Fuse Holders
Blade Fuseholders - FKH Fuseholder with 90˚
connection for ATO® Style Blade Fuse rated 80V
Specifications
Housing: Out of thermoplastic (UL 94-V0, heat-resistant)
Connections: Leaf spring connector systems, soldering contacts
(2 pins), copper alloy, tinned
Color: Black
Packaging unit: 100 pieces
Fuseholder for ATO / FKS size fuses-links. 90° bended solderable
tin plated contacts. Rated voltage 80V.
Sicherungshalter für Sicherungen in ATO / FKS-Größe. 90°gewinkelte, verzinnte Lötanschlüsse. Nennspannung 80V.
Dimensions in mm / Maße in mm
Fuse Holders
Part Number
Artikel-Nr.
178.7017.0001 Complete max. 130°C
Corresponding fuse links see Section “Blade Fuses.”
© 2006 Littelfuse • Automotive Circuit Protection Products
Description
Beschreibung
w w w . l i t t e l f u s e . c o m
Contact Temperature
Kontakttemperatur
