54ACT823
9-Bit D Flip-Flop
General Description
TheACT823 is a 9-bit buffered register. It features Clock Enable and Clear which are ideal for parity bus interfacing in
high performance microprogramming systems. The ACT823
offers noninverting outputs and is fully compatible with
AMD’s Am29823.
Features
n Outputs source/sink 24 mA
n TRI-STATE outputs for bus interfacing
n Inputs and outputs are on opposite sides
n ACT823 has TTL-compatible inputs
n Standard Microcircuit Drawing (SMD) 5962-9161001
Ordering Code
Order Number Package Number Package Description
54ACT823DMQB J24A 24-Lead Ceramic Dual-in-line
54ACT823FMQB W24C 24-Lead Cerpack
54ACT823LMQB E28A 28-Lead Ceramic Leadless Chip Carrier, Type C
Logic Symbols
Pin Names Description
D
0–D8
Data Inputs
O
0–O8
Data Outputs
OE
Output Enable
CLR
Clear
CP Clock Input
EN
Clock Enable
FACT™is a trademark of Fairchild Semiconductor Corporation.
TRI-STATE
™
is a trademark of National Semiconductor Corporation.
DS100253-1
IEEE/IEC
DS100253-2
August 1998
54ACT823 9-Bit D Flip-Flop
© 1998 National Semiconductor Corporation DS100253 www.national.com
Page 2
Connection Diagrams
Pin Assignment for DIP
and Cerpack
DS100253-3
Pin Assignment
for LCC
DS100253-4
www.national.com 2
Page 3
Functional Description
The ACT823 consists of nine D-type edge-triggered
flip-flops. These have TRI-STATE outputs for bus systems
organized with inputs and outputs on opposite sides. The
buffered clock (CP) and buffered Output Enable (OE) are
common to all flip-flops. The flip-flops will store the state of
their individual D inputs that meet the setup and hold time requirements on the LOW-to-HIGH CP transition. With OE
LOW, the contents of the flip-flops are available at the outputs. When OE is HIGH, the outputs go to the high impedance state. Operation of the OE input does not affect the
state of the flip-flops. In addition to the Clock and Output En-
able pins, there are Clear (CLR) and Clock Enable (EN) pins.
These devices are ideal for parity bus interfacing in high performance systems.
When CLR is LOW and OE is LOW, the outputs are LOW.
When CLR is HIGH, data can be entered into the flip-flops.
When EN is LOW, data on the inputs is transferred to the
outputs on the LOW-to-HIGH clock transition. When the EN
is HIGH, the outputs do not change state, regardless of the
data or clock input transitions.
Function Table
Inputs Internal Output Function
OE
CLR EN CP D Q O
H X L N L L Z High Z
H X L N H H Z High Z
H L X X X L Z Clear
L L X X X L L Clear
H H H X X NC Z Hold
L H H X X NC NC Hold
H H L N L L Z Load
H H L N H H Z Load
L H L N L L L Load
L H L N H H H Load
H=HIGH Voltage Level
L=LOW Voltage Level
X=Immaterial
Z=High Impedance
N=LOW-to-HIGH Transition
NC=No Change
Logic Diagram
DS100253-5
Please note that this diagram is provided only for the understanding of logic operations and should not be used to estimate propagation delays.
3 www.national.com
Page 4
Absolute Maximum Ratings (Note 1)
If Military/Aerospace specified devices are required,
please contact the National Semiconductor Sales Office/
Distributors for availability and specifications.
Supply Voltage (V
CC
) −0.5V to 7.0V
DC Input Diode Current (I
IK
)
V
I
=
−0.5V −20 mA
V
I
=
V
CC
+ 0.5V +20 mA
DC Input Voltage (V
I
) −0.5V to VCC+ 0.5V
DC Output Diode Current (I
OK
)
V
O
=
−0.5V −20 mA
V
O
=
V
CC
+ 0.5V +20 mA
DC Output Voltage (V
O
) −0.5V to VCC+ 0.5V
DC Output Source or Sink Current
(I
O
)
±
50 mA
DC V
CC
or Ground Current
per Output Pin (I
CC
or I
GND
)
±
50 mA
Storage Temperature (T
STG
) −65˚C to +150˚C
Junction Temperature (T
J
)
CDIP 175˚C
Recommended Operating
Conditions
Supply Voltage (VCC)
ACT 4.5V to 5.5V
Input Voltage (V
I
) 0VtoV
CC
Output Voltage (VO) 0VtoV
CC
Operating Temperature (TA)
54ACT −55˚C to +125˚C
Minimum Input Edge Rate (∆V/∆t)
ACT Devices
V
IN
from 0.8V to 2.0V
V
CC
@
4.5V, 5.5V 125 mV/ns
Note 1: Absolute maximum ratings are those values beyond which damage
to the device may occur. The databook specifications should be met, without
exception, to ensure that the system design is reliable over its power supply,
temperature, and output/input loading variables. National does not recommend operation of FACT
™
circuits outside databook specifications.
DC Electrical Characteristics
Symbol Parameter V
CC
T
A
=
Units Conditions
(V) −55˚C to +125˚C
V
IH
Minimum High Level 4.5 2.0 V V
OUT
=
0.1V
Input Voltage 5.5 2.0 or V
CC
−0.1V
V
IL
Maximum Low Level 4.5 0.8 V V
OUT
=
0.1V
Input Voltage 4.5 0.8 or V
CC
−0.1V
V
OH
Minimum High Level
Output Voltage
4.5 3.7
V
I
OH
=
−24 mA
V
OL
Maximum Low Level
Output Voltage
4.5 0.5
V
I
OL
=
24 mA
I
IN
Maximum Input
Leakage Current
5.5
±
1.0 µA V
I
=
V
CC
, GND
I
OZ
Maximum TRI-STATE 5.5
±
10.0 µA V
I
=
V
IL,VIH
Current V
O
=
V
CC
, GND
I
CCT
Maximum ICC/Input 5.5 1.6 mA V
I
=
V
CC
−2.1V
I
OLD
(Note 3) Minimum
Dynamic Output
Current
5.5 50 mA V
OLD
=
1.65V Max
I
OHD
5.5 −50 mA V
OHD
=
3.85V Min
I
CC
Maximum Quiescent 5.5 160 µA V
IN
=
V
CC
Supply Current or GND
Note 2: All outputs loaded; thresholds on input associated with output under test.
Note 3: Maximum test duration 2.0 ms, one output loaded at a time.
AC Electrical Characteristics
Symbol Parameter V
CC
(V)
(Note 4)
T
A
=
−55˚C to +125˚C
C
L
=
50 pF
Units
Min Max
f
max
Maximum Clock 5.0 95 MHz
Frequency
t
PLH
Propagation Delay 5.0 1.0 12.0 ns
CP to O
n
www.national.com 4
Page 5
AC Electrical Characteristics (Continued)
Symbol Parameter V
CC
(V)
(Note 4)
T
A
=
−55˚C to +125˚C
C
L
=
50 pF
Units
Min Max
t
PHL
Propagation Delay 5.0 1.0 12.0 ns
CP to O
n
t
PHL
Propagation Delay 5.0 1.0 18.0 ns
CLR to O
n
t
PZH
Output Enable Time 5.0 1.0 11.5 ns
OE to O
n
t
PZL
Output Enable Time 5.0 1.0 12.0 ns
OE to O
n
t
PHZ
Output Disable Time 5.0 1.0 13.5 ns
OE to O
n
t
PLZ
Output Disable Time 5.0 1.0 12.0 ns
OE to O
n
Note 4: Voltage Range 5.0 is 5.0V±0.5V
AC Operating Requirements
Symbol Parameter VCC(V)
(Note 5)
T
A
=
−55˚C to +125˚C
C
L
=
50 pF
Units
Guaranteed Minimum
t
s
Setup Time, HIGH or LOW 5.0 4.0 ns
DtoCP
t
h
Hold Time, HIGH or LOW 5.0 3.0 ns
D
n
to CP
t
s
Setup Time, HIGH or LOW 5.0 4.0 ns
EN to CP
t
h
Hold Time, HIGH or LOW 5.0 3.0 ns
EN to CP
t
w
CP Pulse Width 5.0 6.0 ns
HIGH or LOW
t
w
CLR Pulse Width, LOW 5.0 7.5 ns
t
rec
CLR to CP 5.0 4.5 ns
Recovery Time
Note 5: Voltage Range 5.0 is 5.0V±0.5V
5 www.national.com
Page 6
Capacitance
Symbol Parameter Max Units Conditions
C
IN
Input Capacitance 4.5 pF V
CC
=
OPEN
C
PD
Power Dissipation
Capacitance
4.4 pF V
CC
=
5.0V
www.national.com 6
Page 7
Physical Dimensions inches (millimeters) unless otherwise noted
24 Lead Ceramic Dual-in-line
Package Number J24A
24 Lead Cerpack
Package Number W24C
7 www.national.com
Page 8
Physical Dimensions inches (millimeters) unless otherwise noted (Continued)
LIFE SUPPORT POLICY
NATIONAL’S PRODUCTS ARE NOT AUTHORIZED FOR USE AS CRITICAL COMPONENTS IN LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT THE EXPRESS WRITTEN APPROVAL OF THE PRESIDENT OF NATIONAL SEMICONDUCTOR CORPORATION. As used herein:
1. Life support devices or systems are devices or systems which, (a) are intended for surgical implant into
the body, or (b) support or sustain life, and whose failure to perform when properly used in accordance
with instructions for use provided in the labeling, can
be reasonably expected to result in a significant injury
to the user.
2. A critical component in any component of a life support
device or system whose failure to perform can be reasonably expected to cause the failure of the life support
device or system, or to affect its safety or effectiveness.
National Semiconductor
Corporation
Americas
Tel: 1-800-272-9959
Fax: 1-800-737-7018
Email: support@nsc.com
www.national.com
National Semiconductor
Europe
Fax: +49 (0) 1 80-530 85 86
Email: europe.support@nsc.com
Deutsch Tel: +49 (0) 1 80-530 85 85
English Tel: +49 (0) 1 80-532 78 32
Français Tel: +49 (0) 1 80-532 93 58
Italiano Tel: +49 (0) 1 80-534 16 80
National Semiconductor
Asia Pacific Customer
Response Group
Tel: 65-2544466
Fax: 65-2504466
Email: sea.support@nsc.com
National Semiconductor
Japan Ltd.
Tel: 81-3-5620-6175
Fax: 81-3-5620-6179
28 Lead Ceramic Leadless Chip Carrier
Package Number E28A
54ACT823 9-Bit D Flip-Flop
National does not assume any responsibility for use of any circuitry described, no circuit patent licenses are implied and National reserves the right at any time without notice to change said circuitry and specifications.
