Datasheet 306225 Specification

306225 YBK 2,5306225 YBK 2,5

2,5mm2,s p ring type,1 inp u t 1 output fe ed thro ugh terminal2,5mm2,s p ring type,1 inp u t 1 output fe ed thro ugh terminal
block,Insula tio n mate ria l PA,Bla ckblock,Insula tio n mate ria l PA,Bla ck

Ge n e ral P roduct I n formationGe n e ral P roduct I n formation

Insulating material PA

Inflammability class acc. to UL 94 V2

Packing Unit 100

Weight (g) ---

Dimen sionsDimen sions

Width 5 mm

Length 51 mm

Height (MR 32) --- mm

Height (MR 35x7.5) 35.5 mm

TSE / CE Te ch n ical DataTSE / CE Te ch n ical Data

Nominal Vol tage 750 V ~

Nominal Current 24 A

Cross Section

2.5 mm

2

Norm EN60947-7-1

VDE Te ch n ical DataVDE Te ch n ical Data

Nominal Vol tage --- V ~

Nominal Current --- A

Cross Section

2.5 mm

2

VDE Norm ---

UL / CSA T e c h n ical DataUL / CSA T e c h n ical Data

Nominal Vol tage 600 V ~

Nominal Current 20 A

Cross Section AWG/22-12

ATEX T e c h n ical DataATEX T e c h n ical Data

Nominal Vol tage --- V ~

Nominal Current --- A

Cross Section 2.5

Connection DataConnection Data

Minimum sol id strand cross section

0.5 mm

2

© 2022 Klemsan A.Ş.

www.klemsan.com

Maximum solid Strand cross section

4 mm

2

Minimum fi ne Strand cross section

0.5 mm

2

Maximum fine strand cross section

2.5 mm

2

AWG Conductor Range 22-12

Connection Type spring/yaylı

Insulation Strippi ng l ength 10 mm

Tightening torque --- Nm

Ukrayna Uygunluk Sertifikası - Ukrayna Uygunluk Sertifikası

Avrupa standartlarına uygunluk belgesi - CE Certificate

Avrupa standartlarına uygunluk belgesi - UL Certificate

Rusya Onaylı Denizcilik Sertifikası - Rusya Denizcilik Certificate

LAPEM - RETIE Sertifikası - LAPEM - Retie Certificate

OrderOrder

InfoInfo

306220 2,5mm2,spring type,1 input 1 output feed through terminal block,Insulation material PA,Beige

306221 2,5mm2,spring type,1 input 1 output feed through terminal block,Insulation material PA,Blue

306222 2,5mm2,spring type,1 input 1 output feed through terminal block,Insulation material PA,Green

306223 2,5mm2,spring type,1 input 1 output feed through terminal block,Insulation material PA,Yellow

306224 2,5mm2,spring type,1 input 1 output feed through terminal block,Insulation material PA,Red

306229 2,5mm2,spring type,1 input 1 output feed through terminal block,Insulation material PA,Grey

306225 2,5mm2,spring type,1 input 1 output feed through terminal block,Insulation material PA,Black

306226 2,5mm2,spring type,1 input 1 output feed through terminal block,Insulation material PA,White

306227 2,5mm2,spring type,1 input 1 output feed through terminal block,Insulation material PA,Orange

306228 2,5mm2,spring type,1 input 1 output feed through terminal block,Insulation material PA,Brown
