DAS PL-EV26S Data Sheet
DESCRIPTION
The EVENT-26A is a symmetrical, ultra-compact, two-way
powered line array system. Designed by DAS engineers to deliver
stunning performance and exceptional ease-of-use, the stylish
polypropylene cabinet design offers a highly portable and roadworthy system. A comprehensive range of accessories makes the
EVENT-26A ideal for small to mid-size rental and installation
applications.
The EVENT-26A combines two 6.5" transducers and a single
M-60 compression driver in a rugged yet lightweight polymer
cabinet. The symmetric "V" shaped configuration of the cone
transducers provides consistent 100º of horizontal coverage
down to 200 Hz. The M-60 compression driver is coupled to an
advanced waveguide design that provides control of the vertical
dispersion as well as precise coupling between units when used
in vertical arrays.
Powered by a two-channel Class D amplifier providing 800
Wpeak power, the amp´s rear panel includes quality Neutrik®
XLR and powerCON connectors. The DAScontrolTM interface
makes the preset selection for the number of units in the array
both fast and simple. An onboard DSP featuring a 24-bit highend processor handles X-over, EQ, delay, and limiter functions.
The powerful FIR filtering technology incorporated in the
EVENT-26A offers constant phase response which translates to
transparent sound and exceptional clarity, improving the
listening experience.
Streamlined deployment of EVENT-26A arrays is possible thanks
to the innovative FSSTM (Fast Set Splay) rigging system developed
to permit angle selection while stacked on dollies. The stainlesssteel rigging hardware allows flown arrays of up to 16 units in 1º
steps from 0º to 10º.
Low-frequency reinforcement for the EVENT-26A is provided by
its flyable companion subwoofer the EVENT-115A.
KEY FEATURES
· Ultra-compact, lightweight powered line array
· High-efficiency Class D amplifier with SMPS
· Dual voltage mains for use anywhere in the world
· Easy system configuration thanks to DAScontrol
TM
· High-end 24-bit DSP with LCD screen
· FIR processing for constant phase response
· FSSTM Fast Set Splay rigging for quick deployment
APPLICATIONS
· House of worship
· Theatres, auditoria and performing arts centers
· Live music clubs
· Corporate A/V
· Live sound touring/Rental services
SPECIFICATIONS
Performance
Frequency Range (-10 dB) 76 Hz - 19 kHz
Horizontal Coverage (-6 dB) 100º
Vertical Coverage Splay Dependent
Maximum Peak SPL at 1 m 131 dB
Electronics and Connectors
Nominal Amplifier Power (continuous) 400 W
Nominal Amplifier Power (peak) 800 W
Input Type Balanced
Input Impeadance 20 kohms
Input Sensitivity 6.2 V (+18 dBu)
Audio Signal Input Connector 1 x Female XLR
Audio Signal Loop Thru Connector 1 x Male XLR
AC Input Connector powerCON NAC3MPA
AC Output Connector powerCON NAC3MPB
Operating Range 90-127/180-250 VAC
Current Draw 115 V 1.6 A
Current Draw 230 V 0.8 A
Enclosure
Enclosure Construction Polypropylene
Enclosure Geometry Trapezoidal
DAS Audio Group, S.L. - C/ Islas Baleares 24 - 46988 Fuente del Jarro - Valencia - Spain - Tel. +34961340860
Rigging Captive Rigging System
Color Black
IP Rating IP43
Dimensions ( H x W x D )
Net Weight 16,5 kg ( 36,4 lb )
225 x 480 x 485 mm
8,9 x 18,9 x 19,1 in
Components
LF Driver 6MI
HF Driver M-60
Shipping
Carton Dimensions ( H x W x D )
565 x 565 x 290 mm
22,2 x 22,2 x 11,4 in
ORDERING INFORMATION
Performance
Model Description P/N
System
EVENT-26A 2-way Powered Line Array 10435010
Replacement Parts
6MI Cone Transducer 20208985
DSP-EV26 Dsp 20406439
GM-M60N Diaphragm 20205090
M-60 Compression Driver 20208790
MP-EV26 Power Module 20405100
PIN-6 Pin 30002878
Accessories
AX-EV26 Rigging Accessories 10102365
AXC-ZT Installation & Stacking Acc. 10104320
AXS-EV26 Installation & Stacking Acc. 10102366
FUN-4-EV26 Transport Accessories 10103785
JP-EV26 Rigging Accessories 10102979
PL-EV26S Transport Accessories 10113280
PWCONLINK-09 Electronic Accessories 20502210
SC-05 Electronic Accessories 20501010
SC-1 Electronic Accessories 20501020
SC-10 Electronic Accessories 20501050
TRD-2 Installation & Stacking Acc. 10104010
TRD-6 Installation & Stacking Acc. 10104470
TRD-7 Installation & Stacking Acc. 10104471
DIMENSIONS
