DATALOCKER DL3™ FE (FIPS EDITION)
ENCRYPTED EXTERNAL HARD DRIVE
FE ATUR E S
Always on, hardware-based encryption:
dedicated dual 256-bit AES crypto engines in
XTS and CBC modes
Alpha Numeric
Keypad
(For St rong Passwor ds)
Auto -Lock and
Read-Only
Firmware version
1.61 or higher
Screen simulated.
Rotating Keypad
(To Preve nt Surface
Analysis)
No Sof tware or
Drivers
Mac, Li nux and
Windows Compatible
DUAL TWO-PASS CASCADING ENCRYPTION
Building on the success and design of our award winning DataLocker DL3, the
DataLocker DL3 FE (FIPS Edition) provides unmatched usability and security.
Utilizing the sleek design and portable form factor of its predecessor, the DL3 FE
pairs blazing USB 3.0 speeds and two independent crypto processors.
Utilizing two-pass encryption, data is encrypted with a single round of 256-bit AES
XTS mode encryption directly passed to a second crypto engine undergoing a
second round of 256-bit AES CBC mode encryption.
Your original, unencrypted
1
files, folders and data are
transferred to your DL3 FE.
The DL3 CPU encrypts
2
the incoming data with
a 256-bit AES XTS mode
algorithm.
FIPS 140-2
VALIDATED
The data is then encrypted
3
sequentially with a FIPS
140-2 Validated 256-bit AES
CBC mode algorithm.
Your data is written to the
4
DL3 FE hard drive. Every bit of
stored data is encrypted
twice with two independent
keys that never leave your
device.
Our patented design, featuring a backlit touch screen with an alphanumeric
rotating keypad, allows for strong passwords and absolute security.
Optional 2-factor authentication utilizes a RFID tag in
addition to your password for added protection.
REQUEST A TRIAL
Request a risk free evaluation unit today:
http://datalocker.com/evaluation/
Rapid S ecure W ipe
Self-Destruct Mode
(Optional)
USB 3.0
Interface
(USB 2.0 C ompatible)
No External Power
Required
Optional 2-fac tor RFID
Authentication
Rapid key zeroization for secure redeployment
Self-destruct mode for protection against
brute force attacks
All encryption, administration and
authentication performed on the DL3FE unit
Suppor ts two roles: Administrator to set
policy, User to access data
Strong password rule (non sequential, repeating,
alpha + numeric, minimum 8 characters)
Compatible with DataLocker SafeConsole
manage multiple devices
Multi-lingual user interface (English, French,
German, Spanish, Japanese and Korean)
TECHNICAL SPECIFICATIONS
CAPACITIES
500GB, 1TB, 2TB, 512GB SSD & 960GB SSD
CRYPTOGRAPHIC PROCESSES
FIPS 197 (Cert. #250) &
FIPS 140-2 Validated Crypto Chip (Cer t. #1472)
DIMENSIONS
120mm x 75mm x 23mm (L x W x D)
WEIGHT
Approximately 9 oz.
INTERFACE
USB 3.0 (2.0 compatible)
STANDARDS AND CERTIFICATIONS:
TAA Compliant, RoHS Compliant, FCC, and CE
SYSTEM COMPATIBILITY
Windows, Mac, and Linux
WARRANTY
2 year limited
SA LES CONTACT S
WEBSITE
datalocker.com
US AND CANADA
[email protected]
+1 913 310 9088
®
to
EUROPE
ASIA PACIFIC
LATIN AMERICA
©2017 DATALOCKER , INC. ALL RIG HTS RESERV ED. DATALOCKER IS A RE GISTERED T RADEMAR K OF DATALOCKER INC . ALL OTHER TR ADEMARK S ARE PROPER TY OF THEIR R ESPECTIV E OWNERS. PR OTECTED BY UN ITED STATES PATEN T NO. 8,185,709, JAPAN ESE PATENT #514534 6 AND KOREAN
PATENT NO. 10- 034205. OT HER PATENTS PENDI NG. 01/2017
