Datasheet 93181 Specification

L

4 1

USB-A plug

USB 2.0 HIGH SPEED MINI CABLE

1
5

Ø4.0±0.2

USB-A M Micro-USB-B M

1 Vcc
2 D­3 D+

4 GND
SHELL SHELL

Nr. / No. Länge / Length (m)

95736 0.15

95735 0.30

93922 0.60

93918 1.00

93181 1.80

93920 3.00

93921 5.00

1 Vcc
2 D­3 D+
4 ID
5 GND

Micro-USB Daten- und Ladekabel

- Verbinder: USB-A Stecker > Micro USB-B St.

- Innenleiter: AWG28 (4 x 7/0.12 mm) Kupfer

- Isolierung: PVC; schwarz

- Schirmung: doppelt; 1 mm AL-Folie +
(44/0.12 mm) Geflecht

- USB Standard: High Speed USB 2.0

- Datenrate: max. 480 Mbit/s

- RoHS-konform

Micro USB data and charging cable

- USB-A plug > Micro USB-B plug

- Inner conductor: AWG28 (4 x 7/0.12 mm) copper

- Insulation: PVC; black

- Shielding: double; 1 mm AL foil +
(44/0.12 mm) Braiding

- USB Standard: High Speed USB 2.0

- Data rate: max. 480 Mbps

- RoHS compliant

11.08.2016

30.07.2014

30.07.2014

USB MICRO-B SCHWARZ
