Datalogic QuickScan i QD2100, QuickScan i Quick Reference Manual

QuickScan

TM

i

QD2100 General Purpose Corded

Handheld Linear Imager Bar Code Reader

Quick Reference Guide

Datalogic ADC, Inc.

959 Terry Street
Eugene, OR 97402
USA
Telephone: [phone]
Fax: [phone]

© 2008 - 2013 Datalogic, Inc.
An Unpublished Work - All rights reserved. No part of the contents of this docu­mentation or the procedures described therein may be reproduced or transmitted

in any form or by any means without prior written permission of Datalogic ADC, Inc.
or its subsidiaries or affiliates ("Datalogic" or “Datalogic ADC”). Owners of Datalogic
products are hereby granted a non-exclusive, revocable license to reproduce and
transmit this documentation for the purchaser's own internal business purposes.
Purchaser shall not remove or alter any proprietary notices, including copyright
notices, contained in this documentation and shall ensure that all notices appear
on any reproductions of the documentation.
Should future revisions of this manual be published, you can acquire printed ver­sions by contacting your Datalogic representative. Electronic versions may either
be downloadable from the Datalogic website (www.datalogic.com) or provided on
appropriate media. If you visit our website and would like to make comments or
suggestions about this or other Datalogic publications, please let us know via the
"Contact Datalogic" page.

Disclaimer

Datalogic has taken reasonable measures to provide information in this manual
that is complete and accurate, however, Datalogic reserves the right to change any
specification at any time without prior notice.
Datalogic and the Datalogic logo are registered trademarks of Datalogic S.p.A. in
many countries, including the U.S.A. and the E.U. All other brand and product
names may be trademarks of their respective owners.

This product may be covered by one or more of the following patents:

4603262 • 4639606 • 4652750 • 4672215 • 4699447 • 4709369 • 4749879 • 4786798 • 4792666 •
4794240 • 4798943 • 4799164 • 4820911 • 4845349 • 4861972 • 4861973 • 4866257 • 4868836 •
4879456 • 4939355 • 4939356 • 4943127 • 4963719 • 4971176 • 4971177 • 4991692 • 5001406 •
5015831 • 5019697 • 5019698 • 5086879 • 5115120 • 5144118 • 5146463 • 5179270 • 5198649 •
5200597 • 5202784 • 5208449 • 5210397 • 5212371 • 5212372 • 5214270 • 5229590 • 5231293 •
5232185 • 5233169 • 5235168 • 5237161 • 5237162 • 5239165 • 5247161 • 5256864 • 5258604 •
5258699 • 5260554 • 5274219 • 5296689 • 5298728 • 5311000 • 5327451 • 5329103 • 5330370 •
5347113 • 5347121 • 5371361 • 5382783 • 5386105 • 5389917 • 5410108 • 5420410 • 5422472 •
5426507 • 5438187 • 5440110 • 5440111 • 5446271 • 5446749 • 5448050 • 5463211 • 5475206 •
5475207 • 5479011 • 5481098 • 5491328 • 5493108 • 5504350 • 5508505 • 5512740 • 5541397 •
5552593 • 5557095 • 5563402 • 5565668 • 5576531 • 5581707 • 5594231 • 5594441 • 5598070 •
5602376 • 5608201 • 5608399 • 5612529 • 5629510 • 5635699 • 5641958 • 5646391 • 5661435 •
5664231 • 5666045 • 5671374 • 5675138 • 5682028 • 5686716 • 5696370 • 5703347 • 5705802 •
5714750 • 5717194 • 5723852 • 5750976 • 5767502 • 5770847 • 5786581 • 5786585 • 5787103 •
5789732 • 5796222 • 5804809 • 5814803 • 5814804 • 5821721 • 5822343 • 5825009 • 5834708 •
5834750 • 5837983 • 5837988 • 5852286 • 5864129 • 5869827 • 5874722 • 5883370 • 5905249 •
5907147 • 5923023 • 5925868 • 5929421 • 5945670 • 5959284 • 5962838 • 5979769 • 6000619 •
6006991 • 6012639 • 6016135 • 6024284 • 6041374 • 6042012 • 6045044 • 6047889 • 6047894 •
6056198 • 6065676 • 6069696 • 6073849 • 6073851 • 6094288 • 6112993 • 6129279 • 6129282 •
6134039 • 6142376 • 6152368 • 6152372 • 6155488 • 6166375 • 6169614 • 6173894 • 6176429 •
6188500 • 6189784 • 6213397 • 6223986 • 6230975 • 6230976 • 6244510 • 6259545 • 6260763 •
6266175 • 6273336 • 6276605 • 6279829 • 6290134 • 6290135 • 6293467 • 6303927 • 6311895 •
6318634 • 6328216 • 6332576 • 6332577 • 6343741 • 6454168 • 6478224 • 6568598 • 6578765 •
6705527 • 6857567 • 6974084 • 6991169 • 7051940 • 7170414 • 7172123 • 7201322 • 7204422 •
7215493 • 7224540 • 7234641 • 7243850 • 7374092 • 7407096 • 7490770 • 7495564 • 7506816 •
7527198 • 7527207 • 7537166 • 7562817 • 601 26 118.6 • AU703547 • D312631 • D313590 •
D320011 • D320012 • D323492 • D330707 • D330708 • D349109 • D350127 • D350735 • D351149 •
D351150 • D352936 • D352937 • D352938 • D352939 • D358588 • D361565 • D372234 • D374630 •
D374869 • D375493 • D376357 • D377345 • D377346 • D377347 • D377348 • D388075 • D446524 •
D606544 •EP0256296 • EP0260155 • EP0260156 • EP0295936 • EP0325469 • EP0349770 •
EP0368254 • EP0442215 • EP0498366 • EP0531645 • EP0663643 • EP0698251 • EP01330772 •
EP870761 • GB2252333 • GB2284086 • GB2301691 • GB2304954 • GB2307093 • GB2308267 •
GB2308678 • GB2319103 • GB2333163 • GB2343079 • GB2344486 • GB2345568 • GB2354340 •
ISR107546 • ISR118507 • ISR118508 • JP1962823 • JP1971216 • JP2513442 • JP2732459 •
JP2829331 • JP2953593 • JP2964278 • MEX185552 • MEX187245 • RE37166 • RE40071

Additional patents pending.

Quick Reference Guide i

Datalogic ADC, Inc.

QUICKSCAN

TM

PRODUCT SERIES END USER LICENSE

AGREEMENT

Notice to End User: The Datalogic Product you have acquired contains
embedded Software, which is integral to the product's operation. This Soft­ware is being provided to you under license, subject to the terms and condi­tions of this Agreement. If you use the Datalogic Product, you will be deemed
to have accepted the terms and conditions of this Agreement. If you do not
intend to be bound to the terms of this Agreement, Datalogic is not willing to
license the Software to you, you may not use the Datalogic Product or the
Software, and you must contact the party from whom you acquired the Data­logic Product for instructions.

This End User Software License Agreement ("Agreement") is a legally binding
agreement governing the licensing of the Software and Documentation by Dat­alogic ADC, Inc. and its Affiliates ("Datalogic") to the entity or person who has
purchased or otherwise acquired a Datalogic Product ("End User"). For pur­poses of this Agreement, any software that is associated with a separate
end-user license agreement is licensed to you under the terms of that license
agreement. Datalogic and End User hereby agree as follows:

1. Definitions.

1.1 "Affiliate" means a business entity currently existing or later acquired that
controls, is controlled by, or is under common control with Datalogic
S.p.A.

1.2 "Documentation" means materials such as user's guides, program refer­ence guides, quick reference guides, manuals, or similar materials
associated with or related to the Datalogic Product, whether in printed,
"online", or other form.

1.3 "Proprietary Information" means: (a) source code, object code, software,
documentation, and any related internal design, system design, data
base design, algorithms, technology, technical data or information,
implementation techniques, and trade secrets related to the Software,
(b) any other trade secrets marked appropriately or identified as propri­etary or confidential, and (c) any information that End User, under the
circumstances, should recognize as confidential. Proprietary Informa­tion does not include any information that the receiving party can
establish was (1) in the public domain, (2) already in the receiving
party's possession or rightfully known prior to receipt, (3) rightfully
learned from a third party not in violation of any other's proprietary
rights, or (4) independently developed without access to Proprietary
Information.

1.4 "Datalogic Product" means the Datalogic

TM

QuickscanTM series scanner
product, including all embedded Software in and all Documentation
related to such product, which has been purchased or otherwise
acquired by End User, whether obtained directly or indirectly from Data­logic.

1.5 "Software" means any software or computer programs of Datalogic or its
third party licensors in machine readable form which is embedded in
the Datalogic Product, whether obtained directly or indirectly from Dat­alogic, including any replacement, update, upgrade, enhancement or
modification.

2. Scope Of License Granted.

2.1 Datalogic grants to End User a non-exclusive, non-transferable, perpetual
license to use the Software, solely on the Datalogic Product in which it
is embedded ("designated Datalogic Product"), in machine-readable
form only, solely for End User's internal business purposes. This Agree­ment does not convey ownership of the Software to End User. Title to
the Software shall be and remain with Datalogic or the third party from
whom Datalogic has obtained a licensed right. As used in this Agree­ment, the term "purchase" or its equivalents when applied to the Soft­ware shall mean "acquire under license." End User is not entitled to

ii QuickScanTM i

receipt or use of the source code to any Software.

2.2 End User shall not copy, modify, decompile, disassemble, reverse engi­neer, or otherwise reproduce or remanufacture the Software, whether
modified or unmodified, nor sell, assign, sublicense, distribute, lend,
rent, give, or otherwise transfer the Software to any other person or
organization, for purposes other than as expressly provided in this
Agreement, without Datalogic's prior written consent.

3. Transfers, Support.

3.1 Any copying, installing, reproduction, remanufacture, reverse engineer­ing, electronic transfer, or other use of the Software on other than the
designated Datalogic Product will be a material breach of this Agree­ment. However, Datalogic may elect not to terminate this Agreement or
the granted licenses, but instead may elect to notify End User that End
User is deemed to have ordered and accepted a license for each
breaching use. End User shall pay Datalogic the applicable list price for
such licenses as of the date of such breach.

3.2 End User shall not sell, assign, sublicense, distribute, lend, rent, give,
or otherwise transfer the Datalogic Product to any third party unless
such third party agrees with Datalogic in writing to be bound by the
terms and conditions of this Agreement. Any such transfer of the Data­logic Product absent such agreement shall be null and void.

3.3 End User may obtain support for Software from Datalogic at Datalogic's
standard support fees and under Datalogic's standard support terms
and conditions in effect at the time the support is requested.

4. Intellectual Property.

End User acknowledges that the Software constitutes valuable trade secrets of
Datalogic or Datalogic's third party licensors and that the Software is protected
by intellectual property laws and treaties. The license set forth in this Agree­ment does not transfer to End User any ownership of Datalogic's or its third
party licensors' copyrights, patents, trademarks, service marks, trade secrets,
or other intellectual property rights and End User shall have no right to com­mence any legal actions to obtain such rights. End User shall not remove, mod­ify, or take any other action that would obscure any copyright, trademark, patent
marking, or other intellectual property notices contained in or on the Datalogic
Product.

5. Proprietary Information.

5.1 End User acknowledges that Proprietary Information is the confidential,
proprietary, and trade secret property of Datalogic and Datalogic's third
party licensors and End User acquires no right or interest in any Propri­etary Information.

5.2 End User shall not disclose, provide, or otherwise make available the
Proprietary Information of Datalogic or its third party licensors to any
person other than End User's authorized employees or agents who are
under confidentiality agreement, and End User shall not use the Propri­etary Information other than in conjunction with use of the Datalogic
Product exclusively for End User's internal business purposes. End
User shall take steps to protect the Proprietary Information no less
securely than if it were End User's own intellectual property.

5.3 The provisions of this Proprietary Information Section shall survive and
continue for five (5) years after the termination of this Agreement.

6. Limited Warranty.

6.1 Datalogic warrants that, under normal use and operation, the Datalogic
Product will conform substantially to the applicable Documentation for
the period specified in the Documentation. During this period, for all
reproducible nonconformities for which Datalogic has been given writ­ten notice, Datalogic will use commercially reasonable efforts to rem­edy nonconformities verified by Datalogic. End User agrees to supply
Datalogic with all reasonably requested information and assistance
necessary to help Datalogic in remedying such nonconformities. For all
defects reported to Datalogic within the warranty period, Datalogic's lia­bility is limited to providing End User with one copy of corrections or

Quick Reference Guide iii

responding to End User's problem reports according to Datalogic's
standard assistance practices. Datalogic does not warrant that the
product will meet End User's requirements or that use of the product
will be uninterrupted or error free, or that Datalogic's remedial efforts
will correct any nonconformance. This limited warranty does not cover
any product that have been subjected to damage or abuse, whether
intentionally, accidentally, or by neglect, or to unauthorized repair or
unauthorized installation, and shall be void if End User modifies the
product, uses the product in any manner other than as established in
the Documentation, or if End User breaches any of the provisions of
this Agreement.

6.2 EXCEPT AS PROVIDED IN THIS AGREEMENT, THE DATALOGIC
PRODUCT IS PROVIDED "AS IS" AND DATALOGIC MAKES NO
WARRANTIES OF ANY KIND, EXPRESS OR IMPLIED, WRITTEN OR
ORAL, WITH RESPECT TO THE PRODUCT, AND SPECIFICALLY
DISCLAIMS THE IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE.

7. Infringement.

7.1 Datalogic will defend End User against any claim in a lawsuit that the
Datalogic Product furnished hereunder infringe a United States patent
or copyright of a third party and Datalogic will pay any damages finally
awarded against End User by a court of competent jurisdiction that are
attributable to such claim or will pay End User's part of any settlement
that is attributable to such claim, provided, that 1) End User notifies
Datalogic promptly in writing of the claim, 2) Datalogic controls the
defense or settlement of the claim, and 3) End User cooperates fully
with Datalogic in such defense or settlement. All notices of a claim
should be sent to Datalogic ADC, Inc., Legal Department, 959 Terry
Street, Eugene, OR 97402.

7.2 In the defense or settlement of any such claim, Datalogic may, at its
option, 1) procure for End User the right to continue using the Datalogic
Product, 2) modify the Datalogic Product so that it becomes
non-infringing, 3) replace the Datalogic Product with an equivalent
product not subject to such claim, or 4) provide End User an opportu­nity to return the Datalogic Product and receive a refund of the pur­chase price paid, less a reasonable allowance for use.

7.3 Datalogic shall have no liability to End User for claims of infringement
based upon 1) the use of any Datalogic Product in combination with
any product which Datalogic has not either furnished or authorized for
use with such Datalogic Product 2) the use of any Datalogic Product
designed, manufactured, or modified to the specifications of End User,
or 3) End User's modification of the Datalogic Product without written
authorization from Datalogic.

7.4 THE FOREGOING STATES DATALOGIC'S COMPLETE AND ENTIRE
OBLIGATION CONCERNING CLAIMS OF PATENT, COPYRIGHT, OR
OTHER INTELLECTUAL PROPERTY INFRINGEMENT, CANCELS
AND SUPERCEDES ANY PRIOR AGREEMENTS, WHETHER ORAL
OR WRITTEN, BETWEEN THE PARTIES CONCERNING SUCH
CLAIMS, AND WILL NOT BE MODIFIED OR AMENDED BY ANY
PAST, CONTEMPORANEOUS, OR FUTURE AGREEMENTS OR
DEALINGS BETWEEN THE PARTIES, WHETHER ORAL OR WRIT­TEN, EXCEPT AS SET FORTH IN A FUTURE WRITING SIGNED BY
BOTH PARTIES.

8. Limitation Of Liability.

EXCEPT AS PROVIDED IN SECTION 7, DATALOGIC SHALL NOT BE LIABLE
FOR ANY CLAIMS AGAINST END USER BY ANY OTHER PARTY. IN NO
EVENT SHALL DATALOGIC'S LIABILITY FOR DAMAGES, IF ANY, WHETHER
BASED UPON CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT
LIABILITY, STRICT LIABILITY, WARRANTY, OR ANY OTHER BASIS,
EXCEED THE PRICE OR FEE PAID BY END USER FOR THE DATALOGIC
PRODUCT. UNDER NO CIRCUMSTANCES SHALL DATALOGIC BE LIABLE
TO END USER OR ANY THIRD PARTY FOR LOST PROFITS, LOST DATA,
INTERRUPTION OF BUSINESS OR SERVICE, OR FOR ANY OTHER SPE­CIAL, CONSEQUENTIAL, CONTINGENT, INDIRECT, INCIDENTAL, PUNI­TIVE, EXEMPLARY, OR OTHER SIMILAR DAMAGES, EVEN IF DATALOGIC

iv QuickScanTM i

HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

9. Government Restricted Rights; International Use.

9.1 Use, duplication, or disclosure of the Software by the U.S. Government
is subject to the restrictions for computer software developed at private
expense as set forth in the U.S. Federal Acquisition Regulations at FAR

52.227-14(g), or 52.227-19 or in the Rights in Technical Data and Com­puter Software clause at DFARS 252.227-7013(c)(1)(ii), whichever is
applicable.

9.2 If End User is using the Datalogic Product outside of the United States,
End User must comply with the applicable local laws of the country in
which the Datalogic Product is used, with U.S. export control laws, and
with the English language version of this Agreement. The provisions of
the "United Nations Convention on International Sale of Goods" shall
not apply to this Agreement.

10. Termination.

10.1 Either party may terminate this Agreement or any license granted
under this Agreement at any time upon written notice if the other party
breaches any provision of this Agreement.

10.2 Upon termination of this Agreement, End User immediately shall cease
using any nonembedded software and shall return to Datalogic or
destroy all non-embedded software covered by this Agreement, and
shall furnish Datalogic with a certificate of compliance with this provi­sion signed by an officer or authorized representative of End User. For
embedded software, End User agrees to sign a waiver prepared by
Datalogic concerning further use of the embedded Software. End
User's resumed or continued use of the embedded Software after ter­mination shall constitute End User's agreement to be bound by the
terms and conditions of this Agreement for such use.

11. General Provisions.

11.1 Entire Agreement; Amendment. This document contains the entire
agreement between the parties relating to the licensing of the Software
and supersedes all prior or contemporaneous agreements, written or
oral, between the parties concerning the licensing of the Software. This
Agreement may not be changed, amended, or modified except by writ­ten document signed by Datalogic.

11.2 Notice. All notices required or authorized under this Agreement shall be
given in writing, and shall be effective when received, with evidence of
receipt. Notices to Datalogic shall be sent to the attention of Contract
Administration, Datalogic ADC, Inc., 959 Terry Street, Eugene, OR
97402, or such other address as may be specified by Datalogic in writ­ing.

11.3 Waiver. A party's failure to enforce any of the terms and conditions of this
Agreement shall not prevent the party's later enforcement of such
terms and conditions.

11.4 Governing Law; Venue: This Agreement and the rights of the parties
hereunder shall be governed by and construed in accordance with the
laws of the State of Oregon U.S.A, without regard to the rules govern­ing conflicts of law. The state or federal courts of the State of Oregon
located in either Multnomah or Lane counties shall have exclusive juris­diction over all matters regarding this Agreement, except that Datalogic
shall have the right, at its absolute discretion, to initiate proceedings in
the courts of any other state, country, or territory in which End User
resides, or in which any of End User's assets are located.

11.5 Attorneys' Fees. In the event an action is brought to enforce the terms
and conditions of this Agreement, the prevailing party shall be entitled
to reasonable attorneys' fees, both at trial and on appeal.

- END -

Software Product Policy

Quick Reference Guide v

Software Product Policy

Datalogic reserves the right to ship its products with the latest version of software/firm­ware available. This provides our customers with the very latest in Datalogic software
technology.

The only exception to this policy is when the buyer has a signed contract with Datalogic
that clearly defines the terms and conditions for making software/firmware changes in
products shipped to the buyer.

Customers Under Software Support

Customers that elect to subscribe to Datalogic Software Maintenance and Support
Agreement will receive 30 days advance notification of: (1) the release of a new software
version; and/or (2) discontinuation of any prior software version that will no longer be
supported. Datalogic will provide maintenance for a fee that will assist customers in
transitioning to the next software version. If a customer is currently using the software
version being discontinued, the customer may elect to transition to any one of the
newer versions, depending on the hardware in use.

To arrange for a Software Maintenance and Support Agreement please contact your
Datalogic sales person.

vi QuickScanTM i

NOTES

Connect/Disconnect Cable

Quick Reference Guide 1

Connect/Disconnect Cable

Connect Host Interface

Keyboard Wedge Interface

RS-232 Interface

USB Interface

IBM 46xx Interface

1

2

2QuickScan

TM

i

Aim and Scan

3

012345

012345

65°

65°

Parts of the Imager

Quick Reference Guide 3

Parts of the Imager

Scanning Modes

The imager can operate in one of several scanning modes:

Trigger Single —

When the trigger is pulled, scanning is activated

until one of the following occurs:

- a programmable duration

1

has elapsed

- a label has been read

- the trigger is released

This mode is associ ate d with typical handheld reader operation:
when the trigger is pulled, scanning starts and the product scans
until the trigger is released, or a label is read, or the maximum
programmable duration

1

has elapsed.

Trigger Hold Multiple —

When the trigger is pulled, scanning starts
and the product scans until the trigger is released or a program­mable duration

1

has elapsed. Reading a label does not disable
scanning. Double Read Timeout2 prevents undesired multiple
reads while in this mode.

Trigger Pulse Multiple —

When the trigger is pulled and released,
scanning is activated until programmable duration1 has elapsed
or the trigger has been pulled again to transition to another
state. Double Read Timeout

2

prevents undesired multiple reads

while in this mode.

Flashing —

The reader flashes3 on and off regardless of the trigger

status.

1. See the Product Reference Guide (PRG) for additional programmable
features, in this case: Scanning Active Time.

2. Double Read Timeout is also programmed using the PRG.

3. Controlled by Flash On Time and Flash Off Time. Use the PRG to pro­gram these options.

Trigger

Scan
Window

LED

Nose
Boot

4QuickScan

TM

i

Always On —

No trigger pull is required to read a barcode. Scanning

is continually on. If the trigger is pulled, the reader acts as if it
is in Trigger Single Mode. Double Read Timeout1 prevents
undesired multiple reads while in this mode.

Stand Mode —

No trigger pull is required to read a bar code. Scan­ning is turned on automatically when an item is placed in read­er’s field of view. If the trigger is pulled, the reader acts as if it
in

Trigger Single mode. Double Read Timeout2 prevents un-

desired multiple reads while in this mode.

Trigger Object Sense —

This mode is similar to Stand Mode, ex-

cept that a trigger pull is required to activate the decoder.

Scan Mode = Trigger Single

Scan Mode = Trigger Hold Multiple

Scan Mode = Trigger Pulse Multiple

1. Double Read Timeout is programmed using the PRG.

2. Double Read Timeout is programmed using the PRG.

Scanning Modes

Quick Reference Guide 5

Scanning Modes — continued

Scan Mode = Flashing

Scan Mode = Always On

Scan Mode = Stand Mode

Scan Mode = Trigger Object Sense

6QuickScan

TM

i

Troubleshooting

Problem Possible Cause Possible Solutions

Nothing happens when
the scan button is
pulled.

No power to the
imager.

Check system power.
Ensure power supply is
connected.

Interface or power
cables are loose.

Ensure all cable connec­tions are secure.

LED comes on, but bar­code does not decode.

Imager not pro­grammed for correct
barcode type.

Ensure imager is pro­grammed to read the type
of barcode scanned. Refer
to the Product Reference
Guide (PRG) for more
information.

Barcode label is
unreadable.

Check the label to ensure
it is not defaced. Try scan­ning another barcode
type.

Distance between
imager and barcode
is incorrect.

Move imager closer to or
further from the barcode.

Barcode reading ability
has degraded.

Scan Window has
become scratched or
contaminated with
dust.

Replace window as
instructed in this guide.

Barcode is decoded but
not transmitted to the
host.

Imager not pro­grammed for the cor­rect host type.

Scan the appropriate host
type barcode. Refer to the
Product Reference Guide
(PRG) for more informa­tion.

NOTE

For detailed troubleshooting, refer
to the Product Reference Guide.

LED and Beeper Indications

Quick Reference Guide 7

LED and Beeper Indications

The imager’s beeper sounds and its LED illuminates to indicate
various functions or errors on the reader. A “Green Spot” also
lights to indicate a good read. The tables below list these indi­cations. One exception to the behaviors listed in the tables is
that the reader’s functions are programmable, and may or may
not be turned on. For example, certain indications, such as the
power-up beep can be disabled using programming barcode la­bels. Reference the PRG for a more detailed list.

Indication LED Beeper

Power-up

LED flashes/blinks on
power-up, however, this may
be too rapid to view. With a
USB interface, the LED
blinks until enumeration with
the host is completed.

Imager beeps four times
at highest frequency and
volume upon power-up.

Good Read

LED behavior for this indica­tion is configurable using the
PRG.

One beep at current fre­quency, volume,
mono/bi-tonal setting and
duration upon a success­ful label scan.

ROM Failure 200ms on / 200ms off

Imager sounds one error
beep at highest volume
for 200 mS.

Limited Scanning
Label Read

N/A

Imager 'chirps' six times
at the highest frequency
and current volume.

Imager Disabled

The LED blinks continuously
100mS on / 900 mS off

N/A

8QuickScan

TM

i

Programming Barcodes

For your convenience, this guide includes the programming

barcodes required to configure the imager for use with different
interface (terminal/host) types.

See the Product Reference Guide (PRG) for more complete in-

formation about programming and configurable features. You
can download the latest version of the PRG and any other avail­able publications for the imager from the website listed on the
back cover of this manual.

Resetting the Standard Product Defaults

If you aren’t sure what programming options are in your imag-

er, or you’ve changed some options and want the factory set­tings restored, scan the Factory Default Settings barcode below.
This will copy the factory configuration for the currently active
interface to the current configuration.

Factory Default Settings

Host Interfaces

NOTE

Cables may vary depending upon sys­tem configuration.

Some interfaces require the imager to
start in the disabled state when pow­ered on. If additional imager configura­tion is desired while in this state, pull
the trigger and hold it for five seconds.
The imager will change to a state that
allows programming with barcodes.

Programming Barcodes

Quick Reference Guide 9

RS-232 Interface

To use an RS-232 interface, scan the barcode for the desired
RS-232 host type.

Select RS-232 Standard

Select RS-232 Wincor Nixdorf

Select RS-232 OPOS (for use with OPOS/UPOS/JavaPOS)

IBM Interface

Select IBM Port 5B

Select IBM Port 9B

10 QuickScanTM i

USB Interface

The imager attaches directly to a USB host, or a powered USB

hub, and is powered by it. No additional power supply is re­quired. When using a USB interface, the imager auto-detects
the USB and defaults to the HID keyboard interface.

Select USB-COM-STD

1

(simulates RS-232 standard interface)

Select USB Keyboard (with standard key encoding)

Select USB Alternate Keyboard (with alternate key encoding)

Select USB OEM

Select USB-KBD-APPLE (for Apple computers)

1. Download the correct USB Com driver from www.datalogic.com.

Programming Barcodes

Quick Reference Guide 11

Keyboard Wedge Interface

To use a Keyboard Wedge interface, scan the barcode for the
desired keyboard type.

Select KBD-AT

(AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70, 80, 90 & 95

w/Standard Key Encoding)

Select KBD-AT-NK

(IBM AT PS2 with standard key encoding but without external kbd.)

Select KBD-AT-ALT

(AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70, 80, 90 & 95

w/Alternate Key)

Select KBD-AT-ALT-NK (for IBM AT PS2 with alternate key

encoding but without external keyboard)

12 QuickScanTM i

Keyboard Wedge Interface — continued

Select KBD-XT (PC/XT w/Standard Key Encoding)

Select KBD-IBM-3153 (for IBM Terminal 3153)

Select KBD-IBM-M

(for IBM Terminals 31xx, 32xx, 34xx, 37xx make only keyboard)

Select KBD-IBM-MB

(for IBM Terminals 31xx, 32xx, 34xx, 37xx make break keyboard)

Select KBD-DIG-VT

(for DIGITAL Terminals VT2xx, VT3xx, VT4xx)

Ergonomic Recommendations

Quick Reference Guide 13

Ergonomic Recommendations

• Reduce or eliminate repetitive motion

• Maintain a natural position

• Reduce or eliminate excessive force

• Keep objects that are used frequently within easy reach

• Perform tasks at correct heights

• Reduce or eliminate vibration

• Reduce or eliminate direct pressure

• Provide adjustable workstations

• Provide adequate clearance

• Provide a suitable working environment

• Improve work procedures.

Regulatory Information

All models are designed to be compliant with rules and regula­tions in locations they are sold and will be labeled as required.
Any changes or modifications to equipment, not expressly ap­proved by Datalogic could void the user's authority to operate
the equipment.

Power Supply

Use only a power supply approved by Datalogic for this prod­uct and model. Models require either a Listed class II or class
III with a Limited Power Source(LPS) which supplies power di­rectly to the imager. For the safety certification to be valid, class
III input power sources must be IEC/EN60950-1 (EN
60335-series, EN 60065 or relevant) approved.
Input: 100 - 240 VACOutput: 5.2 VDC
Max Current: 0.4 AmpsPower: 15 Watts

CAUTION

In order to avoid or minimize the
potential risk of ergonomic injury fol­low the recommendations below.
Consult with your local Health &
Safety Manager to ensure that you
are adhering to your company’s
safety programs to prevent employee
injury.

NOTE

For USB Power Off Ter­minal applications,
attach to USB 1.0, 1.1 or

2.0 host device only.

Atención

Características de la

fuente de alimentación

eléctrica.

Entrada: 100 - 240 Vca
350mA 50/60 Hz
Salida: +5 VDC @ 2.5A
(-) Negativo al centro

Utilice en su red solo fuentes certificadas
en Argentina.
El uso de fuentes de alimentación no
compatibles puede resultar en riesgo de
incendio o de choque eléctrico para el
usuario.

14 QuickScanTM i

Hinweis

Benutzen Sie nur eine von Datalogic genehmigte Stromver-

sorgung. Die Modelle erfordern eine Stromquelle der Klasse II
oder III mit einer Leistungsbegrenzung (LPS). Für eine gültige
Sicherheitszertifizierung müssen Klasse III Stromquellen am
Eingang nach den Bestimmungen IEC/EN60950-1 (EN
60335-Serien, EN 60065 oder entsprechenden) zugelassen
sein.

Eingang: 100 - 240 VACAusgang: 5.2 VDC
Max. Strom: 0.4 AmpsMax. Leistung: 15 W

Radio Frequency Interference Requirements

This equipment has been tested and found to
comply with the limits for a Class B digital de­vice, pursuant to Part 15 of the FCC rules.

These limits are designed to provide reason­able protection against harmful interference in a residential in­stallation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accor­dance with the instruction manual, may cause harmful interfer­ence to radio communications. However there is no guarantee
that interference will not occur in a particular installation. If the
equipment does cause harmful interference to radio or televi­sion reception, which can be determined by turning the equip­ment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:

• Re-orient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician
for help.

Radio Frequency Interference Requirements - Canada

This Class B digital apparatus complies with Canadian IC-

ES-003.

Cet appareil numérique de la classe B est conforme à la norme

NMB-003 du Canada.

CAUTION

The user is cautioned that changes
or modifications not expressly
approved by the party responsible
for compliance could void the
user’s authority to operate the
equipment.

Tested to comply
with FCC Standards

FOR HOME OR OFFICE USE

Replacing the Scan Window

Quick Reference Guide 15

Replacing the Scan Window

If the Scan Window becomes scratched, broken or contaminat­ed with heavy dust, fix it by removing the Nose Boot and clean­ing or installing a new window. Datalogic offers a replacement
window as an orderable accessory.

To replace the Scan Window, first remove power from the im­ager then hold the imager with the Scan Window facing up.
Gently pull off the Nose Boot and tilt the imager to one side to
remove the window.

Holding it by its edges, carefully place the clean replacement
Scan Window in position and secure it in place by reinstalling
the Nose Boot.

CAUTION

Proceed to the next step immedi­ately. DO NOT leave the interior of
the imager exposed.

Nose Boot

Scan Window

16 QuickScanTM i

Imager Labeling

Labels are shown here to illustrate their location only. Please

view the labels on your product for actual details.

Waste Electrical and Electronic Equipment (WEEE) Statement

English

For information about the disposal of Waste Electrical and Electronic Equipment (WEEE) , please refer to the website
at www.datalogic.com.

Italian

Per informazioni sullo smaltimento delle apparecchiature elettriche ed elettroniche consultare il sito Web
www.datalogic.com.

French

Pour toute information relative à l’élimination des déchets électroniques (WEEE), veuillez consulter le site internet
www.datalogic.com.

German

Informationen zur Entsorgung von Elektro- und Elektronik- Altgeräten (WEEE) erhalten Sie auf der Webseite
www.datalogic.com.

Spanish

Si desea información acerca de los procedimientos para el desecho de los r esiduos del equipo eléctrico y electrónico
(WEEE), visite la página Web www.datalogic.com.

Portuguese

Para informações sobre a disposição de Sucatagem de Equipamentos Elétricos e Eletrônicos (WEEE -Waste
Electrical and Electronic Equipment), consultar o site web www.datalogic.com.

Chinese

Japanese

廃電気電子機器 (ＷＥＥＥ) の処理についての関連事項は Datalogic のサイト
www.datalogic.com をご参照下さい。

Datalogic ADC Limited Factory Warranty

Warranty Coverage

Datalogic ADC (“Datalogic”) hardware products are warranted against defects in material and work-

manship under normal and proper use. The liability of Datalogic under this warranty is limited to
furnishing the labor and parts necessary to remedy any defect covered by this warranty and restore the
product to its norm al operating condition. Repair or replacement of product during the warranty does
not extend the original warranty term. Products are sold on the basis of specifications applicable at the
time of manufacture and Datalogic has no obligation to modify or update products once sold.

If Datalogic determines that a product has defects in material or workmanship, Datalogic shall, at its

sole option repair or replace the product without additional charge for parts and labor, or credit or
refund the defective products duly returned to Datalogic. To perform repairs, Datalogic may use new
or reconditioned parts, components, subassemblies or products that have been tested as meeting ap­plicable specifications for equivalent new material and products. Customer will allow Datalogic to
scrap all parts removed from the repaired product. The warranty period shall extend from the date of
shipment from Datalogic for the duration published by Datalogic for the product at the time of pur­chase (Warranty period). Datalogic warrants repaired hardware devices against defects in workman­ship and materials on the repaired assembly for a 90 day period starting from the date of shipment of
the repaired product from Datalogic or until the expiration of the original warranty period, whichever
is longer. Datalogic does not guarantee, and it is not responsible for, the maintenance of, damage to,
or loss of configurations, data, and applications on the repaired units and at its sole discretion can re­turn the units in the “factory default” configuration or with any software or firmware update available
at the time of the repair (other than the firmware or software installed during the manufacture of the
product). Customer accepts responsibility to maintain a back up copy of its software and data.

Warranty Claims Process

Laser &

Regulatory

Regulatory &
Serial Number

S/N

N263

FOR LASER VERSION: COMPLIES WITH 21 CFR

1040.10 AND 1040.11 EXCEPT FOR DEVIATIONS
PURSUANT TO LASER NOTICE NO. 50 DATED
JUNE 24, 2007. IEC/EN60825-1:2007. SEE QRG FOR
PATENT INFO.

Imager Labeling

Quick Reference Guide 17

In order to obtain service under the Factory Warranty, Customer must notify Datalogic of the
claimed defect before the expiration of the applicable Warranty period and obtain from Datalogic a
return authorization number (RMA) for return of the product to a designated Datalogic service cen­ter. If Datalogic determines Customer’s claim is valid, Datalogic will repair or replace product without
additional charge for parts and labor. Customer shall be responsible for packaging and shipping the
product to the designated Datalogic service center, with shipping charges prepaid. Datalogic shall pay
for the return of the product to Customer if the shipment is to a location within the country in which
the Datalogic service center is located. Customer shall be responsible for paying all shipping charges,
duties, taxes, and any other charges for products returned to any other locations. Failure to follow
the applicable RMA policy, may result in a processing fee. Customer shall be responsible for return
shipment expenses for products which Datalogic, at its sole discretion, determines are not defective
or eligible for warranty repair.

Warrant y Exclusions

The Datalogic Factory Warranty shall not apply to:

(i) any product which has been damaged, modified, altered, repaired or upgraded by other than

Datalogic service personnel or its authorized representatives;

(ii) any claimed defect, failure or damage which Datalogic determines was caused by faulty

operations, improper use, abuse, misuse, wear and tear, negligence, improper storage or use
of parts or accessories not approved or supplied by Datalogic;

(iii) any claimed defect or damage caused by the use of product with any other instrument,

equipment or apparatus;

(iv) any claimed defect or damage caused by the failure to provide proper maintenance, includ-

ing but not limited to cleaning the upper window in accordance with product manual;

(v) any defect or damage caused by natural or man-made disaster such as but not limited to fire,

water damage, floods, other natural disasters, vandalism or abusive events that would cause
internal and external component damage or destruction of the whole unit, consumable
items;

(vi) any damage or malfunctioning caused by non-restoring action as for example firmware or

software upgrades, software or hardware reconfigurations etc.;

(vii) the replacement of upper window/cartridge due to scratching, stains or other degradation

and/or

(viii) any consumable or equivalent (e.g., cables, power supply, batteries, keypads, touch screen,

triggers etc.).

No Assignment

Customer may not assign or otherwise transfer its rights or obligations under this warranty except to
a purchaser or transferee of product. No attempted assignment or transfer in violation of this provi­sion shall be valid or binding upon Datalogic.
DATALOGIC'S LIMITED WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EX­PRESS OR IMPLIED, ORAL OR WRITTEN, STATUTORY OR OTHERWISE, INCLUDING,
WITHOUT LIMITATION, ANY IMPLIED WARRANTIES OF MERCHANTABILITY, FIT­NESS FOR A PARTICULAR PURPOSE, OR NONINFRINGEMENT. DATALOGIC SHALL
NOT BE LIABLE FOR ANY DAMAGES SUSTAINED BY CUSTOMER ARISING FROM DE­LAYS IN THE REPLACEMENT OR REPAIR OF PRODUCTS UNDER THE ABOVE. THE
REMEDY SET FORTH IN THIS WARRANTY STATEMENT IS THE CUSTOMER’S SOLE
AND EXCLUSIVE REMEDY FOR WARRANTY CLAIMS. UNDER NO CIRCUMSTANCES
WILL DATALOGIC BE LIABLE TO CUSTOMER OR ANY THIRD PARTY FOR ANY LOST
PROFITS, OR ANY INCIDENTAL, CONSEQUENTIAL IN-DIRECT, SPECIAL OR CON­TINGENT DAMAGES REGARDLESS OF WHETHER DATALOGIC HAD ADVANCE NO­TICE OF THE POSSIBILITY OF SUCH DAMAGES.

Risk of Loss

Customer shall bear risk of loss or damage for product in transit to Datalogic. Datalogic shall assume
risk of loss or damage for product in Datalogic’s possession. In the absence of specific written instruc­tions for the return of product to Customer, Datalogic will select the carrier, but Datalogic shall not
thereby assume any liability in connection with the return shipment.

18 QuickScanTM i

QuickScan i QD2100 China RoHS

PART

部件名称

Lead

(Pb)

Mercury

(Hg)

Cadmium

(Cd)

Hexavalent

Chromium

(Cr(VI))

Polybrominated

biphenyls

(PBB)

Polybrominated

diphenyl ethers

(PBDE)

有毒有害物凝或元素

卋

汞

叏

六价卲

多ᄽ侶૖
多ᄽԲ૖ㅘ

Cable

⬉㓚

X

O

O

O

O

O

Assy, Module

ܝᄺ㒘ӊ

X

O

O

O

O

O

Printed Circuit Board

Assy

⬉䏃ᵓ㒘ӊ

X

O

O

O

O

O

O代表此Ẋ部件的所有均凝ޗறխࢬܶ具Ẋڶڶ୭凝݁܅Պխ䦀Գا٥ࡉ㧺ஒ䣈䢓ຝ所咒ؒ的

《䶣՗ஒ䣈঴խڶڶ୭凝ૻၦ૞ޣρ(SJ/T 11363-2006) 億ࡳૻၦ。

X:

代表此Ẋ部件所用的均凝ޗறխ, 至少有一㮕材料其所含的有毒有害物凝೏Պխ䦀Գا٥ࡉ㧺ஒ䣈䢓ຝ所咒ؒ的

《䶣՗ஒ䣈঴խڶڶ୭凝ૻၦ૞ޣρ(SJ/T 11363-2006) 億ࡳૻ量

EFUP determined by “Look-up Method” (scanner).ʳʳ㩾অࠌشཚૻ࠷㢾Պ“ ” （䮅༴䣗α

RoHS TABLE,CHINA,QUICKSCAN I QD2100

®

DECLARATION OF CONFORMITY

EC-82
Rev.:1
Pag.: 1 di 1

Datalogic ADC, Inc.
959 Terry Street
Eugene, Oregon 97402
USA

La presente dichiarazione di conformità è rilasciata sotto la responsabilità esclusiva di Datalogic ADC, Inc. per:
This Declaration of Conformity is issued under the sole responsibility of Datalogic ADC, Inc. for:
Cette déclaration de conformité est établie sous la seule responsabilité de Datalogic ADC, Inc:
Diese Konformitätserklärung wird unter der alleinigen Verantwortung des Datalogic ADC, Inc. erteilt für:
Esta declaración de conformidad se expide bajo la exclusiva responsabilidad de Datalogic ADC, Inc. para:

Quickscan i QD2100; Barcode Reader

e tutti i suoi modelli
and all its models
et tous ses modèles
und seine Modelle
y todos sus modelos

sono conformi alle Direttive del Consiglio Europeo sottoelencate:
are in conformity with the requirements of the European Council Directives listed below:
sont conformes aux spécifications des Directives de l’Union Européenne ci-dessous:
den nachstehenden angeführten Direktiven des Europäischen Rats:
cumple con los requisitos de las Directivas del Consejo Europeo, según la lista siguiente:

2004/108/EC EMC Directive
2006/95/EC Low Voltage Directive
2011/65/EU RoHS Directive (8 June 2011)

Basate sulle legislazioni degli Stati membri in relazione alla compatibilità elettromagnetica ed alla sicurezza
dei prodotti.
On the approximation of the laws of Member States relating to electromagnetic compatibility and product
safety.
Basée sur la législation des Etats membres relative à la compatibilté électromagnétique et à la sécurité des
produits.
Über die Annäherung der Gesetze der Mitgliedsstaaten in bezug auf elektromagnetische
Verträglichkeit und Produktsicherheit entsprechen.
Basado en la aproximación de las leyes de los Países Miembros respecto a la compatibilidad
electromagnética y las Medidas de seguridad relativas al producto.

Questa dichiarazione è basata sulla conformità dei prodotti alle norme seguenti:
This declaration is based upon compliance of the products to the following standards:
Cette déclaration repose sur la conformité des produits aux normes suivantes:
Diese Erklärung basiert darauf, daß das Produkt den folgenden Normen entspricht:
Esta declaración se basa en el cumplimiento de los productos con las siguientes normas:

EN 55022 (CLASS B ITE ),
SEPTEMBER 2006

LIMITS AND METHODS OF MEASUREMENTS OF RADIO
DISTURBANCE CHARACTERISTICS OF INFORMATION TECHNOLOGY
EQUIPMENT

EN 55024, SEPTEMBER 1998:
AMENDMENT A2:JUNE 2003

INFORMATION TECHNOLOGY EQUIPMENT - IMMUNITY
CHARACTERISTICS LIMITS AND METHODS OF MEASUREMENT

EN 60950-1, APRIL
2006+A11:2009+A1:2010+A12:2011

INFORMATION TECHNOLOGY EQUIPMENT - SAFETY ­PART 1 : GENERAL REQUIREMENTS

EN 50581, SEPT 2012

TECHNICAL DOCUMENTATIONI FOR THE ASSESSMENT OF ELECTRICAL
AND ELECTRONIC PRODUCTS WITH RESPECT TO THE RESTRICTION OF
HAZARDUOUS SUBSTANCES

EUGENE, OREGON USA, APRIL, 2013

BRAD WEST
VICE PRESIDENT – GLOBAL SUPPLY CHAIN OPERATIONS

13

Datalogic ADC, Inc.

959 Terry Street | Eugene |OR 97402 | USA
Telephone: [phone]

|

Fax: [phone]

820045914 (Rev. F) August 2013

www.datalogic.com

© 2008 - 2013 Datalogic, Inc. • All rights reserved.
Datalogic and the Datalogic logo are registered trademarks of
Datalogic S.p.A. in many countries, including the U.S.A. and the E.U.
