RF Optical Mouse
Model #M301
User’s Manual Guide
2
User’s Manual Guide
Hardware Installation
1.Connecting the receiver module
For USB Interface
- Plug the receiver cable into the USB port of your
system.
- System will automatically detect for new hardware.
- Follow system instruction for setup
For USB and PS/2 Combo (If no USB port)
- Connect the PS/2 adaptor to the USB connector of
the receiver.
- Restart your system.
3
Note:
- For optimal performance, place the receiver at least 8 inches (20 cm)
away from any electronics devices (ex. computer, monitor, etc.) to
avoid interference.
- If placing the receiver on metal surface, please use a non-metal pad
under it.
2. Load batteries in optical mouse ( 2 AA batteries)
3. Syncranizing the receiver and wireless mouse
1. Press the connect button on the receiver.
2. Then use a point object to press the connect button on bottom
side of the mouse
4
Troubleshooting
Make sure the receiver cable is connected to the port
Press connect button on receiver, and then press the
Cautions
Mouse does not work
1.
correctly.
2. Check battery.
3.
connect button on the mouse.
4. Make sure your mouse in not sitting on a red or
highly reflective surface (ex. Mirror, glass, etc.)
ID conflict. (When two mice have mutual interference)
1. Press connect button on receiver to select new ID.
2. Press connect button on bottom of the mouse.
-
Long periods of repetitive motion using a mouse may be
associated with physical discomfort and injury in your
hands, wrists, arms, shoulders, neck, or back. To reduce
the risk of injury, we suggest taking frequent short breaks
and keep your shoulders relaxed.
This product has been tested to comply with international
standard IEC 825-1:1993
5
FCC Warning!
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to
correct the interference by on or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for
help.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference and (2)
this device must accept any interference received, including
interference that may cause undesired operation.
Note: The manufacturer is not responsible for any radio or TV
interference caused by unauthorized modifications to this equipment.
Such modifications could void the user's authority to operate the
equipment.
