Page 1
10A015
1.5 Watts, 20 Volts, Class A
Linear to 1000 MHz
GENERAL DESCRIPTION
The 10A015 is a COMMON EMITTER transistor capable of providing 1.5
Watts of Class A, RF Output power to 1000 MHz. This transistor is
specifically designed for general Class A amplifier applications. It utilizes
gold metalization and diffused ballasting to provide high reliability and
supreme ruggedness.
ABSOLUTE MAXIMUM RATINGS
Maximum Power Dissipation @ 25 C 6 Watts
Maximum Voltage and Current
BVces Collector to Emitter Voltage 50 Volts
BVebo Emitter to Base Voltage 3.5 Volts
Ic Collector Current 750 mA
Ma ximum Temperatures
Storage Temperature - 65 to + 150 C
Operating Junction Temperature + 200 C
ELECTRICAL CHARACTERISTICS @ 25 C
SYMBOL CHARACTERISTICS TEST CONDITIONS MIN TYP MAX UNITS
Pout
Pin
Pg
Ft
VSWR
Power Out
Power Input
Power Gain
Transition Frequency
Load Mismatch Tolerance
o
o
o
O
F = 1 GHz
Ic = 220 mA
Vcc = 20 Volts
Vce = 20V, Ic =220 mA
CASE OUTLINE
55FT, STYLE 2
1.5
0.19
9.0
2.7
9.5
30:1
Watts
Watts
GHz
dB
BVebo
BVces
BVceo
h
FE
Cob
θ
jc
Issue February 1996
GHz TECHNOLOGY INC. RESERVES THE RIGHT TO MAKE CHANGES WITHOUT FURTHER NOTICE. GHz RECOMMENDS THAT
BEFORE THE PRODUCT(S) DESCRIBED HEREIN ARE WRITTEN INTO SPECIFICATIONS, OR USED IN CRITICAL APPLICATIONS,
THAT THE PERFORMANCE CHARACTERISTICS BE VERIFIED BY CONTACTING THE FACTORY.
GHz Technology Inc. 3000 Oakmead Village Drive, Santa Clara, CA 95051-0808 Tel. 408 / 986-8031 Fax 408 / 986-8120
Emitter to Base Breakdown
Collector to Emitter Breakdown
Collector to Emitter Breakdown
DC Current Gain
Output Capacitance
Thermal Resistance
Ie = 1 mA
Ic = 10 mA
Ic = 10 mA
Vce = 5 V, Ic =100 mA
Vcb = 5 V, f = 1 MHz
3.5
50
24
20
3.8
20 29
Volts
Volts
Volts
pF
o
C/W
Page 2
Typical Performance
10A015
10A015 (20V , 0.22A)
Page 3
MMICAD for Windows Fri Jul 08 10:34:39 1994
CIRCUIT: MES
FREQ --- S11 --- --- S21 --- --- S12 --- --- S22 -- MHz MAG ANG MAG ANG MAG ANG MAG ANG
0.100 0.71444 -160.782 16.0356 116.519 0.02275 35.0393 0.42058 -77.3759
0.200 0.79473 -172.871 8.98445 96.9768 0.02727 34.4150 0.30289 -105.202
0.300 0.81513 -179.724 6.16077 84.5847 0.03101 37.3839 0.27523 -117.550
0.400 0.82391 175.497 4.67553 76.1937 0.03520 40.2138 0.27423 -124.308
0.500 0.82552 171.380 3.75402 69.3057 0.03928 43.6423 0.28109 -128.108
0.600 0.82599 167.564 3.12463 62.5982 0.04408 45.5915 0.29711 -131.121
0.700 0.82590 164.137 2.67908 55.8207 0.04924 46.9769 0.31596 -133.463
0.800 0.82751 160.922 2.34296 49.7308 0.05511 47.4369 0.33725 -135.825
0.900 0.82895 157.536 2.07752 43.8716 0.06110 46.9143 0.35824 -138.380
1.000 0.82649 154.035 1.86687 38.3915 0.06582 46.7907 0.37937 -140.217
1.100 0.82518 150.725 1.69487 32.9740 0.07183 46.5604 0.40196 -142.351
1.200 0.82311 147.466 1.54892 27.6537 0.07808 45.9531 0.42623 -144.711
1.300 0.82374 144.089 1.42774 22.5346 0.08474 44.9908 0.44824 -146.998
1.400 0.82316 140.784 1.32241 17.4996 0.09114 43.8844 0.47145 -149.618
1.500 0.82222 137.234 1.22854 12.5140 0.09820 42.5710 0.49267 -151.943
1.600 0.82163 133.648 1.14693 7.78041 0.10526 41.1111 0.51301 -154.495
1.700 0.82074 130.047 1.07333 3.20224 0.11234 39.4652 0.53328 -156.985
1.800 0.81902 126.149 1.00886 -1.32148 0.12009 37.6259 0.55348 -159.283
1.900 0.81773 122.433 0.95068 -5.60939 0.12790 35.8041 0.57051 -161.854
2.000 0.81598 118.694 0.89701 -9.73811 0.13579 33.9701 0.58856 -164.287
2.100 0.81452 114.613 0.85022 -13.8881 0.14379 31.7736 0.60869 -166.749
2.200 0.81224 110.743 0.80716 -17.8736 0.15202 29.5273 0.62745 -169.473
2.300 0.80926 106.728 0.76737 -21.7289 0.16146 27.4446 0.64638 -172.567
2.400 0.80939 102.646 0.73137 -25.4845 0.17122 24.8018 0.65855 -175.679
2.500 0.80620 98.4842 0.69786 -29.2295 0.18040 22.0881 0.67062 -178.831
2.600 0.80747 94.2752 0.66676 -32.6879 0.18940 19.4187 0.67631 178.293
2.700 0.80377 89.9974 0.63783 -36.1092 0.19878 16.5881 0.68340 175.321
2.800 0.79977 85.6483 0.61013 -39.5377 0.20856 13.7516 0.69046 172.288
2.900 0.79459 81.4224 0.58377 -42.5949 0.21777 10.9093 0.69394 169.137
3.000 0.79043 77.3116 0.55864 -45.4501 0.22710 8.07792 0.69414 165.980
