Datasheet 38521 Specification

Verpackung

/ Pack ing

Innenleiter /

Inner conductor

7/0.192 BC

(#28)

1/0.254 TC

/ Innenleiter

/ Isolation

/ Folienschirmung

/ Drainage
/ Geflecht

/ Kabelmantel PVC

Nr. / No. Kabellänge / Cable length (m)

38514 0.50 bulk
45880 0.50 SB
38515 1.00 bulk
45881 1.00 SB
38516 1.50 bulk
45882 1.50 SB
38517 2.00 bulk
45883 2.00 SB
38518 3.00 bulk
45884 3.00 SB
38519 5.00 bulk
45885 5.00 SB

38520 7.50 bulk

45886 7.50 SB

38521 10.00 bulk

45887 10.00 SB

38522 15.00 bulk

1/0.254 CCS

1/0.320 BC

1/0.254 CCS

7/0.152 BC

1/0.254 BC

1/0.320 BC

7/0.152 BC

1/0.254 BC

(#30)

(#30)

(#28),

(#30)

(#26),

(#30)

(#24),

(#26),

(#30)

Ø (mm)

6.0±0.2

7.0±0.2

8.0±0.3

10.0±0.4

8.0±0.3bulk20.00 w. amplifier38523

18.09.2017 tf

18.09.2017 tf

Änderungen vorbehalten / Subject to change

High Speed HDMI™ Kabel mit Ethernet

- HighSpeed HDMI™ für 3D und Ultra HD
bis 4K @ 50/60 Hz (2160p)

- HDCP 2.2 konform

- unterstützt Audio Return Channel (ARC)
und High Dynamic Range (HDR)

- vergoldete Kontaktflächen für optimale
Signalübertragung

- 21:9 - CinemaScope-Seitenverhältnis

Anschlüsse: 2x HDMI Standard-Stecker (Typ A)

TM TM

Datenübertragung: max. 18 Gbit/s
sonstige Formate: 4K (UHD), ARC, HEC, HDR,
Audio 1536 Hz, x.v. Colour (xvYCC), 3D,
Cinemascope

- Isolationswiderstand: 300 V @ 10 MOhm

- Kontaktwiderstand: 5/10 Ohm

HDMI™ Kabel HiSpeed/wE G 2.0

High-speed HDMI™ cable with Ethernet

- High-speed HDMI™ for 3D and Ultra HD
up to 4K @ 50/60 Hz (2160p)

- HDCP 2.2 compliant

- supports Audio Return Channel (ARC)
and high dynamic range (HDR)

- gold-plated contact surfaces for optimum
signal transmission

- 21:9 – CinemaScope aspect ratio

Connectors: 2x HDMI Standard plug (Type A)
Data transmission: max. 18 Gbit/s
Other formats: 4K (UHD), ARC, HEC, HDR,
Audio 1536 Hz, x.v. Colour (xvYCC), 3D,
Cinemascope

- Insulation resistance: 300 V @ 10 MOhms

- Conductor resistance: 5/10 Ohms
