Ordering number : ENN6783

2SK2682

N-Channel Silicon MOSFET

2SK2682

Ultrahigh-Speed Switching Applications

Features

•

Low ON-resistance.

• High-speed diode.

• Micaless package facilitating mounting.

Package Dimensions

unit : mm

2078B

[2SK2682]

10.0

3.2

16.1

3.6

1

23

0.9

1.2

0.75

3.5

7.2

16.0

14.0

4.5

0.7

2.8

0.6

1 : Gate
2 : Drain
3 : Source

Specifications

2.4

2.552.55

SANYO : TO-220FI-LS

Absolute Maximum Ratings at Ta=25°C

Parameter Symbol Conditions Ratings Unit
Drain-to-Source Voltage V
Gate-to-Source Voltage V
Drain Current (DC) I
Drain Current (Pulse) I

Allowable Power Dissipation P
Channel T emperature T ch 150 °C

Storage T emperature Tstg --55 to +150 °C

DSS
GSS

D

DP

D

PW≤10µs, duty cycle≤1% 52 A

Tc=25°C35W

250 V
±30 V

13 A

2W

Electrical Characteristics at Ta=25°C

Parameter Symbol Conditions

Drain-to-Source Breakdown Voltage V
Gate-to-Source Breakdown Voltage V
Zero-Gate Voltage Drain Current I
Gate-to-Source Leakage Current I
Cutoff Voltage VGS(off) VDS=10V, ID=1mA 2.0 3.0 V
Forward Transfer Admittance
Static Drain-to-Source On-State Resistance RDS(on) ID=6A, VGS=10V 200 270 mΩ

(BR)DSSID
(BR)GSSIG

DSS
GSS

yfs





=1mA, VGS=0 250 V

=±100µA, VGS=0 ±30 V
VDS=250V, VGS=0 1.0 mA
VGS=±25V, VDS=0 ±10 µA

VDS=10V, ID=6A 6 10 S

min typ max

Any and all SANYO products described or contained herein do not have specifications that can handle
applications that require extremely high levels of reliability, such as life-support systems, aircraft's
control systems, or other applications whose failure can be reasonably expected to result in serious
physical and/or material damage. Consult with your SANYO representative nearest you before using
any SANYO products described or contained herein in such applications.

SANYO assumes no responsibility for equipment failures that result from using products at values that
exceed, even momentarily, rated values (such as maximum ratings, operating condition ranges, or other
parameters) listed in products specifications of any and all SANYO products described or contained
herein.

Ratings

Continued on next page.

SANYO Electric Co.,Ltd. Semiconductor Company

TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110-8534 JAPAN

N1500 TS IM TA-3044

No.6783-1/4

Unit

2SK2682

Continued from preceding page.

Parameter Symbol Conditions

Input Capacitance Ciss VDS=20V , f=1MHz 1290 pF
Output Capacitance Coss VDS=20V , f=1MHz 300 pF
Reverse Transfer Capacitance Crss VDS=20V , f=1MHz 125 pF
Turn-ON Delay Time td(on) See specified Test Circuit 22 ns
Rise Time t
Turn-OFF Delay Time td(off) See specified Test Circuit 320 ns
Fall Time t
Diode Forward Voltage V
Diode Reverse Recovery Time t

SD

See specified Test Circuit 66 ns

r

See specified Test Circuit 105 ns

f

IS=12A, VGS=0 1.0 1.5 V
IS=12A, di/dt=100A/µs 160 ns

rr

min typ max

Marking : K2682
