Danfoss Electronics TGE 10, TGE 20, TGE 40 Data Sheet

Data sheet

Thermostatic expansion valves

Type TGE 10, TGE 20 and TGE 40

TGE is a dedicated designed series of
thermostatic expansion valves for all standard
refrigerants.
The tight design meets the environmental
demands for today and future.
Versions for non standard refrigerants can be
produced to order.

Applications

• Water chillers

• Bus A/C

• Rooftop units

• Heat pumps

• Refrigerated containers

• Others A/C and refrigeration system

Features • Refrigerants: R410A, R32, R452B, R454B, R22,

R134a, R1234ze, R407F, R407A, R404A, R507,
R407C and R290

• Capacity range: 3.5 – 52 TR / 12 – 182 kW
for R410A

• Balance port design

• Biow with expansion in both directions

• Low hysteresis

• Long lifetime for heat pump applications

• Mechanical connections types solder ODF,
are, MIO, ORFS are available

• Laser welded, stainless steel power element,
capillary tube, and bulb

• MOP (Max. Operating Pressure) function is
available

• Optional bleed function

• PS / MWP (maximum working pressure):
46 bar/ 667 psig

• Straightway ow

• Adjustable superheat setting

• Cylindrical bulb and patented bulb strap
design

• Compliance with ATEX hazard zone 2

• UL certied

© Danfoss | DCS (az) | 2019.01

DKRCC.PD.AXV.3A.02 | 1

Data sheet | Thermostatic expansion valves, type TGE 10, TGE 20, TGE 40

Refrigerants: Refrigerants: R410A, R32, R452B, R454B, R22, R134a, R1234ze, R407F, R407A, R404A, R507, R407C and R290.

For other refrigerants, please contact Danfoss.
Note: this product is approved for R290 by ignition source assessment in accordance to standard EN13463–1.

Approvals

Technical data

Max. temperature on thermostatic element: MAH : 150 °C / 302 °F
K : 150 °C / 302 °F
N: 100 °C / 210 °F

Max. temperature on valve body: 110 °C / 230 °F
Max. working pressure: 46 bar / 667 psig.
Max. test pressure: 51 bar / 740 psig.

Standard evaporating temperature ranges

Charge Temperature range

MAH -30 – 15 °C / -22 – 60 °F

N -40 – 10 °C / -40 –50 °F without MOP

K –25 – 10 °C, MOP 15 °C / –15 – 50 °F, MOP 60 °F

Max. operating pressure

Refrigerant

Range K: –25 – 10 °C / –15 – 50 °F, MOP +15 °C / +60 °F

MOP point in evaporating pressure p

1

)

e

R410A 11.4 bar / 165 psig
R22 6.9 bar / 100 psig
R134a 3.8 bar / 55 psig
R407C 6.6 bar / 95 psig
R404A/ R507 8.3 bar / 120 psig

1

) MOP for R32, R452B, R454B, R1234ze, R407F, R407A and R290 please contact Danfoss for more info.

Connections

Type Inlet solder ODF

[inch]

3

5

TGE 10

TGE 20

TGE 40

/

5

/

7

/

8

8

8

, ½ ,

7

,

/

, 11/

8

/

, 11/

8

7

8,

8

/

8

Inlet solder ODF

[mm]
10, 12, 16, 22

16, 22, 28

22, 28

Outlet solder ODF

[inch]

5

7

,

8 ,

8

/

5

8 ,

/

7

8

/

8

/

11/

7

,

,

8

8

/

11/

13/

,

,

8

8

11/

13/

8

Outlet solder ODF

[mm]
16, 22, 28

16, 22, 28, 35

22, 28, 35

Capillary tube length

Type Capillary tube length
TGE 10 / TGE 20 1.5 m 59 inch
TGE 40 3 m 118 inch

Valve options In addition to the standard programme, variants of following options may be available:

• Refrigerants

• Evaporating temperature range

• MOP point

• Static superheat setting (0K – 8K / 0 – 14.4 °F)

• Mechanical connections

• Bleed function (15% or 30%)

Please contact your nearest Danfoss sales oce to discuss valve options.

© Danfoss | DCS (az) | 2019.01

DKRCC.PD.AXV.3A.02 | 2

Data sheet | Thermostatic expansion valves, type TGE 10, TGE 20, TGE 40

Design and function

1. Bulb with capillary tube

2. Thermostatic element

3. Thrust pad

4. Push pin seal

5. Cone

6. Valve body

7. Static SH adjustment spindle

8. Protective cap

1

2
3

4

5

6

7

8

Fig. 1
Balanced port design
TGE 10

Danfoss
67N47.10

1

2
3

4

5

6

7

8

Fig. 2
Double balanced port design
TGE 20 and TGE 40

Balanced port design and advantage

The TGE series of thermostatic expansion valves have balanced port design.
Balanced port design prevents changes in pressure drop across the valve from inuencing operation
and provides excellent control on applications having widely varying operating conditions.
Balanced port TXV’s are recommended in refrigeration and air conditioning systems with any combi­nations of these conditions:

1) Widely varying head pressures

2) Widely varying evaporator loads

3) Widely varying pressure drop across the TXV

4) Fluctuating or extremely low liquid temperatures

5) Intermittent liquid line ash gas

TGE valves are designed for biow operations. TGE 10 has minor capacity reduction in reverse ow.

The central push pin is tted with a robust seal
(Pos 4) that ensures maximum tightness for the
life of the valve.
Static superheat (SS) can be adjusted by the
setting spindle (Pos 6), see g. 1.
The standard superheat setting (SS) is 4K / 7.2 °F
and adjustable for 0 – 8K / 0 – 14.4 °F.

SS = Static Superheat
OS = Opening Superheat
SH = SS + OS = total superheat

Example:

Static superheat SS = 4K / 7.2 °F
Opening superheat OS = 4K / 7.2 °F
The opening superheat is 4K / 7.2 °F, i.e. from
the point the valve begins to open up to rated
capacity. Opening superheat is determined by
the design and cannot be changed.
Total superheat SH = SS + OS
SH = 4 + 4 = 8K / 14.4 °F
Total superheat SH can be altered by changing SS
(by using the setting spindle).

Fig. 3

© Danfoss | DCS (az) | 2019.01

DKRCC.PD.AXV.3A.02 | 3

67N27.11

Data sheet | Thermostatic expansion valves, type TGE 10, TGE 20, TGE 40

Application

TGE

EVR

Fig. 4
Traditional refrigeration plant

Fig. 4 A diagram of a traditional refrigeration plant where TGE is used for ow in one direction only.

SGI/SGN

Outdoor coil

DCL/DML

Fig. 5

Indoor coil

TGE

NRV

SGI/SGN

STF

DCB/DMB

Outdoor coil

TGE

NRV

Danfoss

67N13.12

Conventional system with summer/winter operation

Fig. 5 A conventional split heat pump system shown in cooling mode. This system has two
TGE thermostatic expansion valves with xed direction ow. An NRV check valve is placed in series
with each TGE to allow liquid refrigerant to bypass when ow is opposite the TXV xed direction.

Outdoor coil

Indoor coil

STF

Danfoss

© Danfoss | DCS (az) | 2019.01

DML/DCL

Fig. 6

TGE

Simplied heat pump system

Fig. 6 A heat pump system similar to that in g. 5 but with a more compact design, where the distance
between evaporator and condenser is very short. This system has only one bi–ow TGE valve metering
liquid refrigerant eectively in both directions. Changeover is by means of a 4–way valve.
A suction lter drier is often placed in suction lines just before the compressor. The normal ow
direction of TGE is determined by the primary function, i.e. cooling or heating.

DKRCC.PD.AXV.3A.02 | 4

67N11.18

Data sheet | Thermostatic expansion valves, type TGE 10, TGE 20, TGE 40

Identication

The valve is tted with a product label
(on top of the diaphragm) which holds
information as follows:

TGE = Valve type
9 TR = Rated capacity Q in TR
32 kW = Rated capacity Q in kW
R410A = Refrigerant
–25 – 10 °C / –15 – 50 °F
= Evaporating temperature range
067N3006 = Code number
MOP 165 = Max. operating pressure 165 psig
PS 46 bar / MWP 667 psig
= Max. working pressure in bar and psig

BE3216C: BE = China
32 = week
16 = 2016
C = wednesday

MADE IN CHINA

TGE

9 TR
32 kW
R410A

-25/+10°C / -15/+50 °F

067N3006 MOP 165 / +15 °C

PS 46 bar / MWP 667 psig

BE3216C

REFRIGERANT VALVE 53R0

Danfoss

Rated capacity

Valve type Orice

TGE 10

TGE 20

TGE 40

2

) The rated capacity is based on:

2

)

no.

12.5 50 14 74 21 50 14 60 17 43 12 29 8 22 6 43 12 39 11 31 9 39 11 44 12

12.5 54 15 81 23 55 15 67 19 43 12 29 8 22 6 46 13 39 11 31 9 42 12 44 12

213) 91 26 135 38 98 28 116 33 75 21 51 15 39 11 82 23 72 21 53 15 77 22 75 21

R410A R32 R452B 4) R454B 4) R22 R134a R1234ze R407F R407A

KW TR KW TR KW TR KW TR KW TR KW TR KW TR KW TR KW TR KW TR KW TR KW TR

3 12 3.5 18 5 12 3.5 14 4 10 3 6 1.5 5 1.5 10 3 9 2.5 7 2 9 2.5 10 3

4 16 4.5 24 7 16 4.5 19 5.5 14 4 8 2.5 7 2 14 4 12 3.5 9 2.5 13 3.5 14 4

6 24 6.5 35 10 24 6.5 28 8 20 6 12 3.5 10 3 20 6 17 5 14 4 19 5 19 5

8 32 9 47 13 32 9 39 11 27 7.5 17 4.5 14 4 27 7.5 23 6.5 18 5 25 7 25 7

9 37 11 54 15 38 11 46 13 32 9 20 5.5 16 4.5 32 9 28 8 21 6 30 8.5 32 9

11 45 13 68 19 46 13 56 16 38 11 24 7 20 5.5 40 11 34 10 26 7.5 36 10 36 10

16 60 17 87 25 60 17 70 20 50 14 35 9.5 27 7.5 50 14 46 13 35 10 49 14 50 14

16 68 19 102 29 68 19 81 23 54 15 37 10 27 7.5 57 16 50 14 39 11 53 15 54 15

20 79 23 120 34 81 23 98 28 63 18 44 12 31 8.5 67 19 59 17 45 13 62 18 63 18

26 110 31 165 47 117 33 133 38 92 26 61 17 49 14 95 27 80 23 64 18 84 24 92 26

30 125 35 187 53 134 38 151 43 104 30 70 20 57 16 108 31 91 26 72 21 95 27 106 30

40 161 46 236 67 172 49 193 55 134 38 87 25 72 20 138 39 116 33 92 26 121 34 133 38

42 182 52 273 78 208 59 229 65 148 42 102 29 81 23 165 47 140 40 105 30 148 42 152 43

Evaporating temperature te : 4.4 °C / 40 °F
Condensing temperature tc : 38 °C / 100 °F
Refrigerant temperature ahead of valve tl : 37 °C / 98 °F

3

) Contact Danfoss for more information

4

) New sales code numbers are on request.

Range N, K, MAH

R404A /

R507

R407C R290

© Danfoss | DCS (az) | 2019.01

TGE 10 TGE 20 TGE 40

DKRCC.PD.AXV.3A.02 | 5

Data sheet | Thermostatic expansion valves, type TGE 10, TGE 20, TGE 40

Ordering

Only solder versions, connection size 28 mm / 1 1⁄8 in. or below are approved for ammable
refrigerants.

Range N -40 – 10 °C / -40 –50 °F, OS = 4 K / 7.2 °F

Valve type Orice

no.

TGE 10 3 12 3.5 18 5
TGE 10 3 12 3.5 18 5
TGE 10 4 16 4.5 24 7
TGE 10 6 24 6.5 35 10
TGE 10 6 24 6.5 35 10
TGE 10 6 24 6.5 35 10
TGE 10 8 32 9 47 13
TGE 10 8 32 9 47 13
TGE 10 9 37 11 54 15
TGE 10 11 45 13 68 19
TGE 10 12.5 50 14 74 21
TGE 20 12.5 54 15 81 23
TGE 40 26 110 31 165 47 1 1⁄8 x 1 1⁄8

The rated capacity is based on:
Evaporating temperature te : 4.4 °C / 40 °F
Condensing temperature tc : 38 °C / 100 °F
Refrigerant temperature ahead of valve tl : 37 °C / 98 °F

Rated capacity

R410A

Rated capacity

R32

[KW] [TR] [KW] [TR]

Connections solder ODF Code no.

Inlet x Outlet

[inch]

3

⁄8 x 5⁄8

1

⁄2 x 5⁄8

1

⁄2 x 7⁄8

1

⁄2 x 5⁄8

1

⁄2 x 7⁄8

5

⁄8 x 7⁄8

1

⁄2 x 5⁄8

5

⁄8 x 7⁄8

5

⁄8 x 7⁄8

5

⁄8 x 7⁄8

5

⁄8 x 7⁄8

5

⁄8 x 7⁄8

Pressure

equalization

[inch]

R410A/R32

1

⁄4 067N3150

1

⁄4 067N3151

1

⁄4 067N3152

1

⁄4 067N3153

1

⁄4 067N3154

1

⁄4 067N3155

1

⁄4 067N3293

1

⁄4 067N3156

1

⁄4 067N3296

1

⁄4 067N3157

1

⁄4 067N3410

1

⁄4 067N3159

1

⁄4 067N3234

Multi pack

Range N -40 – 10 °C / -40 –50 °F, OS = 4 K / 7.2 °F

Valve type Orice

no.

TGE 10 11 45 13
TGE 10 16 60 17
TGE 20 12.5 54 15
TGE 20 12.5 54 15
TGE 20 12.5 54 15
TGE 20 16 68 19
TGE 20 16 68 19
TGE 20 20 79 23
TGE 20 20 79 23
TGE 40 26 110 31
TGE 40 26 110 31 1 1⁄8 x 1 3⁄8
TGE 40 30 125 35 1 1⁄8 x 1 3⁄8
TGE 40 40 161 46 1 1⁄8 x 1 3⁄8
TGE 40 42 182 52 1 1⁄8 x 1 3⁄8

The rated capacity is based on:
Evaporating temperature te : 4.4 °C / 40 °F
Condensing temperature tc : 38 °C / 100 °F
Refrigerant temperature ahead of valve tl : 37 °C / 98 °F

Rated capacity Connections solder ODF Code no.

Inlet x Outlet

[KW] [TR]

[inch]

5

⁄8 x 1 1⁄8

7

⁄8 x 1 1⁄8

5

⁄8 x 1 1⁄8

7

⁄8 x 7⁄8

7

⁄8 x 1 1⁄8

5

⁄8 x 1 1⁄8

7

⁄8 x 1 1⁄8

7

⁄8 x 1 1⁄8

7

⁄8 x 1 3⁄8

7

⁄8 x 1 3⁄8

Pressure

equalization

[inch]

1

⁄4 067N3158

1

⁄4 067N3411

1

⁄4 067N3160

1

⁄4 067N3231

1

⁄4 067N3232

1

⁄4 067N3161

1

⁄4 067N3162

1

⁄4 067N3163

1

⁄4 067N3164

1

⁄4 067N3165

1

⁄4 067N3166

1

⁄4 067N3168

1

⁄4 067N3169

1

⁄4 067N3400

R410A

Multi pack

© Danfoss | DCS (az) | 2019.01

DKRCC.PD.AXV.3A.02 | 6

Data sheet | Thermostatic expansion valves, type TGE 10, TGE 20, TGE 40

Ordering

Range K -25 – 10 °C /-15 – 50 °F with MOP 15 °C / 60 °F, OS = 4 K / 7.2 °F

Valve type Orice

no.

TGE 10 3 12 3.5

TGE 10 3 12 3.5
TGE 10 4 16 4.5
TGE 10 6 24 6.5
TGE 10 6 24 6.5
TGE 10 8 32 9.0
TGE 10 9 37 11
TGE 10 11 45 13
TGE 10 11 45 13
TGE 10 12.5 50 14
TGE 10 16 60 17
TGE 20 12.5 54 15
TGE 20 12.5 54 15
TGE 20 16 68 19
TGE 20 16 68 19
TGE 20 20 79 23
TGE 40 26 110 31
TGE 40 26 110 31
TGE 40 30 125 35 1 1⁄8 x 1 3⁄8
TGE 40 40 161 46 1 1⁄8 x 1 3⁄8
TGE 40 42 182 52 1 1⁄8 x 1 3⁄8

The rated capacity is based on:
Evaporating temperature te : 4.4 °C / 40 °F
Condensing temperature tc : 38 °C / 100 °F
Refrigerant temperature ahead of valve tl : 37 °C / 98 °F

Rated capacity Connections solder ODF Code no.

Inlet x Outlet

[KW] [TR]

[inch]

3

⁄8 x 5⁄8

1

⁄2 x 5⁄8

1

⁄2 x 7⁄8

1

⁄2 x 5⁄8

5

⁄8 x 7⁄8

5

⁄8 x 7⁄8

5

⁄8 x 7⁄8

5

⁄8 x 7⁄8

5

⁄8 x 1 1⁄8

5

⁄8 x 1 1⁄8

5

⁄8 x 1 1⁄8

5

⁄8 x 7⁄8

5

⁄8 x 1 1⁄8

5

⁄8 x 1 1⁄8

7

⁄8 x 1 1⁄8

7

⁄8 x 1 1⁄8

7

⁄8 x 1 1⁄8

7

⁄8 x 1 3⁄8

Pressure

equalization

[inch]

1

⁄4 067N3000

1

⁄4 067N3001

1

⁄4 067N3002

1

⁄4 067N3003

1

⁄4 067N3005

1

⁄4 067N3006

1

⁄4 067N3340

1

⁄4 067N3007

1

⁄4 067N3008

1

⁄4 067N3402

1

⁄4 067N3401

1

⁄4 067N3009

1

⁄4 067N3010

1

⁄4 067N3011

1

⁄4 067N3012

1

⁄4 067N3013

1

⁄4 067N3135

1

⁄4 067N3015

1

⁄4 067N3018

1

⁄4 067N3019

1

⁄4 067N3341

R410A

Multi pack

Range MAH -30 – 15 °C / -22 – 60 °F with anti hunting charge, OS = 4 K / 7.2 °F

Valve type Orice

no.

TGE 10 3 12 3.5
TGE 10 4 16 4.5
TGE 10 6 24 6.5
TGE 10 6 24 6.5
TGE 10 8 32 9
TGE 10 9 37 11
TGE 10 11 45 13
TGE 10 12.5 50 14
TGE 10 16 60 17
TGE 20 12.5 54 15
TGE 20 12.5 54 15
TGE 20 16 68 19
TGE 20 20 79 23
TGE 40 26 110 31
TGE 40 26 110 31 1 1⁄8 x 1 3⁄8
TGE 40 30 125 35 1 1⁄8 x 1 3⁄8
TGE 40 40 161 46 1 1⁄8 x 1 3⁄8
TGE 40 42 182 52 1 1⁄8 x 1 3⁄8

The rated capacity is based on:
Evaporating temperature te : 4.4 °C / 40 °F
Condensing temperature tc : 38 °C / 100 °F
Refrigerant temperature ahead of valve tl : 37 °C / 98 °F

Rated capacity Connections solder ODF Code no.

[KW] [TR]

Inlet x Outlet

[inch]

Pressure

equalization

[inch]

1

⁄2 x 5⁄8

1

⁄2 x 7⁄8

1

⁄2 x 5⁄8

5

⁄8 x 7⁄8

5

⁄8 x 7⁄8

5

⁄8 x 7⁄8

5

⁄8 x 7⁄8

5

⁄8 x 7⁄8

7

⁄8 x 1 1⁄8

5

⁄8 x 7⁄8

5

⁄8 x 1 1⁄8

7

⁄8 x 1 1⁄8

7

⁄8 x 1 1⁄8

7

⁄8 x 1 3⁄8

1

⁄4 067N9201

1

⁄4 067N9202

1

⁄4 067N9203

1

⁄4 067N9200

1

⁄4 067N9206

1

⁄4 067N9287

1

⁄4 067N9207

1

⁄4 067N9509

1

⁄4 067N9512

1

⁄4 067N9209

1

⁄4 067N9210

1

⁄4 067N9212

1

⁄4 067N9213

1

⁄4 067N9215

1

⁄4 067N9216

1

⁄4 067N9218

1

⁄4 067N9219

1

⁄4 067N9289

R410A

Multi pack

© Danfoss | DCS (az) | 2019.01

DKRCC.PD.AXV.3A.02 | 7

Data sheet | Thermostatic expansion valves, type TGE 10, TGE 20, TGE 40

Ordering

Range N -40 – 10 °C / -40 –50 °F, OS = 4 K / 7.2 °F

Valve type Orice

no.

TGE 10 3 10 3
TGE 10 3 10 3
TGE 10 4 14 4
TGE 10 6 20 6
TGE 10 6 20 6

Rated capacity Connections solder ODF

Inlet x Outlet

[KW] [TR]

[inch] [mm] [inch] [mm]

3

⁄8 x 5⁄8 –

1

⁄2 x 5⁄8 –

1

⁄2 x 7⁄8 –

1

⁄2 x 5⁄8 –

1

⁄2 x 7⁄8 –

Pressure equalization Code no.

1

⁄4 – 067N2150

1

⁄4 – 067N2151

1

⁄4 – 067N2152

1

⁄4 – 067N2153

1

⁄4 – 067N2154

R22/R407C 1)

Multi pack

TGE 10 6 20 6 – 12 × 22 – 6 067N2194
TGE 10 6 20 6 – 16 × 16 – 6 067N2263
TGE 10 6 20 6
TGE 10 8 27 7.5

5

⁄8 x 7⁄8 –

5

⁄8 x 7⁄8 –

1

⁄4 – 067N2155

1

⁄4 – 067N2156

TGE 10 8 27 7.5 – 16 × 22 – 6 067N2196
TGE 10 9 32 9

5

⁄8 x 7⁄8 –

1

⁄4 – 067N2460

TGE 10 9 32 9 – 16 x 22 – 6 067N2281
TGE 10 11 38 11

5

⁄8 x 7⁄8 –

1

⁄4 – 067N2157

TGE 10 11 38 11 – 16 × 22 – 6 067N2197
TGE 10 11 38 11

5

⁄8 x 1 1⁄8 –

1

⁄4 – 067N2158

TGE 10 11 38 11 – 16 × 28 – 6 067N2198
TGE 10 12.5 43 12
TGE 10 16 50 14
TGE 10 16 50 14
TGE 20 12.5 43 12
TGE 20 12.5 43 12

5

⁄8 x 7⁄8 –

5

⁄8 x 1 1⁄8 –

7

⁄8 x 1 1⁄8 –

5

⁄8 x 7⁄8 –

5

⁄8 x 1 1⁄8 –

1

⁄4 – 067N2720

1

⁄4 – 067N2721

1

⁄4 – 067N2722

1

⁄4 – 067N2159

1

⁄4 – 067N2160

TGE 20 12.5 43 12 – 16 × 28 – 6 067N2200
TGE 20 16 54 15
TGE 20 16 54 15
TGE 20 16 54 15
TGE 20 20 63 18
TGE 20 20 63 18
TGE 40 26 92 26
TGE 40 26 92 26
TGE 40 30 104 30

5

⁄8 x 7⁄8 –

5

⁄8 x 1 1⁄8 –

7

⁄8 x 1 1⁄8 –

7

⁄8 x 1 1⁄8 –

7

⁄8 x 1 3⁄8 –

7

⁄8 x 1 1⁄8 –

7

⁄8 x 1 3⁄8 –

7

⁄8 x 1 3⁄8 –

TGE 40 30 104 30 1 1⁄8 x 1 3⁄8 –
TGE 40 40 134 38 1 1⁄8 x 1 3⁄8 –

TGE 40 42 148 42 1 1⁄8 x 1 3⁄8 –

1

⁄4 – 067N2255

1

⁄4 – 067N2161

1

⁄4 – 067N2162

1

⁄4 – 067N2163

1

⁄4 – 067N2164

1

⁄4 – 067N2251

1

⁄4 – 067N2165

1

⁄4 – 067N2167

1

⁄4 – 067N2168

1

⁄4 – 067N2169

1

⁄4 – 067N2283

The rated capacity is based on:
Evaporating temperature te : 4.4 °C / 40 °F
Condensing temperature tc : 38 °C / 100 °F
Refrigerant temperature ahead of valve tl : 37 °C / 98 °F

1

) For R407C plants, please select valves from the dedicated R407C program.

© Danfoss | DCS (az) | 2019.01

DKRCC.PD.AXV.3A.02 | 8

Data sheet | Thermostatic expansion valves, type TGE 10, TGE 20, TGE 40

Ordering

Range K –25 – 10 °C / –15 – 50 °F with MOP 15 °C / 60 °F,
OS = 4 K / 7.2 °F

Valve type Orice

no.

TGE 10 3 10 3
TGE 10 3 10 3
TGE 10 4 14 4
TGE 10 6 20 6
TGE 10 6 20 6
TGE 10 8 27 7.5
TGE 10 9 32 9
TGE 10 11 38 11
TGE 10 11 38 11
TGE 10 12.5 43 12
TGE 10 16 50 14
TGE 20 12.5 43 12
TGE 20 12.5 43 12
TGE 20 16 54 15
TGE 20 16 54 15
TGE 20 20 63 18
TGE 20 20 63 18
TGE 40 26 92 26
TGE 40 26 92 26 1 1⁄8 x 1 3⁄8
TGE 40 30 104 30
TGE 40 30 104 30 1 1⁄8 x 1 3⁄8
TGE 40 40 134 38 1 1⁄8 x 1 3⁄8

The rated capacity is based on:
Evaporating temperature te : 4.4 °C / 40 °F
Condensing temperature tc : 38 °C / 100 °F
Refrigerant temperature ahead of valve tl : 37 °C / 98 °F

1

) For R407C plants, please select valves from the dedicated R407C program.

Rated capacity Connections solder ODF Code no.

Inlet x Outlet

[KW] [TR]

[inch]

3

⁄8 x 5⁄8

1

⁄2 x 5⁄8

1

⁄2 x 7⁄8

1

⁄2 x 5⁄8

5

⁄8 x 7⁄8

5

⁄8 x 7⁄8

5

⁄8 x 7⁄8

5

⁄8 x 7⁄8

5

⁄8 x 1 1⁄8

5

⁄8 x 7⁄8

7

⁄8 x 1 1⁄8

5

⁄8 x 7⁄8

5

⁄8 x 1 1⁄8

5

⁄8 x 1 1⁄8

7

⁄8 x 1 1⁄8

7

⁄8 x 1 1⁄8

7

⁄8 x 1 3⁄8

7

⁄8 x 1 3⁄8

7

⁄8 x 1 3⁄8

R22/R407C 1)

Pressure

equalization

[inch]

1

⁄4 067N2000

1

⁄4 067N2001

1

⁄4 067N2002

1

⁄4 067N2003

1

⁄4 067N2005

1

⁄4 067N2006

1

⁄4 067N2415

1

⁄4 067N2007

1

⁄4 067N2008

1

⁄4 067N2700

1

⁄4 067N2701

1

⁄4 067N2009

1

⁄4 067N2010

1

⁄4 067N2011

1

⁄4 067N2012

1

⁄4 067N2013

1

⁄4 067N2014

1

⁄4 067N2015

1

⁄4 067N2016

1

⁄4 067N2017

1

⁄4 067N2018

1

⁄4 067N2019

Multi pack

Range MAH -30 – 15 °C / -22 – 60 °F with anti hunting charge,
OS = 4 K / 7.2 °F

Valve type Orice

no.

TGE 10 6 20 6
TGE 10 8 27 7.5
TGE 10 11 38 11
TGE 20 12.5 43 12
TGE 20 16 54 15
TGE 20 20 63 18
TGE 40 26 92 26
TGE 40 30 104 30 1 1⁄8 x 1 3⁄8
TGE 40 40 134 38 1 1⁄8 x 1 3⁄8

The rated capacity is based on:
Evaporating temperature te : 4.4 °C / 40 °F
Condensing temperature tc : 38 °C / 100 °F
Refrigerant temperature ahead of valve tl : 37 °C / 98 °F

1

) For R407C plants, please select valves from the dedicated R407C program.

Rated capacity Connections solder ODF Code no.

Inlet x Outlet

[KW] [TR]

[inch]

1

⁄2 x 7⁄8

5

⁄8 x 7⁄8

5

⁄8 x 7⁄8

5

⁄8 x 7⁄8

7

⁄8 x 1 1⁄8

7

⁄8 x 1 3⁄8

7

⁄8 x 1 3⁄8

R22/R407C 1)

Pressure

equalization

[inch]

1

⁄4 067N9404

1

⁄4 067N9406

1

⁄4 067N9407

1

⁄4 067N9409

1

⁄4 067N9412

1

⁄4 067N9413

1

⁄4 067N9415

1

⁄4 067N9418

1

⁄4 067N9419

Multi pack

© Danfoss | DCS (az) | 2019.01

DKRCC.PD.AXV.3A.02 | 9

Data sheet | Thermostatic expansion valves, type TGE 10, TGE 20, TGE 40

Ordering

Range N -40 – 10 °C / -40 –50 °F, OS = 4 K / 7.2 °F

Valve type Orice

TGE 10 3 6 1.5

Rated capacity Connections solder ODF Code no.

no.

[KW] [TR]

Inlet x Outlet Pressure equalization

[inch] [mm] [inch] [mm]

3

⁄8 x 5⁄8 –

1

⁄4 – 067N5150

R134a

Multi pack

TGE 10 3 6 1.5 – 12 × 16 – 6 067N5191
TGE 10 4 8 2.5

1

⁄2 x 7⁄8 –

1

⁄4 – 067N5152

TGE 10 4 8 2.5 – 12 × 22 – 6 067N5192
TGE 10 6 12 3.5
TGE 10 6 12 3.5

1

⁄2 x 5⁄8 –

1

⁄2 x 7⁄8 –

1

⁄4 – 067N5153

1

⁄4 – 067N5154

TGE 10 6 12 3.5 – 16 × 22 – 6 067N5195
TGE 10 8 17 4.5

5

⁄8 x 7⁄8 –

1

⁄4 – 067N5156

TGE 10 8 17 4.5 – 16 × 22 – 6 067N5196
TGE 10 9 20 5.5
TGE 10 11 24 7
TGE 10 12.5 29 8
TGE 10 16 35 9.5
TGE 20 12.5 29 8
TGE 20 16 37 10
TGE 20 16 37 10
TGE 20 20 44 12
TGE 40 26 61 17

5

⁄8 x 7⁄8 –

5

⁄8 x 7⁄8 –

5

⁄8 x 7⁄8 –

7

⁄8 x 1 1⁄8 –

5

⁄8 x 7⁄8 –

5

⁄8 x 1 1⁄8 –

7

⁄8 x 1 1⁄8 –

7

⁄8 x 1 1⁄8 –

7

⁄8 x 1 3⁄8 –

TGE 40 26 61 17 1 1⁄8 x 1 3⁄8 –
TGE 40 30 70 20

7

⁄8 x 1 3⁄8 –

TGE 40 30 70 20 1 1⁄8 x 1 3⁄8 –
TGE 40 40 87 25 1 1⁄8 x 1 3⁄8 –

1

⁄4 – 067N5260

1

⁄4 – 067N5157

1

⁄4 – 067N5720

1

⁄4 – 067N5721

1

⁄4 – 067N5159

1

⁄4 – 067N5161

1

⁄4 – 067N5162

1

⁄4 – 067N5163

1

⁄4 – 067N5165

1

⁄4 – 067N5166

1

⁄4 – 067N5167

1

⁄4 – 067N5168

1

⁄4 – 067N5169

The rated capacity is based on:
Evaporating temperature te : 4.4 °C / 40 °F
Condensing temperature tc : 38 °C / 100 °F
Refrigerant temperature ahead of valve tl : 37 °C / 98 °F

Range N -40 – 10 °C / -40 –50 °F, OS = 4 K / 7.2 °F

Valve type Orice

TGE 10 3 6 1.5 –
TGE 10 4 8 2.5 –
TGE 10 4 8 2.5
TGE 10 6 12 3.5 –
TGE 10 6 12 3.5
TGE 10 6 12 3.5 –
TGE 10 6 12 3.5
TGE 10 6 12 3.5 –
TGE 10 8 17 4.5 –
TGE 10 8 17 4.5 –
TGE 10 8 17 4.5
TGE 10 8 17 4.5 –
TGE 10 8 17 4.5 –
TGE 10 9 20 5.5 –
TGE 10 11 24 7 –
TGE 10 12.5 29 8 –
TGE 10 16 35 9.5 –
TGE 10 16 35 9.5
TGE 20 12.5 29 8 –
TGE 20 16 37 10 –
TGE 20 16 37 10
TGE 20 20 44 12 –

The rated capacity is based on:
Evaporating temperature te : 4.4 °C / 40 °F
Condensing temperature tc : 38 °C / 100 °F
Refrigerant temperature ahead of valve tl : 37 °C / 98 °F

Rated capacity Connections are / MIO Code no.

no.

Inlet x Outlet

[KW] [TR]

Flare MIO Flare MIO

3

⁄8 x 1⁄2 –

1

⁄2 x 5⁄8 –

3

⁄8 x 1⁄2 –

1

⁄2 × 5⁄8 –

5

⁄8 x 3⁄4 –

5

⁄8 x 3⁄4 –

[inch]

Pressure equalization

1

⁄2 x 5⁄8 –

3

⁄8 x 1⁄2

1

⁄2 x 5⁄8 –

3

⁄8 x 1⁄2

3

⁄8 x 1⁄2 –

3

⁄8 × 1⁄2 –

1

⁄2 × 5⁄8 –

3

⁄8 x 1⁄2

5

⁄8 x 3⁄4 –

5

⁄8 x 3⁄4 –

5

⁄8 x 3⁄4 –

5

⁄8 x 3⁄4 –

5

⁄8 x 3⁄4 –

5

⁄8 x 3⁄4 –

5

⁄8 x 3⁄4 –

5

⁄8 x 3⁄4 –

R134a

Multi pack

[inch]

1

1

⁄4 – 067N7153

1

⁄4 – 067N7154

1

⁄4 – 067N7157

1

⁄4 – 067N7158

1

⁄4 – 067N7160

1

⁄4 – 067N7163

1

⁄4 – 067N7164

1

⁄4 – 067N7203

1

⁄4 – 067N7168

⁄4 067N7150

1

⁄4 067N7171

1

⁄4 067N7177

1

⁄4 067N7176

1

⁄4 067N7161

1

⁄4 067N7165

1

⁄4 067N7181

1

⁄4 067N7166

1

⁄4 067N7200

1

⁄4 067N7201

1

⁄4 067N7167

1

⁄4 067N7169

1

⁄4 067N7174

© Danfoss | DCS (az) | 2019.01

DKRCC.PD.AXV.3A.02 | 10

Data sheet | Thermostatic expansion valves, type TGE 10, TGE 20, TGE 40

Ordering

Range K -25 – 10 °C /-15 – 50 °F with MOP 15 °C / 60 °F, OS = 4 K / 7.2 °F

Valve type Orice

no.

TGE 10 3 6 1.5
TGE 10 4 8 2.5
TGE 10 6 12 3.5

Rated capacity Connections solder ODF Code no.

[KW] [TR]

Inlet x Outlet Pressure equalization

[inch] [mm] [inch] [mm]

3

⁄8 x 5⁄8 –

1

⁄2 x 7⁄8 –

1

⁄2 x 5⁄8 –

1

⁄4 – 067N5000

1

⁄4 – 067N5002

1

⁄4 – 067N5003

R134a

Multi pack

TGE 10 6 12 3.5 – 12 × 16 – 6 067N5043
TGE 10 6 12 3.5
TGE 10 8 17 4.5
TGE 10 11 24 7

5

⁄8 x 7⁄8 –

5

⁄8 x 7⁄8 –

5

⁄8 x 7⁄8 –

1

⁄4 – 067N5005

1

⁄4 – 067N5006

1

⁄4 – 067N5007

TGE 10 11 24 7 – 16 × 22 – 6 067N5047
TGE 10 11 24 7
TGE 10 12.5 29 8
TGE 20 12.5 29 8
TGE 20 16 37 10
TGE 20 20 44 12
TGE 40 26 61 17

5

⁄8 x 1 1⁄8 –

5

⁄8 x 7⁄8 –

5

⁄8 x 7⁄8 –

5

⁄8 x 1 1⁄8 –

7

⁄8 x 1 1⁄8 –

7

⁄8 x 1 3⁄8 –

TGE 40 30 70 20 1 1⁄8 x 1 3⁄8 –
TGE 40 40 87 25 1 1⁄8 x 1 3⁄8 –

1

⁄4 – 067N5008

1

⁄4 – 067N5700

1

⁄4 – 067N5009

1

⁄4 – 067N5011

1

⁄4 – 067N5013

1

⁄4 – 067N5015

1

⁄4 – 067N5018

1

⁄4 – 067N5019

The rated capacity is based on:
Evaporating temperature te : 4.4 °C / 40 °F
Condensing temperature tc : 38 °C / 100 °F
Refrigerant temperature ahead of valve tl : 37 °C / 98 °F

Range K –25 – 10 °C / –15 – 50 °F with MOP 15 °C / 60°F, OS = 4 K / 7.2 °F

Valve type Orice

no.

TGE 10 4 8 2.5 –
TGE 10 6 12 3.5
TGE 10 6 12 3.5
TGE 10 8 17 4.5 –
TGE 10 8 17 4.5
TGE 10 8 17 4.5 –
TGE 10 8 17 4.5
TGE 10 9 20 5.5 –
TGE 10 11 24 7 –
TGE 10 11 24 7
TGE 10 12.5 29 8 –
TGE 10 12.5 29 8
TGE 10 16 35 9.5 –
TGE 20 12.5 29 8 –
TGE 20 12.5 29 8
TGE 20 16 37 10 –
TGE 20 16 37 10
TGE 20 20 44 12

The rated capacity is based on:
Evaporating temperature te : 4.4 °C / 40 °F
Condensing temperature tc : 38 °C / 100 °F
Refrigerant temperature ahead of valve tl : 37 °C / 98 °F

Rated capacity Connections are / MIO Code no.

[KW] [TR]

Inlet x Outlet

[inch]

Pressure equalization

Flare MIO Flare MIO

1

3

⁄8 x 1⁄2 –

1

⁄2 x 5⁄8 –

1

⁄2 x 5⁄8 –

5

⁄8 x 3⁄4 –

5

⁄8 x 3⁄4 –

5

⁄8 x 3⁄4 –

5

⁄8 x 3⁄4 –

5

⁄8 x 3⁄4 –

5

⁄8 x 3⁄4 –

⁄2 × 5⁄8 –

1

⁄2 × 5⁄8 –

5

⁄8 x 3⁄4 –

5

⁄8 x 3⁄4 –

5

⁄8 x 3⁄4 –

5

⁄8 x 3⁄4 –

5

⁄8 x 3⁄4 –

5

⁄8 x 3⁄4 –

5

⁄8 x 3⁄4 –

1

⁄4 – 067N7003

1

⁄4 – 067N7004

1

⁄4 – 067N7008

1

⁄4 – 067N7013

1

⁄4 – 067N7016

1

⁄4 – 067N7212

1

⁄4 – 067N7018

1

⁄4 – 067N7020

1

⁄4 – 067N7021

[inch]

1

⁄4 067N7002

1

⁄4 067N7010

1

⁄4 067N7012

1

⁄4 067N7046

1

⁄4 067N7015

1

⁄4 067N7210

1

⁄4 067N7211

1

⁄4 067N7017

1

⁄4 067N7019

R134a

Multi pack

© Danfoss | DCS (az) | 2019.01

DKRCC.PD.AXV.3A.02 | 11

Data sheet | Thermostatic expansion valves, type TGE 10, TGE 20, TGE 40

Ordering

Only solder versions, connection size 28 mm / 1 1⁄8 in. or below are approved for ammable
refrigerants.

Range –30 – 10 °C/ –22 – 50 °F,OS = 4 K/7.2 °F

Valve type Orice

no.

TGE 10 8 14 4
TGE 10 11 20 5.5
TGE 10 12.5 22 6
TGE 20 20 31 8.5
TGE 40 26 49 14

The rated capacity is based on:
Evaporating temperature te : 4.4 °C / 40 °F
Condensing temperature tc : 38 °C / 100 °F
Refrigerant temperature ahead of valve tl : 37 °C / 98 °F

Range N -40 – 10 °C / -40 –50 °F, OS = 4 K / 7.2 °F

Valve type Orice no. Rated capacity

TGE 10 4 14 4 12 3.5

TGE 10 6 20 6 17 5
TGE 10 8 27 7.5 23 6.5
TGE 10 9 32 9 28 8
TGE 10 11 40 11 34 10

The rated capacity is based on:
Evaporating temperature te : 4.4 °C / 40 °F
Condensing temperature tc : 38 °C / 100 °F
Refrigerant temperature ahead of valve tl : 37 °C / 98 °F

1

) On systems charged with R407F, SS = 4.0 °C / 7.2 °F, on systems charged with R407A, SS = 2.7 °C / 4.9 °F.

Rated capacity Connections solder ODF Code no.

[KW] [TR]

Inlet x Outlet Pressure equalization

[inch] [inch]

5

⁄8 x 7⁄8

5

⁄8 x 7⁄8

5

⁄8 x 7⁄8

7

⁄8 x 1 1⁄8

7

⁄8 x 1 1⁄8

1

⁄4 067N8001

1

⁄4 067N8002

1

⁄4 067N8003

1

⁄4 067N8004

1

⁄4 067N8005

Multi pack

R407F/R407A1)

Rated capacity

R407F

R407A

[KW] [TR] [KW] [TR]

Connections solder ODF Code no.

Inlet x Outlet Pressure

equalization

[inch] [inch]

1

⁄2 x 7⁄8

5

⁄8 x 7⁄8

5

⁄8 x 7⁄8

5

⁄8 x 7⁄8

5

⁄8 x 1 1⁄8

1

⁄4 067N4700

1

⁄4 067N4701

1

⁄4 067N4702

1

⁄4 067N4703

1

⁄4 067N4704

R1234ze

Multi pack

Range N -40 – 10 °C / -40 –50 °F, OS = 4 K / 7.2 °F

R404A/R507

Valve type Orice no. Rated capacity Connections solder ODF Code no.

[KW] [TR]

TGE 10 3 7 2
TGE 10 4 9 2.5
TGE 10 6 14 4
TGE 10 6 14 4
TGE 10 8 18 5
TGE 10 8 18 5
TGE 10 9 21 6
TGE 10 11 26 7.5
TGE 10 12.5 31 9
TGE 10 16 35 10
TGE 20 12.5 31 9
TGE 20 16 39 11

Inlet x Outlet

[inch]

3

⁄8 x 5⁄8

1

⁄2 x 7⁄8

1

⁄2 x 5⁄8

1

⁄2 x 7⁄8

1

⁄2 x 5⁄8

5

⁄8 x 7⁄8

5

⁄8 x 7⁄8

5

⁄8 x 7⁄8

5

⁄8 x 7⁄8

5

⁄8 x 1 1⁄8

5

⁄8 x 7⁄8

5

⁄8 x 1 1⁄8

TGE 20 16 39 11 1 1⁄8 x 1 3⁄8
TGE 20 16 39 11
TGE 20 20 45 13
TGE 40 26 64 18

7

⁄8 x 1 1⁄8

7

⁄8 x 1 1⁄8

7

⁄8 x 1 3⁄8

TGE 40 30 72 21 1 1⁄8 x 1 3⁄8
TGE 40 40 92 26 1 1⁄8 x 1 3⁄8

Pressure equalization

[inch]

1

⁄4 067N6170

1

⁄4 067N6172

1

⁄4 067N6173

1

⁄4 067N6151

1

⁄4 067N6175

1

⁄4 067N6150

1

⁄4 067N6167

1

⁄4 067N6154

1

⁄4 067N6300

1

⁄4 067N6301

1

⁄4 067N6158

1

⁄4 067N6155

1

⁄4 067N6188

1

⁄4 067N6181

1

⁄4 067N6162

1

⁄4 067N6161

1

⁄4 067N6186

1

⁄4 067N6187

Multi pack

The rated capacity is based on:
Evaporating temperature te : 4.4 °C / 40 °F
Condensing temperature tc : 38 °C / 100 °F
Refrigerant temperature ahead of valve tl : 37 °C / 98 °F

© Danfoss | DCS (az) | 2019.01

DKRCC.PD.AXV.3A.02 | 12

Data sheet | Thermostatic expansion valves, type TGE 10, TGE 20, TGE 40

Ordering

Range N -40 – 10 °C / -40 –50 °F, OS = 4 K / 7.2 °F

Valve type Orice

no.

TGE 10 3 9 2.5

Rated capacity Connections solder ODF Code no.

[KW] [TR]

Inlet x Outlet Pressure equalization

[inch] [mm] [inch] [mm]

1

⁄2 x 5⁄8 –

1

⁄4 – 067N4151

R407C

Multi pack

TGE 10 3 9 2.5 – 12 × 16 – 6 067N4191
TGE 10 4 13 3.5

1

⁄2 x 7⁄8 –

1

⁄4 – 067N4152

TGE 10 4 13 3.5 – 12 × 22 – 6 067N4192
TGE 10 6 19 5

1

⁄2 x 5⁄8 –

1

⁄4 – 067N4153

TGE 10 6 19 5 – 12 × 16 – 6 067N4193
TGE 10 8 25 7
TGE 10 8 25 7

1

⁄2 x 5⁄8 –

5

⁄8 x 7⁄8 –

1

⁄4 – 067N4236

1

⁄4 – 067N4156

TGE 10 8 25 7 – 16 × 22 – 6 067N4196
TGE 10 11 36 10

5

⁄8 x 7⁄8 –

1

⁄4 – 067N4157

TGE 10 11 36 10 – 16 × 22 – 6 067N4197
TGE 10 12.5 39 11
TGE 10 16 49 14
TGE 20 12.5 42 12
TGE 20 16 53 15
TGE 20 16 53 15
TGE 20 20 62 18
TGE 40 26 84 24
TGE 40 30 95 27

5

⁄8 x 7⁄8 –

7

⁄8 x 1 1⁄8 –

5

⁄8 x 7⁄8 –

5

⁄8 x 1 1⁄8 –

7

⁄8 x 1 1⁄8 –

7

⁄8 x 1 1⁄8 –

7

⁄8 x 1 3⁄8 –

7

⁄8 x 1 3⁄8 –

TGE 40 40 121 34 1 1⁄8 x 1 3⁄8 –

1

⁄4 – 067N4410

1

⁄4 – 067N4411

1

⁄4 – 067N4159

1

⁄4 – 067N4161

1

⁄4 – 067N4162

1

⁄4 – 067N4163

1

⁄4 – 067N4165

1

⁄4 – 067N4167

1

⁄4 – 067N4169

The rated capacity is based on:
Evaporating temperature te : 4.4 °C / 40 °F
Condensing temperature tc : 38 °C / 100 °F
Refrigerant temperature ahead of valve tl : 37 °C / 98 °F

Range N -40 – 10 °C / -40 –50 °F, OS = 4 K / 7.2 °F

Valve type Orice

no.

TGE 10 4 13 3.5
TGE 10 6 19 5
TGE 10 8 25 7
TGE 10 11 36 10

The rated capacity is based on:
Evaporating temperature te : 4.4 °C / 40 °F
Condensing temperature tc : 38 °C / 100 °F
Refrigerant temperature ahead of valve tl : 37 °C / 98 °F

Rated capacity Connections MIO Code no.

[KW] [TR] Inlet x Outlet inch Pressure equalization inch

1

1

5

5

⁄2 x 5⁄8 MIO
⁄2 x 5⁄8 MIO
⁄8 x 3⁄4 MIO
⁄8 x 3⁄4 MIO

R407C

Multi pack

1

⁄4 MIO 067N7400

1

⁄4 MIO 067N7401

1

⁄4 MIO 067N7402

1

⁄4 MIO 067N7403

© Danfoss | DCS (az) | 2019.01

DKRCC.PD.AXV.3A.02 | 13

Data sheet | Thermostatic expansion valves, type TGE 10, TGE 20, TGE 40

Ordering

Range K –25 – 10 °C / –15 – 50 °F with MOP 15 °C / 60 °F, OS = 4 K / 7.2 °F

Valve type Orice

no.

TGE 10 3 9 2.5

Rated capacity Connections solder ODF Code no.

[KW] [TR]

Inlet x Outlet Pressure equalization

[inch] [mm] [inch] [mm]

3

⁄8 x 5⁄8 –

1

⁄4 – 067N4000

R407C

Multi pack

TGE 10 3 9 2.5 – 12 × 16 – 6 067N4041
TGE 10 4 13 3.5
TGE 10 6 19 5
TGE 10 6 19 5
TGE 10 8 25 7

1

⁄2 x 7⁄8 –

1

⁄2 x 5⁄8 –

1

⁄2 x 7⁄8 –

5

⁄8 x 7⁄8 –

1

⁄4 – 067N4002

1

⁄4 – 067N4003

1

⁄4 – 067N4004

1

⁄4 – 067N4006

TGE 10 8 25 7 – 16 × 22 – 6 067N4046
TGE 10 11 36 10

5

⁄8 x 7⁄8 –

1

⁄4 – 067N4007

TGE 10 11 36 10 – 16 × 22 – 6 067N4047
TGE 10 12.5 39 11
TGE 10 16 49 14
TGE 20 12.5 42 12
TGE 20 12.5 42 12
TGE 20 16 53 15
TGE 20 20 62 18
TGE 40 26 84 24
TGE 40 30 95 27

5

⁄8 x 1 1⁄8 –

5

⁄8 x 1 1⁄8 –

5

⁄8 x 7⁄8 –

5

⁄8 x 1 1⁄8 –

5

⁄8 x 1 1⁄8 –

7

⁄8 x 1 1⁄8 –

7

⁄8 x 1 3⁄8 –

7

⁄8 x 1 3⁄8 –

TGE 40 40 121 34 1 1⁄8 x 1 3⁄8 –

1

⁄4 – 067N4400

1

⁄4 – 067N4401

1

⁄4 – 067N4009

1

⁄4 – 067N4010

1

⁄4 – 067N4011

1

⁄4 – 067N4013

1

⁄4 – 067N4015

1

⁄4 – 067N4017

1

⁄4 – 067N4019

The rated capacity is based on:
Evaporating temperature te : 4.4 °C / 40 °F
Condensing temperature tc : 38 °C / 100 °F
Refrigerant temperature ahead of valve tl : 37 °C / 98 °F

Only solder versions, connection size 28mm / 1 1⁄8 in. or below are approved for ammable refrigerants.

Range N -40 – 10 °C / -40 – 50 °F, OS = 4 K / 7.2 °F

Valve type

TGE 10 6 19 5
TGE 10 11 36 10
TGE 20 12.5 44 12
TGE 20 16 54 15
TGE 20 20 63 18

Orice no. Rated capacity Connections solder ODF Code no.

[KW] [TR]

Inlet x Outlet Pressure equalization

[inch] [inch]

5

⁄8 x 7⁄8

5

⁄8 × 7⁄8

5

⁄8 × 7⁄8

7

⁄8 × 7⁄8

7

⁄8 × 7⁄8

Range K –25 – 10 °C / –15 – 50 °F without MOP, OS = 4 K / 7.2 °F

Valve type Orice

no.

Rated capacity Connections solder ODF Code no.

Inlet x Outlet Pressure

[KW] [TR]

1

⁄4 067N9100

1

⁄4 067N9103

1

⁄4 067N9104

1

⁄4 067N9105

1

⁄4 067N9106

equalization

R2901)

Multi pack

R2901)

Multi pack

[inch] [inch]

TGE 40 26 92 26
TGE 40 40 133 38

The rated capacity is based on:
Evaporating temperature te : 4.4 °C / 40 °F
Condensing temperature tc : 38 °C / 100 °F
Refrigerant temperature ahead of valve tl : 37 °C / 98 °F

1

) SS = 5K / 9°F (except 067N9100, 067N9103)

7

⁄8 × 7⁄8

7

⁄8 × 7⁄8

1

⁄4 067N9107

1

⁄4 067N9109

Ordering
(Spare parts)

© Danfoss | DCS (az) | 2019.01

Bulb straps (delivered separately) in Industrial pack

Code no. Max. tube diameter Quantity / pack

067N0551

067N0557 2 1⁄8 40

067N0559 3 1⁄8 40

7

⁄8 40

DKRCC.PD.AXV.3A.02 | 14

Data sheet | Thermostatic expansion valves, type TGE 10, TGE 20, TGE 40

Sizing

TGE

pe~t

e

Q

e

4

EVR

Fig. 7

Sizing examples (SI units)

Refrigerant: R410A
Evaporator capacity : Qe= 30 kW
Evaporator with several circuits, i.e.
a valve with distributor is required
Evaporating temperature: te = 0 °C
pe = 7 bar
Condensing temperature: tc = 35 °C
pc = 21 bar
Refrigrant liquid temperature: tl = 25 °C
Subcooling: ∆t

= 35 °C – 25 °C = 10 K

sub

Pressure drop ∆p2 in the liquid distributor can also be assumed as 1.0 bar.

sub

The correction factor at ∆t

sub

(f

) = 10 K is 1.07.
The correction factor at distributer (fp) = 0.96.
The corrected evaporator capacity thus
30 kW divided by 1.07 and 0.96 = 29.2 kW.

Since the capacity of the expansion valve must be equal to or slightly
higher than the corrected evaporator capacity of 29.2 kW, a TGE 10 orice
08 giving 32 kW would be a suitable choice (See tables below).

Capacity in kW. -40 – 15 °C
Opening superheat sh = 4 K SI units R410A

Valve

Orice

type

TGE 10

Cond.

no.

temp.

-40 -30 -20 -10 0 10 15

[°C]

3 35 5.47 7.09 8.84 10.6 12.1 12.8 12.7

4 35 7.33 9.52 11.9 14.4 16.4 17.4 17.2

6 35 10.7 13.9 17.4 21.0 24.1 25.5 25.2

8 35 14.4 18.7 23.4 28.1 32.0 33.6 33.0

9 35 16.5 21.5 27.2 32.8 37.2 39.3 39.0

Evaporating temperature [°C]

Subcooling correction factor 'fsub'

Subcooling [K] 2 4 10 15 20 25 30

Correction factor 0.98 1.00 1.07 1.13 1.18 1.24 1.30

Distributer correction factor 'fp' *

Pressure

drop [bar]

Δp

0 1 1 1 1 1 1 1

1 0.97 0.97 0.97 0.96 0.96 0.94 0.93

1.5 0.96 0.96 0.95 0.95 0.93 0.91 0.89

2 0.94 0.94 0.93 0.93 0.91 0.88 0.85

*Calculated at 32 °C condensing temperature.

-40 -30 -20 -10 0 10 15

Evaporating temperature [°C]

Correction factor

© Danfoss | DCS (az) | 2019.01

SGI/SGN

DCL/DML

Sizing examples (US units)

Refrigerant: R410A
Evaporator capacity : Qe= 8.6 TR
Evaporator with several circuits, i.e.
a valve with distributor is required
Evaporating temperature: te = 40 °F
pe = 118 psig
Condensing temperature: t

= 95 °F

c

pc = 296 psig
Refrigrant liquid temperature: tl = 75 °F
Subcooling: ∆t

= 95 °F –75 °F = 20 °F

sub

Pressure drop ∆p2 in the liquid distributor can also be assumed as 15 psi.

sub

The correction factor at ∆t

sub

(f

) =20 °F is 1.08.
The correction factor at distributer (fp) = 0.95.
The corrected evaporator capacity thus

8.6 TR divided by 1.08 and 0.95 = 8.38 TR.

Since the capacity of the expansion valve must be equal to or slightly
higher than the corrected evaporator capacity of 8.38 TR, a TGE 10 orice
08 giving 9.4 TR would be a suitable choice (See tables below).

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R410A

Valve

Orice

type

TGE 10

Cond.

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 95 1.55 2.07 2.62 3.17 3.57 3.64 3.58

4 95 2.08 2.78 3.54 4.29 4.84 4.95 4.87

6 95 3.03 4.06 5.18 6.28 7.09 7.24 7.12

8 95 4.08 5.45 6.93 8.38 9.40 9.55 9.33

9 95 4.70 6.29 8.08 9.78 11.0 11.2 11.1

Evaporating temperature [°F]

Subcooling correction factor 'fsub'

Subcooling [°F] 2 7 10 20 30 40 50

Correction factor 0.97 1.00 1.02 1.08 1.15 1.21 1.27

Distributer correction factor 'fp' *

Pressure

drop [psi]

Δp

0 1 1 1 1 1 1 1

15 0.97 0.97 0.97 0.96 0.95 0.94 0.93

25 0.95 0.95 0.94 0.93 0.92 0.90 0.87

30 0.94 0.94 0.93 0.92 0.90 0.88 0.84

*Calculated at 90 °F condensing temperature.

-40 -20 0 20 40 50 60

Evaporating temperature [°F]

Correction factor

DKRCC.PD.AXV.3A.02 | 15

Data sheet | Thermostatic expansion valves, type TGE 10, TGE 20, TGE 40

Capacity in kW. -40 – 15 °C
Opening superheat sh = 4 K SI units R410A

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -30 -20 -10 0 10 15

[°C]

3 25 5.63 7.19 8.80 10.2 11.1 10.7 9.68

4 25 7.60 9.73 12.0 14.0 15.2 14.6 13.2

6 25 11.2 14.4 17.7 20.6 22.4 21.6 19.5

8 25 15.2 19.5 23.8 27.7 29.9 28.6 25.7

9 25 17.4 22.3 27.6 32.4 35.3 34.1 30.7

11 25 22.6 29.1 35.4 40.3 42.1 38.4 33.8

12.5 25 23.2 30.0 37.2 43.8 47.7 46.3 41.7

16 25 27.3 35.0 43.3 50.7 55.3 53.4 47.8

12.5 25 22.7 30.1 38.3 46.4 52.1 51.6 47.3

16 25 28.3 37.7 48.1 58.5 66.2 66.0 60.7

20 25 34.8 45.9 57.8 69.3 77.0 75.1 67.9

21 25 45.7 59.0 72.0 81.9 85.2 78.2 68.4

26 25 45.1 59.7 76.7 94.5 108.7 110 101

30 25 51.3 68.0 87.3 108 123 124 114

40 25 61.9 82.1 106 132 152 154 140

42 25 90.8 115 140 161 170 158 139

Evaporating temperature [°C]

Capacity in kW. -40 – 15 °C
Opening superheat sh = 4 K SI units R410A

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -30 -20 -10 0 10 15

[°C]

3 35 5.47 7.09 8.84 10.6 12.1 12.8 12.7

4 35 7.33 9.52 11.9 14.4 16.4 17.4 17.2

6 35 10.7 13.9 17.4 21.0 24.1 25.5 25.2

8 35 14.4 18.7 23.4 28.1 32.0 33.6 33.0

9 35 16.5 21.5 27.2 32.8 37.2 39.3 39.0

11 35 21.4 28.2 35.3 41.8 46.1 46.4 44.4

12.5 35 21.9 28.7 36.3 43.9 50.0 53.1 52.8

16 35 25.7 33.5 42.3 51.0 58.2 62.0 61.7

12.5 35 21.3 28.5 36.8 45.9 54.3 59.4 59.5

16 35 26.4 35.3 45.8 57.4 68.4 75.4 75.7

20 35 32.4 43.1 55.2 68.3 80.4 87.2 86.6

21 35 44.8 58.7 73.0 85.2 92.6 92.9 89.9

26 35 41.5 55.4 72.1 91.3 111 124 126

30 35 47.0 62.8 81.8 104 125 140 142

40 35 57.4 77.2 102 130 157 175 177

42 35 90.3 116 143 169 186 189 184

Evaporating temperature [°C]

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R410A

Valve

Orice

Cond.

type

TGE 10

TGE 20

TGE 40

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 75 1.60 2.09 2.59 2.99 3.10 2.95 2.57

4 75 2.16 2.83 3.52 4.07 4.24 4.03 3.52

6 75 3.19 4.19 5.20 6.03 6.26 5.95 5.17

8 75 4.33 5.67 7.02 8.09 8.33 7.88 6.81

9 75 4.96 6.51 8.16 9.50 9.89 9.41 8.10

11 75 6.44 8.48 10.4 11.6 11.5 10.6 8.93

12.5 75 6.62 8.76 11.0 12.9 13.4 12.8 11.0

16 75 7.77 10.2 12.8 14.9 15.5 14.7 12.6

12.5 75 6.47 8.83 11.4 13.8 14.8 14.3 12.6

16 75 8.08 11.1 14.4 17.4 18.9 18.3 16.2

20 75 9.94 13.5 17.2 20.5 21.7 20.7 18.1

21 75 13.0 17.2 21.1 23.6 23.3 21.5 17.9

26 75 12.9 17.6 23.0 28.3 31.2 30.4 26.9

30 75 14.7 20.0 26.2 32.2 35.4 34.4 30.4

40 75 17.7 24.1 31.9 39.6 43.7 42.5 37.0

42 75 25.7 33.4 41.0 46.5 46.8 43.5 36.3

Evaporating temperature [°F]

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R410A

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 95 1.55 2.07 2.62 3.17 3.57 3.64 3.58

4 95 2.08 2.78 3.54 4.29 4.84 4.95 4.87

6 95 3.03 4.06 5.18 6.28 7.09 7.24 7.12

8 95 4.08 5.45 6.93 8.38 9.40 9.55 9.33

9 95 4.70 6.29 8.08 9.78 11.0 11.2 11.1

11 95 6.07 8.23 10.5 12.4 13.3 13.2 12.5

12.5 95 6.20 8.37 10.8 13.1 14.7 15.1 15.0

16 95 7.29 9.79 12.6 15.2 17.2 17.6 17.5

12.5 95 6.06 8.34 11.0 13.9 16.3 16.9 16.9

16 95 7.48 10.3 13.7 17.4 20.5 21.4 21.5

20 95 9.19 12.6 16.5 20.6 24.0 24.8 24.5

21 95 12.7 17.1 21.6 25.1 26.6 26.4 25.4

26 95 11.8 16.2 21.6 27.8 33.4 35.2 35.7

30 95 13.3 18.4 24.5 31.5 37.9 39.9 40.3

40 95 16.3 22.6 30.7 39.7 47.3 49.6 50.1

42 95 25.7 33.7 42.4 49.8 53.8 53.8 51.8

Evaporating temperature [°F]

Subcooling correction factor 'fsub'

Subcooling [K] 2 4 10 15 20 25 30

Correction factor 0.98 1.00 1.07 1.13 1.18 1.24 1.30

Distributer correction factor 'fp' *

Pressure

drop [bar]

Δp

0 1 1 1 1 1 1 1

1 0.97 0.97 0.97 0.96 0.96 0.94 0.93

1.5 0.96 0.96 0.95 0.95 0.93 0.91 0.89

2 0.94 0.94 0.93 0.93 0.91 0.88 0.85

*Calculated at 32 °C condensing temperature.

-40 -30 -20 -10 0 10 15

Evaporating temperature [°C]

Correction factor

© Danfoss | DCS (az) | 2019.01

Subcooling correction factor 'fsub'

Subcooling [°F] 2 7 10 20 30 40 50

Correction factor 0.97 1.00 1.02 1.08 1.15 1.21 1.27

Distributer correction factor 'fp' *

Pressure

drop [psi]

Δp

0 1 1 1 1 1 1 1

15 0.97 0.97 0.97 0.96 0.95 0.94 0.93

25 0.95 0.95 0.94 0.93 0.92 0.90 0.87

30 0.94 0.94 0.93 0.92 0.90 0.88 0.84

*Calculated at 90 °F condensing temperature.

-40 -20 0 20 40 50 60

Evaporating temperature [°F]

Correction factor

DKRCC.PD.AXV.3A.02 | 16

Data sheet | Thermostatic expansion valves, type TGE 10, TGE 20, TGE 40

Capacity in kW. -40 – 15 °C
Opening superheat sh = 4 K SI units R410A

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

3 45 5.14 6.72 8.47 10.3 12.2 13.6 13.9

4 45 6.83 8.95 11.3 13.9 16.4 18.3 18.8

6 45 9.83 12.9 16.4 20.1 23.8 26.6 27.3

8 45 13.1 17.2 21.8 26.7 31.5 35.0 35.7

9 45 15.1 19.9 25.5 31.4 36.7 40.5 41.6

11 45 19.4 26.1 33.4 40.7 46.7 49.7 49.4

12.5 45 19.6 26.2 33.7 41.6 48.8 54.2 56.0

16 45 23.1 30.7 39.4 48.6 57.2 63.9 66.1

12.5 45 19.4 25.9 33.7 42.6 51.9 60.0 62.6

16 45 23.8 31.9 41.6 52.8 64.8 75.3 78.9

20 45 29.1 38.9 50.3 63.1 76.7 88.5 92.2

21 45 42.4 56.3 71.1 84.7 94.3 98.7 98.8

26 45 37.0 49.5 64.7 82.9 103 122 129

30 45 41.7 55.9 73.2 93.8 117 138 145

40 45 50.9 69.2 92.9 121 151 176 185

42 45 87.1 113 141 169 191 202 203

-40 -30 -20 -10 0 10 15

[°C]

Evaporating temperature [°C]

Capacity in kW. -40 – 15 °C
Opening superheat sh = 4 K SI units R410A

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -30 -20 -10 0 10 15

[°C]

3 55 4.67 6.13 7.76 9.53 11.4 13.0 13.6

4 55 6.14 8.09 10.3 12.7 15.2 17.4 18.3

6 55 8.70 11.5 14.7 18.2 21.8 25.1 26.3

8 55 11.4 15.2 19.4 24.0 28.7 32.8 34.2

9 55 13.0 17.4 22.7 28.4 33.9 38.5 40.4

11 55 16.8 23.1 30.1 37.3 43.9 48.3 49.1

12.5 55 16.6 22.5 29.5 37.2 44.6 51.0 53.7

16 55 19.5 26.5 34.6 43.5 52.4 60.4 63.9

12.5 55 17.1 22.8 29.5 37.3 45.9 54.4 58.0

16 55 20.7 27.7 36.1 45.9 56.8 67.7 72.5

20 55 25.3 33.9 43.7 55.0 67.5 80.2 85.7

21 55 38.3 51.7 66.4 80.3 91.1 97.7 99.4

26 55 32.0 42.8 55.9 71.6 89.6 108 117

30 55 35.9 48.1 63.0 80.8 101 122 132

40 55 42.4 58.3 79.4 106 135 163 175

42 55 81.1 106 134 163 187 202 206

Evaporating temperature [°C]

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R410A

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

3 115 1.45 1.94 2.50 3.10 3.64 3.85 3.97

4 115 1.92 2.59 3.35 4.16 4.91 5.20 5.37

6 115 2.76 3.73 4.84 6.02 7.12 7.54 7.78

8 115 3.66 4.97 6.43 7.98 9.39 9.90 10.2

9 115 4.22 5.75 7.54 9.38 10.9 11.5 11.9

11 115 5.43 7.56 9.87 12.1 13.8 14.1 14.1

12.5 115 5.49 7.55 9.96 12.4 14.6 15.4 16.0

16 115 6.45 8.85 11.6 14.5 17.1 18.1 18.9

12.5 115 5.44 7.49 9.97 12.8 15.7 16.9 17.8

16 115 6.65 9.21 12.3 15.9 19.6 21.2 22.4

20 115 8.15 11.2 14.9 19.0 23.2 25.0 26.2

21 115 11.9 16.3 21.0 25.0 27.5 28.1 28.2

26 115 10.3 14.3 19.2 25.1 31.4 34.3 36.6

30 115 11.7 16.1 21.7 28.3 35.5 38.7 41.3

40 115 14.2 20.0 27.7 36.8 46.0 49.8 52.8

42 115 24.6 32.7 41.7 50.2 56.1 57.6 57.9

-40 -20 0 20 40 50 60

[°F]

Evaporating temperature [°F]

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R410A

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

3 135 1.29 1.74 2.25 2.81 3.36 3.60 3.80

4 135 1.69 2.30 2.98 3.73 4.49 4.82 5.09

6 135 2.39 3.26 4.25 5.34 6.43 6.92 7.30

8 135 3.13 4.29 5.60 7.02 8.43 9.04 9.50

9 135 3.53 4.90 6.56 8.35 9.99 10.7 11.3

11 135 4.59 6.55 8.72 10.9 12.8 13.4 13.7

12.5 135 4.50 6.32 8.52 10.9 13.1 14.1 15.0

16 135 5.28 7.42 9.98 12.8 15.5 16.7 17.9

12.5 135 4.70 6.44 8.52 11.0 13.6 14.9 16.1

16 135 5.68 7.82 10.4 13.5 16.9 18.5 20.0

20 135 6.93 9.55 12.6 16.1 20.0 21.9 23.7

21 135 10.6 14.8 19.4 23.5 26.5 27.4 28.0

26 135 8.74 12.1 16.2 21.1 26.7 29.6 32.2

30 135 9.80 13.6 18.2 23.8 30.2 33.4 36.4

40 135 11.4 16.3 23.0 31.3 40.3 44.7 48.6

42 135 22.5 30.4 39.3 48.0 54.8 57.0 58.4

-40 -20 0 20 40 50 60

[°F]

Evaporating temperature [°F]

Subcooling correction factor 'fsub'

Subcooling [K] 2 4 10 15 20 25 30

Correction factor 0.98 1.00 1.07 1.13 1.18 1.24 1.30

Distributer correction factor 'fp' *

Pressure

drop [bar]

Δp

0 1 1 1 1 1 1 1

1 0.97 0.97 0.97 0.96 0.96 0.94 0.93

1.5 0.96 0.96 0.95 0.95 0.93 0.91 0.89

2 0.94 0.94 0.93 0.93 0.91 0.88 0.85

*Calculated at 32 °C condensing temperature.

-40 -30 -20 -10 0 10 15

Evaporating temperature [°C]

Correction factor

© Danfoss | DCS (az) | 2019.01

Subcooling correction factor 'fsub'

Subcooling [°F] 2 7 10 20 30 40 50

Correction factor 0.97 1.00 1.02 1.08 1.15 1.21 1.27

Distributer correction factor 'fp' *

Pressure

drop [psi]

Δp

0 1 1 1 1 1 1 1

15 0.97 0.97 0.97 0.96 0.95 0.94 0.93

25 0.95 0.95 0.94 0.93 0.92 0.90 0.87

30 0.94 0.94 0.93 0.92 0.90 0.88 0.84

*Calculated at 90 °F condensing temperature.

-40 -20 0 20 40 50 60

Evaporating temperature [°F]

Correction factor

DKRCC.PD.AXV.3A.02 | 17

Data sheet | Thermostatic expansion valves, type TGE 10, TGE 20, TGE 40

Capacity in kW. -40 – 15 °C
Opening superheat sh = 4 K SI units R32

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -30 -20 -10 0 10 15

[°C]

3 25 8.96 11.4 13.9 16.1 17.3 16.5 14.7

4 25 12.1 15.4 18.8 21.8 23.5 22.4 20.0

6 25 17.6 22.5 27.7 32.0 34.4 32.8 29.4

8 25 23.8 30.4 37.1 42.7 45.4 43.0 38.3

9 25 25.6 33.0 40.9 47.6 51.3 49.2 44.1

11 25 35.3 45.7 55.5 62.0 62.9 56.6 49.6

12.5 25 33.9 44.0 54.6 63.9 68.9 66.2 59.5

16 25 39.9 51.4 63.5 74.0 79.9 76.5 68.3

12.5 25 35.8 47.6 60.4 72.8 81.5 80.0 72.1

16 25 44.5 59.0 75.3 91.0 102 103 94.4

20 25 54.6 71.6 90.0 107 118 116 104

21 25 67.9 88.2 106 120 124 113 97.9

26 25 67.5 89.4 114 140 159 161 147

30 25 76.6 102 130 158 180 182 167

40 25 92.6 123 159 197 226 224 198

42 25 142 180 217 246 256 233 202

Evaporating temperature [°C]

Capacity in kW. -40 – 15 °C
Opening superheat sh = 4 K SI units R32

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

3 35 9.01 11.6 14.4 17.0 19.2 20.1 19.8

4 35 12.0 15.6 19.3 23.0 25.9 27.3 26.8

6 35 17.4 22.5 28.1 33.4 37.4 39.0 38.7

8 35 23.3 30.1 37.5 44.3 49.2 51.0 50.2

9 35 25.0 32.7 41.2 49.3 55.4 58.1 57.6

11 35 34.6 45.8 57.2 66.2 70.3 69.0 66.3

12.5 35 32.7 43.1 54.5 65.5 73.9 77.6 77.0

16 35 38.5 50.4 63.5 76.2 86.1 90.7 89.9

12.5 35 34.6 46.2 59.3 73.3 86.2 93.9 93.6

16 35 43.0 57.5 74.3 91.6 107 117 119

20 35 52.6 69.8 89.2 108 125 134 135

21 35 68.7 90.3 111 129 139 139 133

26 35 64.2 86.0 112 139 164 181 184

30 35 72.6 97.4 127 157 185 204 208

40 35 87.6 118 155 198 238 262 262

42 35 147 188 229 266 290 290 277

-40 -30 -20 -10 0 10 15

[°C]

Evaporating temperature [°C]

Capactiy in TR, range: -40 – 60 °F
Opening superheat sh = 7.2 °F US units R32

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 75 2.54 3.32 4.07 4.67 4.79 4.52 3.87

4 75 3.42 4.48 5.52 6.33 6.52 6.16 5.27

6 75 5.01 6.55 8.12 9.32 9.56 9.04 7.72

8 75 6.75 8.82 10.9 12.4 12.6 11.9 10.1

9 75 7.27 9.62 12.0 13.9 14.3 13.6 11.6

11 75 10.0 13.3 16.2 17.7 17.0 15.6 13.0

12.5 75 9.66 12.8 16.1 18.7 19.3 18.3 15.7

16 75 11.3 15.0 18.7 21.6 22.3 21.1 17.9

12.5 75 10.2 13.9 18.0 21.6 23.0 22.0 19.1

16 75 12.7 17.3 22.4 27.0 29.2 28.4 25.0

20 75 15.5 20.9 26.7 31.5 33.4 32.0 27.3

21 75 19.3 25.5 31.0 34.4 33.7 30.9 25.6

26 75 19.2 26.2 34.1 41.6 45.6 44.5 38.9

30 75 21.8 29.8 38.8 47.2 51.6 50.4 44.1

40 75 26.4 36.1 47.6 58.8 64.4 61.7 51.6

42 75 40.1 52.1 63.1 70.6 69.7 64.0 52.9

Evaporating temperature [°F]

Capactiy in TR, range: -40 – 60 °F
Opening superheat sh = 7.2 °F US units R32

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 95 2.56 3.39 4.25 5.07 5.63 5.72 5.60

4 95 3.41 4.53 5.71 6.83 7.61 7.74 7.59

6 95 4.94 6.57 8.34 9.91 10.9 11.1 11.0

8 95 6.60 8.78 11.1 13.1 14.3 14.5 14.2

9 95 7.10 9.55 12.2 14.7 16.2 16.5 16.3

11 95 9.84 13.4 16.9 19.4 20.0 19.6 18.7

12.5 95 9.29 12.6 16.2 19.5 21.7 22.0 21.8

16 95 11.0 14.7 18.9 22.7 25.3 25.8 25.5

12.5 95 9.83 13.5 17.7 22.1 25.7 26.7 26.5

16 95 12.2 16.8 22.2 27.5 31.8 33.1 33.7

20 95 14.9 20.4 26.6 32.5 36.9 38.1 38.3

21 95 19.5 26.3 32.7 37.7 40.0 39.5 37.5

26 95 18.2 25.2 33.4 41.9 49.0 51.3 52.3

30 95 20.6 28.5 37.9 47.5 55.4 58.0 59.0

40 95 24.9 34.6 46.7 60.2 71.6 74.5 74.1

42 95 41.6 54.7 67.6 78.3 83.5 82.5 78.0

Evaporating temperature [°F]

Subcooling correction factor 'fsub'

Subcooling [K] 2 4 10 15 20 25 30

Correction factor 0.98 1.00 1.06 1.10 1.15 1.20 1.24

Distributer correction factor 'fp' *

Pressure

drop [bar]

Δp

0 1 1 1 1 1 1 1

1 0.97 0.97 0.97 0.96 0.96 0.94 0.93

1.5 0.96 0.96 0.95 0.95 0.94 0.92 0.89

2 0.94 0.94 0.94 0.93 0.91 0.88 0.86

*Calculated at 32 °C condensing temperature.

-40 -30 -20 -10 0 10 15

Evaporating temperature [°C]

Correction factor

© Danfoss | DCS (az) | 2019.01

Subcooling correction factor 'fsub'

Subcooling [°F] 2 7 10 20 30 40 50

Correction factor 0.97 1.00 1.02 1.07 1.12 1.17 1.22

Distributer correction factor 'fp' *

Pressure

drop [psi]

Δp

0 1 1 1 1 1 1 1

15 0.97 0.97 0.97 0.96 0.95 0.94 0.93

25 0.95 0.95 0.94 0.94 0.92 0.90 0.88

30 0.94 0.94 0.93 0.92 0.90 0.88 0.85

*Calculated at 90 °F condensing temperature.

-40 -20 0 20 40 50 60

Evaporating temperature [°F]

Correction factor

DKRCC.PD.AXV.3A.02 | 18

Data sheet | Thermostatic expansion valves, type TGE 10, TGE 20, TGE 40

Capacity in kW. -40 – 15 °C
Opening superheat sh = 4 K SI units R32

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

3 45 8.85 11.5 14.3 17.2 19.9 21.9 22.3

4 45 11.7 15.2 19.1 23.0 26.7 29.4 30.1

6 45 16.7 21.8 27.6 33.3 38.2 41.7 42.7

8 45 22.0 28.9 36.5 44.0 50.2 54.2 55.4

9 45 23.6 31.3 40.0 48.8 56.4 61.7 63.3

11 45 32.8 44.4 56.9 67.6 74.2 76.1 75.6

12.5 45 30.4 40.6 52.3 64.1 74.4 81.6 83.9

16 45 35.8 47.6 61.1 74.9 87.2 96.3 99.2

12.5 45 32.8 43.7 56.3 70.2 84.5 96.7 101

16 45 40.2 54.2 70.7 88.2 105 119 125

20 45 49.0 65.8 85.0 105 124 139 145

21 45 67.8 90.0 112 131 146 153 152

26 45 59.2 79.9 105 132 159 182 192

30 45 66.6 90.1 118 149 179 205 216

40 45 80.0 109 146 189 235 273 285

42 45 148 191 235 276 308 321 318

-40 -30 -20 -10 0 10 15

[°C]

Evaporating temperature [°C]

Capacity in kW. -40 – 15 °C
Opening superheat sh = 4 K SI units R32

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

3 55 8.53 11.1 13.9 16.9 19.7 22.1 23.0

4 55 11.1 14.6 18.4 22.3 26.2 29.5 30.7

6 55 15.5 20.4 26.1 32.0 37.4 41.7 43.6

8 55 20.1 26.7 34.3 41.9 48.7 54.1 56.2

9 55 21.5 28.9 37.4 46.4 54.6 61.3 64.1

11 55 29.7 41.1 54.2 66.2 74.6 78.9 79.9

12.5 55 27.1 36.7 48.0 60.0 71.0 80.1 84.0

16 55 31.8 43.1 56.2 70.2 83.6 95.3 100

12.5 55 30.5 40.5 52.1 65.0 78.8 91.9 97.4

16 55 36.2 49.2 64.7 81.5 97.9 113 120

20 55 44.0 59.7 78.0 97.4 116 134 142

21 55 65.8 87.8 110 130 146 157 158

26 55 52.3 71.3 94.2 120 146 170 182

30 55 58.6 80.0 106 135 164 192 205

40 55 69.8 96.3 130 172 218 262 280

42 55 148 190 234 277 312 332 333

-40 -30 -20 -10 0 10 15

[°C]

Evaporating temperature [°C]

Capactiy in TR, range: -40 – 60 °F
Opening superheat sh = 7.2 °F US units R32

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 115 2.51 3.34 4.25 5.16 5.95 6.23 6.40

4 115 3.30 4.43 5.65 6.90 7.98 8.38 8.61

6 115 4.70 6.34 8.17 9.95 11.4 11.9 12.2

8 115 6.21 8.38 10.8 13.1 14.9 15.4 15.8

9 115 6.66 9.09 11.9 14.6 16.8 17.6 18.1

11 115 9.23 12.9 16.9 20.0 21.6 21.7 21.6

12.5 115 8.55 11.8 15.5 19.2 22.1 23.2 24.0

16 115 10.1 13.8 18.1 22.4 26.0 27.4 28.4

12.5 115 9.23 12.7 16.7 21.2 25.6 27.4 28.7

16 115 11.3 15.7 21.0 26.5 31.5 33.6 35.6

20 115 13.8 19.1 25.2 31.5 37.0 39.4 41.5

21 115 19.2 26.2 33.0 38.9 42.8 43.6 43.3

26 115 16.6 23.2 31.1 39.7 47.8 51.4 54.6

30 115 18.7 26.1 35.2 44.9 54.0 58.0 61.6

40 115 22.4 31.7 43.6 57.7 71.8 77.6 81.4

42 115 42.2 55.6 69.4 81.9 90.3 91.9 90.8

Evaporating temperature [°F]

Capactiy in TR, range: -40 – 60 °F
Opening superheat sh = 7.2 °F US units R32

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 135 2.40 3.21 4.10 5.01 5.87 6.23 6.52

4 135 3.12 4.20 5.39 6.63 7.80 8.30 8.69

6 135 4.29 5.85 7.66 9.49 11.1 11.8 12.4

8 135 5.56 7.63 10.0 12.4 14.4 15.2 15.9

9 135 5.95 8.25 11.0 13.7 16.2 17.2 18.2

11 135 8.18 11.8 15.9 19.6 21.8 22.4 22.8

12.5 135 7.45 10.5 14.0 17.7 21.1 22.5 23.8

16 135 8.74 12.3 16.4 20.8 24.9 26.7 28.4

12.5 135 8.50 11.6 15.3 19.3 23.6 25.6 27.4

16 135 9.98 14.0 18.9 24.2 29.1 31.5 33.9

20 135 12.1 17.0 22.8 28.8 34.5 37.3 40.0

21 135 18.5 25.4 32.2 38.4 43.0 44.4 44.9

26 135 14.4 20.3 27.5 35.4 43.3 47.1 50.9

30 135 16.0 22.7 30.9 39.9 48.8 53.0 57.3

40 135 19.1 27.3 38.2 51.6 66.1 72.9 78.6

42 135 41.8 55.3 69.1 82.0 91.6 94.2 94.7

Evaporating temperature [°F]

Subcooling correction factor 'fsub'

Subcooling [K] 2 4 10 15 20 25 30

Correction factor 0.98 1.00 1.06 1.10 1.15 1.20 1.24

Distributer correction factor 'fp' *

Pressure

drop [bar]

Δp

0 1 1 1 1 1 1 1

1 0.97 0.97 0.97 0.96 0.96 0.94 0.93

1.5 0.96 0.96 0.95 0.95 0.94 0.92 0.89

2 0.94 0.94 0.94 0.93 0.91 0.88 0.86

*Calculated at 32 °C condensing temperature.

-40 -30 -20 -10 0 10 15

Evaporating temperature [°C]

Correction factor

© Danfoss | DCS (az) | 2019.01

Subcooling correction factor 'fsub'

Subcooling [°F] 2 7 10 20 30 40 50

Correction factor 0.97 1.00 1.02 1.07 1.12 1.17 1.22

Distributer correction factor 'fp' *

Pressure

drop [psi]

Δp

0 1 1 1 1 1 1 1

15 0.97 0.97 0.97 0.96 0.95 0.94 0.93

25 0.95 0.95 0.94 0.94 0.92 0.90 0.88

30 0.94 0.94 0.93 0.92 0.90 0.88 0.85

*Calculated at 90 °F condensing temperature.

-40 -20 0 20 40 50 60

Evaporating temperature [°F]

Correction factor

DKRCC.PD.AXV.3A.02 | 19

Data sheet | Thermostatic expansion valves, type TGE 10, TGE 20, TGE 40

Capacity in kW. -40 – 15 °C
Opening superheat sh = 4 K SI units R452B

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

3 25 5.49 6.90 8.40 9.86 10.9 11.24 10.8

4 25 7.44 9.36 11.4 13.4 15.0 15.39 14.7

6 25 11.0 13.9 17.0 20.0 22.3 22.89 21.9

8 25 14.9 18.9 23.1 27.1 30.2 30.73 29.3

9 25 17.4 22.1 27.1 31.9 35.7 36.55 34.9

11 25 21.9 28.1 34.6 40.3 43.7 42.75 39.8

12.5 25 23.5 29.6 36.4 43.1 48.2 49.1 46.7

16 25 27.5 34.6 42.4 49.9 55.7 56.7 53.8

12.5 25 21.7 28.5 36.3 44.5 51.8 54.9 53.0

16 25 27.1 35.6 45.5 56.1 65.7 69.9 67.8

20 25 33.2 43.5 55.2 67.3 77.7 81.3 77.9

21 25 44.3 57.6 71.0 82.9 90.2 88.6 82.3

26 25 44.6 60.1 78.0 97.6 116 125 123

30 25 50.6 68.2 88.7 111 131 142 139

40 25 60.5 81.6 107 137 164 176 170

42 25 91.5 118 146 172 187 186 175

-40 -30 -20 -10 0 10 15

[°C]

Evaporating temperature [°C]

Capacity in kW. -40 – 15 °C
Opening superheat sh = 4 K SI units R452B

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

3 35 5.45 6.91 8.54 10.2 11.8 12.9 13.2

4 35 7.33 9.32 11.5 13.9 16.0 17.6 18.0

6 35 10.7 13.7 16.9 20.4 23.6 26.0 26.6

8 35 14.5 18.5 22.9 27.5 31.8 34.8 35.4

9 35 16.7 21.5 26.7 32.2 37.4 41.2 42.0

11 35 21.0 27.5 34.6 41.5 47.1 49.8 49.4

12.5 35 22.4 28.5 35.7 43.3 50.6 55.6 56.4

16 35 26.2 33.4 41.6 50.3 58.7 64.6 65.7

12.5 35 21.0 27.7 35.6 44.6 53.9 61.4 63.4

16 35 25.9 34.3 44.3 55.7 67.7 77.6 80.4

20 35 31.7 41.9 53.7 66.9 80.3 91.0 93.7

21 35 44.1 58.0 72.7 86.9 98.5 101 103

26 35 41.7 56.5 74.1 94.2 115 134 141

30 35 47.1 63.9 83.9 107 131 152 159

40 35 56.2 76.2 102 132 166 196 204

42 35 92.8 121 151 180 204 217 217

-40 -30 -20 -10 0 10 15

[°C]

Evaporating temperature [°C]

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R452B

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 75 1.56 2.00 2.47 2.90 3.14 3.12 2.91

4 75 2.11 2.72 3.36 3.95 4.30 4.27 3.99

6 75 3.13 4.04 5.01 5.89 6.40 6.35 5.93

8 75 4.26 5.51 6.82 7.99 8.63 8.53 7.93

9 75 4.96 6.43 7.99 9.42 10.2 10.2 9.46

11 75 6.24 8.18 10.2 11.8 12.3 11.8 10.7

12.5 75 6.69 8.63 10.8 12.7 13.8 13.6 12.7

16 75 7.84 10.1 12.5 14.7 15.9 15.7 14.6

12.5 75 6.18 8.33 10.8 13.3 15.1 15.3 14.4

16 75 7.71 10.4 13.6 16.9 19.3 19.5 18.5

20 75 9.47 12.8 16.4 20.1 22.6 22.6 21.2

21 75 12.6 16.7 20.9 24.2 25.4 24.5 22.2

26 75 12.8 17.7 23.4 29.5 34.3 35.0 33.5

30 75 14.5 20.1 26.7 33.6 38.9 39.7 37.9

40 75 17.3 24.1 32.4 41.5 48.4 48.9 45.7

42 75 25.9 34.4 42.9 50.0 52.9 51.6 47.2

Evaporating temperature [°F]

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R452B

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 95 1.55 2.01 2.53 3.06 3.52 3.67 3.75

4 95 2.08 2.71 3.42 4.15 4.78 5.00 5.11

6 95 3.05 3.99 5.04 6.12 7.06 7.39 7.55

8 95 4.10 5.38 6.80 8.24 9.46 9.88 10.1

9 95 4.75 6.25 7.94 9.67 11.2 11.7 12.0

11 95 5.97 8.02 10.3 12.4 13.8 14.1 14.0

12.5 95 6.35 8.32 10.6 13.0 15.1 15.8 16.0

16 95 7.44 9.73 12.4 15.1 17.6 18.4 18.6

12.5 95 5.97 8.11 10.7 13.6 16.4 17.5 18.0

16 95 7.36 10.0 13.3 17.0 20.6 22.1 22.9

20 95 9.01 12.2 16.0 20.3 24.4 25.9 26.6

21 95 12.5 16.9 21.6 25.9 28.9 29.5 29.1

26 95 11.8 16.6 22.3 28.7 35.3 38.2 40.2

30 95 13.4 18.7 25.2 32.6 40.0 43.2 45.4

40 95 16.0 22.4 30.6 40.7 51.2 55.6 58.2

42 95 26.4 35.3 44.8 53.7 60.2 61.8 61.6

Evaporating temperature [°F]

Subcooling correction factor 'fsub'

Subcooling [K] 2 4 10 15 20 25 30

Correction factor 0.98 1.00 1.06 1.11 1.16 1.21 1.26

Distributer correction factor 'fp' *

Pressure

drop [bar]

Δp

0 1 1 1 1 1 1 1

1 0.97 0.97 0.97 0.96 0.96 0.94 0.93

1.5 0.95 0.95 0.95 0.94 0.93 0.92 0.90

2 0.94 0.94 0.93 0.92 0.91 0.89 0.86

*Calculated at 32 °C condensing temperature.

-40 -30 -20 -10 0 10 15

Evaporating temperature [°C]

Correction factor

© Danfoss | DCS (az) | 2019.01

Subcooling correction factor 'fsub'

Subcooling [°F] 2 7 10 20 30 40 50

Correction factor 0.98 1.00 1.02 1.07 1.13 1.18 1.24

Distributer correction factor 'fp' *

Pressure

drop [psi]

Δp

0 1 1 1 1 1 1 1

15 0.97 0.97 0.96 0.96 0.95 0.94 0.93

25 0.95 0.94 0.94 0.93 0.92 0.90 0.88

30 0.94 0.93 0.93 0.92 0.90 0.88 0.86

*calculated at 90 °F condensing temperature.

-40 -20 0 20 40 50 60

Evaporating temperature [°F]

Correction factor

DKRCC.PD.AXV.3A.02 | 20

Data sheet | Thermostatic expansion valves, type TGE 10, TGE 20, TGE 40

Capacity in kW. -40 – 15 °C
Opening superheat sh = 4 K SI units R452B

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

3 45 5.30 6.76 8.41 10.2 12.0 13.5 14.2

4 45 7.07 9.05 11.3 13.7 16.1 18.3 19.2

6 45 10.2 13.1 16.4 20.0 23.6 26.8 28.1

8 45 13.6 17.6 22.0 26.7 31.4 35.6 37.2

9 45 15.7 20.3 25.5 31.2 36.8 42.0 44.0

11 45 19.7 26.1 33.4 40.9 47.6 52.4 53.7

12.5 45 20.7 26.7 33.6 41.5 49.6 56.9 59.5

16 45 24.3 31.2 39.2 48.3 57.7 66.4 69.8

12.5 45 19.9 26.3 33.9 42.7 52.5 62. 66.0

16 45 24.3 32.2 41.7 52.8 65.3 77.6 82.9

20 45 29.6 39.2 50.4 63.4 77.7 91.6 97.5

21 45 42.9 56.9 72.0 87.3 101 111 113

26 45 38.2 51.9 68.3 87.3 108 130 139

30 45 42.9 58.4 77.0 98.6 122 146 157

40 45 51.2 69.6 93.0 122 156 193 209

42 45 92.4 121 152 183 211 232 237

-40 -30 -20 -10 0 10 15

[°C]

Evaporating temperature [°C]

Capacity in kW. -40 – 15 °C
Opening superheat sh = 4 K SI units R452B

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

3 55 5.07 6.49 8.10 9.85 11.7 13.4 14.2

4 55 6.71 8.62 10.8 13.2 15.6 18.0 19.1

6 55 9.58 12.4 15.5 19.0 22.6 26.0 27.6

8 55 12.6 16.4 20.6 25.2 29.9 34.4 36.4

9 55 14.5 18.8 23.8 29.2 34.9 40.4 42.9

11 55 18.2 24.3 31.4 39.0 46.2 52.0 54.2

12.5 55 18.7 24.2 30.7 38.2 46.2 54.2 57.7

16 55 21.9 28.4 35.9 44.4 53.9 63.4 67.8

12.5 55 18.5 24.3 31.3 39.5 48.7 58.3 62.9

16 55 22.3 29.5 38.1 48.4 60.0 72.3 78.2

20 55 27.0 35.8 46.0 58.0 71.4 85.6 92.4

21 55 40.9 54.5 69.4 84.7 99.3 111 115

26 55 34.5 47.0 61.8 79.0 98.2 119 129

30 55 38.5 52.6 69.4 88.9 111 134 145

40 55 46.0 62.5 83.4 109 141 177 195

42 55 90.7 119 150 181 210 234 243

-40 -30 -20 -10 0 10 15

[°C]

Evaporating temperature [°C]

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R452B

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 115 1.50 1.96 2.49 3.05 3.60 3.85 4.05

4 115 2.00 2.62 3.34 4.11 4.86 5.20 5.49

6 115 2.88 3.81 4.86 5.99 7.10 7.60 8.02

8 115 3.84 5.08 6.49 8.00 9.45 10.1 10.6

9 115 4.42 5.87 7.54 9.34 11.1 11.9 12.6

11 115 5.56 7.59 9.90 12.3 14.2 14.9 15.3

12.5 115 5.82 7.70 9.94 12.5 15.0 16.1 17.0

16 115 6.82 9.02 11.6 14.5 17.5 18.8 19.9

12.5 115 5.61 7.62 10.1 13.0 16.1 17.5 18.8

16 115 6.84 9.33 12.4 16.0 20.0 21.9 23.6

20 115 8.32 11.4 15.0 19.2 23.7 25.9 27.8

21 115 12.1 16.6 21.4 26.2 30.2 31.6 32.3

26 115 10.7 15.1 20.3 26.5 33.2 36.5 39.7

30 115 12.0 17.0 22.9 29.9 37.5 41.2 44.7

40 115 14.4 20.2 27.8 37.3 49.0 54.3 59.6

42 115 26.2 35.3 45.1 54.8 63.0 66.0 67.9

Evaporating temperature [°F]

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R452B

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 135 1.42 1.87 2.38 2.94 3.51 3.78 4.03

4 135 1.88 2.48 3.17 3.92 4.69 5.07 5.41

6 135 2.67 3.55 4.55 5.65 6.77 7.31 7.82

8 135 3.52 4.69 6.02 7.47 8.94 9.63 10.3

9 135 4.02 5.39 6.96 8.68 10.5 11.3 12.1

11 135 5.06 6.99 9.24 11.6 13.8 14.7 15.4

12.5 135 5.18 6.89 8.95 11.3 13.9 15.1 16.2

16 135 6.06 8.07 10.44 13.2 16.2 17.7 19.1

12.5 135 5.14 6.96 9.17 11.8 14.7 16.2 17.6

16 135 6.19 8.43 11.2 14.4 18.2 20.1 21.9

20 135 7.50 10.2 13.5 17.3 21.5 23.7 25.9

21 135 11.5 15.7 20.4 25.3 29.6 31.3 32.6

26 135 9.56 13.5 18.1 23.6 29.7 32.9 36.0

30 135 10.7 15.1 20.4 26.5 33.4 37.0 40.5

40 135 12.7 17.9 24.5 33.0 43.3 48.9 54.6

42 135 25.6 34.5 44.2 54.0 62.7 66.3 69.2

Evaporating temperature [°F]

Subcooling correction factor 'fsub'

Subcooling [K] 2 4 10 15 20 25 30

Correction factor 0.98 1.00 1.06 1.11 1.16 1.21 1.26

Distributer correction factor 'fp' *

Pressure

drop [bar]

Δp

0 1 1 1 1 1 1 1

1 0.97 0.97 0.97 0.96 0.96 0.94 0.93

1.5 0.95 0.95 0.95 0.94 0.93 0.92 0.90

2 0.94 0.94 0.93 0.92 0.91 0.89 0.86

*Calculated at 32 °C condensing temperature.

-40 -30 -20 -10 0 10 15

Evaporating temperature [°C]

Correction factor

© Danfoss | DCS (az) | 2019.01

Subcooling correction factor 'fsub'

Subcooling [°F] 2 7 10 20 30 40 50

Correction factor 0.98 1.00 1.02 1.07 1.13 1.18 1.24

Distributer correction factor 'fp' *

Pressure

drop [psi]

Δp

0 1 1 1 1 1 1 1

15 0.97 0.97 0.96 0.96 0.95 0.94 0.93

25 0.95 0.94 0.94 0.93 0.92 0.90 0.88

30 0.94 0.93 0.93 0.92 0.90 0.88 0.86

*calculated at 90 °F condensing temperature.

-40 -20 0 20 40 50 60

Evaporating temperature [°F]

Correction factor

DKRCC.PD.AXV.3A.02 | 21

Data sheet | Thermostatic expansion valves, type TGE 10, TGE 20, TGE 40

Capacity in kW. -40 – 15 °C
Opening superheat sh = 4 K SI units R454B

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

3 25 6.54 8.24 10.0 11.7 12.8 12.7 11.7

4 25 8.84 11.2 13.6 15.9 17.5 17.3 15.9

6 25 13.1 16.5 20.2 23.6 26.0 25.7 23.6

8 25 17.7 22.4 27.4 32.0 35.0 34.3 31.4

9 25 20.6 26.2 32.1 37.6 41.4 40.8 37.5

11 25 26.1 33.5 40.9 47.1 50.1 47.1 42.2

12.5 25 27.4 35.0 43.2 50.9 56.2 55.4 50.9

16 25 32.1 40.9 50.3 59.0 65.0 64.0 58.5

12.5 25 28.3 36.6 45.8 55.2 62.7 63.7 59.3

16 25 34.2 44.3 55.7 67.5 77.2 79.0 73.8

20 25 41.9 54.0 67.2 80.4 90.6 91.0 83.9

21 25 56.3 71.2 85.6 97.4 103 97.4 87.4

26 25 54.4 70.7 89.5 109 126 131 123

30 25 61.8 80.4 102 124 144 149 140

40 25 74.1 96.4 123 153 178 182 168

42 25 109 136 164 188 202 193 175

-40 -30 -20 -10 0 10 15

[°C]

Evaporating temperature [°C]

Capacity in kW. -40 – 15 °C
Opening superheat sh = 4 K SI units R454B

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

3 35 6.56 8.36 10.3 12.4 14.2 15.3 15.3

4 35 8.81 11.3 13.9 16.7 19.2 20.8 20.8

6 35 12.9 16.5 20.5 24.6 28.3 30.6 30.6

8 35 17.3 22.2 27.5 33.0 37.9 40.6 40.5

9 35 20.0 25.8 32.1 38.7 44.7 48.2 48.2

11 35 25.4 33.2 41.6 49.7 55.7 57.3 55.7

12.5 35 26.2 34.0 42.7 51.8 60.0 64.9 65.0

16 35 30.7 39.7 49.7 60.2 69.7 75.6 75.8

12.5 35 27.5 35.7 45.2 55.8 66.1 73.7 74.9

16 35 33.0 42.9 54.6 67.7 80.9 90.8 92.6

20 35 40.3 52.3 65.9 80.9 95.6 106 107

21 35 56.6 72.6 88.8 104 115 118 115

26 35 51.7 67.6 86.5 108 131 148 152

30 35 58.4 76.5 98.1 123 148 168 172

40 35 70.1 91.7 119 152 187 213 217

42 35 111 141 172 202 226 236 232

-40 -30 -20 -10 0 10 15

[°C]

Evaporating temperature [°C]

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R454B

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 75 1.85 2.39 2.94 3.42 3.61 3.49 3.10

4 75 2.51 3.24 4.00 4.66 4.94 4.77 4.24

6 75 3.71 4.80 5.94 6.92 7.33 7.07 6.29

8 75 5.04 6.52 8.05 9.35 9.83 9.45 8.35

9 75 5.86 7.62 9.45 11.0 11.7 11.3 9.99

11 75 7.43 9.72 12.0 13.6 13.8 12.9 11.2

12.5 75 7.81 10.2 12.8 15.0 15.9 15.3 13.6

16 75 9.15 11.9 14.8 17.3 18.3 17.6 15.6

12.5 75 8.07 10.7 13.6 16.4 18.0 17.6 15.8

16 75 9.74 12.9 16.5 20.1 22.2 21.8 19.8

20 75 11.9 15.8 19.9 23.8 25.8 25.1 22.4

21 75 15.9 20.6 25.0 28.1 28.5 26.8 23.2

26 75 15.5 20.7 26.7 32.7 36.6 36.3 33.0

30 75 17.6 23.5 30.4 37.3 41.6 41.2 37.4

40 75 21.1 28.3 36.9 45.8 51.2 50.1 44.7

42 75 30.7 39.3 47.8 54.4 56.0 53.1 46.4

Evaporating temperature [°F]

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R454B

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 95 1.86 2.43 3.06 3.69 4.20 4.33 4.33

4 95 2.50 3.28 4.14 5.00 5.71 5.90 5.90

6 95 3.65 4.80 6.07 7.36 8.40 8.68 8.67

8 95 4.91 6.46 8.17 9.88 11.2 11.5 11.5

9 95 5.68 7.51 9.54 11.6 13.3 13.7 13.7

11 95 7.22 9.70 12.4 14.8 16.2 16.3 15.7

12.5 95 7.44 9.91 12.7 15.5 17.8 18.4 18.4

16 95 8.72 11.6 14.8 18.1 20.7 21.5 21.5

12.5 95 7.80 10.4 13.5 16.8 19.9 20.9 21.3

16 95 9.36 12.5 16.3 20.5 24.4 25.8 26.3

20 95 11.4 15.3 19.6 24.4 28.7 30.1 30.4

21 95 16.1 21.1 26.2 30.7 33.4 33.6 32.6

26 95 14.7 19.7 25.9 32.9 39.6 42.1 43.2

30 95 16.6 22.4 29.3 37.3 44.9 47.7 48.9

40 95 19.9 26.8 35.7 46.4 57.0 60.6 61.6

42 95 31.6 41.0 50.8 59.9 66.1 67.0 65.6

Evaporating temperature [°F]

Subcooling correction factor 'fsub'

Subcooling [K] 2 4 10 15 20 25 30

Correction factor 0.98 1.00 1.06 1.12 1.17 1.22 1.27

Distributer correction factor 'fp' *

Pressure

drop [bar]

Δp

0 1 1 1 1 1 1 1

1 0.97 0.97 0.97 0.96 0.96 0.94 0.93

1.5 0.96 0.95 0.95 0.94 0.93 0.91 0.89

2 0.94 0.94 0.93 0.92 0.91 0.88 0.85

*Calculated at 32 °C condensing temperature.

-40 -30 -20 -10 0 10 15

Evaporating temperature [°C]

Correction factor

© Danfoss | DCS (az) | 2019.01

Subcooling correction factor 'fsub'

Subcooling [°F] 2 7 10 20 30 40 50

Correction factor 0.97 1.00 1.02 1.08 1.13 1.19 1.25

Distributer correction factor 'fp' *

Pressure

drop [psi]

Δp

0 1 1 1 1 1 1 1

15 0.97 0.97 0.96 0.96 0.95 0.94 0.93

25 0.95 0.95 0.94 0.93 0.91 0.90 0.87

30 0.94 0.93 0.93 0.92 0.90 0.88 0.85

*calculated at 90 °F condensing temperature.

-40 -20 0 20 40 50 60

Evaporating temperature [°F]

Correction factor

DKRCC.PD.AXV.3A.02 | 22

Data sheet | Thermostatic expansion valves, type TGE 10, TGE 20, TGE 40

Capacity in kW. -40 – 15 °C
Opening superheat sh = 4 K SI units R454B

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

3 45 6.44 8.25 10.3 12.5 14.6 16.5 17.1

4 45 8.57 11.0 13.8 16.8 19.7 22.2 23.1

6 45 12.4 15.9 20.0 24.4 28.8 32.5 33.7

8 45 16.4 21.3 26.7 32.5 38.3 43.0 44.5

9 45 18.9 24.6 31.0 37.9 44.9 50.8 52.7

11 45 24.0 31.9 40.8 49.9 57.9 62.7 63.2

12.5 45 24.4 31.9 40.6 50.0 59.5 67.4 70.1

16 45 28.6 37.4 47.3 58.3 69.4 79.2 82.6

12.5 45 26.1 33.9 43.1 53.6 64.9 75.3 79.4

16 45 31.0 40.5 51.7 64.7 78.9 92.4 97.8

20 45 37.8 49.2 62.4 77.4 93.6 109 115

21 45 55.7 72.0 89.0 106 120 129 130

26 45 47.9 62.8 80.7 102 125 149 158

30 45 53.9 70.8 91.2 115 142 168 179

40 45 64.6 84.7 110 142 181 220 235

42 45 112 142 175 208 238 259 263

-40 -30 -20 -10 0 10 15

[°C]

Evaporating temperature [°C]

Capacity in kW. -40 – 15 °C
Opening superheat sh= 4 K SI units R454B

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

3 55 6.19 7.96 9.96 12.2 14.4 16.5 17.4

4 55 8.16 10.5 13.2 16.2 19.3 22.2 23.4

6 55 11.6 15.0 19.0 23.3 27.8 32.0 33.8

8 55 15.2 19.8 25.0 30.7 36.6 42.1 44.3

9 55 17.4 22.8 28.9 35.7 42.8 49.5 52.3

11 55 22.0 29.7 38.5 47.9 56.8 63.5 65.4

12.5 55 22.1 29.2 37.4 46.5 56.0 64.9 68.7

16 55 25.9 34.2 43.6 54.2 65.4 76.5 81.4

12.5 55 24.3 31.5 40.0 49.8 60.6 71.5 76.5

16 55 28.7 37.3 47.6 59.7 73.1 87.1 93.6

20 55 34.8 45.3 57.4 71.4 86.9 103 111

21 55 53.7 69.8 86.8 104 119 131 135

26 55 43.5 56.9 73.2 92.5 115 138 149

30 55 48.7 63.9 82.3 104 129 156 168

40 55 58.3 76.2 99.0 128 164 206 226

42 55 111 141 174 208 240 266 274

-40 -30 -20 -10 0 10 15

[°C]

Evaporating temperature [°C]

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R454B

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 115 1.82 2.40 3.05 3.75 4.41 4.69 4.89

4 115 2.42 3.20 4.08 5.04 5.95 6.33 6.61

6 115 3.49 4.62 5.92 7.33 8.68 9.23 9.64

8 115 4.63 6.16 7.89 9.75 11.5 12.2 12.7

9 115 5.32 7.11 9.17 11.4 13.5 14.4 15.1

11 115 6.76 9.27 12.1 15.0 17.2 17.9 18.1

12.5 115 6.85 9.24 12.0 15.0 17.9 19.1 20.0

16 115 8.03 10.8 14.0 17.5 21.0 22.5 23.6

12.5 115 7.35 9.82 12.8 16.2 19.7 21.3 22.6

16 115 8.74 11.7 15.3 19.6 24.1 26.2 27.9

20 115 10.6 14.2 18.5 23.3 28.5 30.9 32.8

21 115 15.8 20.9 26.3 31.5 35.5 36.8 37.2

26 115 13.5 18.2 23.9 30.8 38.4 42.0 45.1

30 115 15.1 20.5 27.0 34.8 43.4 47.4 50.9

40 115 18.2 24.5 32.8 43.5 56.0 62.1 67.2

42 115 31.8 41.4 51.8 62.2 70.9 73.9 75.4

Evaporating temperature [°F]

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R454B

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 135 1.74 2.29 2.93 3.63 4.34 4.66 4.94

4 135 2.29 3.03 3.89 4.83 5.79 6.24 6.63

6 135 3.24 4.32 5.56 6.93 8.34 8.99 9.56

8 135 4.24 5.68 7.32 9.13 11.0 11.8 12.5

9 135 4.84 6.52 8.46 10.6 12.8 13.8 14.7

11 135 6.11 8.53 11.3 14.3 16.9 17.9 18.6

12.5 135 6.13 8.34 10.9 13.8 16.7 18.1 19.3

16 135 7.17 9.75 12.7 16.1 19.6 21.4 23.0

12.5 135 6.76 9.02 11.7 14.8 18.2 19.9 21.5

16 135 7.97 10.7 13.9 17.8 22.0 24.2 26.3

20 135 9.66 12.9 16.8 21.2 26.1 28.7 31.1

21 135 15.1 20.1 25.5 30.8 35.3 37.0 38.2

26 135 12.0 16.2 21.4 27.5 34.6 38.2 41.7

30 135 13.5 18.2 24.0 31.0 39.0 43.1 47.0

40 135 16.1 21.7 28.9 38.4 50.3 56.9 63.4

42 135 31.2 40.8 51.2 61.8 71.5 75.3 78.1

Evaporating temperature [°F]

Subcooling correction factor 'fsub'

Subcooling [K] 2 4 10 15 20 25 30

Correction factor 0.98 1.00 1.06 1.12 1.17 1.22 1.27

Distributer correction factor 'fp' *

Pressure

drop [bar]

Δp

0 1 1 1 1 1 1 1

1 0.97 0.97 0.97 0.96 0.96 0.94 0.93

1.5 0.96 0.95 0.95 0.94 0.93 0.91 0.89

2 0.94 0.94 0.93 0.92 0.91 0.88 0.85

*Calculated at 32 °C condensing temperature.

-40 -30 -20 -10 0 10 15

Evaporating temperature [°C]

Correction factor

© Danfoss | DCS (az) | 2019.01

Subcooling correction factor 'fsub'

Subcooling [°F] 2 7 10 20 30 40 50

Correction factor 0.97 1.00 1.02 1.08 1.13 1.19 1.25

Distributer correction factor 'fp' *

Pressure

drop [psi]

Δp

0 1 1 1 1 1 1 1

15 0.97 0.97 0.96 0.96 0.95 0.94 0.93

25 0.95 0.95 0.94 0.93 0.91 0.90 0.87

30 0.94 0.93 0.93 0.92 0.90 0.88 0.85

*calculated at 90 °F condensing temperature.

-40 -20 0 20 40 50 60

Evaporating temperature [°F]

Correction factor

DKRCC.PD.AXV.3A.02 | 23

Data sheet | Thermostatic expansion valves, type TGE 10, TGE 20, TGE 40

Capacity in kW. -40 – 15 °C
Opening superheat sh = 4 K SI units R22

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

3 25 4.39 5.68 7.02 8.22 8.97 8.70 7.90

4 25 5.94 7.70 9.54 11.2 12.2 11.9 10.8

6 25 8.76 11.4 14.1 16.6 18.1 17.5 15.9

8 25 11.9 15.5 19.1 22.3 24.2 23.2 20.9

9 25 13.9 18.1 22.5 26.4 28.8 27.7 25.0

11 25 17.7 23.1 28.4 32.4 33.8 31.1 27.7

12.5 25 17.8 23.2 29.0 34.2 37.5 36.4 32.7

16 25 21.0 27.2 33.7 39.7 43.4 42.0 37.4

12.5 25 16.5 21.9 28.0 34.1 38.7 38.9 36.0

16 25 20.7 27.5 35.3 43.2 49.2 49.8 46.2

20 25 25.6 33.7 42.7 51.5 57.7 57.1 52.3

21 25 33.6 43.5 53.1 61.0 64.7 60.3 53.4

26 25 34.6 46.5 60.2 74.5 85.9 87.4 80.8

30 25 39.4 52.9 68.6 84.8 97.7 99.1 91.5

40 25 47.3 63.7 83.3 104 121 121 109

42 25 67.2 86.8 107 124 132 125 111

-40 -30 -20 -10 0 10 15

[°C]

Evaporating temperature [°C]

Capacity in kW. -40 – 15 °C
Opening superheat sh = 4 K SI units R22

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

3 35 4.44 5.81 7.30 8.79 10.1 10.7 10.6

4 35 5.96 7.82 9.86 11.9 13.6 14.5 14.4

6 35 8.69 11.4 14.5 17.5 20.0 21.3 21.1

8 35 11.7 15.4 19.4 23.4 26.7 28.1 27.6

9 35 13.6 18.0 22.7 27.6 31.6 33.6 33.2

11 35 17.3 23.2 29.3 34.8 38.2 38.4 36.9

12.5 35 17.3 22.9 29.2 35.4 40.6 43.2 43.0

16 35 20.4 26.8 34.0 41.1 47.1 50.2 50.0

12.5 35 16.3 21.7 28.1 35.1 41.8 46.1 46.5

16 35 20.2 27.0 35.1 44.1 52.8 58.6 59.3

20 35 25.0 33.1 42.5 52.8 62.4 68.1 68.2

21 35 34.1 44.6 55.6 65.8 73.2 75.0 72.7

26 35 33.0 44.6 58.6 74.5 90.4 102 104

30 35 37.4 50.6 66.5 84.6 103 115 117

40 35 45.0 61.0 81.2 105 130 146 146

42 35 69.3 90.4 113 134 151 156 152

-40 -30 -20 -10 0 10 15

[°C]

Evaporating temperature [°C]

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R22

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 75 1.24 1.65 2.06 2.40 2.50 2.39 2.09

4 75 1.68 2.24 2.80 3.27 3.42 3.27 2.86

6 75 2.49 3.31 4.15 4.84 5.06 4.82 4.21

8 75 3.38 4.50 5.62 6.51 6.74 6.39 5.54

9 75 3.96 5.28 6.62 7.71 8.03 7.63 6.59

11 75 5.02 6.73 8.30 9.31 9.21 8.55 7.33

12.5 75 5.07 6.77 8.56 10.0 10.5 10.0 8.57

16 75 5.96 7.91 9.94 11.6 12.2 11.6 9.79

12.5 75 4.70 6.40 8.32 10.1 11.0 10.7 9.58

16 75 5.89 8.05 10.5 12.8 14.1 13.7 12.3

20 75 7.28 9.85 12.7 15.2 16.3 15.8 13.9

21 75 9.51 12.6 15.5 17.6 17.8 16.6 14.0

26 75 9.86 13.6 18.0 22.3 24.7 24.1 21.5

30 75 11.2 15.5 20.5 25.4 28.0 27.4 24.3

40 75 13.5 18.7 25.0 31.3 34.5 33.2 28.9

42 75 19.0 25.1 31.2 35.8 36.4 34.1 29.1

Evaporating temperature [°F]

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R22

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 95 1.26 1.70 2.17 2.63 2.96 3.03 2.99

4 95 1.69 2.28 2.93 3.56 4.03 4.12 4.07

6 95 2.47 3.34 4.30 5.23 5.91 6.04 5.96

8 95 3.32 4.49 5.77 6.99 7.84 7.98 7.82

9 95 3.85 5.25 6.77 8.25 9.33 9.54 9.39

11 95 4.92 6.78 8.70 10.3 11.0 10.9 10.4

12.5 95 4.93 6.70 8.69 10.6 12.0 12.3 12.2

16 95 5.79 7.84 10.1 12.3 13.9 14.3 14.2

12.5 95 4.63 6.34 8.41 10.6 12.5 13.1 13.2

16 95 5.75 7.90 10.5 13.4 15.9 16.7 16.8

20 95 7.09 9.67 12.7 16.0 18.6 19.4 19.3

21 95 9.67 13.0 16.5 19.5 21.3 21.3 20.5

26 95 9.37 13.1 17.6 22.7 27.4 28.9 29.4

30 95 10.6 14.8 20.0 25.8 31.1 32.7 33.2

40 95 12.8 17.9 24.5 32.3 39.3 41.3 41.3

42 95 19.7 26.4 33.5 39.9 44.0 44.2 42.8

Evaporating temperature [°F]

Subcooling correction factor 'fsub'

Subcooling [K] 2 4 10 15 20 25 30

Correction factor 0.98 1.00 1.05 1.10 1.14 1.18 1.23

Distributer correction factor 'fp' *

Pressure

drop [bar]

Δp

0 1 1 1 1 1 1 1

1 0.96 0.95 0.95 0.94 0.93 0.91 0.89

1.5 0.93 0.93 0.92 0.91 0.90 0.86 0.82

2 0.91 0.90 0.90 0.88 0.86 0.81 0.76

*Calculated at 32 °C condensing temperature.

-40 -30 -20 -10 0 10 15

Evaporating temperature [°C]

Correction factor

© Danfoss | DCS (az) | 2019.01

Subcooling correction factor 'fsub'

Subcooling [°F] 2 7 10 20 30 40 50

Correction factor 0.98 1.00 1.01 1.06 1.11 1.16 1.21

Distributer correction factor 'fp' *

Pressure

drop [psi]

Δp

0 1 1 1 1 1 1 1

15 0.95 0.95 0.95 0.94 0.92 0.91 0.88

25 0.92 0.92 0.91 0.89 0.87 0.84 0.79

30 0.91 0.90 0.89 0.87 0.84 0.80 0.74

*calculated at 90 °F condensing temperature.

-40 -20 0 20 40 50 60

Evaporating temperature [°F]

Correction factor

DKRCC.PD.AXV.3A.02 | 24

Data sheet | Thermostatic expansion valves, type TGE 10, TGE 20, TGE 40

Capacity in kW. -40 – 15 °C
Opening superheat sh = 4 K SI units R22

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

3 45 4.39 5.79 7.35 9.00 10.6 11.8 12.1

4 45 5.84 7.73 9.85 12.1 14.3 15.9 16.4

6 45 8.40 11.2 14.3 17.6 20.8 23.2 23.8

8 45 11.2 14.9 19.0 23.4 27.5 30.5 31.2

9 45 12.9 17.3 22.2 27.4 32.5 36.4 37.4

11 45 16.5 22.5 29.1 35.5 40.6 42.9 42.7

12.5 45 16.3 21.9 28.3 35.1 41.4 46.2 47.8

16 45 19.2 25.6 33.1 40.9 48.2 54.1 56.0

12.5 45 15.7 20.9 27.2 34.5 42.1 48.8 51.2

16 45 19.4 25.8 33.7 42.9 52.8 61.6 64.8

20 45 23.8 31.6 40.9 51.5 62.7 72.4 75.5

21 45 33.8 44.7 56.3 67.9 77.8 83.6 84.2

26 45 30.8 41.7 55.1 71.0 88.5 105 111

30 45 34.7 47.1 62.3 80.4 100 119 126

40 45 41.7 56.7 76.1 101 129 155 164

42 45 70.1 91.9 116 140 161 175 176

-40 -30 -20 -10 0 10 15

[°C]

Evaporating temperature [°C]

Capacity in kW. -40 – 15 °C
Opening superheat sh= 4 K SI units R22

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

3 55 4.26 5.64 7.21 8.91 10.6 12.2 12.7

4 55 5.61 7.46 9.57 11.9 14.2 16.3 17.1

6 55 7.95 10.6 13.7 17.1 20.5 23.6 24.7

8 55 10.4 14.0 18.1 22.5 27.0 30.9 32.2

9 55 11.9 16.2 21.0 26.3 31.7 36.6 38.5

11 55 15.3 21.2 27.9 34.8 40.9 44.9 45.7

12.5 55 14.8 20.2 26.5 33.4 40.3 46.4 49.0

16 55 17.4 23.6 31.0 39.0 47.2 54.6 57.9

12.5 55 14.9 19.7 25.6 32.7 40.5 48.2 51.5

16 55 18.2 24.1 31.5 40.3 50.3 60.2 64.6

20 55 22.3 29.5 38.2 48.4 59.9 71.2 76.0

21 55 32.9 43.7 55.6 67.7 78.9 87.3 89.6

26 55 28.2 38.1 50.4 65.3 82.4 100 109

30 55 31.6 42.9 56.8 73.7 93.1 113 123

40 55 37.8 51.4 69.1 92.1 120 151 165

42 55 69.9 91.8 116 142 165 183 189

-40 -30 -20 -10 0 10 15

[°C]

Evaporating temperature [°C]

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R22

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 115 1.24 1.69 2.19 2.71 3.19 3.37 3.48

4 115 1.65 2.25 2.93 3.65 4.30 4.55 4.70

6 115 2.37 3.25 4.25 5.30 6.26 6.61 6.83

8 115 3.15 4.33 5.65 7.04 8.26 8.70 8.93

9 115 3.63 5.02 6.60 8.26 9.79 10.4 10.7

11 115 4.65 6.56 8.66 10.6 12.0 12.3 12.3

12.5 115 4.59 6.36 8.42 10.6 12.4 13.2 13.7

16 115 5.39 7.45 9.83 12.3 14.5 15.4 16.1

12.5 115 4.45 6.08 8.11 10.5 12.9 13.9 14.7

16 115 5.46 7.50 10.1 13.1 16.2 17.5 18.6

20 115 6.72 9.17 12.2 15.6 19.1 20.6 21.6

21 115 9.57 13.0 16.7 20.3 23.1 23.9 24.2

26 115 8.66 12.1 16.4 21.6 27.2 29.7 31.8

30 115 9.76 137 18.6 24.5 30.8 33.6 35.9

40 115 11.7 16.5 22.8 30.9 40.0 44.1 46.9

42 115 19.9 26.9 34.5 42.1 48.1 50.0 50.6

Evaporating temperature [°F]

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R22

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 135 1.20 1.64 2.14 2.68 3.22 3.45 3.64

4 135 1.57 2.16 2.83 3.57 4.30 4.63 4.90

6 135 2.22 3.07 4.05 5.13 6.19 6.66 7.05

8 135 2.91 4.04 5.33 6.75 8.13 8.72 9.18

9 135 3.32 4.65 6.19 7.87 9.57 10.3 11.0

11 135 4.26 6.13 8.26 10.4 12.2 12.8 13.1

12.5 135 4.09 5.78 7.80 10.0 12.1 13.1 14.0

16 135 4.80 6.77 9.12 11.7 14.2 15.4 16.5

12.5 135 4.19 5.68 7.57 9.84 12.3 13.5 14.6

16 135 5.08 6.93 9.30 12.2 15.3 16.9 18.3

20 135 6.22 8.46 11.2 14.6 18.2 20.0 21.6

21 135 9.26 12.7 16.5 20.3 23.6 24.8 25.6

26 135 7.83 10.9 14.8 19.7 25.2 28.0 30.6

30 135 8.77 12.3 16.7 22.2 28.4 31.6 34.6

40 135 10.5 14.7 20.4 28.0 37.4 42.3 46.8

42 135 19.8 26.7 34.5 42.5 49.6 52.3 54.1

Evaporating temperature [°F]

Subcooling correction factor 'fsub'

Subcooling [K] 2 4 10 15 20 25 30

Correction factor 0.98 1.00 1.05 1.10 1.14 1.18 1.23

Distributer correction factor 'fp' *

Pressure

drop [bar]

Δp

0 1 1 1 1 1 1 1

1 0.96 0.95 0.95 0.94 0.93 0.91 0.89

1.5 0.93 0.93 0.92 0.91 0.90 0.86 0.82

2 0.91 0.90 0.90 0.88 0.86 0.81 0.76

*Calculated at 32 °C condensing temperature.

-40 -30 -20 -10 0 10 15

Evaporating temperature [°C]

Correction factor

© Danfoss | DCS (az) | 2019.01

Subcooling correction factor 'fsub'

Subcooling [°F] 2 7 10 20 30 40 50

Correction factor 0.98 1.00 1.01 1.06 1.11 1.16 1.21

Distributer correction factor 'fp' *

Pressure

drop [psi]

Δp

0 1 1 1 1 1 1 1

15 0.95 0.95 0.95 0.94 0.92 0.91 0.88

25 0.92 0.92 0.91 0.89 0.87 0.84 0.79

30 0.91 0.90 0.89 0.87 0.84 0.80 0.74

*Calculated at 90 °F condensing temperature.

-40 -20 0 20 40 50 60

Evaporating temperature [°F]

Correction factor

DKRCC.PD.AXV.3A.02 | 25

Data sheet | Thermostatic expansion valves, type TGE 10, TGE 20, TGE 40

Capacity in kW. -40 – 15 °C.
Opening superheat sh = 4 K SI units R134a

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

3 25 2.44 3.10 3.85 4.62 5.23 5.31 4.92

4 25 3.33 4.24 5.27 6.33 7.18 7.30 6.77

6 25 5.00 6.37 7.92 9.52 10.8 11.0 10.2

8 25 6.90 8.78 10.9 13.1 14.7 14.9 13.7

9 25 8.11 10.3 12.8 15.4 17.5 17.8 16.4

11 25 10.5 13.0 16.1 19.1 21.2 20.8 18.9

12.5 25 11.2 14.1 17.5 21.0 23.8 24.2 22.3

16 25 13.2 16.5 20.4 24.4 27.5 27.8 25.6

12.5 25 10.6 14.0 17.9 22.3 26.1 27.3 25.6

16 25 13.4 17.6 22.7 28.4 33.4 35.0 32.9

20 25 16.6 21.8 27.8 34.2 39.6 40.8 37.9

21 25 21.0 27.1 33.9 40.5 45.0 44.0 39.8

26 25 22.1 29.1 37.6 47.2 55.9 59.2 56.0

30 25 25.3 33.3 43.0 53.9 63.8 67.5 63.8

40 25 30.5 40.0 51.7 65.0 77.5 81.9 76.6

42 25 39.7 50.8 63.7 76.7 86.1 85.7 78.2

-40 -30 -20 -10 0 10 15

[°C]

Evaporating temperature [°C]

Capacity in kW. -40 – 15 °C.
Opening superheat sh = 4 K SI units R134a

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

3 35 2.46 3.16 3.99 4.92 5.84 6.49 6.59

4 35 3.34 4.29 5.43 6.70 7.97 8.89 9.02

6 35 4.96 6.39 8.09 10.0 11.9 13.3 13.5

8 35 6.79 8.75 11.1 13.6 16.5 17.9 18.1

9 35 7.99 10.3 13.0 16.1 19.1 21.2 21.5

11 35 9.95 12.9 16.4 20.2 23.6 25.4 25.3

12.5 35 11.0 13.9 17.6 21.6 25.7 28.6 29.0

16 35 12.8 16.3 20.5 25.2 29.8 33.0 33.5

12.5 35 10.5 13.8 18.0 22.9 28.2 32.4 33.3

16 35 13.1 17.3 22.6 29.0 35.7 41.3 42.6

20 35 16.1 21.4 27.7 35.0 42.6 48.4 49.5

21 35 21.2 27.7 35.3 43.3 50.2 53.8 53.4

26 35 21.2 28.1 36.9 47.4 59.0 68.7 71.3

30 35 24.1 32.1 42.0 54.1 67.2 78.3 81.1

40 35 29.2 38.6 50.6 65.5 82.3 96.6 99.9

42 35 40.7 52.7 67.0 82.6 96.8 105 106

-40 -30 -20 -10 0 10 15

[°C]

Evaporating temperature [°C]

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R134a

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 75 0.69 0.90 1.14 1.36 1.49 1.46 1.30

4 75 0.94 1.23 1.56 1.87 2.05 2.01 1.79

6 75 1.42 1.85 2.34 2.81 3.08 3.01 2.69

8 75 1.96 2.55 3.22 3.85 4.20 4.09 3.64

9 75 2.30 2.99 3.79 4.56 5.00 4.90 4.33

11 75 2.89 3.77 4.74 5.61 5.95 5.70 4.98

12.5 75 3.19 4.10 5.16 6.20 6.80 6.66 5.89

16 75 3.74 4.80 6.02 7.20 7.85 7.67 6.75

12.5 75 3.02 4.07 5.35 6.68 7.56 7.51 6.81

16 75 3.81 5.16 6.79 8.51 9.68 9.65 8.77

20 75 4.71 6.36 8.27 10.2 11.4 11.2 10.1

21 75 5.94 7.86 10.0 11.9 12.6 12.1 10.5

26 75 6.30 8.53 11.3 14.2 16.3 16.4 15.0

30 75 7.20 9.76 12.9 16.2 18.6 18.7 17.0

40 75 8.70 11.7 15.5 19.6 22.6 22.6 20.3

42 75 11.2 14.7 18.8 22.6 24.3 23.5 20.6

Evaporating temperature [°F]

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R134a

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 95 0.70 0.92 1.19 1.49 1.76 1.84 1.87

4 95 0.95 1.25 1.62 2.03 2.40 2.52 2.56

6 95 1.41 1.87 2.41 3.03 3.58 3.77 3.82

8 95 1.93 2.55 3.30 4.12 4.86 5.09 5.14

9 95 2.27 2.99 3.88 4.86 5.73 6.02 6.10

11 95 2.83 3.77 4.89 6.08 7.02 7.23 7.15

12.5 95 3.11 4.06 5.23 6.54 7.72 8.11 8.24

16 95 3.64 4.76 6.12 7.61 8.94 9.37 9.51

12.5 95 2.97 4.04 5.40 7.01 8.60 9.19 9.47

16 95 3.71 5.07 6.80 8.87 10.9 11.7 12.1

20 95 4.58 6.25 8.30 10.7 12.9 13.7 14.1

21 95 6.02 8.10 10.5 13.0 14.9 15.3 15.1

26 95 6.02 8.23 11.1 14.6 18.1 19.5 20.3

30 95 6.85 9.38 12.7 16.6 20.6 22.22 23.1

40 95 8.29 11.3 15.2 20.2 25.4 27.4 28.4

42 95 11.6 15.4 20.0 24.9 28.9 29.9 29.9

Evaporating temperature [°F]

Subcooling correction factor 'fsub'

Subcooling [K] 2 4 10 15 20 25 30

Correction factor 0.98 1.00 1.06 1.11 1.16 1.21 1.26

Distributer correction factor 'fp' *

Pressure

drop [bar]

Δp

0 1 1 1 1 1 1 1

1 0.93 0.93 0.92 0.92 0.90 0.87 0.83

1.5 0.90 0.89 0.88 0.87 0.84 0.79 0.74

2 0.86 0.85 0.84 0.82 0.79 0.71 0.62

*Calculated at 32 °C condensing temperature.

-40 -30 -20 -10 0 10 15

Evaporating temperature [°C]

Correction factor

© Danfoss | DCS (az) | 2019.01

Subcooling correction factor 'fsub'

Subcooling [°F] 2 7 10 20 30 40 50

Correction factor 0.97 1.00 1.02 1.07 1.13 1.19 1.24

Distributer correction factor 'fp' *

Pressure

drop [psi]

Δp

0 1 1 1 1 1 1 1

15 0.93 0.93 0.92 0.91 0.89 0.86 0.82

25 0.88 0.87 0.86 0.84 0.80 0.76 0.68

30 0.86 0.85 0.83 0.81 0.75 0.70 0.60

*Calculated at 90 °F condensing temperature.

-40 -20 0 20 40 50 60

Evaporating temperature [°F]

Correction factor

DKRCC.PD.AXV.3A.02 | 26

Data sheet | Thermostatic expansion valves, type TGE 10, TGE 20, TGE 40

Capacity in kW. -40 – 15 °C.
Opening superheat sh = 4 K SI units R134a

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

3 45 2.41 3.12 3.98 5.00 6.10 7.13 7.52

4 45 3.25 4.21 5.39 6.78 8.29 9.71 10.3

6 45 4.78 6.21 7.96 10.0 12.3 14.4 15.2

8 45 6.48 8.44 10.8 13.5 16.6 19.4 20.4

9 45 7.60 9.85 12.7 15.0 19.5 22.7 23.9

11 45 9.44 12.4 16.1 20.3 24.6 28.1 29.0

12.5 45 10.3 13.3 17.0 21.3 26.1 30.4 32.1

16 45 12.1 15.6 19.9 24.9 30.3 35.3 37.1

12.5 45 10.0 13.3 17.4 22.5 28.3 34.2 36.6

16 45 12.4 16.5 21.7 28.1 35.6 43.3 46.5

20 45 15.3 20.3 26.5 34.0 42.6 51.1 54.5

21 45 20.8 27.4 35.5 44.3 52.8 59.2 60.9

26 45 19.7 26.2 34.7 45.3 58.0 71.0 76.7

30 45 22.3 29.8 39.4 51.6 65.9 80.7 87.1

40 45 27.0 35.9 47.6 62.7 81.4 102 110

42 45 40.6 52.9 68.0 85.3 103 117 121

-40 -30 -20 -10 0 10 15

[°C]

Evaporating temperature [°C]

Capacity in kW. -40 – 15 °C.
Opening superheat sh = 4 K SI units R134a

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

3 55 2.31 3.00 3.86 4.89 6.07 7.29 7.85

4 55 3.09 4.02 5.18 6.59 8.20 9.88 10.6

6 55 4.48 5.86 7.57 9.65 12.0 14.5 15.7

8 55 6.00 7.88 10.2 13.0 16.2 19.5 20.9

9 55 6.95 9.11 11.9 15.2 19.0 22.8 24.6

11 55 8.68 11.6 15.2 19.6 24.4 28.8 30.5

12.5 55 9.30 12.1 15.7 20.1 25.2 30.3 32.7

16 55 10.9 14.2 18.4 23.5 29.3 35.3 38.0

12.5 55 9.41 12.4 16.3 21.1 27.0 33.5 36.6

16 55 11.5 15.3 20.1 26.2 33.7 42.0 46.1

20 55 14.1 18.7 24.6 31.8 40.4 49.9 54.4

21 55 19.7 26.3 34.4 43.7 53.1 61.2 64.3

26 55 17.7 23.7 31.5 41.5 53.9 68.0 74.9

30 55 20.0 26.8 35.6 47.0 61.1 77.1 85.0

40 55 24.2 32.3 43.0 57.2 75.9 98.5 110

42 55 39.3 51.6 67.0 85.0 104.0 121 128

-40 -30 -20 -10 0 10 15

[°C]

Evaporating temperature [°C]

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R134a

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 115 0.68 0.91 1.19 1.52 1.88 2.04 2.16

4 115 0.92 1.23 1.61 2.06 2.55 2.77 2.95

6 115 1.35 1.81 2.37 3.05 3.78 4.10 4.36

8 115 1.83 2.45 3.22 4.13 5.09 5.52 5.85

9 115 2.14 2.86 3.78 4.86 5.98 6.47 6.87

11 115 2.66 3.61 4.80 6.18 7.51 8.02 8.33

12.5 115 2.90 3.84 5.05 6.48 7.99 8.66 9.20

16 115 3.40 4.51 5.91 7.55 9.27 10.0 10.7

12.5 115 2.83 3.85 5.20 6.88 8.79 9.72 10.5

16 115 3.50 4.79 6.48 8.62 11.1 12.3 13.3

20 115 4.30 5.89 7.92 10.4 13.2 14.5 15.6

21 115 5.88 8.00 10.6 13.4 16.0 16.9 17.5

26 115 5.53 7.61 10.4 13.9 18.1 20.1 22.0

30 115 6.26 8.64 11.8 15.8 20.5 22.9 24.9

40 115 7.59 10.4 14.2 19.3 25.6 28.9 31.6

42 115 11.5 15.4 20.4 25.9 31.2 33.3 34.8

Evaporating temperature [°F]

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R134a

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 135 0.65 0.87 1.14 1.48 1.87 2.06 2.25

4 135 0.86 1.16 1.53 2.00 2.52 2.79 3.04

6 135 1.25 1.68 2.24 2.92 3.70 4.10 4.46

8 135 1.67 2.26 3.00 3.92 4.96 5.48 5.96

9 135 1.92 2.60 3.49 4.60 5.83 6.44 7.01

11 135 2.41 3.32 4.49 5.92 7.46 8.16 8.71

12.5 135 2.56 3.45 4.61 6.06 7.71 8.54 9.30

16 135 3.00 4.05 5.40 7.08 8.98 9.93 10.8

12.5 135 2.62 3.56 4.81 6.41 8.35 9.39 10.4

16 135 3.21 4.37 5.93 7.96 10.4 11.8 13.1

20 135 3.91 5.37 7.24 9.60 12.4 14.0 15.4

21 135 5.51 7.59 10.2 13.2 16.1 17.4 18.4

26 135 4.90 6.76 9.27 12.6 16.7 18.9 21.2

30 135 5.51 7.63 10.5 14.2 18.9 21.5 24.0

40 135 6.67 9.20 12.7 17.4 23.8 27.5 31.2

42 135 11.0 15.0 20.0 25.8 31.8 34.5 36.9

Evaporating temperature [°F]

Subcooling correction factor 'fsub'

Subcooling [K] 2 4 10 15 20 25 30

Correction factor 0.98 1.00 1.06 1.11 1.16 1.21 1.26

Distributer correction factor 'fp' *

Pressure

drop [bar]

Δp

0 1 1 1 1 1 1 1

1 0.93 0.93 0.92 0.92 0.90 0.87 0.83

1.5 0.90 0.89 0.88 0.87 0.84 0.79 0.74

2 0.86 0.85 0.84 0.82 0.79 0.71 0.62

*Calculated at 32 °C condensing temperature.

-40 -30 -20 -10 0 10 15

Evaporating temperature [°C]

Correction factor

© Danfoss | DCS (az) | 2019.01

Subcooling correction factor 'fsub'

Subcooling [°F] 2 7 10 20 30 40 50

Correction factor 0.97 1.00 1.02 1.07 1.13 1.19 1.24

Distributer correction factor 'fp' *

Pressure

drop [psi]

Δp

0 1 1 1 1 1 1 1

15 0.93 0.93 0.92 0.91 0.89 0.86 0.82

25 0.88 0.87 0.86 0.84 0.80 0.76 0.68

30 0.86 0.85 0.83 0.81 0.75 0.70 0.60

*Calculated at 90 °F condensing temperature.

-40 -20 0 20 40 50 60

Evaporating temperature [°F]

Correction factor

DKRCC.PD.AXV.3A.02 | 27

Data sheet | Thermostatic expansion valves, type TGE 10, TGE 20, TGE 40

Capacity in kW. -30 – 10 °C.
Opening superheat sh = 4 K SI units R1234ze

Valve
type

TGE 10

TGE 20

TGE 40

Orice

Cond.

no.

temp.

[°C]

3 25 2.45 3.20 3.94 4.51 4.56

4 25 3.33 4.36 5.39 6.19 6.28

6 25 4.97 6.52 8.07 9.25 9.35

8 25 6.79 8.91 11.0 12.6 12.6

9 25 7.94 10.5 13.0 14.9 15.0

11 25 10.0 13.2 16.1 18.0 17.4

12.5 25 10.7 14.2 17.7 20.3 20.5

16 25 12.5 16.5 20.5 23.5 23.6

12.5 25 5.52 9.56 14.2 18.7 20.7

16 25 6.86 12.0 18.0 23.8 26.6

20 25 8.82 15.3 22.1 28.3 31.0

21 25 9.57 19.0 27.2 32.9 33.8

26 25 20.1 28.1 37.1 45.6 48.8

30 25 22.9 32.0 42.4 52.0 55.6

40 25 27.5 38.5 51.3 63.4 67.4

42 25 35.6 47.7 59.8 68.7 69.1

Evaporating temperature [°C]

-30 -20 -10 0 10

Capacity in kW. -30 – 10 °C.
Opening superheat sh = 4 K SI units R1234ze

Valve
type

TGE 10

TGE 20

TGE 40

Orice

Cond.

no.

temp.

[°C]

3 35 2.46 3.28 4.17 5.01 5.60

4 35 3.32 4.44 5.66 6.83 7.65

6 35 4.90 6.59 8.42 10.2 11.4

8 35 6.64 8.93 11.4 13.7 15.3

9 35 7.72 10.4 13.4 16.2 18.2

11 35 9.82 13.3 17.0 20.1 21.5

12.5 35 10.2 14.0 18.0 22.0 24.6

16 35 12.0 16.3 21.0 25.5 28.5

12.5 35 5.35 9.41 14.4 19.8 24.4

16 35 6.55 11.7 18.0 25.0 31.0

20 35 8.06 14.7 22.1 29.8 36.2

21 35 9.04 19.3 28.7 36.6 41.4

26 35 19.1 27.0 36.7 47.4 56.7

30 35 21.6 30.6 41.7 54.0 64.4

40 35 25.9 36.9 50.8 66.9 80.6

42 35 36.3 49.6 64.0 77.3 85.5

Evaporating temperature [°C]

-30 -20 -10 0 10

Capactiy in TR. -22 – 50 °F
Opening superheat sh = 7.2 °F US units R1234ze

Valve
type

TGE 10

TGE 20

TGE 40

Orice

Cond.

no.

temp.

3 75 0.61 0.72 0.95 1.17 1.28 1.25

4 75 0.82 0.97 1.30 1.60 1.77 1.72

6 75 1.23 1.46 1.94 2.40 2.64 2.57

8 75 1.68 1.99 2.66 3.27 3.57 3.46

9 75 1.96 2.33 3.12 3.86 4.24 4.12

11 75 2.48 2.95 3.93 4.75 5.02 4.76

12.5 75 2.63 3.14 4.23 5.26 5.80 5.63

16 75 3.09 3.67 4.92 6.09 6.69 6.49

12.5 75 1.13 1.69 2.99 4.46 5.60 5.71

16 75 1.40 2.10 3.77 5.65 7.15 7.32

20 75 1.78 2.71 4.76 6.86 8.41 8.54

21 75 1.49 3.03 5.93 8.28 9.48 9.29

26 75 4.88 5.97 8.53 11.4 13.4 13.5

30 75 5.56 6.80 9.73 13.0 15.3 15.3

40 75 6.67 8.16 11.7 15.7 18.6 18.5

42 75 8.65 10.4 14.2 17.8 19.5 18.9

-30 -20 0 20 40 50

[°F]

Evaporating temperature [°F]

Capactiy in TR. -22 – 50 °F
Opening superheat sh = 7.2 °F US units R1234ze

Valve
type

TGE 10

TGE 20

TGE 40

Orice

Cond.

no.

temp.

3 95 0.60 0.72 0.99 1.27 1.51 1.59

4 95 0.82 0.98 1.34 1.72 2.06 2.17

6 95 1.20 1.44 1.98 2.56 3.07 3.23

8 95 1.62 1.95 2.69 3.47 4.14 4.34

9 95 1.88 2.27 3.14 4.08 4.90 5.15

11 95 2.38 2.89 4.02 5.15 5.96 6.10

12.5 95 2.49 3.02 4.21 5.51 6.64 6.99

16 95 2.92 3.53 4.91 6.39 7.70 8.10

12.5 95 1.09 1.63 2.96 4.59 6.27 6.94

16 95 1.31 2.01 3.69 5.76 7.93 8.81

20 95 1.54 2.48 4.62 7.00 9.35 10.3

21 95 1.25 2.89 6.09 8.97 11.1 11.8

26 95 4.58 5.64 8.23 11.4 14.8 16.1

30 95 5.18 6.39 9.35 13.0 16.8 18.3

40 95 6.21 7.66 11.3 15.9 20.9 22.9

42 95 8.80 10.7 15.0 19.5 23.3 24.3

-30 -20 0 20 40 50

[°F]

Evaporating temperature [°F]

Subcooling correction factor 'fsub'

Subcooling [K] 2 4 10 15 20 25 30

Correction factor 0.98 1.00 1.06 1.12 1.17 1.22 1.29

Distributer correction factor 'fp' *

Pressure

drop [bar]

Δp

0 1 1 1 1 1

1 0.90 0.90 0.89 0.86 0.82

1.5 0.85 0.84 0.82 0.79 0.71

2 0.80 0.78 0.75 0.70 0.59

*Calculated at 32 °C condensing temperature.

-30 -20 -10 0 10

Evaporating temperature [°C]

Correction factor

© Danfoss | DCS (az) | 2019.01

Subcooling correction factor 'fsub'

Subcooling [°F] 2 7 10 20 30 40 50

Correction factor 0.97 1.00 1.02 1.08 1.14 1.20 1.27

Distributer correction factor 'fp' *

Pressure

drop [psi]

Δp

0 1 1 1 1 1 1

15 0.90 0.90 0.89 0.88 0.85 0.81

25 0.83 0.83 0.81 0.78 0.72 0.66

30 0.80 0.79 0.77 0.73 0.65 0.57

*Calculated at 90 °F condensing temperature.

-30 -20 0 20 40 50

Evaporating temperature [°F]

Correction factor

DKRCC.PD.AXV.3A.02 | 28

Data sheet | Thermostatic expansion valves, type TGE 10, TGE 20, TGE 40

Capacity in kW. -30 – 10 °C.
Opening superheat sh = 4 K SI units R1234ze

Valve
type

TGE 10

TGE 20

TGE 40

Orice

Cond.

no.

temp.

[°C]

3 45 2.40 3.24 4.20 5.20 6.10

4 45 3.22 4.37 5.67 7.03 8.27

6 45 4.68 6.39 8.34 10.4 12.2

8 45 6.27 8.58 11.2 14.0 16.4

9 45 7.24 9.97 13.1 16.4 19.4

11 45 9.25 12.9 17.0 20.9 23.7

12.5 45 9.46 13.2 17.4 22.0 26.1

16 45 11.07 15.4 20.3 25.5 30.4

12.5 45 5.02 8.96 13.9 19.5 25.3

16 45 6.07 11.0 17.2 24.4 31.7

20 45 7.02 13.5 21.0 29.2 37.3

21 45 8.12 18.7 29.0 38.1 45.3

26 45 17.5 25.0 34.4 45.7 57.4

30 45 19.7 28.3 39.0 51.8 65.1

40 45 23.6 34.0 47.6 64.9 83.6

42 45 36.1 50.0 65.5 81.4 94.4

Evaporating temperature [°C]

-30 -20 -10 0 10

Capacity in kW. -30 – 10 °C.
Opening superheat sh = 4 K SI units R1234ze

Valve
type

TGE 10

TGE 20

TGE 40

Orice

Cond.

no.

temp.

[°C]

3 55 2.28 3.11 4.07 5.13 6.18

4 55 3.05 4.18 5.48 6.90 8.32

6 55 4.34 6.00 7.94 10.1 12.2

8 55 5.74 7.97 10.57 13.4 16.2

9 55 6.58 9.21 12.3 15.7 19.1

11 55 8.41 12.0 16.2 20.5 24.1

12.5 55 8.45 12.0 16.1 20.8 25.4

16 55 9.86 14.0 18.8 24.2 29.7

12.5 55 4.61 8.31 12.9 18.4 24.2

16 55 5.47 10.1 15.8 22.7 30.1

20 55 5.80 12.0 19.2 27.2 35.7

21 55 6.95 17.7 28.2 37.9 46.3

26 55 15.7 22.4 31.1 41.7 53.7

30 55 17.6 25.2 35.1 47.1 60.6

40 55 20.9 30.2 42.7 59.0 78.8

42 55 35.2 49.0 64.9 81.8 97.4

Evaporating temperature [°C]

-30 -20 -10 0 10

Capactiy in TR. -22 – 50 °F
Opening superheat sh = 7.2 °F US units R1234ze

Valve
type

TGE 10

TGE 20

TGE 40

Orice

Cond.

no.

temp.

3 115 0.58 0.70 0.98 1.29 1.60 1.74

4 115 0.78 0.94 1.31 1.73 2.16 2.36

6 115 1.13 1.37 1.92 2.55 3.20 3.49

8 115 1.51 1.83 2.58 3.43 4.29 4.66

9 115 1.73 2.12 3.00 4.01 5.05 5.51

11 115 2.20 2.71 3.89 5.19 6.35 6.76

12.5 115 2.25 2.76 3.96 5.35 6.78 7.40

16 115 2.63 3.23 4.62 6.22 7.88 8.63

12.5 115 1.00 1.52 2.81 4.42 6.27 7.16

16 115 1.18 1.84 3.45 5.49 7.83 8.98

20 115 1.23 2.15 4.24 6.67 9.30 10.6

21 115 0.91 2.61 5.96 9.12 11.9 12.9

26 115 4.14 5.12 7.55 10.7 14.4 16.2

30 115 4.66 5.77 8.54 12.1 16.3 18.4

40 115 5.56 6.90 10.3 14.9 20.7 23.7

42 115 8.69 10.6 15.1 20.2 25.0 27.0

-30 -20 0 20 40 50

[°F]

Evaporating temperature [°F]

Capactiy in TR. -22 – 50 °F
Opening superheat sh = 7.2 °F US units R1234ze

Valve
type

TGE 10

TGE 20

TGE 40

Orice

Cond.

no.

temp.

3 135 0.54 0.66 0.93 1.24 1.58 1.75

4 135 0.73 0.89 1.25 1.67 2.12 2.35

6 135 1.02 1.25 1.79 2.41 3.10 3.43

8 135 1.34 1.65 2.37 3.21 4.11 4.55

9 135 1.53 1.90 2.74 3.73 4.82 5.36

11 135 1.94 2.43 3.59 4.93 6.26 6.82

12.5 135 1.95 2.43 3.55 4.90 6.38 7.11

16 135 2.27 2.83 4.14 5.70 7.44 8.31

12.5 135 0.90 1.38 2.58 4.08 5.85 6.76

16 135 1.03 1.64 3.13 5.00 7.22 8.38

20 135 0.88 1.75 3.73 6.04 8.62 9.95

21 135 0.53 2.23 5.61 8.87 11.8 13.1

26 135 3.64 4.51 6.68 9.52 13.0 14.8

30 135 4.06 5.05 7.51 10.7 14.7 16.8

40 135 4.82 5.99 9.00 13.1 18.7 21.8

42 135 8.38 10.3 14.8 19.9 25.2 27.7

-30 -20 0 20 40 50

[°F]

Evaporating temperature [°F]

Subcooling correction factor 'fsub'

Subcooling [K] 2 4 10 15 20 25 30

Correction factor 0.98 1.00 1.06 1.12 1.17 1.22 1.29

Distributer correction factor 'fp' *

Pressure

drop [bar]

Δp

0 1 1 1 1 1

1 0.90 0.90 0.89 0.86 0.82

1.5 0.85 0.84 0.82 0.79 0.71

2 0.80 0.78 0.75 0.70 0.59

*Calculated at 32 °C condensing temperature.

-30 -20 -10 0 10

Evaporating temperature [°C]

Correction factor

© Danfoss | DCS (az) | 2019.01

Subcooling correction factor 'fsub'

Subcooling [°F] 2 7 10 20 30 40 50

Correction factor 0.97 1.00 1.02 1.08 1.14 1.20 1.27

Distributer correction factor 'fp' *

Pressure

drop [psi]

Δp

0 1 1 1 1 1 1

15 0.90 0.90 0.89 0.88 0.85 0.81

25 0.83 0.83 0.81 0.78 0.72 0.66

30 0.80 0.79 0.77 0.73 0.65 0.57

*Calculated at 90 °F condensing temperature.

-30 -20 0 20 40 50

Evaporating temperature [°F]

Correction factor

DKRCC.PD.AXV.3A.02 | 29

Data sheet | Thermostatic expansion valves, type TGE 10, TGE 20, TGE 40

Capacity in kW. -40 – 15 °C.
Opening superheat sh = 4 K SI units R407F

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

3 25 4.75 5.89 7.19 8.52 9.61 9.98 9.64

4 25 6.42 7.97 9.75 11.6 13.1 13.6 13.2

6 25 9.46 11.8 14.4 17.1 19.3 20.1 19.5

8 25 12.9 16.0 19.5 23.1 25.9 26.8 25.8

9 25 15.0 18.7 22.9 27.2 30.7 31.9 30.8

11 25 19.0 23.8 29.1 34.0 37.1 36.8 34.7

12.5 25 20.0 25.0 30.7 36.5 41.4 43.1 41.8

16 25 23.4 29.2 35.7 42.4 47.9 49.8 48.2

12.5 25 19.4 24.7 31.0 37.9 44.3 47.8 47.1

16 25 24.2 30.9 38.9 47.8 56.1 60.8 60.2

20 25 29.8 37.7 47.1 57.0 65.9 70.1 68.6

21 25 39.8 49.7 60.3 69.9 76.2 75.6 71.3

26 25 39.0 49.9 63.3 78.3 92.7 102 101

30 25 44.3 56.8 72.0 89.0 105 115 115

40 25 53.3 68.5 87.6 110 132 143 139

42 25 78.0 96.6 117 137 151 152 144

-40 -30 -20 -10 0 10 15

[°C]

Evaporating temperature [°C]

Capacity in kW. -40 – 15 °C.
Opening superheat sh= 4 K SI units R407F

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

3 35 4.68 5.85 7.24 8.76 10.2 11.2 11.5

4 35 6.28 7.88 9.76 11.8 13.8 15.3 15.6

6 35 9.17 11.5 14.3 17.4 20.3 22.4 22.8

8 35 12.4 15.5 19.3 23.3 27.1 29.7 30.2

9 35 14.4 18.1 22.5 27.4 32.0 35.2 35.9

11 35 18.3 23.3 29.1 35.0 39.7 41.8 41.5

12.5 35 18.9 23.9 29.9 36.5 42.7 47.2 48.2

16 35 22.2 28.0 34.9 42.4 49.6 54.9 56.1

12.5 35 18.7 23.9 30.3 37.7 45.3 51.6 53.6

16 35 23.1 29.6 37.8 47.2 57.0 65.2 67.9

20 35 28.4 36.2 45.8 56.5 67.4 76.0 78.5

21 35 39.3 49.7 61.2 72.5 81.7 86.0 85.6

26 35 36.6 47.2 60.5 76.2 92.8 107 112

30 35 41.5 53.5 68.7 86.5 105 121 127

40 35 49.3 63.8 82.6 106 133 157 163

42 35 78.2 97.7 120 143 163 174 174

-40 -30 -20 -10 0 10 15

[°C]

Evaporating temperature [°C]

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R407F

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 75 1.35 1.71 2.12 2.52 2.77 2.78 2.63

4 75 1.82 2.32 2.88 3.42 3.78 3.79 3.60

6 75 2.69 3.42 4.26 5.07 5.59 5.60 5.32

8 75 3.66 4.65 5.76 6.82 7.47 7.46 7.06

9 75 4.27 5.44 6.77 8.05 8.88 8.89 8.44

11 75 5.40 6.92 8.56 9.94 10.5 10.2 9.44

12.5 75 5.69 7.28 9.09 10.9 12.0 12.0 11.5

16 75 6.68 8.51 10.6 12.6 13.9 13.9 13.2

12.5 75 5.53 7.21 9.23 11.4 13.1 13.4 12.9

16 75 6.90 9.02 11.6 14.4 16.6 17.0 16.6

20 75 8.49 11.0 14.0 17.1 19.3 19.6 18.8

21 75 11.3 14.4 17.7 20.4 21.6 21.0 19.4

26 75 11.1 14.6 18.9 23.7 27.6 28.5 28.0

30 75 12.7 16.6 21.5 27.0 31.3 32.3 31.7

40 75 15.2 20.1 26.3 33.3 39.0 39.7 38.0

42 75 22.1 28.0 34.3 40.1 43.1 42.3 39.2

Evaporating temperature [°F]

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R407F

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 95 1.33 1.70 2.15 2.63 3.05 3.19 3.26

4 95 1.78 2.29 2.90 3.56 4.13 4.33 4.43

6 95 2.60 3.36 4.25 5.22 6.06 6.35 6.49

8 95 3.51 4.52 5.72 6.99 8.07 8.43 8.57

9 95 4.08 5.27 6.70 8.22 9.55 10.0 10.2

11 95 5.19 6.78 8.63 10.4 11.7 11.9 11.8

12.5 95 5.37 6.97 8.89 11.0 12.8 13.4 13.7

16 95 6.31 8.16 10.37 12.8 14.9 15.6 16.0

12.5 95 5.30 6.97 9.05 11.4 13.7 14.7 15.3

16 95 6.55 8.65 11.3 14.3 17.3 18.5 19.4

20 95 8.05 10.7 13.7 17.1 20.4 21.6 22.4

21 95 11.2 14.5 18.1 21.6 24.0 24.4 24.3

26 95 10.4 13.8 18.1 23.2 28.3 30.5 32.0

30 95 11.8 15.6 20.6 26.4 32.1 34.5 36.2

40 95 14.0 18.6 24.8 32.7 41.2 44.6 46.5

42 95 22.2 28.4 35.5 42.6 48.1 49.5 49.5

Evaporating temperature [°F]

Subcooling correction factor 'fsub'

Subcooling [K] 2 4 10 15 20 25 30

Correction factor 0.98 1.00 1.06 1.12 1.17 1.22 1.27

Distributer correction factor 'fp' *

Pressure

drop [bar]

Δp

0 1 1 1 1 1 1 1

1 0.97 0.96 0.96 0.96 0.95 0.94 0.93

1.5 0.95 0.95 0.94 0.94 0.93 0.91 0.89

2 0.93 0.93 0.92 0.91 0.90 0.87 0.85

*Calculated at 32 °C condensing temperature.

-40 -30 -20 -10 0 10 15

Evaporating temperature [°C]

Correction factor

© Danfoss | DCS (az) | 2019.01

Subcooling correction factor 'fsub'

Subcooling [°F] 2 7 10 20 30 40 50

Correction factor 0.97 1.00 1.02 1.08 1.14 1.20 1.25

Distributer correction factor 'fp' *

Pressure

drop [psi]

Δp

0 1 1 1 1 1 1 1

15 0.96 0.96 0.96 0.95 0.95 0.94 0.93

25 0.94 0.94 0.93 0.92 0.91 0.89 0.87

30 0.93 0.92 0.92 0.91 0.89 0.87 0.84

*Calculated at 90 °F condensing temperature.

-40 -20 0 20 40 50 60

Evaporating temperature [°F]

Correction factor

DKRCC.PD.AXV.3A.02 | 30

Data sheet | Thermostatic expansion valves, type TGE 10, TGE 20, TGE 40

Capacity in kW. -40 – 15 °C.
Opening superheat sh = 4 K SI units R407F

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

3 45 4.46 5.63 7.04 8.64 10.3 11.7 12.3

4 45 5.94 7.52 9.43 11.6 13.8 15.8 16.6

6 45 8.59 10.9 13.7 16.9 20.2 23.0 24.1

8 45 11.5 14.6 18.3 22.5 26.8 30.4 31.7

9 45 13.3 16.9 21.3 26.4 31.5 36.0 37.7

11 45 16.9 21.9 27.9 34.4 40.3 44.2 45.0

12.5 45 17.2 22.1 28.0 34.8 41.8 47.9 50.2

16 45 20.2 25.9 32.7 40.5 48.7 56.1 58.9

12.5 45 17.3 22.3 28.5 35.9 43.9 51.5 54.8

16 45 21.3 27.4 35.3 44.6 54.8 64.6 68.9

20 45 26.1 33.6 42.8 53.6 65.2 76.1 80.6

21 45 37.7 48.1 59.9 72.2 83.2 90.6 92.3

26 45 33.1 43.0 55.6 71.0 88.1 105 112

30 45 37.4 48.6 62.9 80.3 99.8 119 127

40 45 44.2 57.3 74.8 97.8 126 157 170

42 45 76.3 95.9 119 144 167 184 189

-40 -30 -20 -10 0 10 15

[°C]

Evaporating temperature [°C]

Capacity in kW. -40 – 15 °C.
Opening superheat sh = 4 K SI units R407F

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

3 55 4.11 5.23 6.60 8.19 9.91 11.5 12.3

4 55 5.43 6.92 8.76 10.9 13.2 15.5 16.5

6 55 7.73 9.89 12.6 15.7 19.1 22.4 23.8

8 55 10.2 13.1 16.7 20.8 25.3 29.4 31.2

9 55 11.7 15.1 19.3 24.2 29.6 34.7 36.9

11 55 15.0 19.7 25.6 32.4 39.0 44.1 45.7

12.5 55 14.9 19.4 24.9 31.5 38.7 45.7 48.7

16 55 17.6 22.7 29.2 36.8 45.3 53.7 57.5

12.5 55 15.5 20.0 25.7 32.7 40.5 48.4 52.1

16 55 18.8 24.4 31.5 40.2 50.1 60.3 65.1

20 55 23.0 29.8 38.3 48.5 59.9 71.4 76.8

21 55 34.8 44.9 56.7 69.3 81.1 90.3 93.4

26 55 28.7 37.4 48.7 62.9 79.2 96.4 105

30 55 32.3 42.1 54.9 71.0 89.5 109 118

40 55 38.4 49.8 65.0 85.5 113 145 161

42 55 72.3 91.5 114 140 165 185 193

-40 -30 -20 -10 0 10 15

[°C]

Evaporating temperature [°C]

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R407F

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 115 1.26 1.63 2.09 2.60 3.11 3.33 3.50

4 115 1.67 2.17 2.79 3.49 4.19 4.49 4.73

6 115 2.41 3.15 4.05 5.08 6.09 6.53 6.88

8 115 3.22 4.20 5.41 6.77 8.08 8.63 9.06

9 115 3.72 4.88 6.31 7.93 9.53 10.2 10.8

11 115 4.75 6.33 8.28 10.3 12.0 12.6 12.8

12.5 115 4.82 6.36 8.27 10.5 12.6 13.6 14.3

16 115 5.67 7.46 9.66 12.2 14.8 15.9 16.8

12.5 115 4.87 6.44 8.46 10.9 13.4 14.6 15.6

16 115 5.96 7.92 10.5 13.5 16.7 18.3 19.6

20 115 7.31 9.68 12.7 16.2 19.8 21.5 23.0

21 115 10.6 13.9 17.7 21.6 24.7 25.8 26.4

26 115 9.28 12.4 16.5 21.5 27.0 29.6 32.0

30 115 10.5 14.0 18.7 24.4 30.5 33.5 36.1

40 115 12.4 16.5 22.2 30.0 39.5 44.3 48.5

42 115 21.6 27.8 35.2 43.1 50.0 52.5 54.1

Evaporating temperature [°F]

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R407F

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 135 1.14 1.49 1.93 2.45 2.99 3.24 3.47

4 135 1.50 1.97 2.56 3.25 3.99 4.34 4.66

6 135 2.13 2.80 3.66 4.67 5.75 6.26 6.71

8 135 2.80 3.70 4.84 6.18 7.57 8.22 8.80

9 135 3.21 4.27 5.61 7.20 8.90 9.69 10.4

11 135 4.10 5.57 7.47 9.65 11.6 12.4 13.0

12.5 135 4.07 5.45 7.22 9.35 11.6 12.7 13.7

16 135 4.78 6.40 8.45 10.9 13.7 15.0 16.2

12.5 135 4.26 5.66 7.49 9.73 12.2 13.4 14.6

16 135 5.15 6.88 9.16 12.0 15.1 16.7 18.2

20 135 6.29 8.40 11.1 14.4 18.0 19.8 21.5

21 135 9.66 12.8 16.6 20.5 24.1 25.4 26.5

26 135 7.83 10.5 14.1 18.7 23.9 26.6 29.2

30 135 8.78 11.8 15.9 21.1 27.0 30.1 33.0

40 135 10.51 14.0 18.9 25.7 34.7 39.9 45.0

42 135 20.2 26.3 33.6 41.6 49.3 52.4 54.8

Evaporating temperature [°F]

Subcooling correction factor 'fsub'

Subcooling [K] 2 4 10 15 20 25 30

Correction factor 0.98 1.00 1.06 1.12 1.17 1.22 1.27

Distributer correction factor 'fp' *

Pressure

drop [bar]

Δp

0 1 1 1 1 1 1 1

1 0.97 0.96 0.96 0.96 0.95 0.94 0.93

1.5 0.95 0.95 0.94 0.94 0.93 0.91 0.89

2 0.93 0.93 0.92 0.91 0.90 0.87 0.85

*Calculated at 32 °C condensing temperature.

-40 -30 -20 -10 0 10 15

Evaporating temperature [°C]

Correction factor

© Danfoss | DCS (az) | 2019.01

Subcooling correction factor 'fsub'

Subcooling [°F] 2 7 10 20 30 40 50

Correction factor 0.97 1.00 1.02 1.08 1.14 1.20 1.25

Distributer correction factor 'fp' *

Pressure

drop [psi]

Δp

0 1 1 1 1 1 1 1

15 0.96 0.96 0.96 0.95 0.95 0.94 0.93

25 0.94 0.94 0.93 0.92 0.91 0.89 0.87

30 0.93 0.92 0.92 0.91 0.89 0.87 0.84

*Calculated at 90 °F condensing temperature.

-40 -20 0 20 40 50 60

Evaporating temperature [°F]

Correction factor

DKRCC.PD.AXV.3A.02 | 31

Data sheet | Thermostatic expansion valves, type TGE 10, TGE 20, TGE 40

Capacity in kW. -40 – 15 °C
Opening superheat sh = 4 K SI units R407A

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -30 -20 -10 0 10 15

[°C]

3 25 3.89 4.95 6.15 7.35 8.33 8.72 8.52

4 25 5.26 6.70 8.34 9.99 11.4 11.9 11.6

6 25 7.77 9.90 12.3 14.8 16.8 17.6 17.2

8 25 10.5 13.4 16.7 20.0 22.6 23.5 22.9

9 25 12.6 16.0 19.8 23.8 27.2 28.4 27.5

11 25 15.6 20.0 24.9 29.4 32.4 32.4 30.9

12.5 25 16.7 21.3 26.7 32.2 36.8 38.5 37.4

16 25 19.6 25.0 31.1 37.4 42.6 44.5 43.2

12.5 25 15.8 20.6 26.4 32.8 38.5 41.7 41.3

16 25 19.6 25.8 33.2 41.3 48.9 53.2 52.9

20 25 24.2 31.6 40.2 49.4 57.5 61.5 60.5

21 25 33.0 42.2 52.1 61.3 67.4 67.4 63.7

26 25 31.5 40.9 52.5 65.7 78.6 86.9 86.9

30 25 35.9 46.6 59.8 74.8 89.4 98.6 98.6

40 25 43.2 56.2 72.4 91.7 110.9 122 120

42 25 62.4 78.6 96.8 115 128 131 125

Evaporating temperature [°C]

Capacity in kW. -40 – 15 °C

Opening superheat sh = 4 K SI units R407A

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -30 -20 -10 0 10 15

[°C]

3 35 3.74 4.81 6.09 7.48 8.81 9.78 10.0

4 35 5.01 6.47 8.21 10.1 11.9 13.3 13.6

6 35 7.32 9.46 12.0 14.8 17.5 19.5 20.0

8 35 9.85 12.7 16.2 19.9 23.5 25.9 26.5

9 35 11.9 15.3 19.4 23.8 28.1 31.2 31.9

11 35 14.5 19.1 24.4 29.9 34.4 36.6 36.5

12.5 35 15.6 20.3 25.8 31.9 37.7 42.0 43.0

16 35 18.4 23.8 30.1 37.1 43.8 48.9 50.1

12.5 35 14.7 19.3 25.2 32.0 39.1 45.0 46.8

16 35 18.1 24.0 31.3 40.0 49.1 56.9 59.5

20 35 22.3 29.4 38.0 48.0 58.2 66.5 68.9

21 35 32.3 41.8 52.4 63.1 71.8 76.3 76.2

26 35 29.4 38.4 49.9 63.6 78.3 91.4 96.2

30 35 33.3 43.6 56.7 72.2 88.9 104 109

40 35 39.7 52.0 68.0 88.3 112 133 139

42 35 62.0 78.8 98.4 119 138 149 150

Evaporating temperature [°C]

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R407A

Valve

Orice

Cond.

type

TGE 10

TGE 20

TGE 40

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 75 1.11 1.44 1.82 2.18 2.41 2.43 2.34

4 75 1.50 1.95 2.47 2.96 3.29 3.32 3.20

6 75 2.22 2.89 3.66 4.39 4.87 4.91 4.73

8 75 3.01 3.93 4.95 5.93 6.54 6.56 6.28

9 75 3.58 4.66 5.89 7.09 7.88 7.92 7.54

11 75 4.45 5.85 7.37 8.65 9.19 9.02 8.46

12.5 75 4.76 6.24 7.93 9.60 10.7 10.8 10.3

16 75 5.59 7.30 9.23 11.1 12.4 12.4 11.8

12.5 75 4.50 6.05 7.92 9.87 11.4 11.7 11.4

16 75 5.61 7.57 9.95 12.5 14.5 14.9 14.6

20 75 6.93 9.26 12.0 14.8 16.9 17.2 16.7

21 75 9.38 12.3 15.4 18.0 19.2 18.8 17.3

26 75 9.01 12.0 15.8 19.9 23.5 24.4 24.0

30 75 10.3 13.7 18.0 22.7 26.7 27.7 27.3

40 75 12.4 16.5 21.8 27.9 33.1 34.0 32.8

42 75 17.7 22.8 28.5 33.8 36.7 36.4 34.0

Evaporating temperature [°F]

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R407A

Valve

Orice

Cond.

type

TGE 10

TGE 20

TGE 40

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 95 1.06 1.40 1.82 2.26 2.64 2.78 2.85

4 95 1.42 1.89 2.45 3.05 3.58 3.77 3.88

6 95 2.08 2.76 3.58 4.48 5.27 5.54 5.68

8 95 2.80 3.72 4.82 6.00 7.03 7.36 7.52

9 95 3.38 4.47 5.77 7.18 8.43 8.86 9.08

11 95 4.13 5.57 7.27 8.96 10.2 10.4 10.3

12.5 95 4.44 5.91 7.70 9.63 11.3 11.9 12.2

16 95 5.22 6.93 8.98 11.2 13.2 13.9 14.2

12.5 95 4.17 5.66 7.56 9.77 11.9 12.8 13.3

16 95 5.15 7.01 9.41 12.2 15.0 16.2 16.9

20 95 6.34 8.58 11.4 14.6 17.7 18.9 19.6

21 95 9.17 12.2 15.6 18.8 21.1 21.7 21.6

26 95 8.34 11.2 15.0 19.4 24.0 26.0 27.5

30 95 9.46 12.8 17.0 22.1 27.2 29.4 31.1

40 95 11.3 15.2 20.5 27.2 34.7 37.8 39.7

42 95 17.6 23.0 29.2 35.7 40.8 42.3 42.7

Evaporating temperature [°F]

Subcooling correction factor 'fsub'

Subcooling [K] 2 4 10 15 20 25 30

Correction factor 0.98 1.00 1.07 1.12 1.18 1.24 1.29

Distributer correction factor 'fp' *

Pressure

drop [bar]

Δp

0 1 1 1 1 1 1 1

1 0.96 0.96 0.96 0.96 0.95 0.94 0.92

1.5 0.95 0.94 0.94 0.93 0.92 0.90 0.88

2 0.93 0.92 0.92 0.91 0.89 0.87 0.84

*Calculated at 32 °C condensing temperature.

-40 -30 -20 -10 0 10 15

Evaporating temperature [°C]

Correction factor

© Danfoss | DCS (az) | 2019.01

Subcooling correction factor 'fsub'

Subcooling [°F] 2 7 10 20 30 40 50

Correction factor 0.97 1.00 1.02 1.08 1.15 1.21 1.27

Distributer correction factor 'fp' *

Pressure

drop [psi]

Δp

0 1 1 1 1 1 1 1

15 0.96 0.96 0.96 0.95 0.94 0.93 0.92

25 0.94 0.93 0.93 0.92 0.90 0.89 0.86

30 0.92 0.92 0.91 0.90 0.88 0.86 0.83

*Calculated at 90 °F condensing temperature.

-40 -20 0 20 40 50 60

Evaporating temperature [°F]

Correction factor

DKRCC.PD.AXV.3A.02 | 32

Data sheet | Thermostatic expansion valves, type TGE 10, TGE 20, TGE 40

Capacity in kW. -40 – 15 °C
Opening superheat sh = 4 K SI units R407A

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -30 -20 -10 0 10 15

[°C]

3 45 3.45 4.49 5.76 7.22 8.73 10.1 10.6

4 45 4.59 5.99 7.70 9.68 11.8 13.6 14.3

6 45 6.63 8.66 11.2 14.1 17.1 19.8 20.9

8 45 8.83 11.5 14.9 18.8 22.8 26.2 27.5

9 45 10.9 14.1 18.1 22.8 27.5 31.7 33.3

11 45 13.0 17.3 22.7 28.7 34.3 38.1 39.0

12.5 45 14.0 18.5 23.9 30.1 36.6 42.3 44.5

16 45 16.5 21.7 28.0 35.2 42.7 49.5 52.2

12.5 45 13.2 17.4 22.8 29.5 37.0 44.3 47.4

16 45 16.1 21.4 28.2 36.6 46.1 55.5 59.6

20 45 19.8 26.2 34.2 44.0 54.9 65.4 69.8

21 45 30.5 39.9 50.9 62.3 72.5 79.7 81.7

26 45 26.4 34.7 45.5 58.7 73.8 88.9 95.8

30 45 29.8 39.2 51.5 66.6 83.6 101 108

40 45 35.3 46.5 61.2 80.6 105 132 144

42 45 59.7 76.6 96.6 119 140 157 162

Evaporating temperature [°C]

Capacity in kW. -40 – 15 °C

Opening superheat sh = 4 K SI units R407A

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -30 -20 -10 0 10 15

[°C]

3 55 3.07 4.01 5.20 6.61 8.16 9.67 10.3

4 55 4.04 5.30 6.89 8.80 10.9 13.0 14.0

6 55 5.74 7.56 9.87 12.6 15.7 18.7 20.1

8 55 7.56 9.98 13.0 16.7 20.8 24.7 26.3

9 55 9.41 12.4 16.2 20.6 25.5 30.2 32.3

11 55 11.0 14.9 20.0 26.0 32.1 37.0 38.6

12.5 55 12.0 16.0 21.0 27.0 33.6 40.0 42.9

16 55 14.1 18.8 24.6 31.6 39.3 47.1 50.6

12.5 55 11.4 15.0 19.8 25.8 32.9 40.4 44.0

16 55 13.8 18.2 24.2 31.7 40.7 50.2 54.8

20 55 16.9 22.3 29.4 38.1 48.5 59.5 64.7

21 55 27.7 36.7 47.4 58.9 69.9 78.7 81.8

26 55 22.5 29.8 39.4 51.5 65.7 80.9 88.5

30 55 25.3 33.6 44.5 58.2 74.3 91.5 100

40 55 30.3 39.9 52.7 69.9 92.6 120 134

42 55 55.6 71.9 91.6 114 136 156 163

Evaporating temperature [°C]

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R407A

Valve

Orice

Cond.

type

TGE 10

TGE 20

TGE 40

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 115 0.97 1.30 1.71 2.18 2.65 2.86 3.03

4 115 1.29 1.73 2.28 2.92 3.57 3.86 4.09

6 115 1.86 2.50 3.31 4.25 5.20 5.61 5.95

8 115 2.47 3.33 4.41 5.66 6.90 7.42 7.83

9 115 3.04 4.08 5.37 6.85 8.33 8.97 9.50

11 115 3.62 5.00 6.73 8.64 10.3 11.0 11.1

12.5 115 3.93 5.33 7.08 9.10 11.1 12.0 12.7

16 115 4.62 6.25 8.28 10.61 13.0 14.0 14.9

12.5 115 3.69 5.02 6.79 8.97 11.4 12.5 13.5

16 115 4.51 6.16 8.37 11.1 14.2 15.6 16.9

20 115 5.54 7.54 10.1 13.3 16.8 18.4 19.9

21 115 8.59 11.6 15.1 18.7 21.6 22.7 23.3

26 115 7.37 10.0 13.5 17.9 22.7 25.0 27.3

30 115 8.32 11.3 15.3 20.2 25.7 28.4 30.8

40 115 9.88 13.4 18.2 24.7 32.9 37.2 41.0

42 115 16.9 22.2 28.7 35.7 42.0 44.5 46.3

Evaporating temperature [°F]

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R407A

Valve

Orice

Cond.

type

TGE 10

TGE 20

TGE 40

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 135 0.84 1.14 1.51 1.97 2.46 2.70 2.91

4 135 1.11 1.50 2.01 2.62 3.28 3.61 3.90

6 135 1.57 2.13 2.86 3.76 4.73 5.20 5.62

8 135 2.06 2.81 3.78 4.96 6.23 6.83 7.37

9 135 2.56 3.50 4.70 6.13 7.67 8.40 9.08

11 135 2.99 4.21 5.82 7.73 9.58 10.3 10.9

12.5 135 3.24 4.48 6.09 8.03 10.1 11.1 12.0

16 135 3.81 5.27 7.14 9.39 11.9 13.1 14.2

12.5 135 3.11 4.22 5.74 7.69 9.97 11.1 12.3

16 135 3.76 5.12 7.00 9.44 12.3 13.8 15.3

20 135 4.60 6.27 8.48 11.3 14.6 16.4 18.0

21 135 7.64 10.5 13.9 17.5 20.8 22.1 23.1

26 135 6.12 8.4 11.4 15.3 19.9 22.3 24.7

30 135 6.86 9.4 12.9 17.3 22.5 25.2 27.9

40 135 8.24 11.2 15.3 21.0 28.6 33.0 37.5

42 135 15.4 20.6 26.9 34.0 40.9 43.8 46.3

Evaporating temperature [°F]

Subcooling correction factor 'fsub'

Subcooling [K] 2 4 10 15 20 25 30

Correction factor 0.98 1.00 1.07 1.12 1.18 1.24 1.29

Distributer correction factor 'fp' *

Pressure

drop [bar]

Δp

0 1 1 1 1 1 1 1

1 0.96 0.96 0.96 0.96 0.95 0.94 0.92

1.5 0.95 0.94 0.94 0.93 0.92 0.90 0.88

2 0.93 0.92 0.92 0.91 0.89 0.87 0.84

*Calculated at 32 °C condensing temperature.

-40 -30 -20 -10 0 10 15

Evaporating temperature [°C]

Correction factor

© Danfoss | DCS (az) | 2019.01

Subcooling correction factor 'fsub'

Subcooling [°F] 2 7 10 20 30 40 50

Correction factor 0.97 1.00 1.02 1.08 1.15 1.21 1.27

Distributer correction factor 'fp' *

Pressure

drop [psi]

Δp

0 1 1 1 1 1 1 1

15 0.96 0.96 0.96 0.95 0.94 0.93 0.92

25 0.94 0.93 0.93 0.92 0.90 0.89 0.86

30 0.92 0.92 0.91 0.90 0.88 0.86 0.83

*Calculated at 90 °F condensing temperature.

-40 -20 0 20 40 50 60

Evaporating temperature [°F]

Correction factor

DKRCC.PD.AXV.3A.02 | 33

Data sheet | Thermostatic expansion valves, type TGE 10, TGE 20, TGE 40

Capacity in kW. -40 – 15 °C
Opening superheat sh = 4 K

Valve

Orice

Cond.

type

TGE 10

TGE 20

TGE 40

no.

temp.

-40 -30 -20 -10 0 10 15

[°C]

3 25 3.13 4.03 5.00 5.92 6.53 6.41 5.88

4 25 4.24 5.47 6.80 8.06 8.92 8.77 8.04

6 25 6.27 8.10 10.1 12.0 13.2 13.0 11.9

8 25 8.54 11.0 13.7 16.2 17.8 17.3 15.8

9 25 10.0 12.9 16.0 19.0 21.0 20.8 19.0

11 25 12.7 16.4 20.2 23.5 25.1 23.5 21.0

12.5 25 13.4 17.3 21.7 25.8 28.5 28.3 25.9

16 25 15.7 20.2 25.2 29.8 33.0 32.6 29.8

12.5 25 12.9 17.1 21.9 26.8 30.5 30.8 28.6

16 25 16.2 21.5 27.6 33.9 38.9 39.5 36.7

20 25 19.9 26.1 33.2 40.3 45.5 45.12 41.5

21 25 26.2 33.6 41.2 47.6 50.7 47.8 42.6

26 25 26.3 34.8 44.8 55.3 64.0 66.7 62.9

30 25 30.0 39.6 51.0 63.0 72.8 75.7 71.3

40 25 36.0 47.8 62.1 77.7 90.4 91.8 84.4

42 25 51.0 65.0 79.9 93.2 101 95.9 85.7

Evaporating temperature [°C]

SI units R404A/R507

Capacity in kW. -40 – 15 °C
Opening superheat sh = 4 K SI units R404A/R507

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -30 -20 -10 0 10 15

[°C]

3 35 2.91 3.83 4.87 5.98 6.97 7.52 7.50

4 35 3.92 5.16 6.58 8.10 9.47 10.2 10.2

6 35 5.74 7.57 9.67 11.9 13.9 15.1 15.0

8 35 7.75 10.2 13.0 16.0 18.6 20.0 19.8

9 35 9.23 12.1 15.3 18.7 21.7 23.4 23.5

11 35 11.6 15.3 19.5 23.6 26.9 27.8 26.9

12.5 35 12.2 16.1 20.6 25.2 29.3 31.6 31.7

16 35 14.3 18.9 24.0 29.4 34.0 36.7 36.8

12.5 35 11.7 15.7 20.5 26.0 31.4 35.0 35.3

16 35 14.5 19.5 25.7 32.7 39.6 44.4 45.0

20 35 17.8 23.8 31.0 39.0 46.7 51.5 51.6

21 35 24.7 32.3 40.5 48.2 53.9 55.6 54.5

26 35 23.7 31.8 41.7 52.9 63.8 72.0 74.1

30 35 27.0 36.1 47.4 60.1 72.4 81.6 83.8

40 35 31.9 43.0 57.1 74.3 92.2 104 105

42 35 48.5 63.0 79.1 95.0 107 112 111

Evaporating temperature [°C]

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R404A/R507

Valve

Orice

Cond.

type

TGE 10

TGE 20

TGE 40

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 75 0.89 1.18 1.48 1.74 1.84 1.77 1.57

4 75 1.21 1.60 2.01 2.37 2.52 2.42 2.15

6 75 1.79 2.37 2.99 3.53 3.74 3.59 3.18

8 75 2.44 3.22 4.05 4.76 5.00 4.79 4.21

9 75 2.87 3.77 4.75 5.60 5.96 5.75 5.05

11 75 3.63 4.79 5.96 6.84 6.93 6.49 5.58

12.5 75 3.84 5.08 6.43 7.61 8.11 7.84 6.91

16 75 4.50 5.93 7.47 8.81 9.36 9.02 7.92

12.5 75 3.70 5.03 6.55 7.99 8.74 8.53 7.65

16 75 4.63 6.32 8.26 10.2 11.2 11.0 9.85

20 75 5.69 7.69 9.92 12.0 13.0 12.5 11.1

21 75 7.47 9.79 12.1 13.8 14.1 13.2 11.3

26 75 7.54 10.2 13.4 16.6 18.7 18.6 16.9

30 75 8.59 11.7 15.3 18.9 21.2 21.1 19.2

40 75 10.3 14.1 18.7 23.4 26.1 25.4 22.5

42 75 14.5 19.0 23.5 27.2 28.0 26.42 22.6

Evaporating temperature [°F]

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R404A/R507

Valve

Orice

Cond.

type

TGE 10

TGE 20

TGE 40

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 95 0.83 1.12 1.45 1.80 2.07 2.14 2.12

4 95 1.11 1.51 1.96 2.44 2.82 2.91 2.89

6 95 1.63 2.21 2.89 3.59 4.14 4.28 4.25

8 95 2.20 2.98 3.88 4.81 5.52 5.67 5.61

9 95 2.62 3.52 4.57 5.62 6.43 6.64 6.65

11 95 3.28 4.47 5.80 7.06 7.84 7.88 7.60

12.5 95 3.47 4.70 6.14 7.58 8.68 8.97 8.98

16 95 4.07 5.50 7.15 8.81 10.1 10.4 10.4

12.5 95 3.31 4.59 6.16 7.92 9.46 9.92 10.0

16 95 4.11 5.72 7.70 9.95 12.0 12.6 12.8

20 95 5.05 6.97 9.28 11.8 14.0 14.6 14.6

21 95 7.01 9.41 12.0 14.3 15.7 15.8 15.4

26 95 6.73 9.30 12.5 16.1 19.3 20.4 21.1

30 95 7.65 10.6 14.2 18.3 21.9 23.2 23.8

40 95 9.05 12.6 17.2 22.8 28.1 29.6 29.9

42 95 13.8 18.4 23.5 28.3 31.4 31.9 31.3

Evaporating temperature [°F]

Subcooling correction factor 'fsub'

Subcooling [K] 2 4 10 15 20 25 30

Correction factor 0.97 1.00 1.08 1.15 1.22 1.29 1.36

Distributer correction factor 'fp' *

Pressure

drop [bar]

Δp

0 1 1 1 1 1 1 1

1 0.96 0.96 0.96 0.95 0.94 0.92 0.91

1.5 0.94 0.94 0.94 0.93 0.91 0.88 0.86

2 0.92 0.92 0.91 0.90 0.88 0.84 0.80

*Calculated at 32 °C condensing temperature.

-40 -30 -20 -10 0 10 15

Evaporating temperature [°C]

Correction factor

© Danfoss | DCS (az) | 2019.01

Subcooling correction factor 'fsub'

Subcooling [°F] 2 7 10 20 30 40 50

Correction factor 0.96 1.00 1.02 1.10 1.18 1.25 1.33

Distributer correction factor 'fp' *

Pressure

drop [psi]

Δp

0 1 1 1 1 1 1 1

15 0.96 0.96 0.96 0.95 0.93 0.92 0.90

25 0.94 0.93 0.92 0.91 0.89 0.87 0.83

30 0.92 0.92 0.91 0.89 0.86 0.84 0.79

*Calculated at 90 °F condensing temperature.

-40 -20 0 20 40 50 60

Evaporating temperature [°F]

Correction factor

DKRCC.PD.AXV.3A.02 | 34

Data sheet | Thermostatic expansion valves, type TGE 10, TGE 20, TGE 40

Capacity in kW. -40 – 15 °C
Opening superheat sh = 4 K SI units R404A/R507

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -30 -20 -10 0 10 15

[°C]

3 45 2.57 3.44 4.47 5.64 6.83 7.81 8.10

4 45 3.43 4.61 6.00 7.58 9.22 10.6 11.0

6 45 4.98 6.70 8.74 11.1 13.5 15.4 16.0

8 45 6.67 8.97 11.7 14.8 17.9 20.4 21.1

9 45 8.01 10.7 13.9 17.4 20.8 23.6 24.5

11 45 9.94 13.5 17.7 22.2 26.4 29.1 29.4

12.5 45 10.5 14.1 18.5 23.3 27.9 31.6 32.8

16 45 12.3 16.5 21.6 27.2 32.6 37.0 38.4

12.5 45 10.0 13.6 18.1 23.5 29.4 34.7 36.6

16 45 12.3 16.8 22.4 29.2 36.8 43.8 46.3

20 45 15.1 20.6 27.2 35.0 43.7 51.4 54.0

21 45 22.1 29.4 37.7 46.0 53.1 57.5 58.4

26 45 20.2 27.5 36.6 47.5 58.9 69.4 73.9

30 45 22.9 31.1 41.6 53.9 66.8 78.6 83.5

40 45 26.8 36.5 49.4 65.9 85.5 104 110

42 45 44.0 58.0 74.1 91.1 106 117 119

Evaporating temperature [°C]

Capacity in kW. -40 – 15 °C

Opening superheat sh = 4 K SI units R404A/R507

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -30 -20 -10 0 10 15

[°C]

3 55 2.13 2.91 3.83 4.92 6.11 7.25 7.72

4 55 2.82 3.86 5.11 6.57 8.19 9.75 10.4

6 55 4.04 5.55 7.36 9.49 11.9 14.1 15.0

8 55 5.36 7.37 9.77 12.6 15.7 18.6 19.8

9 55 6.39 8.72 11.6 14.9 18.4 21.6 23.0

11 55 7.95 11.2 15.0 19.3 23.7 27.3 28.4

12.5 55 8.25 11.4 15.3 19.8 24.5 28.8 30.7

16 55 9.70 13.4 17.9 23.2 28.8 34.0 36.2

12.5 55 8.07 11.1 14.9 19.6 25.0 30.7 33.3

16 55 9.86 13.6 18.3 24.2 31.1 38.4 41.7

20 55 12.1 16.7 22.2 29.1 37.1 45.6 49.3

21 55 18.3 25.0 32.8 41.0 48.5 54.3 56.3

26 55 15.8 21.9 29.7 39.3 50.1 61.0 66.2

30 55 17.8 24.7 33.6 44.5 56.7 69.0 74.9

40 55 21.0 29.0 39.6 53.8 72.0 92.2 101

42 55 37.1 49.9 65.2 81.9 98.0 111 116

Evaporating temperature [°C]

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R404A/R507

Valve

Orice

Cond.

type

TGE 10

TGE 20

TGE 40

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 115 0.72 0.99 1.32 1.70 2.06 2.21 2.31

4 115 0.96 1.33 1.77 2.28 2.78 2.99 3.12

6 115 1.39 1.93 2.58 3.33 4.06 4.36 4.55

8 115 1.85 2.58 3.45 4.43 5.39 5.76 5.99

9 115 2.23 3.06 4.09 5.20 6.24 6.65 6.95

11 115 2.76 3.89 5.23 6.65 7.87 8.23 8.34

12.5 115 2.91 4.05 5.45 6.97 8.37 8.92 9.33

16 115 3.42 4.75 6.37 8.14 9.78 10.4 10.9

12.5 115 2.78 3.91 5.36 7.10 8.96 9.78 10.4

16 115 3.42 4.84 6.64 8.85 11.2 12.3 13.1

20 115 4.20 5.90 8.02 10.6 13.3 14.5 15.3

21 115 6.16 8.47 11.1 13.7 15.7 16.3 16.6

26 115 5.60 7.89 10.8 14.3 17.9 19.5 21.0

30 115 6.34 8.94 12.3 16.3 20.3 22.1 23.7

40 115 7.42 10.5 14.7 20.1 26.5 29.3 31.4

42 115 12.3 16.7 21.9 27.2 31.6 33.1 34.0

Evaporating temperature [°F]

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R404A/R507

Valve

Orice

Cond.

type

TGE 10

TGE 20

TGE 40

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 135 0.57 0.81 1.10 1.44 1.81 1.99 2.14

4 135 0.76 1.08 1.47 1.93 2.43 2.67 2.87

6 135 1.08 1.54 2.11 2.78 3.51 3.86 4.15

8 135 1.43 2.04 2.79 3.68 4.63 5.08 5.45

9 135 1.69 2.40 3.31 4.36 5.43 5.93 6.38

11 135 2.12 3.10 4.29 5.65 6.99 7.52 7.87

12.5 135 2.18 3.13 4.36 5.78 7.23 7.89 8.49

16 135 2.56 3.68 5.11 6.78 8.50 9.30 10.0

12.5 135 2.16 3.08 4.25 5.73 7.45 8.33 9.13

16 135 2.63 3.77 5.23 7.08 9.27 10.4 11.4

20 135 3.22 4.61 6.34 8.50 11.0 12.4 13.5

21 135 4.91 6.96 9.40 12.0 14.2 15.0 15.7

26 135 4.16 6.00 8.46 11.5 14.8 16.5 18.2

30 135 4.68 6.77 9.56 13.0 16.8 18.7 20.6

40 135 5.57 7.99 11.3 15.9 21.8 25.0 27.9

42 135 10.0 14.0 18.8 24.0 28.8 30.8 32.4

Evaporating temperature [°F]

Subcooling correction factor 'fsub'

Subcooling [K] 2 4 10 15 20 25 30

Correction factor 0.97 1.00 1.08 1.15 1.22 1.29 1.36

Distributer correction factor 'fp' *

Pressure

drop [bar]

Δp

0 1 1 1 1 1 1 1

1 0.96 0.96 0.96 0.95 0.94 0.92 0.91

1.5 0.94 0.94 0.94 0.93 0.91 0.88 0.86

2 0.92 0.92 0.91 0.90 0.88 0.84 0.80

*Calculated at 32 °C condensing temperature.

-40 -30 -20 -10 0 10 15

Evaporating temperature [°C]

Correction factor

© Danfoss | DCS (az) | 2019.01

Subcooling correction factor 'fsub'

Subcooling [°F] 2 7 10 20 30 40 50

Correction factor 0.96 1.00 1.02 1.10 1.18 1.25 1.33

Distributer correction factor 'fp' *

Pressure

drop [psi]

Δp

0 1 1 1 1 1 1 1

15 0.96 0.96 0.96 0.95 0.93 0.92 0.90

25 0.94 0.93 0.92 0.91 0.89 0.87 0.83

30 0.92 0.92 0.91 0.89 0.86 0.84 0.79

*Calculated at 90 °F condensing temperature.

-40 -20 0 20 40 50 60

Evaporating temperature [°F]

Correction factor

DKRCC.PD.AXV.3A.02 | 35

Data sheet | Thermostatic expansion valves, type TGE 10, TGE 20, TGE 40

Capacity in kW. -40 – 15 °C.
Opening superheat sh = 4 K SI units R407C

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

3 25 4.13 5.24 6.49 7.76 8.80 9.24 9.07

4 25 5.58 7.09 8.80 10.6 12.0 12.6 12.4

6 25 8.23 10.5 13.0 15.6 17.8 18.7 18.3

8 25 112 14.2 17.6 21.1 23.9 24.9 24.3

9 25 13.3 16.9 21.0 25.2 28.7 30.1 29.3

11 25 16.5 21.2 26.3 31.1 34.2 34.4 32.9

12.5 25 17.7 22.6 28.2 34.0 38.9 40.9 39.8

16 25 20.8 26.4 32.8 39.4 45.0 47.2 46.0

12.5 25 16.7 21.8 27.9 34.6 40.7 44.2 44.0

16 25 20.8 27.2 35.0 43.6 51.6 56.4 56.3

20 25 25.7 33.4 42.5 52.2 60.8 65.2 64.4

21 25 35.0 44.6 55.0 64.7 71.3 71.5 67.9

26 25 33.4 43.3 55.4 69.4 83.0 92.1 92.6

30 25 38.1 49.3 63.1 79.0 94.4 105 105

40 25 45.8 59.4 76.5 96.8 117 129 127

42 25 66.1 83.1 102 121 136 139 133

-40 -30 -20 -10 0 10 15

[°C]

Evaporating temperature [°C]

Capacity in kW. -40 – 15 °C.
Opening superheat sh = 4 K SI units R407C

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

3 35 4.00 5.14 6.49 7.96 9.36 10.4 10.7

4 35 5.37 6.91 8.74 10.8 12.7 14.1 14.5

6 35 7.84 10.1 12.8 15.8 18.6 20.8 21.3

8 35 10.5 13.6 17.2 21.2 24.9 27.6 28.2

9 35 12.7 16.3 20.6 25.3 29.8 33.2 34.0

11 35 15.6 20.3 26.0 31.8 36.6 38.9 38.9

12.5 35 16.7 21.6 27.5 33.9 40.1 44.7 45.8

16 35 19.7 25.4 32.1 39.4 46.6 52.0 53.4

12.5 35 15.7 20.6 26.8 34.0 41.5 47.8 49.9

16 35 19.4 25.6 33.4 42.5 52.2 60.5 63.3

20 35 23.9 31.3 40.5 51.0 61.9 70.7 73.3

21 35 34.6 44.6 55.8 67.1 76.3 81.2 81.2

26 35 31.5 41.0 53.1 67.6 83.2 97.2 103

30 35 35.7 46.5 60.3 76.8 94.4 110 116

40 35 42.5 55.6 72.5 93.9 119 142 148

42 35 66.3 84.1 105 127 146 158 160

-40 -30 -20 -10 0 10 15

[°C]

Evaporating temperature [°C]

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R407C

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 75 1.17 1.52 1.92 2.30 2.55 2.57 2.49

4 75 1.59 2.07 2.61 3.13 3.48 3.52 3.41

6 75 2.35 3.05 3.86 4.63 5.15 5.21 5.04

8 75 3.19 4.15 5.23 6.26 6.91 6.95 6.70

9 75 3.79 4.92 6.21 7.48 8.34 8.40 8.04

11 75 4.72 6.18 7.77 9.13 9.72 9.57 9.02

12.5 75 5.04 6.59 8.37 10.1 11.3 11.4 10.9

16 75 5.92 7.71 9.74 11.7 13.1 13.2 12.6

12.5 75 4.76 6.39 8.35 10.4 12.0 12.4 12.2

16 75 5.94 8.00 10.5 13.2 15.3 15.8 15.6

20 75 7.33 9.79 12.7 15.7 17.9 18.2 17.8

21 75 9.93 13.0 16.2 19.0 20.3 19.9 18.5

26 75 9.54 12.7 16.6 21.0 24.8 25.8 25.6

30 75 10.9 14.5 18.9 23.9 28.2 29.3 29.1

40 75 13.1 17.5 23.0 29.5 35.0 36.0 34.9

42 75 18.7 24.1 30.1 35.7 38.8 38.6 36.2

Evaporating temperature [°F]

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R407C

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 95 1.14 1.50 1.93 2.40 2.81 2.95 3.04

4 95 1.52 2.02 2.61 3.24 3.81 4.01 4.13

6 95 2.23 2.95 3.82 4.76 5.60 5.90 6.06

8 95 2.99 3.97 5.13 6.38 7.47 7.83 8.01

9 95 3.62 4.77 6.15 7.64 8.96 9.43 9.67

11 95 4.42 5.94 7.74 9.53 10.8 11.1 11.0

12.5 95 4.75 6.31 8.20 10.2 12.1 12.7 13.0

16 95 5.58 7.40 9.56 11.9 14.0 14.8 15.2

12.5 95 4.46 6.04 8.05 10.4 12.7 13.6 14.2

16 95 5.51 7.48 10.0 13.0 16.0 17.2 18.1

20 95 6.79 9.16 12.1 15.5 18.8 20.1 20.9

21 95 9.81 13.0 16.6 20.0 22.5 23.1 23.0

26 95 8.93 12.0 16.0 20.7 25.5 27.6 29.2

30 95 10.1 13.6 18.1 23.5 28.9 31.3 33.1

40 95 12.1 16.3 21.8 29.0 36.8 40.2 42.3

42 95 18.8 24.5 31.1 37.9 43.4 45.0 45.4

Evaporating temperature [°F]

Subcooling correction factor 'fsub'

Subcooling [K] 2 4 10 15 20 25 30

Correction factor 0.98 1.00 1.06 1.12 1.17 1.22 1.27

Distributer correction factor 'fp' *

Pressure

drop [bar]

Δp

0 1 1 1 1 1 1 1

1 0.96 0.96 0.96 0.95 0.95 0.93 0.92

1.5 0.94 0.94 0.94 0.93 0.92 0.90 0.88

2 0.92 0.92 0.91 0.91 0.89 0.86 0.84

*Calculated at 32 °C condensing temperature.

-40 -30 -20 -10 0 10 15

Evaporating temperature [°C]

Correction factor

© Danfoss | DCS (az) | 2019.01

Subcooling correction factor 'fsub'

Subcooling [°F] 2 7 10 20 30 40 50

Correction factor 0.97 1.00 1.02 1.08 1.14 1.19 1.25

Distributer correction factor 'fp' *

Pressure

drop [psi]

Δp

0 1 1 1 1 1 1 1

15 0.96 0.96 0.96 0.95 0.94 0.93 0.92

25 0.93 0.93 0.93 0.92 0.90 0.88 0.86

30 0.92 0.92 0.91 0.90 0.88 0.86 0.83

*Calculated at 90 °C condensing temperature.

-40 -20 0 20 40 50 60

Evaporating temperature [°F]

Correction factor

DKRCC.PD.AXV.3A.02 | 36

Data sheet | Thermostatic expansion valves, type TGE 10, TGE 20, TGE 40

Capacity in kW. -40 – 15 °C.
Opening superheat sh = 4 K SI units R407C

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

3 45 3.75 4.85 6.20 7.75 9.36 10.8 11.4

4 45 4.98 6.47 8.29 10.4 12.6 14.6 15.4

6 45 7.19 9.35 12.0 15.1 18.4 21.3 22.4

8 45 9.57 12.5 16.0 20.2 24.4 28.1 29.5

9 45 11.8 15.3 19.5 24.4 29.5 33.9 35.7

11 45 14.1 18.7 24.4 30.8 36.8 40.8 41.8

12.5 45 15.2 19.9 25.7 32.4 39.3 45.4 47.7

16 45 17.9 23.4 30.1 37.8 45.8 53.1 56.0

12.5 45 14.3 18.8 24.6 31.7 39.7 47.4 50.8

16 45 17.5 23.1 30.3 39.3 49.4 59.5 63.8

20 45 21.5 28.3 36.8 47.2 58.9 70.1 74.8

21 45 33.1 43.2 54.8 66.9 77.8 85.4 87.6

26 45 28.6 37.5 49.0 63.1 79.1 95.2 103

30 45 32.3 42.4 55.4 71.5 89.6 108 116

40 45 38.3 50.2 65.9 86.6 113 141 154

42 45 64.8 82.7 104 127 150 168 174

-40 -30 -20 -10 0 10 15

[°C]

Evaporating temperature [°C]

Capacity in kW. -40 – 15 °C.
Opening superheat sh = 4 K SI units R407C

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

3 55 3.39 4.41 5.68 7.20 8.86 10.5 11.2

4 55 4.46 5.82 7.54 9.59 11.8 14.1 15.0

6 55 6.35 8.31 10.8 13.8 17.1 20.3 21.7

8 55 8.36 11.0 14.3 18.2 22.6 26.7 28.5

9 55 10.4 13.6 17.7 22.5 27.7 32.7 35.0

11 55 12.2 16.4 21.9 28.3 34.8 40.1 41.8

12.5 55 13.2 17.5 23.0 29.5 36.5 43.4 46.4

16 55 15.5 20.6 26.9 34.4 42.7 51.0 54.8

12.5 55 12.6 16.5 21.6 28.1 35.8 43.8 47.7

16 55 15.3 20.0 26.4 34.5 44.2 54.4 59.4

20 55 18.7 24.5 32.1 41.5 52.6 64.4 70.0

21 55 30.6 40.3 51.8 64.2 75.9 85.3 88.7

26 55 24.9 32.8 43.1 56.1 71.3 87.7 95.8

30 55 28.0 36.9 48.6 63.4 80.7 99.1 108

40 55 33.5 43.8 57.6 76.1 101 130 145

42 55 61.5 79.0 100 124 148 169 177

-40 -30 -20 -10 0 10 15

[°C]

Evaporating temperature [°C]

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R407C

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 115 1.05 1.40 1.84 2.34 2.84 3.07 3.25

4 115 1.40 1.87 2.46 3.14 3.83 4.14 4.39

6 115 2.02 2.70 3.56 4.56 5.58 6.02 6.38

8 115 2.68 3.60 4.75 6.08 7.40 7.96 8.40

9 115 3.30 4.41 5.79 7.37 8.94 9.63 10.2

11 115 3.94 5.41 7.26 9.29 11.0 11.6 11.9

12.5 115 4.27 5.76 7.63 9.78 11.9 12.9 13.6

16 115 5.02 6.76 8.92 11.4 13.9 15.1 16.0

12.5 115 4.01 5.43 7.31 9.64 12.2 13.4 14.5

16 115 4.90 6.66 9.02 12.0 15.2 16.8 18.2

20 115 6.02 8.15 10.9 14.3 18.0 19.8 21.3

21 115 9.33 12.5 16.3 20.0 23.2 24.3 25.0

26 115 8.01 10.8 14.6 19.2 24.3 26.9 29.2

30 115 9.04 12.2 16.5 21.7 27.6 30.4 33.1

40 115 10.7 14.5 19.6 26.6 35.3 39.9 44.0

42 115 18.3 24.0 30.9 38.3 45.1 47.8 49.6

Evaporating temperature [°F]

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R407C

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 135 0.94 1.25 1.66 2.15 2.68 2.93 3.16

4 135 1.23 1.65 2.20 2.86 3.58 3.92 4.24

6 135 1.74 2.35 3.14 4.10 5.15 5.66 6.11

8 135 2.29 3.10 4.15 5.42 6.78 7.43 8.01

9 135 2.85 3.86 5.16 6.70 8.35 9.14 9.87

11 135 3.32 4.64 6.39 8.44 10.4 11.2 11.80

12.5 135 3.60 4.95 6.69 8.77 11.0 12.1 13.1

16 135 4.23 5.82 7.83 10.3 12.9 14.2 15.5

12.5 135 3.46 4.66 6.30 8.40 10.9 12.1 13.4

16 135 4.18 5.65 7.69 10.3 13.4 15.0 16.6

20 135 5.12 6.92 9.31 12.4 15.9 17.8 19.6

21 135 8.49 11.6 15.2 19.1 22.6 24.0 25.1

26 135 6.80 9.24 12.5 16.7 21.6 24.2 26.8

30 135 7.63 10.4 14.1 18.9 24.5 27.4 30.3

40 135 9.16 12.4 16.8 22.9 31.1 35.9 40.7

42 135 17.2 22.7 29.5 37.1 44.5 47.7 50.3

Evaporating temperature [°F]

Subcooling correction factor 'fsub'

Subcooling [K] 2 4 10 15 20 25 30

Correction factor 0.98 1.00 1.06 1.12 1.17 1.22 1.27

Distributer correction factor 'fp' *

Pressure

drop [bar]

Δp

0 1 1 1 1 1 1 1

1 0.96 0.96 0.96 0.95 0.95 0.93 0.92

1.5 0.94 0.94 0.94 0.93 0.92 0.90 0.88

2 0.92 0.92 0.91 0.91 0.89 0.86 0.84

*Calculated at 32 °C condensing temperature.

-40 -30 -20 -10 0 10 15

Evaporating temperature [°C]

Correction factor

© Danfoss | DCS (az) | 2019.01

Subcooling correction factor 'fsub'

Subcooling [°F] 2 7 10 20 30 40 50

Correction factor 0.97 1.00 1.02 1.08 1.14 1.19 1.25

Distributer correction factor 'fp' *

Pressure

drop [psi]

Δp

0 1 1 1 1 1 1 1

15 0.96 0.96 0.96 0.95 0.94 0.93 0.92

25 0.93 0.93 0.93 0.92 0.90 0.88 0.86

30 0.92 0.92 0.91 0.90 0.88 0.86 0.83

*Calculated at 90 °F condensing temperature.

-40 -20 0 20 40 50 60

Evaporating temperature [°F]

Correction factor

DKRCC.PD.AXV.3A.02 | 37

Data sheet | Thermostatic expansion valves, type TGE 10, TGE 20, TGE 40

Capacity in kW. -40 – 15 °C
Opening superheat sh = 4 K SI units R290

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -30 -20 -10 0 10 15

[°C]

3 25 4.76 5.99 7.27 8.42 9.14 8.85 8.03

4 25 6.47 8.15 9.90 11.5 12.5 12.1 11.0

6 25 9.60 12.1 14.7 17.1 18.6 18.0 16.3

8 25 13.1 16.5 20.0 23.1 25.0 24.0 21.6

9 25 15.3 19.4 23.6 27.5 29.9 29.0 26.0

11 25 19.5 24.5 29.5 33.4 35.0 32.5 28.7

12.5 25 19.9 25.1 30.6 35.8 39.0 38.0 34.3

16 25 23.3 29.3 35.6 41.4 45.0 43.7 39.3

12.5 25 18.5 23.7 29.6 35.4 39.7 39.7 36.5

16 25 23.2 29.9 37.4 45.0 50.7 50.9 47.0

20 25 28.7 36.6 45.3 53.7 59.7 58.8 53.6

21 25 36.6 45.9 55.4 63.3 67.1 63.0 55.8

26 25 39.3 51.2 64.5 78.1 89.0 90.5 83.9

30 25 44.8 58.4 73.6 89.1 101 103 95.2

40 25 53.9 70.2 89.3 109 125 125 114

42 25 72.9 91.5 111 128 136 129 115

Evaporating temperature [°C]

Capacity in kW. -40 – 15 °C

Opening superheat sh = 4 K SI units R290

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -30 -20 -10 0 10 15

[°C]

3 35 4.68 5.98 7.40 8.84 10.1 10.8 10.7

4 35 6.32 8.08 10.0 12.0 13.7 14.7 14.6

6 35 9.30 11.9 14.8 17.7 20.3 21.6 21.4

8 35 12.6 16.1 20.0 23.8 27.1 28.7 28.4

9 35 14.8 19.0 23.6 28.2 32.1 34.1 34.0

11 35 18.8 24.2 29.8 35.1 38.8 39.6 38.3

12.5 35 19.0 24.4 30.4 36.5 41.7 44.5 44.3

16 35 22.3 28.5 35.4 42.4 48.3 51.5 51.2

12.5 35 17.7 23.0 29.2 36.0 42.6 46.9 47.2

16 35 22.2 28.8 36.7 45.5 54.0 59.8 60.4

20 35 27.3 35.3 44.5 54.4 63.8 69.6 69.7

21 35 36.4 46.3 56.8 66.7 74.0 76.3 74.6

26 35 36.8 48.6 62.3 77.6 92.8 104 106

30 35 41.9 55.3 70.9 88.3 106 118 120

40 35 50.5 66.5 86.1 109 132 147 148

42 35 73.3 93.1 115 135 151 157 155

Evaporating temperature [°C]

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R290

Valve

Orice

Cond.

type

TGE 10

TGE 20

TGE 40

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 75 1.35 1.74 2.13 2.45 2.55 2.44 2.12

4 75 1.84 2.37 2.90 3.35 3.49 3.34 2.91

6 75 2.73 3.52 4.32 4.99 5.19 4.95 4.31

8 75 3.73 4.79 5.87 6.74 6.96 6.61 5.72

9 75 4.37 5.63 6.94 8.03 8.37 7.98 6.85

11 75 5.54 7.12 8.61 9.63 9.59 8.92 7.58

12.5 75 5.65 7.29 9.02 10.5 11.0 10.5 9.03

16 75 6.63 8.51 10.5 12.1 12.6 12.0 10.3

12.5 75 5.26 6.91 8.76 10.5 11.3 10.9 9.71

16 75 6.62 8.73 11.1 13.3 14.5 14.1 12.5

20 75 8.17 10.7 13.4 15.8 16.9 16.2 14.2

21 75 10.4 13.3 16.2 18.3 18.5 17.3 14.7

26 75 11.2 15.0 19.2 23.3 25.6 25.0 22.3

30 75 12.8 17.1 21.9 26.5 29.1 28.5 25.3

40 75 15.4 20.6 26.6 32.6 35.6 34.4 30.1

42 75 20.7 26.5 32.4 37.0 37.8 35.5 30.3

Evaporating temperature [°F]

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R290

Valve

Orice

Cond.

type

TGE 10

TGE 20

TGE 40

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 95 1.33 1.74 2.19 2.64 2.98 3.05 3.02

4 95 1.79 2.35 2.97 3.59 4.06 4.16 4.12

6 95 2.64 3.47 4.39 5.30 5.99 6.14 6.07

8 95 3.57 4.69 5.92 7.12 7.99 8.16 8.02

9 95 4.21 5.53 7.00 8.42 9.46 9.69 9.62

11 95 5.33 7.04 8.81 10.4 11.3 11.2 10.8

12.5 95 5.40 7.10 9.03 10.9 12.3 12.6 12.6

16 95 6.33 8.30 10.5 12.7 14.3 14.6 14.5

12.5 95 5.03 6.71 8.71 10.9 12.8 13.3 13.4

16 95 6.29 8.41 11.0 13.8 16.2 17.0 17.1

20 95 7.76 10.3 13.2 16.4 19.1 19.8 19.7

21 95 10.3 13.5 16.8 19.8 21.5 21.7 21.1

26 95 10.5 14.2 18.6 23.5 28.0 29.5 30.0

30 95 11.9 16.2 21.2 26.8 31.8 33.5 34.0

40 95 14.3 19.4 25.8 33.2 39.9 41.8 41.9

42 95 20.8 27.1 33.9 40.2 44.2 44.7 43.7

Evaporating temperature [°F]

Subcooling correction factor 'fsub'

Subcooling [K] 2 4 10 15 20 25 30

Correction factor 0.98 1.00 1.06 1.11 1.16 1.21 1.26

Distributer correction factor 'fp' *

Pressure

drop [bar]

Δp

0 1 1 1 1 1 1 1

1 0.95 0.95 0.94 0.93 0.92 0.89 0.87

1.5 0.92 0.92 0.91 0.90 0.88 0.84 0.79

2 0.90 0.89 0.88 0.86 0.83 0.77 0.71

*Calculated at 32 °C condensing temperature.

-40 -30 -20 -10 0 10 15

Evaporating temperature [°C]

Correction factor

© Danfoss | DCS (az) | 2019.01

Subcooling correction factor 'fsub'

Subcooling [°F] 2 7 10 20 30 40 50

Correction factor 0.97 1.00 1.02 1.07 1.13 1.18 1.24

Distributer correction factor 'fp' *

Pressure

drop [psi]

Δp

0 1 1 1 1 1 1 1

15 0.95 0.94 0.94 0.93 0.91 0.89 0.86

25 0.91 0.91 0.90 0.88 0.84 0.81 0.75

30 0.89 0.89 0.87 0.85 0.81 0.77 0.69

*Calculated at 90 °F condensing temperature.

-40 -20 0 20 40 50 60

Evaporating temperature [°F]

Correction factor

DKRCC.PD.AXV.3A.02 | 38

Data sheet | Thermostatic expansion valves, type TGE 10, TGE 20, TGE 40

Capacity in kW. -40 – 15 °C
Opening superheat sh = 4 K SI units R290

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -30 -20 -10 0 10 15

[°C]

3 45 4.48 5.78 7.25 8.85 10.4 11.7 12.1

4 45 6.00 7.76 9.76 11.9 14.1 15.9 16.4

6 45 8.73 11.3 14.3 17.5 20.7 23.2 24.0

8 45 11.7 15.2 19.2 23.4 27.6 30.8 31.6

9 45 13.8 18.0 22.7 27.7 32.5 36.2 37.4

11 45 17.5 23.0 29.0 35.0 40.3 43.4 43.7

12.5 45 17.5 22.8 29.0 35.7 42.0 46.9 48.5

16 45 20.6 26.7 33.9 41.5 48.8 54.6 56.5

12.5 45 16.5 21.6 27.7 34.8 42.4 49.2 51.7

16 45 20.5 26.8 34.5 43.6 53.4 62.3 65.6

20 45 25.3 32.9 41.9 52.4 63.4 73.2 76.6

21 45 35.0 45.1 56.3 67.4 76.9 83.0 84.2

26 45 33.5 44.6 57.8 73.3 90.3 107 113

30 45 37.9 50.6 65.6 83.2 103 121 128

40 45 45.8 60.8 79.7 103 130 155 163

42 45 71.5 91.8 115 138 158 172 175

Evaporating temperature [°C]

Capacity in kW. -40 – 15 °C

Opening superheat sh = 4 K SI units R290

Valve

Orice

type

TGE 10

TGE 20

TGE 40

Cond.

no.

temp.

-40 -30 -20 -10 0 10 15

[°C]

3 55 4.16 5.42 6.87 8.49 10.2 11.8 12.5

4 55 5.54 7.23 9.19 11.4 13.7 15.9 16.8

6 55 7.97 10.4 13.3 16.5 19.9 23.1 24.4

8 55 10.6 13.9 17.7 22.0 26.4 30.5 32.2

9 55 12.4 16.3 21.0 26.1 31.3 35.9 37.9

11 55 15.7 21.1 27.1 33.4 39.5 44.2 45.5

12.5 55 15.5 20.5 26.5 33.2 40.1 46.3 48.9

16 55 18.2 24.0 31.0 38.8 46.8 54.2 57.4

12.5 55 15.0 19.7 25.3 32.2 39.9 47.8 51.3

16 55 18.5 24.3 31.4 40.0 49.9 60.0 64.7

20 55 22.7 29.7 38.2 48.2 59.5 71.0 76.1

21 55 32.6 42.6 53.8 65.4 76.2 84.6 87.6

26 55 29.5 39.6 51.8 66.3 83.1 101 110

30 55 33.3 44.7 58.6 75.1 94.1 114 124

40 55 40.3 53.6 70.8 93.0 120 150 163

42 55 67.8 87.8 111 135 158 177 184

Evaporating temperature [°C]

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R290

Valve

Orice

Cond.

type

TGE 10

TGE 20

TGE 40

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 115 1.26 1.67 2.15 2.66 3.14 3.33 3.46

4 115 1.69 2.25 2.89 3.59 4.25 4.52 4.70

6 115 2.46 3.28 4.23 5.26 6.23 6.62 6.87

8 115 3.30 4.40 5.67 7.02 8.28 8.76 9.06

9 115 3.88 5.19 6.72 8.31 9.74 10.3 10.7

11 115 4.91 6.65 8.57 10.5 12.0 12.4 12.5

12.5 115 4.92 6.60 8.59 10.7 12.6 13.3 13.9

16 115 5.78 7.73 10.0 12.4 14.7 15.5 16.2

12.5 115 4.65 6.24 8.22 10.5 12.9 14.0 14.8

16 115 5.76 7.76 10.3 13.2 16.3 17.7 18.8

20 115 7.10 9.51 12.4 15.8 19.3 20.8 21.9

21 115 9.89 13.1 16.6 20.1 22.8 23.7 24.1

26 115 9.39 12.9 17.2 22.2 27.6 30.2 32.2

30 115 10.6 14.6 19.5 25.2 31.4 34.2 36.5

40 115 12.8 17.6 23.7 31.5 40.1 43.9 46.7

42 115 20.2 26.7 33.9 41.2 47.1 49.1 50.3

Evaporating temperature [°F]

Capactiy in TR. -40 – 60 °F
Opening superheat sh = 7.2 °F US units R290

Valve

Orice

Cond.

type

TGE 10

TGE 20

TGE 40

no.

temp.

-40 -20 0 20 40 50 60

[°F]

3 135 1.16 1.55 2.01 2.53 3.07 3.32 3.54

4 135 1.54 2.07 2.69 3.40 4.14 4.48 4.78

6 135 2.21 2.98 3.89 4.93 6.00 6.50 6.94

8 135 2.93 3.96 5.17 6.54 7.94 8.58 9.11

9 135 3.39 4.64 6.12 7.76 9.37 10.1 10.8

11 135 4.34 6.02 7.93 9.94 11.8 12.5 13.0

12.5 135 4.25 5.81 7.73 9.88 12.0 13.0 13.9

16 135 4.99 6.81 9.03 11.5 14.1 15.2 16.3

12.5 135 4.16 5.60 7.42 9.62 12.1 13.4 14.5

16 135 5.11 6.90 9.18 12.0 15.1 16.8 18.3

20 135 6.28 8.46 11.1 14.4 18.0 19.8 21.5

21 135 9.06 12.2 15.8 19.4 22.7 24.0 25.0

26 135 8.10 11.3 15.1 19.8 25.3 28.1 30.8

30 135 9.12 12.7 17.1 22.4 28.6 31.8 34.9

40 135 11.1 15.2 20.7 28.0 37.0 41.7 46.1

42 135 18.9 25.3 32.6 40.2 47.2 50.1 52.4

Evaporating temperature [°F]

Subcooling correction factor 'fsub'

Subcooling [K] 2 4 10 15 20 25 30

Correction factor 0.98 1.00 1.06 1.11 1.16 1.21 1.26

Distributer correction factor 'fp' *

Pressure

drop [bar]

Δp

0 1 1 1 1 1 1 1

1 0.95 0.95 0.94 0.93 0.92 0.89 0.87

1.5 0.92 0.92 0.91 0.90 0.88 0.84 0.79

2 0.90 0.89 0.88 0.86 0.83 0.77 0.71

*Calculated at 32 °C condensing temperature.

-40 -30 -20 -10 0 10 15

Evaporating temperature [°C]

Correction factor

© Danfoss | DCS (az) | 2019.01

Subcooling correction factor 'fsub'

Subcooling [°F] 2 7 10 20 30 40 50

Correction factor 0.97 1.00 1.02 1.07 1.13 1.18 1.24

Distributer correction factor 'fp' *

Pressure

drop [psi]

Δp

0 1 1 1 1 1 1 1

15 0.95 0.94 0.94 0.93 0.91 0.89 0.86

25 0.91 0.91 0.90 0.88 0.84 0.81 0.75

30 0.89 0.89 0.87 0.85 0.81 0.77 0.69

*Calculated at 90 °F condensing temperature.

-40 -20 0 20 40 50 60

Evaporating temperature [°F]

Correction factor

DKRCC.PD.AXV.3A.02 | 39

ØD1

Data sheet | Thermostatic expansion valves, type TGE 10, TGE 20, TGE 40

Dimensions and weights

Danfoss
67N50.10

H3

H1

Dimensions and weight in SI units

Type Connections. ODF solder

inlet x outlet x equalization

[in.] [mm] [m] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [mm] [kg]

3

⁄8 x 5⁄8 x 1⁄4 10 x 16 x 6 1.5 28.5 7.5 5.0 93.0 41.5 45.5 37.0 70 45 14.35 9.0 12 7 0.37

1

⁄2 x 5⁄8 x 1⁄4 12 x 16 x 6 1.5 28.5 7.5 5.0 93.0 41.5 45.5 37.0 70 45 14.35 10 12 7 0.37

1

⁄2 x 7⁄8 x 1⁄4 12 x 22 x 6 1.5 28.5 7.5 5.0 93.0 41.5 59.5 37.0 70 45 14.35 10 17 7 0.37

5

TGE 10

TGE 20

TGE 40

⁄8 x 5⁄8 x 1⁄4 16 x 16 x 6 1.5 28.5 7.5 5.0 93.0 45.5 45.5 37.0 70 45 14.35 12 12 7 0.37

5

⁄8 x 7⁄8 x 1⁄4 16 x 22 x 6 1.5 28.5 7.5 5.0 93.0 45.5 59.5 37.0 70 45 14.35 12 17 7 0.37

5

⁄8 x 1 1⁄8 x 1⁄4 16 x 28 x 6 1.5 28.5 7.5 5.0 93.0 45.5 59.5 37.0 70 45 14.35 12 20 7 0.37

7

⁄8 x 7⁄8 x 1⁄4 22 x 22 x 6 1.5 28.5 7.5 5.0 93.0 45.5 59.5 37.0 70 45 14.35 12 17 7 0.37

7

⁄8 x 1 1⁄8 x 1⁄4 22 x 28 x 6 1.5 28.5 7.5 5.0 93.0 45.5 59.5 37.0 70 45 14.35 12 20 7 0.37

5

⁄8 x 5⁄8 x 1⁄4 16 x 16 x 6 1.5 32.0 9.0 8.0 121 48.0 62.0 40.5 78 53 19.20 12 12 7 0.57

5

⁄8 x 7⁄8 x 1⁄4 16 x 22 x 6 1.5 32.0 9.0 8.0 121 48.0 62.0 40.5 78 53 19.20 12 17 7 0.57

5

⁄8 x 1 1⁄8 x 1⁄4 16 x 28 x 6 1.5 32.0 9.0 8.0 121 48.0 66.0 40.5 78 53 19.20 12 20 7 0.57

7

⁄8 x 7⁄8 x 1⁄4 22 x 22 x 6 1.5 32.0 9.0 8.0 121 62.0 62.0 40.5 78 53 19.20 17 17 7 0.57

7

⁄8 x 1 1⁄8 x 1⁄4 22 x 28 x 6 1.5 32.0 9.0 8.0 121 62.0 66.0 40.5 78 53 19.20 17 20 7 0.57

7

⁄8 x 1 3⁄8 x 1⁄4 22 x 35 x 6 1.5 32.0 9.0 8.0 121 62.0 66.0 40.5 78 53 19.20 17 24 7 0.57

1 1⁄8 x 1 1⁄8 x 1⁄4 28 x 28 x 6 1.5 32.0 9.0 8.0 121 62.0 66.0 40.5 78 53 19.20 20 20 7 0.57

1 1⁄8 x 1 3⁄8 x 1⁄4 28 x 35 x 6 1.5 32.0 9.0 8.0 121 62.0 66.0 40.5 78 53 19.20 20 24 7 0.57

7

⁄8 x 7⁄8 x 1⁄4 22 x 22 x 6 3 39.0 15 11 148 65.5 69.5 43.5 78 60 19.20 17 20 7 0.93

7

⁄8 x 1 1⁄8 x 1⁄4 22 x 28 x 6 3 39.0 15 11 148 65.5 69.5 43.5 78 60 19.20 17 20 7 0.93

7

⁄8 x 1 3⁄8 x 1⁄4 22 x 35 x 6 3 39.0 15 11 148 65.5 74.5 43.5 78 60 19.20 17 25 7 0.93

1 1⁄8 x 1 1⁄8 x 1⁄4 28 x 28 x 6 3 39.0 15 11 148 69.5 69.5 43.5 78 60 19.20 20 20 7 0.93

1 1⁄8 x 1 3⁄8 x 1⁄4 28 x 35 x 6 3 39.0 15 11 148 69.5 74.5 43.5 78 60 19.20 20 25 7 0.93

B

Capillary

tube length

L4

H2

A

H4

ØD2

L2

L1

H1 H2 H3 H4 L1 L2 L3 L4 ØD1 ØD2 A B C Weight

C

L3

© Danfoss | DCS (az) | 2019.01

DKRCC.PD.AXV.3A.02 | 40

Dimensions and weights

ØD1

Danfoss
67N50.10

H3

H1

Dimensions and weight in US units

Type Connections. ODF solder

inlet x outlet x equalization

[in.] [mm] [in.] [in] [in.] [in.] [in.] [in.] [in.] [in.] [in.] [in.] [in.] [in.] [in.] [in.]

3/8 x 5/8 x 1/4 10 x 16 x 6 59 1.12 0.30 0.20 3.66 1.63 1.79 1.46 2.76 1.77 0.56 0.36 0.48 0.28 0.81

1/2 x 5/8 x 1/4 12 x 16 x 6 59 1.12 0.30 0.20 3.66 1.63 1.79 1.46 2.76 1.77 0.56 0.39 0.48 0.28 0.81

1/2 x 7/8 x 1/4 12 x 22 x 6 59 1.12 0.30 0.20 3.66 1.63 2.34 1.46 2.76 1.77 0.56 0.39 0.66 0.28 0.81

TGE 10

TGE 20

TGE 40

5/8 x 5/8 x 1/4 16 x 16 x 6 59 1.12 0.30 0.20 3.66 1.79 1.79 1.46 2.76 1.77 0.56 0.48 0.48 0.28 0.81

5/8 x 7/8 x 1/4 16 x 22 x 6 59 1.12 0.30 0.20 3.66 1.79 2.34 1.46 2.76 1.77 0.56 0.48 0.66 0.28 0.81

5/8 x 1 1/8 x 1/4 16 x 28 x 6 59 1.12 0.30 0.20 3.66 1.79 2.34 1.46 2.76 1.77 0.56 0.48 0.78 0.28 0.81

7/8 x 7/8 x 1/4 22 x 22 x 6 59 1.12 0.30 0.20 3.66 1.79 2.34 1.46 2.76 1.77 0.56 0.48 0.66 0.28 0.81

7/8 x 1 1/8 x 1/4 22 x 28 x 6 59 1.12 0.30 0.20 3.66 1.79 2.34 1.46 2.76 1.77 0.56 0.48 0.78 0.28 0.81

5/8 x 5/8 x 1/4 16 x 16 x 6 59 1.26 0.35 0.31 4.76 1.89 2.44 1.59 3.07 2.09 0.76 0.48 0.48 0.28 1.27

5/8 x 7/8 x 1/4 16 x 22 x 6 59 1.26 0.35 0.31 4.76 1.89 2.44 1.59 3.07 2.09 0.76 0.48 0.66 0.28 1.27

5/8 x 1 1/8 x 1/4 16 x 28 x 6 59 1.26 0.35 0.31 4.76 1.89 2.6 1.59 3.07 2.09 0.76 0.48 0.78 0.28 1.27

7/8 x 7/8 x 1/4 22 x 22 x 6 59 1.26 0.35 0.31 4.76 2.44 2.44 1.59 3.07 2.09 0.76 0.66 0.66 0.28 1.27

7/8 x 1 1/8 x 1/4 22 x 28 x 6 59 1.26 0.35 0.31 4.76 2.44 2.6 1.59 3.07 2.09 0.76 0.66 0.78 0.28 1.27

7/8 x 1 3/8 x 1/4 22 x 35 x 6 59 1.26 0.35 0.31 4.76 2.44 2.6 1.59 3.07 2.09 0.76 0.66 0.98 0.28 1.27

1 1/8 x 1 1/8 x 1/4 28 x 28 x 6 59 1.26 0.35 0.31 4.76 2.44 2.6 1.59 3.07 2.09 0.76 0.78 0.78 0.28 1.27

1 1/8 x 1 3/8 x 1/4 28 x 35 x 6 59 1.26 0.35 0.31 4.76 2.44 2.6 1.59 3.07 2.09 0.76 0.78 0.98 0.28 1.27

7/8 x 7/8 x 1/4 22 x 22 x 6 118 1.54 0.59 0.43 5.83 2.58 2.74 1.71 3.07 2.36 0.76 0.66 0.78 0.28 2.05

7/8 x 1 1/8 x 1/4 22 x 28 x 6 118 1.54 0.59 0.43 5.83 2.58 2.74 1.71 3.07 2.36 0.76 0.66 0.78 0.28 2.05

7/8 x 1 3/8 x 1/4 22 x 35 x 6 118 1.54 0.59 0.43 5.83 2.58 2.93 1.71 3.07 2.36 0.76 0.66 0.98 0.28 2.05

1 1/8 x 1 1/8 x 1/4 28 x 28 x 6 118 1.54 0.59 0.43 5.83 2.74 2.74 1.71 3.07 2.36 0.76 0.78 0.78 0.28 2.05

1 1/8 x 1 3/8 x 1/4 28 x 35 x 6 118 1.54 0.59 0.43 5.83 2.74 2.93 1.71 3.07 2.36 0.76 0.78 0.98 0.28 2.05

B

Capillary

tube length

L4

H2

A

L2

H1 H2 H3 H4 L1 L2 L3 L4 ØD1 ØD2 A B C Weight

L1

H4

ØD2

C

L3

[lbs]

© Danfoss | DCS (az) | 2019.01

DKRCC.PD.AXV.3A.02 | 41
