Product datasheet
ORIGINAL - GLASS WEDGE BASE -
Original spare part
__
The cost-effective original spare parts for trucks
The ORIGINAL signal lamps with glass wedge bases are
available as original spare parts for different lamp types. Use
these original spare parts for interior lighting, as reading
lights, for instrument and switch lighting, as position and
parking light and a lot of other applications in your truck.
Discover these reliable lamps and OSRAM´s proven high
quality.
Product datasheet | ORIGINAL - GLASS WEDGE BASE August 27, 2022, 07:56:26
© 2022, OSRAM GmbH. All rights reserved. Page 1 of 4
Page 2
Product datasheet
Technical data
Product information
Order reference 2341
Application (Category and Product specific) Auxiliary lamp
Electrical data
Power input 1 W
Nominal voltage 24.0 V
Nominal wattage 1.00 W
Power input tolerance ±8 %
Test voltage 28.0 V
Photometrical data
Luminous flux 3 lm
Luminous flux tolerance ±25 %
Dimensions & weight
__
Length 20.0 mm
Diameter 5 mm
Product weight 0.40 g
Lifespan
Lifespan B3 300 h
Lifespan Tc 1000 h
Additional product data
Base (standard designation) W2x4.6d
Product datasheet | ORIGINAL - GLASS WEDGE BASE August 27, 2022, 07:56:26
© 2022, OSRAM GmbH. All rights reserved. Page 2 of 4
Page 3
Product datasheet
Capabilities
Technology AUX
Certificates & standards
ECE category -
Country specific categorizations
Order reference 2341
Environmental information
Information according Art. 33 of EU Regulation (EC) 1907/2006 (REACh)
Date of Declaration 19-01-2022
Primary Article Identifier 4008321132529 | 4008321013200
Candidate List Substance 1 No declarable substances contained
Declaration No. in SCIP database In work
Country specific information
Product code METEL code SEG-No. STK number UK Org
__
4008321132529 OSRA2341 - 4739278 -
4008321132536 OSRA2341 - 4739278 -
4008321132529 OSRA2341 - 4739278 -
Logistical Data
Product code Product description Packaging unit
(Pieces/Unit)
4008321132529 ORIGINAL - WEDGE
BASE 2341
4008321132536 ORIGINAL - WEDGE
BASE 2341
4008321132543 ORIGINAL - WEDGE
BASE 2341
Unpacked
1
Folding carton box1046 mm x 29 mm x
Shipping carton box50148 mm x 115 mm x
Dimensions (length
x width x height)
- x - x -
112 mm
55 mm
Volume Gross weight
0.15 dm³ 14.89 g
0.94 dm³ 104.39 g
The mentioned product code describes the smallest quantity unit which can be ordered. One shipping unit can contain one or
more single products. When placing an order, for the quantity please enter single or multiples of a shipping unit.
Application advice
For more detailed application information and graphics please see product datasheet.
Product datasheet | ORIGINAL - GLASS WEDGE BASE August 27, 2022, 07:56:26
© 2022, OSRAM GmbH. All rights reserved. Page 3 of 4
Page 4
Product datasheet
Disclaimer
Subject to change without notice. Errors and omission excepted. Always make sure to use the most recent release.
