QuickScan™ QM24XX
General Purpose Handheld
Area Imager Bar Code Reader
with Datalogic’s STAR Cordless System™
Quick Reference Guide
Datalogic ADC, Inc.
959 Terry Street
Eugene, OR 97402
USA
Telephone: (541) 683-5700
Fax: (541) 345-7140
©2014 Datalogic ADC, Inc.
An Unpublished Work - All rights reserved. No part of the contents
of this documentation or the procedures described therein may be
reproduced or transmitted in any form or by any means without
prior written permission of Datalogic ADC, Inc. or its subsidiaries or
affiliates ("Datalogic" or “Datalogic ADC”). Owners of Datalogic
products are hereby granted a non-exclusive, revocable license to
reproduce and transmit this documentation for the purchaser's
own internal business purposes. Purchaser shall not remove or
alter any proprietary notices, including copyright notices, contained in this documentation and shall ensure that all notices
appear on any reproductions of the documentation.
Should future revisions of this manual be published, you can
acquire printed versions by contacting your Datalogic representative. Electronic versions may either be downloadable from the
Datalogic website (www.datalogic.com) or provided on appropriate
media. If you visit our website and would like to make comments
or suggestions about this or other Datalogic publications, please
let us know via the "Contact Datalogic" page.
Disclaimer
Datalogic has taken reasonable measures to provide information
in this manual that is complete and accurate, however, Datalogic
reserves the right to change any specification at any time without
prior notice.
Datalogic and the Datalogic logo are registered trademarks of Datalogic S.p.A. in many countries, including the U.S.A. and the E.U. All
other brand and product names may be trademarks of their
respective owners.
Patents
See www.patents.datalogic.com
for patent list.
This product is covered by one or more of the following patents:
Design Patents: EP002158717, ZL201330271434.1
Utility patents: EP0996284B1, EP0997760B1, EP0999514B1,
EP1128315B1, EP1396811B1, EP1413971B1, EP1828957B1,
JP4435343B2, US6478224, US6512218, US6513714,
US6561427, US6808114, US6997385, US7053954, US7075663,
US7234641, US7387246, US7721966, US8245926, US8561906
Quick Reference Guide i
Table of Contents
Software Product Policy ............................................................. vi
Customers Under Software Support ................................ vi
Description .................................................................................... 1
Setting Up the Reader ................................................................. 2
Locking the Reader to the Base ........................................ 2
To Lock the Reader in the Base................................ 2
Connecting the Base Station ...................................................... 4
Base Station Connection and Routing .............................. 4
System and Network Layouts ...........................................6
Stand Alone Layout ................................................... 6
Using the BC20XX™ Radio Base ......................................... 7
Radio Base LEDs ........................................................ 7
Charging the Batteries ................................................................ 8
Battery Safety ..................................................................... 8
Replacing the Battery Pack .............................................. 11
Using the Quickscan™ QM24XX ................................................ 13
Linking the Reader ..................................................................... 14
Link Datalogic RF Devices to Base......................... 14
Power Off .................................................................................... 14
Selecting the Base Interface Type ............................................ 15
Interface Selection ............................................................15
Configuring the Interface ........................................ 15
Keyboard Interface .................................................. 17
Scancode Tables....................................................... 19
Country Mode........................................................... 19
Caps Lock State........................................................ 24
Numlock.................................................................... 25
Programming .............................................................................. 26
Using Programming Bar Codes .......................................26
Configure Other Settings .................................................. 26
Resetting Standard Product Defaults ............................ 26
Reading Parameters ..................................................................27
Aiming System .................................................................. 27
Good Read Green Spot Duration .....................................28
Scan Modes ................................................................................ 29
Pick Mode ........................................................................... 31
Multiple Labels in a Volume ............................................31
Technical Specifications ............................................................ 32
LED and Beeper Indications ...................................................... 36
Error Codes ................................................................................. 38
Base Station Indications ...........................................................39
Regulatory Information .............................................................40
ii QuickScan™ QM24XX
Statement of Agency Compliance ...................................40
FCC Class B Compliance Statement....................... 40
FCC RF Radiation Exposure Statement................. 41
Canadian Notice ................................................................ 41
Power Supply ..................................................................... 42
Imager Labeling .................................................................42
WEEE Statement ............................................................... 44
Datalogic ADC Limited Factory Warranty .......................45
Warranty Coverage .................................................. 45
Warranty Claims Process........................................ 45
Warranty Exclusions................................................ 46
No Assignment ........................................................ 47
Risk of Loss .............................................................. 47
Ergonomic Recommendations .................................................48
Cleaning .............................................................................. 49
Services and Support .................................................................50
Quick Reference Guide iii
DATALOGIC ADC, INC.
END USER SOFTWARE LICENSE AGREEMENT (EULA)
FOR THE QUICKSCAN™ QM24XX
Notice to End User: There are two types of software covered by this END USER
LICENSE AGREEMENT ("EULA"): (1) The Datalogic Product you have acquired contains embedded software ("Embedded Software") which is integral to the Product's
operation; and (2) Optional Application Software provided to you on an optional
basis ("Application Software"). Embedded Software and Application Software are
collectively referred to as "Software" and are subject to the terms and conditions
contained in this EULA. Software is provided only for use with, and for authorized
end users of, the Datalogic QuickScan™ QM24XX ("Product"). Portions of the
Embedded Software include or operate with Open Source software or libraries
("Open Source"). Use of Open Source is subject to the Open Source licenses entitled
"QBT-QM24XX .zip License File .pdf" available at the following website: http://
www.datalogic.com/software_lan_sb2783_1.html.
This EULA (End User Software License Agreement) (“EULA” or "Agreement") is a
legally binding agreement governing the licensing of the Software and Documentation by Datalogic ADC, Inc. and its subsidiaries and affiliates ("Datalogic") to the
entity or person who has purchased or otherwise acquired a Datalogic Product
("End User"). For purposes of this Agreement, any software that is not Embedded
Software or Application Software is software associated with a separate end-user
license agreement is licensed to you under the terms of that license agreement.
Datalogic and End User hereby agree as follows:
1. Definitions.
1.1 "Affiliate" means a business entity currently existing or later acquired that
controls, is controlled by, or is under common control with Datalogic S.p.A.
1.2 "Documentation" means materials such as user's guides, program reference
guides, quick reference guides, manuals, or similar materials associated with
or related to the Datalogic Product, whether in printed, "online", or other form.
1.3 "Proprietary Information" means: (a) source code, object code, software, documentation, and any related internal design, system design, data base design,
algorithms, technology, technical data or information, implementation techniques, and trade secrets related to the Software, (b) any other trade secrets
marked appropriately or identified as proprietary or confidential, and (c) any
information that End User, under the circumstances, should recognize as confidential. Proprietary Information does not include any information that the
receiving party can establish was (1) in the public domain, (2) already in the
receiving party's possession or rightfully known prior to receipt, (3) rightfully
learned from a third party not in violation of any other's proprietary rights, or
(4) independently developed without access to Proprietary Information.
1.4 "Datalogic Product" means the Datalogic® QuickScan™ series scanner product,
including all embedded Software in and all Documentation related to such
product, which has been purchased or otherwise acquired by End User,
whether obtained directly or indirectly from Datalogic.
1.5 "Software" means any software or computer programs of Datalogic or its third
party licensors in machine readable form which is embedded in the Datalogic
Product, whether obtained directly or indirectly from Datalogic, including any
replacement, update, upgrade, enhancement or modification.
2. Scope Of License Granted.
2.1 Datalogic grants to End User a non-exclusive, non-transferable, perpetual
license to use the Software, solely on the Datalogic Product in which it is
embedded ("designated Datalogic Product"), in machine-readable form only,
solely for End User's internal business purposes. This Agreement does not
convey ownership of the Software to End User. Title to the Software shall be
and remain with Datalogic or the third party from whom Datalogic has
obtained a licensed right. As used in this Agreement, the term "purchase" or
its equivalents when applied to the Software shall mean "acquire under
license." End User is not entitled to receipt or use of the source code to any
Software.
2.2 End User shall not copy, modify, decompile, disassemble, reverse engineer, or
otherwise reproduce or remanufacture the Software, whether modified or
unmodified, nor sell, assign, sublicense, distribute, lend, rent, give, or otherwise
transfer the Software to any other person or organization, for purposes other
than as expressly provided in this Agreement, without Datalogic's prior written
consent.
3. Transfers, Support.
3.1 Any copying, installing, reproduction, remanufacture, reverse engineering,
electronic transfer, or other use of the Software on other than the designated
iv QuickScan™ QM24XX
Datalogic Product will be a material breach of this Agreement. However, Datalogic may elect not to terminate this Agreement or the granted licenses, but
instead may elect to notify End User that End User is deemed to have ordered
and accepted a license for each breaching use. End User shall pay Datalogic
the applicable list price for such licenses as of the date of such breach.
3.2 End User shall not sell, assign, sublicense, distribute, lend, rent, give, or otherwise transfer the Datalogic Product to any third party unless such third party
agrees with Datalogic in writing to be bound by the terms and conditions of
this Agreement. Any such transfer of the Datalogic Product absent such
agreement shall be null and void.
3.3 End User may obtain support for Software from Datalogic at Datalogic's standard support fees and under Datalogic's standard support terms and conditions in effect at the time the support is requested.
4. Intellectual Property.
End User acknowledges that the Software constitutes valuable trade secrets of
Datalogic or Datalogic's third party licensors and that the Software is protected by
intellectual property laws and treaties. The license set forth in this Agreement
does not transfer to End User any ownership of Datalogic's or its third party licensors' copyrights, patents, trademarks, service marks, trade secrets, or other intellectual property rights and End User shall have no right to commence any legal
actions to obtain such rights. End User shall not remove, modify, or take any other
action that would obscure any copyright, trademark, patent marking, or other
intellectual property notices contained in or on the Datalogic Product.
5. Proprietary Information.
5.1 End User acknowledges that Proprietary Information is the confidential, proprietary, and trade secret property of Datalogic and Datalogic's third party
licensors and End User acquires no right or interest in any Proprietary Information.
5.2 End User shall not disclose, provide, or otherwise make available the Proprietary Information of Datalogic or its third party licensors to any person other
than End User's authorized employees or agents who are under confidentiality
agreement, and End User shall not use the Proprietary Information other than
in conjunction with use of the Datalogic Product exclusively for End User's
internal business purposes. End User shall take steps to protect the Proprietary Information no less securely than if it were End User's own intellectual
property.
5.3 The provisions of this Proprietary Information Section shall survive and continue for five (5) years after the termination of this Agreement.
6. Limited Warranty.
6.1 Datalogic warrants that, under normal use and operation, the Datalogic Product will conform substantially to the applicable Documentation for the period
specified in the Documentation. During this period, for all reproducible nonconformities for which Datalogic has been given written notice, Datalogic will
use commercially reasonable efforts to remedy nonconformities verified by
Datalogic. End User agrees to supply Datalogic with all reasonably requested
information and assistance necessary to help Datalogic in remedying such
nonconformities. For all defects reported to Datalogic within the warranty
period, Datalogic's liability is limited to providing End User with one copy of
corrections or responding to End User's problem reports according to Datalogic's standard assistance practices. Datalogic does not warrant that the
product will meet End User's requirements or that use of the product will be
uninterrupted or error free, or that Datalogic's remedial efforts will correct any
nonconformance. This limited warranty does not cover any product that have
been subjected to damage or abuse, whether intentionally, accidentally, or by
neglect, or to unauthorized repair or unauthorized installation, and shall be
void if End User modifies the product, uses the product in any manner other
than as established in the Documentation, or if End User breaches any of the
provisions of this Agreement.
6.2 EXCEPT AS PROVIDED IN THIS AGREEMENT, THE DATALOGIC PRODUCT IS
PROVIDED "AS IS" AND DATALOGIC MAKES NO WARRANTIES OF ANY KIND,
EXPRESS OR IMPLIED, WRITTEN OR ORAL, WITH RESPECT TO THE PRODUCT,
AND SPECIFICALLY DISCLAIMS THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
7. Infringement.
7.1 Datalogic will defend End User against any claim in a lawsuit that the Datalogic Product furnished hereunder infringe a United States patent or copyright
of a third party and Datalogic will pay any damages finally awarded against
End User by a court of competent jurisdiction that are attributable to such
claim or will pay End User's part of any settlement that is attributable to such
Quick Reference Guide v
claim, provided, that 1) End User notifies Datalogic promptly in writing of the
claim, 2) Datalogic controls the defense or settlement of the claim, and 3) End
User cooperates fully with Datalogic in such defense or settlement. All notices
of a claim should be sent to Datalogic ADC, Inc., Legal Department, 959 Terry
Street, Eugene, OR 97402.
7.2 In the defense or settlement of any such claim, Datalogic may, at its option, 1)
procure for End User the right to continue using the Datalogic Product, 2)
modify the Datalogic Product so that it becomes non-infringing, 3) replace the
Datalogic Product with an equivalent product not subject to such claim, or 4)
provide End User an opportunity to return the Datalogic Product and receive a
refund of the purchase price paid, less a reasonable allowance for use.
7.3 Datalogic shall have no liability to End User for claims of infringement based
upon 1) the use of any Datalogic Product in combination with any product
which Datalogic has not either furnished or authorized for use with such Datalogic Product 2) the use of any Datalogic Product designed, manufactured, or
modified to the specifications of End User, or 3) End User's modification of the
Datalogic Product without written authorization from Datalogic.
7.4 THE FOREGOING STATES DATALOGIC'S COMPLETE AND ENTIRE OBLIGATION
CONCERNING CLAIMS OF PATENT, COPYRIGHT, OR OTHER INTELLECTUAL
PROPERTY INFRINGEMENT, CANCELS AND SUPERCEDES ANY PRIOR AGREEMENTS, WHETHER ORAL OR WRITTEN, BETWEEN THE PARTIES CONCERNING
SUCH CLAIMS, AND WILL NOT BE MODIFIED OR AMENDED BY ANY PAST, CONTEMPORANEOUS, OR FUTURE AGREEMENTS OR DEALINGS BETWEEN THE
PARTIES, WHETHER ORAL OR WRITTEN, EXCEPT AS SET FORTH IN A FUTURE
WRITING SIGNED BY BOTH PARTIES.
8. Limitation Of Liability.
EXCEPT AS PROVIDED IN SECTION 7, DATALOGIC SHALL NOT BE LIABLE FOR ANY
CLAIMS AGAINST END USER BY ANY OTHER PARTY. IN NO EVENT SHALL DATALOGIC'S LIABILITY FOR DAMAGES, IF ANY, WHETHER BASED UPON CONTRACT,
TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY, STRICT LIABILITY, WARRANTY, OR ANY OTHER BASIS, EXCEED THE PRICE OR FEE PAID BY END USER FOR
THE DATALOGIC PRODUCT. UNDER NO CIRCUMSTANCES SHALL DATALOGIC BE
LIABLE TO END USER OR ANY THIRD PARTY FOR LOST PROFITS, LOST DATA,
INTERRUPTION OF BUSINESS OR SERVICE, OR FOR ANY OTHER SPECIAL, CONSEQUENTIAL, CONTINGENT, INDIRECT, INCIDENTAL, PUNITIVE, EXEMPLARY, OR
OTHER SIMILAR DAMAGES, EVEN IF DATALOGIC HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
9. Government Restricted Rights; International Use.
9.1 Use, duplication, or disclosure of the Software by the U.S. Government is subject to the restrictions for computer software developed at private expense as
set forth in the U.S. Federal Acquisition Regulations at FAR 52.227-14(g), or
52.227-19 or in the Rights in Technical Data and Computer Software clause at
DFARS 252.227-7013(c)(1)(ii), whichever is applicable.
9.2 If End User is using the Datalogic Product outside of the United States, End
User must comply with the applicable local laws of the country in which the
Datalogic Product is used, with U.S. export control laws, and with the English
language version of this Agreement. The provisions of the "United Nations
Convention on International Sale of Goods" shall not apply to this Agreement.
10. Termination.
10.1Either party may terminate this Agreement or any license granted under this
Agreement at any time upon written notice if the other party breaches any
provision of this Agreement.
10.2Upon termination of this Agreement, End User immediately shall cease using
any nonembedded software and shall return to Datalogic or destroy all nonembedded software covered by this Agreement, and shall furnish Datalogic
with a certificate of compliance with this provision signed by an officer or
authorized representative of End User. For embedded software, End User
agrees to sign a waiver prepared by Datalogic concerning further use of the
embedded Software. End User's resumed or continued use of the embedded
Software after termination shall constitute End User's agreement to be bound
by the terms and conditions of this Agreement for such use.
11. General Provisions.
11.1 Entire Agreement; Amendment. This document contains the entire agreement between the parties relating to the licensing of the Software and supersedes all prior or contemporaneous agreements, written or oral, between the
parties concerning the licensing of the Software. This Agreement may not be
changed, amended, or modified except by written document signed by Datalogic.
Software Product Policy
vi QuickScan™ QM24XX
11.2 Notice. All notices required or authorized under this Agreement shall be given
in writing, and shall be effective when received, with evidence of receipt.
Notices to Datalogic shall be sent to the attention of Contract Administration,
Datalogic ADC, Inc., 959 Terry Street, Eugene, OR 97402, or such other address
as may be specified by Datalogic in writing.
11.3 Waiver. A party's failure to enforce any of the terms and conditions of this
Agreement shall not prevent the party's later enforcement of such terms and
conditions.
11.4 Governing Law; Venue: This Agreement and the rights of the parties hereunder shall be governed by and construed in accordance with the laws of the
State of Oregon U.S.A, without regard to the rules governing conflicts of law.
The state or federal courts of the State of Oregon located in either Multnomah
or Lane counties shall have exclusive jurisdiction over all matters regarding
this Agreement, except that Datalogic shall have the right, at its absolute discretion, to initiate proceedings in the courts of any other state, country, or territory in which End User resides, or in which any of End User's assets are
located.
11.5 Attorneys' Fees. In the event an action is brought to enforce the terms and
conditions of this Agreement, the prevailing party shall be entitled to reasonable attorneys' fees, both at trial and on appeal.
- END -
Software Product Policy
Datalogic reserves the right to ship its products with the latest
version of software/firmware available. This provides our customers with the very latest in Datalogic software technology.
The only exception to this policy is when the buyer has a signed
contract with Datalogic that clearly defines the terms and conditions for making software/firmware changes in products shipped
to the buyer.
Customers Under Software Support
Customers that elect to subscribe to Datalogic Software Maintenance and Support Agreement will receive 30 days advance notification of: (1) the release of a new software version; and/or (2)
discontinuation of any prior software version that will no longer
be supported. Datalogic will provide maintenance for a fee that
will assist customers in transitioning to the next software version. If a customer is currently using the software version being
discontinued, the customer may elect to transition to any one of
the newer versions, depending on the hardware in use.
To arrange for a Software Maintenance and Support Agreement
please contact your Datalogic sales person.
Quick Reference Guide 1
QuickScan™ QM24XX
Description
With rich feature sets and extensive options, the QuickScan™
product series from Datalogic represents the premium level of
data collection equipment for general purpose applications.
The QuickScan QM24XX readers have enhanced optics with
improved motion tolerance allowing codes placed on fast
moving objects to be easily and quickly captured, creating the
ideal reader for tasks requiring high throughput like those
found in retail and light industrial environments.
OmniDirectional
Operation
To read a symbol simply aim the reader and pull
the trigger. The QuickScan™ QM24XX is a powerful
omni-directional reader, so the orientation of the
symbol is not important.
Datalogic’s exclusive patented ‘Green Spot’ for
good-read feedback helps to improve productivity
in noisy environments or in situations where
silence is required. When using the product with
the cradle at a 45° position, the Green Spot can
work as an aiming system to aid in positioning the
bar code for quick and intuitive reading.
Decoding
Reliably decodes all standard 1D (linear) and 2D
bar codes, including GS1 DataBar™ linear codes,
Postal Codes (China Post), Stacked Codes (such as
GS1 DataBar Expanded Stacked, GS1 DataBar
Stacked, GS1 DataBar, Stacked Omnidirectional).
The data stream — acquired from decoding a
symbol — is rapidly sent to the host. The reader is
immediately available to read another symbol.
Setting Up the Reader
2 QuickScan™ QM24XX
Setting Up the Reader
Follow the steps below to connect and get your reader up and
communicating with its host.
1. Configure the Base Station starting on this page.
2. Charge the Batteries (see page 8).
3. Link to the Base Station (see page 14).
4. Select the Interface Type (see page 15).
5. Configure the Reader starting on page 26 (optional,
depends on settings needed).
Locking the Reader to the Base
The Base Station provides a locking mechanism to ensure
electrical contact between Reader and Base, in case of inadvertent movements.
To Lock the Reader in the Base
1. Insert the Reader into the Base. The lock lever rests in
its natural disengaged position toward the bottom of
the Base.
Lock lever
Setting Up the Reader
Quick Reference Guide 3
Figure 1. Lock lever disengaged
2. Engage the locking mechanism by pushing up the lever
as far as it will go.
Figure 2. Lever in locked position
It is good practice to put the scanner in the locked
condition at the end of the working shift, or when
not in use for an extended period of time. This will
ensure that the scanner is fully seated for complete battery recharge.
Connecting the Base Station
4 QuickScan™ QM24XX
Connecting the Base Station
Figure 3 shows how to connect the Base Station to a termi-
nal, PC or other host device. Turn off the host before connection and consult the manual for that equipment (if necessary)
before proceeding. Connect the interface cable before applying power to the Base Station.
Base Station Connection and Routing
1. Remove the rubber Cable Stopper from the bottom of
the Base Station.
2. Securely plug the Power Cable and Interface (I/F) Cable
connectors into their respective ports in the underside
of the Base Station.
The QuickScan QM24XX can also be Powered by
the Terminal. When powered by the Terminal, the
battery charger is automatically set as Slow
charge.
For some specific interfaces or hosts or lengths of
cable, the use of an external power supply may be
recommended for full recharging capability (see
"Technical Specifications" on page 32 for more
details).
Cable Stopper
Power Cable
I/F Cable
Connecting the Base Station
Quick Reference Guide 5
3. After the cables are plugged in, reinsert the rubber
Cable Stopper.
4. Connect to an AC Adapter, and plug the AC power cord
into the (wall) outlet.
Figure 3. Connecting the Base Station
Host Connection —
Verify before connection that the reader’s
cable type is compatible with your host equipment.
Most connections plug directly into the host device as shown
in Figure 4. Keyboard Wedge interface cables have a ‘Y’ connection where its female end mates with the male end of the
cable from the keyboard and the remaining end at the keyboard port on the terminal/PC.
Cable Stopper
reinserted
Base
Station
I/F Cable
AC/DC
Adapter
DC Power
Cord
Wall plug
Connector
Connecting the Base Station
6 QuickScan™ QM24XX
Figure 4. Connecting to the Host
Power Connection —
Plug the AC Adapter into an approved AC
wall socket with the cable facing downwards (as shown in
Figure 3) to prevent undue strain on the socket.
System and Network Layouts
Stand Alone Layout
Figure 5. Reader Layout
U
S
B
I
B
M
K
e
y
b
o
a
r
d
W
e
d
g
e
W
a
n
d
or...
or...
or...
Reader
Base Station
Host
Connecting the Base Station
Quick Reference Guide 7
Using the BC20XX™ Radio Base
Radio Base LEDs
LEDs on the QuickScan Base provide information about the
Base as well as battery charging status, as shown in Figure 6.
Figure 6. QuickScan Base LEDs
Table 1. Radio Base LEDs
LED STATUS
Power on /
Data
Yellow On = Base is powered
Yellow Blinking = Base receives data and
commands from the Host or the Reader.
Charging Red On = the Battery is charging.
Charge completed
Green On = the Battery is completely
charged.
Charging +
Charge completed
Red and Green Blinking together = the
Reader is not correctly placed onto the
Base.
Yellow LED
Red LED /
Green LED
Charging the Batteries
8 QuickScan™ QM24XX
Charging the Batteries
The battery can be charged by connecting the reader directly
to a host through the micro-USB connector available in the
bottom of the handle, as shown.
Alternatively, simply insert the QuickScan into the base. When
the scanner is fully seated in the cradle, it will sound a “chirp”
to indicate that the cradle has detected the scanner connection.
The LEDs on the base (shown in Table 1 on page 7) will indicate the status of the battery.
Battery Safety
To install, charge and/or perform any other action on the battery, follow the instructions in this manual.
Before using the Battery, read “Battery Safety” in
the following section. Datalogic recommends
annual replacement of rechargeable battery
packs to ensure maximum performance.
WARNING
Do not discharge the battery using any device
except for the scanner. When the battery is
used in devices other than the designated
product, it may damage the battery or reduce
its life expectancy. If the device causes an
abnormal current to flow, it may cause the
battery to become hot, explode or ignite and
cause serious injury.
Lithium-ion battery packs may get hot,
explode or ignite and cause serious injury if
exposed to abusive conditions. Be sure to follow the safety warnings listed on the following page.
Micro-USB
Connector
Charging the Batteries
Quick Reference Guide 9
WARNING
•Do not place the battery pack in fire or
heat.
•Do not connect the positive terminal and
negative terminal of the battery pack to
each other with any metal object (such as
wire).
•Do not carry or store the battery pack
together with metal objects.
•Do not pierce the battery pack with nails,
strike it with a hammer, step on it or otherwise subject it to strong impacts or
shocks.
•Do not solder directly onto the battery
pack.
•Do not expose the battery pack to liquids,
or allow the battery to get wet.
•Do not apply voltages to the battery pack
contacts.
WARNING
In the event the battery pack leaks and the
fluid gets into your eye, do not rub the eye.
Rinse well with water and immediately seek
medical care. If left untreated, the battery fluid
could cause damage to the eye.
CAUTION
Always charge the battery at 32° – 104°F (0° 40°C) temperature range.
Use only the authorized power supplies, battery pack, chargers, and docks supplied by
your Datalogic reseller. The use of any other
power supplies can damage the device and
void your warranty.
Do not disassemble or modify the battery. The
battery contains safety and protection devices,
which, if damaged, may cause the battery to
generate heat, explode or ignite.
Charging the Batteries
10 QuickScan™ QM24XX
As with other battery types, Lithium-Ion (LI) batteries will lose
capacity over time. Capacity deterioration is noticeable after
one year of service whether the battery is in use or not. It is
difficult to precisely predict the finite life of a LI battery, but
cell manufacturers rate them at 500 charge cycles. In other
words, the batteries should be expected to take 500 full discharge/charge cycles before needing replacement. This number is higher if partial discharging/recharging is adhered to
rather than full/deep discharging.
CAUTION
Do not place the battery in or near fire, on
stoves or other high temperature locations.
Do not place the battery in direct sunlight, or
use or store the battery inside cars in hot
weather. Doing so may cause the battery to
generate heat, explode or ignite. Using the
battery in this manner may also result in a
loss of performance and a shortened life
expectancy.
CAUTION
Do not place the battery in microwave ovens,
high-pressure containers or on induction
cookware.
Immediately discontinue use of the battery if,
while using, charging or storing the battery,
the battery emits an unusual smell, feels hot,
changes color or shape, or appears abnormal
in any other way.
Do not replace the battery pack when the
device is turned on.
Do not remove or damage the battery pack’s
label.
CAUTION
Do not use the battery pack if it is damaged in
any part.
Battery pack usage by children should be
supervised.
CAUTION
Storage of batteries for long time at fully charged
status or at fully discharged status should be
avoided.
Charging the Batteries
Quick Reference Guide 11
The useful life of LI batteries depends on usage and number
of charges, etc., after which they should be removed from service, especially in mission critical applications. Do not continue to use a battery showing excessive loss of capacity, it
should be properly recycled / disposed of and replaced.
Collect and recycle waste batteries separately from the device
to comply with European Directive 2006/66/EC, 2011/65/EU,
2002/96/EC and 2012/19/EU and subsequent modifications,
US and China regulatory and other laws and regulations about
the environment.
Replacing the Battery Pack
1. Using a coin or a screwdriver, unscrew the bottom of
the battery pack until it is disengaged.
The battery pack will rise slightly in the rear, pushed by
the contact springs.
CAUTION
Only in case of long storage, to avoid deep discharge of the battery it is recommended to partially recharge the battery every three months to
keep the charge status at a medium level.
As a reference, run a fast recharge for 20 minutes
every three months on unused products to avoid
any performance deterioration of the cell.
Before proceeding, read “Battery Safety” on
the preceding pages. Datalogic recommends
annual replacement of rechargeable battery
packs to ensure maximum performance.
Charging the Batteries
12 QuickScan™ QM24XX
2. Extract the battery pack by slightly rotating the pack
and pulling away from the reader.
To mount the new battery pack reverse the process:
1. Insert the top of the new pack inside the reader’s handle.
2. Rotate the battery pack downward while pressing the
bottom side of the battery pack (to seat securely into
the contacts springs) so that the edges of the pack and
the handle board are aligned, while replacing the screw
in the bottom of the handle.
Using the Quickscan™ QM24XX
Quick Reference Guide 13
Using the Quickscan™ QM24XX
The Quickscan™ QM24XX normally functions by capturing and
decoding codes. The aiming system is activated on trigger pull
and indicates the center of the field of view which should be
positioned over the bar code:
Aiming System
Relative Size and Location of Aiming System Pattern
A beam illuminates the label. The projected pattern of the
aiming system will be smaller when the reader is closer to the
bar code and larger when it is farther from the code. Symbologies with smaller bars or elements (mil size) should be read
closer to the unit. Symbologies with larger bars or elements
(mil size) should be read farther from the unit.
If the aiming system is centered you will get a good read. Successful reading is signaled by an audible tone plus a goodread green spot LED indicator.
Reference the QuickScan QM24XX Product Reference Guide
(PRG) on the Datalogic website for more information about
this feature and other programmable settings.
Linear bar code
2D Matrix symbol
Linking the Reader
14 QuickScan™ QM24XX
Linking the Reader
Link Datalogic RF Devices to Base
For RF devices, before configuring the interface it is necessary
to link the handheld with the base.
To link the handheld and the base, either press the trigger to
wake it, or simply mount into the base to wake up for operation. If the reader was previously linked to another base, you
must first scan the
Unlink
bar code before re-linking to the
new base.
Power Off
Scan the bar code below to shut off power to the handheld
until the next trigger pull.
PowerOff
Unlink
Selecting the Base Interface Type
Quick Reference Guide 15
Selecting the Base Interface Type
Upon completing the physical connection between the base
and its host, proceed directly to Interface Selection (below) for
information and programming for the interface type the base
is connected to (for example: RS-232, Keyboard Wedge, USB,
etc.) and scan the appropriate bar code to select your system’s correct interface type.
Interface Selection
The base will support the following host interfaces:
•RS-232
• RS-232 OPOS
•USB
• Keyboard Wedge
For defaults and additional information associated with each
interface, proceed to the corresponding chapter in the QuickScan Q24XX PRG.
Configuring the Interface
Scan the programming bar code which selects the appropriate
interface type for the system the reader will be connected to.
Unlike some other programming features and
options, interface selections require that you
scan only one programming bar code label. DO
NOT scan an ENTER/EXIT bar code prior to
scanning an interface selection bar code.
Some interfaces require the scanner to start in
the disabled state when powered up. If additional scanner configuration is desired while
in this state, pull the trigger and hold for 5
seconds. The scanner will change to a state
that allows programming with bar codes.
Selecting the Base Interface Type
16 QuickScan™ QM24XX
RS-232
RS-232 standard interface
Select RS232-STD
RS-232 Wincor-Nixdorf
Select RS232-WN
RS-232 for use with OPOS/UPOS/JavaPOS
Select RS-232 OPOS
USB COM to simulate RS-232 standard interface
Select USB-COM-STD
a
USB-OEM
USB-OEM
(can be used for OPOS/UPOS/JavaPOS)
Select USB-OEM
a. Download the correct USB COM driver from www.datalogic.com
Selecting the Base Interface Type
Quick Reference Guide 17
Keyboard Interface
Use the programming bar codes to select options for
USB Keyboard and Wedge Interfaces.
KEYBOARD
AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70, 80, 90 & 95 w/
Standard Key Encoding
Select KBD-AT
Keyboard Wedge for IBM AT PS2 with standard key encoding
but without external keyboard
Select KBD-AT-NK
AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70, 80, 90 & 95
w/Alternate Key
Select KBD-AT-ALT
Keyboard Wedge for IBM AT PS2 with alternate key encoding
but without external keyboard
Select KBD-AT-ALT-NK
Selecting the Base Interface Type
18 QuickScan™ QM24XX
KEYBOARD (continued)
PC/XT w/Standard Key Encoding
Select KBD-XT
Keyboard Wedge for IBM Terminal 3153
Select KBD-IBM-3153
Keyboard Wedge for IBM Terminals 31xx, 32xx, 34xx, 37xx
make only keyboard
Select KBD-IBM-M
Keyboard Wedge for IBM Terminals 31xx, 32xx, 34xx, 37xx
make break keyboard
Select KBD-IBM-MB
USB Keyboard with alternate key encoding
Select USB Alternate Keyboard
Selecting the Base Interface Type
Quick Reference Guide 19
Scancode Tables
Reference the QuickScan QM24XX ™ PRG for information
about control character emulation which applies to keyboard
interfaces.
Country Mode
This feature specifies the country/language supported by the
keyboard. Only these interfaces support ALL Country Modes:
• USB Keyboard (without alternate key encoding)
• AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70, 80, 90 & 95
w/Std Key Encoding
• Keyboard Wedge for IBM AT PS2 with standard key
encoding but without external keyboard
• AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70, 80, 90 & 95
without Alternate Key
• Keyboard Wedge for IBM AT PS2 without alternate
key encoding but without external keyboard
KEYBOARD (continued)
USB Keyboard for Apple computers
Select USB-KBD-APPLE
Keyboard Wedge for DIGITAL Terminals
VT2xx, VT3xx, VT4xx
Select KBD-DIG-VT
USB Keyboard with standard key encoding
Select USB Keyboard
Selecting the Base Interface Type
20 QuickScan™ QM24XX
All other interfaces support ONLY the following Country
Modes: U.S., Belgium, Britain, France, Germany, Italy, Spain,
Sweden.
COUNTRY MODE
ENTER/EXIT PROGRAMMING MODE
Country Mode = U.S.
Country Mode = Belgium
Country Mode = Britain
Country Mode = Croatia*
*
Supports only the interfaces listed in the Country Mode feature description
Selecting the Base Interface Type
Quick Reference Guide 21
COUNTRY MODE (continued)
Country Mode = Czech Republic*
Country Mode = Denmark*
Country Mode = France
Country Mode = Germany
Country Mode = Hungary*
Country Mode = Italy
*
Supports only the interfaces listed in the Country Mode feature description
Selecting the Base Interface Type
22 QuickScan™ QM24XX
COUNTRY MODE (continued)
Country Mode = Japanese 106-key*
Country Mode = Norway*
Country Mode = Poland*
Country Mode = Portugal*
Country Mode = Romania*
Country Mode = Spain
*
Supports only the interfaces listed in the Country Mode feature description
Selecting the Base Interface Type
Quick Reference Guide 23
COUNTRY MODE (continued)
Country Mode = Sweden
Country Mode = Slovakia*
Country Mode = Switzerland*
*
Supports only the interfaces listed in the Country Mode feature description
Selecting the Base Interface Type
24 QuickScan™ QM24XX
Caps Lock State
This option specifies the format in which the reader sends
character data. This applies to keyboard wedge interfaces.
This does not apply when an alternate key encoding keyboard
is selected.
ENTER/EXIT PROGRAMMING MODE
Caps Lock State = Caps Lock OFF
Caps Lock State = Caps Lock ON
Caps Lock State = AUTO Caps Lock Enable
Selecting the Base Interface Type
Quick Reference Guide 25
Numlock
This option specifies the setting of the Numbers Lock (Numlock) key while in keyboard wedge interface. This only applies
to alternate key encoding interfaces. It does not apply to USB
keyboard.
ENTER/EXIT PROGRAMMING MODE
Numlock = Numlock key unchanged
Numlock = Numlock key toggled
Programming
26 QuickScan™ QM24XX
Programming
The reader is factory-configured with a set of standard
default features. After scanning the interface bar code from
the Interfaces section, select other options and customize
your reader through use of the programming bar codes available in the Product Reference Guide (PRG). Check the corresponding features section for your interface, and also the
Data Editing and Symbologies chapters.
Using Programming Bar Codes
This manual contains bar codes which allow you to reconfigure your reader. Some programming bar code labels, like the
"Standard Product Default Settings" on page 26, require only
the scan of that single label to enact the change.
Other bar codes require the reader to be placed in Programming Mode prior to scanning them. Scan an ENTER/EXIT bar
code once to enter Programming Mode; scan the desired
parameter settings; scan the ENTER/EXIT bar code again to
accept your changes, which exits Programming Mode and
returns the reader to normal operation.
Configure Other Settings
Additional programming bar codes are available in the PRG to
allow for customizing programming features. If your installation requires different programming than the standard factory default settings, refer to the PRG.
Resetting Standard Product Defaults
Reference the PRG for a listing of standard factory settings. If
you aren’t sure what programming options are in your reader,
or you’ve changed some options and want the factory settings restored, scan the
Standard Product Default Settings
bar
code below to copy the factory configuration for the currently
active interface to the current configuration.
Factory defaults are based on the interface
type. Configure the reader for the correct interface before scanning this label.
Standard Product Default Settings
Reading Parameters
Quick Reference Guide 27
Reading Parameters
Point the reader at the target and pull the trigger to enable
the aiming system and the illuminator (red beam) to decode
the barcode label. The aiming system will briefly switch off
during the acquisition time and if no code is decoded will
switch on again before the next acquisition. The illuminator
will remain on until the symbol is decoded.
As you read code symbols, adjust the distance at which you
are holding the reader.
Aiming System
A number of options for customizing control of the Aiming
System are available. See the PRG for more information and
programming bar codes.
Reading Parameters
28 QuickScan™ QM24XX
Good Read Green Spot Duration
Successful reading can be signaled by a good read green spot.
Use the bar codes below to specify the duration of the good
read pointer beam after a good read.
ENTER/EXIT PROGRAMMING MODE
Green Spot Duration = Disable (Green Spot is Off)
♦
Green Spot Duration = Short (300 msec)
Green Spot Duration = Medium (500 msec)
Green Spot Duration = Long (800 msec)
Scan Modes
Quick Reference Guide 29
Scan Modes
The imager can operate in one of several scanning modes.
Trigger Single —
When the trigger is pulled, scanning is acti-
vated until one of the following occurs:
• a programmable duration
1
has elapsed
• a label has been read
• the trigger is released
This mode is associated with typical handheld reader operation.
Trigger Hold Multiple —
When the trigger is pulled, scanning
starts and the product scans until the trigger is released or a
programmable duration
1
has elapsed. Reading a label does
not disable scanning. Double Read Timeout
1
prevents unde-
sired multiple reads while in this mode.
Trigger Pulse Multiple —
When the trigger is pulled and
released, scanning is activated until programmable duration1
has elapsed or the trigger has been pulled again to transition
to another state. Double Read Timeout
1
prevents undesired
multiple reads while in this mode.
Flashing —
The reader flashes1 on and off regardless of the
trigger status.
Always On —
No trigger pull is required to read a bar code.
Scanning is continually on. If the trigger is pulled, the reader
acts as if it is in Trigger Single Mode. Double Read Timeout
1
prevents undesired multiple reads while in this mode.
Stand Mode —
No trigger pull is required to read a bar code.
Scanning is turned on automatically when an item is placed in
reader’s field of view. If the trigger is pulled, the reader acts as
if it is in Single Read
mode. Double Read Timeout
1
prevents
undesired multiple reads while in this mode.
1. See the Product Reference Guide (PRG) for more information
Scan Modes
30 QuickScan™ QM24XX
SCAN MODE
ENTER/EXIT PROGRAMMING MODE
♦
Scan Mode = Trigger Single
Scan Mode = Trigger Hold Multiple
Scan Mode = Trigger Pulse Multiple
Scan Mode = Flashing
Scan Mode = Always On
Scan Mode = Stand Mode
Scan Modes
Quick Reference Guide 31
Pick Mode
Pick Mode is a Decoding and Transmission process where bar
codes that are not within the configurable distance from the
center of the aiming pattern are not acknowledged or transmitted to the host. It is active only while the scanner is in
Trigger Single mode. If the scanner switches to a different
Read Mode, Pick Mode is automatically disabled.
Multiple Labels in a Volume
Enables/disables the ability of scanner to decode multiple
labels in the same image. Several programming options are
available for this feature, see the PRG for more information.
This feature is not compatible with Multiple
Labels Reading in a Volume. See the PRG for
more information.
ENTER/EXIT PROGRAMMING MODE
♦
Pick Mode = Disable
Pick Mode = Enable
Technical Specifications
32 QuickScan™ QM24XX
Technical Specifications
The following table contains Physical and Performance Characteristics, User Environment and Regulatory information.
Physical Characteristics
Color White or Black
Dimensions
Height 6.4”/163 mm
Length 3.6”/91 mm
Width 1.6”/41 mm
Weight (without cable)
Approximately
200 g (reader)
230 g (base charger)
Electrical Characteristics
Battery Type Li-Ion battery pack
6 hours with Host Power through the
micro USB cable connection
Typical charge time for
full charge from full
discharge
4 hours with Base and 12V external
power supply adapter
a
Max 22 hours with Base and Host
power (in this case no supply adapter
is needed)
a
Operating autonomy
(continuous reading)
30,000 reads
(typical)
Cradle consumption
and DC input supply
range
Volt 4.75-14 VDC; Power <8W
b
;
Imax 500mA when in host/bus powered mode
b
.
Performance Characteristics
Light Source LEDs
Roll (Tilt) Angle
c
Up to ± 180°
Technical Specifications
Quick Reference Guide 33
Pitch Angle
c.
± 40°
Skew (Yaw) Angle
c.
± 40°
Field of View 40° H x 26° V
a. Charge Times are much lower when battery is within daily typical operating
condition.
b. Typical input current measured under factory default configuration.
c. Based on ISO 15423 specifications
Depth of Field (Typical)
a
a. 13 mils DOF based on EAN. All other 1D codes are Code 39. All labels grade
A, typical environmental light, 20°C, label inclination 10°
Symbology
Code 39
5mil: 0.2" - 5.9" (0.5 - 15cm)
10mil: 0" - 8.7" (0 - 22cm)
20mil: up to 16" (40cm)
EAN
7.5mil: 0" - 5.9" (0 - 15cm)
13mil: 0.2" - 13.8" (0.5 - 35cm)
PDF-417
6.6mil: 0.39" - 5.1" (1.0 - 130cm)
10mil: 0" - 8.3" (0 - 21cm)
15mil: 0.2" - 9.5" (0.5 - 24cm)
DataMatrix
10mil: 0.39" - 5.1" (1.0 - 13 cm)
15mil: 0" - 7.1" (0 - 18cm)
QR Code
10mil: 0.2" - 5.1" (0.5 - 13cm)
15mil: 0" - 7.1" (0 - 18cm)
Minimum
Element Width
Standard Range:
1D Min Resolution = 4 mil
PDF-417 Min Resolution = 5 mil
Datamatrix Min Resolution = 7.5 mil
Technical Specifications
34 QuickScan™ QM24XX
Decode Capability
1D Bar Codes
UPC/EAN/JAN (A, E, 13, 8); UPC/EAN/JAN (including P2 /P5);
UPC/EAN/JAN (including; ISBN / Bookland & ISSN); UPC/EAN
Coupons; Code 39 (including full ASCII); Code 39 Trioptic; Code39
CIP (French Pharmaceutical); LOGMARS (Code 39 w/ standard
check digit enabled); Danish PPT; Code 32 (Italian Pharmacode 39);
Code 128; Code 128 ISBT; Interleaved 2 of 5; Standard 2 of 5; Interleaved 2 of 5 CIP (HR); Industrial 2 of 5; Discrete 2 of 5; Datalogic 2
of 5 (China Post Code/Chinese 2 of 5); IATA 2of5 Air cargo code;
Code 11; Codabar; Codabar (NW7); ABC Codabar; Code 93; MSI;
PZN; Plessey; Anker Plessey; Follet 2 of 5; GS1 DataBar Omnidirectional; GS1 DataBar Limited; GS1 DataBar Expanded; GS1
DataBar Truncated; DATABAR Expanded Coupon.
2D / Stacked Codes
The QuickScan QM24XX scanner is capable of decoding the following symbologies using multiple frames (i.e. Multi-Frame
Decoding):
PDF-417; QR Code; Aztec; Datamatrix; Inverse Datamatrix; Datamatrix is configurable for the following parameters:; Normal or
Inverted; Square or Rectangular Style; Data length (1 - 3600 characters); Maxicode; QR Codes (QR, Micro QR and Multiple QR
Codes); Aztec; Postal Codes; Australian Post; Japanese Post; KIX
Post; Planet Code; Postnet; Royal Mail Code (RM45CC); Intelligent
Mail Bar Code (IMB); Sweden Post; Portugal Post; LaPoste A/R 39;
4-State Canada; PDF-417; MacroPDF; Micro PDF417; GS1 Composites (1 - 12); Codablock F; French CIP13
a
; GS1 DataBar Stacked;
GS1 DataBar Stacked Omnidirectional; GS1 DataBar Expanded
Stacked; GSI Databar Composites; Chinese Sensible Code; Inverted
2D codes.
Note: The reader can apply the Normal/Reverse Decoding Control
to the following symbologies: Datamatrix, QR, Micro QR, Aztec and
Chinese Sensible Code.
Interfaces Supportedb
RS-232 Std, RS-232 Wincor-Nixdorf, RS-232 OPOS, USB Com Std.,
USB Keyboard, USB Alternate Keyboard, USB OEM, Keyboard
Wedge (AT with or w/o Alternate Key, IBM AT PS2 with or w/o
Alternate Key, PC-XT, IBM 3153, IBM Terminals 31xx, 32xx,34xx,
37xx make only and make break keyboard, Digital Terminals VT2x,
VT3xx, VT4xx, and Apple).
Technical Specifications
Quick Reference Guide 35
User Environment
Operating Temperature
32° to 122° F (0° to 50° C)
Charging Temperature
32° to 104° F (0° to 40° C)
Storage Temperature
-4° to 158° F (-20° to 70° C)
Humidity
Operating: 5% to 90% relative humidity,
non-condensing
Drop Specifications
Scanner withstands 18 drops from 1.5
meters (4.9 feet) to concrete
Ambient Light
Immunity
Up to 100,000 Lux
Contaminants
Spray/rain Dust/
particulates
IEC 529-IP42 (scanner only)
ESD Level 16 KV
a. It is acceptable to handle this with ULE
b. See "Interface Selection" on page 15 for a listing of available interface sets
by version type.
Regulatory
Electrical Safety UL 60950, CSA C22.2 No. 60950, IEC 60950
EMI/RFI
Europe; Russia; Australia; China;
Singapore; Mexico
LED and Beeper Indications
36 QuickScan™ QM24XX
LED and Beeper Indications
The reader’s beeper sounds and its LED illuminates to indicate various functions or errors on the reader. An optional
“Green Spot” also performs useful functions. The following
tables list these indications. One exception to the behaviors
listed in the tables is that the reader’s functions are programmable, and so may or may not be turned on. For example, certain indications such as the power-up beep can be disabled
using programming bar code labels.
Radio Features
Frequency working center 433MHz
Range (in open air) 25 m
Max number of devices per
base station
16
Indication Description LED Beeper
Power-up Beep
The reader is in the process of powering-up.
N/A
Reader beeps four
times at highest frequency and volume
upon power-up.
Good Read Beep
A label has been successfully scanned by the
reader.
LED behavior for this
indication is configurable via the feature
“Good Read: When to
Indicate”
(see the PRG for information.)
The reader will beep
once at current frequency, volume,
mono/bi-tonal setting
and duration upon a
successful label scan.
ROM Failure
There is an error in the
reader's software/programming
Flashes
Reader sounds one
error beep at highest
volume.
Limited Scanning
Label Read
Indicates that a host connection is not established when the IBM or
USB interface is enabled.
N/A
Reader 'chirps' six
times at the highest
frequency and current
volume.
Reader Active
Mode
The reader is active and
ready to scan.
The LED is lit steadily
a
N/A
LED and Beeper Indications
Quick Reference Guide 37
a Except when in sleep mode or when a Good Read LED Duration other than
00 is selected
Programming Mode
- The following indications ONLY occur when
the reader is in Programming Mode.
Reader
Disabled
The reader has been disabled by the host.
The LED blinks continuously
N/A
Green Spot
a
flashes momentarily
Upon successful read of a
label, the software shall
turn the green spot on
for the time specified by
the configured value.
N/A N/A
Indication Description LED Beeper
Label Programming
Mode Entry
A valid programming
label has been scanned.
LED blinks con-
tinuously
Reader sounds four
low frequency beeps.
Label Programming
Mode Rejection of Label
A label has been rejected. N/A
Reader sounds three
times at lowest frequency and current
volume.
Label Programming
Mode Acceptance of Partial Label
In cases where multiple
labels must be scanned to
program one feature, this
indication acknowledges
each portion as it is successfully scanned.
N/A
Reader sounds one
short beep at highest
frequency and current
volume.
Label Programming
Mode Acceptance of Programming
Configuration option(s)
have been successfully
programmed via labels
and the reader has exited
Programming Mode.
N/A
Reader sounds one
high frequency beep
and 4 low frequency
beeps followed by
reset beeps.
Label Programming
Mode Cancel Item Entry
Cancel label has been
scanned.
N/A
Reader sounds two
times at low frequency and current
volume.
Indication Description LED Beeper
Error Codes
38 QuickScan™ QM24XX
Error Codes
Upon startup, if the reader sounds a long tone, this means the
reader has not passed its automatic Selftest and has entered
FRU (Field Replaceable Unit) isolation mode. If the reader is
reset, the sequence will be repeated. The following table
describes the LED flashes/beep codes associated with an
error found.
Number of
LED Flashes/
Beeps
Error Corrective Action
1 Configuration
Contact Helpdesk
for assistance
2 Interface PCB
6 Digital PCB
12 Imager
Base Station Indications
Quick Reference Guide 39
Base Station Indications
Indication LEDS
Power-up Complete Yellow LED on
Reader Disabled by the HOST or
the communication with HOST is
not established
Yellow LED blinking
~1Hz
Data/labels are transmitted to
the HOST
Yellow LEDs turned off
for 100mSec
Programming Mode
Yellow LED blinks
quickly
Configuration alignment with
the HH is in progress
Red LED blinks quickly
Battery charger in progress Red LED on
Battery charger complete Green LED on
Battery charger error
Green LED and Red LEDs
blink alternatively ~1Hz
No HH is placed on the cradle Red and Green LEDs off
Regulatory Information
40 QuickScan™ QM24XX
Regulatory Information
All versions of the reader are designed to be compliant with
rules and regulations in locations they are sold and will be
labeled as required.
Any changes or modifications to equipment, not expressly
approved by Datalogic could void the user's authority to operate the equipment.
Statement of Agency Compliance
This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must
accept any interference received, including interference that
may cause undesired operation. Any change or modification
to the product not expressly approved by Datalogic could void
the user's authority to operate the device.
FCC Class B Compliance Statement
The user is cautioned that changes or modifications not
expressly approved by the part responsible for compliance
could void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the
limits for a Class B digital device pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio or television technician for help.
Regulatory Information
Quick Reference Guide 41
FCC RF Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits
under Specific Absorption Rate (SAR) tests for portable
devices operating closer than 20 cm to nearby persons, set
forth in an uncontrolled environment. The QuickScan QM24XX
cordless imaging reader has been demonstrated to meet
these RF emissions safety limits.
Canadian Notice
This equipment does not exceed the Class B limits for radio
noise emissions as described in the Radio Interference Regulations of the Canadian Department of Communications.
Le present appareil numerique n’emet pas de bruits radioelectriques depassant les limites applicables aux appareils
numeriques de la classe B prescrites dans le Reglement sur le
brouillage radioelectrique edicte par le ministere des Communications du Canada.
CAUTION
Do not attempt to open or otherwise service any
components in the optics cavity. Opening or servicing any part of the optics cavity by unauthorized personnel may violate safety regulations.
Regulatory Information
42 QuickScan™ QM24XX
Power Supply
This device is intended to be connected to a UL Listed/CSA
Certified computer which supplies power directly to the
reader or else be supplied by UL Listed/CSA Certified Power
Unit marked “Class 2” or LPS power source rated 5-14V minimum 900mA, which supplies power directly to the Base/
Charger via the power connector of the Base itself.
Adaptador para Fuente de Poder Externa
Imager Labeling
Sample labels are shown here to illustrate their location only.
Please view the labels on your product for actual details, as
they may vary from those depicted.
Atencíon
Características de la
fuente de alimentación
eléctrica.
Entrada:
100 - 240 Vca
min .35A 50-60 Hz
Salida:
+5VDC, máx 2.5A
(-)Negativo al centro
Entrada:
100 - 240 Vca
min 0.6A 50-60 Hz
Salida:
+12VDC, máx 1.5A
(-)Negativo al centro
Utilice en su red solo fuentes certificadas en Argentina.
El uso de fuentes de alimentación no compatibles puede resultar
en riesgo de incendio o de choque eléctrico para el usuario.
ME10
.gnitsiltnetaprofegakcapdnalaunamtcudorpeeS
CLASS 1 LED PRODUCT .
N263
10
Scanner Regulatory Label
Regulatory Information
Quick Reference Guide 43
China RoHS Table of Restricted Elements
Quickscan® QM24XX China RoHS
㒊௳ྡ⛠
Lead
(Pb)
Mercury
(Hg)
Cadmium
(Cd)
Hexavalent
Chromium
(Cr(VI))
Polybrominated
biphenyls
(PBB)
Polybrominated
diphenyl ethers
(PBDE)
᭷ẘ᭷ᐖ≀峐ᡈඖ⣲
PART
摭
ợ
擱
භ௴撔
ከ㹜俼劗
ከ㹜Ḵ劗慂
Cable
⭥
㔶
X O O O O O
Printed Circuit Board Assy
⭥䐟ᶯ㓴
X O O O O O
Assembly, Module
ݹᆖ㓴Ԧ
X O O O O O
Power Supply
⭥Ⓚ
X O O O O O
O
௦⾲Ṉ䥵㒊௳ⓗᡤ᭷ᆒ峐㛸㕁⏓䘬宍䥵㚱㭺㚱⭛䈑峐⛯ỶḶ⋶Ṣ㮹ℙ⚥ᾉ〗ṏ悐ᡤ栩ⶫⓗ
ࠓ䓝⫸ᾉ〗ṏ⑩㚱㭺㚱⭛䈑峐䘬旸慷天㯪˫(SJ/T 11363-2006) 奬⭂䘬旸慷ࠋ
X:௦⾲
Ṉ䥵㒊௳ᡤ⏝ⓗᆒ峐㛸㕁, ⮳ᑡ᭷୍䰣ᮦᩱᡤྵⓗ᭷ẘ᭷ᐖ≀峐檀Ḷ⋶Ṣ㮹ℙ⚥ᾉ〗ṏ悐ᡤ栩ⶫⓗ
ࠓ䓝⫸ᾉ〗ṏ⑩㚱㭺㚱⭛䈑峐䘬旸慷天㯪˫(SJ/T 11363-2006) 奬⭂䘬旸㔞
EFUP determined by “Look-up Method” (scanner).ġġ䍗ᾅἧ䓐㛇旸⍾⅛Ḷ“㞍堐㱽”㸦㈓㍷Ẓ炸
Regulatory Information
44 QuickScan™ QM24XX
WEEE Statement
English
For information about the disposal of Waste Electrical
and Electronic Equipment (WEEE), please refer to the
website at www.datalogic.com.
Italian
Per informazioni sullo smaltimento delle
apparecchiature elettriche ed elettroniche consultare il
sito Web www.datalogic.com.
French
Pour toute information relative à l’élimination des
déchets électroniques (WEEE), veuillez consulter le site
internet www.datalogic.com.
German
Informationen zur Entsorgung von Elektro- und
Elektronik- Altgeräten (WEEE) erhalten Sie auf der
Webseite www.datalogic.com.
Spanish
Si desea información acerca de los procedimientos para
el desecho de los residuos del equipo eléctrico y
electrónico (WEEE), visite la página Web
www.datalogic.com.
Portuguese
Para informações sobre a disposição de Sucatagem de
Equipamentos Elétricos e Eletrônicos (WEEE -Waste
Electrical and Electronic Equipment), consultar o site
web www.datalogic.com.
Chinese
有关处理废弃电气电子设备
(WEEE)
的信息， 请参考
Datalog-
ic
公司的网站
www.datalogic.com
。
Japanese
廃電気電子機器
(WEEE)
の処理についての関連事項は
Datalogic
のサイト www.datalogic.com をご参照下さ
い。
Waste Electrical and Electronic
Equipment (WEEE) Statement
Regulatory Information
Quick Reference Guide 45
Datalogic ADC Limited Factory Warranty
Warranty Coverage
Datalogic ADC (“Datalogic”) hardware products are warranted
against defects in material and workmanship under normal
and proper use. The liability of Datalogic under this warranty
is limited to furnishing the labor and parts necessary to remedy any defect covered by this warranty and restore the product to its normal operating condition. Repair or replacement
of product during the warranty does not extend the original
warranty term. Products are sold on the basis of specifications applicable at the time of manufacture and Datalogic has
no obligation to modify or update products once sold.
If Datalogic determines that a product has defects in material
or workmanship, Datalogic shall, at its sole option repair or
replace the product without additional charge for parts and
labor, or credit or refund the defective products duly returned
to Datalogic. To perform repairs, Datalogic may use new or
reconditioned parts, components, subassemblies or products
that have been tested as meeting applicable specifications for
equivalent new material and products. Customer will allow
Datalogic to scrap all parts removed from the repaired product. The warranty period shall extend from the date of shipment from Datalogic for the duration published by Datalogic
for the product at the time of purchase (Warranty period).
Datalogic warrants repaired hardware devices against defects
in workmanship and materials on the repaired assembly for a
90 day period starting from the date of shipment of the
repaired product from Datalogic or until the expiration of the
original warranty period, whichever is longer. Datalogic does
not guarantee, and it is not responsible for, the maintenance
of, damage to, or loss of configurations, data, and applications
on the repaired units and at its sole discretion can return the
units in the “factory default” configuration or with any software or firmware update available at the time of the repair
(other than the firmware or software installed during the
manufacture of the product). Customer accepts responsibility
to maintain a back up copy of its software and data.
Warranty Claims Process
In order to obtain service under the Factory Warranty, Customer must notify Datalogic of the claimed defect before the
expiration of the applicable Warranty period and obtain from
Datalogic a return authorization number (RMA) for return of
the product to a designated Datalogic service center. If Datalogic determines Customer’s claim is valid, Datalogic will
Regulatory Information
46 QuickScan™ QM24XX
repair or replace product without additional charge for parts
and labor. Customer shall be responsible for packaging and
shipping the product to the designated Datalogic service center, with shipping charges prepaid. Datalogic shall pay for the
return of the product to Customer if the shipment is to a location within the country in which the Datalogic service center is
located. Customer shall be responsible for paying all shipping
charges, duties, taxes, and any other charges for products
returned to any other locations. Failure to follow the applicable RMA policy, may result in a processing fee. Customer shall
be responsible for return shipment expenses for products
which Datalogic, at its sole discretion, determines are not
defective or eligible for warranty repair.
Warranty Exclusions
The Datalogic Factory Warranty shall not apply to:
(i) any product which has been damaged, modified,
altered, repaired or upgraded by other than Datalogic service personnel or its authorized representatives;
(ii) any claimed defect, failure or damage which Data-
logic determines was caused by faulty operations,
improper use, abuse, misuse, wear and tear, negligence, improper storage or use of parts or accessories not approved or supplied by Datalogic;
(iii) any claimed defect or damage caused by the use of
product with any other instrument, equipment or
apparatus;
(iv) any claimed defect or damage caused by the failure
to provide proper maintenance, including but not
limited to cleaning the upper window in accordance
with product manual;
(v) any defect or damage caused by natural or man-
made disaster such as but not limited to fire, water
damage, floods, other natural disasters, vandalism
or abusive events that would cause internal and
external component damage or destruction of the
whole unit, consumable items;
(vi) any damage or malfunctioning caused by non-
restoring action as for example firmware or software upgrades, software or hardware reconfigurations etc.;
(vii) the replacement of upper window/cartridge due to
scratching, stains or other degradation and/or
(viii) any consumable or equivalent (e.g., cables, power
supply, batteries, keypads, touch screen, triggers
etc.).
Regulatory Information
Quick Reference Guide 47
No Assignment
Customer may not assign or otherwise transfer its rights or
obligations under this warranty except to a purchaser or
transferee of product. No attempted assignment or transfer
in violation of this provision shall be valid or binding upon
Datalogic.
DATALOGIC'S LIMITED WARRANTY IS IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, ORAL OR WRITTEN,
STATUTORY OR OTHERWISE, INCLUDING, WITHOUT LIMITATION, ANY IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, OR NONINFRINGEMENT.
DATALOGIC SHALL NOT BE LIABLE FOR ANY DAMAGES SUSTAINED BY CUSTOMER ARISING FROM DELAYS IN THE
REPLACEMENT OR REPAIR OF PRODUCTS UNDER THE
ABOVE. THE REMEDY SET FORTH IN THIS WARRANTY STATEMENT IS THE CUSTOMER’S SOLE AND EXCLUSIVE REMEDY
FOR WARRANTY CLAIMS. UNDER NO CIRCUMSTANCES WILL
DATALOGIC BE LIABLE TO CUSTOMER OR ANY THIRD PARTY
FOR ANY LOST PROFITS, OR ANY INCIDENTAL, CONSEQUENTIAL IN-DIRECT, SPECIAL OR CONTINGENT DAMAGES
REGARDLESS OF WHETHER DATALOGIC HAD ADVANCE
NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.
Risk of Loss
Customer shall bear risk of loss or damage for product in
transit to Datalogic. Datalogic shall assume risk of loss or
damage for product in Datalogic’s possession. In the absence
of specific written instructions for the return of product to
Customer, Datalogic will select the carrier, but Datalogic shall
not thereby assume any liability in connection with the return
shipment.
Ergonomic Recommendations
48 QuickScan™ QM24XX
Ergonomic Recommendations
• Reduce or eliminate repetitive motion
• Maintain a natural position
• Reduce or eliminate excessive force
• Keep frequently used objects within easy reach
• Perform tasks at correct heights
• Reduce or eliminate vibration
• Reduce or eliminate direct pressure
• Provide adjustable workstations
• Provide adequate clearance
• Provide a suitable working environment
• Improve work procedures.
CAUTION
To avoid or minimize potential risk of ergonomic injury follow the recommendations
below. Consult with your local Health & Safety
Manager to ensure you are adhering to your
company’s safety programs to prevent
employee injury.
Ergonomic Recommendations
Quick Reference Guide 49
Cleaning
Exterior surfaces and scan windows exposed to spills,
smudges or debris require periodic cleaning to ensure best
performance during scanning. Contacts on the scanner and
base should also be cleaned as needed to ensure a good connection.
Use a soft, dry cloth to clean the product. If the product is very
soiled, clean it with a soft cloth moistened with a diluted nonaggressive cleaning solution or diluted ethyl alcohol.
CAUTION
Do not use abrasive or aggressive cleansing
agents or abrasive pads to clean scan windows,
contacts or plastics.
Do not spray or pour liquids directly onto the
unit.
Services and Support
50 QuickScan™ QM24XX
Services and Support
Datalogic provides several services as well as technical support through its website. Log on to
www.datalogic.com and
click on the links indicated for further information.
Products
Search to find your product page where you can download
specific
Manuals and Software & Utilities, including:
•
Datalogic Aladdin™, a multi-platform utility pro-
gram that allows device configuration using a PC. It
provides RS-232 interface configuration as well as
bar code printing.
Service & Support
• Technical Support –Product documentation and
programming guides and Technical Support
Departments over the world
•
Service Programs –Warranty Extensions and
Maintenance Agreements
•
Repair Services – Flat Rate Repairs and Return
Material Authorization (RMA) Repairs.
•
Downloads – Manuals & Documentation, Data
Sheets, Product Catalogues, etc.
Contact Us
• Information Request Form and Sales & Service
Network
DECLARATION OF CONFORMITY
La presente dichiarazione di conformità è rilasciata sotto la responsabilità esclusiva di Datalogic
ADC Srl per:
This Declaration of Conformity is issued under the sole responsibility of Datalogic ADC Srl for:
Cette déclaration de conformité est établie sous la seule responsabilité de Datalogic Srl pour:
Diese Konformitätserklärung wird unter der alleinigen Verantwortung des Datalogic ADC Srl
erteilt für:
Esta declaración de conformidad se expide bajo la exclusiva responsabilidad de Datalogic ADC Srl
para:
QuickScan QM2400 ; Cordless Barcode Reader
BC2030 ; Cordless Base station /Charger
sono conformi alle Direttive del Consiglio Europeo sottoelencate:
are in conformity with the requirements of the European Council Directives listed below:
sont conformes aux spécifications des Directives de l'Union Européenne ci-dessous:
den nachstehenden angeführten Direktiven des Europäischen Rats:
cumple con los requisitos de las Directivas del Consejo Europeo, según la lista siguiente:
1999/5/EC - R&TTE Directive
2011/65/EU - RoHS Directive
Questa dichiarazione è basata sulla conformità dei prodotti alle norme seguenti:
This declaration is based upon compliance of the products to the following standards:
Cette déclaration repose sur la conformité des produits aux normes suivantes:
Diese Erklärung basiert darauf, daß das Produkt den folgenden Normen entspricht:
Esta declaración se basa en el cumplimiento de los productos con las siguientes normas:
Datalogic ADC Srl, Via S. Vitalino, 13
Lippo di Calderara di Reno (BO) 40012 Italy
EC-114
Rev.: 0
Pag.: 1 d i 1
e tutti i suoi modelli
and all its models
et tous ses modèles
und seine Modelle
y todos sus modelos
ETSI EN 301 489-3 V1.4.1,
A
UGUST
2002 :
E
LECTROMAGNETIC COMPATIBILITY AND RADIO SPECTRUM
M
ATTERS
(ERM); E
LECTROMAGNETIC COMPATIBILITY
(EMC) S
TANDARD FOR RADIO EQUIPMENT AND SERVICES
;
P
ART
3: S
PECIFIC CONDITIONS FOR SHORT-RANGE
D
EVICES
(SRD) O
PERATING ON FREQUENCIES BETWEEN
9
KHZ AND
40GHZ
ETSI EN 301 489-1 V1.9.2,
S
EPTEMBER
2011 :
E
LECTROMAGNETIC COMPATIBILITY AND RADIO SPEC
-
TRUM MATTERS
(ERM); E
LECTROMAGNETIC COMPATIBIL
-
ITY
(EMC) S
TANDARD FOR RADIO EQUIPMENT AND
S
ERVICES
; P
ART
1: C
OMMON TECHNICAL REQUIREMENTS
ETSI EN 300 220-2 V2.4.1,
M
AY
2012 :
E
LECTROMAGNETIC COMPATIBILITY AND RADIO SPECTRUM
M
ATTERS
(ERM); S
HORT RANGE DEVICES
(SRD); R
ADIO
E
QUIPMENT TO BE USED IN THE
25MHZ TO 1000MHZ
F
REQUENCY RANGE WITH POWER LEVELS RANGING UP TO
500
M
W; P
ART
2: H
ARMONIZED
EN C
OVERING ESSEN
-
TIAL REQUIREMENTS UNDER ARTICLE
3.2 OF
THE
R&TTE
D
IRECTIVE
EN 60950-1, D
ECEMBER
2006 +
A
MENDMENT
A11:2009 + A
MEND
-
MENT
A1:2010 + A
MENDMENT
A12:2011 + A
MENDMENT
A2:2013
I
NFORMATION TECHNOLOGY EQUIPMENT
- S
AFETY
-
P
ART
1 : G
ENERAL REQUIREMENTS
EN 50581, S
EPTEMBER
2012 :
T
ECHNICAL DOCUMENTATION FOR THE ASSESSMENT OF
E
LECTRICAL AND ELECTRONIC PRODUCTS WITH RESPECT
TO THE RESTRICTION OF HAZARDOUS SUBSTANCES
Lippo di Calderara,
July 28th , 2014
Ruggero Cacioppo
Quality & Reliability Manager - Europe
14
©2014 Datalogic ADC, Inc. • All rights reserved.
