VERTICAL 20mm COIN CELL
LOW PROFILE SURFACE & THRU HOLE MOUNT COIN CELL HOLDERS
SURFACE MOUNT COIN CELL HOLDERS
This space saving vertical design features a rugged, lightweight body that mounts squarely and
securely on PC boards for easy installation and replacement of batteries. Reliable spring tension
assures low contact resistance.
A “unique” space saving design. The battery is installed vertically from the top.The contacts
of this holder are polarized to assure proper continuity and circuit protection.
.300 [7.6]
.280 [7.1]
.150 [3.8]
.094 [2.4]
.047 [1.19] DIA.
(2) PLS
DIA.
Mounting Detail
.315 [8.0]
.600 [15.2]
.118 [3.0]
.136 [3.5] DIA.
(2) PLS
.060 [1.52]
.050 [1.27]
.515 [13.1]
DIA.
(2) PLS
Mounting Detail
• Accepts all major manufacturers’
20mm diameter batteries
• Molded notch prevents improper
insertion of 2032 size cells
• Space saving design for high
density packaging
• Retains cells securely, withstands
shock and vibration
• Polarity clearly marked
• Mounts securely for
wave soldering
• Temperature range
-60°F to +293°F
(-50°C to +145°C)
MATERIAL:
Contacts: .012 (.30) thick Spring Steel, Tin Nickel Plate
Base: PBT, UL Rated 94V-0
• Polarized holder
• Mounts securely for wave soldering
• Reliable spring tension assures low
contact resistance
• Retains 20mm batteries securely to
withstand shock and vibration
• Temperature range -60°F to +293°F
(-50°C to +145°C)
MATERIAL:
Contacts: .016 (.41) thick Spring Steel, Tin Nickel Plate
Base: PBT, UL Rated 94V-0
.315 [8.0]
1.000
[25.4]
REF.
.300 [7.6]
.145 [3.7]
.070 [1.78]
.600 [15.2]
.150
[3.8]
.515
[13.1]
.920 [23.4]
.238 [6.1]
.918
[23.3]
NEGATIVE
POSITIVE
.795 [20.2]
DIA.
1.040 [26.4]
.193
[4.9]
.050 [1.27]
.045 [1.14]
POS
(2) PLS
NEG
SMT Design - Holders for 20mm and 23mm Lithium Coin Cell Batteries
• Temp. range -60ºF to +540ºF (-50ºC to +282ºC) • Low profile for high density packaging
• Ideal for memory back-up applications • SMT solder tail with “Flow-Hole” design for
• Polarity clearly marked (+) increased joint strength
• UL approved material, 94V-0 • Viewable solder tails assures reliable joint inspection
• Rugged construction, light weight • Safe for all soldering & reflow operations
• Compatible with vacuum and mechanical • All conductive polystyrene carrier tape meets ANSI/EIA
pick & place assembly systems - 481 standard
MATERIAL: Contacts: .015 (.38) thick Steel, Tin Nickel Plate Base: Nylon 46, UL Rated 94V-0
Tape & Reel Spec’s: 44mm wide; 32mm pitch; 13 inch reel (200 pieces per reel)
C
MIN.
.125
[3.2]
MIN.
D MIN.
Pad Layout
C
EA
B
D
D
.437
[11.1]
.125
[3.2]
.931
[23.7]
NEG
.600
[15.2]
Designed for quick and easy installation and replacement of 1220 and 2032 coin cell lithium batteries.
The contacts of these holders are polarized to assure proper continuity and circuit protection.
Tape & Reel Spec’s: 44mm wide; 24mm pitch;
13 inch reel (500 pieces per reel)
Tape & Reel Spec’s: 32mm wide; 20mm pitch; 13 inch reel (500 pieces per reel)
.433 [11.0]
1.154 [29.3]
.276
[7.0]
.102 [2.6]
MIN.
ZONE FOR OPTIONAL
ADHESIVE FIXATION
.142
[3.6]
MIN.
Pad Layout
Mounting Detail
.130 [3.3]
TYP.
1.060 [26.9]
.011 REF. x
.032 [.81] W.
(2) PLS
.011 REF. x
.032 [.81] W.
(1) PL
.217 [5.5]
.157 [4.0]
.039 [1.0]
(2) PLS
.071 [1.80]
(2) PLS
.048 [1.22]
DIA. LEG
.036 [0.91]
DIA. LEG
.740 [18.8]
.295 [7.5]
.138 [3.5]
.567 [14.4]
.512 [13.0] I. DIA.
.591 [15.0] DIA.
• Polarized Holder
• Retains cell securely to withstand shock
and vibration
• Reliable dual spring contacts assure low
contact resistance
• Low Profile for densely packaged PCB’s
• Compatible with vacuum and mechanical
pick & place assembly systems
• Conductive polystyrene carrier tape meets
ANSI/EIA – 481 standard
2032 SURFACE MOUNT
2032 THRU HOLE MOUNT
MATERIAL:
Contacts: .006 (.15) thick
Phosphor Bronze
Cat. No. 1060 - Gold Plate
Cat. No. 1059 - Tin Plate
Base: Glass Filled LCP,
UL Rated 94V-0
COMPACT
SMALL PAD PATTERN
CAT. NO. ON TAPE CE LLS A B C D E CELL BATTERY
1061 1061TR 1 .256 (6.5) .290 (7.4) 1.015 (25.8) .156 (4.0) .896 (22.8)
20mm
2016*, 2020,
1062 1062TR 2 .375 (9.5) .406 (10.3) 1.015 (25.8) .156 (4.0) .896 (22.8) 2025, 2032
1071 1071TR 1 .256 (6.5) .290 (7.4) 1.015 (25.8) .156 (4.0) 1.000 (25.4) 23mm 2320, 2325, 2330
*Cat. No. 1061 (1 or 2 cells); Cat. No. 1062 (3 cells)
LARGE PAD PATTERN
CAT. NO. ON TAPE CE LLS A B C D E CELL BATTERY
1063 1063TR 1 .256 (6.5) .290 (7.4) 1.250 (31.8) .278 (7.1) .896 (22.8)
20mm
2016*, 2020,
1064 1064TR 2 .375(9.5) .406 (10.3) 1.250 (31.8) .278 (7.1) .896 (22.8) 2025, 2032
1073 1073TR 1 .256 (6.5) .290 (7.4) 1.250 (31.8) .278 (7.1) 1.000 (25.4) 23mm 2320, 2325, 2330
*Cat. No. 1063 (1 or 2 cells); Cat. No. 1064 (3 cells)
AVAILABLE ON TAPE AND REEL
AVAILABLE ON TAPE AND REEL
1.060 [26.9]
.038 [0.97] DIA.
(3) PLS
.100 [2.6]
MATERIAL:
Contacts: .008 (.20) thick
Phosphor Bronze, Gold Plate
Base: Glass filled PPS, UL Rated 94V-0
CAT. NO. 1065
CAT. NO. 1067
CAT. NO. 1060 (Bulk)
CAT. NO. 1060TR (Tape & Reel)
CAT. NO. 1059
CAT. NO. 1056TR (Tape & Reel)
CAT. NO. 1056 (Bulk)
AVAILABLE ON TAPE AND REEL
1.118 [28.4]
.142 [3.6]
1.256 [31.9]
.866 [22.0]
.630
[16.0]
.217
[5.5]
SLIMLINE
.670 [17.0]
.280 [7.1]
.055 [1.40]
REF.
.785
[19.9]
.300
[7.6]
.531 [13.5]
x .062 [1.57] L.
.062 [1.57] DIA.
.038 [.97]
CONTACT
(2) PLS
.875 [22.2]
LEG
.140
[3.6]
BASE
Pad Layout
.295 [7.5]
.144 [3.7]
MIN.
(2) PLS
.102 [2.6]
MIN.
(2) PLS
.042 [1.07]
DIA.
.055 [1.40] DIA.
.480 [12.2]
MIN.
.088 [2.24]
1220 SURFACE MOUNT
