WMS4T-B
Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands
Product code: D3832
USER MANUAL
ENGLISH
V1
1
WMS4T-B
Product code: D3832
Table of contents
1. Introduction .......................................................................................................................................................... 3
Before Using the Product .................................................................................................................................. 3
Intended Use ....................................................................................................................................................... 3
Text Conventions ................................................................................................................................................ 3
Symbols and Signal Words ................................................................................................................................ 4
Symbols on the Information Label .................................................................................................................. 4
2. Safety .................................................................................................................................................................... 5
Warnings and Safety Instructions .................................................................................................................... 5
Requirements for the User ................................................................................................................................. 6
3. Description of the Device ................................................................................................................................... 7
Front View ............................................................................................................................................................ 7
Back View ............................................................................................................................................................ 7
Bottom View ........................................................................................................................................................ 8
Mounting Plate ................................................................................................................................................... 8
Product Specifications ...................................................................................................................................... 9
Dimensions .........................................................................................................................................................10
4. Installation and Setup ....................................................................................................................................... 11
Safety Instructions for Installation ..................................................................................................................11
Installation Site Requirements ........................................................................................................................11
Mounting and Setup ........................................................................................................................................11
Drilling Mounting Holes ..........................................................................................................................12
Drilling into Wood ...............................................................................................................................12
Drilling into Concrete .........................................................................................................................12
Connecting Devices ..............................................................................................................................13
100 V Amplifier Mode ........................................................................................................................13
Conventional Amplifier Mode .........................................................................................................14
Installing the Mounting Plate ................................................................................................................15
Setting Line Transformer Taps ...............................................................................................................16
Installing the Speaker .............................................................................................................................17
Adjusting the Angle................................................................................................................................18
Adjusting the Logo .................................................................................................................................19
Option 1 ...............................................................................................................................................19
Option 2 ...............................................................................................................................................19
Connecting the Amplifier .....................................................................................................................20
5. Troubleshooting ................................................................................................................................................. 20
6. Maintenance ..................................................................................................................................................... 21
Preventive Maintenance ................................................................................................................................21
Basic Cleaning Instructions ...................................................................................................................21
Corrective Maintenance ................................................................................................................................21
7. Deinstallation, Transportation and Storage .................................................................................................... 22
Instructions for Deinstallation ..........................................................................................................................22
Instructions for Transportation ........................................................................................................................22
Storage ...............................................................................................................................................................22
8. Disposal .............................................................................................................................................................. 22
9. Approval ............................................................................................................................................................. 22
2
WMS4T-B
Product code: D3832
Preface
Thank you for purchasing this DAP product.
The purpose of this user manual is to provide instructions for the correct and safe use of this product.
Keep the user manual for future reference as it is an integral part of the product. The user manual shall be
stored at an easily accessible location.
This user manual contains information concerning:
● Safety instructions
● Installation and operation of the device
● Intended and non-intended use of the device
● Maintenance procedures
● Troubleshooting
● Transport, storage and disposal of the device
Non-observance of the instructions in this user manual may result in serious injuries and damage of
property.
©2022 DAP. All rights reserved.
No part of this document may be copied, published or otherwise reproduced without the prior written
consent of Highlite International.
Design and product specifications are subject to change without prior notice.
For the latest version of this document or other language versions, please visit our website
www.highlite.com or contact us at service@highlite.com.
Highlite International and its authorized service providers are not liable for any injury, damage, direct or
indirect loss, consequential or economic loss or any other loss arising from the use of, or inability to use or
reliance on the information contained in this document.
3
WMS4T-B
Product code: D3832
1. Introduction
Before Using the Product
Important
Read and follow the instructions in this user manual before installing, operating or
servicing this product.
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual.
After unpacking, check the contents of the box. If any parts are missing or damaged, contact your
Highlite International dealer.
Your shipment includes:
● DAP WMS4T-B
● Mounting plate
● Mounting screw
● Rubber gasket
● User manual
Fig. 01
Intended Use
This device is designed to be used as a 100 V line wall-mount speaker. The device is suitable for fixed
permanent installation in commercial and public spaces. It can be installed indoors and outdoors. Any
incorrect use may lead to hazardous situations and result in injuries and material damage.
Any other use, not mentioned under intended use, is regarded as non-intended and incorrect use.
Text Conventions
Throughout the user manual the following text conventions are used:
● References: References to chapters and parts of the device are in bold lettering, for example:
“Refer to 2. Safety”, “press the power switch (03)”
● 0–255: Defines a range of values
● Notes: Note: (in bold lettering) is followed by useful information or tips
4
WMS4T-B
Product code: D3832
Symbols and Signal Words
Safety notes and warnings are indicated throughout the user manual by safety signs.
Always follow the instructions provided in this user manual.
DANGER
Indicates an imminently hazardous situation which, if not avoided, will result in
death or serious injury.
WARNING
Indicates an imminently hazardous situation which, if not avoided, could result
in death or serious injury.
CAUTION
Indicates a potentially hazardous situation, which, if not avoided, may result in
minor or moderate injury.
Attention
Indicates important information for the correct operation and use of the
product.
Important
Read and observe the instructions in this document.
Provides important information about the disposal of this product.
Symbols on the Information Label
This product is provided with an information label. The information label is located on the bottom plate of
the device.
The information label contains the following symbols:
This device shall not be treated as household waste.
Read and follow the instructions in the user manual before installing, operating or
servicing the device.
5
WMS4T-B
Product code: D3832
2. Safety
Important
Read and follow the instructions in this user manual before installing, operating or
servicing this product.
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual.
Warnings and Safety Instructions
DANGER
Danger for children
For adult use only. The device must be installed beyond the reach of children.
● Do not leave various parts of the packaging (plastic bags, polystyrene foam, nails, etc.) within
children’s reach. Packaging material is a potential source of danger for children.
Attention
Speaker load
● Make sure that the total wattage of all connected speakers does not exceed the rated wattage of
the amplifier.
● Make sure that the speaker cable run is appropriate for the total speaker load.
Attention
General safety
● Do not shake the device. Avoid brute force when installing or operating the device.
● If the device fails to work properly, discontinue the use immediately.
Attention
This device shall be used only for the purposes it is designed for.
This device is designed to be used as a 100 V line wall-mount speaker. Any incorrect use may lead to
hazardous situations and result in injuries and material damage.
● This device is not suitable for households.
● This device does not contain user-serviceable parts. Unauthorized modifications to the device will
render the warranty void. Such modifications may result in injuries and material damage.
6
WMS4T-B
Product code: D3832
Attention
Do not expose the device to conditions that exceed the rated IP class conditions.
This device is IP54 rated. IP (Ingress Protection) 54 class means that the device is dust-protected. Ingress of
dust does not interfere with satisfactory operation of the device. Water splashed against the enclosure
from any direction shall have no harmful effect.
Requirements for the User
This product may be used by ordinary persons. Maintenance may be carried out by ordinary persons.
Service and installation shall be carried out only by instructed or skilled persons. Contact your Highlite
International dealer for more information.
Instructed persons have been instructed and trained by a skilled person, or are supervised by a skilled
person, for specific tasks and work activities associated with the installation, service and maintenance of
this product, so that they can identify risks and take precautions to avoid them.
Skilled persons have training or experience, which enables them to recognize risks and to avoid hazards
associated with the installation, service and maintenance of this product.
Ordinary persons are all persons other than instructed persons and skilled persons. Ordinary persons
include not only users of the product but also any other persons that may have access to the device or
who may be in the vicinity of the device.
7
WMS4T-B
Product code: D3832
3. Description of the Device
The DAP WMS4T-B is an IP-rated 100 V speaker for low-impedance audio installations. The device can be
easily mounted to a wall, in a horizontal or vertical orientation. The DAP logo on the front is rotatable. The
device can be used in shops, restaurants or clubs, as well as in sheltered outdoor locations.
Front View
Fig. 02
Speaker grill
Rotatable logo
Rubber ball-joint cover
Back View
Fig. 03
Mounting panel
4 x speaker mounting holes
Speaker connector
Mounting plate (See 3.4. Mounting Plate on page 8)
Rubber gasket
Line transformer tap cover
Line transformer tap selector
8
WMS4T-B
Product code: D3832
Bottom View
Fig. 04
Mounting screw (M3 x 10 mm)
2 x adjustment screws (M6 x 45 mm)
Ball-joint
Mounting Plate
Fig. 05
4 x mounting holes (Ø 5 mm)
4 x mounting hooks
4-pin terminal connector
9
WMS4T-B
Product code: D3832
Product Specifications
Model:
DAP WMS4T-B
Physical:
Dimensions:
144 x 180 x 260 mm (L x W x H)
Weight:
1,9 kg
Inputs:
Passive input connector:
4-pin terminal
Transformer:
100 V
Output:
Passive output connector:
4-pin terminal
Audio Specifications:
Speaker system:
2-way
Speaker sensitivity (1 W/1 m):
86,5 dB
Speaker impedance:
8 Ω
Maximum SPL at 1 m:
98,5 dB
Frequency response:
90–20000 Hz
Woofer diameter:
4′′
Woofer magnet type:
Ferrite
Compression driver magnet type:
Ferrite
Line transformer taps:
@ 70 V: 1,25 W/2,5 W/5 W/7,5 W
@ 100 V: 2,5 W/5 W/7,5 W/15 W
8 Ω
Construction:
Housing:
ABS
Color:
Black
IP rating:
IP54
Product Properties:
Speaker grill:
Aluminum
Thermal:
Max. ambient temperature ta:
From -10 to 45 °C
10
WMS4T-B
Product code: D3832
Dimensions
Fig. 06
11
WMS4T-B
Product code: D3832
4. Installation and Setup
Safety Instructions for Installation
WARNING
Incorrect installation can cause serious injuries and damage of property.
Installation Site Requirements
● The device can be used outdoors.
● The device can be mounted on a wall in a vertical or horizontal orientation.
● The device must be installed away from heating sources.
● The maximum ambient temperature t
a
= 45 °C must never be exceeded.
● The relative humidity must not exceed 50 % with an ambient temperature of 45 °C.
Mounting and Setup
To mount the device, you need:
● Phillips screwdriver (PH1)
● Hex key (5 mm)
● Anchors
● Drill bits
● Power drill
To mount and set up the device, follow the steps below:
Drill mounting holes on the wall. See 4.3.1. Drilling Mounting Holes on page 12.
Connect the amplifier and daisy-chain the WMS speakers. See 4.3.2. Connecting Devices on page
13.
Install the mounting plate (07) on the wall. See 4.3.3. Installing the Mounting Plate on page 15.
Set a correct line transformer tap. See 4.3.4. Setting Line Transformer Taps on page 16.
Install the speaker on the mounting plate (07). See 4.3.5. Installing the Speaker on page 17.
Adjust the angle of the device. See 4.3.6. Adjusting the Angle on page 18.
Adjust the orientation of the logo. See 4.3.7. Adjusting the Logo on page 19.
Connect the amplifier to the power supply. See 4.3.8. Connecting the Amplifier on page 20.
Switch on the amplifier.
12
WMS4T-B
Product code: D3832
Drilling Mounting Holes
01) Hold the mounting plate (07) against the wall, as shown in Fig. 07, and mark the mounting locations.
Fig. 07
Drill holes at the marked locations. See 4.3.1.1. Drilling into Wood or 4.3.1.2. Drilling into Concrete on
page 12 for more information.
Insert anchors into the drilled holes (Fig. 08). Do not perform this step when mounting the device on a
wooden wall.
Fig. 08
Drilling into Wood
If you drill into wood, use hardwood drill bits. Predrill before inserting screws, to remove drill dust and to
avoid damaging of the wood.
Fig. 09
Note:
Hardwood drill bits shall be of the diameter slightly smaller than the screws used (e.g. for Ø 5 mm screws,
use a Ø 3,5 mm hardwood drill bit).
Drilling into Concrete
If you drill into a concrete wall, use drill bits for concrete. Do not drill into mortar joints. Screws installed in
mortar joints cannot safely support the weight of the device.
Fig. 10
Note:
Drill bits shall be of the same diameter as the anchors.
13
WMS4T-B
Product code: D3832
Connecting Devices
Connect all cables to the mounting plate (07). Make sure that the cable polarity is correct (+/-) (Fig. 11).
Fig. 11
100 V Amplifier Mode
To use the device with a 100 V amplifier, follow the steps below:
Connect the COM output of the 70/100 V amplifier to one of the (-) connectors on the mounting
plate (07).
Connect the line transformer tap (70 V or 100 V) of the 70/100 V amplifier to one of the (+)
connectors on the mounting plate (07).
Connect multiple speakers as shown in Fig. 12.
Fig. 12
14
WMS4T-B
Product code: D3832
Conventional Amplifier Mode
To use the device with a conventional amplifier, follow the steps below:
Connect the (-) output of the conventional amplifier to one of the (-) connectors on the mounting
plate (07) of the first speaker.
Connect the (+) output of the conventional amplifier to one of the (+) connectors on the mounting
plate (07) of the first speaker.
Connect multiple speakers as shown in Fig. 13.
Fig. 13
15
WMS4T-B
Product code: D3832
Installing the Mounting Plate
Install the mounting plate (07) with the mounting hooks facing up (Fig. 14).
Fig. 14
To install the mounting plate (07), follow the steps below:
Hold the mounting plate (07), with the rubber gasket (08), against the wall, in such a way that all
cables fit through the opening in the rubber gasket (08) (Fig. 15).
Note:
Make sure that the opening in the gasket is located at the bottom (Fig. 15). If, for any reason, such
installation is not possible, seal the opening with a waterproof sealant to protect the device from the
ingress of water (Fig. 16).
Fig. 15
Fig. 16
Insert and tighten the screws to install the mounting plate (07) and the rubber gasket (08) on the wall
(Fig. 17). The screws shall be at least 12,5 mm long. Do not overtighten the screws as this can
damage the mounting plate (07). The damaged mounting plate (07) cannot support the weight of
the device and can break easily.
Fig. 17
16
WMS4T-B
Product code: D3832
Setting Line Transformer Taps
The device has multiple selectable line transformer taps.
To select line transformer taps, follow the steps below:
01) Pry up and remove the line transformer tap cover (09) to get access to the line transformer tap
selector (10).
02) Turn the line transformer tap selector (10) to select a line transformer tap. The available line
transformer taps are:
Fig. 18
03) Install the line transformer tap cover (09) again.
Note:
The line transformer tap values depend on the type of amplifier connected to the PA system.
● For a 70 V amplifier, the line transformer taps are: 1,25 W/2,5 W/5 W/7,5 W.
● For a 100 V amplifier, the line transformer taps are: 2,5 W/5 W/7,5 W/15 W.
● For a conventional amplifier, use only the “8 Ω” line transformer tap.
The higher the wattage setting, the higher the volume level of the speaker.
17
WMS4T-B
Product code: D3832
Installing the Speaker
To mount the speaker, follow the steps below:
Turn the mounting screw (11) counter-clockwise to remove it.
Hang the speaker on the mounting plate (07) (Fig. 19).
Notes:
● The 4 x mounting hooks (15) shall fit through the 4 x speaker mounting holes (05) on the
mounting panel (04).
● The speaker connector (06) shall fit in the 4-pin terminal connector (16) on the mounting plate
(07).
Fig. 19
Insert the mounting screw (11) and tighten it with the Phillips screwdriver (Fig. 20).
Fig. 20
18
WMS4T-B
Product code: D3832
Adjusting the Angle
You can adjust the angle of the device with the adjustment screws (12).
To adjust the angle, follow the steps below:
01) Fold the rubber ball-joint cover (03) to get access to the adjustment screws (12).
02) Loosen the adjustment screws (12) with the hex key (Fig. 21).
Fig. 21
03) Tilt the device. The tilt range is 30° in all directions (Fig. 22).
Fig. 22
04) Rotate the ball-joint (13) to set the device in a vertical or horizontal orientation (Fig. 23). The ball-joint
rotation range is 90°.
Fig. 23
05) Tighten the adjustment screws (12) with the hex key, so that the device cannot move freely.
06) Unfold the rubber ball-joint cover (03).
19
WMS4T-B
Product code: D3832
Adjusting the Logo
You can adjust the orientation of the DAP logo on the speaker grill so that it is always legible, regardless
of the orientation of the device.
Option 1
Use a tool to pry up the rotatable logo (02).
Move the rotatable logo (02) to the correct orientation.
Fig. 24
Option 2
01) Pry up the speaker grill (01) and remove it from the device (Fig. 25).
Fig. 25
Fig. 26
02) On the inside of the speaker grill (01), press on the spring-loaded pin and move the rotatable logo
(02) to the correct orientation (Fig. 26).
03) Release the spring-loaded pin.
04) Install the speaker grill (01) on the device.
20
WMS4T-B
Product code: D3832
Connecting the Amplifier
Attention
Speaker load
Before connecting the amplifier to the power supply, make sure that the total load of all connected
speakers is below the maximum rating of the amplifier. If the total load is higher, it may cause damage to
the amplifier and to the speakers.
The total load depends also on the current line transformer tap setting of the speakers. See 4.3.4. Setting
Line Transformer Taps on page 16 for more information.
To determine if the settings are correct:
Add up the wattage settings of all connected speakers.
Compare the value with the maximum rating of the amplifier. If necessary, disconnect speaker(s).
5. Troubleshooting
This troubleshooting guide contains solutions to problems which can be carried out by an ordinary
person. The device does not contain user-serviceable parts.
Unauthorized modifications to the device will render the warranty void. Such modifications may result in
injuries and material damage.
Refer servicing to instructed or skilled persons. Contact your Highlite International dealer in case the
solution is not described in the table.
Problem
Probable cause(s)
Solution
The device does not
function at all
Bad connection
● Check if the connections between the
devices are correct
No power to the amplifier
● Check if the amplifier is on
Incorrect settings
● Check if correct line transformer taps
are selected
● Check if the amplifier is compatible with
the device
No sound
Incorrect polarity of the
connections
● Check if the polarity of the connections
between the devices is correct
21
WMS4T-B
Product code: D3832
6. Maintenance
Preventive Maintenance
Attention
Before use, examine the device visually for any defects.
Make sure that:
● There are no deformations on the housing.
● The device is rigidly mounted to the wall.
Basic Cleaning Instructions
To clean the device, follow the steps below:
Clean the device with a soft, lint-free cloth.
Attention
● Do not immerse the device in liquid.
● Do not use alcohol or solvents.
Corrective Maintenance
The device does not contain user-serviceable parts. Do not open the device and do not modify the
device.
Refer repairs and servicing to instructed or skilled persons. Contact your Highlite International dealer for
more information.
22
WMS4T-B
Product code: D3832
7. Deinstallation, Transportation and Storage
Instructions for Deinstallation
WARNING
Incorrect deinstallation can cause serious injuries and damage of property.
● Disconnect power supply before deinstallation.
● Always observe the national and site-specific regulations during deinstallation and derigging of the
device.
● Wear personal protective equipment in compliance with the national and site-specific regulations.
Instructions for Transportation
● Use the original packaging to transport the device, if possible.
● Always observe the handling instructions printed on the outer carton box, for example: “Handle with
care”, “This side up”, “Fragile”.
Storage
● Clean the device before storing. Follow the cleaning instructions in chapter 6.1.1. Basic Cleaning
Instructions on page 21.
● Store the device in the original packaging, if possible.
8. Disposal
Correct disposal of this product
Waste Electrical and Electronic Equipment
This symbol on the product, its packaging or documents indicates that the product
shall not be treated as household waste. Dispose of this product by handing it to the
respective collection point for recycling of electrical and electronic equipment. This
is to avoid environmental damage or personal injury due to uncontrolled waste
disposal. For more detailed information about recycling of this product contact the
local authorities or the authorized dealer.
9. Approval
Check the respective product page on the website of Highlite International (www.highlite.com) for an
available declaration of conformity.
©2022 DAP
Loading...
