INCHANGE Semiconductor isc Product Specification
www.iscsemi.cn
isc Silicon PNP Power Transistor 2SB760
DESCRIPTION
·Collector-Emitter Breakdown Voltage-
: V
(BR)CEO
·Good Linearity of h
·Wide Area of Safe Operation
·Complement to Type 2SD855
APPLICATIONS
·Medium power amplifier applications.
ABSOLUTE MAXIMUM RATINGS(T
= -60V(Min)
FE
=25℃)
a
SYMBOL PARAMETER VALUE UNIT
V
V
V
I
P
T
CBO
CEO
EBO
I
C
CM
C
T
J
stg
Collector-Base Voltage -60 V
Collector-Emitter Voltage -60 V
Emitter-Base Voltage -5 V
Collector Current-Continuous -1 A
Collector Current-Peak -2 A
Collector Power Dissipation
=25℃
@ T
C
Junction Temperature 150
Storage Temperature Range -55~150
30 W
℃
℃
isc Website：www.iscsemi.cn
Page 2
INCHANGE Semiconductor isc Product Specification
www.iscsemi.cn
isc Silicon PNP Power Transistor 2SB760
ELECTRICAL CHARACTERISTICS
TC=25℃ unless otherwise specified
SYMBOL PARAMETER CONDITIONS MIN TYP. MAX UNIT
V
(BR)CEO
V
CE
V
BE(on)
I
I
h
h
h
(sat)
CEO
EBO
FE-1
FE-2
FE-1
Collector-Emitter Breakdown Voltage IC= -30mA; IB= 0 -60 V
Collector-Emitter Saturation Voltage IC= -1A; IB= -0.125A B -1.0 V
Base-Emitter On Voltage IC= -1A; VCE= -4V -1.3 V
Collector Cutoff Current VCE= -60V; IB= 0 B -300
Emitter Cutoff Current VEB= -5V; IC= 0 -1 mA
DC Current Gain IC= -0.2A; VCE= -4V 40 250
DC Current Gain IC= -1A; VCE= -4V 15
Classifications
R Q P
μA
40-90 70-150 120-250
isc Website：www.iscsemi.cn
2
