E cores and accessories E55/28/21
CORE SETS
Effective core parameters
SYMBOL PARAMETER VALUE UNIT
Σ(I/A) core factor (C1) 0.350 mm
V
e
I
e
A
e
A
min
effective volume 44000 mm
effective length 124 mm
effective area 353 mm
minimum area 345 mm
m mass of core half ≈ 108 g
handbook, halfpage
−1
3
2
2
R < 0.6
Dimensions in mm.
56.2
37.5
17.2
0
−2.1
+1.5
0
0
−0.5
CBW063
18.5
21.0
+0.8
R3
0
0
−0.8
27.5
±0.3
Fig.1 E55/28/21 core half.
Core halves
A
measured in combination with a non-gapped core half, clamping force for AL measurements 40 ±20 N, unless stated
L
otherwise.
A
GRADE
L
(nH)
3C81 100 ±5%
160 ±5%
250 ±5%
315 ±5%
400 ±8%
630 ±10%
(1)
(1)
(1)
(1)
(1)
(1)
µ
e
≈ 28 ≈ 8740 E55/28/21-3C81-E100
≈ 45 ≈ 4560 E55/28/21-3C81-E160
≈ 70 ≈ 2500 E55/28/21-3C81-E250
≈ 88 ≈ 1840 E55/28/21-3C81-E315
≈ 112 ≈ 1360 E55/28/21-3C81-E400
≈ 176 ≈ 780 E55/28/21-3C81-E630
TOTAL AIR GAP
(µm)
TYPE NUMBER
8625 ±25% ≈ 2410 ≈ 0 E55/28/21-3C81
3C90 100 ±5%
160 ±5%
250 ±5%
315 ±5%
400 ±8%
630 ±10%
(1)
(1)
(1)
(1)
(1)
(1)
≈ 28 ≈ 8740 E55/28/21-3C90-E100
≈ 45 ≈ 4560 E55/28/21-3C90-E160
≈ 70 ≈ 2500 E55/28/21-3C90-E250
≈ 88 ≈ 1840 E55/28/21-3C90-E315
≈ 112 ≈ 1360 E55/28/21-3C90-E400
≈ 176 ≈ 780 E55/28/21-3C90-E630
6300 ±25% ≈ 1760 ≈ 0 E55/28/21-3C90
3C91 8625 ±25% ≈ 2410 ≈ 0 E55/28/21-3C91
3C92 4700 ±25% ≈ 1310 ≈ 0 E55/28/21-3C92
3C94 6400 ±25% ≈ 1790 ≈ 0 E55/28/21-3C94
2008 Sep 01 435
Page 3
Ferroxcube
E cores and accessories E55/28/21
GRADE
A
L
(nH)
µ
e
TOTAL AIR GAP
(µm)
TYPE NUMBER
3C95 8625 ±25% ≈ 2410 ≈ 0 E55/28/21-3C95
3F3 100 ±5%
160 ±5%
250 ±5%
315 ±5%
400 ±8%
630 ±10%
(1)
(1)
(1)
(1)
(1)
(1)
≈ 28 ≈ 8740 E55/28/21-3F3-E100
≈ 45 ≈ 4560 E55/28/21-3F3-E160
≈ 70 ≈ 2500 E55/28/21-3F3-E250
≈ 88 ≈ 1840 E55/28/21-3F3-E315
≈ 112 ≈ 1360 E55/28/21-3F3-E400
≈ 176 ≈ 780 E55/28/21-3F3-E630
5700 ±25% ≈1590 ≈ 0 E55/28/21-3F3
Note
1. Measured in combination with an equal gapped core half.
Properties of core sets under power conditions
B (mT) at CORE LOSS (W) at
GRADE
H = 250 A/m;
f = 25 kHz;
T = 100 °C
f = 25 kHz;
ˆ
= 200 mT;
B
T = 100 °C
f=100kHz;
ˆ
= 100 mT;
B
T = 100 °C
f = 100 kHz;
ˆ
=200mT;
B
T=25°C
f = 100 kHz;
ˆ
= 200 mT;
B
T=100°C
f = 400 kHz;
ˆ
=50mT;
B
T = 100 °C
3C81 ≥320 ≤ 9.0 −− − −
3C90 ≥320 ≤ 4.8 ≤ 5.9 −−−
3C91 ≥320 −≤ 3.5
(1)
−≤ 20
(1)
−
3C92 ≥370 −≤ 3.8 −≤ 27 −
3C94 ≥320 −≤ 3.8 −≤ 27 −
3C95 ≥320 −−≤ 27.7 ≤ 26.4 −
3F3 ≥320 −≤ 5.6 −−≤ 10
Note
1. Measured at 60 °C.
2008 Sep 01 436
Page 4
Ferroxcube
E cores and accessories E55/28/21
COIL FORMERS
General data for E55/28/21 coil former without pins
PARAMETER SPECIFICATION
Coil former material polyamide (PA6.6), glass reinforced, flame retardant in accordance with
“UL 94-HB”; UL file number E41613(M)
Maximum operating temperature 130 °C, “IEC 60 085”, class B
3 ±0.1
(5×)
handbook, full pagewidth
1 ±0.1
Dimensions in mm.
0
20
−0.2
+0.2
17.6
0
24.2 ±0.2
0
37
−0.2
2 ±0.1
(6×)
5 ±0.1
+0.2
33.2
0
35.7 ±0.1
38.8 ±0.2
Fig.2 E55/28/21 coil former (E).
Winding data and area product for E55/28/21 coil former without pins (E)
21.7
+0.2
0
23.8
0
−0.2
43.5
CBW064
0
−0.2
NUMBER OF
SECTIONS
MINIMUM
WINDING
AREA
2
(mm
)
MINIMUM
WINDING
WIDTH
(mm)
AVERAGE
LENGTH OF
TURN
(mm)
AREA
PRODUCT
Ae x Aw
(mm4)
TYPE NUMBER
1 250 33.2 116 88250 CP-E55/28/21-1S
2008 Sep 01 437
Page 5
Ferroxcube
E cores and accessories E55/28/21
General data for E55/28/21 coil former without pins (A)
PARAMETER SPECIFICATION
Coil former material polyamide (PA6.6), glass reinforced, flame retardant in accordance with
“UL 94-HB”; UL file number E41938(M)
Maximum operating temperature 130 °C, “IEC 60 085”, class B
handbook, full pagewidth
Dimensions in mm.
42.15
max.
21.1
min.
36.6
19
16.9
37
33.7
Fig.3 E55/28/21 coil former (A).
Winding data and area product for E55/28/21 coil former without pins (A)
NUMBER OF
SECTIONS
MINIMUM
WINDING
AREA
2
(mm
)
NOMINAL
WINDING
WIDTH
(mm)
AVERAGE
LENGTH OF
TURN
(mm)
1 277 33.7 113 97800 CP-E55/28/21-1S-A
AREA
PRODUCT
Ae x Aw
(mm4)
CBW065
TYPE NUMBER
2008 Sep 01 438
Page 6
Ferroxcube
E cores and accessories E55/28/21
General data for 14-pins E55/28/21 coil former
PARAMETER SPECIFICATION
Coil former material polyamide (PA6.6), glass reinforced, flame retardant in accordance with
“UL 94-HB”; UL file number E41938(M)
Pin material copper-zinc alloy (CuZn), tin (Sn) plated
Maximum operating temperature 105 °C, “IEC 60 085”, class A
Resistance to soldering heat “IEC 60068-2-20”, Part 2, Test Tb, method 1B: 350 °C, 3.5 s
Solderability “IEC 60068-2-20”, Part 2, Test Ta, method 1: 235 °C, 2 s
handbook, full pagewidth
Dimensions in mm.
44.2
max.
7.4
min.
37.35 max.
17.45 min.
5
19.75
1.15
21.15
min.
CBW066
Fig.4 E55/28/21 coil former; 14-pins.
Winding data and area product for 14-pins E55/28/21 coil former
0.4
35.65 max.
33
40.15
43.95 max.
23.7
4.3 min.
NUMBER OF
SECTIONS
MINIMUM
WINDING
AREA
2
(mm
)
NOMINAL
WINDING
WIDTH
(mm)
AVERAGE
LENGTH OF
TURN
(mm)
AREA
PRODUCT
Ae x Aw
(mm4)
TYPE NUMBER
1 278 33 119 98100 CPH-E55/28/21-1S-14P-Z
2008 Sep 01 439
Page 7
Ferroxcube
E cores and accessories E55/28/21
MOUNTING PARTS GENERAL DATA FOR MOUNTING PARTS
ITEM REMARKS FIGURE TYPE NUMBER
Clasp steel, zinc (Zn) plated 5 CLA-E55/28/21
Spring steel, zinc (Zn) plated 6 SPR-E55/28/21
58.8 max.
handbook, full pagewidth
35 27.942123.5
Dimensions in mm.
handbook, full pagewidth
2.8
50.8
44
4
∅9
65.3 max.
CBW495
Fig.5 E55/28/21 clasp.
+0.5
6.8
0
0.2
min.
21 ±0.2
Dimensions in mm.
4.2
60.2 ±0.2
24.3
46
CBW068
56.1
Fig.6 E55/28/21 spring.
2008 Sep 01 440
Page 8
Ferroxcube
E cores and accessories E55/28/21
