54LCX16374
Low Voltage 16-Bit D Flip-Flop with 5V Tolerant Inputs
and Outputs
General Description
The LCX16374 contains sixteen non-inverting D flip-flops
with TRI-STATE
®
outputs and is intended for bus oriented
applications. The device is byte controlled. A buffered clock
(CP) and OutputEnable (OE) are common to each byte and
can be shorted together for full 16-bit operation.
The LCX16374 is designed for low voltage (3.3V) V
CC
applications with capability of interfacing to a 5V signal environment.
The LCX16374 is fabricated with an advanced CMOS technology to achieve high speed operation while maintaining
CMOS low power dissipation.
Features
n 5V tolerant inputs and outputs
n Power down high impedance inputs and outputs
n Supports live insertion/withdrawal
n 2.0V–3.6V V
CC
supply operation
n
±
24 mA output drive
n Implements patented noise/EMI reduction circuitry
n Functionally compatible with the 54 series 16374
n ESD performance:
Human body model
>
2000V
Machine model
>
200V
n Standard Microcircuit Drawing (SMD) 5962-99535
Ordering Code
Order Number Package Number Package Description
54LCX16374W-QML WA48A 48-Lead Ceramic Flatpack
Logic Symbol
Pin Descriptions
Pin Description
Names
OE
n
Output Enable Input (Active Low)
CP
n
Clock Pulse Input
I
0–I15
Inputs
O
0–O15
Outputs
Connection Diagram
TRI-STATE®is a registered trademark of National Semiconductor Corporation.
DS101199-1
Pin Assignment for
Cerpack
DS101199-2
July 1999
54LCX16374 Low Voltage 16-Bit D Flip-Flop with 5V Tolerant Inputs and Outputs
© 1999 National Semiconductor Corporation DS101199 www.national.com
Page 2
Functional Description
The LCX16374 consists of sixteen edge-triggered flip-flops
with individual D-type inputs andTRI-STATE true outputs.
The device is byte controlled with each byte functioning identically, but independent of the other. The control pins can be
shorted together to obtain full 16-bit operation. Each byte
has a buffered clock and buffered Output Enable common to
all flip-flops within that byte. The description which follows
applies to each byte. Each flip-flop will store the state of their
individual D inputs that meet the setup and hold time requirements on the LOW-to-HIGH Clock (CP
n
) transition. With the
Output Enable (OE
n
) LOW, the contents of the flip-flops are
available at the outputs. When OEnis HIGH, the outputs go
to the high impedance state. Operation of the OEninput
does not affect the state of the flip-flops.
Inputs Outputs
CP
1
OE
1
I0–I
7
O0–O
7
LH H
LL L
LL X O
0
XH X Z
Inputs Outputs
CP
2
OE
2
I8–I
15
O8–O
15
LH H
LL L
LL X O
0
XH X Z
H
=
High Voltage Level
L=Low Voltage Level
X=Immaterial
Z=High Impedance
O
0
=
Previous O
0
before HIGH to LOW of CP
Logic Diagrams
Byte 1 (0:7)
DS101199-3
Byte 2 (8:15)
DS101199-4
Please note that this diagram is provided only for the understanding of logic operations and should not be used to estimate propagation delays.
www.national.com 2
Page 3
Absolute Maximum Ratings (Note 1)
If Military/Aerospace specified devices are required,
please contact the National Semiconductor Sales Office/
Distributors for availability and specifications.
Supply Voltage (V
CC
) −0.5V to +7.0V
DC Input Voltage (V
I
) −0.5V to +7.0V
DC Input Diode Current (I
IK
)
V
I
<
GND −50 mA
DC Output Diode Current (I
OK
)
V
O
<
GND −50mA
V
O
≥ V
CC
+50mA
DC Output Voltage (V
O
) (Note
2)
Output in High or Low State -0.5V to V
CC
+ 0.5V
Output in TRI-STATE -0.5V to 7.0V
DC Output Source or Sink
Current (I
O
)
±
50mA
DC V
CC
or Ground Current
±
100mA
Storage Temperature Range
(T
STG
) −65˚C to +150˚C
Power Dissapation 750mW
Junction Temperature (T
J
) 175˚C
Recommended Operating
Conditions
(Note 3)
Supply Voltage (V
CC
)
Operating 2.0V to 3.6V
Data Retention 1.5V to 3.6V
Input Voltage (V
I
) 0V to 5.5V
Output Voltage (V
O
)
High or Low State 0V to V
CC
TRI-STATE 0V to 5.5V
Operating Temperature (T
A
) −55˚C to
+125˚C
Minimum Input Edge Rate (∆t/∆V)
V
IN
from 0.8V to 2.0V, VCC= 3.0V 0ns/V to 10ns/V
Note 1: The Absolute Maximum Ratings are those values beyond which the
safety of the device cannot be guaranteed. The device should not be operated at these limits. The parametric values defined in the Electrical Characteristics tables are not guaranteed at the Absolute Maximum Ratings. The
“Recommended Operating Conditions” table will define the conditions for actual device operation.
Note 2: I
O
Absolute Maximum Rating must be observed.
Note 3: Unused inputs must be held HIGH or LOW. They may not float.
DC Electrical Characteristics
Symbol Parameter Conditions V
CC
T
A
=
−55˚C to +125˚C Units
(V) Min Max
V
IH
HIGH Level Input Voltage 2.7–3.6 2.0 V
V
IL
LOW Level Input Voltage 2.7–3.6 0.8 V
V
OH
HIGH Level Output Voltage I
OH
=
−100 µA 2.7–3.6 V
CC
− 0.2 V
I
OH
=
−12 mA 2.7 2.2 V
I
OH
=
−12 mA 3.0 2.4 V
I
OH
=
−24 mA 3.0 2.2 V
V
OL
LOW Level Output Voltage I
OL
=
100 µA 2.7–3.6 0.2 V
I
OL
=
12 mA 2.7 0.4 V
I
OL
=
24 mA 3.0 0.55 V
I
I
Input Leakage Current 0 ≤ VI≤ 5.5V 2.7–3.6
±
5.0 µA
I
OZ
3-STATE Output Leakage 0 ≤ VO≤ 5.5V 2.7–3.6
±
5.0 µA
V
I
=
V
IH
or V
IL
I
OFF
Power-Off Leakage Current VIor V
O
=
5.5V 0 10 µA
I
CC
Quiescent Supply Current V
I
=
V
CC
or GND 2.7–3.6 20 µA
3.6V ≤ V
I,VO
≤5.5V 2.7–3.6
±
20 µA
∆I
CC
Increase in ICCper Input V
IH
=
V
CC
−0.6V 2.7–3.6 500 µA
www.national.com3
Page 4
AC Electrical Characteristics
Symbol Parameter
T
A
=
−55˚C to +125˚C, C
L
=
50pF, R
L
=
500Ω
UnitsV
CC
=
3.3V
±
0.3V V
CC
=
2.7V
Min Max Min Max
f
MAX
Maximum Clock Frequency 200 200 MHz
t
PHL
Propagation Delay 0.5 6.5 1.0 7.0 ns
t
PLH
CP to O
n
0.5 6.5 1.0 7.0
t
PZL
Output Enable Time 0.5 6.5 1.0 7.0 ns
t
PZH
0.5 6.5 1.0 7.0
t
PLZ
Output Disable Time 1.0 6.5 1.0 7.0 ns
t
PHZ
1.0 6.5 1.0 7.0
t
S
Setup Time 3.5 3.5 ns
t
H
Hold Time 2.0 2.0 ns
t
W
Pulse Width 4.0 4.0 ns
t
OSHL
Output to Output Skew (Note 4) 1.0 1.0 ns
t
OSLH
1.0 1.0
Note 4: Skew is defined as the absolute value of the difference between the actual propagation delay for any two seperate outputs of the same device. The specification applies to any outputs switching in the same direction, either HIGH to LOW (t
OSHL
) or LOW to HIGH (t
OSLH
). Parameter guaranteed by design.
Dynamic Switching Characteristics
Symbol Parameter Conditions
V
CC
(V)
T
A
=
25˚C
Units
Max
V
OLP
Quiet Output Dynamic Peak V
OL
C
L
=
50 pF, V
IH
=
3.3V, V
IL
=
0V 3.3 1.2 V
V
OLV
Quiet Output Dynamic Valley V
OL
C
L
=
50 pF, V
IH
=
3.3V, V
IL
=
0V 3.3 -1.1 V
Capacitance
Symbol Parameter Conditions Max Units
C
IN
Input Capacitance V
CC
=
Open, V
I
=
0V or V
CC
10 pF
C
OUT
Output Capacitance V
CC
=
3.3V, V
I
=
0V or V
CC
12 pF
C
PD
Power Dissipation Capacitance V
CC
=
3.3V, V
I
=
0V or V
CC
,f=10 MHz 40 pF
www.national.com 4
