Page 1
Product datasheet
ENH 250W 120V 24/CS 1/SKU
Product features and benefits
_
Robust construction for reliable, lasting performance
_
Consistent color over the life of the lamps
_
Instant on and nearly constant luminous flux over the life of
the lamp
_
Broad product portfolio supporting the stage and studio
markets
_
Dimmable with traditional amber shift
__
Areas of application
_
Stage and theatre
_
Studio, TV and film
_
Professional Photography
_
Club & Disco
September 9, 2022, 18:50:47 © 2022, OSRAM GmbH. All rights reserved.
Hal with Reflector 93506 250 W 120 V Page 1 of 3
Page 2
Product datasheet
Technical data
General product information
Product Number 54986
Product Name ENH 250W 120V 24/CS 1/SKU
Ordering Abbreviation ENH 250W 120V 24/CS 1/SKU
Brand Name OSRAM
Application Projector - Slide
Product Remark
Electrical data
Nominal Wattage 250 W
Nominal Voltage 120 V
Type of Current AC
_
s (Operating Position) = Vertical, base down
_
Lumens refers to screen lumens.
Light technical data
Luminous Flux 340 lm
Working Distance a (in) 5.948 in
Working Distance a (mm) 152.5 mm
__
Color Rendering Index 100
Average Rated Life 175 h
Physical attributes
Maximum Overall Length (in) 1.735 in
Maximum Overall Length (mm) 44.5 mm
Length l (in) 1.735 in
Length l (mm) 44.5 mm
Length l max. (in) 1.735 in
Length l max. (mm) 44.5 mm
Diameter d (in) 2.008 in
Diameter d (mm) 51.00 mm
Reflector Coating 51.00
Additional product data
Operating Position s 90
Class C (gas)
September 9, 2022, 18:50:47 © 2022, OSRAM GmbH. All rights reserved.
Hal with Reflector 93506 250 W 120 V Page 2 of 3
Page 3
Product datasheet
Packaging Information
Product number EAN/UPC Packaging Quantity Outside dimensions l x w x h Gross weight
54986 4050300349930 Folding box (SKU) 1 1.7 in x 1.7 in x 2.2 in 0.1 lb
54986 4050300349947 Shipping box (Case) 24 7.6 in x 5.3 in x 6 in 2.1 lb
The mentioned product code describes the smallest quantity unit which can be ordered. One shipping unit can contain one or
more single products. When placing an order, for the quantity please enter single or multiples of a shipping unit.
Disclaimer
OSRAM does not accept liability for errors, changes and omissions.
__
September 9, 2022, 18:50:47 © 2022, OSRAM GmbH. All rights reserved.
Hal with Reflector 93506 250 W 120 V Page 3 of 3
