Datasheet 15602, 15601 Specification

LifY

PVC single core, extra finely stranded, highly flexible

TECHNICAL DATA

• Core identification: see table

PVC single core in alignment with DIN VDE 0250, DIN VDE
0285-525-1 / DIN EN 50525-1

Temperature range flexible -15°C to +80°C
Nominal voltage 0.5 - 1 mm²: AC U

/U 300/500

0

V

1.5 - 70 mm²: AC U0/U
450/750 V

Peak operating voltage 0.1 - 0.25 mm²: 300 V
(not for high power current

installation purposes)

Test voltage 0.1 - 0.25 mm²: 2000 V

0.5 - 1 mm²: 2500 V

1.5 - 70 mm²: 3000 V

Minimum bending radius flexible 8x Outer-Ø
fixed 4x Outer-Ø

CABLE STRUCTURE

n

• Copper wire bare, extra finely stranded

• Core insulation: PVC

Cross-sec.
mm²

0.1 - 51 x 0.05 1.0 1.2 2.1 15101 15113 15103 15104 15102 15105 15106

0.14 26 72 x 0.05 1.0 1.4 2.6 15201 15213 15203 15204 15202 15205 15206

0.25 24 65 x 0.07 1.3 2.5 4.2 15301 15313 15303 15304 15302 15305 15306

0.5 20 132 x 0.07 2.0 5.5 8.0 15401 15413 15403 15404 15402 15405 15406

0.75 18 195 x 0.07 2.2 8.0 12.0 15501 15513 15503 15504 15502 15505 15506

1 17 260 x 0.07 2.5 10.8 18.0 15601 15613 15603 15604 15602 15605 15606

1.5 16 192 x 0.1 3.5 15.0 22.0 15701 15713 15703 15704 15702 15705 15706

2.5 14 320 x 0.1 3.8 25.0 37.0 15801 15813 15803 15804 15802 15805 15806

4 12 512 x 0.1 4.9 40.0 50.0 15901 15913 15903 15904 15902 15905 15906

6 10 768 x 0.1 6.0 60.0 71.0 15093 15135 15115 15116 15114 - -

10 8 1280 x 0.1 7.3 100.0 130.0 15094 15136 15118 15119 15117 - -

16 6 2048 x 0.1 8.8 160.0 187.0 15095 15137 15121 15122 15120 - -

25 4 3234 x 0.1 9.9 240.0 294.0 15096 15138 15124 15125 15123 - -

35 2 4508 x 0.1 11.7 336.0 380.0 15097 15139 15127 15128 15126 - -

50 1 6468 x 0.1 14.7 480.0 521.0 15098 15140 15130 15131 15129 - -

70 2/0 8967 x 0.1 15.5 672.0 740.0 15099 15141 15133 15134 15132 - -

AWG,

approx.

Wire

structure

Outer

Ø mm,

approx.

Cu-weight

kg/km

Weight

kg/km,

approx.

PROPERTIES

n

• the materials used during manufacturing are cadmium-free, con­tain no silicone and are free from substances harmful to the wetting
properties of lacquers

TESTS

n

• flame-retardant acc.to DINVDE0482-332-1-2 / DINEN60332­1-2 / IEC60332-1-2

APPLICATION

n

Highly flexible single core for connections in switch cabinet construc­tion, measurement set-ups in laboratories, engineering and technical
trainings as well as other applications that require increased bending
properties.

NOTES

n

• the conductor is metrically (mm²) constructed, AWGnumbers are
approximated, and are for reference only

black green-yellow blue brown red white grey

Part no. Part no. Part no. Part no. Part no. Part no. Part no.

Cross-sec.
mm²

16.09.2021 / We reserve the right to make technical changes; the imprint in the image is purely exemplary

0.1 - 51 x 0.05 1.0 1.2 2.1 15107 15108 15109 15100 151015 15111 15112

0.14 26 72 x 0.05 1.0 1.4 2.6 15207 15208 15209 15200 152015 15211 15212

0.25 24 65 x 0.07 1.3 2.5 4.2 15307 15308 15309 15300 153015 15311 15312

0.5 20 132 x 0.07 2.0 5.5 8.0 15407 15408 15409 15400 154015 15411 15412

0.75 18 195 x 0.07 2.2 8.0 12.0 15507 15508 15509 15500 155015 15511 15512

Continued on next page 1/2

AWG,

approx.

Wire

structure

Outer

Ø mm,

approx.

Cu-weight

kg/km

Weight

kg/km,

approx.

violet yellow orange green dark blue pink beige

Part no. Part no. Part no. Part no. Part no. Part no. Part no.

LifY

PVC single core, extra finely stranded, highly flexible

Cross-sec.
mm²

1 17 260 x 0.07 2.5 10.8 18.0 15607 15608 15609 15600 156015 15611 15612

1.5 16 192 x 0.1 3.5 15.0 22.0 15707 15708 15709 15700 157015 15711 15712

2.5 14 320 x 0.1 3.8 25.0 37.0 15807 15808 15809 15800 158015 15811 15812

4 12 512 x 0.1 4.9 40.0 50.0 15907 15908 15909 15900 159015 15911 15912

Cross-sec.
mm²

0.1 - 51 x 0.05 1.0 1.2 2.1 15110

0.14 26 72 x 0.05 1.0 1.4 2.6 15210

0.25 24 65 x 0.07 1.3 2.5 4.2 15310

0.5 20 132 x 0.07 2.0 5.5 8.0 15410

0.75 18 195 x 0.07 2.2 8.0 12.0 15510

1 17 260 x 0.07 2.5 10.8 18.0 15610

1.5 16 192 x 0.1 3.5 15.0 22.0 15710

2.5 14 320 x 0.1 3.8 25.0 37.0 15810

4 12 512 x 0.1 4.9 40.0 50.0 15910

AWG,

approx.

AWG,

approx.

Wire

structure

Wire

structure

Outer

Ø mm,

approx.

Outer

Ø mm,

approx.

Cu-weight

kg/km

Cu-weight

kg/km

Weight

kg/km,

approx.

Weight

kg/km,

approx.

violet yellow orange green dark blue pink beige

Part no. Part no. Part no. Part no. Part no. Part no. Part no.

transparent

Part no.

16.09.2021 / We reserve the right to make technical changes; the imprint in the image is purely exemplary

2/2
