74F109 Dual JK Positive Edge-Triggered Flip-Flop

74F109
Dual JK

Positive Edge-Triggered Flip-Flop

General Description

The F109 consists of two high-spe ed, com pletel y indepe n­dent transition clocked JK

flip-flops. The clocking operat i on
is independent of rise and fal l tim es o f th e cl oc k wave for m.
The JK

design allows operati on as a D-type f lip-flop ( refer

to F74 data sheet) by connecting the J and K

inputs.

Asynchronous Inputs:

LOW input to S

D

sets Q to HIGH level

LOW input to C

D

sets Q to LOW level

Clear and Set are independent of clock
Simultaneous LOW on C

D

and SD makes

both Q and Q

HIGH

Ordering Code:

Devices also availab le in Tape and Reel. Specify by appending su ffix let te r “X” to the ordering code.

Logic Symbols

IEEE/IEC

Connection Diagram

Order Number Package Number Package Description

74F109SC M16A 16-Lead Small Outline Integrated Circuit (SOIC), JEDEC MS-012, 0.150” Narrow Body
74F109SJ M16D 16-Lead Small Outline Package (SOP), EIAJ TYPE 11, 5.3mm Wide
74F109PC N16E 16-Lead Plastic Dual-In-Line Package (PDIP), JEDEC MS-001, 0.300” Wide

www.fairchildsemi.com 2

74F109

Truth Table

H (h) = HIGH Voltage Level

L (l) = LOW Voltage Level



= LOW-to-HIGH Transition

X = Immaterial
Q0 (Q0) = Before LOW-to-HIGH Transition of Clock
Lower case letters indicate the state of the referenced output one setup time prior to the LOW-to-HIGH clock transition.

Unit Loading/Fan Out

Block Diagram

Please note that this diagram is provided only for the understanding of logic operations and should not be used to estimate propagation delays.

Inputs Outputs

S

D

C

D

CP J K QQ

LHXXXHL
HLXXXLH
LLXXXHH
HH



IILH

HH



hI Toggle

HH



IhQQ

HH



hhHL

HHLXXQQ

Pin Names Description

U.L. Input I

IH/IIL

HIGH/LOW Output IOH/I

OL

J1, J2, K1, K2Data Inputs 1.0/1.0 20 µA/−0.6 mA
CP

1

, CP

2

Clock Pulse Inputs (Active Rising Edge) 1.0/1.0 20 µA/−0.6 mA

C

D1

, C

D2

Direct Clear Inputs (Active LOW) 1.0/3.0 20 µA/−1.8 mA

S

D1

, S

D2

Direct Set Inputs (Active LOW) 1.0/3.0 20 µA/−1.8 mA

Q

1

, Q2, Q1, Q2Outputs 50/33.3 −1 mA/20 mA

3 www.fairchildsemi.com

74F109

Absolute Maximum Ratings(Note 1) Recommended Operating

Conditions

Note 1: Absolute maximum ratings are values beyond which the device

may be damaged or have its useful life impaired . Functional operation
under these conditions is not implied.

Note 2: Either voltage lim it or c urrent limit is sufficient to pro te c t in puts.

DC Electrical Characteristics

Storage Temperature −65°C to +150°C
Ambient Temperature under Bias −55°C to +125°C
Junction Temperature under Bias −55°C to +175°C
V

CC

Pin Potential to

Ground Pin −0.5V to +7.0V
Input Voltage (Note 2) −0.5V to +7.0V
Input Current (Note 2) −30 mA to +5.0 mA
Voltage Applied to Output

in HIGH State (with V

cc

= 0V)

Standard Output −0.5V to V

CC

3-STATE Output −0.5V to +5.5V
Current Applied to Output

in LOW State (Max) twice the rated I

OL

(mA)

Free Air Ambient Temperature 0°C to +70°C
Supply Voltage +4.5V to +5.5V

Symbol Parameter Min Typ Max Units

V

CC

Conditions

V

IH

Input HIGH Voltage 2.0 V Recognized as a HIGH Signal

V

IL

Input LOW Voltage 0.8 V Recognized as a LOW Signal

V

CD

Input Clamp Diode Voltage −1.2 V Min IIN = −18 mA

V

OH

Output HIGH Voltage 10% V

CC

2.5
VMin

IOH = −1 mA

5% V

CC

2.7 IOH = −1 mA

V

OL

Output LOW Voltage 10% V

CC

0.5 V Min IOL = 20 mA

I

IH

Input HIGH Current 5.0 µAMaxVIN = 2.7V

I

BVI

Input HIGH Current Breakdown Test 7.0 µAMaxVIN = 7.0V

I

CEX

Output HIGH Leakage Current 50 µAMaxV

OUT

= V

CC

V

ID

Input Leakage Test

4.75 V 0.0

IID = 1.9 µA
All Other Pins Grounded

I

OD

Output Leakage

3.75 µA0.0

V

IOD

= 150 mV

Circuit Current All Other Pins Grounded

I

IL

Input LOW Current −0.6 mA Max VIN = 0.5V (Jn, Kn)

−1.8 mA Max VIN = 0.5V (CDn, SDn)

I

OS

Output Short-Circuit Current −60 −150 mA Max V

OUT

= 0V

I

CC

Power Supply Current 11.7 17.0 mA Max CP = 0V

www.fairchildsemi.com 4

74F109

AC Electrical Characteristics

AC Operating Requirements

Symbol Parameter

TA = +25°CT

A

= 0°C to +70°C

Units

V

CC

= +5.0V VCC = +5.0V

C

L

= 50 pF CL = 50 pF

Min Typ Max Min Max

f

MAX

Maximum Clock Frequency 100 125 90 MHz

t

PLH

Propagation Delay 3.8 5.3 7.0 3.8 8.0

ns

t

PHL

CPn to Qn or Q

n

4.4 6.2 8.0 4.4 9.2

t

PLH

Propagation Delay 3.2 5.2 7.0 3.2 8.0 ns

t

PHL

CDn or SDn to

3.5 7.0 9.0 3.5 10.5 ns

Qn or Q

n

Symbol Parameter

T

A

= +25°CT

A

= 0°C to +70°C

UnitsV

CC

= +5.0V VCC = +5.0V

Min Max Min Max

t

S

(H) Setup Time, HIGH or LOW 3.0 3.0

ns

tS(L) Jn or Kn to CP

n

3.0 3.0
tH(H) Hold Time, HIGH or LOW 1.0 1.0
tH(L) Jn or Kn to CP

n

1.0 1.0
tW(H) CPn Pulse Width 4.0 4.0

ns

tW(L) HIGH or LOW 5.0 5.0
t

W

(L) CDn or SDn Pulse Width LOW 4.0 4.0 ns

t

REC

Recovery Time

2.0 2.0 ns

CDn or SDn to CP

5 www.fairchildsemi.com

74F109

Physical Dimensions inches (millimeters) unless otherwise noted

16-Lead Small Outline Integrated Circuit (SOIC), JEDEC MS-012, 0.150” Narrow Body

Package Number M16A

www.fairchildsemi.com 6

74F109

Physical Dimensions inches (millimeters) unless otherwise noted (Continued)

16-Lead Small Outline Package (SOP), EIAJ TYPE II, 5.3mm Wide

Package Number M16D

7 www.fairchildsemi.com

74F109 Dual JK Positive Edge-Triggered Flip-Flop

Physical Dimensions inches (millimeters) unless otherwise noted (Continued)

16-Lead Plastic Dual-In- Line Package (PDIP), JEDEC MS-001, 0.300” Wide

Package Number N16E
