logic 0 Voltage 0.4 V 1 mA load current

SDO

Output Logic 1 Voltage 2.7 V 1 mA load current Output Logic 0 Voltage 0.4 V 1 mA load current

TIMING

SCLK

Clock Rate, 1/t Pulse Width High, t Pulse Width Low, t

40 MHz

CLK

10 ns

HIGH

12 ns

LOW

SDIO to SCLK Setup, tDS 3 ns SCLK to SDIO Hold, tDH 0 ns SCLK to Valid SDIO and SDO, tDV 15 ns CS to SCLK Setup, tS

CS to SCLK Hold, tC CS Minimum Pulse Width High

Internal 30 kΩ pull-up resistor

10 ns 0 ns 6 ns

Rev. B | Page 11 of 104

Page 12

AD9547

SERIAL PORT SPECIFICATIONS—I2C MODE

Table 18.

Parameter Min Typ Max Unit Test Conditions/Comments

SDA (AS INPUT), SCL

Input Logic 1 Voltage 0.7 × DVDD3 V Input Logic 0 Voltage 0.3 × DVDD3 V Input Current −10 +10 µA For VIN = 10% to 90% of DVDD3 Hysteresis of Schmitt Trigger Inputs 0.015 × DVDD3 V Pulse Width of Spikes That Must Be

Suppressed by the Input Filter, t

50 ns

SDA (AS OUTPUT)

Output Logic 0 Voltage 0.4 V IO = 3 mA Output Fall Time from V

IHmin

to V

20 + 0.1 C

ILmax

250 ns 10 pF ≤ Cb ≤ 400 pF

TIMING

SCL Clock Rate 400 kHz Bus Free Time Between a Stop and Start

Condition, t Repeated Start Condition Setup Time, t Repeated Hold Time Start Condition, t

Stop Condition Setup Time, t Low Period of the SCL Clock, t High Period of the SCL Clock, t SCL/SDA Rise Time, t

BUF

SU;STA

HD;STA

0.6 µs

SU;STO

1.3 µs

LOW

0.6 µs

HIGH

SCL/SDA Fall Time, tF 20 + 0.1 C Data Setup Time, t Data Hold Time, t Capacitive Load for Each Bus Line, C

Cb is the capacitance (pF) of a single bus line.

100 ns

SU;DAT

100 ns

HD;DAT

400 pF

1.3 µs

0.6 µs

20 + 0.1 C

300 ns

No internal pull-up/pull-down resistor

After this period, the first clock pulse is generated

Rev. B | Page 12 of 104

Page 13

AD9547

JITTER GENERATION

Table 19.

Parameter Min Typ Max Unit Test Conditions/Comments

CONDITIONS: f

= 100 Hz3

LOOP

= 8 kHz1, f

REF

= 155.52 MHz2,

DDS

Bandwidth: 100 Hz to 77 MHz 0.71 ps rms Random jitter Bandwidth: 5 kHz to 20 MHz 0.34 ps rms Random jitter Bandwidth: 20 kHz to 80 MHz 0.43 ps rms Random jitter Bandwidth: 50 kHz to 80 MHz 0.43 ps rms Random jitter Bandwidth: 4 MHz to 80 MHz 0.31 ps rms Random jitter

CONDITIONS: f

= 1 kHz3

LOOP

= 19.44 MHz1, f

REF

= 155.52 MHz2,

DDS

Bandwidth: 100 Hz to 77 MHz 1.05 ps rms Random jitter Bandwidth: 5 kHz to 20 MHz 0.34 ps rms Random jitter Bandwidth: 20 kHz to 80 MHz 0.43 ps rms Random jitter Bandwidth: 50 kHz to 80 MHz 0.43 ps rms Random jitter Bandwidth: 4 MHz to 80 MHz 0.32 ps rms Random jitter

CONDITIONS: f

= 1 kHz3

LOOP

= 19.44 MHz1, f

REF

= 311.04 MHz2,

DDS

Bandwidth: 100 Hz to 100 MHz 0.67 ps rms Random jitter Bandwidth: 5 kHz to 20 MHz 0.31 ps rms Random jitter Bandwidth: 20 kHz to 80 MHz 0.33 ps rms Random jitter Bandwidth: 50 kHz to 80 MHz 0.33 ps rms Random jitter Bandwidth: 4 MHz to 80 MHz 0.16 ps rms Random jitter

is the frequency of the active reference.

REF

is the output frequency of the DDS.

DDS

is the DPLL digital loop filter bandwidth.

LOOP

is the frequency at the SYSCLKP and SYSCLKN pins.

SYSCLK

fS is the sample rate of the output DAC.

= 50 MHz4 crystal; fS = 1 GHz5;

SYSCLK

Q-divider = 1; default SYSCLK PLL charge pump current; results valid for LVPECL, LVDS, and CMOS output logic types

= 50 MHz4 crystal; fS = 1 GHz5;

SYSCLK

Q-divider = 1; default SYSCLK PLL charge pump current; results valid for LVPECL, LVDS, and CMOS output logic types

= 50 MHz4 crystal; fS = 1 GHz5;

SYSCLK

Q-divider = 1; default SYSCLK PLL charge pump current; results valid for LVPECL, LVDS, and CMOS output logic types

Rev. B | Page 13 of 104

Page 14

AD9547

ABSOLUTE MAXIMUM RATINGS

Table 20.

Parameter Rating

Analog Supply Voltage (AVDD) 2 V Digital Supply Voltage (DVDD) 2 V Digital I/O Supply Voltage

(DVDD3)

DAC Supply Voltage (AVDD3) 3.6 V Maximum Digital Input Voltage −0.5 V to DVDD3 + 0.5 V Storage Temperature Range −65°C to +150°C Operating Temperature Range −40°C to +85°C Lead Temperature

(Soldering 10 sec)

Junction Temperature 150°C

3.6 V

300°C

Stresses above those listed under Absolute Maximum Ratings may cause permanent damage to the device. This is a stress rating only; functional operation of the device at these or any other conditions above those indicated in the operational section of this specification is not implied. Exposure to absolute maximum rating conditions for extended periods may affect device reliability.

ESD CAUTION

Rev. B | Page 14 of 104

Page 15

AD9547

PIN CONFIGURATION AND FUNCTION DESCRIPTIONS

DVDDM7M6M5M4 646362616059585756555453525150

DVDD

SCLK/SCL

SDIO

SDO

CS/SDA

DVDD

DVDD3

DVDD

RESET

DVDD

VSS

AVDD3

12 13 14 15 16

DACOUTP

DACOUTN

NOTES

1. NC = NO CONNEC T.

2. THE EXPOSED PAD MUST BE CONNECTED TO GROUND (VSS).

PIN 1

INDICATOR

2 3 4 5 6 7 8 9

171819202122232425262728293031

AVDD

VSS

CLKINN

DVDD

DVDD3M3M2M1M0

AD9547

TOP VIEW

(Not to Scale)

VSS

AVDD

CLKINP

OUT_RSET

AVDD3

DVDD

IRQNCAVDD

AVDD3 49

REFBB

REFB

AVDD

REFAA

REFA

AVDD3

AVDD

TDC_VRT

TDC_VRB

AVDD

SYSCLKP

SYSCLKN

AVDD

SYSCLK_LF

SYSCLK_VREG

AVDD3

AVDD

OUT0P

OUT0N

AVDD

OUT1P

AVDD3

OUT1N

Figure 2. Pin Configuration

Table 21. Pin Function Descriptions

Input/

Pin No.

1, 6, 8, 53, 59,

Output Pin Type Mnemonic Description

I Power DVDD 1.8 V Digital Supply.

2 I 3.3 V CMOS SCLK/SCL

3 I/O 3.3 V CMOS SDIO

Serial Programming Clock. Data clock for serial programming. SCLK is used for SPI mode, and SCL is used for I

C® mode.

Serial Data Input/Output. When the device is in 4-wire mode, data is written via this pin. In 3-wire mode, both data reads and writes occur on this pin. There is no internal pull-up/pull-down resistor on this pin.

4 O 3.3 V CMOS SDO

Serial Data Output. Use this pin to read data in 4-wire mode (high impedance in 3-wire mode). There is no internal pull-up/pull-down resistor on this pin.

5 I 3.3 V CMOS

/SDA SPI Mode.

Chip Select (CS) Input. Active low. When programming a device, this pin must be held low. In systems where more than one AD9547 is present, this pin enables individual programming of each AD9547. In SPI mode, this pin has an internal 30 kΩ pull-up resistor.

C Mode.

I Serial Data Line (SDA) Input/Output. In I read operations and an input during write operations. There is no internal pull-up resistor in I

C mode. 7, 58 I Power DVDD3 3.3 V I/O Digital Supply. 9 I 3.3 V CMOS RESET

Chip Reset. Assertion of this pin (active high) resets the device. This pin has an internal 50 kΩ pull-down resistor.

10, 11 I Power DVDD

1.8 V DAC Decode Digital Supply. Isolate the supply associated with these

DVDD pins from the supply associated with the other DVDD pins. 12, 15, 19, 22 O Ground VSS Analog Ground. Connect to ground. 13 O

Differential

DACOUTP DAC Output. DACOUTP contains an internal 50 Ω pull-down resistor.

output

14 O

Differential output

DACOUTN

Complementary DAC Output. DACOUTN contains an internal 50 Ω pull-down

resistor. 16 I Power AVDD3 3.3 V Analog (DAC) Power Supply. 17, 18 I Power AVDD 1.8 V Analog (DAC) Power Supply.

Rev. B | Page 15 of 104

08300-002

C Mode, this pin is an output during

Page 16

AD9547

Input/

Pin No.

20 I

21 I

23 I Power AVDD 1.8 V Analog (Input Receiver) Power Supply. 24 O

25, 31 I Power AVDD3

26 O

27 O

28, 32 I Power AVDD 1.8 V Analog (Output Divider) Power Supply. 29 O

30 O

33 I Power AVDD3 3.3 V Analog (System Clock) Power Supply. 34 I SYSCLK_VREG

35 O SYSCLK_LF

36, 39 I Power AVDD 1.8 V Analog (System Clock) Power Supply. 37 I

38 I

40, 41 I

42 I Power AVDD 1.8 V Analog (Time-to-Digital Converter) Power Supply. 43, 49 I Power AVDD3 3.3 V Analog (Reference Input) Power Supply. 44 I

45 I

46, 50 I Power AVDD 1.8 V Analog (Reference Input) Power Supply.

Output Pin Type Mnemonic Description

Differential input

Current set resistor

LVPECL, LVDS, or CMOS

Differential input

CLKINN

CLKINP

OUT_RSET

OUT0P

OUT0N

OUT1P

OUT1N

SYSCLKN

SYSCLKP

TDC_VRB, TDC_VRT

REFA

REFAA

Clock Distribution Input. In standard operating mode, this pin is connected to the filtered DACOUTN output. This internally biased input is typically ac-coupled, and, when configured as such, can accept any differential signal with a singleended swing of at least 400 mV.

Clock Distribution Input. In standard operating mode, this pin is connected to the filtered DACOUTP output.

Connect an optional 3.12 kΩ resistor from this pin to ground (see the Output Current Control with an External Resistor section).

Analog Supply for Output Driver. These pins are normally 3.3 V but can be

1.8 V. Pin 25 powers OUT0. Pin 31 powers OUT1. Apply power to these pins even if the corresponding outputs (OUT0P/OUT0N, OUT1P/OUT1N) are not used. See the Power Supply Partitions section.

Output 0. This output can be configured as LVPECL, LVDS, or single-ended CMOS. LVPECL and LVDS operation require a 3.3 V output driver power supply. CMOS operation can be either 1.8 V or 3.3 V, depending on the output driver power supply.

Complementary Output 0. This output can be configured as LVPECL, LVDS, or single-ended CMOS.

Output 1. This output can be configured as LVPECL, LVDS, or single-ended CMOS. LVPECL and LVDS operation require a 3.3 V output driver power supply. CMOS operation can be either 1.8 V or 3.3 V, depending on the output driver power supply.

Complementary Output 1. This output can be configured as LVPECL, LVDS, or single-ended CMOS.

System Clock Loop Filter Voltage Regulator. Connect a 0.1 F capacitor from this pin to ground. This pin is also the ac ground reference for the integrated external loop filter of the SYSCLK PLL multiplier (see the SYSCLK PLL Multiplier section).

System Clock Multiplier Loop Filter. When using the frequency multiplier to drive the system clock, an external loop filter can be attached to this pin.

Complementary System Clock Input. Complementary signal to SYSCLKP. SYSCLKN contains internal dc biasing and should be ac-coupled with a 0.01 F capacitor, except when using a crystal. When using a crystal, connect it across SYSCLKP and SYSCLKN.

System Clock Input. SYSCLKP contains internal dc biasing and should be accoupled with a 0.01 F capacitor, except when using a crystal. When using a crystal, connect it directly across SYSCLKP and SYSCLKN. Single-ended 1.8 V CMOS is also an option but can introduce a spur if the duty cycle is not 50%. When using SYSCLKP as a single-ended input, connect a 0.01 F capacitor from SYSCLKN to ground.

Use capacitive decoupling on these pins (see Figure 36).

Reference A Input. This internally biased input is typically ac-coupled and, when configured as such, can accept any differential signal with a singleended swing of up to 3.3 V. If dc-coupled, input can be LVPECL, CMOS, or LVDS.

Complementary Reference A Input. Complementary signal to the input provided on Pin 44. The user can configure this pin as a separate single-ended input.

Rev. B | Page 16 of 104

Page 17

AD9547

Input/

Pin No.

47 I

48 I

51 I NC No Connection. This pin should be left floating. 52 O Logic IRQ Interrupt Request Line. 54, 55, 56, 57,

60, 61, 62, 63 EP O

Output Pin Type Mnemonic Description

Differential input

I/O 3.3 V CMOS

Exposed pad

REFB

REFBB

M0, M1, M2, M3, M4, M5, M6, M7

Exposed pad The exposed pad must be connected to ground (VSS).

Reference B Input. This internally biased input is typically ac-coupled and,

when configured as such, can accept any differential signal with a single-ended

swing of up to 3.3 V. If dc-coupled, input can be LVPECL, CMOS, or LVDS.

Complementary Reference B Input. Complementary signal to the input provided

on Pin 47. The user can configure this pin as a separate single-ended input.

Configurable I/O Pins. These pins are configured under program control.

Rev. B | Page 17 of 104

Page 18

AD9547

–

TYPICAL PERFORMANCE CHARACTERISTICS

= input reference clock frequency, fO = clock frequency, f

REF

DPLL loop bandwidth, PLL off = SYSCLK PLL bypassed, PLL on = SYSCLK PLL enabled, I SYSCLK PLL loop filter. AVDD, AVDD3, and DVDD at nominal supply voltage, f otherwise noted.

PHASE NOISE (dBc/Hz)

–80

–90

–100

–110

–120

–130

–140

–150

–160

INTEGRATED RMS JITTER (PHASE NOISE): 5kHz TO 20MHz: 173fs (–75.4d Bc ) 20kHz TO 80MHz : 315 fs (–70.2dBc) ( EXTRAPOLATED)

100 1k 10k 100k 1M 10M 100M

FREQUENCY OFFSET (Hz)

Figure 3. Additive Phase Noise (Output Driver = LVPECL),

= 19.44 MHz, fO = 155.52 MHz,

REF

LBW = 1 kHz, f

= 1 GHz, PLL Off

SYSCLK

= SYSCLK input frequency, fS =internal system clock frequency, LBW =

SYSCLK

= SYSCLK PLL charge pump current, LF =

= 1 GHz, ICP = automatic mode, LF = internal, unless

–80

–90

–100

–110

–120

–130

PHASE NOISE (dBc/Hz)

–140

–150

–160

100 1k 10k 100k 1M 10M 100M

8300-068

INTEGRATED RMS JITTER (PHASE NOISE): 5kHz TO 20MHz: 103fs (–74.0dBc) 20kHz TO 80MHz: 160fs (–70.1dBc)

FREQUENCY OFFSET (Hz)

Figure 5. Additive Phase Noise (Output Driver = LVPECL),

= 19.44 MHz, fO = 311.04 MHz,

REF

LBW = 1 kHz, f

= 1 GHz, PLL Off

SYSCLK

8300-066

PHASE NOISE ( dBc/Hz)

–80

–90

–100

–110

–120

–130

–140

–150

–160

INTEGRATE D RMS JI T T E R (PHAS E NO I S E) : 5kHz TO 20MHz: 333fs (–69.8dBc) 20kHz TO 80MHz: 430fs (–67.6dBc) (EXTRAPO LATED)

100 1k 10k 100k 1M 10M 100M

FREQUENCY OFFSET (Hz)

Figure 4. Additive Phase Noise (Output Driver = LVPECL),

= 19.44 MHz, fO = 155.52 MHz,

REF

LBW = 1 kHz, f

= 50 MHz (Crystal), PLL On

SYSCLK

–80

–90

–100

–110

–120

–130

PHASE NOISE (dBc/Hz)

–140

–150

–160

100 1k 10k 100k 1M 10M 100M

8300-056

INTEGRAT E D RM S JITTER (P HASE NOISE): 5kHz TO 20MHz: 310fs (–64.4dBc) 20kHz TO 80MHz: 330fs (–63.9dBc)

FREQUENCY OFFSET (Hz)

08300-067

Figure 6. Additive Phase Noise (Output Driver = LVPECL),

= 19.44 MHz, fO = 311.04 MHz,

REF

LBW = 1 kHz, f

= 50 MHz (Crystal), PLL On

SYSCLK

Rev. B | Page 18 of 104

Page 19

AD9547

–

PHASE NOISE (dBc/Hz)

–80

–90

–100

–110

–120

–130

–140

–150

–160

INTEGRATED RMS JITTER (PHASE NOISE): 5kHz TO 20MHz: 361fs (–69.0d Bc ) 20kHz TO 80MHz : 441 fs (–67.3dBc) ( EXTRAPOLATED)

100 1k 10k 100k 1M 10M 100M

FREQUENCY OFFSET (Hz)

Figure 7. Additive Phase Noise (Output Driver = LVPECL),

= 19.44 MHz, fO = 155.52 MHz,

REF

LBW = 1 kHz, f

= 50 MHz, PLL On

SYSCLK

08300-069

–80

–90

–100

–110

–120

–130

PHASE NOISE ( dBc/Hz)

–140

–150

–160

100 1k 10k 100k 1M 10M 100M

50MHz CRYSTAL

ROHDE & SCHWARZ SMA100 (50MHz)

ROHDE & SCHWARZ

SMA100 (1GHz)

FREQUENCY OFFSET (Hz)

Figure 10. Additive Phase Noise Comparison of SYSCLK Input Options

(Output Driver = LVPECL),

= 19.44 MHz, fO = 311.04 MHz, LBW = 1 kHz

REF

08300-058

–80

–90

–100

–110

–120

–130

PHASE NOISE (dBc/Hz)

–140

–150

–160

100 1k 10k 100k 1M 10M 100M

INTEGRATED RMS JITTER (PHASE NOISE): 12kHz TO 20MHz: 245f s ( –65.0dBc) 20kHz TO 80MHz: 300f s ( –64.3dBc)

FREQUENCY OFFSET (Hz)

Figure 8. Additive Phase Noise (Output Driver = LVPECL),

LBW = 1 kHz, f

2× Frequency Multiplier, I

–100

–110

–120

–130

–140

PHASE NOISE (dBc/Hz)

–150

–160

–170

100 1k 10k 100k 1M 10M

= 50 MHz (Crystal), PLL On with

SYSCLK

= 375 μA, LF = External (350 kHz)

ROHDE & SCHWARZ

SMA100 (1GHz)

20MHz OCXO

ROHDE & SCHWARZ SMA100 (50MHz)

FREQUENCY OF FSET (Hz)

= 19.44 MHz, fO = 155.52 MHz,

REF

Figure 9. Phase Noise of SYSCLK Input Sources

–80

–90

–100

–110

–120

–130

PHASE NOISE (dBc/Hz)

–140

–150

–160

100 1k 10k 100k 1M 10M 100M

8300-051

INTEGRATED RMS JITTER (PHASE NO I SE): 5kHz TO 20MHz: 336fs (–69.7d Bc) 20kHz TO 80MHz : 425fs (–67.6dBc)

FREQUENCY OFFSET (Hz)

8300-052

Figure 11. Additive Phase Noise (Output Driver = LVPECL),

= 8 kHz, fO = 155.52 MHz,

LBW = 100 Hz, f

–10

–20

–30

–40

CLOSED-LOOP GAIN (dB)

–50

–60

–70

10 100 1k 10k 100k

8300-053

REF

= 50 MHz (Crystal), PLL On

SYSCLK

CLOSED-LOOPPEAKING: 0.04dB

FREQUENCY OFFSET (Hz)

8300-047

Figure 12. Jitter Transfer Bandwidth, Output Driver = LVPECL,

= 19.44 MHz, fO = 155.52 MHz,

LBW = 100 Hz (Phase Margin = 88°), f

REF

= 1 GHz, PLL Off

SYSCLK

Rev. B | Page 19 of 104

Page 20

AD9547

1.0

2.0

0.8

LVPECL

0.6

0.4

AMPLITUDE (V)

0.2

0 100 200 300 400 500 600 700

LVDS

FREQUENCY (MHz)

Figure 13. Amplitude vs. Toggle Rate,

LVPECL and LVDS

4.0

3.5

3.0

2.5

AMPLITUDE ( V )

2.0

10pF LO AD

20pF LOAD

5pF LO AD

1.5 20pF LOAD

AMPLITUDE (V)

1.0

10pF LOAD

0.5

8300-049

50 100 150 250200

FREQUENCY (MHz)

08300-062

Figure 16. Amplitude vs. Toggle Rate,

1.8 V CMOS

4.0

3.5

3.0

2.5

AMPLITUDE ( V )

2.0

5pF LOAD

10pF LOAD

1.5

1.0 0 100 200 300 400 500

FREQUENCY (M Hz)

Figure 14. Amplitude vs. Toggle Rate,

3.3 V CMOS (Strong Mode)

140

130

120

110

100

POWER (mW)

0 100 200 300 400 500

LVPECL

LVDS

FREQUENCY (M Hz)

Figure 15. Power Consumption vs. Frequency,

LVPECL and LVDS

(Single Channel)

1.5

1.0 0 102030405

8300-055

FREQUENCY (M Hz)

8300-063

Figure 17. Amplitude vs. Toggle Rate,

3.3 V CMOS (Weak Mode)

POWER (mW)

0 50 100 150 200

8300-064

10pF LOAD

20pF LOAD

FREQUENCY (MHz)

5pF LO AD

08300-061

Figure 18. Power Consumption vs. Frequency,

1.8 V CMOS

Rev. B | Page 20 of 104

Page 21

AD9547

160

140

120

10pF LO AD

20pF LO AD

5pF LO AD

FREQUENCY ( M Hz )

100

POWER (mW)

0 50 100 150 200 250 300 350

Figure 19. Power Consumption vs. Frequency,

3.3 V CMOS (Strong Mode)

1.0

0.8

0.6

0.4

0.2

–0.2

–0.4

DIFFERENT IAL AMPLITUDE (V)

–0.6

–0.8

–1.0

012345

TIME (ns)

Figure 20. Output Waveform,

LVPECL (400 MHz)

20pF LO AD 5pF LOAD

POWER (mW)

10 15 20 25 30 35 40

08300-060

10pF LO AD

FREQUENCY ( M Hz )

08300-059

Figure 22. Power Consumption vs. Frequency,

3.3 V CMOS (Weak Mode)

0.5

0.4

0.3

0.2

0.1

–0.1

–0.2

DIFFERENT IAL AMPLITUDE (V)

–0.3

–0.4

–0.5

012345

08300-050

TIME (ns)

8300-048

Figure 23. Output Waveform,

LVDS (400 MHz)

3.5

3.0

2.5

2.0

1.5

1.0

AMPLITUDE (V)

0.5

–0.5

0246810121416

20pF LO AD

TIME (ns)

10pF LOAD

Figure 21. Output Waveform,

3.3 V CMOS (100 MHz, Strong Mode)

8300-057

Rev. B | Page 21 of 104

3.5

3.0

2.5

AMPLITUDE ( V )

2.0

1.5

1.0

0.5

–0.5

20 pF LOAD

0 1020304050607080

5pF LOAD

TIME (ns)

Figure 24. Output Waveform,

3.3 V CMOS (20 MHz, Weak Mode)

8300-046

Page 22

AD9547

2.0

1.5

1.0

0.5

AMPLITUDE ( V)

–0.5

024

20pF LO AD

6 8 10 12 14 16

TIME (ns)

10pF LO AD

8300-065

Figure 25. Output Waveform,

1.8 V CMOS (100 MHz)

Rev. B | Page 22 of 104

Page 23

AD9547

INPUT/OUTPUT TERMINATION RECOMMENDATIONS

0.1µF

AD9547

3.3V LVDS OUTPUT

100Ω

IMPEDANCE

0.1µF

HIGH

INPUT

DOWNSTREAM

Figure 26. AC-Coupled LVDS or LVPECL Output Driver

AD9547

3.3V

LVPECL-

COMPATIBLE

OUTPUT

100Ω

DOWNSTREAM

Figure 27. DC-Coupled LVDS or LVPECL Output Driver

0.1µF

AD9547

SELF-BIASED

100Ω

REFERENCE

0.1µF

INPUT

(OPTIONAL)

Figure 28. Reference Input

DEVICE

08300-005

AD9547

(OPTIONAL)

SELF-BIASED

SYSCLKx

INPUT

08300-006

100Ω

0.1µF

08300-003

Figure 29. SYSCLKx Input

0.1µF

AD9547

(OPTIONAL)

SELF-BIASED

CLKINx

INPUT

08300-007

100Ω

0.1µF

08300-004

Figure 30. CLKINx Input

Rev. B | Page 23 of 104

Page 24

AD9547

GETTING STARTED

POWER-ON RESET

The AD9547 monitors the voltage on the power supplies at powerup. When DVDD3 is greater than 2.35 V ± 0.1 V and DVDD (Pin 1, Pin 6, Pin 8, Pin 53, Pin 59, and Pin 64) is greater than

1.4 V ± 0.05 V, the device generates a 75 ns reset pulse. The power-up reset pulse is internal and independent of the RESET pin. This internal power-up reset sequence eliminates the need for the user to provide external power supply sequencing. Within 45 ns after the leading edge of the internal reset pulse, the M0 to M7 multifunction pins function as high impedance digital inputs and continue to do so until programmed otherwise.

INITIAL M0 TO M7 PIN PROGRAMMING

During a device reset (either via the power-up reset pulse or the RESET pin), the multifunction pins (M0 to M7) function as high impedance inputs, but upon removal of the reset condition, level-sensitive latches capture the logic pattern present on the multifunction pins. The AD9547 requires that the user supply the desired logic state to the M0 to M7 pins by means of pull-up and/or pull-down resistors (nominally 10 k to 30 k).

The initial state of the M0 to M7 pins following a reset is referred to as FncInit, Bits[7:0]. Bits[7:0] of FncInit map directly to the logic states of M[7:0], respectively. The three LSBs of FncInit (FncInit, Bits[2:0]) determine whether the serial port interface functions according to the SPI or the I FncInit, Bits[2:0] = 000 selects the SPI interface. Any other value selects the I set to the value of FncInit, Bits[2:0].

The five MSBs of FncInit (FncInit, Bits[7:3]) determine the operation of the EEPROM loader. On the falling edge of RESET, if FncInit, Bits[7:3] = 00000, then the EEPROM contents are not transferred to the control registers and the device registers assume their default values. However, if FncInit, Bits[7:3] ≠ 00000, then the EEPROM controller transfers the contents of the EEPROM to the control registers with CONDITION = FncInit, Bits[7:3] (see the EEPROM section).

C port, with the three LSBs of the I2C bus address

C protocol. Specifically,

DEVICE REGISTER PROGRAMMING

The initial state of the M0 to M7 pins establishes the serial I/O port protocol (SPI or I tocol, and assuming that an EEPROM download is not used, program the device according to the recommended sequence that follows.

1. Program the system clock functionality.

The system clock parameters reside in the 0x100 register address space. They include the following:

• System clock PLL controls

• System clock period

• System clock stability timer

It is essential to program the system clock period because many of the AD9547 subsystems rely on this value. It is highly recom-

C). Using the appropriate serial port pro-

Rev. B | Page 24 of 104

mended that the system clock stability timer be programmed, as well. This is especially important when using the system clock PLL but also applies if using an external system clock source, especially if the external source is not expected to be completely stable when power is applied to the AD9547.

2. Initialize the system clock.

After the system clock functionality is programmed, issue an I/O update using Register 0x0005, Bit 0 to invoke the system clock settings.

3. Calibrate the system clock (only if using SYSCLK PLL).

Set the calibrate system clock bit in the cal/sync register (Address 0x0A02, Bit 0) and issue an I/O update. Then clear the calibrate system clock bit and issue another I/O update. This action allows time for the calibration to proceed while programming the remaining device registers.

4. Program the multifunction pins (optional).

This step is required only if the user intends to use any of the multifunction pins for status or control. The multifunction pin parameters reside in the 0x0200 register address space. The default configuration of the multifunction pins is as undesignated high impedance input pins.

5. Program the IRQ functionality (optional).

This step is required only if the user intends to use the IRQ feature. IRQ control resides in the 0x0200 register address space. It includes the following:

• IRQ pin mode control

• IRQ mask

The IRQ mask default values prevent interrupts from being generated. The IRQ pin mode default is open-drain NMOS.

6. Program the watchdog timer (optional).

This step is required only if the user intends to use the watchdog timer. Watchdog timer control resides in the 0x0200 register address space. The watchdog timer is disabled by default.

7. Program the DAC full-scale current (optional).

This step is required only if the user intends to use a full-scale current setting other than the default value. DAC full-scale current control resides in the 0x0200 register address space.

8. Program the digital phase-locked loop (DPLL).

The DPLL parameters reside in the 0x0300 register address space. They include the following:

• Free-run frequency (DDS frequency tuning word)

• DDS phase offset

• DPLL pull-in range limits

• DPLL closed-loop phase offset

• Phase slew control (for hitless reference switching)

• Tuning word history control (for holdover operation)

Page 25

AD9547

9. Program the clock distribution outputs.

The clock distribution parameters reside in the 0x0400 register address space. They include the following:

• Output power-down control

• Output enable (disabled by default)

• Output synchronization

• Output mode control

• Output divider functionality

• Program the reference inputs.

10. The reference input parameters reside in the 0x0500

• Reference power-down

• Reference logic family

• Reference profile assignment control

• Phase build-out control

11. Program the reference profiles.

The reference profile parameters reside in the 0x0600 and 0x0700 register address spaces. They include the following:

• Reference priority

• Reference period

• Reference period tolerance

• Reference validation timer

• Reference redetect timer

• Digital loop filter coefficients

• Reference prescaler (R divider)

• Feedback dividers (S, U, and V)

• Phase and frequency lock detector controls

12. Generate reference acquisition.

After the registers are programmed, issue an I/O update using Register 0x0005, Bit 0 to invoke all of the register settings that have been programmed up to this point.

If the settings are programmed for manual profile assignment, the DPLL locks to the first available reference that has the highest priority. If the settings are programmed for automatic profile assignment, then write to the reference profile selection register (Address 0x0A0D) to select the state machines that require starting. Next, issue an I/O update (Address 0x0005, Bit 0) to start the selected state machines. Upon completion of the reference detection sequence, the DPLL locks to the first available reference with the highest priority.

13. Generate the output clock.

If the registers are programmed for automatic clock distribution synchronization via DPLL phase or frequency lock, the synthesized output signal appears at the clock distribution outputs (assuming that the output is enabled and the DDS output signal has been routed to the CLKINx input pins). Otherwise, set and then clear the sync distribution bit (Address 0x0A02, Bit 1) or use a multifunction pin input (if programmed accordingly) to generate a clock distribution sync pulse, which causes the synthesized output signal to appear at the clock distribution outputs.

Rev. B | Page 25 of 104

Page 26

AD9547

THEORY OF OPERATION

AD9547

OUT_RSET

OUT0P OUT0N

OUT1P OUT1N

CLKINP CLKINN

EXTERNAL

ANALOG

FILTER

REFA

REFAA

REFB

REFBB

M0 TO M7

IRQ

DIFFERENTIAL

SINGLE-ENDED

2 OR 4

INPUT

REF

MONITOR

IRQ AND

STATUS

LOGIC

DIGITAL PLL CORE

÷R

TDC/PFD

PHASE

CONTROLLER

PROG.

DIGITAL

LOOP

FILTER

CONTROL

LOGIC

÷S

TW CLAMP

AND

HISTORY

HOLDOVER

LOGIC

DDS/DAC

LOW NOISE

CLOCK

MULTIPLIER

SYSCLK PORT

POST

DIV

POST

DIV

CLOCK

DISTRIBUTION

AMP

DIGITAL

INTERFACE

Figure 31. Detailed Block Diagram

OVERVIEW

The AD9547 provides clocking outputs that are directly related in phase and frequency to the selected (active) reference but with jitter characteristics primarily governed by the system clock. The AD9547 supports up to four reference inputs and a wide range of reference frequencies. The core of this product is a digital phaselocked loop (DPLL). The DPLL has a programmable digital loop filter that greatly reduces jitter transferred from the active reference to the output. The AD9547 supports both manual and automatic holdover modes. While in holdover mode, the AD9547 continues to provide an output as long as the DAC sample clock is present. The holdover output frequency is a time average of the output frequency history just prior to the transition to the holdover condition.

The device offers manual and automatic reference switchover capability if the active reference is degraded or fails completely. A direct digital synthesizer (DDS) and integrated DAC constitute a digitally controlled oscillator (DCO). The DCO output is a sinusoidal signal (450 MHz maximum) at a frequency that is determined by the active reference frequency and the programmed values of the reference prescaler (R) and feedback divider (S). Although not explicitly shown in Figure 31, the S divider has both an integer and fractional component, which is similar to a fractional-N synthesizer.

SYSCLKN SYSCLKP

The SYSCLKx input provides the sample clock for the DAC, which is either a directly applied high frequency source or a low frequency source coupled with the integrated PLL-based frequency multiplier. The low frequency option also allows for the use of a crystal resonator connected directly across the SYSCLKx inputs.

The DAC output routes directly off chip where an external filter removes the sampling artifacts before returning the signal on chip at the CLKINx inputs. Once on chip, an integrated comparator converts the filtered sinusoidal signal to a clock signal (square wave) with very fast rise and fall times.

The clock distribution section provides two output drivers. Each driver is programmable either as a single differential LVPECL/ LVDS output or as a dual single-ended CMOS output. Furthermore, a dedicated 30-bit programmable divider precedes each driver. The clock distribution section operates at up to 725 MHz. This enables use of a band-pass reconstruction filter (for example, a SAW filter) to extract a Nyquist image from the DAC output spectrum, thereby allowing output frequencies that exceed the typical 450 MHz limit at the DAC output.

08300-009

Rev. B | Page 26 of 104

Page 27

AD9547

REFERENCE CLOCK INPUTS

Two pairs of pins provide access to the reference clock receivers. Each pair is configurable either as a single differential receiver or as two independent single-ended receivers. To accommodate input signals with slow rising and falling edges, both the differential and single-ended input receivers employ hysteresis. Hysteresis also ensures that a disconnected or floating input does not cause the receiver to oscillate spontaneously.

When configured for differential operation, the input receivers accommodate either ac- or dc-coupled input signals. The receiver is internally dc biased to handle ac-coupled operation.

When configured for single-ended operation, the input receivers exhibit a pull-down load of 45 kΩ (typical). Three user-programmable threshold voltage ranges are available for each single-ended receiver.

REFERENCE MONITORS

The reference monitors depend on a known and accurate system clock period. Therefore, the functioning of the reference monitors is not reliable until the system clock is stable. To avoid an incorrect valid indication, the reference monitors indicate fault status until the system clock stability timer expires (see the System Clock Period section).

Reference Period Monitor

Each reference input has a dedicated monitor that repeatedly measures the reference period. The AD9547 uses the reference period measurements to determine the validity of the reference based on a set of user provided parameters in the profile register area of the register map (see the Profile Registers (Register 0X0600 to Register 0X07FF) section). The AD9547 also uses the reference period monitor to assign a particular reference to a profile when the user programs the device for automatic profile assignment.

The monitor works by comparing the measured period of a particular reference input against the parameters stored in the profile register assigned to that same reference input. The parameters include the reference period, an inner tolerance, and an outer tolerance. A 40-bit number defines the reference period in units of femtoseconds (fs). The 40-bit range allows for a reference period entry of up to 1.1 ms (909 Hz). A 20-bit number defines the inner and outer tolerances. The value stored in the register is the reciprocal of the tolerance specification. For example, a tolerance specification of 50 ppm yields a register value of 1/(50 ppm) = 1/0.000050 = 20,000 (0x04E20).

The use of two tolerance values provides hysteresis for the monitor decision logic. The inner tolerance applies to a previously faulted reference and specifies the largest period tolerance that a previously faulted reference can exhibit before it qualifies as nonfaulted. The outer tolerance applies to an already nonfaulted reference and specifies the largest period tolerance that a nonfaulted reference can exhibit before being faulted.

To produce decision hysteresis, the inner tolerance must be less than the outer tolerance. That is, a faulted reference must meet tighter requirements to become nonfaulted than a nonfaulted reference must meet to become faulted.

Reference Validation Timer

Each reference input has a dedicated validation timer. The validation timer establishes the amount of time that a previously faulted reference must remain fault free before the AD9547 declares it to be nonfaulted. The timeout period of the validation timer is programmable via a 16-bit register (see the validation register contained within each of the eight profile registers in the register map, Address 0x0600 to Address 0x07FF). The 16-bit number stored in the validation register represents units of milliseconds, which yields a maximum timeout period of 65,535 ms.

Note that a validation period of zero must be programmed to disable the validation timer. With the validation timer disabled, the user must validate a reference manually via the force validation timeout register (Address 0x0A0E).

Reference Redetect Timer

Each reference input has a dedicated redetect timer. The redetect timer is useful only when the device is programmed for automatic profile selection. The redetect timer establishes the amount of time that a reference must remain faulted before the AD9547 attempts to reassign it to a new profile. The timeout period of the redetect timer is programmable via a 16-bit register (see the redetect timer register contained within each of the eight profile registers in the register map, Address 0x0600 to Address 0x07FF). The 16-bit number stored in the redetect timer register represents units of milliseconds, which yields a maximum timeout period of 65,535 ms.

Note that a timeout period of 0 must be programmed to disable the redetect timer.

Rev. B | Page 27 of 104

Page 28

AD9547

FORCE VALI DATION

TIMEOUT

REF MONITOR

BYPASS

REF MONITOR

OVERRIDE

REFERENCE

MONITOR

REF FAULT

REFERENCE VALIDATION LOGIC

(4 COPIES, 1 PER REFERENCE INPUT)

FAULTED

Figure 32. Reference Validation Override

Reference Validation Override Control

Register 0x0A0E to Register 0x0A10 provide the user with the ability to override the reference validation logic, enabling a certain level of troubleshooting capability. Each of the four input references has a dedicated block of validation logic, as shown in Figure 32. The state of the valid signal at the output defines a particular reference as valid (1) or not valid (0), which includes the validation period (if activated) as prescribed by the validation timer. The override controls are the three control bits on the left side of the diagram.

The main feature to note is that when faulted = 1, the output latch is reset, which forces valid = 0 (indicating an invalid reference), regardless of the state of any other signal. Under the default condition (that is, all three control bits are set to 0), the reference monitor is the primary source of the validation process. This is because, under the default condition, the ref fault signal from the reference monitor is identical to the faulted signal.

The function of the faulted signal is fourfold.

• When faulted = 1, valid = 0, regardless of the state of any

other control signal. Therefore, faulted = 1 indicates an invalid reference.

• When the faulted signal transitions from 0 to 1 (that is, from

not faulted to faulted), the validation timer is momentarily reset, which means that, when it is enabled, it must exhaust its full counting sequence before it expires.

• When faulted = 0 (that is, the reference is not faulted), the

validation timer is allowed to perform its timing sequence. When faulted = 1 (that is, the reference is faulted), the validation timer is reset and halted.

• The faulted signal passes through an inverter, which converts

it to a not faulted signal that appears at the input of the valid latch. This allows the valid latch to capture the state of the not faulted signal when the validation timer expires.

The reference monitor bypass control bit (Address 0x0A10) enables bypassing of the reference fault signal generated by the reference monitor. When the reference monitor bypass bit = 1, the state of the faulted signal is dictated by the reference monitor override control bit. This is useful when the user relies on an external reference monitor rather than the internal monitor resident in the device.

VALID

VALIDATION TIMER R

TIMEOUT

08300-010

The user programs the reference monitor override bit based on the status of the external monitor. On the other hand, when the reference monitor bypass bit = 0, the reference monitor override control bit (Address 0x0A0F) allows the user to manually test the operation of both the valid latch and the validation timer. In this case, the user relies on the signal generated by the internal reference monitor (reference fault) but uses the reference monitor override bit to emulate a faulted reference. That is, when the reference monitor override bit = 1, faulted = 1, but when the reference monitor override bit = 0, faulted = reference fault.

In addition, the user can emulate a timeout of the validation timer via the force validation timeout control register at Address 0x0A0E. Writing a Logic 1 to this autoclearing bit triggers the valid latch, which is identically equivalent to a timeout of the validation timer.

REFERENCE PROFILES

The AD9547 has eight independent profile registers. A profile register contains 50 bytes that establish a particular set of device parameters. Each of the four input references can be assigned to any one of the eight profiles (that is, more than one reference can be assigned to the same profile). The profiles allow the user to prescribe the specific device functionality that should take effect when one of the input references assigned to a profile becomes the active reference. Each profile register has the same format and stores the following device parameters:

• Reference priority

• Reference period value (in femtoseconds (fs))

• Inner tolerance value (1/tolerance)

• Outer tolerance value (1/tolerance)

• Validation timer value (milliseconds (ms))

• Redetect timer value (milliseconds (ms))

• Digital loop filter coefficients

• Reference prescaler setting (R divider)

• Feedback divider settings (S, U, and V)

• DPLL phase lock detector threshold level

• DPLL phase lock detector fill rate

• DPLL phase lock detector drain rate

• DPLL frequency lock detector threshold level

• DPLL frequency lock detector fill rate

• DPLL frequency lock detector drain rate

Rev. B | Page 28 of 104

Page 29

AD9547

Reference-to-Profile Assignment Control

The user can manually assign a reference to a profile or let the device make the assignment automatically. The manual reference profile selection register (Address 0x0503 and Address 0x0504) is used to program whether a reference-to-profile assignment is manual or automatic. The manual reference profile selection register is a 2-byte register partitioned into four half bytes (or nibbles).

The four nibbles form a one-to-one correspondence with the four reference inputs: one nibble for REF A, the next for REF AA, and so on. For a reference configured as a differential input, however, the device ignores the nibble associated with the two-letter input. For example, if the B reference is differential, only the REF B nibble matters (the device ignores the REF BB nibble).

The MSB of each nibble is the manual profile bit, whereas the three LSBs of each nibble identify one of the eight profiles (0 to 7). A Logic 1 for the manual profile bit assigns the associated reference to the profile identified by the three LSBs of the nibble. A Logic 0 for the manual profile bit configures the associated reference for automatic reference-to-profile assignment (the three LSBs are ignored in this case). Note that references configured for automatic reference-to-profile assignment require activation (see the Reference-to-Profile Assignment State Machine section).

Reference-to-Profile Assignment State Machine

The functional flexibility of the AD9547 resides in the way that it assigns a particular input reference to one of the eight reference profiles. The reference-to-profile assignment state machine effectively builds a reference-to-profile table that maps the index of each input reference to a profile (see Ta ble 2 2).

Table 22. Reference-to-Profile Table

Reference Input Reference Index Profile

A 0 Profile # (or null) AA 1 Profile # (or null) B 2 Profile # (or null) BB 3 Profile # (or null)

Each entry in the profile column consists of a profile number (0 to 7) or a null value. A null value appears when a referenceto-profile assignment does not exist for a particular reference input (following a reset, for example). The information in Table 2 2 appears in the register map (Register 0x0D0C to Register 0x0D0F) so that the user has access to the reference-to-profile assignments on a real-time basis. Register 0x0D0C contains the information for REF A, Register 0x0D0D contains the information for REF AA, Register 0x0D0E for REF B, and Register 0x0D0F for REF BB. Bit 7 of each register is the null indicator for that particular reference. If Bit 7 = 0, the pro-file assignment for that particular reference is null. If Bit 7 = 1, that particular reference is assigned to the profile (0 to 7) identified by Bits[6:4]. Note that Bits[6:4] are meaningless unless Bit 7 = 1.

Rev. B | Page 29 of 104

Following a reset, the reference-to-profile assignment state machine is inactive to avoid improperly assigning a reference to a profile before the system clock stabilizes. The state machine relies on accurate information from the reference monitors, which, in turn, rely on a stable system clock. Because the reference-to-profile assignment state machine is inactive at power-up, the user must initiate it manually by writing to the reference profile selection register (Address 0x0A0D). The state machine activates immediately, unless the system clock is not stabilized. In that case, activation occurs upon expiration of the system clock stability timer. Note that initialization of the state machine is on a perreference basis. That is, each reference input is associated with an independent initialization control bit.

When initialized for processing a reference, the state machine continuously monitors that reference until the occurrence of a device reset. This is true even when the user programs a reference for manual profile selection, in which case the state machine associated with that particular reference operates with its activity masked. The masked background activity allows for seamless operation if the user subsequently reprograms the reference for automatic profile selection.

Reference-to-Profile Assignment

When a reference is programmed for manual profile assignment (see Register 0x0503 to Register 0x0504), the reference-to-profile assignment state machine puts the programmed manual profile number into the profile column of the reference-to-profile table (see Tabl e 22) in the row associated with the appropriate reference. However, when the user programs a reference for automatic profile assignment, the state machine must determine which profile to assign to the reference, as explained in the following paragraphs.

If a null entry appears in the reference-to-profile table for a particular input reference, the validation logic for that reference enters a period estimation mode. Note that a null entry is the default state following a reset, but it also occurs when a reference redetect timer expires. The period estimation mode enables the validation logic to make a blind estimate of the period of the input reference with a tolerance of 0.1%. The validation logic remains in the period estimation mode until it successfully estimates the reference period.

Upon a successful reference period measurement by the validation logic, the state machine compares the measured period to the nominal reference period programmed into each of the eight profiles. The state machine assigns the reference to the profile with the closest match to the measured period. If more than one profile exactly matches the reference period, the state machine chooses the profile with the lowest numeric index. For example, if the reference period in both Profile 3 and Profile 5 matches the measured period, Profile 3 is given the assignment.

To safeguard against making a poor reference-to-profile assignment, the state machine ensures that the measured reference period is within 6.25% of the nominal reference period that appears in the closest match profile. Otherwise, the state machine does not make a profile assignment and leaves the null entry in the reference-to-profile table.

Page 30

AD9547

As long as there are input references programmed for automatic profile assignment, and for which the profile assignment is null, the state machine continues to cycle through those references searching for a profile match. Furthermore, unless an input reference is assigned to a profile, it is considered invalid and excluded as a candidate for a reference switchover.

REFERENCE SWITCHOVER

An attractive feature of the AD9547 is its versatile reference switchover capability. The flexibility of the reference switchover functionality resides in a sophisticated prioritization algorithm coupled with register-based controls. This scheme provides the user with maximum control over the state machine that handles reference switchover.

The main reference switchover control resides in the loop mode register (Address 0x0A01). The user selection mode bits (Bits[4:3]) allow the user to select one of the reference switchover state machine’s four operating modes, as follows:

• Automatic mode (Address 0x0A01, Bits[4:3] = 00)

• Fallback mode (Address 0x0A01, Bits[4:3] = 01)

• Holdover mode (Address 0x0A01, Bits[4:3] = 10)

• Manual mode (Address 0x0A01, Bits[4:3] = 11)

In automatic mode, a fully automatic, priority-based algorithm selects the active reference. When programmed for automatic mode, the device ignores the user reference selection bits (Register 0x0A01, Bits[1:0]). However, when programmed for any of the other three modes, the device uses the user reference bits. They specify a particular input reference (00 = REF A, 01 = REF AA , 10 = REF B, 11 = REF BB).

In fallback mode, the user reference is the active reference when it is valid. Otherwise, the device switches to a new reference using the automatic priority-based algorithm.

In holdover mode, the user reference is the active reference when it is valid. Otherwise, the device switches to holdover mode.

In manual mode, the user reference is the active reference whether it is valid or not. Note that, when using this mode, the user must program the reference-to-profile assignment (see Register 0x0503 and Register 0x0504) as manual for the particular reference that is declared as the user reference. The reason is that if the user reference fails and its redetect timer expires, its profile assignment (shown in reference (user reference) does not have an assigned profile, which places the AD9547 into an undefined state.

The user also has the option to force the device directly into holdover or free-run operation via the user holdover and user free-run bits (Register 0x0A01, Bits[6:5]). In free-run mode, the free-running frequency tuning word register (Address 0x0300 to Address 0x0305) defines the DDS output frequency.

In holdover mode, the DDS output frequency depends on the holdover control settings (see the Holdover section).

Tabl e 22 ) becomes null. This means that the active

Automatic Priority-Based Reference Switchover

The AD9547 has a two-tiered, automatic, priority-based algorithm that is in effect for both automatic and fallback reference switchover. The algorithm relies on the fact that each reference profile contains both a selection priority and a promoted priority. The selection and promoted priority values range from 0 (highest priority) to 7 (lowest priority). The selection priority determines the order in which references are chosen as the active reference. The promoted priority is a separate priority value given to a reference only after it becomes the active reference.

An automatic reference switchover occurs on failure of the active reference or when a previously failed reference becomes valid and its selection priority is higher than the promoted priority of the currently active reference (assuming that the automatic or fallback reference switchover is in effect). When performing an automatic reference switchover, the AD9547 chooses a reference based on the priority settings within the profiles. That is, the device switches to the reference with the highest selection priority (lowest numeric priority value). It does so by using the reference-to-profile table (see Tab l e 22) to determine the reference associated with the profile exhibiting the highest priority.

If multiple references share the same profile, the device chooses the reference having the lowest index value. For example, if the A, B, and BB references (Index 0, Index 2, and Index 3, respectively) share the same profile, a switchover to Reference A occurs because Reference A has the lowest index value. Note, however, that only valid references are included in switchover of the selection process. The switchover control logic ignores any reference with a status indication of invalid.

The promoted priority parameter allows the user to assign a higher priority to a reference after it becomes the active reference. For example, suppose that two references have a selection priority of 3 and a promoted priority of 1, and the remaining references have a selection priority of 2 and a promoted priority of 2. Now, assume that one of the Priority 3 references becomes active because all of the Priority 2 references have failed. Sometime later, however, a Priority 2 reference becomes valid. The switchover logic normally attempts to automatically switch over to the Priority 2 reference because it has higher priority than the presently active Priority 3 reference. However, because the Priority 3 reference is active, its promoted priority of 1 is in effect. This is a higher priority than the newly validated reference’s priority of 2, so the switchover does not occur. This mechanism enables the user to give references preferential treatment while they are selected as the active reference. An example of promoted vs. nonpromoted priority switching appears in state diagram form in Figure 33. Figure 34 shows a block diagram of the interrelationship between the reference inputs, monitors, validation logic, profile selection, and priority selection functionality.

Rev. B | Page 30 of 104

Page 31

AD9547

INITIAL STATE

ALL VALID

ACTIVE

PRIORITY TABLE

INPUT PRIORITY PROMOTED A0 0

AA 1 0

B2 1

BB 3 2

COMMON WITHOUT PROMOTION WITH PROMOTION

Figure 33. Example of Priority Promotion

A VALID

AA VALID

REF A/REF AA

REF B/REF BB

PROFILE

SELECTION

…

VALIDATION

LOGIC

Figure 34. Reference Clock Block Diagram

Phase Build-Out Reference Switching

Phase build-out reference switching is the term given to a reference switchover that completely masks any phase difference between the previous reference and the new reference. That is, there is virtually no phase change that can be detected at the output when a phase build-out switchover occurs.

The AD9547 handles phase build-out switching based on whether the new reference is a phase master. A phase master is any reference with a selection priority value that is less than the phase master threshold priority value (that is, higher priority). The phase master threshold priority value resides in the phase build-out switching register (Address 0x0507), and the selection priority resides in the profile registers (Address 0x0600 to Address 0x07FF). By default, the phase master threshold priority is 0; therefore, no references can be phase masters until the user changes the phase master threshold priority.

When the AD9547 switches from one reference to another, it compares the selection priority value that is stored in the profile that is assigned to the new reference with the phase master threshold priority. The AD9547 performs a phase build-out switchover only if the new reference is not a phase master.

Hitless Reference Switching (Phase Slew Control)

Hitless reference switching is the term given to a reference switchover that limits the rate of change of the phase of the output clock while the PLL is in the process of acquiring phase lock. This prevents the output frequency offset from becoming excessive.

A FAULTED

ACTIVE

AA FAULTED

ACTIVE

PRIORITY

SELECTION

A VALID

AA VALID

LOOP

CONTROLLER

……

08300-011

÷RMONITORS

TDC

08300-012

The all-digital nature of the DPLL core (see the Digital PhaseLocked Loop (DPLL) Core section) gives the user numerical control of the rate at which phase changes occur at the DPLL output. When enabled, a phase slew controller monitors the phase difference between the feedback and reference inputs to the DPLL. The phase slew controller can place a user-specified limit on the rate of change of phase, thus providing a mechanism for hitless reference switching.

The user sets a limit on the rate of change of phase by storing the appropriate value in the 16-bit phase slew rate limit register (Address 0x0316 and Address 0x0317). The 16-bit word, which represents units of ns/sec, puts an upper bound on the rate of change of the phase at the output of the DPLL during a reference switchover. A phase slew rate value of 0 (default) disables the phase slew controller.

The accuracy of the phase slew controller depends on both the phase slew limit value and the system clock frequency. Generally, an increase in the phase slew rate limit value or a decrease in the system clock frequency tends to reduce the error. Therefore, the accuracy is best for the largest phase slew rate limit value and the lowest system clock frequency. For example, assuming the use of a 1 GHz system clock, a phase slew rate limit value of 315 ns/sec (or more) ensures an error of <10%, whereas a phase slew rate limit value above ~3100 ns/sec ensures an error of <1%. On the other hand, assuming the use of a 500 MHz system clock, the same phase slew rate limit values ensure an error of <5% or

0.5%, respectively.

Rev. B | Page 31 of 104

Page 32

AD9547

DIGITAL PHASE-LOCKED LOOP (DPLL) CORE

DPLL Overview

A diagram of the digital PLL core of the AD9547 appears in Figure 35. The phase/frequency detector, feedback path, lock detectors, phase offset, and phase slew rate limiting that make up this second-generation DPLL are all digital implementations.

LOCK

DETECT

PHASE SLEW

REF A

REF BB

LIMIT

REF

TDC

R + 1

TDC AND PFD

Figure 35. Digital PLL Core

The start of the DPLL signal chain is the reference signal, f which is the frequency of the reference input. A reference prescaler reduces the frequency of this signal by an integer factor, R + 1, where R is the 30-bit value stored in the profile register and 0 ≤ R ≤ 1,073,741,823. Therefore, the frequency at the output of the R divider (or the input to the time-to-digital converter (TDC)) is

REF

TDC

1+=R

The TDC samples the output of the R divider. The TDC/PFD produces a time series of digital words and delivers them to the digital loop filter. The digital loop filter offers the following advantages:

Determination of the filter response by numeric

•

coefficients rather than by discrete component values

•

Absence of analog components (R/L/C), which eliminates

tolerance variations due to aging

•

Absence of thermal noise associated with analog

components

•

Absence of control node leakage current associated with

analog components (a source of reference feed-through spurs in the output spectrum of a traditional analog PLL)

The digital loop filter produces a time series of digital words at its output and delivers them to the frequency tuning input of a direct digital synthesizer (DDS), with the DDS replacing the function of the VCO in an analog PLL. The digital words from the loop filter tend to steer the DDS frequency toward frequency and phase lock with the input signal (f an analog output signal via an integrated DAC, effectively mimicking the operation of an analog VCO.

DPPL CORE

CLOSED-LOOP

PHASE OFFSET

DIGITAL

LOOP

FILTER

S + 1 + U/V

TDC

DDS

DDS/

DAC

DACOUT

REF

). The DDS provides

08300-013

The DPLL includes a feedback divider that causes the DDS to operate at an integer-plus-fractional multiple (S + 1 + U/V) of f

. S is the 20-bit value stored in the profile register and has a

TDC

range of 7 ≤ S ≤ 1,048,576. U and V are the 10-bit numerator and denominator values of the optional fractional divide component, also stored in the profile register. Together they establish the nominal DDS frequency (f

REF

DDS

⎛

⎜ ⎝

⎞

⎟

⎠

), given by

DDS

Normally, fractional-N designs exhibit distinctive phase noise and spurious artifacts resulting from the modulation of the integer divider based on the fractional value. This is not the case for the AD9547 because it uses a purely digital means to determine phase errors. Because the phase errors incurred by modulating the feedback divider are deterministic, it is possible to compensate for them digitally. The result is a fractional-N PLL with no discernible modulation artifacts.

Time-to-Digital Converter (TDC)/Phase Frequency Detector (PFD)

The TDC is a highly integrated functional block that incorporates both analog and digital circuitry. There are two pins associated with the TDC that the user must connect to external components. Figure 36 shows the recommended component values and their connections.

For best performance, place components as close as possible to the device pins. Components with low effective series resistance (ESR) and low parasitic inductance yield the best results.

AD9547

0.1µF

10µF

TDC_VRTTDC_VRB

0.1µF

08300-014

0.1µF

Figure 36. TDC Pin Connections

The PFD is an all-digital block. It compares the digital output from the TDC (which relates to the active reference edge) with the digital word from the feedback block (which relates to the rollover edge of the DDS accumulator after division by the feedback divider). The PFD uses a digital code pump and digital integrator (rather than a conventional charge pump and capacitor) to generate the error signal that steers the DDS frequency toward phase lock.

Rev. B | Page 32 of 104

Page 33

AD9547

Closed-Loop Phase Offset

The all-digital nature of the TDC/PFD provides for numerical control of the phase offset between the reference and feedback edges. This allows the user to adjust the relative timing of the distribution output edges relative to the reference input edges by programming the fixed phase lock offset bits (Address 0x030F to Address 0x0313). The 40-bit word is a signed (twos complement) number that represents units of picoseconds (ps).

In addition, the user can adjust the closed-loop phase offset (positive or negative) in incremental fashion. To do so, program the desired step size in the incremental phase lock offset step size bits (Address 0x0314 and Address 0x0315). This is an unsigned number that represents units of picoseconds (ps). The programmed step size is added to the current closed-loop phase offset each time the user writes a Logic 1 to the increment phase offset bit (Register 0x0A0C, Bit 0). Conversely, the programmed step size is subtracted from the current closed-loop phase offset each time the user writes a Logic 1 to the decrement phase offset bit (Register 0x0A0C, Bit 1). The serial I/O port control logic clears both of these bits automatically. The user can remove the incrementally accumulated phase by writing a Logic 1 to the reset incremental phase offset bit (Register 0x0A0C, Bit 2), which is also cleared automatically. Alternatively, rather than using the serial I/O port, the multifunction pins can be set up to perform the increment, decrement, and clear functions.

Note that the incremental phase offset is completely independent of the offset programmed into the fixed phase lock offset register. However, if the phase slew limiter is active (see the Hitless Reference Switching (Phase Slew Control) section), any instantaneous change in closed-loop phase offset (fixed or incremental) is subject to possible slew limitation by the action of the phase slew limiter.

Programmable Digital Loop Filter

The AD9547 loop filter is a third-order digital IIR filter that is analogous to the third-order analog loop shown in Figure 37.

08300-015

Figure 37. Third-Order Analog Loop Filter

The filter requires four coefficients, as shown in Figure 38. The AD9547 evaluation board software automatically generates the required loop filter coefficient values based on user design criteria. The Calculating the Digital Filter Coefficients section contains the design equations for calculating the loop filter coefficients manually.

Each coefficient has a fractional component representing a value from 0 up to, but not including, unity. Each also has an exponential component representing a power of 2 with a negative exponent. That is, the user enters a positive number (x) that the

−x

hardware interprets as a negative exponent of two (2

Thus, the β, γ, and δ coefficients always represent values less than unity. The α coefficient, however, has two additional exponential components, but the hardware interprets these as a positive

exponent of two (that is, 2

). This allows the α coefficient to take

on values that are greater than unity. To provide sufficient dynamic range, the positive exponent appears as two separate terms.

FRACTIONAL

1/2

(6-BIT)

(3-BIT)

(4-BIT)

FRACTIONAL

(17-BIT)

1/2

(6-BIT)

LOOP FILTER

(THIRD-ORDER I IR)

FRACTIONAL (17-BIT)

1/2 (6-BIT)

FRACTIONAL (15-BIT)

1/2 (5-BIT)

4851

(16-BIT)

IN OUT

08300-016

Figure 38. Third-Order Digital IIR Loop Filter

DPLL Phase Lock Detector

The DPLL contains an all-digital phase lock detector. The user controls the threshold sensitivity and hysteresis of the phase lock detector via the profile registers.

The phase lock detector behaves in a manner that is analogous to water in a tub (see Figure 39). The total capacity of the tub is 4096 units with −2048 denoting empty, 0 denoting the 50% point, and +2048 denoting full. The tub also has a safeguard to prevent overflow. Furthermore, the tub has a low water mark at −1024 and a high water mark at +1024. To change the water level, the user adds water with a fill bucket or removes water with a drain bucket. The user specifies the size of the fill and drain buckets via the 8-bit fill rate and drain rate values in the profile registers.

The phase lock detector uses the water level in the tub to determine the lock and unlock conditions. When the water level is below the low water mark (−1024), the detector indicates an unlock con-dition. Conversely, when the water level is above the high water mark (+1024), the detector indicates a lock condition. When the water level is between the marks, the detector holds its last condition. This concept appears graphically in Figure 39, with an overlay of an example of the instantaneous water level (vertical) vs. time (horizontal) and the resulting lock/unlock states.

2048

1024

–1024

–2048

STATE

Figure 39. Phase Lock Detector Diagram

LOCKED UNLOCKED

FILL

DRAIN

RATE

LOCK LEVEL

UNLOCK LEVEL

8300-017

Rev. B | Page 33 of 104

Page 34

AD9547

During any given PFD phase error sample, the detector either adds water with the fill bucket or removes water with the drain bucket (one or the other but not both). The decision on whether to add or remove water depends on the threshold level specified by the user. The phase lock threshold value is a 16-bit number stored in the profile registers and carries units of picoseconds (ps). Thus, the phase lock threshold extends from 0 ns to ±65.535 ns and represents the magnitude of the phase error at the output of the PFD.

The phase lock detector compares each phase error sample at the output of the PFD to the programmed phase threshold value. If the absolute value of the phase error sample is less than or equal to the programmed phase threshold value, the detector control logic dumps one fill bucket into the tub. Otherwise, it removes one drain bucket from the tub. Note that it is not the polarity of the phase error sample but, rather, its magnitude relative to the phase threshold value that determines whether to fill or drain. If more filling is taking place than draining, the water level in the tub eventually rises above the high water mark (+1024), which causes the phase lock detector to indicate lock. If more draining is taking place than filling, the water level in the tub eventually falls below the low water mark (−1024), which causes the phase lock detector to indicate unlock. The ability to specify the threshold level, fill rate, and drain rate enables the user to tailor the operation of the phase lock detector to the statistics of the timing jitter associated with the input reference signal.

Note that when the AD9547 enters the free-run or holdover mode, the DPLL phase lock detector indicates unlocked. Also, when the AD9547 performs a reference switchover, the state of the lock detector prior to the switch is preserved during the transition period.

DPLL Frequency Lock Detector

The operation of the frequency lock detector is identical to that of the phase lock detector. The only difference is that the fill or drain decision is based on the period deviation between the reference and feedback signals of the DPLL instead of the phase error at the output of the PFD.

The frequency lock detector uses a 24-bit frequency threshold register specified in units of picoseconds (ps). Thus, the frequency threshold value extends from 0 s to ±16.777215 s.

FREQUENCY

UNING WORD

(FTW)

48-BIT ACCUMULATO

4848

PHASE

OFFSET

It represents the magnitude of the difference in period between the reference and feedback signals at the input to the DPLL. For example, if the reference signal is 1.25 MHz and the feedback signal is 1.38 MHz, the period difference is approximately 75.36 ns (|1/1,250,000 − 1/1,380,000| ≈ 75.36 ns).

DIRECT DIGITAL SYNTHESIZER (DDS)

DDS Overview

One of the primary building blocks of the digital PLL is a direct digital synthesizer (DDS). The DDS behaves like a sinusoidal signal generator. The frequency of the sinusoid generated by the DDS is determined by a frequency tuning word (FTW), which is a digital (that is, numeric) value. Unlike an analog sinusoidal generator, a DDS uses digital building blocks and operates as a sampled system. Thus, it requires a sampling clock (f as the fundamental timing source of the DDS. The accumulator

behaves as a modulo-2

counter with a programmable step size

(FTW). A block diagram of the DDS appears in Figure 40.

The input to the DDS is the 48-bit FTW. The FTW serves as a step size value. On each cycle of f

, the accumulator adds the

value of the FTW to the running total at its output. For example, given that FTW = 5, the accumulator counts by fives, incrementing on each f the upper end of its capacity (2

cycle. Over time, the accumulator reaches

in this case), at which point, it rolls over but retains the excess. The average rate at which the accumulator rolls over establishes the frequency of the output sinusoid. The average rollover rate of the accumulator establishes the output frequency (f

FTW

⎛

⎜

⎝

) of the DDS and is given by

DDS

⎞

⎟

SDDS

⎠

Solving this equation for FTW yields

⎡

FTW

⎢

2round

⎢

⎣

For example, given that f

⎤

⎞

⎛

DDS

⎟

⎜

⎥

⎟

⎜

⎥

⎠

⎝

⎦

= 1 GHz and f

DDS

FTW = 43,774,988,378,041 (0x27D028A1DFB9).

Note that the minimum DAC output frequency is 62.5 MHz; therefore, normal operation requires an FTW that yields an output frequency in excess of this lower bound.

ANGLE TO

AMPLITUDE

CONVERSION

1419

DAC

(14-BIT)

DAC+

DAC–

) that serves

= 155.52 MHz, then

Figure 40. DDS Block Diagram

Rev. B | Page 34 of 104

8300-018

Page 35

AD9547

DDS Phase Offset

The relative phase of the sinusoid generated by the DDS is numerically controlled by adding a phase offset word to the output of the DDS accumulator. This is accomplished via the open loop phase offset register (Address 0x030D to Address 0x030E), which is a programmable 16-bit value (phase). The resulting phase offset, Φ (radians), is given by

phase

⎛

π=Δ

⎜ ⎝

⎞ ⎟

⎠

Phase offset and relative time offset are directly related. The time offset is (Δphase/2

)/f

(seconds), where f

DDS

is the

output frequency of the DDS (Hz).

DAC Output

The output of the digital core of the DDS is a time series of numbers representing a sinusoidal waveform. The DAC translates the numeric values to an analog signal. The DAC output signal appears at two pins that constitute a balanced current source architecture (see Figure 41).

AVDD3

CURRENT

SCALE

CODE

214 – 1

DACOUTP DACOUTN

GND

MIRROR

CURRENT

SWITCH ARRAY

SWITCH

CONTROL

CODE

Figure 41. DAC Output Pins

50Ω50Ω

GND

IFS1–

CODE

– 1

8300-019

The value of IFS is programmable via the 10-bit DAC full-scale current word in the DAC current register (Address 0x0213 and Address 0x0214). The value of the 10-bit word (I

SCALE

) sets IFS

according to the following formula:

⎛

⎞

= 120 µA × (72 +

)

⎜

⎝

SCALE

⎟ ⎠

TUNING WORD PROCESSING

The frequency tuning words that dictate the output frequency of the DDS come from one of three sources (see Figure 42).

The free-running frequency tuning word register

•

The output of the digital loop filter

•

The output of the tuning word history processor

TUNING WO RD

HISTORY

FREE-RUN

TUNING WO RD

TUNING WORD

UPDATE

FROM DIGITAL

LOOP FILTER

TUNING

WORD

ROUTING

CONTROL

Figure 42. Tuning Word Processing

When the DPLL is in free-run mode, the DDS tuning word is the value stored in the free-running frequency tuning word register (Address 0x0300 to Address 0x0305). When the DPLL is operating normally (closed loop), the DDS tuning word comes from the output of the digital loop filter, which changes dynamically to maintain phase lock with the input reference signal (assuming that the device has not performed an automatic switch to holdover mode). When the DPLL is in holdover mode, the DDS tuning word depends on a historical record of past tuning words during the time that the DPLL operated in closed-loop mode.

However, regardless of the operating mode, the DDS output frequency is ultimately subject to the boundary conditions imposed by the frequency clamp logic as explained in the Frequency Clamp section.

Frequency Clamp

The user controls the frequency clamp boundaries via the pullin range limit registers (Address 0x0307 to Address 0x030C). These registers allow the user to fix the DDS output frequency between an upper and lower bound with a granularity of 24 bits. Note that these upper and lower bounds apply regardless of the frequency tuning word that appears at the input to the DDS. The register value relates to the absolute upper or lower frequency bound (f

= fS × (N/224)

CLAMP

where

N is the value stored in the upper- or lower-limit register,

is the system sample rate.

and

CLAMP

) as

Even though the frequency clamp limits put a bound on the DDS output frequency, the DPLL is still free to steer the DDS frequency within the clamp limits. The default register values set the clamp range from 0 Hz (dc) to f the frequency clamp functionality until the user alters the register values.

Frequency Tuning Word History

The AD9547 has the ability to track the history of the tuning word samples generated by the DPLL digital loop filter output. It does so by periodically computing the average tuning word value over a user-specified interval. The user programs the interval via the 24-bit history accumulation timer register (Address 0x0318 to Address 0x031A). This 24-bit value represents a time interval (T

AVG

extends from 1 ms to a maximum of 4:39:37.215 (hr:min:sec).

TUNING WO RD

HISTORY

PROCESSOR

TUNING

WORD

CLAMP

LOWER TUNING

WORD

UPPER

TUNING

WORD

, effectively eliminating

TO DDS

) in units of milliseconds (ms) that

08300-070

Rev. B | Page 35 of 104

Page 36

AD9547

Note that history accumulation timer = 0 should not be programmed because it may cause improper device operation.

The control logic performs a calculation of the average tuning word during the T

interval and stores the result in the holdover

AVG

history register (Address 0x0D14 to Address 0x0D19). Computation of the average for each T

interval is independent of the

AVG

previous interval (that is, the average is a memoryless average as opposed to a true moving average). In addition, at the end of each

interval, the device generates an internal strobe pulse. The

AVG

strobe pulse sets the history updated bit in the IRQ monitor register (assuming that the bit is enabled via the IRQ mask register). Furthermore, the strobe pulse is available as an output signal via the multifunction pins (see the Multifunction Pins (M0 to M7) section).

History accumulation begins when the device switches to a new reference. By default, the device clears any previous history when it switches to a new reference. Furthermore, the user can clear the tuning word history under software control using Bit 2 of Register 0x0A03 or under hardware control via the multifunction pins (see the Multifunction Pins (M0 to M7) section). However, the user has the option of programming the device to retain (rather than clear) the old history by setting the persistent history bit (Register 0x031B, Bit 3).

When the tuning word history is nonexistent (that is, after a power-up, reset, or switchover to a new reference with the persistent history bit cleared), the device waits for the history accumulation timer (T

) to expire before storing the first

AVG

history value in the holdover history register.

In cases where T

is quite large (4½ hours, for example), a

AVG

problem arises in that the first averaged result does not become available until the full T

interval passes. Thus, it is possible

AVG

that as much as 4½ hours can elapse before the first averaged result is available. If the device must switch to holdover during this time, a tuning word history is not available.

To alleviate this problem, the user can access the incremental average bits in the history mode register (Register 0x031B, Bits[2:0]). If the history has been cleared, this 3-bit value, K (0 ≤ K ≤ 7), specifies the number of intermediate averages to take during the first, and only the first, T

interval. When K = 0, no

AVG

intermediate averages are calculated; therefore, the first average occurs after Interval T

(the default operating mode). However,

AVG

if K = 4, for example, four intermediate averages are taken during the first T

These average computations occur at T

/2, and T

AVG

of powers of 2 beginning with T mediate averages occurs only during the first T

interval.

AVG

/16, T

AVG

(note that the denominator exhibits a sequence

AVG

/2K). The calculation of inter-

AVG

/8, T

/4,

AVG

interval. All subsequent average computations occur at evenly spaced intervals of T

AVG

LOOP CONTROL STATE MACHINE

The loop control state machine is responsible for monitoring, initiating, and sequencing changes to the DPLL loop. Generally, it automatically controls the transition between input references and the entry and exit of holdover mode. In controlling loop state changes, the state machine also arbitrates the application of new loop filter coefficients, divider settings, and phase detector offsets based on the profile settings. The user can manually force the device into holdover or free-run mode via the loop mode register (Address 0x0A01), as well as force the selection of a specific input reference.

Switchover

Switchover occurs when the loop controller switches directly from one input reference to another. Functionally, the AD9547 handles a reference switchover by briefly entering holdover mode then immediately recovering. During the switchover event, however, the AD9547 preserves the status of the lock detectors in order to avoid phantom unlock indications.

Holdover

The holdover state of the DPLL is an open-loop operating mode; that is, the device no longer operates as a closed-loop system. Instead, the output frequency remains constant and is dependent on the device programming and availability of the tuning word history as explained in the following paragraphs.

If a tuning word history exists (see the Frequency Tuning Word History section), the holdover frequency is the average frequency just prior to entering the holdover state. If there is no tuning word history, the holdover frequency depends on the state of the single sample fallback bit in the history mode register (Register 0x031B, Bit 4). If the single sample fallback bit is Logic 0, the holdover frequency is the frequency defined in the free-running frequency tuning word register (Address 0x0300 to Address 0x0305). If the single sample fallback bit is Logic 1, the holdover frequency is the last instantaneous frequency output by the DDS just prior to the device entering holdover mode (note that this is not the average frequency prior to holdover).

The initial holdover frequency accuracy depends on the loop bandwidth of the DPLL and the time elapsed to compute a tuning word history. The longer the historical average, the more accurate the initial holdover frequency (assuming a drift-free system clock). Furthermore, the stability of the system clock establishes the stability and long-term accuracy of the holdover output frequency. Another consideration is the 48-bit frequency tuning resolution of the DDS and its relationship to fractional frequency error, ∆f

In this equation, f

is the sample rate of the output DAC and fO

is the DDS output frequency. The worst-case scenario is maximum

(1 GHz) and minimum fO (62.5 MHz), which yields ∆fO/fO =

2.8 × 10

−14

, which is less than one part in ten trillion.

O/fO

Rev. B | Page 36 of 104

Page 37

AD9547

Recovery from Holdover

When in holdover, if a valid reference becomes available, the device exits holdover operation. The loop state machine restores the DPLL to closed-loop operation, locks to the selected reference, and sequences the recovery of all the loop parameters based on the profile settings for the active reference.

Note that if the user holdover bit (Register 0x0A01, Bit 6) is set, the device does not automatically exit holdover when a valid reference is available. However, automatic recovery can occur after clearing the user holdover bit.

SYSTEM CLOCK INPUTS

Functional Description

The system clock circuit provides a low jitter, stable, high frequency clock for use by the rest of the chip. The user has the option of directly driving the SYSCLKx inputs with a high frequency clock source at the desired system clock rate. Alternatively, the SYSCLKx input can be configured to operate in conjunction with the internal SYSCLK PLL. The SYSCLK PLL can synthesize the system clock by means of a crystal resonator connected across the SYSCLKx input pins or by means of direct application of a low frequency clock source.

The SYSCLKx inputs are internally biased to a dc level of ~1 V. Take care to ensure that any external connections do not disturb the dc bias because such a disturbance can significantly degrade performance. Generally, the SYSCLKx inputs should be ac-coupled to the signal source (except when using a crystal resonator).

Low Loop Bandwidth Applications Using a TCXO/OCXO

For many applications, the use of a crystal oscillator is a costeffective and simple choice. The stability is good enough to support loop bandwidths down to 50 Hz, and the holdover performance is good enough for all except the most demanding applications.

In cases where Stratum 2 or Stratum 3 holdover performance is needed, or in cases where the loop bandwidth must be <50 Hz, the user must use either a TCXO or OCXO. The user should choose a TCXO/OCXO with a high output frequency and CMOS output to achieve the best performance.

When interfacing the TCXO/OCXO, a voltage divider on the output should be used to reduce the voltage swing to 1 V p-p, and that signal should be ac-coupled to the SYSCLKP pin. The SYSCLKN pin can be bypassed to ground with a 0.01 µF capacitor.

Choosing the System Clock Oscillator Frequency

The best performance of the AD9548 is achieved when the system clock is not an integer multiple of the DDS output frequency.

As an example, using a 19.44 MHz oscillator for the system clock in a 156.25 MHz Ethernet application yields better performance than a 25 MHz oscillator.

Another good system clock choice for many communications applications is a 49.152 MHz crystal used in IEEE 1394 (FireWire) because nearly all output frequencies are not integer related to this frequency and the crystal is readily available.

System Clock Details

A block diagram of the system clock appears in Figure 43. The signal at the SYSCLKx input pins becomes the internally buffered DAC sampling clock (f

High frequency direct (HF)

•

Low frequency synthesized (LF)

•

Crystal resonator synthesized (XTAL)

Note that both the LF and XTAL paths require the use of the SYSCLK PLL (see the SYSCLK PLL Multiplier section).

The main purpose of the HF path is to allow the direct use of a high frequency (500 MHz to 1 GHz) external clock source for clocking the AD9547. This path is optimized for high frequency and low noise floor. Note that the HF input also provides a path to SYSCLK PLL (see the SYSCLK PLL Multiplier section), which includes an input divider (M) programmable for divide-by −1,

−2, −4, or −8. The purpose of the divider is to limit the frequency at the input to the PLL to less than 150 MHz, which is the maximum PFD rate.

) via one of three paths.

Rev. B | Page 37 of 104

Page 38

AD9547

SYSCLKN

SYSCLKP

XTAL

2×

÷M

Figure 43. System Clock Block Diagram

The LF path permits the user to provide an LVPECL, LVDS, CMOS, or sinusoidal low frequency clock for multiplication by the integrated SYSCLK PLL. The LF path handles input frequencies from 3.5 MHz up to 100 MHz. However, when using a sinusoidal input signal, it is best to use a frequency in excess of 20 MHz. Otherwise, the resulting low slew rate can lead to substandard noise performance. Note that the LF path includes an optional 2× frequency multiplier to double the rate at the input to the SYSCLK PLL and potentially reduce the PLL in-band noise. However, to avoid exceeding the maximum PFD rate of 150 MHz, use of the 2× frequency multiplier is valid only for input frequencies below 125 MHz.

The XTAL path enables the connection of a crystal resonator (typically 10 MHz to 50 MHz) across the SYSCLKx input pins. An internal amplifier provides the negative resistance required to induce oscillation. The internal amplifier expects a 3.2 mm ×

2.5 mm AT cut, fundamental mode crystal with a maximum motional resistance of 100 . The following crystals, listed in alphabetical order, may meet these criteria. Note that, although these crystals meet the preceding criteria according to their data sheets, Analog Devices, Inc., does not guarantee their opera-tion with the AD9547, nor does Analog Devices endorse one crystal manufacturer/supplier over another.

AVX/Kyocera CX3225SB

•

ECS ECX-32

•

Epson/Toyocom TSX-3225

•

NDK NX3225SA

•

Siward SX-3225

LOOP

FILTER

÷N

SYSCLK_LF

CALIBRATION

VCO

SYSTEM CLOCK

08300-020

LOCK

DETECT

PFD AND

CHARGE

PUMP

SYSCLK_VRE

SYSCLK PLL MULTIPLIER

The SYSCLK PLL multiplier is an integer-N design and relies on an integrated LC tank and VCO. It provides a means to convert a low frequency clock input to the desired system clock frequency,

(900 MHz to 1 GHz). The SYSCLK PLL multiplier accepts input

signals between 3.5 MHz and 500 MHz, but frequencies in excess of 150 MHz require the M-divider to ensure compliance with the maximum PFD rate (150 MHz). The PLL contains a feedback divider (N) that is programmable for divide values between 6 and

255. The nominal VCO gain is 70 MHz/V.

Lock Detector

The SYSCLK PLL has a built-in lock detector. Register 0x0100, Bit 2 determines whether the lock detector is active. When it is active (default), the user controls the sensitivity of the lock detector via the lock detect divider bits (Register 0x0100, Bits[1:0]).

Note that a value of zero must be written to the system clock stability timer (Register 0x0106 to Register 0x0108) whenever the lock detector is disabled (Register 0x0100, Bit 2 = 1).

The SYSCLK PLL phase detector operates at the PFD rate, which is

/N. Each PFD sample indicates whether the reference and feed-

VCO

back signals are phase aligned (within a certain threshold range).

While the PLL is in the process of acquiring a lock condition, the PFD samples typically consist of an arbitrary sequence of in-phase and out-of-phase indications. As the PLL approaches complete phase lock, the number of consecutive in-phase PFD samples grows larger. Thus, one way of indicating a locked condition is to count the number of consecutive in-phase PFD samples and, if it exceeds a certain value, declare the PLL locked.

This is exactly the role of the lock detect divider bits. When the lock detector is enabled (Register 0x0100, Bit 2 = 0), the lock detect divider bits determine the number of consecutive in-phase decisions that are required (128, 256, 512, or 1024) before the lock detector declares a locked condition. The default setting is 128.

Rev. B | Page 38 of 104

Page 39

AD9547

Charge Pump

The charge pump operates in either automatic or manual mode, based on the charge pump mode bit (Register 0x0100, Bit 6).

When Register 0x0100, Bit 6 = 0, the AD9547 automatically selects the appropriate charge pump current based on the N divider value. Note that the user does not have control of the charge pump current bits (Register 0x0100, Bits[5:3]) in automatic mode. When Register 0x0100, Bit 6 = 1, the user determines the charge pump current via the charge pump current bits (Register 0x0100, Bits[5:3]). The charge pump current varies from 125 A to 1 mA in 125 A steps. The default setting is 500 A.

SYSCLK PLL Loop Filter

The AD9547 has an internal second-order loop filter that establishes the loop dynamics for input signals between 12.5 MHz and 100 MHz. By default, the device uses the internal loop filter. However, an external loop filter option is available by setting the external loop filter enable bit (Register 0x0100, Bit 7). This bit bypasses the internal loop filter and allows the device to use an externally connected second-order loop filter, as shown in Figure 44.

AD9547

SYSCLK_VREG

34 35

Figure 44. External Loop Filter Schematic

SYSCLK_LF

08300-021

To determine the external loop filter components, the user decides on the desired open loop bandwidth (f

) and phase margin (φ).

These parameters allow calculation of the loop filter components, as follows:

R1 =

C1 =

C2 =

⎛

⎜

⎝

VCOCP

)(2

fNKIπ

⎛

VCOCP

⎜

π )cos(

)2(

⎝

sin

)tan(

()

⎞ ⎟

⎟ ⎠

φ−

)sin(1

⎞ ⎟

⎟ ⎠

where:

= 7 × 107 V/ns (typical).

VCO

is the programmed charge pump current (amperes).

N is the programmed feedback divider value. f

is the desired open-loop bandwidth (Hz).

Φ is the desired phase margin (radians).

For example, assuming that N = 40, I

= 0.5 mA, fOL = 400 kHz,

and Φ = 50°, then the loop filter calculations yield R1 = 3.31 k, C1 = 330 pF, and C2 = 50.4 pF.

System Clock Period

Many of the user-programmable parameters of the AD9547 have absolute time units. To make this possible, the AD9547 requires a priori knowledge of the period of the system clock. To accommodate this requirement, the user programs the 21-bit nominal system clock period in the nominal SYSCLK period register (Address 0x0103 to Address 0x0105). The contents of this register reflect the actual period of the system clock in units of femtoseconds (fs). The user must program this register properly to ensure proper operation of the device because many of its subsystems rely on this value.

System Clock Stability Timer

The system clock stability timer, located in Register 0x0106 to Register 0x0108, is a 20-bit value programmed in units of milliseconds (ms). If the programmed timer value is 0, the timer immediately indicates that it has timed out. If the programmed timer value is nonzero and the SYSCLK PLL is enabled, the timer starts timing when the SYSCLK PLL lock detector indicates lock and times out after the prescribed period. However, when the user disables the SYSCLK PLL, the timer ignores the SYSCLK PLL lock detector and starts timing the instant that the SYSCLK PLL is disabled. The user can monitor the status of the stability timer at Register 0x0D01, Bit 4, via the multifunction pins or via the IRQ pin.

Note that the system clock stability timer must be programmed before the SYSCLK PLL is either activated or disabled.

SYSCLK PLL Calibration

When using the SYSCLK PLL, it is necessary to calibrate the LC-VCO to ensure that the PLL can remain locked to the system clock input signal. Assuming the presence of either an external SYSCLK input signal or a crystal resonator, the calibration process executes after the user sets and then clears the calibrate system clock bit in the cal/sync register (Register 0x0A02, Bit 0). During the calibration process, the device calibrates the VCO amplitude and frequency. The status of the system clock calibration process is user accessible via the system clock status register (Register 0x0D01, Bit 1). It is also available via the IRQ monitor register (Bit 1 of Register 0x0D02), provided that the status bit is enabled via the IRQ mask register (Register 0x0209 and Register 0x0210).

When the calibration sequence is complete, the SYSCLK PLL eventually attains a lock condition, at which point the system clock stability timer begins its countdown sequence. Expiration of the timer indicates that the SYSCLK PLL is stable, which is reflected in the system clock status register (Register 0x0D01, Bit 4).

Note that the monitors/detectors associated with the input references (REF A/REF AA and REF B/REF BB) are internally disabled until the SYSCLK PLL indicates that it is stable.

Rev. B | Page 39 of 104

Page 40

AD9547

CLOCK DISTRIBUTION

The clock distribution block of the AD9547 provides an integrated solution for generating multiple clock outputs based on frequency dividing the DPLL output. The distribution output consists of two channels (OUT0 and OUT1). Each channel has a dedicated divider and output driver section, as shown in Figure 45.

CLKINP CLKINN

SYNC

CONTROL

ENABLE

4 4 4

Figure 45. Clock Distribution

Clock Input (CLKINx)

The clock input handles input signals from a variety of logic families (assuming proper terminations and sufficient voltage swing). It also handles sine wave input signals such as those delivered by the DAC reconstruction filter. Its default operating frequency range is 62.5 MHz to 500 MHz.

Super-Nyquist Operation

Typically, the maximum usable frequency at the DAC output is about 45% of the system clock frequency. However, because it is a sampled DAC, its output spectrum contains Nyquist images. Of particular interest are the images appearing in the first Nyquist zone (50% to 100% of the system clock frequency). Super-Nyquist operation takes advantage of these higher frequencies, but this implies that the CLKINx input operates in excess of 500 MHz, which is outside its default operating limits.

The CLKINx receiver actually consists of two separate receivers: the default receiver and an optional high frequency receiver, which handles input signals up to 800 MHz. To select the high frequency receiver, write a Logic 1 to Register 0x0400, Bit4.

Super-Nyquist operation requires a band-pass filter at the DAC output instead of the usual low-pass reconstruction filter. SuperNyquist operation is viable as long as the image frequency does not exceed the 800 MHz input range of the receiver. Furthermore, to provide acceptable jitter performance, which is a consideration for image signals with low amplitude, the signal at the CLKINx inputs must meet the minimum slew rate requirements.

ENABLEn/MODE

RESET

OUT0

OUT1

SYNC SOURCE

OUT_RSET

OUT0P

OUT0N

OUT1P OUT1N

08300-022

Clock Dividers

The output clock distribution dividers are referred to as Q0 and Q1, corresponding to the OUT0 and OUT1 output channels, respectively. Each divider is programmable with 30 bits of division depth. The actual divide ratio is one more than the programmed register value; therefore, a register value of 3, for example, results in a divide ratio of 4. Thus, each divider offers a range of divide ratios

from 1 to 2

(1 to 1,073,741,824).

With an even divide ratio, the output signal always exhibits a 50% duty cycle. When the clock divider is bypassed (a divide ratio of 1), the output duty cycle is the same as the input duty cycle. Odd output divide ratios (excluding 1) exhibit automatic duty cycle correction given by

12 −

CycleDutyOutput

where:

N (which must be an odd number) is the divide ratio. X is the normalized fraction of the high portion of the input period

(that is, 0 < X < 1).

For example, if N = 5 and the input duty cycle is 20% (X = 0.2), then the output duty cycle is 44%. Note that, when the user programs an output as noninverting, then the device adjusts the falling edge timing to accomplish the duty cycle cor-rection. Conversely, the device adjusts the rising edge timing for an inverted output.

Output Power-Down

Each output channel offers independent control of power-down functionality via the distribution settings register (Address 0x0400). Each output channel has a dedicated power-down bit for powering down the output driver. However, if both channels are powered down, the entire distribution output enters a deep sleep mode.

Even though each channel has a channel power-down control signal, it may sometimes be desirable to power down an output driver while maintaining the divider’s synchronization with the other channel dividers. This is accomplished by either of the following methods:

•

In CMOS mode, use the divider output enable control bit

to stall an output. This provides power savings while maintaining dc drive at the output.

•

In LVDS/LVPECL mode, place the output in tristate mode

(this works in CMOS mode as well).

Output Enable

Each output channel offers independent control of enable/ disable functionality using the distribution enable register (Address 0x0401). The distribution outputs use synchronization logic to control enable/disable activity to avoid the production of runt pulses and to ensure that outputs with the same divide ratios become active/inactive in unison.

Rev. B | Page 40 of 104

Page 41

AD9547

Output Mode

The user has independent control of the operating mode of each of the two output channels via the distribution channel modes register (Address 0x0404 and Address 0x0405). The operating mode control includes

•

Logic family and pin functionality

•

Output drive strength

•

Output polarity

The three LSBs of both distribution channel mode registers comprise the mode bits. The mode value selects the desired logic family and pin functionality of an output channel, as listed in Tabl e 23 .

Table 23. Output Channel Logic Family and Pin Functionality

Mode Bits [2:0] Logic Family and Pin Functionality

000 CMOS (both pins) 001 CMOS (positive pin), tristate (negative pin) 010 Tristate (positive pin), CMOS (negative pin) 011 Tristate (both pins) 100 LVDS 101 LVPECL 110 Unused 111 Unused

Regardless of the selected logic family, each is capable of dc operation. However, the upper frequency is limited by the load conditions, drive strength, and impedance matching inherent in each logic family. Practical limitations set the maximum CMOS frequency to approximately 250 MHz, whereas LVPECL and LVDS are capable of 725 MHz.

In addition to the three mode bits, both distribution channel mode registers include the following control bits:

•

Polarity invert

•

CMOS phase invert Drive strength

•

The polarity invert bit enables the user to choose between normal polarity and inverted polarity. Normal polarity is the default state. Inverted polarity reverses the representation of Logic 0 and Logic 1 regardless of the logic family.

The CMOS phase invert bit applies only when the mode bits select the CMOS logic family. In CMOS mode, both output pins of the channel have a dedicated CMOS driver. By default, both drivers deliver identical signals. However, setting the CMOS phase invert bit causes the signal on an OUTxN pin to be the opposite of the signal appearing on the OUTxP pin.

The drive strength bit allows the user to control whether the output uses weak (0) or strong (1) drive capability (applies to CMOS and LVDS but not LVPECL). For the CMOS family, the strong setting implies normal CMOS drive capability, whereas the weak setting implies low capacitive loading and allows for reduced EMI. For the LVDS family, the weak setting provides

3.5 mA drive current for standard LVDS operation, whereas the

strong setting provides 7 mA for double terminated or double voltage LVDS operation. Note that 3.5 mA and 7 mA are the nominal drive current values when using the internal current setting resistor.

Output Current Control with an External Resistor

By default, the output drivers have an internal current setting resistor (3.12 k nominal) that establishes the nominal drive current for the LVDS and LVPECL operating modes. Instead of using the internal resistor, the user can elect to set the external distribution resistor bit (Register 0x0400, Bit 5) and connect an external resistor to the OUT_RSET pin. Note that this feature supports an external resistor value of 3.12 k only, allowing for tighter control of the output current than is possible by using the internal current setting resistor. However, if the user elects to use a nonstandard external resistance, the following equations provide the output drive current as a function of the external resistance (R):

8325.10

LVDS

LVPECL

665.21

76.24

The numeric subscript associated with the LVDS output current corresponds to the logic state of the drive strength bit in the distribution channel modes registers (Address 0x0404, Bit 3 and Address 0x0405, Bit 3). For R = 3.12 k, the equations yield I

= 3.5 mA, I

LVD S0

= 7.0 mA, and I

LVD S1

= 8.0 mA. Note that

LVP EC L

the device maintains a constant 1.238 V (nominal) across the external resistor.

Clock Distribution Synchronization

A block diagram of the distribution synchronization functionality appears in Figure 46. The synchronization sequence begins with the primary synchronization signal, which ultimately results in delivery of a synchronization strobe to the clock distribution logic.

As indicated, the primary synchronization signal originates from the following four possible sources:

•

Direct synchronization source via the sync distribution bit

(Register 0x0A02, Bit 1)

•

Automatic synchronization source based on frequency or

phase lock detection, as controlled via the automatic synchronization register (Address 0x0403)

Multifunction pin synchronization source via one of the

•

multifunction pins (M0 to M7)

•

EEPROM synchronization source via the EEPROM

All four sources of the primary synchronization signal are logic OR’d, so any one of them can synchronize the clock distribution output at any time. When using the multifunction pins, the synchronization event is the falling edge of the selected signal. When using the sync distribution bit, the user first sets then clears the bit.

Rev. B | Page 41 of 104

Page 42

AD9547

The synchronization event is the clearing operation; that is, the Logic 1 to Logic 0 transition of the bit.

The primary synchronization signal can synchronize the distribution output directly, or it can enable a secondary synchronization signal. This functionality depends on the two sync source bits in the distribution synchronization register (Register 0x0402, Bits[5:4]).

When sync source = 00 (direct), the falling edge of the primary synchronization signal directly synchronizes the distribution output.

When sync source = 01, the rising edge of the primary synchronization signal triggers the circuitry that detects a rising edge of the active input reference. The detection of the rising edge synchronizes the distribution output.

When sync source = 10, the rising edge of the primary synchronization signal triggers the circuitry that detects a rollover of the DDS accumulator (after processing by the DPLL feedback divider). This corresponds to the zero crossing of the output of the phase-toamplitude converter in the DDS (less the open-loop phase offset stored in Register 0x030D and Register 0x030E). The detection of the DPLL feedback edge synchronizes the distribution output.

Active Reference Synchronization (Zero Delay)

Active reference synchronization is the term applied to the case when sync source = 01 (Register 0x0402, Bits[5:4]). Referring to Figure 46, this means that the active reference sync path is active because Bit 4 = 1, enabling the lower AND gate and disabling the upper AND gate. The edge detector in the active reference sync block monitors the rising edges of the active reference (the mux selects the active reference automatically). The edge

PRIMARY

DIRECT SYNC

SOURCE

(ADDRESS DX 0x0A02[1])

AUTOMATIC SYNC

SOURCE

(REGISTER DX 0x0403)

MULTIF UNCT I O N PI N

SYNC SOURCE

EEPROM SYNC

SOURCE

SYNCHRONIZATION

SIGNAL

FEEDBACK

DIRECT SYNC

EDGE

DETECT

DPLL

EDGE

DPLL EDGE SYNC

ARM

DETECT

SYSCLK/4

EDGE

detector is armed via the primary synchronization signal, which is one of the four inputs to the OR gate (typically the direct sync source). As soon as the edge detector is armed, its output goes high, which stalls the output dividers in the clock distribution block. Furthermore, once armed, a rising edge from the active reference forces the output of the edge detector low. This restarts the output dividers, thereby synchronizing the clock distribution block.

The term zero delay applies because it provides a means to edgealign the output signal with the active input reference signal. Typically, zero-delay architectures use the output signal in the feedback loop of a PLL to track input/output edge alignment. Active reference synchronization, however, operates open loop. That is, synchronization of the output via the distribution synchronization logic occurs on a single edge of the active reference.

The fact that an active reference edge triggers the falling edge of the synchronization pulse means that the falling edge is asynchronous to the signal that clocks the distribution output dividers (CLKINx). Therefore, the output clock distribution logic reclocks the internal synchronization pulse to synchronize it with the CLKINx signal. This means that the output dividers restart after a deterministic delay associated with the reclocking circuitry. This deterministic delay has two components. The first deterministic delay component is four or five periods of the CLKINx signal. The one period uncertainty is due to the unknown position of the asynchronous reference clock edge relative to the CLKINx signal. The second deterministic delay component is one output period of the distribution divider.

0x0402[5]

TO MULTIFUNCTION PIN STATUS LOGIC

TO CLOCK DISTRIBUTION SYNCHRONIZATION CONTROL

STALL

DIVIDERS

SYNC OUTPUT DISTRIBUTION

0x0402[4]

REF A

REF BB

ACTIVE REFE RE NCE S Y NC

RESET

ARM

DETECT

EDGE

08300-023

Figure 46. Output Synchronization Block Diagram

Rev. B | Page 42 of 104

Page 43

AD9547

The deterministic delay, expressed as t equation, is a function of the frequency division factor (Q the channel divider associated with the zero-delay channel.

LATENCY

= (Qn + 4) × t

CLK_IN

or t

LATENCY

In addition to deterministic delay, there is random delay (t associated with the propagation of the reference signal through the input reference receiver, as well as the propagation of the clock signal through the clock distribution logic. The total delay is

= t

DELAY

The user can compensate for t

LATENCY

+ t

PROP

by using the device’s phase

DELAY

offset controls to move the edge timing of the distribution output signal relative to the input reference edge. One method is to use the open-loop phase offset registers (Address 0x030D and Address 0x030E) for timing adjustment. However, be sure to use sufficiently small phase increments to make the adjustment. Too large a phase step can result in the clock distribution logic missing a CLKINx edge, thus disrupting the edge alignment process. The appropriate phase increment depends on the transient response of any external circuitry connected between the DACOUTx and CLKINx pins.

The other method is to use the closed-loop phase offset registers (Address 0x030F to Address 0x0315) for timing adjustment. However, be sure to use a sufficiently small phase vs. time profile.

in the following

LATENCY

= (Qn + 5) × t

) of

CLK_IN

PROP

Changing the phase too quickly can cause the DPLL to lose lock, thus ruining the edge alignment process. Note that the AD9547 phase slew limit register (Address 0x0316 and 0x0317) can be used to limit the rate of change of phase automatically, thereby mitigating the potential loss-of-lock problem.

)

To guarantee synchronization of the output dividers, it is important to make any edge timing adjustments after the synchronization event. Furthermore, when making timing adjustments, the distribution outputs can be disabled and then renabled after the adjustment is complete. This prevents the device from generating output clock signals during the timing adjustment process.

Note that the form of zero-delay synchronization described here does not track propagation time variations within the distribution clock input path or the reference input path (on or off chip) over temperature, supply, and so on. It is strictly a one-time synchronization event.

Synchronization Mask

Each output channel has a dedicated synchronization mask bit (Register 0x0402, Bits[1:0]). When the mask bit associated with a particular channel is set, that channel does not respond to the synchronization signal. This allows the device to operate with the masked channels active and the unmasked channels stalled while they wait for a synchronization pulse.

Rev. B | Page 43 of 104

Page 44

AD9547

STATUS AND CONTROL

MULTIFUNCTION PINS (M0 TO M7)

The AD9547 has eight digital CMOS I/O pins (M0 to M7) that are configurable for a variety of uses. The function of these pins is programmable via the register map. Each pin can control or monitor an assortment of internal functions, based on the contents of Register 0x0200 to Register 0x0207. To monitor an internal function with a multifunction pin, write a Logic 1 to the MSB of the register associated with the desired multifunction pin. The value of the seven LSBs of the register defines the control function, as shown in Tabl e 24 .

Table 24. Multifunction Pin Output Functions (D7 = 1)

D[6:0] Value Output Function Source Proxy

0 Static Logic 0 1 Static Logic 1 2 System clock divided by 32 3 Watchdog timer output 4 EEPROM upload in p rogress Register 0x0D00, Bit 0 5 EEPROM download in progress Register 0x0D00, Bit 1 6 EEPROM fault detected Register 0x0D00, Bit 2 7 SYSCLK PLL lock detected Register 0x0D01, Bit 0 8 SYSCLK PLL calibration in progress Register 0x0D01, Bit 1 9 Unused Unused 10 Unused Unused 11 SYSCLK PLL stable Register 0x0D01, Bit 4 12 to 15 Unused Unused 16 DPLL free running Register 0x0D0A, Bit 0 17 DPLL active Register 0x0D0A, Bit 1 18 DPLL in hold over Register 0x0D0A, Bit 2 19 DPLL in reference switchover Register 0x0D0A, Bit 3 20 Active reference: phase master Register 0x0D0A, Bit 6 21 DPLL phase locked Register 0x0D0A, Bit 4 22 DPLL frequency locked Register 0x0D0A, Bit 5 23 DPLL phase slew limited Register 0x0D0A, Bit 7 24 DPLL frequency clam ped Register 0x0D0B, Bit 7 25 Tuning word history available Register 0x0D0B, Bit 6 26 Tuning word history updated Register 0x0D05, Bit 4 27 to 31 Unused Unused 32 R eference A fault Register 0x0D0C, Bit 2 33 Reference AA fault Register 0x0D0D, Bit 2 34 R eference B fault Register 0x0D0E, Bit 2 35 Reference BB fault Register 0x0D0F, Bit 2 36 to 47 Unused Unused 48 R eference A valid Register 0x0D0C, Bit 3 49 Reference AA valid Register 0x0D0D, Bit 3 50 R eference B valid Register 0x0D0E, Bit 3 51 Reference BB valid Register 0x0D0F, Bit 3 52 to 63 Unused Unused 64 Reference A active reference Register 0x0D0B,

Bits[1:0]

65 Reference AA active reference Register 0x0D0B,

Bits[1:0}

66 Reference B active reference Register 0x0D0B,

Bits[1:0]

67 Reference BB active reference Register 0x0D0B,

Bits[1:0]

68 to 79 Unused Unused

Rev. B | Page 44 of 104

D[6:0] Value Output Function Source Proxy

80 Clock distribution sync pulse Register 0x0D03, Bit 3 81 to

127

Unused

To control an internal function with a multifunction pin, write a Logic 0 to the most significant bit of the register associated with the desired multifunction pin. The monitored function depends on the value of the seven least significant bits of the register, as shown in Tab l e 25 . Note that the default setting is M0 through M7 configured as inputs and the input function set to unused (the first entry in Tab le 2 5).

Table 25. Multifunction Pin Input Functions (D7 = 0)

D[6:0] Value

0 Unused (default) Unused 1 I/O update Register 0x0005, Bit 0 2 Full power-down Register 0x0A00, Bit 0 3 Watchdog reset Register 0x0A03, Bit 0 4 IRQ reset Register 0x0A03, Bit 1 5 Tuning word history reset Register 0x0A03, Bit 2 6 to 15 Unused Unused 16 Holdover Register 0x0A01, Bit 6 17 Free run Register 0x0A01, Bit 5 18 Reset incremental phase

19 Increment incremental phase

20 Decrement incremental

21 to 31 Unused Unused 32 Override Reference Monitor A Register 0x0A0F, Bit 0 33 Override Reference Monitor AA Register 0x0A0F, Bit 1 34 Override Reference Monitor B Register 0x0A0F, Bit 2 35 Override Reference Monitor BB Register 0x0A0F, Bit 3 36 to 47 Unused Unused 48 Force Validation Timeout A Register 0x0A0E, Bit 0 49 Force Validation Timeout AA Register 0x0A0E, Bit 1 50 Force Validation Timeout B Register 0x0A0E, Bit 2 51 Force Validation Timeout BB Register 0x0A0E, Bit 3 52 to 63 Unused Unused 64 Enable OUT0 Register 0x0401, Bit 0 65 Enable OUT1 Register 0x0401, Bit 1 66, 67 Unused Unused 68 Enable OUT0, OUT1 Register 0x0401, Bits[1:0] 69 Sync clock distribution

70 to 127 Unused Unused

Input Function Destination Proxy

offset

phase offset

outputs

If more than one multifunction pin operates on the same control signal, then internal priority logic ensures that only one multifunction pin serves as the signal source. The selected pin is the one with the lowest numeric suffix. For example, if both M3 and M7 operate on the same control signal, M3 is used as the signal source and the redundant pin is ignored.

Page 45

AD9547

At power-up, the multifunction pins can be used to force the device into certain configurations as defined in the Initial M0 to M7 Pin Programming section. This functionality, however, is valid only during power-up or following a reset, after which the pins can be reconfigured via the serial programming port or via the EEPROM.

IRQ PIN

The AD9547 has a dedicated interrupt request (IRQ) pin. The IRQ pin output mode register (Register 0x0208, Bits[1:0]) controls how the IRQ pin asserts an interrupt based on the value of the two bits, as shown in Tab le 2 6 .

Table 26. IRQ Pin Control—Register 0x0208, Bits[1:0]

Setting Description

The AD9547 asserts the IRQ pin when any of the bits in the IRQ monitor registers (Address 0x0D02 to Address 0x0D09) are Logic 1. Each bit in these registers is associated with an internal function that is capable of producing an interrupt. Furthermore, each bit of the IRQ monitor register is the result of a logical AND of the associated internal interrupt signal and the corresponding bit in the IRQ mask register (Address 0x0209 to Address 0x0210). That is, the bits in the IRQ mask register have a one-to-one correspondence with the bits in the IRQ monitor register. When an internal function produces an interrupt signal and the associated IRQ mask bit is set, the corresponding bit in the IRQ monitor register is set.

The user should be aware that clearing a bit in the IRQ mask register removes only the mask associated with the internal interrupt signal. It does not clear the corresponding bit in the IRQ monitor register.

The IRQ pin is the result of a logical OR of all the IRQ monitor register bits. Thus, the AD9547 asserts the IRQ pin as long as any of the IRQ monitor register bits are Logic 1. Note that it is possible to have multiple bits set in the IRQ monitor register. Therefore, when the AD9547 asserts the IRQ pin, it may indicate an interrupt from several different internal functions. The IRQ monitor register provides the user with a means to interrogate the AD9547 to determine which internal function(s) produced the interrupt.

The IRQ pin is high impedance when deasserted and active low when asserted and requires an external pull-up resistor (this is the default operating mode).

The IRQ pin is high impedance when deasserted and active high when asserted and requires an external pull-down resistor.

The IRQ pin is Logic 0 when deasserted and Logic 1 when asserted.

The IRQ pin is Logic 1 when deasserted and Logic 0 when asserted.

Typically, when the AD9547 asserts the IRQ pin, the user interrogates the IRQ monitor register to identify the source of the interrupt request. After servicing an indicated interrupt, the user should clear the associated IRQ monitor register bit via the IRQ clearing registers (Address 0x0A04 to Address 0x0A0B). The bits in the IRQ clearing register have a one-to-one correspondence with the bits in the IRQ monitor register. Note that the IRQ clearing register is autoclearing. The IRQ pin remains asserted until the user clears all of the bits in the IRQ monitor register that indicate an interrupt.

It is also possible to collectively clear all of the IRQ monitor register bits by setting the reset all IRQs bit in the reset functions register (Register 0x0A03, Bit 1). Note that this is an autoclearing bit. Setting this bit results in deassertion of the IRQ pin. Alternatively, the user can program any of the multifunction pins to clear all IRQs. This allows the user to clear all IRQs by means of a hardware pin rather than by a serial I/O port operation.

WATCHDOG TIMER

The watchdog timer is a general-purpose, programmable timer. To set its timeout period, the user writes to the 16-bit watchdog timer register (Address 0x0211 and Address 0x0212). A value of zero in this register disables the timer. A nonzero value sets the timeout period in units of milliseconds (ms), giving the watchdog timer a range of 1 ms to 65,535 ms. The relative accuracy of the timer is approximately 0.1% with an uncertainty of 0.5 ms.

If enabled, the timer runs continuously and generates a timeout event whenever the timeout period expires. The user has access to the watchdog timer status via the IRQ mechanism and the multifunction pins (M0 to M7). In the case of the multifunction pins, the timeout event of the watchdog timer is a pulse that lasts 32 system clock periods.

There are two ways to reset the watchdog timer (thereby preventing it from causing a timeout event). The first is by writing a Logic 1 to the autoclearing reset watchdog bit in the reset functions register (Register 0x0A03, Bit 0). Alternatively, the user can program any of the multifunction pins to reset the watchdog timer. This allows the user to reset the timer by means of a hardware pin rather than by a serial I/O port operation.

Rev. B | Page 45 of 104

Page 46

AD9547

EEPROM

EEPROM Overview

The AD9547 contains an integrated 2048-byte electrically erasable programmable read-only memory (EEPROM). The AD9547 can be configured to perform a download at power-up via the multifunction pins (M3 to M7), but uploads and downloads can also be done on demand via the EEPROM control registers (Address 0x0E00 to Address 0x0E03).

The EEPROM provides the ability to upload and download configuration settings to and from the register map. Figure 47 shows a functional diagram of the EEPROM.

Register 0x0E10 to Register 0x0E3F represent a 48-byte scratch pad that enables the user to store a sequence of instructions for transferring data to the EEPROM from the device settings portion of the register map. Note that the default values for these registers provide a sample sequence for saving/retrieving all of the AD9547 EEPROM-accessible registers. Figure 47 shows the connectivity between the EEPROM and the controller that manages data transfer between the EEPROM and the register map.

The controller oversees the process of transferring EEPROM data to and from the register map. There are two modes of operation handled by the controller: saving data to the EEPROM (upload mode) or retrieving data from the EEPROM (download mode). In either case, the controller relies on a specific instruction set.

M7 M6 M5 M4 M3

DEVICE SETTINGS ADDRESS

POINTER

DEVICE SETTINGS

(0x0100 TO 0x0A10)

EEPROM

CONTROLLER

DATA

Figure 47. EEPROM Functional Diagram

DATA

SCRATCH PAD

(0x0E10 TO 0x0E3F)

CONDITION

(0x0E01 [4:0])

EEPROM Instructions

Tabl e 27 lists the EEPROM controller instruction set. The controller recognizes all instruction types, whether it is in upload or download mode, except for the pause instruction, which it recognizes only in upload mode.

The I/O update, calibrate, distribution sync, and end instructions are mostly self-explanatory. The others, however, warrant further detail, as described in the following paragraphs.

Data instructions are those that have a value from 0x00 to 0x7F. A data instruction tells the controller to transfer data between the EEPROM and the register map. The controller needs the following two parameters to carry out the data transfer:

The number of bytes to transfer

•

The register map target address

DATA

EEPROM ADDRESS POINTER

SCRATCH PAD

ADDRESS

POINTER

EEPROM

(0x000 TO 0x7F F)

SERIAL

INPUT/OUTPUT

PORT

Rev. B | Page 46 of 104

08300-024

The controller decodes the number of bytes to transfer directly from the data instruction itself by adding one to the value of the instruction. For example, the data instruction, 0x1A, has a decimal value of 26; therefore, the controller knows to transfer 27 bytes (one more than the value of the instruction). Whenever the controller encounters a data instruction, it knows to read the next two bytes in the scratch pad because these bytes contain the register map target address.

Note that, in the EEPROM scratch pad, the two registers that make up the address portion of a data instruction have the MSB of the address in the D7 position of the lower register address. The bit weight increases left to right, from the lower register address to the higher register address. Furthermore, the starting address always indicates the lowest numbered register map address in the range of bytes to transfer. That is, the controller always starts at the register map target address and counts upward, regardless of whether the serial I/O port is operating in I

C, SPI LSB first, or

SPI MSB first mode.

As part of the data transfer process during an EEPROM upload, the controller calculates a 1-byte checksum and stores it as the final byte of the data transfer. As part of the data transfer process during an EEPROM download, however, the controller again calculates a 1-byte checksum value but compares the newly calculated checksum with the one that was stored during the upload process. If an upload/download checksum pair does not match, the controller sets the EEPROM fault status bit (Register 0x0D03, Bit 1). If the upload/download checksums match for all data instructions encountered during a download sequence, the controller sets the EEPROM complete status bit (Register 0x0D03, Bit 0).

Condition instructions are those that have a value from 0xB0 to 0xCF. Condition Instruction 0xB1 to Condition Instruction 0xCF represent Condition 1 to Condition 31, respectively. Condition Instruction 0xB0 is special because it represents the null condition (see the EEPROM Conditional Processing section).

A pause instruction, like an end instruction, is stored at the end of a sequence of instructions in the scratch pad. When the controller encounters a pause instruction during an upload sequence, it keeps the EEPROM address pointer at its last value. This way, the user can store a new instruction sequence in the scratch pad and upload the new sequence to the EEPROM. The new sequence is stored in the EEPROM address locations immediately following the previously saved sequence. This process is repeatable until an upload sequence contains an end instruction. The pause instruction is also useful when used in conjunction with condition processing. It allows the EEPROM to contain multiple occurrences of the same register(s), with each occurrence linked to a set of conditions (see the EEPROM Conditional Processing section).

Page 47

AD9547

Table 27. EEPROM Controller Instruction Set

Instruction Value (Hex) Instruction Type

0x00 to 0x7F Data 3

0x80 I/O update 1

0xA0 Calibrate 1

0xA1 Distribution sync 1

0xB0 to 0xCF Condition 1

0xFE Pause 1

0xFF End 1

EEPROM Upload

To upload data to the EEPROM, the user must first ensure that the write enable bit (Register 0x0E00, Bit 0) is set. Then, on setting the autoclearing save to EEPROM bit (Register 0x0E02, Bit 0), the controller initiates the EEPROM data storage process.

Uploading EEPROM data requires that the user first write an instruction sequence into the scratch pad registers. During the upload process, the controller reads the scratch pad data byte by byte, starting at Register 0x0E10 and incrementing the scratch pad address pointer as it goes, until it reaches a pause or end instruction.

As the controller reads the scratch pad data, it transfers the data from the scratch pad to the EEPROM (byte by byte) and increments the EEPROM address pointer accordingly, unless it encounters a data instruction. A data instruction tells the controller to transfer data from the device settings portion of the register map to the EEPROM. The number of bytes to transfer is encoded within the data instruction, and the starting address for the transfer appears in the next two bytes in the scratch pad.

When the controller encounters a data instruction, it stores the instruction in the EEPROM, increments the EEPROM address pointer, decodes the number of bytes to be transferred, and increments the scratch pad address pointer. Then it retrieves the next two bytes from the scratch pad (the target address) and increments the scratch pad address pointer by 2. Next, the controller transfers the specified number of bytes from the register map (beginning at the target address) to the EEPROM.

Bytes Required Description

A data instruction tells the controller to transfer data to or from the device settings part of the register map. A data instruction requires two additional bytes that, together, indicate a starting address in the register map. Encoded in the data instruction is the number of bytes to transfer, which is one more than the instruction value.

When the controller encounters this instruction while downloading from the EEPROM, it issues a soft I/O update (see Register 0x0005 in Table 42).

When the controller encounters this instruction while downloading from the EEPROM, it initiates a system clock calibration sequence (see Register 0x0A02 in Table 120).

When the controller encounters this instruction while downloading from the EEPROM, it issues a sync pulse to the output distribution synchronization (see Register 0x0A02 in Table 120).

0xB1 to 0xCF are condition instructions and correspond to Condition 1 to Condition 31, respectively. 0xB0 is the null condition instruction. See the EEPROM Conditional Processing section for details.

When the controller encounters this instruction in the scratch pad while uploading to the EEPROM, it resets the scratch pad address pointer and holds the EEPROM address pointer at its last value. This allows storage of more than one instruction sequence in the EEPROM. Note that the controller does not copy this instruction to the EEPROM during upload.

When the controller encounters this instruction in the scratch pad while uploading to the EEPROM, it resets both the scratch pad address pointer and the EEPROM address pointer and then enters an idle state.

When the controller encounters this instruction while downloading from the EEPROM, it resets the EEPROM address pointer and then enters an idle state.

When it completes the data transfer, the controller stores an extra byte in the EEPROM to serve as a checksum for the transferred block of data. To account for the checksum byte, the controller increments the EEPROM address pointer by one more than the number of bytes transferred. Note that, when the controller transfers data associated with an active register, it actually transfers the buffered contents of the register (see the Buffered/Active Registers section for details on the difference between buffered and active registers). This allows for the transfer of nonzero autoclearing register contents.

Note that conditional processing does not occur during an upload sequence (see the EEPROM Conditional Processing section).

EEPROM Download

An EEPROM download results in a transfer of data from the EEPROM to the device register map. To download data, the user sets the autoclearing load from EEPROM bit (Register 0x0E03, Bit 1). This commands the controller to initiate the EEPROM download process. During download, the controller reads the EEPROM data byte by byte, incrementing the EEPROM address pointer as it goes, until it reaches an end instruction. As the controller reads the EEPROM data, it executes the stored instructions, which includes transferring stored data to the device settings portion of the register map whenever it encounters a data instruction.

Note that conditional processing is applicable only when downloading (see the EEPROM Conditional Processing section).

Rev. B | Page 47 of 104

Page 48

AD9547

Automatic EEPROM Download

Following power-up, assertion of the RESET pin, or a soft reset (Register 0x0000, Bit 5 = 1), if FncInit[7:3] ≠ 0 (see the Initial M0 to M7 Pin Programming section), the instruction sequence stored in the EEPROM executes automatically with condition = FncInit[7:3]. In this way, a previously stored set of register values downloads automatically on power-up or with a hard or soft reset. See the EEPROM Conditional Processing section for details regarding conditional processing and the way that it modifies the down-load process.

EEPROM Conditional Processing

The condition instructions allow conditional execution of EEPROM instructions during a download sequence. During an upload sequence, however, they are stored as is and have no effect on the upload process.

Note that, during EEPROM downloads, the condition instructions themselves and the end instruction always execute unconditionally.

Conditional processing makes use of two elements: the condition (from Condition 1 to Condition 31) and the condition tag board. The relationships among the condition, the condition tag board, and the EEPROM controller appear schematically in Figure 48.

Condition is a 5-bit value with 32 possibilities. Condition = 0 is the null condition. When the null condition is in effect, the EEPROM controller executes all instructions unconditionally. The remaining 31 possibilities, condition = 1 through condition = 31, modify the EEPROM controller’s handling of a download sequence.

The condition originates from one of two sources (see Figure 48), as follows:

•

FncInit, Bits[7:3], which is the state of multifunction pins

M3 to M7 at power-up (see the Initial M0 to M7 Pin Programming section)

•

If Register 0x0E01, Bits[4:0] ≠ 0, then the condition is the value stored in Register 0x0E01, Bits[4:0]; otherwise, the condition is FncInit, Bits[7:3]. Note that a nonzero condition that is present in Register 0x0E01, Bits[4:0] takes precedence over FncInit, Bits[7:3].

The condition tag board is a table that is maintained by the EEPROM controller. When the controller encounters a condition instruction, it decodes Condition Instruction 0xB1 through Condition Instruction 0xCF as condition = 1 through condition = 31, respectively, and tags that particular condition in the condition tag board. However, Condition Instruction 0xB0 decodes as the null condition, for which the controller clears the condition tag board; subsequent download instructions execute unconditionally (until the controller encounters a new condition instruction).

During download, the EEPROM controller executes or skips instructions, depending on the value of the condition and the contents of the condition tag board. Note, however, that condition instructions and the end instruction always execute unconditionally during download. If condition = 0, all instructions during download execute unconditionally. If condition ≠ 0 and there are any tagged conditions in the condition tag board, the controller executes instructions only if the condition is tagged.

EEPROM

STORE CONDITIO N

INSTRUCTIONS AS

THEY ARE READ FRO M

THE SCRATCH PAD.

SCRATCH

PAD

EXAMPLE

CONDITIO N 3 AND

CONDITION 13

ARE TAGGED

IF B1 ≤ INSTRUCTION ≤ CF,

THEN TAG DECO DE D CONDITIO N

WATCH FOR

OCCURRENCE OF

CONDITION

INSTRUCTIONS

DURING

DOWNLOAD.

UPLOAD

PROCEDURE

EEPROM CONT ROLLER

DOWNLOAD

PROCEDURE

Figure 48. EEPROM Conditional Processing

CONDITION

TAG BOARD

1 65432

111098

25 26 27 28 29

IF INST RUCTION = B0,

THEN CLEAR ALL TAGS

CONDITION

HANDLER

Rev. B | Page 48 of 104

INSTRUCTION(S)

EXECUTE/SKIP

15141312

0x0E01, BITS [4:0]

2322212019181716

30 3124

IF {NO TAGS} OR {CONDITION = 0} EXECUTE INSTRUCTIONS ELSE IF {CONDITIO N IS TAGGED} EXECUTE INS TRUCTIONS ELSE SKIP INSTRUCTIONS ENDIF ENDIF

5 5

IF {0x0E01, BITS[4:0] ≠ 0} CONDITION = 0x0E01, BIT S [ 4:0] ELSE CONDITION = FncInit, BI TS[7:3] ENDIF

M7 M3

FncInit, BITS[7:3]

CONDITION

Page 49

AD9547

If the condition is not tagged, the controller skips instructions until it encounters a condition instruction that decodes as a tagged condition. Note that the condition tag board allows for multiple conditions to be tagged at any given moment. This conditional processing mechanism enables the user to have one download instruction sequence with many possible outcomes, depending on the value of the condition and the order in which the controller encounters the condition instructions.

Tabl e 28 lists a sample EEPROM download instruction sequence. It illustrates the use of condition instructions and how they alter the download sequence. The table begins with the assumption that no conditions are in effect. That is, the most recently executed condition instruction is 0xB0, or no conditional instructions have been processed.

Table 28. EEPROM Conditional Processing Example

Instruction Action

0x08 0x01 0x00 0xB1 Tag Condition 1 0x19 0x04 0x00 0xB2 Tag Condition 2 0xB3 Tag Condition 3 0x07 0x05 0x00 0x0A

0xB0 Clear the condition tag board 0x80

0x0A

Transfer the system clock register contents regardless of the current condition

Transfer the clock distribution register contents only if condition = 1

Transfer the reference input register contents only if condition = 1, 2, or 3

Calibrate the system clock only if condition = 1, 2, or 3

Execute an I/O update, regardless of the value of the condition

Calibrate the system clock, regardless of the value of the condition

Storing Multiple Device Setups in EEPROM

Conditional processing makes it possible to create a number of different device setups, store them in EEPROM, and download a specific setup on demand. To do so, first program the device control registers for a specific setup. Then, store an upload sequence in the EEPROM scratch pad with the following general form:

Condition instruction (0xB1 to 0xCF) to identify the

setup with a specific condition (1 to 31)

Data instructions (to save the register contents) along

with any required calibrate and/or I/O update instructions

Pause instruction (0xFE)

With the upload sequence written to the scratch pad, perform an EEPROM upload (Register 0x0E02, Bit 0).

Now reprogram the device control registers for the next desired setup. Then store a new upload sequence in the EEPROM scratch pad with the following general form:

Condition Instruction 0xB0

The next desired condition instruction (0xB1 to 0xCF, but

2. different from the one used during the previous upload to identify a new setup)

Data instructions (to save the register contents) along with

any required calibrate and/or I/O update instructions

Pause instruction (FE)

With the upload sequence written to the scratch pad, perform an EEPROM upload (Register 0x0E02, Bit 0).

Repeat the process of programming the device control registers for a new setup, storing a new upload sequence in the EEPROM scratch pad (Step 1 through Step 4) and executing an EEPROM upload (Register 0x0E02, Bit 0) until all of the desired setups are uploaded to the EEPROM.

Note that, on the final upload sequence stored in the scratch pad, the pause instruction (FE) must be replaced with an end instruction (FF).

To download a specific setup on demand, first store the condition associated with the desired setup in Register 0x0E01, Bits[4:0]. Then perform an EEPROM download (Register 0x0E03, Bit 1). Alternatively, to download a specific setup at power-up, apply the required logic levels necessary to encode the desired condition on the M3 to M7 multifunction pins. Then power up the device, and an automatic EEPROM download occurs. The condition (as established by the M3 to M7 multifunction pins) guides the download sequence and results in a specific setup.

Keep in mind that the number of setups that can be stored in the EEPROM is limited. The EEPROM can hold a total of 2048 bytes. Each nondata instruction requires one byte of storage. Each data instruction, however, requires N + 4 bytes of storage, where N is the number of transferred register bytes. The other four bytes include the data instruction itself (one byte), the target address (two bytes), and the checksum calculated by the EEPROM controller during the upload sequence (one byte).

Rev. B | Page 49 of 104

Page 50

AD9547

SERIAL CONTROL PORT

POWER-ON RESETSERIAL CONT ROL ARBITER

SCLK/SCL

CS/SDA

SDIO

SDO

EEPROM

SPI

I2C

EEPROM

CONTROLLER

400kHz

Figure 49. Serial Port Functional Diagram

The AD9547 serial control port is a flexible, synchronous serial communications port that provides a convenient interface to many industry-standard microcontrollers and microprocessors. The AD9547 serial control port is compatible with most synchronous transfer formats, including Philips IC, Motorola® SPI, and Intel® SSR protocols. The serial control port allows read/write access to the AD9547 register map.

In SPI mode, single or multiple byte transfers are supported. The SPI port configuration is programmable via Register 0x0000. This register is integrated into the SPI control logic rather than the register map and is distinct from the I

C Register 0x0000.

It is also inaccessible to the EEPROM controller.

A functional diagram of the serial control port, including its relationship to the EEPROM, appears in Figure 49.

Although the AD9547 supports both the SPI and I

C serial port protocols, only one is active following power-up (as determined by the multifunction pins, M0 to M2, during the startup sequence). That is, the only way to change the serial port protocol is to reset the device (or cycle the device power supply). Both protocols use a common set of control pins as shown in Figure 50.

SCLK/SCL

SDIO

SDO

CS/SDA

Figure 50. Serial Control Port

AD9547

SERIAL

CONTROL

PORT

08300-027

13-BIT ADDRESS

SPACE

READ-ONLY

REGION

READ/WRITE

REGION

ANALOG BLOCKS AND

DIGITAL CORE

MULTI-

FUNCTION

PIN CONTROL

LOGIC

M7 M6 M5 M4 M3 M2 M1 M0

8300-026

SPI/I2C PORT SELECTION

Because the AD9547 supports both the SPI and IC protocols, the active serial port protocol depends on the logic state of the three multifunction pins, M0 to M2, at startup. If all three pins are set to Logic 0 at startup, the SPI protocol is active. Otherwise, the IC protocol is active with seven different IC slave address settings that are based on the startup logic pattern on the M0 to M2 pins (see Table 2 9). Note that the four MSBs of the slave address are hardware coded as 1001.

Table 29. Serial Port Mode Selection

M2 M1 M0 Serial Port Mode

0 0 0 SPI 0 0 1 I²C (address = 1001001) 0 1 0 I²C (address = 1001010) 0 1 1 I²C (address = 1001011) 1 0 0 I²C (address = 1001100) 1 0 1 I²C (address = 1001101) 1 1 0 I²C (address = 1001110) 1 1 1 I²C (address = 1001111)

SPI SERIAL PORT OPERATION

Pin Descriptions

The SCLK (serial clock) pin (SCLK/SCL) serves as the serial shift clock. This pin is an input. SCLK synchronizes serial control port read and write operations. The rising edge SCLK registers write data bits, and the falling edge registers read data bits. The SCLK pin supports a maximum clock rate of 40 MHz.

The SDIO (serial data input/output) pin is a dual-purpose pin and acts either as an input only (unidirectional mode) or as both an input and an output (bidirectional mode). The AD9547 default SPI mode is bidirectional.

The SDO I/O mode. It serves as the data output pin for read operations.

The gates read and write operations. This pin is internally connected to a 30 kΩ pull-up resistor. When SDIO pins go into a high impedance state.

(serial data out) pin is useful only in unidirectional

(chip select) pin (

/SDA) is an active low control that

is high, the SDO and

Rev. B | Page 50 of 104

Page 51

AD9547

SPI Mode Operation

The SPI port supports both 3-wire (bidirectional) and 4-wire (unidirectional) hardware configurations and both MSB-first and LSB-first data formats. Both the hardware configuration and data format features are programmable. By default, the AD9547 uses the bidirectional MSB-first mode. The bidirectional mode is the default mode so that the user can still write to the device to switch to unidirectional mode, if it is wired for unidirectional operation.

Assertion (active low) of the operation to the AD9547 SPI port. For data transfers of three bytes or fewer (excluding the instruction word), the device supports the

the allowing time for the system controller to process the next byte. CS

can be deasserted only on byte boundaries, however. This

applies to both the instruction and data portions of the transfer.

Table 30. Byte Transfer Count

W1 W0 Bytes to Transfer

0 0 1 0 1 2 1 0 3 1 1 Streaming mode

During stall high periods, the serial control port state machine enters a wait state until all data is sent. If the system controller decides to abort a transfer midstream, the state machine must be reset either by completing the transfer or by asserting the pin for at least one complete SCLK cycle (but less than eight SCLK cycles). Deasserting the terminates the serial transfer and flushes the buffer.

In streaming mode (see Tab l e 30 ), any number of data bytes can be transferred in a continuous stream. The register address is automatically incremented or decremented. serted at the end of the last byte transferred, thereby ending the stream mode.

stalled high mode (see ). In this mode,

pin can be temporarily deasserted on any byte boundary,

pin initiates a write or read

Tabl e 30

pin on a nonbyte boundary

must be deas-

Communication Cycle—Instruction Plus Data

The SPI protocol consists of a two-part communication cycle. The first part is a 16-bit instruction word that is coincident with the first 16 SCLK rising edges and a payload. The instruction word provides the AD9547 serial control port with information regarding the payload. The instruction word includes the R/ indicates the direction of the payload transfer (that is, a read or write operation). The instruction word also indicates the number of bytes in the payload and the starting register address of the first payload byte.

bit that

Write

If the instruction word indicates a write operation, the payload is written into the serial control port buffer of the AD9547. Data bits are registered on the rising edge of SCLK. The length of the transfer (1, 2, or 3 bytes or streaming mode) depends on the W0 and W1 bits (see Ta bl e 30 ) in the instruction byte. When not streaming, bits to stall the bus (except after the last byte, where it ends the cycle). When the bus is stalled, the serial transfer resumes when CS

is asserted. Deasserting the CS pin on a nonbyte boundary resets the serial control port. Reserved or blank registers are not skipped over automatically during a write sequence. Therefore, the user must know what bit pattern to write to the reserved registers to preserve proper operation of the part. Generally, it does not matter what data is written to blank registers, but it is customary to write 0s.

Most of the serial port registers are buffered. Refer to the Buffered/Active Registers section for details on the difference between buffered and active registers. Therefore, data written into buffered registers does not immediately take effect. An additional operation is needed to transfer buffered serial control port contents to the registers that actually control the device. This is accomplished with an I/O update operation that is performed in one of two ways: by writing a Logic 1 to Register 0x0005, Bit 0 (this bit is self-clearing) or by using an external signal via an appropriately programmed multifunction pin. The user can change as many register bits as desired before executing an I/O update. The I/O update operation transfers the buffer register contents to their active register counterparts.

can be deasserted after each sequence of eight

Read

The AD9547 supports the long instruction mode only. If the instruction word indicates a read operation, the next N × 8 SCLK cycles clock out the data from the address specified in the instruction word. N is the number of data bytes read and depends on the W0 and W1 bits of the instruction word. The readback data is valid on the falling edge of SCLK. Blank registers are not skipped over during readback.

A readback operation takes data from either the serial control port buffer registers or the active registers, as determined by Register 0x0004, Bit 0.

Rev. B | Page 51 of 104

Page 52

AD9547

SPI Instruction Word (16 Bits)

The MSB of the 16-bit instruction word is R/

, which indicates whether the instruction is a read or a write. The next two bits, W1 and W0, indicate the number of bytes in the transfer (see ).

Tabl e 30 The final 13 bits are the register address (A12 to A0), which indicates the starting register address of the read/write operation (see ).

Tabl e 32

SPI MSB/LSB First Transfers

The AD9547 instruction word and payload can be MSB first or LSB first. The default for the AD9547 is MSB first. The LSB-first mode can be set by writing a 1 to Register 0x0000, Bit 6. Immediately after the LSB-first bit is set, subsequent serial control port operations are LSB first.

When MSB-first mode is active, the instruction and data bytes must be written from MSB to LSB. Multibyte data transfers in MSB-first format start with an instruction byte that includes the register address of the most significant payload byte. Subsequent data bytes must follow in order from high address to low address. In MSB-first mode, the serial control port internal address generator decrements for each data byte of the multibyte transfer cycle.

When Register 0x0000, Bit 6 = 1 (LSB first), the instruction and data bytes must be written from LSB to MSB. Multibyte data transfers in LSB-first format start with an instruction byte that includes the register address of the least significant payload byte, followed by multiple data bytes. The serial control port internal byte address generator increments for each byte of the multibyte transfer cycle.

For multibyte MSB-first (default) I/O operations, the serial control port register address decrements from the specified starting address toward Address 0x0000. For multibyte LSB-first I/O operations, the serial control port register address increments from the starting address toward Address 0x1FFF. Unused addresses are not skipped during multibyte I/O operations; therefore, the user should write the default value to a reserved register and 0s to unmapped registers. Note that it is more efficient to issue a new write command than to write the default value to more than two consecutive reserved (or unmapped) registers.

Table 31. Streaming Mode (No Addresses Are Skipped)

Write Mode

Address Direction Stop Sequence

LSB First Increment 0x0000 ... 0x1FFF MSB First Decrement 0x1FFF ... 0x0000

Table 32. Serial Control Port, 16-Bit Instruction Word, MSB First

MSB LSB I15 I14 I13 I12 I11 I10 I9 I8 I7 I6 I5 I4 I3 I2 I1 I0

R/W

W1 W0 A12 A11 A10 A9 A8 A7 A6 A5 A4 A3 A2 A1 A0

DON'T CARE

SCLK

DON'T CARE

SDIO A12W0W1R/W A11 A10 A9 A8 A7 A6 A5 A4 A3 A2 A1 A0 D7 D6 D5 D4 D3 D2 D1 D0 D7 D6 D5 D4 D3 D2 D1 D0

16-BIT INSTRUCTI ON HEADER REGIST E R (N) DATA REGISTE R ( N – 1) DATA

DON'T CARE

08300-029

Figure 51. Serial Control Port Write—MSB First, 16-Bit Instruction, Two Bytes of Data

SCLK

SDIO

SDO

DON'T CARE

A12W0W1R/W A11A10 A9 A8 A7 A6 A5 A4 A3 A2 A1 A0

D7 D6 D5 D4 D3 D2 D1 D0 D7 D6 D5 D4 D3 D2 D1 D0 D7 D6 D5 D4 D3 D2 D1 D0 D7 D6 D5 D4 D3 D2 D1 D0

DON'T CARE

08300-030

Figure 52. Serial Control Port Read—MSB First, 16-Bit Instruction, Four Bytes of Data

HIGH

LOW

CLK

SCLK

SDIO

DON'T CARE

W1W0A12A11A10A9A8A7A6A5D4D3D2D1D0

R/W

Figure 53. Serial Control Port Write—MSB First, 16-Bit Instruction, Timing Measurements

Rev. B | Page 52 of 104

DON'T CARE

08300-031

Page 53

AD9547

SCLK

SDIO

DON'T CARE

SDIO

SDO

Figure 54. Serial Control Port Timing—Read

A0 A1 A2 A3 A4 A5 A6 A7 A8 A9 A10 A11 A12 D1D0R/WW1W0 D2 D3 D4 D5 D6 D7 D0 D1 D2 D3 D4 D5 D6 D7

16-BIT INSTRUCTION HEADER REGI STER (N) DATA REGISTER (N + 1) DATA

Figure 55. Serial Control Port Write—LSB First, 16-Bit Instruction, Two Bytes of Data

DATA BIT N – 1DATA BIT N

08300-032

DON'T CARE

08300-033

SCLK

SDIO

CLK

HIGH

BIT N BIT N + 1

Figure 56. Serial Control Port Timing—Write

Table 33. Serial Control Port Timing

Parameter Description

tDS Setup time between data and the rising edge of SCLK tDH Hold time between data and the rising edge of SCLK t

Period of the clock

CLK

tC t

Minimum period that SCLK should be in a logic high state

HIGH

Minimum period that SCLK should be in a logic low state

LOW

SCLK to valid SDIO and SDO (see Figure 54)

Setup time between the CS Setup time between the SCLK rising edge and CS

falling edge and SCLK rising edge (start of the communication cycle)

LOW

rising edge (end of the communication cycle)

08300-034

Rev. B | Page 53 of 104

Page 54

AD9547

SDA

I²C SERIAL PORT OPERATION

The I2C interface has the advantage of requiring only two control pins and is a de facto standard throughout the I industry. However, its disadvantage is programming speed, which is 400 kbps maximum. The AD9547 IC port design is based on the IC fast mode standard from Philips, so it supports both the 100 kHz standard mode and the 400 kHz fast mode. Fast mode imposes a glitch tolerance requirement on the control signals; that is, the input receivers ignore pulses of less than 50 ns duration.

The AD9547 IC port consists of a serial data line (SDA) and a serial clock line (SCL). In an IC bus system, the AD9547 is connected to the serial bus (data bus SDA and clock bus SCL) as a slave device; that is, no clock is generated by the AD9547. The AD9547 uses direct 16-bit memory addressing instead of traditional 8-bit memory addressing.

The AD9547 allows for up to seven unique slave devices to occupy

the I

C bus. These are accessed via a 7-bit slave address that is transmitted as part of an I ing slave address responds to subsequent I

C packet. Only the device with a match-

C commands. The device slave address is 1001xxx (the last three bits are determined by the M0 to M2 pins). The four MSBs (1001) are hardwired, whereas the three LSBs (xxx, determined by the M0 to M2 pins) are programmable via the power-up state of the multifunction pins (see the Initial M0 to M7 Pin Programming section).

I2C Bus Characteristics

A summary of the various I2C protocols appears in Tab le 3 4 .

Table 34. I2C Bus Abbreviation Definitions

Abbreviation Definition

S Start Sr Repeated start P Stop A Acknowledge A W

No acknowledge Write

R Read

The transfer of data appears graphically in Figure 57. One clo pulse is generated for each data bit transferred. The data on the SDA line must be stable during the

high period of the clock. The high or low state of the data line can change only when the clock signal on the SCL line is low.

SCL

DATA

LINE

BLE;

DATA VALID ALLOWED

Figure 57. Valid Bit Transfer

CHANGE

OF DATASTA

Start/stop functionality appears graphically in Figure 58. The start condition is characterized by a high-to-low transition o the SDA line while SCL is high. The start condition is always generated by the master to initialize data transfer. The stop condition is characterized by a low-to-high transitio

n on the SDA line while SCL is high. The stop condition is always generated by the master to terminate data transfer.

SDA

SCL

START CONDI TION STOP CONDIT ION

Figure 58. Start and Stop Condition

Every byte on the SDA line must be eight bits long. Each byte must be followed by an acknowledge bit. Bytes are sent MSB first.

The acknowledge bit (A) is the ninth bit attached to any 8-bit data byte. An acknowledge bit is always generated by the receiving device (receiver) to inform the transmitter tha byte has been received. It is done by pulling the SDA line low during the ninth clock pulse after each 8-bit data byte.

The no acknowledge bit (

) is the ninth bit attached to any 8-bit data byte. A no acknowledge bit is always generated by the receiving device (receiver) to inform the transmitter that the byte has not been received. It is done by leaving the SDA line high during the ninth clock pulse after each 8-bit data byte.

t the

00-036 083

08300-035

SCL

MSB

ACK FROM

SLAVE RECEIVER

Figure 59. Acknowledge Bit

Rev. B | Page 54 of 104

ACK FROM

SLAVE RECEIVER

3 TO 73 TO 7 89

08300-037

Page 55

AD9547

Data Transfer Process

The master initiates data transfer by asserting a start condition. This indicates that a data stream follows. All IC slave devices connected to the serial bus respond to the start condition.

The master then sends an 8-bit address byte over the SDA line,

consisting of a 7-bit slave address (MSB first) plus an R/

bit. This bit determines the direction of the data transfer, that is, whether data is written to or read from the slave device (0 = write, 1 = read).

The peripheral whose address corresponds to the transmitted address responds by sending an acknowledge bit. All other devices on the bus remain idle while the selected device waits for data to be read from or written to it. If the R/

mitter) writes to the slave device (receiver). If the R/

bit = 0, the master (trans-

bit = 1, the master (receiver) reads from the slave device (transmitter). See the section for the command format. Data Transfer Format

Data is then sent over the serial bus in the format of nine clock pulses, one data byte (eight bits) from either master (write mode) or slave (read mode) followed by an acknowledge bit from the receiving device. The number of bytes that can be transmitted per transfer is unrestricted. In write mode, the first two data

bytes immediately after the slave address byte are the internal memory (control registers) address bytes with the high address byte first. This addressing scheme gives a memory address up to

− 1 = 65,535. The data bytes after these two memory address bytes are register data written into or read from the control registers. In read mode, the data bytes after the slave address byte are register data written into or read from the control registers.

When all data bytes are read or written, stop conditions are established. In write mode, the master (transmitter) asserts a stop condition to end data transfer during the 10

clock pulse following the acknowledge bit for the last data byte from the slave device (receiver). In read mode, the master device (receiver) receives the last data byte from the slave device (transmitter) but does not pull SDA low during the ninth clock pulse. This is known as a no acknowledge bit. When receiving the no acknowledge bit, the slave device knows the data transfer is finished and enters idle mode. The master then takes the data line low during the low period before the 10

clock pulse, and high during the 10th clock pulse

to assert a stop condition.

A start condition can be used in place of a stop condition. Furthermore, a start or stop condition can occur at any time, and partially transferred bytes are discarded.

MSB

ACK FROM

SLAVE RECEIVER

Figure 60. Data Transfer Process (Master Write Mode, 2-Byte Transfer Used for Illustration)

Figure 61. Data Transfer Process (Master Read Mode, 2-Byte Transfer Used for Illustration)

ACK FROM

MASTER RECEIVER

3 TO 73 TO 7 8910

ACK FROM

SLAVE RECEIVE R

NO ACK FROM

MASTER RECEIVER

08300-038

08300-039

SCL

Data Transfer Format

In write byte format, the write byte protocol is used to write a register address to the RAM starting from the specified RAM address.

S Slave

Address

A RAM Address

High Byte

A RAM Address

Low Byte

A RAM

Data 0

A RAM

Data 1

A RAM

Data 2

A P

In send byte format, the send byte protocol is used to set up the register address for subsequent reads.

S Slave Address W A RAM Address High Byte A RAM Address Low Byte A P

In receive byte format, the receive byte protocol is used to read the data bytes from RAM starting from the current address.

S Slave Address R A RAM Data 0 A RAM Data 1 A RAM Data 2

Read byte format combines the format of the send byte and the receive byte formats.

S Slave

Address

A RAM

Address

High Byte

A RAM

Address

Low Byte

A Sr Slave

Address

Rev. B | Page 55 of 104

R A RAM

Data

A RAM

Data

A RAM

Data

Page 56

AD9547

SDA

I²C Serial Port Timing

HD;STA

LOW

SCL

SSr

HD;DAT

SU;DAT

HIGH

SU;STA

HD;STA

Figure 62. I²C Serial Port Timing

Table 35. IC Timing Definitions

Parameter Description

Serial clock

SCL

Bus free time between stop and start conditions

BUF

Repeated hold time start condition

HD;STA

Repeated start condition setup time

SU;STA

Stop condition setup time

SU;STO

Data hold time

HD;DAT

Data setup time

SU;DAT

SCK clock low period

LOW

SCK clock high period

HIGH

tR Minimum/maximum receive SCL and SDA rise time tF Minimum/maximum receive SCL and SDA fall time t

Pulse width of voltage spikes that must be suppressed by the input filter

SU;STO

BUF

08300-040

Rev. B | Page 56 of 104

Page 57

AD9547

I/O PROGRAMMING REGISTERS

The register map spans an address range from 0x0000 through 0x0E3F (0 to 3647, decimal). Each address provides access to one byte (eight bits) of data. Each individual register is identified by its four-digit hexadecimal address (for example, Register 0x0A10). In some cases, a group of addresses collectively define a register (for example, the IRQ mask register consists of Register 0x0209, Register 0x020A, Register 0x020B, Register 0x020C, Register 0x020D, Register 0x020E, Register 0x020F, and Register 0x0210).

In general, when a group of registers defines a control parameter, the LSB of the value resides in the D0 position of the register with the lowest address. The bit weight increases from right to left, from the lowest register address to the highest register address. For example, the default value of the incremental phase lock offset step size register (Address 0x0314 to Address 0x0315) is the 16-bit hexadecimal number, 0x03E8 (not 0xE803). Note that the EEPROM storage sequence registers (Address 0x0E10 to Address 0x0E3F) are an exception to this convention (see the EEPROM Instructions section).

BUFFERED/ACTIVE REGISTERS

There are two broad categories of registers on the AD9547: buffered and active (see Figure 63). Buffered registers are those that can be written to directly from the serial port. They do not need an I/O update to apply their contents to the internal device functions. In contrast, active registers require an I/O update to transfer data between the buffered registers and the internal device functions. In operation, the user programs as many buffered registers as desired and then issues an I/O update. The I/O update is performed by writing to Register 0x0005, Bit 0 = 1 (or by the external application of the neces-sary logic level to one of the multifunction pins previously programmed as an I/O update input). The contents of the buffered registers that are connected directly to the internal device functions affect those functions immediately. The contents of buffered registers that connect to active registers do not affect the internal device functions until the I/O update event occurs.

An S or C in the Opt column of the register map identifies an active register (otherwise, it is a buffered register). An S entry means that the I/O update signal to the active register is synchronized with the serial port clock or with an input signal driving one of the multifunction pins. On the other hand, a C entry means that the I/O update signal to the active register is synchronized with a clock signal derived from the internal system clock (f

When reading back a register that has both buffered and active contents, Register 0x0004, Bit 0 can be used to select whether to read back the buffered or active contents. Readback of the active contents occurs when Register 0x0004, Bit 0 = 0, whereas readback of the buffered contents occurs when Register 0x0004, Bit 0 = 1. Note that a read-only active register requires an I/O update before its contents can be read.

/32), as shown in Figure 63.

CS/SDA

SDIO

SDO

SCLK/SCL

AUTOCLEARING REGISTERS

An A in the Opt column of the register map identifies an autoclearing register. Typically, the active value for an autoclearing register takes effect following an I/O update. The bit is cleared by the internal device logic upon completion of the prescribed action.

REGISTER ACCESS RESTRICTIONS

Read and write access to the registers may be restricted, depending on the register in question, the source and direction of access, and the current state of the device. Each register can be classified into one or more access types. When more than one type applies, the most restrictive condition that applies at that time is used.

When access is denied to a register, all attempts to read the register return a 0 byte, and all attempts to write to the register are ignored. Access to nonexistent registers is handled in the same way as for a denied register.

Regular Access

Registers with regular access do not fall into any other category. Both read and write access to registers of this type can be from the serial port or the EEPROM controller. However, only one of these sources can have access to a register at any given time (access is mutually exclusive). When the EEPROM controller is active, either in load or store mode, it has exclusive access to the registers.

Read-Only Access

An R in the Opt column of the register map identifies read-only registers. Access is available at all times, including when the EEPROM controller is active.

Exclusion from EEPROM Access

An E in the Opt column of the register map identifies a register with contents that are inaccessible to the EEPROM. That is, the contents of this type of register cannot be transferred directly to the EEPROM or vice versa. Note that read-only registers (R) are inaccessible to the EEPROM, as well.

Rev. B | Page 57 of 104

FROM

MULTIFUNCTION

PIN LOGIC

SERIAL

CONTROL

PORT

Figure 63. Buffered and Active Registers

EDGE

DETECT

/32

I/O UPDATE

BUFFERED REGISTERS

ACTIVE C

REGISTERS

ACTIVE S

REGISTERS

TO INT E R NAL DEVICE FUNCTIO NS

08300-041

Page 58

AD9547

REGISTER MAP

The register addresses and defaults are hexadecimal values. Use the default value when writing to registers and/or bits marked as unused.

Table 36.

Addr Opt1 Name D7 D6 D5 D4 D3 D2 D1 D0 Def

Serial Port Configuration and Part Identification 0x0000 E SPI control

0x0000 Dup I2C control Unused Soft reset Unused 0x00 0x0001 E Reserved Unused 0x0002 R

0x0003 R Device ID Device ID 0x48 0x0004 E

0x0005 A, E I/O update Unused I/O update 0x00 System Clock (SYSCLK) 0x0100 S

0x0101 S N divider N divider[7:0] 0x28 0x0102 S

0x0103 C 0x0104 C 0x42 0x0105 C Unused Nominal SYSCLK period[20:16] 0x0F 0x0106 C 0x0107 C 0x00 0x0108 C Unused System clock stability period[19:16] (in ms) 0x00 General Configuration 0x0200 S M0 control M0 in/out M0 function[6:0] 0x00 0x0201 S M1 control M1 in/out M1 function[6:0] 0x00 0x0202 S M2 control M2 in/out M2 function[6:0] 0x00 0x0203 S M3 control M3 in/out M3 function[6:0] 0x00 0x0204 S M4 control M4 in/out M4 function[6:0] 0x00 0x0205 S M5 control M5 in/out M5 function[6:0] 0x00 0x0206 S M6 control M6 in/out M6 function[6:0] 0x00 0x0207 S M7 control M7 in/out M7 function[6:0] 0x00 0x0208 C

0x0209 C IRQ mask Unused

0x020A C Unused

0x020B C Switching Closed Free run Holdover

0x020C C Unused

0x020D C

0x020E C

0x020F C Unused 0x00 0x0210 C Unused 0x00 0x0211 C 0x0212 C 0x00 0x0213 S DAC current DAC full-scale current[7:0] 0xFF 0x0214 S

Silicon revision level

Charge pump/ lock detect control

System clock input options

Nominal system clock period

System clock stability period

IRQ pin output mode

Watchdog timer

Unidirectional

External loop filter enable

Unused

Ref AA new profile

Ref BB new profile

DAC shutdown

LSB first/ IncAddr

Charge pump mode (auto/man)

M divider reset

Ref AA validated

Ref BB validated

Soft reset

SYSCLK unlocked

Ref AA fault cleared

Ref BB fault cleared

Long instruction

Silicon revision number 0xF5

Unused

Charge pump current[2:0]

M divider[1:0]

Nominal SYSCLK period[15:0] (in fs)

(1 ns at 1 ppm accuracy)

SYSCLK stability period[15:0] (in ms) 0x01

Unused IRQ pin output mode[1:0] 0x00

SYSCLK locked

History updated

Ref AA fault

Ref BB fault

Watchdog timer [15:0] (in ms up to 65,535 ms) 0x00

Unused DAC full-scale current[9:8] 0x01

2× frequency multiplier enable

Distribution sync

Frequency unlocked

Frequency unclamped

Ref A new profile

Ref B new profile

Lock detect timer disable

PLL enable SYSCLK source[1:0] 0x45

Unused

Watchdog timer

Frequency locked

Frequency clamped

Ref A validated

Ref B validated

Unused 0x10

Read buffer register

Lock detect timer[1:0] 0x18

SYSCLK cal complete

EEPROM fault

Phase unlocked

Phase slew unlimited

Ref A fault cleared

Ref B fault cleared

SYSCLK cal started

EEPROM complete

Phase locked

Phase slew limited

Ref A fault

Ref B fault

0x00

0x40

0x00

Rev. B | Page 58 of 104

Page 59

AD9547

Addr Opt1 Name D7 D6 D5 D4 D3 D2 D1 D0 Def

DPLL 0x0300 C 0x0301 C 0x00 0x0302 C 0x00 0x0303 C 0x00 0x0304 C 0x00 0x0305 C 0x00 0x0306 A, C Update TW Unused Update TW 0x00 0x0307 C 0x0308 C 0x00 0x0309 C 0x00 0x030A C 0x030B C 0xFF 0x030C C 0xFF 0x030D C 0x030E C 0x00 0x030F C 0x0310 C 0x00 0x0311 C 0x00 0x0312 C 0x00 0x0313 C 0x00 0x0314 C 0x0315 C 0x03

0x0316 C 0x0317 C 0x00 0x0318 C 0x0319 C 0x75 0x031A C 0x00 0x031B C History mode Unused

Clock Distribution Output Configuration 0x0400 S

0x0401 S

0x0402 S

0x0403 C

0x0404 S

0x0405 S Unused

0x0406 S Unused Unused 0x03 0x0407 S 0x03 0x0408 S 0x0409 S 0x00 0x040A S 0x00 0x040B S Unused Q0[29:24] 0x00 0x040C S 0x040D S 0x00 0x040E S 0x00 0x040F S Unused Q1[29:24] 0x00

Free-running frequency tuning word

Pull-in range lower limit

Pull-in range upper limit

Open-loop phase offset

Fixed closedloop phase lock offset

Incremental closed-loop phase lock offset step size

Phase slew rate limit

History accumulation timer

Distribution settings

Distribution enable

Distribution synchronization

Automatic synchronization

Distribution channel modes

Distribution channel divider, Q0

Distribution channel divider, Q1

Unused

Unused Sync source[1:0] Unused

Unused

Free-running frequency tuning word[47:0] 0x00

Pull-in range lower limit[23:0] 0x00

Pull-in range upper limit[23:0] 0xFF

Open-loop phase offset word[15:0] 0x00

Fixed phase lock offset[39:0] (in ps; signed) 0x00

Incremental phase lock offset step size[15:0] (in ps/step) 0xE8

Phase slew rate limit[15:0] (in ns/sec) 0x00

History accumulation timer[23:0] (in ms) 0x30

Incremental average[2:0] 0x00

OUT1 powerdown

OUT1 enable

OUT1 sync mask

OUT0 mode 0x03

OUT1 mode 0x03

OUT0 powerdown

OUT0 enable

OUT0 sync mask

External distribution resistor

OUT0 CMOS phase invert

OUT1 CMOS phase invert

Single sample fallback

Receiver mode

Unused

Unused Automatic sync mode[1:0] 0x00

OUT0 polarity invert

OUT1 polarity invert

Persistent history

Unused

OUT0 drive strength

OUT1 drive strength

Q0[23:0] 0x00

Q1[23:0] 0x00

0x0C

0x00

Rev. B | Page 59 of 104

Page 60

AD9547

Addr Opt1 Name D7 D6 D5 D4 D3 D2 D1 D0 Def

0x0410 S Reserved Unused 0x0411 S 0x0412 S 0x0413 S 0x0414 S 0x0415 S 0x0416 S 0x0417 S Reference Input Configuration 0x0500 S

0x0501 S 0x0502 S Unused 0x00 0x0503 C

0x0504 C

0x0505 C Unused 0x00 0x0506 C Unused 0x00 0x0507 C

Profile Registers—Profile 0 0x0600 Priorities Unused Promoted priority[2:0] Selection priority[2:0] 0x00 0x0601 0x0602 0x00 0x0603 0x00 0x0604 0x00 0x0605 0x00 0x0606 Unused (write 0s to these bits) 0x00 0x0607 0x00 0x0608 Tolerance Inner tolerance[15:0] (1/tolerance) (removes fault status; 10% down to 1 ppm) 0x00 0x0609 0x00 0x060A Unused Inner tolerance[19:16] 0x00 0x060B Outer tolerance[15:0] (1/tolerance) (indicates fault status; 10% down to 1 ppm) 0x00 0x060C 0x00 0x060D Unused Outer tolerance[19:16] 0x00 0x060E 0x060F 0x00 0x0610 0x0611 0x00 0x0612 0x0613 0x00

0x0614 Alpha-2 exponent[1:0] Alpha-1 exponent[5:0] 0x00 0x0615 Beta-0 linear[6:0]

0x0616 Beta-0 linear[14:7] 0x00 0x0617 Unused Beta-1 exponent[4:0] Beta-0 linear[16:15] 0x00 0x0618 Gamma-0 linear[15:0] 0x00 0x0619 0x00 0x061A Unused Gamma-1 exponent[4:0]

0x061B Delta-0 linear[7:0] 0x00 0x061C

0x061D Alpha-3 exponent[3:0] Delta-1 exponent[4:1] 0x00

Reference power-down

Reference logic family

Manual reference profile selection

Phase buildout switching

Reference period

Validation timer

Redetect timer

Digital loop filter coefficients

Ref BB logic family[1:0] Ref B logic family[1:0] Ref AA logic family[1:0] Ref A logic family[1:0] 0x00

Enable Ref AA manual profile

Enable Ref BB manual profile

Delta-1 exponent[0]

Unused

Ref AA manual profile[2:0]

Ref BB manual profile[2:0]

Unused Phase master threshold priority[2:0] 0x00

Nominal reference period[39:0] (in fs up to 1.1 ms) 0x00

Validation timer[15:0] (in ms up to 65,535 ms) 0x00

Redetect timer[15:0] (in ms up to 65,535 ms) 0x00

Alpha-0 linear[15:0] 0x00

Ref BB powerdown

Enable Ref A manual profile

Enable Ref B manual profile

Delta-0 linear[14:8] 0x00

Ref B powerdown

Ref AA powerdown

Ref A manual profile[2:0] 0x00

Ref B manual profile[2:0] 0x00

Ref A powerdown

Gamma-0 linear[16]

Alpha-2

exponent[2]

0xF0

0x00

Rev. B | Page 60 of 104

Page 61

AD9547

Addr Opt1 Name D7 D6 D5 D4 D3 D2 D1 D0 Def

0x061E R divider R[23:0] 0x00 0x061F 0x00 0x0620 0x00 0x0621 Unused R[29:24] 0x00 0x0622 S divider S[15:0] 0x00 0x0623 0x00 0x0624 Unused S[19:16] 0x00 0x0625 Unused 0x00 0x0626 0x0627 U[3:0] Unused V[9:8] 0x00 0x0628 Unused U[9:4] 0x00 0x0629 0x062A 0x00 0x062B Phase lock fill rate[7:0] 0x00 0x062C Phase lock drain rate[7:0] 0x00 0x062D Frequency lock threshold[23:0] (in ps) 0x00 0x062E 0x00 0x062F 0x00 0x0630 Frequency lock fill rate[7:0] 0x00 0x0631 Frequency lock drain rate[7:0] 0x00 Profile Registers—Profile 1 0x0632 Priorities

0x0633 0x0634 0x00 0x0635 0x00 0x0636 0x00 0x0637 0x00 0x0638 Unused (write 0s to these bits) 0x00 0x0639 0x00 0x063A Tolerance Inner tolerance[15:0] (1/tolerance) (removes fault status; 10% down to 1 ppm) 0x00 0x063B 0x00 0x063C Unused Inner tolerance[19:16] 0x00 0x06CD Outer tolerance[15:0] (1/tolerance) (indicates fault status; 10% down to 1 ppm) 0x00 0x063E 0x00 0x063F Unused Outer tolerance[19:16] 0x00 0x0640 0x0641 0x00 0x0642 0x0643 0x00 0x0644 0x0645 0x00 0x0646 Alpha-2 exponent[1:0] Alpha-1 exponent[5:0] 0x00 0x0647 Beta-0 linear[6:0]

0x0648 Beta-0 linear[14:7] 0x00 0x0649 Unused Beta-1 exponent[4:0] Beta-0 linear[16:15] 0x00 0x064A Gamma-0 linear[15:0] 0x00 0x064B 0x00 0x064C Unused Gamma-1 exponent[4:0]

0x064D Delta-0 linear[7:0] 0x00 0x064E

0x064F Alpha-3 exponent[3:0] Delta-1 exponent[4:1] 0x00

Fractional feedback divider

Lock detectors

Reference period

Validation timer

Redetect timer

Digital loop filter coefficients

Phase lock

scale

Delta-1 exponent[0]

Phase lock threshold[15:0] (in ps) 0x00

Unused Promoted priority[2:0] Selection priority[2:0] 0x00

Nominal reference period[39:0] (in units of fs up to 1.1 ms) 0x00

Validation timer[15:0] (in units of ms up to 65.5 sec) 0x00

Redetect timer[15:0] (in units of ms up to 65.5 sec) 0x00

V[7:0] 0x00

Alpha-0 linear[15:0] 0x00

Alpha-2 exponent[2]

Gamma-0 linear[16]

Delta-0 linear[14:8] 0x00

0x00

Rev. B | Page 61 of 104

Page 62

AD9547

Addr Opt1 Name D7 D6 D5 D4 D3 D2 D1 D0 Def

0x0650 R divider R[23:0] 0x00 0x0651 0x00 0x0652 0x00 0x0653 Unused R[29:24] 0x00 0x0654 S divider S[15:0] 0x00 0x0655 0x00 0x0656 Unused S[19:16] 0x00 0x0657 Unused 0x00 0x0658 0x0659 U[3:0] Unused V[9:8] 0x00 0x065A Unused U[9:4] 0x00 0x065B 0x065C 0x00 0x065D Phase lock fill rate[7:0] 0x00 0x065E Phase lock drain rate[7:0] 0x00 0x065F Frequency lock threshold[23:0] (in ps) 0x00 0x0660 0x00 0x0661 0x00 0x0662 Frequency lock fill rate[7:0] 0x00 0x0663 Frequency lock drain rate[7:0] 0x00 0x0664

to 0x067F

Profile Registers—Profile 2 0x0680 Priorities

0x0681 0x0682 0x00 0x0683 0x00 0x0684 0x00 0x0685 0x00 0x0686 Unused (write 0s to these bits) 0x00 0x0687 0x00 0x0688 Tolerance Inner tolerance[15:0] (1/tolerance) (removes fault status; 10% down to 1 ppm) 0x00 0x0689 0x00 0x068A Unused Inner tolerance[19:16] 0x00 0x068B Outer tolerance[15:0] (1/tolerance) (indicates fault status; 10% down to 1 ppm) 0x00 0x068C 0x00 0x068D Unused Outer tolerance [19:16] 0x00 0x068E 0x068F 0x00 0x0690 0x0691 0x00 0x0692 0x0693 0x00 0x0694 Alpha-2 exponent[1:0] Alpha-1 exponent[5:0] 0x00 0x0695 Beta-0 linear[6:0]

0x0696 Beta-0 linear[14:7] 0x00 0x0697 Unused Beta-1 exponent[4:0] Beta-0 linear[16:15] 0x00 0x0698 Gamma-0 linear[15:0] 0x00 0x0699 0x00 0x069A Unused Gamma-1 exponent[4:0]

0x069B Delta-0 linear[7:0] 0x00 0x069C

0x069D Alpha-3 exponent[3:0] Delta-1 exponent[4:1] 0x00

Fractional feedback divider

Lock detectors

Unused Unused

Phase lock

scale

Reference period

Validation timer

Redetect timer

Digital loop filter coefficients

Delta-1 exponent[0]

Unused Promoted priority[2:0] Selection priority[2:0] 0x00

Phase lock threshold[15:0] (in units of ps) 0x00

Nominal period[39:0] (in units of fs up to 1.1 ms) 0x00

Validation timer[15:0] (ms) (up to 65,535 ms) 0x00

Redetect timer[15:0] (ms) (up to 65,535 ms) 0x00

V[7:0] 0x00

Alpha-0 linear[15:0] 0x00

Alpha-2 exponent[2]

Gamma-0 linear[16]

Delta-0 linear[14:8] 0x00

0x00

Rev. B | Page 62 of 104

Page 63

AD9547

Addr Opt1 Name D7 D6 D5 D4 D3 D2 D1 D0 Def

0x069E R divider R[23:0] 0x00 0x069F 0x00 0x06A0 0x00 0x06A1 Unused R[29:24] 0x00 0x06A2 S divider S[15:0] 0x00 0x06A3 0x00 0x06A4 Unused S[19:16] 0x00 0x06A5 Unused 0x00 0x06A6 0x06A7 U[3:0] Unused V[9:8] 0x00 0x06A8 Unused U[9:4] 0x00 0x06A9 0x06AA 0x00 0x06AB Phase lock fill rate[7:0] 0x00 0x06AC Phase lock drain rate[7:0] 0x00 0x06AD Frequency lock threshold[23:0] (in ps) 0x00 0x06AE 0x00 0x06AF 0x00 0x06B0 Frequency lock fill rate[7:0] 0x00 0x06B1 Frequency lock drain rate[7:0] 0x00 Profile Registers—Profile 3 0x06B2 Priorities

0x06B3 0x06B4 0x00 0x06B5 0x00 0x06B6 0x00 0x06B7 0x00 0x06B8 Unused (write 0s to these bits) 0x00 0x06B9 0x00 0x06BA Tolerance Inner tolerance[15:0] (1/tolerance) (removes fault status; 10% down to 1 ppm) 0x00 0x06BB 0x00 0x06BC Unused Inner tolerance[19:16] 0x00 0x06BD Outer tolerance[15:0] (1/tolerance) (indicates fault status; 10% down to 1 ppm) 0x00 0x06BE 0x00 0x06BF Unused Outer tolerance[19:16] 0x00 0x06C0 0x06C1 0x00 0x06C2 0x06C3 0x00 0x06C4 0x06C5 0x00 0x06C6 Alpha-2 exponent[1:0] Alpha-1 exponent[5:0] 0x00 0x06C7 Beta-0 linear[6:0]

0x06C8 Beta-0 linear[14:7] 0x00 0x06C9 Unused Beta-1 exponent[4:0] Beta-0 linear [16:15] 0x00 0x06CA Gamma-0 linear[15:0] 0x00 0x06CB 0x00 0x06CC Unused Gamma-1 exponent[4:0]

0x06CD Delta-0 linear[7:0] 0x00 0x06CE

0x06CF Alpha-3 exponent[3:0] Delta-1 exponent[4:1] 0x00 0x06D0 R divider R[23:0] 0x00 0x06D1 0x00 0x06D2 0x00 0x06D3 Unused R[29:24] 0x00

Fractional feedback divider

Lock detectors

Reference period

Validation timer

Redetect timer

Digital loop filter coefficients

Phase lock

scale

Delta-1 exponent[0]

Phase lock threshold[15:0] (in ps) 0x00

Unused Promoted priority[2:0] Selection priority[2:0] 0x00

Nominal period[39:0] (in fs up to 1.1 ms) 0x00

Validation timer[15:0] (in ms up to 65,535 ms) 0x00

Redetect timer[15:0] (in ms up to 65,535 ms) 0x00

V[7:0] 0x00

Alpha-0 linear[15:0] 0x00

Alpha-2 exponent[2]

Gamma-0 linear[16]

Delta-0 linear[14:8] 0x00

0x00

Rev. B | Page 63 of 104

Page 64

AD9547

Addr Opt1 Name D7 D6 D5 D4 D3 D2 D1 D0 Def

0x06D4 S divider S[15:0] 0x00 0x06D5 0x00 0x06D6 Unused S[19:16] 0x00 0x06D7 Unused 0x00 0x06D8 0x06D9 U[3:0] Unused V[9:8] 0x00 0x06DA Unused U[9:4] 0x00 0x06DB 0x06DC 0x00 0x06D

D 0x06DE Phase lock drain rate[7:0] 0x00 0x06DF Frequency lock threshold[23:0] (in ps) 0x00 0x06E0 0x00 0x06E1 0x00 0x06E2 Frequency lock fill rate[7:0] 0x00 0x06E3 Frequency lock drain rate[7:0] 0x00 0x06E4

to 0x06FF

Profile Registers—Profile 4 through Profile 7 0x0700

to 0x07FF

Operational Controls 0x0A00 S

0x0A01 C Loop mode Unused

0x0A02 S Cal/sync Unused

0x0A03 A, C

0x0A04 A, C IRQ clearing Unused

0x0A05 A, C Unused

0x0A06 A, C Switching Closed Free run Holdover

0x0A07 A, C Unused

0x0A08 A, C

0x0A09 A, C

0x0A0A A, C Unused 0x00 0x0A0B A, C Unused 0x00 0x0A0C A, C

0x0A0D A, C

0x0A0E A, C

0x0A0F C

0x0A10 C

Fractional feedback divider

Lock detectors

Phase lock fill rate[7:0] 0x00

Unused

Profile 4 through Profile 7

General power-down

Reset functions

Incremental phase offset

Reference profile selection state machine startup

Force validation timeout

Reference monitor override

Reference monitor bypass

The functionality of the Profile 4 through Profile 7 address locations (Address 0x0700 to Address 0x07FF) is identical to that of the Profile 0 through Profile 3 address locations (Address 0x0600 to Address 0x06FF)

Reset sans regmap

Unused Clear LF Clear CCI

Ref AA new profile

Ref BB new profile

Unused

User holdover

Ref AA validated

Ref BB validated

SYSCLK powerdown

User free run

SYSCLK unlocked

Ref AA fault cleared

Ref BB fault cleared

Unused

Unused Detect BB Detect B Detect AA Detect A 0x00

Unused

Phase lock threshold[15:0] (in ps) 0x00

Reference powerdown

User selection mode[1:0]

Clear phase accumulator

SYSCLK locked

History updated

Ref AA fault

Ref BB fault

V[7:0] 0x00

TDC powerdown

Reset auto sync

Unused

Distribution sync

Frequency unlocked

Frequency unclamped

Ref A new profile

Ref B new profile

Force Timeout BB

Ref Mon Override BB

Ref Mon Bypass BB

DAC powerdown

Unused

(write a 0

to this bit)

Reset TW history

Watchdog timer

Frequency locked

Frequency clamped

Ref A validated

Ref B validated

Reset phase offset

Force Timeout B

Ref Mon Override B

Ref Mon Bypass B

Dist powerdown

User reference

selection[1:0]

Sync distribution

Reset all IRQs

SYSCLK cal complete

EEPROM fault

Phase unlocked

Phase slew unlimited

Ref A fault cleared

Ref B fault cleared

Decrement phase offset

Force Timeout AA

Ref Mon Override AA

Ref Mon Bypass AA

Full powerdown

Calibrate SYSCLK

Reset watchdog

SYSCLK cal started

EEPROM complete

Phase locked

Phase slew limited

Ref A fault

Ref B fault

Increment phase offset

Force Timeout A

Ref Mon Override A

Ref Mon Bypass A

0x00

Rev. B | Page 64 of 104

Page 65

AD9547

Addr Opt1 Name D7 D6 D5 D4 D3 D2 D1 D0 Def

Status Readback (These registers are read only and are accessible during EEPROM transactions.) 0x0D00 R EEPROM Unused

0x0D01 R SYSCLK Unused Stable Unused

0x0D02 R IRQ monitor Unused

0x0D03 R Unused

0x0D04 R Switching Closed Free run Holdover

0x0D05 R Unused

0x0D06 R

0x0D07 R

0x0D08 R Unused 0x0D09 R 0x0D0A R, C DPLL status

0x0D0B R, C

0x0D0C R, C

0x0D0 D

0x0D0E R, C

0x0D0F R, C

0x0D10 R, C Unused Unused 0x0D11 R, C 0x0D12 R, C 0x0D13 R, C 0x0D14 R, C 0x0D15 R, C 0x0D16 R, C 0x0D17 R, C 0x0D18 R, C 0x0D19 R, C Nonvolatile Memory (EEPROM) Control 0x0E00 Write protect Unused

0x0E01 E Condition Unused Condition value[4:0] 0x00 0x0E02 A, E Save Unused

0x0E03 A, E Load Unused

EEPROM Storage Sequence 0x0E10 E 0x0E11 E Address: 0x0100 0x01 0x0E12 E 0x00 0x0E13 E I/O update Action: I/O update 0x80 0x0E14 E

0x0E15 E 0x0E16 E Address: 0x0200 0x02 0x0E17 E 0x00 0x0E18 E DPLL settings Data: 28 bytes 0x1B

R, C

Ref A input reference status

Ref AA input reference status

Ref B input reference status

Ref BB input reference status

Holdover history

SYSCLK settings

SYSCLK calibration

General configuration settings

Ref AA new profile

Ref BB new profile

Offset slew limiting

Frequency clamped

Profile selected

Ref AA validated

Ref BB validated

Phase build-out

History available

SYSCLK unlocked

Ref AA fault cleared

Ref BB fault cleared

Frequency lock

Selected profile[2:0] Valid Fault Fast Slow

SYSCLK locked

Distribution sync

Frequency unlocked

History updated

Ref AA fault

Ref BB fault

Phase lock

Active reference priority[2:0] Unused Active reference[1:0]

Tuning word history[47:0]

Action: calibrate system clock 0xA0

Frequency unclamped

Ref A new profile

Ref B new profile

Loop switching

Data: 9 bytes 0x08

Data: 21 bytes 0x14

Fault detected

Unused

Watchdog timer

Frequency locked

Frequency clamped

Ref A validated

Ref B validated

Holdover Active

Load in progress

Cal in progress

SYSCLK cal complete

EEPROM fault

Phase unlocked

Phase slew unlimited

Ref A fault cleared

Ref B fault cleared

Half rate mode

Load from EEPROM

Save in progress

Lock detected

SYSCLK cal started

EEPROM complete

Phase locked

Phase slew limited

Ref A fault

Ref B fault

Free running

Write enable

Save to EEPROM

Unused 0x00

0x00

Rev. B | Page 65 of 104

Page 66

AD9547

Addr Opt1 Name D7 D6 D5 D4 D3 D2 D1 D0 Def

0x0E19 E Address: 0x0300 0x03 0x0E1A E 0x00 0x0E1B E 0x0E1C E Address: 0x0400 0x04 0x0E1D E 0x00 0x0E1E E I/O update Action: I/O update 0x80 0x0E1F E 0x0E20 E Address: 0x0500 0x05 0x0E21 E 0x00 0x0E22 E 0x0E23 E Address: 0x0600 0x06 0x0E24 E 0x00 0x0E25 E 0x0E26 E Address: 0x0680 0x06 0x0E27 E 0x80 0x0E28 E 0x0E29 E Address: 0x0700 0x07 0x0E2A E 0x00 0x0E2B E 0x0E2C E Address: 0x0780 0x07 0x0E2D E 0x80 0x0E2E E I/O update Action: I/O update 0x80 0x0E2F E 0x0E30 E Address: 0x0A00 0x0A 0x0E31 E 0x00 0x0E32 E I/O update Action: I/O update 0x80 0x0E33 E End of data Action: end of data 0xFF 0x0E34

to 0x0E3F

See the I/O Programming Registers section for an explanation of the Opt column.

Clock distribution settings

Reference input settings

Profile 0 and Profile 1 settings

Profile2 and Profile 3 settings

Profile 4 and Profile 5 settings

Profile 6 and Profile 7 settings

Operational control settings

E Continuation of scratch pad area

Data: 26 bytes 0x19

Data: 8 bytes 0x07

Data: 100 bytes 0x63

Data: 17 bytes 0x10

Rev. B | Page 66 of 104

Page 67

AD9547

REGISTER BIT DESCRIPTIONS

SERIAL PORT CONFIGURATION AND PART IDENTIFICATION (REGISTER 0x0000 TO REGISTER 0x0005)

Table 37. SPI Control/I2C Control

Address Bit Bit Name Description

0x0000 7 Unidirectional Select SPI port SDO pin operating mode.

0 (default) = 3-wire. 1 = 4-wire (SDO pin enabled).

6 LSB first/IncAddr Bit order for SPI port.

0 (default) = most significant bit and byte first (multibyte transfers use incrementing address). 1 = least significant bit and byte first (multibyte transfers use decrementing address).

5 Soft reset Device reset (invokes an EEPROM download if M[7:3] ≠ 0).

0 (default) = normal operation. 1 = reset.

4 Long instruction

[3:0] Unused Unused.

Table 38. Reserved Register

Address Bit Bit Name Description

0x0001 [7:0] Unused Unused.

16-bit mode (the only mode supported by the device). This bit is read only and reads back as Logic 1.

Table 39. Silicon Revision Level (Read Only)

Address Bit Bit Name Description

0x0002 [7:0] Silicon revision number Default = 0xF5 = 0b11110101.

Table 40. Device ID (Read Only)

Address Bit Bit Name Description

0x0003 [7:0] Device ID Default = 0x48 = 0b01001000.

Table 41. Register Readback Control

Address Bit Bit Name Description

0x0004 [7:1] Unused Unused.

0 Read buffered register

For buffered registers, serial port readback reads from actual (active) registers instead of from the buffer.

0 (default) = reads values currently applied to the device’s internal logic. 1 = reads buffered values that take effect on the next assertion of the I/O update.

Table 42. Soft I/O Update

Address Bit Bit Name Description

0x0005 [7:1] Unused Unused.

0 I/O update

Writing a 1 to this bit transfers the data in the serial I/O buffer registers to the device’s internal control registers. This is an autoclearing bit.

Rev. B | Page 67 of 104

Page 68

AD9547

SYSTEM CLOCK (SYSCLK) (REGISTER 0x0100 TO REGISTER 0x0108)

Table 43. Charge Pump and Lock Detect Control

Address Bit Bit Name Description

0x0100 7 External loop filter enable Enables use of an external SYSCLK PLL loop filter.

0 (default) = internal loop filter. 1 = external loop filter.

6 Charge pump mode Charge pump current control.

0 (default) = automatic. 1 = manual.

[5:3] Charge pump current Selects charge pump current when Bit 6 = 1.

000 = 125 A. 001 = 250 A. 010 = 375 A. 011 (default) = 500 A. 100 = 625 A. 101 = 750 A. 110 = 875 A. 111 = 1000 A.

2 Lock detect timer disable Enable the SYSCLK PLL lock detect timer.

0 (default) = enable. 1 = disable.

[1:0] Lock detect timer Select lock detect timer depth.

00 (default) = 128. 01 = 256. 10 = 512. 11 = 1024.

Table 44. N Divider

Address Bit Bit Name Description

0x0101 [7:0] N divider System clock PLL feedback divider value: 6 ≤ N ≤ 255 (default = 0x28 = 40).

Table 45. System Clock Input Options

Address Bit Bit Name Description

0x0102 7 Unused Unused.

6 M divider reset Reset the M divider.

0 = normal operation. 1 (default) = reset. When not using the M divider, program this bit to Logic 1.

[5:4] M divider System clock input divider.

00 (default) = 1. 01 = 2. 10 = 4. 11 = 8.

2 PLL enable Enable the SYSCLK PLL.

[1:0] SYSCLK source Input mode select for SYSCLKx pins.

2× frequency multiplier enable

Enable the 2× frequency multiplier. 0 (default) = disable. 1 = enable.

0 = disable. 1 (default) = enable.

00 = crystal resonator. 01 (default) = low frequency clock source. 10 = high frequency (direct) clock source. 11 = input receiver power-down.

Rev. B | Page 68 of 104

Page 69

AD9547

Table 46. Nominal System Clock (SYSCLK) Period1

Address Bit Bit Name Description

0x0103 [7:0] Nominal SYSCLK period 0x0104 [7:0] System clock period, Bits[15:8].

(expressed in fs)

0x0105 [7:5] Unused Unused.

[4:0] Nominal SYSCLK period System clock period, Bits[20:16].

Units are femtoseconds (fs). The default value is 0x0F424 = 1,000,000 (1 ns) and implies a system clock frequency of 1 GHz.

Table 47. System Clock Stability Period1

Address Bit Bit Name Description

0x0106 [7:0] 0x0107 [7:0] System clock stability period, Bits[15:8] (default = 0x00).

SYSCLK stability period (expressed in ms)

0x0108 [7:4] Unused Unused.

[3:0] SYSCLK stability period System clock stability period, Bits[19:16] (default = 0x0)

Units are milliseconds (ms). The default value is 0x00001 = 1 (1 ms).

GENERAL CONFIGURATION (REGISTER 0x0200 TO REGISTER 0x0214)

Register 0x0200 to Register 0x0207—Multifunction Pin Control (M0 to M7)

Table 48. Multifunction Pin (M0 to M7) Control1

Address Bit Bit Name Description

0x0200 7 M0 in/out In/out control for the M0 pin.

[6:0] M0 function See Table 24 and Table 25 (default = 0xb0000000).

0x0201 7 M1 in/out In/out control for the M1 pin (same as M0).

[6:0] M1 function See Table 24 and Table 25 (default = 0xb0000000).

0x0202 7 M2 in/out In/out control for the M2 pin (same as M0).

[6:0] M2 function See Table 24 and Table 25 (default = 0xb0000000).

0x0203 7 M3 in/out In/out control for the M3 pin (same as M0).

[6:0] M3 function See Table 24 and Table 25 (default = 0xb0000000).

0x0204 7 M4 in/out In/out control for the M4 pin (same as M0).

[6:0] M4 function See Table 24 and Table 25 (default = 0xb0000000).

0x0205 7 M5 in/out In/out control for the M5 pin (same as M0).

[6:0] M5 function See Table 24 and Table 25 (default = 0xb0000000).

0x0206 7 M6 in/out In/out control for the M6 pin (same as M0).

[6:0] M6 function See Table 24 and Table 25 (default = 0xb0000000).

0x0207 7 M7 in/out In/out control for the M7 pin (same as M0).

[6:0] M7 function See Table 24 and Table 25 (default = 0xb0000000).

The default setting for all the multifunction pins is as an unused control input pin.

System clock period, Bits[7:0].

System clock stability period, Bits[7:0] (default = 0x01).

(default period = 0x00001, or 1 ms).

0 (default) = input (control pin). 1 = output (status pin).

Table 49. IRQ Pin Output Mode

Address Bit Bit Name Description

0x0208 [7:2] Unused Unused.

[1:0] IRQ pin output mode Select the output mode of the IRQ pin.

00 (default) = NMOS, open drain (requires an external pull-up resistor). 01 = PMOS, open drain (requires an external pull-down resistor). 10 = CMOS, active high. 11 = CMOS, active low.

Rev. B | Page 69 of 104

Page 70

AD9547

Register 0x0209 to Register 0x0210—IRQ Mask

The IRQ mask register bits form a one-to-one correspondence with the bits of the IRQ monitor register (Address 0x0D02 to Address 0x0D09). When set to Logic 1, the IRQ mask bits enable the corresponding IRQ monitor bits to indicate an IRQ event. The default for all IRQ mask bits is Logic 0, which prevents the IRQ monitor from detecting any internal interrupts.

Table 50. IRQ Mask for SYSCLK

Address Bit Bit Name Description

0x0209 [7:6] Unused Unused.

5 SYSCLK unlocked Enables IRQ for indicating a SYSCLK PLL state transition from locked to unlocked. 4 SYSCLK locked Enables IRQ for indicating a SYSCLK PLL state transition from unlocked to locked. [3:2] Unused Unused. 1 SYSCLK cal complete Enables IRQ for indicating that SYSCLK calibration is complete. 0 SYSCLK cal started Enables IRQ for indicating that SYSCLK calibration has begun.

Table 51. IRQ Mask for Distribution Sync, Watchdog Timer, and EEPROM

Address Bit Bit Name Description

0x020A [7:4] Unused Unused.

3 Distribution sync Enables IRQ for indicating a distribution sync event. 2 Watchdog timer Enables IRQ for indicating expiration of the watchdog timer. 1 EEPROM fault Enables IRQ for indicating a fault during an EEPROM load or save operation. 0 EEPROM complete Enables IRQ for indicating successful completion of an EEPROM load or save operation.

Table 52. IRQ Mask for the Digital PLL

Address Bit Bit Name Description

0x020B 7 Switching Enables IRQ for indicating that the DPLL is switching to a new reference.

6 Closed Enables IRQ for indicating that the DPLL has entered closed-loop operation. 5 Free run Enables IRQ for indicating that the DPLL has entered free-run mode. 4 Holdover Enables IRQ for indicating that the DPLL has entered holdover mode. 3 Frequency unlocked Enables IRQ for indicating that the DPLL lost frequency lock. 2 Frequency locked Enables IRQ for indicating that the DPLL has acquired frequency lock. 1 Phase unlocked Enables IRQ for indicating that the DPLL lost phase lock. 0 Phase locked Enables IRQ for indicating that the DPLL has acquired phase lock.

Table 53. IRQ Mask for History Update, Frequency Limit, and Phase Slew Limit

Address Bit Bit Name Description

0x020C [7:5] Unused Unused.

4 History updated Enables IRQ for indicating the occurrence of a tuning word history update. 3 Frequency unclamped

2 Frequency clamped

1 Phase slew unlimited

0 Phase slew limited

Enables IRQ for indicating a state transition of the frequency limiter from clamped to unclamped.

Enables IRQ for indicating a state transition of the frequency limiter from unclamped to clamped.

Enables IRQ for indicating a state transition of the phase slew limiter from slew limiting to not slew limiting.

Enables IRQ for indicating a state transition of the phase slew limiter from not slew limiting to slew limiting.

Rev. B | Page 70 of 104

Page 71

AD9547

Table 54. IRQ Mask for Reference Inputs

Address Bit Bit Name Description

0x020D 7 Ref AA new profile Enables IRQ for indicating that Ref AA has switched to a new profile.

6 Ref AA validated Enables IRQ for indicating that Ref AA has been validated. 5 Ref AA fault cleared Enables IRQ for indicating that Ref AA has been cleared of a previous fault. 4 Ref AA fault Enables IRQ for indicating that Ref AA has been faulted. 3 Ref A new profile Enables IRQ for indicating that Ref A has switched to a new profile. 2 Ref A validated Enables IRQ for indicating that Ref A has been validated. 1 Ref A fault cleared Enables IRQ for indicating that Ref A has been cleared of a previous fault. 0 Ref A fault Enables IRQ for indicating that Ref A has been faulted.

0x020E 7 Ref BB new profile Enables IRQ for indicating that Ref BB has switched to a new profile.

6 Ref BB validated Enables IRQ for indicating that Ref BB has been validated. 5 Ref BB fault cleared Enables IRQ for indicating that Ref BB has been cleared of a previous fault. 4 Ref BB fault Enables IRQ for indicating that Ref BB has been faulted. 3 Ref B new profile Enables IRQ for indicating that Ref B has switched to a new profile. 2 Ref B validated Enables IRQ for indicating that Ref B has been validated. 1 Ref B fault cleared Enables IRQ for indicating that Ref B has been cleared of a previous fault.

0 Ref B fault Enables IRQ for indicating that Ref B has been faulted. 0x020F [7:0] Unused Unused. 0x0210 [7:0] Unused Unused.

Table 55. Watchdog Timer1

Address Bit Bit Name Description

0x0211 [7:0] 0x0212 [7:0] Watchdog timer, Bits[15:8] (default = 0x00).

The watchdog timer is expressed in units of milliseconds (ms). The default value is 0 (disabled).

Watchdog timer (expressed in ms)

Watchdog timer, Bits[7:0] (default = 0x00).

Table 56. DAC Current1

Address Bit Bit Name Description

0x0213 [7:0] DAC full-scale current Full-scale current, Bits[7:0] (default = 0xFF). 0x0214 7 DAC shutdown Shut down the DAC current sources.

0 (default) = normal operation.

1 = shut down. [6:2] Unused Unused. [1:0] DAC full-scale current Full-scale current, Bits[9:8] (default = 0b01).

(default current = 0x1FF, or 20.1 mA).

The default DAC full-scale current value is 0x01FF = 511, which equates to 20.1375 mA.

Rev. B | Page 71 of 104

Page 72

AD9547

DPLL CONFIGURATION (REGISTER 0x0300 TO REGISTER 0x031B)

Table 57. Free-Running Frequency Tuning Word1

Address Bit Bit Name Description

0x0300 [7:0] Free-running frequency tuning word 0x0301 [7:0] Free-running frequency tuning word, Bits[15:8]. 0x0302 [7:0] Free-running frequency tuning word, Bits[23:16].

(expressed as a 48-bit frequency tuning word)

0x0303 [7:0] Free-running frequency tuning word, Bits[31:24]. 0x0304 [7:0] Free-running frequency tuning word, Bits[39:32]. 0x0305 [7:0] Free-running frequency tuning word, Bits[47:40].

The default free-running tuning word is 0x000000 = 0, which equates to 0 Hz.

Table 58. Update TW

Address Bit Bit Name Description

0x0306 [7:1] Unused Unused.

0 Update TW

Table 59. Pull-in Range Lower and Upper Limit1

Address Bit Bit Name Description

0x0307 [7:0] 0x0308 [7:0] Lower limit pull-in range, Bits[15:8].

Pull-in range lower limit (expressed as a 24-bit frequency tuning word)

0x0309 [7:0] Lower limit pull-in range, Bits[23:16]. 0x030A [7:0] 0x030B [7:0] Upper limit pull-in range, Bits[15:8].

Pull-in range upper limit (expressed as a 24-bit frequency tuning word)

0x030C [7:0] Upper limit pull-in range, Bits[23:16].

The default pull-in range lower limit is 0 and the upper range limit is 0xFFFFFF, which effectively spans the full output frequency range of the DDS.

Free-running frequency tuning word, Bits[7:0].

A Logic 1 written to this bit transfers the free-running frequency tuning word (Register 0x0300 to Register 0x0305) to the register embedded in the tuning word processing logic. Note that it is not necessary to write the update TW bit when the device is in free-run mode. This is an autoclearing bit.

Lower limit pull-in range, Bits[7:0].

Upper limit pull-in range, Bits[7:0].

Table 60. Open-Loop Phase Offset1

Address Bit Bit Name Description

0x030D [7:0] 0x030E [7:0] DDS phase offset, Bits[15:8].

The default DDS phase offset is 0.

Open-loop phase offset (expressed in units of π/2

radians)

DDS phase offset, Bits[7:0].

Table 61. Fixed Closed-Loop Phase Lock Offset1

Address Bit Bit Name Description

0x030F [7:0] 0x0310 [7:0] Fixed phase lock offset, Bits[15:8].

Fixed phase lock offset (expressed in ps)

Fixed phase lock offset, Bits[7:0].

0x0311 [7:0] Fixed phase lock offset, Bits[23:16]. 0x0312 [7:0] Fixed phase lock offset, Bits[31:24]. 0x0313 [7:0] Fixed phase lock offset, Bits[39:32].

The default fixed closed loop phase lock offset is 0.

Rev. B | Page 72 of 104

Page 73

AD9547

Table 62. Incremental Closed-Loop Phase Lock Offset Step Size1

Address Bit Bit Name Description

0x0314 [7:0] 0x0315 [7:0] Incremental phase lock offset step size, Bits[15:8].

The default incremental closed loop phase lock offset step size value is 0x03E8 = 1000 (1 ns).

Incremental phase lock offset step size (expressed in ps/step)

Table 63. Phase Slew Rate Limit1

Address Bit Bit Name Description

0x0316 [7:0] Phase slew rate limit 0x0317 [7:0] Phase slew rate limit, Bits[15:8].

The default phase slew rate limit is 0 (or disabled).

(expressed in ns/sec)

Table 64. History Accumulation Timer1

Address Bit Bit Name Description

0x0318 [7:0] 0x0319 [7:0] History accumulation timer, Bits[15:8].

History accumulation timer (expressed in ms)

0x031A [7:0] History accumulation timer, Bits[23:16].

Do not program a timer value of 0. The history accumulation timer default value is 0x007530 = 30,000 (30 sec).

Table 65. History Mode

Address Bit Bit Name Description

0x031B [7:5] Unused Unused.

4 Single sample fallback

3 Persistent history Controls the holdover history initialization. When switching to a new reference

[2:0] Incremental average History mode value from 0 to 7 (default = 0).

Incremental phase lock offset step size, Bits[7:0].

Phase slew rate limit, Bits[7:0].

History accumulation timer, Bits[7:0].

Controls the holdover history. If tuning word history is not available for the reference that was active just prior to holdover, then

0 (default) = use the free-running frequency tuning word register value. 1 = use the last tuning word from the DPLL.

0 (default) = clear the tuning word history. 1 = retain the previous tuning word history.

Rev. B | Page 73 of 104

Page 74

AD9547

CLOCK DISTRIBUTION OUTPUT CONFIGURATION (REGISTER 0x0400 TO REGISTER 0x0417)

Table 66. Distribution Settings1

Address Bit Bit Name Description

0x0400 [7:6] Unused Unused.

5 External distribution resistor Output current control for the clock distribution outputs.

0 (default) = internal current setting resistor. 1 = external current setting resistor.

4 Receiver mode Clock distribution receiver mode.

0 (default) = normal operation.

1 = high frequency mode (super-Nyquist). [3:2] Unused Write a 1 to these bits. 1 OUT1 power-down Power down clock distribution output OUT1.

0 (default) = normal operation.

1 = power down. 0 OUT0 power-down Power down clock distribution output OUT0.

0 (default) = normal operation.

1 = power-down.

When Bits [1:0] = 11, the clock distribution output enters a deep sleep mode.

Table 67. Distribution Enable

Address Bit Bit Name Description

0x0401 [7:2] Unused Unused.

1 OUT1 enable Enable the OUT1 driver.

0 (default) = disable.

1 = enable. 0 OUT0 enable Enable the OUT0 driver.

0 (default) = disable.

1 = enable.

Table 68. Distribution Synchronization

Address Bit Bit Name Description

0x0402 [7:6] Unused Unused.

[5:4] Sync source Select the sync source for the clock distribution output channels.

00 (default) = direct.

01 = active reference.

10 = DPLL feedback edge.

11 = reserved. [3:2] Unused Unused. 1 OUT1 sync mask Mask the synchronous reset to the OUT1 divider.

0 (default) = unmasked.

1 = masked. 0 OUT0 sync mask Mask the synchronous reset to the OUT0 divider.

0 (default) = unmasked.

1 = masked.

Table 69. Automatic Synchronization

Address Bit Bit Name Description

0x0403 [7:2] Unused Unused.

[1:0] Automatic sync mode Autosync mode.

00 (default) = disabled.

01 = sync on DPLL frequency lock.

10 = sync on DPLL phase lock.

11 = reserved.

Rev. B | Page 74 of 104

Page 75

AD9547

Table 70. Distribution Channel Modes

Address Bit Bit Name Description

0x0404 [7:6] Unused Unused.

5 OUT0 CMOS phase invert

4 OUT0 polarity invert Invert the polarity of OUT0.

3 OUT0 drive strength OUT0 output drive capability control.

[2:0] OUT0 mode OUT0 operating mode select.

0x0405 [7:6] Unused Unused.

5 OUT1 CMOS phase invert

4 OUT1 polarity invert Invert the polarity of OUT1.

3 OUT1 drive strength OUT1 output drive capability control.

[2:0] OUT1 mode OUT1 operating mode select.

0x0406 [7:0] Unused Unused. 0x0407 [7:0]

When the output mode is CMOS, the bit inverts the relative phase between the two CMOS output pins. Otherwise, this bit is nonfunctional. 0 (default) = not inverted. 1 = inverted.

0 (default) = not inverted. 1 = inverted.

0 (default) = CMOS: low drive strength; LVDS: 3.5 mA nominal. 1 = CMOS: normal drive strength; LVDS: 7 mA nominal.

000 = CMOS (both pins). 001 = CMOS (positive pin), tristate (negative pin). 010 = tristate (positive pin), CMOS (negative pin). 011 (default) = tristate (both pins). 100 = LVDS. 101 = LVPECL. 110 = reserved. 111 = reserved.

When the output mode is CMOS, the bit inverts the relative phase between the two CMOS output pins. Otherwise, this bit is nonfunctional.

0 (default) = not inverted. 1 = inverted.

0 (default) = CMOS: low drive strength; LVDS: 3.5 mA nominal. 1 = CMOS: normal drive strength; LVDS: 7 mA nominal.

Rev. B | Page 75 of 104

Page 76

AD9547

Register 0x0408 to Register 0x0417—Distribution Channel Dividers

Table 71. Q0 Divider1

Address Bit Bit Name Description

0x0408 [7:0] Q0 Q0 divider, Bits[7:0]. 0x0409 [7:0] Q0 divider, Bits[15:8]. 0x040A [7:0] Q0 divider, Bits[23:16]. 0x040B [7:6] Unused Unused.

[5:0] Q0 Q0 divider, Bits[29:24].

The default value is 0 (or divide by 1).

Table 72. Q1 Divider1

Address Bit Bit Name Description

0x040C [7:0] Q1 Q1 divider, Bits[7:0]. 0x040D [7:0] Q1 divider, Bits[15:8]. 0x040E [7:0] Q1 divider, Bits[23:16]. 0x040F [7:6] Unused Unused.

[5:0] Q1 Q1 divider, Bits[29:24].

The default value is 0 (or divide by 1).

Table 73. Reserved

Address Bit Bit Name Description

0x0410 to 0x0417

[7:0] Unused Unused.

REFERENCE INPUT CONFIGURATION (REGISTER 0x0500 TO REGISTER 0x0507)

When all bits are set, the reference receiver section enters a deep sleep mode.

Table 74. Reference Power-Down

Address Bit Bit Name Description

0x0500 [7:4] Unused Write a 1 to these bits.

3 Ref BB power-down REF BB input receiver power-down.

0 (default) = normal operation. 1 = power-down.

2 Ref B power-down REF B input receiver power-down.

0 (default) = normal operation. 1 = power-down.

1 Ref AA power-down REF AA input receiver power-down.

0 (default) = normal operation. 1 = power-down.

0 Ref A power-down REF A input receiver power-down.

0 (default) = normal operation. 1 = power-down.

Rev. B | Page 76 of 104

Page 77

AD9547

Table 75. Reference Logic Family

Address Bit Bit Name Description

0x0501 [7:6] Ref BB logic family Select the logic family for the REF BB input receiver (ignored if Bits[5:4] = 00).

00 (default) = disabled. 01 = 1.2 V to 1.5 V CMOS. 10 = 1.8 V to 2.5 V CMOS. 11 = 3.0 V to 3.3 V CMOS.

[5:4] Ref B logic family Select logic family for REF B input receiver.

00 (default) = differential (REFB/BB is positive/negative input). 01 = 1.2 V to 1.5 V CMOS. 10 = 1.8 V to 2.5 V CMOS.

11 = 3.0 V to 3.3 V CMOS. [3:2] Ref AA logic family The same as Register 0x0501, Bits[7:6] but for REF AA. [1:0] Ref A logic family The same as Register 0x0501, Bits[5:4] but for REF A.

0x0502 [7:0] Unused Unused.

Table 76. Manual Reference Profile Selection

Address Bit Bit Name Description

0x0503 7 Enable Ref AA manual profile Select manual or automatic reference profile assignment for REF AA.

0 (default) = automatic. 1 = manual.

[6:4] Ref AA manual profile Manual profile assignment.

000 (default) = Profile 0. 001 = Profile 1. 010 = Profile 2. 011 = Profile 3. 100 = Profile 4. 101 = Profile 5. 110 = Profile 6.

111 = Profile 7. 3 Enable Ref A manual profile Same as Register 0x0503, Bit 7 but for REF A. [2:0] Ref A manual profile Same as Register 0x0503, Bits[6:4] but for REF A.

0x0504 7 Enable Ref BB manual profile Same as Register 0x0503, Bit 7 but for REF BB.

[6:4] Ref BB manual profile Same as Register 0x0503, Bits[6:4] but for REF BB. 3 Enable Ref B manual profile Same as Register 0x0503, Bit 7 but for REF B. [2:0] Ref B manual profile Same as Register 0x0503, Bits[6:4] but for REF B.

0x0505 [7:0] Unused Unused. 0x0506 [7:0]

Table 77. Phase Build-Out Switching

Address Bit Bit Name Description

0x0507 [7:3] Unused Unused.

[2:0]

Phase master threshold priority

Threshold priority level (a value of 0 to 7, with 0 (default) being the highest priority level). References with a selection priority value lower than this value are treated as phase masters (see the profile registers for selection priority value).

Rev. B | Page 77 of 104

Page 78

AD9547

PROFILE REGISTERS (REGISTER 0x0600 TO REGISTER 0x07FF)

Note that the default value of every bit is 0 for Profile 0 to Profile 7.

Register 0x0600 to Register 0x0631—Profile 0

Table 78. Priorities—Profile 0

Address Bit Bit Name Description

0x0600 [7] Phase lock scale Controls the phase lock threshold unit scaling.

0 = picoseconds. 1 = nanoseconds. [6] Unused Unused. [5:3] Promoted priority

[2:0] Selection priority

Table 79. Reference Period—Profile 0

Address Bit Bit Name Description

0x0601 [7:0] 0x0602 [7:0] Nominal reference period, Bits[15:8]. 0x0603 [7:0] Nominal reference period, Bits[23:16]. 0x0604 [7:0] Nominal reference period, Bits[31:24]. 0x0605 [7:0] Nominal reference period, Bits[39:32]. 0x0606 [7:0] Unused. Unused. Write 0s to these bits. 0x0607 [7:0]

Reference period (expressed in units of fs)

User-assigned priority level (0 to 7) of the reference associated with Profile 0 while that reference is the active reference. The numeric value of the promoted priority must be less than or equal to the numeric value of the selection priority.

User-assigned priority level (0 to 7) of the reference associated with Profile 0, which ranks that reference relative to the others.

Nominal reference period, Bits[7:0].

Table 80. Tolerance—Profile 0

Address Bit Bit Name Description

0x0608 [7:0] Inner tolerance Inner tolerance, Bits[7:0]. 0x0609 [7:0] Inner tolerance, Bits[15:8]. 0x060A [7:4] Unused Unused.

[3:0] Inner tolerance Inner tolerance, Bits[19:16]. 0x060B [7:0] Outer tolerance Outer tolerance, Bits[7:0]. 0x060C [7:0] Outer tolerance, Bits[15:8].

0x060D

[7:4] Unused Unused.

[3:0] Outer tolerance Outer tolerance, Bits[19:16].

Table 81. Validation Timer—Profile 0

Address Bit Bit Name Description

0x060E [7:0] Validation timer 0x060F [7:0] Validation timer, Bits[15:8].

(expressed in units of ms)

Validation timer, Bits[7:0].

Table 82. Redetect Timer—Profile 0

Address Bit Bit Name Description

0x0610 [7:0] Redetect timer 0x0611 [7:0] Redetect timer, Bits[15:8].

(expressed in units of ms)

Redetect timer, Bits[7:0].

Rev. B | Page 78 of 104

Page 79

AD9547

Table 83. Digital Loop Filter Coefficients—Profile 01

Address Bit Bit Name Description

0x0612 [7:0] Alpha-0 linear Alpha-0 coefficient linear, Bits[7:0]. 0x0613 [7:0] Alpha-0 coefficient linear, Bits[15:8]. 0x0614 [7:6] Alpha-2 exponent Alpha-2 coefficient exponent, Bits[1:0].

[5:0] Alpha-1 exponent Alpha-1 coefficient exponent, Bits[5:0].

0x0615 [7:1] Beta-0 linear Beta-0 coefficient linear, Bits[6:0].

0 Alpha-2 exponent Alpha-2 coefficient exponent, Bit 2. 0x0616 [7:0] Beta-0 linear Beta-0 coefficient linear, Bits[14:7]. 0x0617 7 Unused Unused.

[6:2] Beta-1 exponent Beta-1 coefficient exponent, Bits[4:0].

[1:0] Beta-0 linear Beta-0 coefficient linear, Bits[16:15]. 0x0618 [7:0] Gamma-0 linear Gamma-0 coefficient linear, Bits[7:0]. 0x0619 [7:0] Gamma-0 coefficient linear, Bits[15:8]. 0x061A [7:6] Unused Unused.

[5:1] Gamma-1 exponent Gamma-1 coefficient exponent, Bits[4:0].

0 Gamma-0 linear Gamma-0 coefficient linear, Bit 16. 0x061B [7:0] Delta-0 linear Delta-0 coefficient linear, Bits[7:0]. 0x061C 7 Delta-1 exponent Delta-1 coefficient exponent, Bit 0.

[6:0] Delta-0 linear Delta-0 coefficient linear, Bits[14:8]. 0x061D [7:4] Alpha-3 exponent Alpha-3 coefficient exponent, Bits[3:0].

[3:0] Delta-1 exponent Delta-1 coefficient exponent, Bits[4:1].

The digital loop filter coefficients (α, β, γ, and δ) have the general form: x(2y), where x is the linear component and y is the exponential component of the coefficient.

The value of the linear component (x) constitutes a fraction, where 0 ≤ x < 1. The exponential component (y) is an integer. See the Calculating the Digital Filter Coefficients section for details.

Register 0x061E to Register 0x0628—Profile 0 Frequency Multiplication

Table 84. R Divider—Profile 01

Address Bit Bit Name Description

0x061E [7:0] R R, Bits[7:0]. 0x061F [7:0] R, Bits[15:8]. 0x0620 [7:0] R, Bits[23:16]. 0x0621 [7:6] Unused Unused.

[5:0] R R, Bits[29:24].

The value stored in the R divider register yields an actual divide ratio of one more than the programmed value.

Table 85. S Divider—Profile 01

Address Bit Bit Name Description

0x0622 [7:0] S S, Bits[7:0]. 0x0623 [7:0] S S, Bits[15:8]. 0x0624 [7:4] Unused Unused.

[3:0] S S, Bits[19:16]. 0x0625 [7:0] Unused Unused.

The value stored in the S divider register yields an actual divide ratio of one more than the programmed value. Furthermore, the value of S must be at least 7.

Rev. B | Page 79 of 104

Page 80

AD9547

Table 86. Fractional Feedback Divider—Profile 0

Address Bit Bit Name Description

0x0626 [7:0] V V, Bits[7:0]. 0x0627 [7:4] U U, Bits[3:0].

[3:2] Unused Unused. [1:0] V V, Bits[9:8].

0x0628 [7:6] Unused Unused.

[5:0] U U, Bits[9:4].

Table 87. Lock Detectors—Profile 0

Address Bit Bit Name Description

0x0629 [7:0] Phase lock threshold (units determined by Register 0x0600[7]) Phase lock threshold, Bits[7:0]. 0x062A [7:0] Phase lock threshold, Bits[15:8]. 0x062B [7:0] Phase lock fill rate Phase lock fill rate, Bits[7:0]. 0x062C [7:0] Phase lock drain rate Phase lock drain rate, Bits[7:0]. 0x062D [7:0] Frequency lock threshold (expressed in units of ps) Frequency lock threshold, Bits[7:0]. 0x062E [7:0] Frequency lock threshold, Bits[15:8]. 0x062F [7:0] Frequency lock threshold, Bits[23:16]. 0x0630 [7:0] Frequency lock fill rate Frequency lock fill rate, Bits[7:0]. 0x0631 [7:0] Frequency lock drain rate Frequency lock drain rate, Bits[7:0].

Register 0x0632 to Register 0x067F—Profile 1

Table 88. Priorities—Profile 1

Address Bit Bit Name Description

0x0632 [7] Phase lock scale Controls the phase lock threshold unit scaling.

0 = picoseconds. 1 = nanoseconds. [6] Unused Unused. [5:3] Promoted priority

[2:0] Selection priority

User-assigned priority level (0 to 7) of the reference associated with Profile 1 while that reference is the active reference. The numeric value of the promoted priority must be less than or equal to the numeric value of the selection priority.

User-assigned priority level (0 to 7) of the reference associated with Profile 1, which ranks that reference relative to the others.

Table 89. Reference Period—Profile 1

Address Bit Bit Name Description

0x0633 [7:0] Reference period (expressed in units of fs) Nominal reference period, Bits[7:0]. 0x0634 [7:0] Nominal reference period, Bits[15:8]. 0x0635 [7:0] Nominal reference period, Bits[23:16]. 0x0636 [7:0] Nominal reference period, Bits[31:24]. 0x0637 [7:0] Nominal reference period, Bits[39:32]. 0x0638 [7:0] Unused Unused. Write 0s to these bits. 0x0639 [7:0]

Table 90. Tolerance—Profile 1

Address Bit Bit Name Description

0x063A [7:0] Inner tolerance Inner tolerance, Bits[7:0]. 0x063B [7:0] Inner tolerance, Bits[15:8]. 0x063C [7:4] Unused Unused.

[3:0] Inner tolerance Inner tolerance, Bits[19:16]. 0x063D [7:0] Outer tolerance Outer tolerance, Bits[7:0]. 0x063E [7:0] Outer tolerance, Bits[15:8].

Rev. B | Page 80 of 104

Page 81

AD9547

Address Bit Bit Name Description

0x063F [7:4] Unused Unused.

[3:0] Outer tolerance Outer tolerance, Bits[19:16].

Table 91. Validation Timer—Profile 1

Address Bit Bit Name Description

0x0640 [7:0] Validation timer 0x0641 [7:0] Validation timer, Bits[15:8].

(expressed in units of ms)

Table 92. Redetect Timer—Profile 1

Address Bit Bit Name Description

0x0642 [7:0] Redetect timer 0x0643 [7:0] Redetect timer, Bits[15:8].

(expressed in units of ms)

Table 93. Digital Loop Filter Coefficients—Profile 11

Address Bit Bit Name Description

0x0644 [7:0] Alpha-0 linear Alpha-0 coefficient linear, Bits[7:0]. 0x0645 [7:0] Alpha-0 coefficient linear, Bits[15:8]. 0x0646 [7:6] Alpha-2 exponent Alpha-2 coefficient exponent, Bits[1:0].

[5:0] Alpha-1 exponent Alpha-1 coefficient exponent, Bits[5:0].

0x0647 [7:1] Beta-0 linear Beta-0 coefficient linear, Bits[6:0].

0 Alpha-2 exponent Alpha-2 coefficient exponent, Bit 2. 0x0648 [7:0] Beta-0 linear Beta-0 coefficient linear, Bits[14:7]. 0x0649 7 Unused Unused.

[6:2] Beta-1 exponent Beta-1 coefficient exponent, Bits[4:0].

[1:0] Beta-0 linear Beta-0 coefficient linear, Bits[16:15]. 0x064A [7:0] Gamma-0 linear Gamma-0 coefficient linear, Bits[7:0]. 0x064B [7:0] Gamma-0 coefficient linear, Bits[15:8]. 0x064C [7:6] Unused Unused.

[5:1] Gamma-1 exponent Gamma-1 coefficient exponent, Bits[4:0].

0 Gamma-0 linear Gamma-0 coefficient linear, Bit 16. 0x064D [7:0] Delta-0 linear Delta-0 coefficient linear, Bits[7:0]. 0x064E 7 Delta-1 exponent Delta-1 coefficient exponent, Bit 0.

[6:0] Delta-0 linear Delta-0 coefficient linear, Bits[14:8]. 0x064F [7:4] Alpha-3 exponent Alpha-3 coefficient exponent, Bits[3:0].

[3:0] Delta-1 exponent Delta-1 coefficient exponent, Bits[4:1].

The digital loop filter coefficients (α, β, γ, and δ) have the general form: x(2y), where x is the linear component and y is the exponential component of the coefficient.

The value of the linear component (x) constitutes a fraction, where 0 ≤ x < 1. The exponential component (y) is an integer. See the Calculating the Digital Filter Coefficients section for details.

Validation timer, Bits[7:0].

Redetect timer, Bits[7:0].

Register 0x0650 to Register 0x065A—Profile 1 Frequency Multiplication

Table 94. R Divider—Profile 11

Address Bit Bit Name Description

0x0650 [7:0] R R, Bits[7:0]. 0x0651 [7:0] R, Bits[15:8]. 0x0652 [7:0] R, Bits[23:16]. 0x0653 [7:6] Unused Unused.

[5:0] R R, Bits[29:24].

The value stored in the R divider register yields an actual divide ratio of one more than the programmed value.

Rev. B | Page 81 of 104

Page 82

AD9547

Table 95. S Divider—Profile 11

Address Bit Bit Name Description

0x0654 [7:0] S S, Bits[7:0]. 0x0655 [7:0] S S, Bits[15:8]. 0x0656 [7:4] Unused Unused.

[3:0] S S, Bits[19:16].

0x0657 [7:0] Unused Unused.

The value stored in the S divider register yields an actual divide ratio of one more than the programmed value. Furthermore, the value of S must be at least 7.

Table 96. Fractional Feedback Divider—Profile 1

Address Bit Bit Name Description

0x0658 [7:0] V V, Bits[7:0]. 0x0659 [7:4] U U, Bits[3:0].

[3:2] Unused Unused. [1:0] V V, Bits[9:8].

0x065A [7:6] Unused Unused.

[5:0] U U, Bits[9:4].

Table 97. Lock Detectors—Profile 1

Address Bit Bit Name Description

0x065B [7:0] Phase lock threshold (units determined by Register 0x0632[7]) Phase lock threshold, Bits[7:0]. 0x065C [7:0] Phase lock threshold, Bits[15:8]. 0x065D [7:0] Phase lock fill rate Phase lock fill rate, Bits[7:0]. 0x065E [7:0] Phase lock drain rate Phase lock drain rate, Bits[7:0]. 0x065F [7:0] Frequency lock threshold(expressed in units of ps) Frequency lock threshold, Bits[7:0]. 0x0660 [7:0] Frequency lock threshold, Bits[15:8]. 0x0661 [7:0] Frequency lock threshold, Bits[23:16]. 0x0662 [7:0] Frequency lock fill rate Frequency lock fill rate, Bits[7:0]. 0x0663 [7:0] Frequency lock drain rate Frequency lock drain rate, Bits[7:0]. 0x0664 to 0x067F [7:0] Unused Unused.

Register 0x0680 to Register 0x06B1—Profile 2

Table 98. Priorities—Profile 2

Address Bit Bit Name Description

0x0680 [7] Phase lock scale Controls the phase lock threshold unit scaling.

0 = picoseconds. 1 = nanoseconds. [6] Unused Unused. [5:3] Promoted priority

[2:0] Selection priority

User-assigned priority level (0 to 7) of the reference associated with Profile 2 while that reference is the active reference. The numeric value of the promoted priority must be less than or equal to the numeric value of the selection priority.

User-assigned priority level (0 to 7) of the reference associated with Profile 2, which ranks that reference relative to the others.

Table 99. Reference Period—Profile 2

Address Bit Bit Name Description

0x0681 [7:0] Reference period (expressed in units of fs) Nominal reference period, Bits[7:0]. 0x0682 [7:0] Nominal reference period, Bits[15:8]. 0x0683 [7:0] Nominal reference period, Bits[23:16]. 0x0684 [7:0] Nominal reference period, Bits[31:24]. 0x0685 [7:0] Nominal reference period, Bits[39:32]. 0x0686 [7:0] Unused Unused. Write 0s to these bits. 0x0687 [7:0]

Rev. B | Page 82 of 104

Page 83

AD9547

Table 100. Tolerance—Profile 2

Address Bit Bit Name Description

0x0688 [7:0] Inner tolerance Inner tolerance, Bits[7:0]. 0x0689 [7:0] Inner tolerance, Bits[15:8]. 0x068A [7:4] Unused Unused.

[3:0] Inner tolerance Inner tolerance, Bits[19:16]. 0x068B [7:0] Outer tolerance Outer tolerance, Bits[7:0]. 0x068C [7:0] Outer tolerance, Bits[15:8]. 0x068D [7:4] Unused Unused.

[3:0] Outer tolerance Outer tolerance, Bits[19:16].

Table 101. Validation Timer—Profile 2

Address Bit Bit Name Description

0x068E [7:0] 0x068F [7:0] Validation timer, Bits[15:8].

Validation timer (expressed in units of ms)

Table 102. Redetect Timer—Profile 2

Address Bit Bit Name Description

0x0690 [7:0] Redetect timer 0x0691 [7:0] Redetect timer, Bits[15:8].

(expressed in units of ms)

Validation timer, Bits[7:0].

Redetect timer, Bits[7:0].

Table 103. Digital Loop Filter Coefficients—Profile 21

Address Bit Bit Name Description

0x0692 [7:0] Alpha-0 linear Alpha-0 coefficient linear, Bits[7:0]. 0x0693 [7:0] Alpha-0 coefficient linear, Bits[15:8]. 0x0694 [7:6] Alpha-2 exponent Alpha-2 coefficient exponent, Bits[1:0].

[5:0] Alpha-1 exponent Alpha-1 coefficient exponent, Bits[5:0].

0x0695 [7:1] Beta-0 linear Beta-0 coefficient linear, Bits[6:0].

0 Alpha-2 exponent Alpha-2 coefficient exponent, Bit 2. 0x0696 [7:0] Beta-0 linear Beta-0 coefficient linear, Bits[14:7]. 0x0697 7 Unused Unused.

[6:2] Beta-1 exponent Beta-1 coefficient exponent, Bits[4:0].

[1:0] Beta-0 linear Beta-0 coefficient linear, Bits[16:15]. 0x0698 [7:0] Gamma-0 linear Gamma-0 coefficient linear, Bits[7:0]. 0x0699 [7:0] Gamma-0 coefficient linear, Bits[15:8]. 0x069A [7:6] Unused Unused.

[5:1] Gamma-1 exponent Gamma-1 coefficient exponent, Bits[4:0].

0 Gamma-0 linear Gamma-0 coefficient linear, Bit 16. 0x069B [7:0] Delta-0 linear Delta-0 coefficient linear, Bits[7:0]. 0x069C 7 Delta-1 exponent Delta-1 coefficient exponent, Bit 0.

[6:0] Delta-0 linear Delta-0 coefficient linear, Bits[14:8]. 0x069D [7:4] Alpha-3 exponent Alpha-3 coefficient exponent, Bits[3:0].

[3:0] Delta-1 exponent Delta-1 coefficient exponent, Bits[4:1].

The digital loop filter coefficients (α, β, γ, and δ) have the general form: x(2y), where x is the linear component and y is the exponential component of the coefficient.

The value of the linear component (x) constitutes a fraction, where 0 ≤ x < 1. The exponential component (y) is an integer (see the Calculating the Digital Filter Coefficients section for details).

Rev. B | Page 83 of 104

Page 84

AD9547

Register 0x069E to Register 0x06A8—Profile 2 Frequency Multiplication

Table 104. R Divider—Profile 21

Address Bit Bit Name Description

0x069E [7:0] R R, Bits[7:0]. 0x069F [7:0] R, Bits[15:8]. 0x06A0 [7:0] R, Bits[23:16]. 0x06A1 [7:6] Unused Unused.

[5:0] R R, Bits[29:24].

The value stored in the R divider register yields an actual divide ratio of one more than the programmed value.

Table 105. S Divider—Profile 21

Address Bit Bit Name Description

0x06A2 [7:0] S S, Bits[7:0]. 0x06A3 [7:0] S S, Bits[15:8]. 0x06A4 [7:4] Unused Unused.

[3:0] S S, Bits[19:16].

0x06A5 [7:0] Unused Unused.

The value stored in the S divider register yields an actual divide ratio of one more than the programmed value. Furthermore, the value of S must be at least 7.

Table 106. Fractional Feedback Divider—Profile 2

Address Bit Bit Name Description

0x06A6 [7:0] V V, Bits[7:0]. 0x06A7 [7:4] U U, Bits[3:0].

[3:2] Unused Unused. [1:0] V V, Bits[9:8].

0x06A8 [7:6] Unused Unused.

[5:0] U U, Bits[9:4].

Table 107. Lock Detectors—Profile 2

Address Bit Bit Name Description

0x06A9 [7:0] Phase lock threshold (units determined by Register 0x0680[7]) Phase lock threshold, Bits[7:0]. 0x06AA [7:0] Phase lock threshold, Bits[15:8]. 0x06AB [7:0] Phase lock fill rate Phase lock fill rate, Bits[7:0]. 0x06AC [7:0] Phase lock drain rate Phase lock drain rate, Bits[7:0]. 0x06AD [7:0] Frequency lock threshold (expressed in units of ps) Frequency lock threshold, Bits[7:0]. 0x06AE [7:0] Frequency lock threshold, Bits[15:8]. 0x06AF [7:0] Frequency lock threshold, Bits[23:16]. 0x06B0 [7:0] Frequency lock fill rate Frequency lock fill rate, Bits[7:0]. 0x06B1 [7:0] Frequency lock drain rate Frequency lock drain rate, Bits[7:0].

Rev. B | Page 84 of 104

Page 85

AD9547

Register 0x06B2 to Register 0x06FF—Profile 3

Table 108. Priorities—Profile 3

Address Bit Bit Name Description

0x06B2 [7] Phase lock scale Controls the phase lock threshold unit scaling.

0 = picoseconds.

1 = nanoseconds.

[6] Unused Unused.

[5:3] Promoted priority

[2:0] Selection priority

Table 109. Reference Period—Profile 3

Address Bit Bit Name Description

0x06B3 [7:0] 0x06B4 [7:0] Nominal reference period, Bits[15:8]. 0x06B5 [7:0] Nominal reference period, Bits[23:16]. 0x06B6 [7:0] Nominal reference period, Bits[31:24]. 0x06B7 [7:0] Nominal reference period, Bits[39:32]. 0x06B8 [7:0] Unused Unused. Write 0s to these bits. 0x06B9 [7:0]

Reference period (expressed in units of fs)

User-assigned priority level (0 to 7) of the reference associated with Profile 3 while that reference is the active reference. The numeric value of the promoted priority must be less than or equal to the numeric value of the selection priority.

User-assigned priority level (0 to 7) of the reference associated with Profile 3, which ranks that reference relative to the others.

Nominal reference period, Bits[7:0].

Table 110. Tolerance—Profile 3

Address Bit Bit Name Description

0x06BA [7:0] Inner tolerance Inner tolerance, Bits[7:0]. 0x06BB [7:0] Inner tolerance, Bits[15:8]. 0x06BC [7:4] Unused Unused.

[3:0] Inner tolerance Inner tolerance, Bits[19:16]. 0x06BD [7:0] Outer tolerance Outer tolerance, Bits[7:0]. 0x06BE [7:0] Outer tolerance, Bits[15:8]. 0x06BF [7:4] Unused Unused.

[3:0] Outer tolerance Outer tolerance, Bits[19:16].

Table 111. Validation Timer—Profile 3

Address Bit Bit Name Description

0x06C0 [7:0] Validation timer 0x06C1 [7:0] Validation timer, Bits[15:8].

(expressed in units of ms)

Validation timer, Bits[7:0].

Table 112. Redetect Timer—Profile 3

Address Bit Bit Name Description

0x06C2 [7:0] Redetect timer 0x06C3 [7:0] Redetect timer, Bits[15:8].

(expressed in units of ms)

Redetect timer, Bits[7:0].

Table 113. Digital Loop Filter Coefficients—Profile 31

Address Bit Bit Name Description

0x06C4 [7:0] Alpha-0 linear Alpha-0 coefficient linear, Bits[7:0]. 0x06C5 [7:0] Alpha-0 coefficient linear, Bits[15:8]. 0x06C6 [7:6] Alpha-2 exponent Alpha-2 coefficient exponent, Bits[1:0].

[5:0] Alpha-1 exponent Alpha-1 coefficient exponent, Bits[5:0]. 0x06C7 [7:1] Beta-0 linear Beta-0 coefficient linear, Bits[6:0].

0 Alpha-2 exponent Alpha-2 coefficient exponent, Bit 2.

Rev. B | Page 85 of 104

Page 86

AD9547

Address Bit Bit Name Description

0x06C8 [7:0] Beta-0 linear Beta-0 coefficient linear, Bits[14:7]. 0x06C9 7 Unused Unused.

[6:2] Beta-1 exponent Beta-1 coefficient exponent, Bits[4:0].

[1:0] Beta-0 linear Beta-0 coefficient linear, Bits[16:15]. 0x06CA [7:0] Gamma-0 linear Gamma-0 coefficient linear, Bits[7:0]. 0x06CB [7:0] Gamma-0 coefficient linear, Bits[15:8]. 0x06CC [7:6] Unused Unused.

[5:1] Gamma-1 exponent Gamma-1 coefficient exponent, Bits[4:0].

0 Gamma-0 linear Gamma-0 coefficient linear, Bit 16. 0x06CD [7:0] Delta-0 linear Delta-0 coefficient linear, Bits[7:0]. 0x06CE 7 Delta-1 exponent Delta-1 coefficient exponent, Bit 0.

[6:0] Delta-0 linear Delta-0 coefficient linear, Bits[14:8]. 0x06CF [7:4] Alpha-3 exponent Alpha-3 coefficient exponent, Bits[3:0].

[3:0] Delta-1 exponent Delta-1 coefficient exponent, Bits[4:1].

The digital loop filter coefficients (α, β, γ, and δ) have the general form: x(2y), where x is the linear component and y is the exponential component of the coefficient.

The value of the linear component (x) constitutes a fraction, where 0 ≤ x < 1. The exponential component (y) is an integer (see the Calculating the Digital Filter Coefficients section for details).

Register 0x06D0 to Register 0x06DA—Profile 3 Frequency Multiplication

Table 114. R Divider—Profile 31

Address Bit Bit Name Description

0x06D0 [7:0] R R, Bits[7:0]. 0x06D1 [7:0] R, Bits[15:8]. 0x06D2 [7:0] R, Bits[23:16]. 0x06D3 [7:6] Unused Unused.

[5:0] R R, Bits[29:24].

The value stored in the R divider register yields an actual divide ratio of one more than the programmed value.

Table 115. S Divider—Profile 31

Address Bit Bit Name Description

0x06D4 [7:0] S S, Bits[7:0]. 0x06D5 [7:0] S S, Bits[15:8]. 0x06D6 [7:4] Unused Unused.

[3:0] S S, Bits[19:16]. 0x06D7 [7:0] Unused Unused.

The value stored in the S divider register yields an actual divide ratio of one more than the programmed value. Furthermore, the value of S must be at least 7.

Table 116. Fractional Feedback Divider—Profile 3

Address Bit Bit Name Description

0x06D8 [7:0] V V, Bits[7:0]. 0x06D9 [7:4] U U, Bits[3:0].

[3:2] Unused Unused. [1:0] V V, Bits[9:8].

0x06DA [7:6] Unused Unused.

[5:0] U U, Bits[9:4].

Rev. B | Page 86 of 104

Page 87

AD9547

Table 117. Lock Detectors—Profile 3

Address Bit Bit Name Description

0x06DB [7:0] Phase lock threshold (units determined by Register 0x06B2[7]) Phase lock threshold, Bits[7:0]. 0x06DC [7:0] Phase lock threshold, Bits[15:8]. 0x06DD [7:0] Phase lock fill rate Phase lock fill rate, Bits[7:0]. 0x06DE [7:0] Phase lock drain rate Phase lock drain rate, Bits[7:0]. 0x06DF [7:0] Frequency lock threshold (expressed in units of ps) Frequency lock threshold, Bits[7:0]. 0x06E0 [7:0] Frequency lock threshold, Bits[15:8]. 0x06E1 [7:0] Frequency lock threshold, Bits[23:16]. 0x06E2 [7:0] Frequency lock fill rate Frequency lock fill rate, Bits[7:0]. 0x06E3 [7:0] Frequency lock drain rate Frequency lock drain rate, Bits[7:0]. 0x06E4 to 0x06FF [7:0] Unused Unused.

Register 0x0700 to Register 0x07FF—Profile 4 to Profile 7

Profile 4 (Register 0x0700 to Register 0x0731) is identical to Profile 0 (Register 0x0600 to Register 0x0631).

Profile 5 (Register 0x0732 to Register 0x077F) is identical to Profile 1 (Register 0x0632 to Register 0x067F).

Profile 6 (Register 0x0780 to Register 0x07B1) is identical to Profile 2 (Register 0x0680 to Register 0x06B1).

Profile 7 (Register 0x07B2 to Register 0x07FF) is identical to Profile 3 (Register 0x06B2 to Register 0x06FF).

Rev. B | Page 87 of 104

Page 88

AD9547

OPERATIONAL CONTROLS (REGISTER 0x0A00 TO REGISTER 0x0A10)

Table 118. General Power-Down

Address Bit Bit Name Description

0x0A00 7 Reset sans regmap Reset internal hardware but retain programmed register values.

0 (default) = normal operation.

1 = reset. 6 Unused Unused. 5 SYSCLK power-down Place SYSCLK input and PLL in deep sleep mode.

0 (default) = normal operation.

1 = power-down. 4 Reference power-down Place reference clock inputs in deep sleep mode.

0 (default) = normal operation.

1 = power-down. 3 TDC power-down Place the time-to-digital converter in deep sleep mode.

0 (default) = normal operation.

1 = power-down. 2 DAC power-down Place the DAC in deep sleep mode.

0 (default) = normal operation.

1 = power-down. 1 Dist power-down Place the clock distribution outputs in deep sleep mode.

0 (default) = normal operation.

1 = power-down. 0 Full power-down Place the entire device in deep sleep mode.

0 (default) = normal operation.

1 = power-down.

Table 119. Loop Mode

Address Bit Bit Name Description

0x0A01 7 Unused Unused.

6 User holdover Force the device into holdover mode.

0 (default) = normal operation.

1 = force device into holdover mode.

The device functions as though all input references are faulted.

5 User free run Force the device into free-run mode.

0 (default) = normal operation.

1 = force device into free-run mode.

The free-running frequency tuning word register (Address 0x0300 to Address 0x0305)

specifies the DDS output frequency.

Note that, when user free run is set, it overrides user holdover.

[4:3] User selection mode Select the operating mode of the reference switching state machine.

00 (default) = automatic mode. The fully automatic priority-based algorithm selects the

active reference (Bits[1:0] are ignored).

01 = fallback mode. The active reference is the user reference (Bits[1:0]) as long as it is valid.

Otherwise, use the fully automatic priority-based algorithm to select the active reference.

10 = holdover mode. The active reference is the user reference (Bits[1:0]) as long as it is

valid. Otherwise, enter holdover mode.

11 = manual mode. The active reference is always the user reference (Bits[1:0]). When using

manual mode, be sure that the reference declared as the user reference (Bits[1:0]) is

programmed for manual reference-to-profile assignment in the appropriate manual

reference profile selection register (Address 0x0503 and Address 0x0506).

2 Unused Unused. Write a 0 to this bit. [1:0] User reference selection Input reference when user selection mode = 01, 10, or 11.

00 (default) = Input Reference A.

01 = Input Reference AA.

10 = Input Reference B.

11 = Input Reference BB.

Rev. B | Page 88 of 104

Page 89

AD9547

Table 120. Cal/Sync

Address Bit Bit Name Description

0x0A02 [7:2] Unused Unused.

1 Sync distribution

0 Calibrate SYSCLK

Register 0x0A03—Reset Functions

Table 121. Reset Functions1

Address Bit Bit Name Description

0x0A03 7 Unused Unused.

6 Clear LF Setting this bit (default = 0) clears the digital loop filter (intended as a debug tool). 5 Clear CCI Setting this bit (default = 0) clears the CCI filter (intended as a debug tool). 4 Clear phase accumulator Setting this bit (default = 0) clears DDS phase accumulator (not a recommended action). 3 Reset auto sync Setting this bit (default = 0) resets the automatic synchronization logic (see Register 0x0403). 2 Reset TW history

1 Reset all IRQs

0 Reset watchdog

All bits in this register are autoclearing.

Setting this bit (default = 0) initiates synchronization of the clock distribution output. When this bit = 1, the clock distribution output stalls. Synchronization occurs on the 1 to 0 transition of this bit.

Setting this bit (default = 0) initiates an internal calibration of the SYSCLK PLL (assuming it is enabled). The calibration routine automatically selects the proper VCO frequency band and signal amplitude. The internal system clock stalls during the calibration procedure, disabling the device until calibration is complete (a few ms).

Setting this bit (default = 0) resets the tuning word history logic (part of holdover functionality).

Setting this bit (default = 0) clears the entire IRQ monitor register (Register 0x0D02 to Register 0x0D09). It is the equivalent of setting all the bits of the IRQ clearing register (Register 0x0A04 to Register 0x0A0B).

Setting this bit (default = 0) resets the watchdog timer (see Register 0x0211 to Register 0x0212). If the timer times out, it simply starts a new timing cycle. If the timer has not yet timed out, it restarts at Time 0 without causing a timeout event. Continuously resetting the watchdog timer at intervals less than its timeout period prevents the watchdog timer from generating a timeout event.

Register 0x0A04 to Register 0x0A0B—IRQ Clearing

The IRQ clearing registers are identical in format to the IRQ monitor registers (Address 0x0D02 to Address 0x0D09). When set to Logic 1, an IRQ clearing bit resets the corresponding IRQ monitor bit, thereby canceling the interrupt request for the indicated event. The IRQ clearing register is an autoclearing register.

Table 122. IRQ Clearing for SYSCLK

Address Bit Bit Name Description

0x0A04 [7:6] Unused Unused.

5 SYSCLK unlocked Clears SYSCLK unlocked IRQ. 4 SYSCLK locked Clears SYSCLK locked IRQ. [3:2] Unused Unused. 1 SYSCLK cal complete Clears SYSCLK calibration complete IRQ. 0 SYSCLK cal started Clears SYSCLK calibration started IRQ.

Table 123. IRQ Clearing for Distribution Sync, Watchdog Timer, and EEPROM

Address Bit Bit Name Description

0x0A05 [7:4] Unused Unused.

3 Distribution sync Clears distribution sync IRQ. 2 Watchdog timer Clears watchdog timer IRQ. 1 EEPROM fault Clears EEPROM fault IRQ. 0 EEPROM complete Clears EEPROM complete IRQ.

Rev. B | Page 89 of 104

Page 90

AD9547

Table 124. IRQ Clearing for the Digital PLL

Address Bit Bit Name Description

0x0A06 7 Switching Clears switching IRQ.

6 Closed Clears closed IRQ. 5 Free run Clears free-run IRQ. 4 Holdover Clears holdover IRQ. 3 Frequency unlocked Clears frequency unlocked IRQ. 2 Frequency locked Clears frequency locked IRQ. 1 Phase unlocked Clears phase unlocked IRQ. 0 Phase locked Clears phase locked IRQ.

Table 125. IRQ Clearing for History Update, Frequency Limit, and Phase Slew Limit

Address Bit Bit Name Description

0x0A07 [7:5] Unused Unused.

4 History updated Clears history updated IRQ. 3 Frequency unclamped Clears frequency unclamped IRQ. 2 Frequency clamped Clears frequency clamped IRQ. 1 Phase slew unlimited Clears phase slew unlimited IRQ. 0 Phase slew limited Clears phase slew limited IRQ.

Table 126. IRQ Clearing for Reference Inputs

Address Bit Bit Name Description

0x0A08 7 Ref AA new profile Clears Ref AA new profile IRQ.

6 Ref AA validated Clears Ref AA validated IRQ. 5 Ref AA fault cleared Clears Ref AA fault cleared IRQ. 4 Ref AA fault Clears Ref AA fault IRQ. 3 Ref A new profile Clears Ref A new profile IRQ. 2 Ref A validated Clears Ref A validated IRQ. 1 Ref A fault cleared Clears Ref A fault cleared IRQ. 0 Ref A fault Clears Ref A fault IRQ.

0x0A09 7 Ref BB new profile Clears Ref BB new profile IRQ.

6 Ref BB validated Clears Ref BB validated IRQ. 5 Ref BB fault cleared Clears Ref BB fault cleared IRQ. 4 Ref BB fault Clears Ref BB fault IRQ. 3 Ref B new profile Clears Ref B new profile IRQ. 2 Ref B validated Clears Ref B validated IRQ. 1 Ref B fault cleared Clears Ref B fault cleared IRQ.

0 Ref B fault Clears Ref B fault IRQ. 0x0A0A [7:0] Unused Unused. 0x0A0B [7:0]

Rev. B | Page 90 of 104

Page 91

AD9547

Table 127. Incremental Phase Offset Control

Address Bit Bit Name Description

0x0A0C [7:3] Unused Unused.

2 Reset phase offset Resets the incremental phase offset to 0. This is an autoclearing bit. 1 Decrement phase offset

0 Increment phase offset

Table 128. Reference Profile Selection State Machine Startup1

Address Bit Bit Name Description

0x0A0D [7:4] Unused Unused.

3 Detect BB Setting this bit starts the profile selection state machine for Input Reference BB. 2 Detect B Setting this bit starts the profile selection state machine for Input Reference B. 1 Detect AA Setting this bit starts the profile selection state machine for Input Reference AA. 0 Detect A Setting this bit starts the profile selection state machine for Input Reference A.

All bits in this register are autoclearing.

Register 0x0A0E to Register 0x0A10—Reference Validation Override Controls

Decrements the incremental phase offset by the amount specified in the incremental phase lock offset step size register (Register 0x0314 to Register 0x0315).

This is an autoclearing bit. Increments the incremental phase offset by the amount specified in the incremental phase

lock offset step size register (Register 0x0314 to Register 0x0315). This is an autoclearing bit.

Table 129. Force Validation Timeout1

Address Bit Bit Name Description

0x0A0E [7:4] Unused Unused.

3 Force Timeout BB Setting this bit emulates timeout of the validation timer for Reference BB.

This is an autoclearing bit.

2 Force Timeout B Setting this bit emulates timeout of the validation timer for Reference B.

This is an autoclearing bit.

1 Force Timeout AA Setting this bit emulates timeout of the validation timer for Reference AA.

This is an autoclearing bit.

0 Force Timeout A Setting this bit emulates timeout of the validation timer for Reference A.

This is an autoclearing bit.

All bits in this register are autoclearing.

Table 130. Reference Monitor Override1

Address Bit Bit Name Description

0x0A0F [7:4] Unused Unused.

3 Ref Mon Override BB Overrides the reference monitor REF fault signal for Reference BB (default = 0, not overridden). 2 Ref Mon Override B Overrides the reference monitor REF fault signal for Reference B (default = 0, not overridden). 1 Ref Mon Override AA Overrides the reference monitor REF fault signal for Reference AA (default = 0, not overridden). 0 Ref Mon Override A Overrides the reference monitor REF fault signal for Reference A (default = 0, not overridden).

All bits in this register are autoclearing.

Table 131. Reference Monitor Bypass1

Address Bit Bit Name Description

0x0A10 [7:4] Unused Unused.

3 Ref Mon Bypass BB Bypasses the reference monitor for Reference BB (default = 0, not bypassed). 2 Ref Mon Bypass B Bypasses the reference monitor for Reference B (default = 0, not bypassed). 1 Ref Mon Bypass AA Bypasses the reference monitor for Reference AA (default = 0, not bypassed). 0 Ref Mon Bypass A Bypasses the reference monitor for Reference A (default = 0, not bypassed).

All bits in this register are autoclearing.

Rev. B | Page 91 of 104

Page 92

AD9547

STATUS READBACK (REGISTER 0x0D00 TO REGISTER 0x0D19)

All bits in Register 0x0D00 to Register 0x0D19 are read only. These registers are accessible during EEPROM transactions.

Table 132. EEPROM Status

Address Bit Bit Name Description

0x0D00 [7:3] Unused Unused.

2 Fault detected An error occurred while saving data to or loading data from the EEPROM.

1 Load in progress The control logic sets this bit while data is being read from the EEPROM.

0 Save in progress The control logic sets this bit while data is being written to the EEPROM.

Table 133. SYSCLK Status

Address Bit Bit Name Description

0x0D01 [7:5] Unused Unused.

4 Stable

[3:2] Unused Unused. 1 Cal in progress The control logic holds this bit set while the system clock calibration is in progress. 0 Lock detected Indicates the status of the system clock PLL.

Register 0x0D02 to Register 0x0D09—IRQ Monitor

If not masked via the IRQ mask register (Address 0x0209 to Address 0x0210), the appropriate IRQ monitor bit is set to a Logic 1 when the indicated event occurs. These bits can only be cleared via the IRQ clearing register (Address 0x0A04 to Address 0x0A0B), the reset all IRQs bit (Register 0x0A03, Bit 1), or a device reset.

The control logic sets this bit when the device considers the system clock to be stable (see the System Clock Stability Timer section).

0 = unlocked. 1 = locked (or the PLL is disabled).

Table 134. IRQ Monitor for SYSCLK

Address Bit Bit Name Description

0x0D02 [7:6] Unused Unused.

5 SYSCLK unlocked Indicates a SYSCLK PLL state transition from locked to unlocked.

4 SYSCLK locked Indicates a SYSCLK PLL state transition from unlocked to locked.

[3:2] Unused Unused.

1 SYSCLK cal complete Indicates that SYSCLK calibration is complete.

0 SYSCLK cal started Indicates that SYSCLK calibration has begun.

Table 135. IRQ Monitor for Distribution Sync, Watchdog Timer, and EEPROM

Address Bit Bit Name Description

0x0D03 [7:4] Unused Unused.

3 Distribution sync Indicates a distribution sync event.

2 Watchdog timer Indicates expiration of the watchdog timer.

1 EEPROM fault Indicates a fault during an EEPROM load or save operation.

0 EEPROM complete Indicates successful completion of an EEPROM load or save operation.

Table 136. IRQ Monitor for the Digital PLL

Address Bit Bit Name Description

0x0D04 7 Switching Indicates that the DPLL is switching to a new reference.

6 Closed Indicates that the DPLL has entered closed-loop operation.

5 Free run Indicates that the DPLL has entered free-run mode.

4 Holdover Indicates that the DPLL has entered holdover mode.

3 Frequency unlocked Indicates that the DPLL lost frequency lock.

2 Frequency locked Indicates that the DPLL has acquired frequency lock.

1 Phase unlocked Indicates that the DPLL lost phase lock.

0 Phase locked Indicates that the DPLL has acquired phase lock.

Rev. B | Page 92 of 104

Page 93

AD9547

Table 137. IRQ Monitor for History Update, Frequency Limit, and Phase Slew Limit

Address Bit Bit Name Description

0x0D05 [7:5] Unused Unused.

4 History updated Indicates the occurrence of a tuning word history update. 3 Frequency unclamped Indicates a frequency limiter state transition from clamped to unclamped. 2 Frequency clamped Indicates a frequency limiter state transition from unclamped to clamped. 1 Phase slew unlimited Indicates a phase slew limiter state transition from slew limiting to not slew limiting. 0 Phase slew limited Indicates a phase slew limiter state transition from not slew limiting to slew limiting.

Table 138. IRQ Monitor for Reference Inputs

Address Bit Bit Name Description

0x0D06 7 Ref AA new profile Indicates that Ref AA has switched to a new profile.

6 Ref AA validated Indicates that Ref AA has been validated. 5 Ref AA fault cleared Indicates that Ref AA has been cleared of a previous fault. 4 Ref AA fault Indicates that Ref AA has been faulted. 3 Ref A new profile Indicates that Ref A has switched to a new profile. 2 Ref A validated Indicates that Ref A has been validated. 1 Ref A fault cleared Indicates that Ref A has been cleared of a previous fault. 0 Ref A fault Indicates that Ref A has been faulted.

0x0D07 7 Ref BB new profile Indicates that Ref BB has switched to a new profile.

6 Ref BB validated Indicates that Ref BB has been validated. 5 Ref BB fault cleared Indicates that Ref BB has been cleared of a previous fault. 4 Ref BB fault Indicates that Ref BB has been faulted. 3 Ref B new profile Indicates that Ref B has switched to a new profile. 2 Ref B validated Indicates that Ref B has been validated. 1 Ref B fault cleared Indicates that Ref B has been cleared of a previous fault.

0 Ref B fault Indicates that Ref B has been faulted. 0x0D08 [7:0] Unused Unused. 0x0D09 [7:0]

Table 139. DPLL Status

Address Bit Bit Name Description

0x0D0A 7 Offset slew limiting The current closed-loop phase offset is rate limited.

6 Phase build-out A phase build-out transition was made to the currently active reference.

5 Frequency lock The DPLL has achieved frequency lock.

4 Phase lock The DPLL has achieved phase lock.

3 Loop switching The DPLL is in the process of a reference switchover.

2 Holdover The DPLL is in holdover mode.

1 Active The DPLL is active (that is, operating in a closed-loop condition).

0 Free running The DPLL is free running (that is, operating in an open-loop condition). 0x0D0B 7 Frequency clamped The upper or lower frequency tuning word clamp is in effect.

6 History available There is sufficient tuning word history available for holdover operation.

[5:3] Active reference priority Priority value of the currently active reference.

000 = highest priority.

111 = lowest priority. 2 Unused Unused. [1:0] Active reference Index of the currently active reference.

00 = Reference A.

01 = Reference AA.

10 = Reference B.

11 = Reference BB.

Rev. B | Page 93 of 104

Page 94

AD9547

Table 140. Input Reference Status

Address Bit Bit Name Description

0x0D0C 7 Profile selected The control logic sets this bit when it assigns Ref A to one of the eight profiles.

[6:4] Selected profile The index (0 to 7) of the profile assigned to Ref A.

Note that these bits are meaningless unless Bit 7 = 1. 3 Valid Ref A is valid for use (that is, it is unfaulted, and its validation timer has expired). 2 Fault Ref A is not valid for use. 1 Fast If Bit 7 = 1, this bit indicates that the frequency of Ref A is higher than allowed by its profile settings.

If Bit 7 = 0, this bit indicates that the frequency of Ref A is above the maximum input reference

frequency supported by the device. 0 Slow If Bit 7 = 1, this bit indicates that the frequency of Ref A is lower than allowed by its profile settings.

If Bit 7 = 0, this bit indicates that the frequency of Ref A is below the minimum input reference

frequency supported by the device.

0x0D0D [7:0] Same as 0x0D0C but for REF AA instead of REF A. 0x0D0E [7:0] Same as 0x0D0C but for REF B instead of REF A. 0x0D0F [7:0] Same as 0x0D0C but for REF BB instead of REF A. 0x0D10 [7:0] Unused Unused. 0x0D11 [7:0] 0x0D12 [7:0] 0x0D13 [7:0]

Table 141. Holdover History1

Address Bit Bit Name Description

0x0D14 [7:0] 0x0D15 [7:0] Tuning word readback, Bits[15:8]. 0x0D16 [7:0] Tuning word readack, Bits[23:16]. 0x0D17 [7:0] Tuning word readback, Bits[31:24]. 0x0D18 [7:0] Tuning word readback, Bits[39:32]. 0x0D19 [7:0] Tuning word readback, Bits[47:40].

These registers contain the current 48-bit DDS frequency tuning word generated by the tuning word history logic.

Tuning word history

Tuning word readback, Bits[7:0].

NONVOLATILE MEMORY (EEPROM) CONTROL (REGISTER 0x0E00 TO REGISTER 0x0E03)

Table 142. Write Protect

Address Bit Bit Name Description

0x0E00 [7:2] Unused Unused.

1 Half rate mode EEPROM serial communication rate.

0 (default) = 400 kHz (normal). 1 = 200 kHz.

0 Write enable EEPROM write enable/protect.

0 (default) = EEPROM is write protected.

1 = EEPROM is write enabled.

Table 143. Condition

Address Bit Bit Name Description

0x0E01 [7:5] Unused Unused.

[4:0] Condition value When set to a nonzero value (default = 0), these bits establish the condition for EEPROM downloads.

Table 144. Save

Address Bit Bit Name Description

0x0E02 [7:1] Unused Unused.

0 Save to EEPROM Upload data to the EEPROM based on in the EEPROM storage sequence. This is an autoclearing bit.

Rev. B | Page 94 of 104

Page 95

AD9547

Table 145. Load

Address Bit Bit Name Description

0x0E03 [7:2] Unused Unused.

Load from EEPROM

0 Unused Unused.

EEPROM STORAGE SEQUENCE (REGISTER 0x0E10 TO REGISTER 0x0E3F)

The default settings of Register 0x0E10 to Register 0x0E33 embody a sample scratch pad instruction sequence. The following is a description of the register defaults under the assumption that the controller has been instructed to carry out an EEPROM storage sequence.

Table 146. EEPROM Storage Sequence for System Clock Settings

Address Bit Bit Name Description

0x0E10 [7:0] System clock

0x0E11 [7:0] System clock 0x0E12 [7:0]

0x0E13 [7:0] I/O update

Download data from the EEPROM. This is an autoclearing bit.

The default value of this register is 0x08, which the controller interprets as a data instruction. Its decimal value is 8, which tells the controller to transfer nine bytes of data (8 + 1) beginning at the address specified by the next two bytes. The controller stores 0x08 in the EEPROM and increments the EEPROM address pointer.

The default value of these two registers is 0x0100. Note that Register 0x0E11 and Register 0x0E12 are the most significant and least significant bytes of the target address, respectively. Because the previous register contains a data instruction, these two registers define a starting address (in this case, 0x0100). The controller stores 0x0100 in the EEPROM and increments the EEPROM pointer by 2. It then transfers nine bytes from the register map (beginning at Address 0x0100) to the EEPROM and increments the EEPROM address pointer by 10 (nine data bytes and one checksum byte). The nine bytes transferred correspond to the system clock parameters in the register map.

The default value of this register is 0x80, which the controller interprets as an I/O update instruction. The controller stores 0x80 in the EEPROM and increments the EEPROM address pointer.

Table 147. EEPROM Storage Sequence for System Clock Calibration

Address Bit Bit Name Description

0x0E14 [7:0] SYSCLK calibrate

The default value of this register is 0xA0, which the controller interprets as a calibrate instruction. The controller stores 0xA0 in the EEPROM and increments the EEPROM address pointer.

Table 148. EEPROM Storage Sequence for General Configuration Settings

Address Bit Bit Name Description

0x0E15 [7:0] General

0x0E16 [7:0] General 0x0E17 [7:0]

The default value of this register is 0x14, which the controller interprets as a data instruction. Its decimal value is 20, which tells the controller to transfer 21 bytes of data (20 + 1) beginning at the address specified by the next two bytes. The controller stores 0x14 in the EEPROM and increments the EEPROM address pointer.

The default value of these two registers is 0x0200. Note that Register the most significant and least significant bytes of the target address, respectively. Because the previous register contains a data instruction, these two registers define a starting address (in this case, 0x0200). The controller stores 0x0200 in the EEPROM and increments the EEPROM pointer by 2. It then transfers 21 bytes from the register map (beginning at Address 0x0200) to the EEPROM and increments the EEPROM address pointer by 22 (21 data bytes and one checksum byte). The 21 bytes transferred correspond to the general configuration parameters in the register map.

Table 149. EEPROM Storage Sequence for DPLL Settings

Address Bit Bit Name Description

0x0E18 [7:0] DPLL

0x0E19 [7:0] DPLL 0x0E1A [7:0]

The default value of this register is 0x1B, which the controller interprets as a data instruction. Its decimal value is 27, which tells the controller to transfer 28 bytes of data (27 + 1) beginning at the address specified by the next two bytes. The controller stores 0x1B in the EEPROM and increments the EEPROM address pointer.

The default value of these two registers is 0x0300. Note that Register 0x0E19 and Register 0x0E1A are the most significant and least significant bytes of the target address, respectively. Because the previous register contains a data instruction, these two registers define a starting address (in this case, 0x0300). The controller stores 0x0300 in the EEPROM and increments the EEPROM pointer by 2. It then transfers 28 bytes from the register map (beginning at Address 0x0300) to the EEPROM and increments the EEPROM address pointer by 29 (28 data bytes and one checksum byte). The 28 bytes transferred correspond to the DPLL parameters in the register map.

Rev. B | Page 95 of 104

0x0E16 and Register 0x0E17 are

Page 96

AD9547

Table 150. EEPROM Storage Sequence for Clock Distribution Settings

Address Bit Bit Name Description

0x0E1B [7:0] Clock distribution

0x0E1C [7:0] Clock distribution 0x0E1D [7:0]

0x0E1E [7:0] I/O update

Table 151. EEPROM Storage Sequence for Reference Input Settings

Address Bit Bit Name Description

0x0E1F [7:0] Reference inputs

0x0E20 [7:0] Reference inputs 0x0E21 [7:0]

The default value of this register is 0x19, which the controller interprets as a data instruction. Its decimal value is 25; this tells the controller to transfer 26 bytes of data (25 + 1) beginning at the address specified by the next two bytes. The controller stores 0x19 in the EEPROM and increments the EEPROM address pointer.

The default value of these two registers is 0x0400. Note that Register 0x0E1C and Register 0x0E1D are the most significant and least significant bytes of the target address, respectively. Because the previous register contains a data instruction, these two registers define a starting address (in this case, 0x0400). The controller stores 0x0400 in the EEPROM and increments the EEPROM pointer by 2. It then transfers 26 bytes from the register map (beginning at Address 0x0400) to the EEPROM and increments the EEPROM address pointer by 27 (26 data bytes and one checksum byte). The 26 bytes transferred correspond to the clock distribution parameters in the register map.

The default value of this register is 0x80, which the controller interprets as an I/O update instruction. The controller stores 0x80 in the EEPROM and increments the EEPROM address pointer.

The default value of this register is 0x07, which the controller interprets as a data instruction. Its decimal value is 7, which tells the controller to transfer eight bytes of data (7 + 1), beginning at the address specified by the next two bytes. The controller stores 0x07 in the EEPROM and increments the EEPROM address pointer.

The default value of these two registers is 0x0500. Note that Register 0x0E20 and Register 0x0E21 are the most significant and least significant bytes of the target address, respectively. Because the previous register contains a data instruction, these two registers define a starting address (in this case, 0x0500). The controller stores 0x0500 in the EEPROM and increments the EEPROM pointer by 2. It then transfers eight bytes from the register map (beginning at Address 0x0500) to the EEPROM and increments the EEPROM address pointer by nine (eight data bytes and one checksum byte). The eight bytes transferred correspond to the reference inputs parameters in the register map.

Table 152. EEPROM Storage Sequence for Profile 0 and Profile 1 Settings

Address Bit Bit Name Description

0x0E22 [7:0] Profile 0 and Profile 1

0x0E23 [7:0] Profile 0 and Profile 1 0x0E24 [7:0]

The default value of this register is 0x63, which the controller interprets as a data instruction. Its decimal value is 99, which tells the controller to transfer 100 bytes of data (99 + 1), beginning at the address specified by the next two bytes. The controller stores 0x63 in the EEPROM and increments the EEPROM address pointer.

The default value of these two registers is 0x0600. Note that Register 0x0E23 and Register 0x0E24 are the most significant and least significant bytes of the target address, respectively. Because the previous register contains a data instruction, these two registers define a starting address (in this case, 0x0600). The controller stores 0x0600 in the EEPROM and increments the EEPROM pointer by 2. It then transfers 100 bytes from the register map (beginning at Address 0x0600) to the EEPROM and increments the EEPROM address pointer by 101 (100 data bytes and one checksum byte). The 99 bytes transferred correspond to the Profile 0 and Profile 1 parameters in the register map.

Table 153. EEPROM Storage Sequence for Profile 2 and Profile 3 Settings

Address Bit Bit Name Description

0x0E25 [7:0] Profile 2 and Profile 3

0x0E26 [7:0] Profile 2 and Profile 3 0x0E27 [7:0]

The default value of these two registers is 0x0680. Note that Register (0x0E26 and Register 0x0E27 are the most significant and least significant bytes of the target address, respectively. Because the previous register contains a data instruction, these two registers define a starting address (in this case, 0x0680). The controller stores 0x0680 in the EEPROM and increments the EEPROM pointer by 2. It then transfers 100 bytes from the register map (beginning at Address 0x0680) to the EEPROM and increments the EEPROM address pointer by 101 (100 data bytes and one checksum byte). The 99 bytes transferred correspond to the Profile 2 and Profile 3 parameters in the register map.

Rev. B | Page 96 of 104

Page 97

AD9547

Table 154. EEPROM Storage Sequence for Profile 4 and Profile 5 Settings

Address Bit Bit Name Description

0x0E28 [7:0] Profile 4 and Profile 5

0x0E29 [7:0] Profile 4 and Profile 5 0x0E2A [7:0]

Table 155. EEPROM Storage Sequence for Profile 6 and Profile 7 Settings

Address Bit Bit Name Description

0x0E2B [7:0] Profile 6 and Profile 7

0x0E2C [7:0] Profile 6 and Profile 7 0x0E2D [7:0]

0x0E2E [7:0] I/O update

The default value of this register is 0x63, which the controller interprets as a data instruction. Its decimal value is 99, which tells the controller to transfer 100 bytes of data (99 + 1) beginning at the address specified by the next two bytes. The controller stores 0x63 in the EEPROM and increments the EEPROM address pointer.

The default value of these two registers is 0x0700. Note that Register are the most significant and least significant bytes of the target address, respectively. Because

the previous register contains a data instruction, these two registers define a starting address (in this case, 0x0700). The controller stores 0x0700 in the EEPROM and increments the EEPROM pointer by 2. It then transfers 100 bytes from the register map (beginning at Address 0x0700) to the EEPROM and increments the EEPROM address pointer by 101 (100 data bytes and one checksum byte). The 99 bytes transferred correspond to the Profile 4 and Profile 5 parameters in the register map.

The default value of this register is 0x63, which the controller interprets as a data instruction. Its decimal value is 99, this tells the controller to transfer 100 bytes of data (99 + 1) beginning at the address specified by the next two bytes. The controller stores 0x63 in the EEPROM and increments the EEPROM address pointer.

The default value of these two registers is 0x0780. Note that Register 0x0E2C and Register 0x0E2D are the most significant and least significant bytes of the target address, respectively. Because the previous register contains a data instruction, these two registers define a starting address (in this case, 0x0780). The controller stores 0x0780 in the EEPROM and increments the EEPROM pointer by 2. It then transfers 100 bytes from the register map (beginning at Address 0x0780) to the EEPROM and increments the EEPROM address pointer by 101 (100 data bytes and one checksum byte). The 99 bytes transferred correspond to the Profile 6 and Profile 7 parameters in the register map.

The default value of this register is 0x80, which the controller interprets as an I/O update instruction. The controller stores 0x80 in the EEPROM and increments the EEPROM address pointer.

0x0E29 and Register 0x0E2A

Table 156. EEPROM Storage Sequence for Operational Control Settings

Address Bit Bit Name Description

0x0E2F [7:0] Operational controls

0x0E30 [7:0] Operational controls 0x0E31 [7:0]

0x0E32 [7:0] I/O update

The default value of this register is 0x10, which the controller interprets as a data instruction. Its decimal value is 16, this tells the controller to transfer 17 bytes of data (16 + 1) beginning at the address specified by the next two bytes. The controller stores 0x10 in the EEPROM and increments the EEPROM address pointer.

The default value of these two registers is 0x0A00. Note that Register 0x0E30 and Register 0x0E31 are the most significant and least significant bytes of the target address, respectively. Because the previous register contains a data instruction, these two registers define a starting address (in this case, 0x0A00). The controller stores 0x0A00 in the EEPROM and increments the EEPROM pointer by 2. It then transfers 17 bytes from the register map (beginning at Address 0x0A00) to the EEPROM and increments the EEPROM address pointer by 18 (17 data bytes and one checksum byte). The 17 bytes transferred correspond to the operational controls parameters in the register map.

The default value of this register is 0x80, which the controller interprets as an I/O update instruction. The controller stores 0x80 in the EEPROM and increments the EEPROM address pointer.

Table 157. EEPROM Storage Sequence for End of Data

Address Bit Bit Name Description

0x0E33 [7:0] End of data

The default value of this register is 0xFF, which the controller interprets as an end instruction. The controller stores this instruction in the EEPROM, resets the EEPROM address pointer, and enters an idle state. Note that, if this were a pause rather than an end instruction, the controller actions would be the same except that the controller would not reset the EEPROM address pointer.

Rev. B | Page 97 of 104

Page 98

AD9547

APPLICATIONS INFORMATION

POWER SUPPLY PARTITIONS

The AD9547 features multiple power supplies, and their power consumption varies with the AD9547 configuration. This section provides information about which power supplies can be grouped together and how the power consumption of each block varies with frequency.

The numbers quoted in this section are for comparison only. Refer to the Specifications section for exact numbers. With each group, bypass capacitors of 1 F in parallel with 10 F should be used.

Upon applying power to the device, internal circuitry monitors the 1.8 V digital core supply and the 3.3 V digital I/O supply. When these supplies cross the desired threshold level, the device generates an internal 10 s reset pulse. This pulse does not appear on the RESET pin.

3.3 V Supplies

The 3.3 V supply domain consists of two main partitions: digital (DVDD3) and analog (AVDD3). These two supply domains must be kept separate.

Furthermore, the AVDD3 consists of two subdomains: the clock distribution output domain (Pin 25, Pin 31) and the rest of the AVDD3 supply connections. Generally, the ADD3 supply domains can be joined together. However, if an application requires 1.8 V CMOS driver operation in the clock distribution output block, provide one 1.8 V supply domain to power the clock distribution output block. Each output driver has a dedicated supply pin, as shown in Table 158.

Table 158. Output Driver Supply Pins

Output Driver Supply Pin

OUT0 25 OUT1 31

1.8 V Supplies

The 1.8 V supply domain consists of two main partitions: digital (DVDD) and analog (AVDD). These two supply domains must be kept separate.

THERMAL PERFORMANCE

The AD9547 is specified for a case temperature (T that T

is not exceeded, an airflow source can be used. Use the

CASE

following equation to determine the junction temperature on the application PCB:

= T

+ (ΨJT × PD)

CASE

where:

is the junction temperature in degrees Celsius (°C).

is the case temperature in degrees Celsius (°C) measured

CASE

by the customer at the top center of the package.

is the value that is indicated in Table 159.

PD is the power dissipation (see the Power Dissipation section).

Valu es of θ considerations. θ

are provided for package comparison and PCB design

can be used for a first-order approximation of TJ

using the following equation:

= TA + (θJA × PD)

where T

Valu es o f θ

is the ambient temperature in degrees Celsius (°C).

are provided for package comparison and PCB

design considerations when an external heat sink is required.

Valu es o f θ

are provided for package comparison and PCB

design considerations.

). To ensure

CASE

Table 159. Thermal Parameters for the AD9547 64-Lead LFCSP Package

Symbol Thermal Characteristic Using a JEDEC51-7 Plus JEDEC51-5 2S2P Test Board1 Value2 Unit

θJA Junction-to-ambient thermal resistance, 0.0 m/sec air flow per JEDEC JESD51-2 (still air) 21.7 °C/W θ

Junction-to-ambient thermal resistance, 1.0 m/sec air flow per JEDEC JESD51-6 (moving air) 18.9 °C/W

JMA

Junction-to-ambient thermal resistance, 2.5 m/sec air flow per JEDEC JESD51-6 (moving air) 16.9 °C/W

JMA

θJB Junction-to-board thermal resistance, per JEDEC JESD51-8 (still air) 11.3 °C/W θJC Junction-to-case thermal resistance 1.2 °C/W ΨJT Junction-to-top-of-package characterization parameter, 0 m/sec airflow per JEDEC JESD51-2 (still air) 0.1 °C/W

The exposed pad on the bottom of the package must be soldered to ground to achieve the specified thermal performance.

Results are from simulations. The PCB is a JEDEC multilayer type. Thermal performance for actual applications requires careful inspection of the conditions in the

application to determine whether they are similar to those assumed in these calculations.

Rev. B | Page 98 of 104

Page 99

AD9547

(

−

CALCULATING THE DIGITAL FILTER COEFFICIENTS

The digital loop filter coefficients (α, β, γ, and δ, as shown in Figure 38) relate to the time constants (T associated with the equivalent analog circuit for a third-order loop filter (see Figure 64).

FROM

CHARGE

PUMP

Figure 64. Third-Order Analog Loop Filter

The design process begins by deciding on two design parameters related to the second-order loop filter shown in Figure 65: the desired open-loop bandwidth (f

FROM

CHARGE

PUMP

Figure 65. Second-Order Analog Loop Filter

) and the phase margin (θ).

An analysis of the second-order loop filter leads to its primary time constant, T of f

and θ as

T where ω

. It can be shown that T1 is expressible in terms

)sin(1

θ−

)cos(

= 2πfP

An analysis of the third-order loop filter leads to the definition of another time constant, T

. It can be shown that T3 is expressible

in terms of the desired amount of additional attenuation introduced by R

and C3 at some specified frequency offset (f

from the PLL output frequency.

ATTEN

−

OFFSET

110

OFFSET

= where ω

Note that ATTEN is the desired excess attenuation in decibels (dB). Furthermore, ATTEN and ω

≤

fT5

With an expression for T open-loop bandwidth (f shown that ω in terms of T

(fC expressed as a radian frequency) is expressible

, T3, and θ (phase margin) as follows:

()

= 1

()

OFFSET

and T3, it is possible to define an adjusted

) that is slightly less than fP. It can be

⎡

θ+

)tan(

⎢

TTTT

3131

()

[]

⎢

⎣

, T2, and T3) that are

TO VCO

OFFSET

TO VCO

08300-043

08300-042

OFFSET

= 2πf

should be chosen so that

()

TTTT

⎤

3131

−

⎥

θ+

)tan(

⎥

⎦

)

It can also be shown that the adjusted open-loop bandwidth leads to T

(the secondary time constant of the second-order

loop filter), which is expressed as

()

TTω

Calculation of the digital loop filter coefficients requires a scaling constant, K (related to the system clock frequency, f

and the PLL feedback divide ratio, D.

125,578,517,30

1++=

where S, U, and V are the integer and fractional feedback divider values that reside in the profile registers.

Keep in mind that the desired integer feedback divide ratio is one more than the stored value of S (hence, the +1 term in the equation for D in this equation). This leads to the digital filter coefficients given by

δ32=

DTω

⎛

− ⎜

−

⎜

⎝

)

()

Tω

⎞

1132

⎟ ⎟

TTf

⎠

()

TωTω

Calculation of the coefficient register values requires the application of some special functions, which are described as follows:

The if() function

y = if (test_statement, true_value, false_value)

where:

test_statement is a conditional expression (for example, x < 3). true_value is what y equals if the conditional expression is true. false_value is what y equals if the conditional expression is false.

The round() function

y = round(x)

If x is an integer, then y = x. Otherwise, y is the nearest integer to x. For example, round(2.1) = 2, round(2.5) = 3, and round(−3.1) = −3.

The ceil() function

y = ceil(x)

If x is an integer, then y = x. Otherwise, y is the next integer to the right on the number line. For example, ceil(2.8) = 3, whereas ceil(−2.8) = −2.

Rev. B | Page 99 of 104

Page 100

AD9547

The min() function

y = min(x

, x1, ... xn)

where:

through xn is a list of real numbers.

y is the number in the list that is the farthest to the left on the

number line.

The max() function

y = max(x

, x1, ... xn)

where:

through xn is a list of real numbers.

y is the number in the list that is the farthest to the right on the

number line.

The log

() function

(x) =

log

xln

)2()(ln

where: ln() is the natural log function. x is a positive, nonzero number.

Assume that the coefficient calculations for α, β, γ, and δ above yield the following results:

α = 0.012735446

β = −6.98672 × 10

γ = −7.50373 × 10

−5

δ = 0.002015399

These values are floating point numbers that must be quantized according to the bit widths of the linear and exponential components of the coefficients as they appear in the register map. Note that the calculations that follow indicate a positive value for the register entries of β and γ. The reason is that β and γ, which are supposed to be negative values, are stored in the AD9547 registers as positive values. The AD9547 converts the stored values to negative numbers within its signal processing core. A detailed description of the register value computations for α, β, γ, and δ follows.

Rev. B | Page 100 of 104

Calculation of the α Register Values

The quantized α coefficient consists of four components: α0, α1,

, and α3, according to

α ≈ α

quantized

= α0 × 2

16 − α1 + α2 + α

where:

, α1, α2, and α3 are the register values.

provides front-end gain.

provides back-end gain.

shifts the binary decimal point of α0 to the left to accommodate

small values of α.

Calculation of α

w = if(α <1, −ceil(log

= if(α <1, min[63, max(0, w)], 0)

is a two-step process, as follows:

(α)), 0)

If gain is necessary (that is, α > 1), then it is beneficial to apply most or all of it to the front-end gain (α culation of α

is to be done before that of α3. Calculation of α2

) implying that the cal-

is a three-step process that leads directly to the calculation of α

x = if(α > 1, ceil(log

(α)), 0)

y = if(α > 1, min[22, max(0, x)], 0)

= if(y ≥ 8, 7, y)

= if(y ≥ 8, y – 7, 0)

Calculation of α

z = round(α × 2

= min[65535, max(1, z)

is a two-step process, as follows:

16 + α1 − α2 − α

)

Using the example value of α = 0.012735446 yields

w = 6, so α

= 6

x = 0 and y = 0, so α2 = 0 and α3 = 0

z = 53416.332099584, so α0 = 53416

This leads to the following quantized value, which is very close to the desired value of 0.012735446:

quantized

= 53416 × 2

−22

≈ 0.01273566821

Datasheet AD9547 Datasheet (ANALOG DEVICES)

Specifications and Main Features

Frequently Asked Questions

User Manual

FEATURES

APPLICATIONS

GENERAL DESCRIPTION

FUNCTIONAL BLOCK DIAGRAM

TABLE OF CONTENTS

REVISION HISTORY

SPECIFICATIONS

SUPPLY VOLTAGE

SUPPLY CURRENT

POWER DISSIPATION

LOGIC INPUTS (M0 TO M7, RESET)

LOGIC OUTPUTS (M0 TO M7, IRQ)

SYSTEM CLOCK INPUTS (SYSCLKP, SYSCLKN)

DISTRIBUTION CLOCK INPUTS (CLKINP, CLKINN)

REFERENCE INPUTS (REFA/REFAA, REFB/REFBB)

REFERENCE MONITORS

REFERENCE SWITCHOVER SPECIFICATIONS

DISTRIBUTION CLOCK OUTPUTS (OUT0, OUT1)

DAC OUTPUT CHARACTERISTICS (DACOUTP, DACOUTN)

TIME DURATION OF DIGITAL FUNCTIONS

DIGITAL PLL

DIGITAL PLL LOCK DETECTION

HOLDOVER SPECIFICATIONS

SERIAL PORT SPECIFICATIONS—SPI MODE

SERIAL PORT SPECIFICATIONS—I2C MODE

JITTER GENERATION

ABSOLUTE MAXIMUM RATINGS

ESD CAUTION

PIN CONFIGURATION AND FUNCTION DESCRIPTIONS

TYPICAL PERFORMANCE CHARACTERISTICS

INPUT/OUTPUT TERMINATION RECOMMENDATIONS

GETTING STARTED

POWER-ON RESET

INITIAL M0 TO M7 PIN PROGRAMMING

DEVICE REGISTER PROGRAMMING

THEORY OF OPERATION

OVERVIEW

REFERENCE CLOCK INPUTS

REFERENCE MONITORS

Reference Period Monitor

Reference Validation Timer

Reference Redetect Timer

Reference Validation Override Control

REFERENCE PROFILES

Reference-to-Profile Assignment Control

Reference-to-Profile Assignment State Machine

Reference-to-Profile Assignment

REFERENCE SWITCHOVER

Automatic Priority-Based Reference Switchover

Phase Build-Out Reference Switching

Hitless Reference Switching (Phase Slew Control)

DIGITAL PHASE-LOCKED LOOP (DPLL) CORE

DPLL Overview

Time-to-Digital Converter (TDC)/Phase Frequency Detector (PFD)

Closed-Loop Phase Offset

Programmable Digital Loop Filter

DPLL Phase Lock Detector

DPLL Frequency Lock Detector

DIRECT DIGITAL SYNTHESIZER (DDS)

DDS Overview

DDS Phase Offset

DAC Output

TUNING WORD PROCESSING

Frequency Clamp

Frequency Tuning Word History

LOOP CONTROL STATE MACHINE

Switchover

Holdover

Recovery from Holdover

SYSTEM CLOCK INPUTS

Functional Description

Low Loop Bandwidth Applications Using a TCXO/OCXO

Choosing the System Clock Oscillator Frequency

System Clock Details

SYSCLK PLL MULTIPLIER

Lock Detector
