2SC5081
Silicon NPN Epitaxial
Application
VHF / UHF wide band amplifier
Features
• High gain bandwidth product
fT = 13.5 GHz Typ
• High gain, low noise figure
PG = 18 dB Typ, NF = 1.1 dB Typ at f = 900 MHz
Outline
CMPAK–4
2
3
1
4
1. Collector
2. Emitter
3. Base
4. Emitter
Page 2
2SC5081
Absolute Maximum Ratings (Ta = 25°C)
Item Symbol Ratings Unit
Collector to base voltage V
Collector to emitter voltage V
Emitter to base voltage V
Collector current I
Collector power dissipation P
CBO
CEO
EBO
C
C
Junction temperature Tj 150 °C
Storage temperature Tstg –55 to +150 °C
Electrical Characteristics (Ta = 25°C)
Item Symbol Min Typ Max Unit Test conditions
Collector to base breakdown
V
(BR)CBO
voltage
Collector cutoff current I
Emitter cutoff current I
DC current transfer ratio h
CBO
I
CEO
EBO
FE
Collector output capacitance Cob — 0.4 0.75 pF VCB = 5 V, IE = 0, f = 1 MHz
Gain bandwidth product f
T
Power gain PG 15 18 — dB VCE = 5 V, IC = 20 mA,
Noise figure NF — 1.1 2.0 dB VCE = 5 V, IC = 5 mA,
Note: Marking is “ZD–”.
15——V I
——1 µAVCB = 12 V, IE = 0
——1 mAV
——10µAVEB = 1.5 V, IC = 0
50 90 160 VCE = 5 V, IC = 20 mA
10.5 13.5 — GHz VCE = 5 V, IC = 20 mA
15 V
8V
1.5 V
50 mA
100 mW
= 10 µA, IE = 0
C
= 8 V, RBE = ∞
CE
f = 900 MHz
f = 900 MHz
Attention: This device is very sensitive to electro static discharge.
It is recommended to adopt appropriate cautions when handling this transistor.
See characteristic curves of 2SC5080.
2
Page 3
Maximum Collector Dissipation Curve
120
(mW)
100
C
80
60
40
20
Collector Power Dissipation P
0 50 100 150
Ambient Temperature Ta (°C)
2SC5081
3
Page 4
0.3
0.3
+ 0.1
– 0.05
+ 0.1
– 0.05
2.0 ± 0.2
1.3 ± 0.2
0.65
0.65
0.65
0.6
1.25 ± 0.2
0.3
0.4
+ 0.1
– 0.05
+ 0.1
– 0.05
0.2
0.9 ± 0.1
0.425
1.25 ± 0.1
0.425
2.1 ± 0.3
+ 0.1
0.16
– 0.06
0 – 0.1
Unit: mm
Hitachi Code
JEDEC
EIAJ
Weight
(reference value)
CMPAK-4(T)
—
Conforms
0.006 g
Page 5
