DCS 6000
User Manual
Danish Interpretation Systems DIS
Digital Conference System
IS 6132P Interpreter Set
Danish Interpretation Systems User Manual
Copyright © 2002 Danish Interpretation Systems
No part of this publication may be reproduced or utilised in any form or by any means without permission in writing from the
publisher.
Danish Interpretation Systems User Manual
Copyright © 2002 Danish Interpretation Systems
No part of this publication may be reproduced or utilised in any form or by any means without permission in writing from the
publisher.
List of Contents
List of Contents .....................................................3
Document version..............................................3
Important...............................................................4
Compliancy ........................................................4
Installation precautions.....................................4
Cleaning..............................................................4
Repacking...........................................................4
Warranty............................................................4
Description of the DCS 6000 system....................5
Features..............................................................5
System components ...........................................6
Central equipment etc......................................6
Interpreter equipment.......................................6
Conference equipment and channel selectors..6
Operating instructions..........................................7
IS 6132 P Interpreter Set..................................7
General description.......................................... 7
Features ........................................................... 7
User Controls, indications & connectors.........7
Set up for each interpreters set ........................9
Normal operation........................................... 11
System Setup.......................................................14
Typical schematics .......................................... 14
Appendix.............................................................. 15
Language list.................................................... 15
Technical appendix.........................................16
Cabling ..........................................................16
Accessories (not supplied)............................. 16
Technical specifications ................................ 17
Document version
Printed: 12-10-2004 Version: K
Name: IS6132-REV-K.DOC
Danish Interpretation Systems User Manual
Manual 01 18 04445, Printed in Denmark, 02/2003 CHN
4
Important
Compliancy
The equipment has been tested and found to comply
with the limits of the following standards for digital
devices:
• EN55103-1 (Emission)
• EN55103-2 (Immunity)
• FCC rules part 15, class A (Emission)
This device complies with part 15 of the FCC rules.
Operation is subject to the following conditions: (1)
This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
These limits are designed to provide reasonable
protection against harmful interference when the
equipment is operated in a commercial or light
industrial environment. The equipment generates,
uses, and can radiate radio frequency energy and if
not installed and used in accordance with the user
manual it may cause harmful interference to radio
communications.
You are cautioned that any changes or
modifications not expressly approved in this manual
could void your authority to operate this equipment.
Installation precautions
Do not install the unit in a location near heat
sources such as radiators or air ducts, or in a place
exposed to direct sunlight, excessive dust or
humidity, mechanical vibration or shock.
To avoid moisture condensations do not install the
unit where the temperature may rise rapidly.
Cleaning
To keep the cabinet in its original condition,
periodically clean it with a soft cloth. Stubborn
stains may be removed with a cloth lightly
dampened with a mild detergent solution. Never use
organic solvents such as thinners or abrasive
cleaners since these will damage the cabinet.
Repacking
Save the original shipping cardboard box and
packing material; they will become handy if you
ever have to ship the unit. For maximum protection,
re-pack the unit as originally packed from the
factory.
Warranty
The individual units in the DCS 6000 system are
minimum covered by 12 months warranty against
defects in materials or workmanship.
Danish Interpretation Systems User Manual
Manual 01 18 04445, Printed in Denmark, 02/2003 CHN
5
Description of the DCS 6000 system
Features
The DCS 6000 system has the following main
features:
• Fully digital
• Excellent sound quality
• “State of the Art” fully digital integrated
interpretation, discussion and voting system
offering interpretation, language distribution,
conference microphone and voting facilities
with attendance check with Chip Card ™.
• New, unique digital DATA and AUDIO bus.
• 39 incoming channels (8 floor channels + 31
interpreted channels) and one Line input.
• 33 distributed channels (2 x floor + 31
interpreted channels)
• The Delegate and Interpreter units are powered
and controlled by the CU 6010 Central Unit,
which drives up to app. 200 units on 4 chains.
• EX 6010 Extension Units or PS 6000 Power
Supplies available if more units are required
• A total of 4000 units (delegate and/or
interpreter units) can be connected to the
system.
• Using screened CAT5 or CAT5e cabling (FTP
or STP) ensuring a very cost effective
installation and easy set-up of portable systems
• Firmware in Delegate units, Interpreter Units,
Central Units etc. upgradeable through serial
PC-connection (RS232 or RS422)
• Can be operated with or without a PC.
• Added functionality and comprehensive
features provided by SW 6000 software
package running on PC
RS232/RS422 connection on CU 6010 for
external operation of the system of a PC or
control system such as AMX or Crestron
The SW 6000 is an optional software package,
which expands the functionality of the DCS 6000
system. The software runs on standard computer
technology (Standard PC with Windows 2000 or
XP).
Main features of the SW 6000 are:
• Microphone management
• Mimic panel operation
• Interpretation management
• Voting management
• Message handling
• Agenda handling
• Data stored on SQL data base for easy
export/import of data as well as easy links to
external databases
• Multi language user interfaces
• Supports different User types with different
priorities, user interfaces and control
possibilities
• Variety of printing facilities such as speaker’s
log, voting results, delegates list etc.
Danish Interpretation Systems User Manual
Manual 01 18 04445, Printed in Denmark, 02/2003 CHN
6
System components
The CU 6010 Central Unit supports all available
units in the DCS 6000 series:
Central equipment etc.
EX 6010 Extension Unit
PS 6000 Power Supply
AO 6008 Audio Output box
RP 6004 Repeater for four chains
JB 6002 Junction Box with 2 outputs
JB 6004 Junction Box with 4 outputs
Interpreter equipment
IS 6032P Interpreter Set
IS 6132P Interpreter Set
LS 6032P Interpreter Loudspeaker
Conference equipment and channel
selectors
CS 6032FV/H Channel Selector (flush mounted)
CM/DM 6010P Conference Unit (portable)
CM/DM 6020P Conference Unit (portable) with
XLR microphone connector
CM/DM 6070P Conference Unit (portable) with
two built-in channel selectors
CM/DM 6090P Conference Unit (portable) with
two built-in channel selectors and
XLR microphone connector
CM/DM 6060F Conference Unit (flush mounted)
with one built-in channel
selectors
CM/DM 6510F Conference Unit (flush mounted)
with Chip-card and 3 voting
buttons
CM/DM 6560F Conference Unit (flush mounted)
with one built-in channel
selector, Chip-card and 3 voting
buttons
MU 6040C/D Microphone Unit for use with
customised front plate with
Loudspeaker, Microphone and
Buttons. Available in Delegate
(D) and Chairman (C) version
AM 6040 Ambient Noise Microphone
Danish Interpretation Systems User Manual
Manual 01 18 04445, Printed in Denmark, 02/2003 CHN
7
Operating instructions
IS 6132 P Interpreter Set
General description
The IS 6132 Interpreter Set is designed for use for
one interpreter, It is a compact unit for table top
use. The design of the units is easy understandable
with a “listening part” at the left side of the unit and
a “speaking part” at the right side of the unit.
Features
The main features of the IS 6132 Interpreter Unit
are:
• 4 pre-select listening channels
• Large LCD display with back light
possibility
• Clear LED indication in buttons
• For use with either headset or gooseneck
microphone
User Controls, indications & connectors
Front plate layout
Incoming
- VOLUME +
- BASS +
- TREBLE +
c
a
b
d
Relay-select
Outgoing
Mute
Floor
Microphone
B-select
IS 6132 Interpreter Set
A
B
Call
too fast
Engaged
Danish Interpretation Systems
Speaking
Danish Interpretation Systems User Manual
Manual 01 18 04445, Printed in Denmark, 02/2003 CHN
8
Front plate controls
q Incoming Section
• Volume
This control adjusts the listening level in the
connected headphone
• Bass
This control adjust the Bass level in the connected
headphone
• Treble
This control adjust the Treble level in the connected
headphone
• a-b-c-d
These button selects between four pre-selection of
relay channels
• Relay-select
These buttons are used for each of the four preselection to scroll through the available languages
• Floor
This button selects the floor language as the
listening language
q Outgoing Section
• Microphone
This button switches on the microphone. When
switched ON, the button and the light ring on the
gooseneck microphone will light red.
• Mute
This button is used to temporarily switching off the
microphone (when coughing etc). The channel is
still “occupied” when pressing the button, but the
microphone is disconnected as long as the button is
depressed. Mute is indicated by switching off the
light in the light ring of the microphone.
• A
Press this button to select the A-language as the
outgoing channel. A Red LED is indicating, that Alanguage is selected. The Yellow engaged LED is
indicating, that the A-channel is occupied i.e. a
microphone on an interpreter set is switched on at
this channel
• B
Press this button to select the B-language as the
outgoing channel. A Red LED is indicating, that Blanguage is selected The Yellow engaged LED is
indicating, that the B-channel is occupied i.e. a
microphone on an interpreter set is switched on at
this channel.
• B-Select
After pressing the B-button, the B-language can be
selected (if ALL is chosen at the B-mode selection
in the B-language set-up menu.
• Speaking too fast
Pressing this button sends a signal to the Chairman,
that the Speaker has to slow down his speech.
• Call
Not implemented
q Connectors
• XLR connector
The XLR-connector on the front is used for
connecting a microphone to the unit. Please note
that only DIS series GM40xx and GM44xx can be
used.
• Headphone connector
On each side of the interpreter set a mini jack is
located for connecting a headphone for listening to
the Floor language or one of the pre-selected relay
languages (a-b-c-d). On the left side a standard jack
connector is also located with the same
functionality.
Danish Interpretation Systems User Manual
Manual 01 18 04445, Printed in Denmark, 02/2003 CHN
9
• Headset Connector
On the left side, a DIN connector is located for
connecting a DIS headset instead of a microphone.
• “Display” power connector
The unit supports a dimmed backlight (on/off user
selectable) in the LCD display with no external
power supply connected. However special
circumstances can required full light in the display.
At the bottom a power connector is used for
connecting a optional Power Adapter used for
supplying power for full light in the display. Please
note, that the interpreter set is functioning perfectly
also without light in the display.
Please observe that only the Power adapter supplied
with the interpreter set can be used. Other Power
adapters might damage the interpreter set.
• Loudspeaker Connector
A D-Sub 9 pole connector for connecting the
LS6032 Loudspeaker unit is located at the bottom
of the unit. The LS6032 Loudspeaker has a separate
Volume control. The loudspeaker will be
disconnected automatically if a microphone is
switched on at one of the interpreter sets in the
same booth (same A-language). This connector is
only on some versions of the Interpreter Set.
• DCS LAN connector
Two RJ45 sockets are located at the bottom of the
unit for connecting to the previous unit (an
Interpreter set or CU 6010 or an other DCS 6000
unit) and to the next unit.
Set up for each interpreters set
When an IS 6132 interpreter unit is connected to the
CU 6010, the following start-up screen is shown
The 9 digit number at the bottom of the display is
the units serial number. Each of the three positions
separated by dots can hold a value of 0-255 giving a
maximum serial number of 255.255.255.
After some seconds the following type of screen is
shown:
This screen will be different on the various
Interpreter sets, depending on the individual set-up
of the Interpreter Set. If the welcoming screen does
not disappear, the interpreter set has not been setup. For setting up the interpreter set, please see next
section.
A black dot in the middle of the first line indicates
that the Audio out from the interpreter unit is
muted. The reason for this is communication
problems. Cables etc. have to be checked.
Setup menu
Before using an Interpreter Set, a set-up of the Alanguage and B-language has to be done on all
other interpreters’ sets.
When b and B are depressed simultaneously the setup menu is shown:
When the unit is un-configured (has not yet
received an address) the first two menus will not be
available. This is indicated by the missing “-“
-A-language/desk no. ?
-B-language/B-mode
-Ver. and serial no.
-
Communication sta
tus
?
A-language/desk no. ?
B-language/B-mode
-Ver. and serial no.
-
Communication status
?
DANISH INTERPRETATION
SYSTEMS
IS6132
055.004.255
11 SWE FLOOR 2
1 ITA FLOOR ENGLISH
3 FR FLOOR 11
4 DAN FLOOR SWEDISH
11 SWE FLOOR ¦ 2
1 ITA FLOOR ENGLISH
3 FR FLOOR 11
4 DAN FLOOR SWEDISH
Danish Interpretation Systems User Manual
Manual 01 18 04445, Printed in Denmark, 02/2003 CHN
10
If the B-select buttons is pressed the last two menu
items are shown:
A menu is selected by pressing the button to the left
of the menu (a-d). Then the display shows the next
level of menus or selections.
“A” language selection
Pressing the (d) button selects the A-language setup menu:
Press c-button for selecting the A-language for the
Interpreter Set. A black dot is indicating the
selection. Then use Relay-select up/down to scroll
through the available languages. The Desk number
will automatically change to the next available desk
for the selected language. To save the selection,
press OK (B-button).
If the desk number is set to an already occupied
desk number the set will take over the configuration
from the set on that desk and the other set will be
loose the configuration.
“B” language selection
When B-language is selected by pressing the cbutton, the following menu will appear.
Press button (c) for selecting the B-language for the
Interpreter Set. A black dot is indicating the
selection. Use Relay-select up/down to scroll
through the available languages.
Press button (a) for selecting the B-mode for the
Interpreter Set. The B-mode selection has the
following choices:
All The interpreter can select any B-language
himself.
One Only the B-language chosen at the B-
language selection can be used during operation.
None During operation no B-language can be
used (the B-button has no function except for b-B).
To save the selection, press OK (B-button).
Ver. and serial no.
This is an information menu showing the version,
software serial number and the address assigned to
the unit by the CU 6010 Central Unit.
Press OK to return to the Set-up menu
Communication status
This is an information menu showing the
communication status of the unit.
Press Reset to reset the number of Errors etc.
counted. After start up, some errors can be seen, but
if the numbers of errors are constantly increasing,
the cabling or a unit is defective. The fault could
also be a LAN connector, which is not properly
inserted. Please note the “click” from the lock,
when inserting the connector.
Press OK to return to the Set-up menu.
If the communication during start up is failing in a
way, that the Interpreter Unit will not work, this
screen will be shown instead of normal welcoming
screen.
-Backlight ?
-AB with mic on
?
A-language:
¦ 7 Norwegian OK
Desk number: Cancel
1
B-language:
¦ 7 Norwegian OK
B-mode: Cancel
One
IS6132 rev. D
SW ver.: 000.0043 OK
Serial #: 055.004.255
Address: 215
Rx Errors: 0
Tx Retries: 0 OK
Tx dropped: 0 Reset
Danish Interpretation Systems User Manual
Manual 01 18 04445, Printed in Denmark, 02/2003 CHN
11
LCD backlight
This menu gives the user the possibility to control
the dimmed LCD backlight:
The user can toggle the backlight setting between
ON and OFF by pressing the relay-select buttons.
Press OK to return to the Set-up menu
Only dimmed LCD backlight can be controlled
using this menu – strong LCD backlight will be
available if external Power Supply is connected
AB switch with mic on
AB switch with mic on means that the user can
change the outgoing channel from A to B even
when the microphone is active.
The feature is toggled between ON and OFF with
relay-select.
This feature is typically used in two language
scenarios where an interpreter is responsible for
translating from language A to B and also the
reverse from language B to A.
Press OK to return to the Set-up menu.
Normal operation
As mentioned in previous chapter the following
type of screen is shown short time after the system
is powered up:
This screen will be different on the various
Interpreter Sets, depending on the individual set-up
of the Interpreter Set.
Please note, if the welcoming screen is not
disappearing, the “A”-language has not been set-up.
For setting up the interpreter set, please see the
section “Set up for each interpreters set”.
Selection of incoming language
When interpreting, the interpreter will listen to
either the “Floor” language or will listen to one of
the interpreted languages. The Floor button will
select the Floor language and the buttons a, b, c and
d select the pre-selected languages shown on the
LCD-display to the headphone output. Each of the
buttons can be pre-selected to any of the interpreter
channels.
When one of the buttons a, b, c and d is pressed a
LED is lighted in the button pressed indicating, that
this pre-select is chosen.
The two first characters in the display show the
channel number (e.g. 12 or 5) and the following
three characters show the corresponding language
in short (see language list).
When the Floor button is pressed the Floor channel
is selected and the green Floor LED is lit. Also the
indication in one of the buttons a, b, c and d is
removed.
OBS If the functionality, that pressing the Floor
button again shall switch the listening back to the
previous selection of (a, b, c or d) is required, at
setting in the CU 6010 can be changed. Please
consult the DIS factory for this option.
When one of the a-d channels is selected the Floor
LED goes out and the audio from the selected
channel is switched on instead of Floor. It is then
possible to change the listening channel with the
Relay select up and down push buttons. When the
highest number is reached when stepping up, the
counting restarts from 1.
The reverse will happen when stepping down.
LCD backlight:
¦ ON OK
Cancel
AB switch with mic on:
¦ ON OK
Cancel
11 SWE FLOOR 2
1 ITA FLOOR ENGLISH
3 FR FLOOR 11
4 DAN FLOOR SWEDISH
Danish Interpretation Systems User Manual
Manual 01 18 04445, Printed in Denmark, 02/2003 CHN
12
If one of the buttons is held down for more than one
second the channels will scroll through the
languages with a speed of 2-4 languages per
second.
Only the number of channels set at the Channel Setup menu at the CU 6010 can be selected and shown.
The numbers will always be in succession from 1
and up. The same is the case for the CS 6032
channel selectors, with the exception, that the CS
6032 is also showing channel 0 (floor)
Showing quality of Incoming language
To the right of the four a-d language abbreviations
of the quality of the source is shown.
If there is no interpretation at the channel (Floor
audio is present) then “FLOOR” will be shown.
When there is an interpreters set switched on to the
channel where the interpreter is listening to Floor,
then a quality indication “+” is shown.
When an interpreter’s set is switched on to the
channel where the interpreter listens to another
channel whose interpreter listens to Floor, a quality
indication “-.” is shown. This is indication one relay
interpreting.
Brought one level further, a quality indication “- -.”
is shown. This is indication for double or more
relay interpreting
When interpreting on the A-language and the Alanguage of the Interpreter Set is selected, then
“FLOOR“ will be shown, preventing that the
interpreter hears himself. For testing purpose, the
corresponding a, b, c or d button can be pressed for
3 seconds the listening audio will then switch to the
interpreter himself and the quality indication change
to “SELF”. When releasing the button, the listening
audio will switch back to Floor and the quality
indication changes to “FLOOR” again.
If the A-language is not selected the quality
indication “SELF” is shown
All a-d selections show the actual quality of the
channels at all times.
Selection of Outgoing channel
The two push buttons A and B are used to select
whether the interpreter will be routed to the A- or
B-outgoing channel.
When A is pressed the red LED is lighted in the
button. When B is pressed the light in the A-button
will go out and the red LED in the B-button will
light up.
The A-lines will always show the language of the
one selected for the Interpreter Set. The upper line
at the left shows the channel number and the lower
line shows the languages in full name in accordance
to the language list supported (max. 10 char.).
When the system is initialised and set up then the
A-display will show the booth languages and A is
automatically selected. B-display will show the Blanguage selected at the B-language Set-up
When B is pressed the light LED in the button is lit.
It is now possible to change the selection of the Blanguage channel with the B-select push buttons up
and down if the B-mode is set to “All” in the Blanguage setup menu.
The B-selection will only function when B is
selected and the Microphone is not switched On.
Microphone on/off
When the push button is pressed the microphone
audio is put on to the outgoing channel; the LED’s
in the button and the lamp of the microphone are lit
up. If another interpreter already occupies the
outgoing channel nothing will happen.
When the push button again is pressed the sound
from the microphone, the button LED’s and
microphone lamp is switched off.
Mute
The button will switch off the audio from the
microphone to the outgoing channel while it is
depressed (the channel is muted). Also the light ring
in the microphone is switched off while depressed.
When the button is released the microphone audio
is switched on again and the light ring in the
microphone is switched on.
Danish Interpretation Systems User Manual
Manual 01 18 04445, Printed in Denmark, 02/2003 CHN
13
Speaking too fast)
When pushing this button the LED in the Speaking
too fast button lights in 10 sek. in all IS 6132 units.
And at the same time the Speaking too fast
indication will be indicated in units supporting this
function (as some CM6xxx units or PC with SW
6000 software)
Call
Not implemented.
A-Engaged
The yellow LED is lit if the channel is occupied
either by another interpreter or the interpreters set
itself occupies the channel.
B-Engaged
The yellow LED is lit if the channel is occupied
either by another interpreter or the interpreters set
itself occupies the channel.
Error indication
If errors occur in the communication with the CU it
will be indicated by the interpreters set. The set has
two error thresholds. The first threshold is reached
when audio-data from the CU contains too many
errors for the sound to be reproduced correctly. This
is indicated by a black matrix in the normal
operation display and by the communication display
when the set is un-initialised. The second threshold
is reached when the frame error rate reaches a
higher predefined value. When this happens the set
will enter the communication status display
regardless of the state the set was in before errors
occurred.
The error status is checked every 5 seconds and
when no errors has occurred since the last check the
set enters the operation mode it was in before errors
was detected.
Danish Interpretation Systems User Manual
Manual 01 18 04445, Printed in Denmark, 02/2003 CHN
14
System Setup
For generel guidelines etc. please consult the CU 6000 User Manual.
Typical schematics
Informationsteknik User Manual
Manual 01 18 04445, Printed in Denmark, 02/2003 CHN
15
Appendix
Language list
The following languages are supported by the DCS 6000 system:
Language ISO 639-2/B
abbreviation
Floor language FLO
Afrikaans AFR
Albanian ALB
Arabic ARA
Armenian ARM
Azerbaijani AZE
Basque BAQ
Belarusian BEL
Bengali BEN
Bulgarian BUL
Burmese BUR
Cantonese CAN
Catalan CAT
Chinese CHI
Corsican COR
Croatian SCR
Czech CZE
Danish DAN
Dutch DUT
English ENG
Estonian EST
Finnish FIN
French FRE
Gallegan GLG
Georgian GEO
German GER
Greek GRE
Hausa HAU
Hebrew HEB
Hindi HIN
Hungarian HUN
Language ISO 639-2/B
abbreviation
Icelandic ICE
Indonesian IND
Irish GLE
Italian ITA
Japanese JAP
Javanese JAV
Kazakh KAZ
Khmer KHA
Kirghiz KIR
Korean KOR
Kurdish KUR
Lao LAO
Latvian LAV
Lithuanian LIT
Macedonian MAC
Malay MAY
Maltese MAL
Marathi MAR
Mongolian MON
Nepali NEP
Norwegian NOR
Panjabi PAN
Persian PER
Polish POL
Portuguese POR
Raetoroman ROH
Romanian RUM
Russian RUS
Serbian SCC
Sinhalese SIN
Slovak SLO
Language ISO 639-2/B
abbreviation
Slovenian SLV
Spanish SPA
Swahili SWA
Swedish SWE
Tagalog TGL
Tajik TGK
Tamil TAM
Telugu TEL
Thai THA
Tibetan TIB
Turkish TUR
Turkmen TUK
Ukrainian UKR
Urdu URD
Uzbek UZB
Vietnamese VIE
Welsh WEL
Yoruba YOR
Other no 1 N 1
Other no 2 N 2
Other no 3 N 3
Other no 4 N 4
Other no 5 N 5
Other no 6 N 6
Other no 7 N 7
Other no 8 N 8
Other no 9 N 9
Other no 10 N10
Other no 11 N11
Other no 12 N12
IS 6132 User Manual
Manual 01 18 04445, Printed in Denmark, 02/2003 CHN
16
Technical appendix
Cabling
CAT5
The DCS 6000 system uses CAT5, CAT5e or
CAT6 FTP or STP cables with screened RJ45
connectors.
It is important to use only FTP or STP
(screened) cables and screened RJ45 connectors
and not UTP cable, which is unscreened.
EIA 568-B wiring shall be used. How to wire a
CAT5 (EIA 568-B) Cable:
Pin Function Connector #1 Connector #2
1 In-going + ORG/WHT ORG/WHT
2 In-going - ORG ORG
3 +48V GRN/WHT GRN/WHT
4 0V BLU BLU
5 0V BLU/WHT BLU/WHT
6 +48V GRN GRN
7 Outgoing - BRN/WHT BRN/WHT
8 Outgoing + BRN BRN
Note. If other colour codes are used then the four
pairs are connected as follows:
Pair 1: Pin 1 & 2
Pair 2: Pin 3 & 6
Pair 3: Pin 4 & 5
Pair 4: Pin 7 & 8
The phase of the pairs must be correct and the
wiring spec. as stated in CAT5 (EIA 568-B) have to
be followed.
Note: CAT6 cables can normally only be
terminated in sockets (female) and not in cable
plugs. CAT6 should thus only be used for long
cable draws terminating in wall outlets or patch
panels.
Loudspeaker
Pin
Connector D9S
1 POWER (+48VDC)
2 Not connected
3 +SIGNAL
4 Not connected
5 POWER GND
6 MUTE
7 Not connected
8 -SIGNAL
9 SIGNAL GROUND
Accessories (not supplied)
GM 4422 Gooseneck microphone ..........................18 12 05661
DH 9001 Headphone............................................... 14 11 03050
IH 6000 Headset ....................................................11 14 04951
LS 6032P Loudspeaker...........................................15 09 10381
Power adapter (for full light in display) .................S1 01 99870
EC 6000-..5 Connection Cable 0,5 m......................10 03 12500
EC 6000-01 Connection Cable 1 m......................... 10 03 13101
EC 6000-02 Connection Cable 2 m......................... 10 03 13201
EC 6000-05 Connection Cable 5 m......................... 10 03 13501
EC 6000-10 Connection Cable 10 m.......................10 03 14102
EC 6000-20 Connection Cable 20 m.......................10 03 14202
EC 6000-50 Connection Cable 50 m.......................10 03 14502
IS 6132 User Manual
Manual 01 18 04445, Printed in Denmark, 02/2003 CHN
17
Technical specifications
Digital Section
Sound quality .........20 bit audio @ 32 kHz sampling frequency
Number of incoming channels.............................32 (31 + floor)
Number of outgoing channels (interpreted)............................ 31
Analog Section
Microphone input type .......................DIS GM 4xxx series only
Headphone output level: ................................................... 1,5 V
Min. headphone impedance:............................. 4 ohm – 1 kohm
External loudspeaker output level (balanced): ..........max. 2,8 V
Min. loudspeaker amp. input impedance:.......................2 kohm
Frequency response.................................................... 50-15kHz
Signal to noise ratio: ...................................................>85 dBA
Total harmonic distortion: .............................................< 0.1%
General
Power requirement ..................................................24-48 V DC
Power consumption (excl. LS6032P)............... 2,5W maximum
Power supplied from CU 6000 / CU 6010 / EX 6010 / PS 6000
Temperature to guarantee specified performance
............................. 5 Deg C. to 40 Deg C. (10 to 80% humidity)
Storage temperature
..........................-20 Deg C. to 60 Deg C. (10 to 80% humidity)
Weight .............................................................................. 1,0 kg
Dimensions (W x H x D).............................235 x 73 x 115 mm
without knobs and microphone
Connectors
DCS LAN network ...............................................2 pieces RJ45
Microphone input.......................................XLR3 female socket
Headphone connectors .....................2 pieces mini jack 3.5 mm
............................................................. 1 piece standard jack ¼”
Headset connector............................................ 8 pin DIN socket
LS 6032P Loudspeaker Unit socket.....................................D9S
Standards
The IS 6132 conforms to all relevant standards.
Specifications are subject to change without notice.
IS 6132 User Manual
Manual 01 18 04445, Printed in Denmark, 02/2003 CHN
18
Loading...
