Data Sheet
压力变送器
MBS 1700 与 MBS 1750 型
通用型
MBS 1700 和 MBS 1750 紧凑型压力传感器属于
通用变送器,即使在恶劣环境条件下,也能进
行可靠的压力测量。
MBS 1750 设有集成式脉冲缓冲器,专用于具有
严重介质影响的应用(例如气蚀、水锤或压力
峰值),即使在恶劣环境条件下,也能进行可
靠的压力测量。
抗振稳定性高、耐用性高并且 EMC/EMI 防护能
力高,这款压力变送器达到了最严格的工业标
准。
特性
• 外壳和接触液体部件均采用耐酸不锈钢材料
(AISI 316L)
• 相对 ( 表压 ) 压力范围为 0 – 25 bar
• 输出信号: 4 – 20 mA
• 压力连接:
◦ G 1/4A & G 1/2A EN837 (MBS 1700)
◦ G 1/4 DIN 3852-E,垫圈 DIN 3869-15 (MBS
1750)
• 完全数字补偿
AI309034611216zh-000201

MBS 1700 与 MBS 1750 型压力传感器
应用
应用和介质状态 (MBS 1750)
數字 1: MBS 1750
应用
变流速液压系统可能发生气蚀、水锤和压力冲击,例如快速关闭阀门的时候,或者泵在启动和关闭的时候。此
类问题可能发生在入口端和出口端,即使工作压力极低,亦不例外。
介质条件
液体中含有颗粒物可能导致喷嘴堵塞。将传感器安装在垂直位置,可以将喷嘴阻塞的风险降至最低,因为只有
在启动时喷嘴流口的无效容积充注液体之后,喷嘴才可能接触液体。介质粘度对响应时间的影响非常小。即使
粘度高达 100 cSt,响应时间也不会超过 4 ms。
© Danfoss | Climate Solutions | 2022.03 AI309034611216zh-000201 | 2

RL ≤ (UB - 9 V)/0.02 A [Ω]
IEC 60068-2-6
20 g,25 Hz – 2 kHz
EN 10088-1; 1.4404 (AISI 316 L)
EN 10088-1; 1.4404 (AISI 316 L)
MBS 1700 与 MBS 1750 型压力传感器
产品规格
技术参数
Table 1: 性能(EN 60770)
Table 2: 电气规格
Table 3: 环境条件
Table 4: 机械特性
© Danfoss | Climate Solutions | 2022.03 AI309034611216zh-000201 | 3

EN175301-803-A,
Pg 9
39.5
40
13
13
20
12
15
4, 8
3
34
ø33
ø11
A
B C
ø17, 5
ø11, 2
ø18, 8
=27
MBS 1700 与 MBS 1750 型压力传感器
高介质温度下的安装指南
數字 2: 在高介质温度下安装
Table 5: 电气连接
尺寸
數字 3: 尺寸
© Danfoss | Climate Solutions | 2022.03 AI309034611216zh-000201 | 4

G
1
⁄4 A (EN 837)(MBS 1700)
G
1
⁄2 A (EN 837)(MBS 1700)
G
1
⁄4 (DIN 3852-E) 垫圈 DIN 3869-14-NBR(MBS 1750)
针脚 1: + 电源 针脚 2: ÷ 电源 针脚 3: 未使用
接地: 连接至 MBS 外壳
MBS 1700 与 MBS 1750 型压力传感器
Table 6: 扭矩规格
(1)
(1)
取决于各种因素,例如包装材料、对接材料、螺纹润滑及压力大小
取决于各种因素,例如包装材料、对接材料、螺纹润滑及压力大小
电气连接
數字 4: EN 175301-803-A,
Table 7: 电气连接
© Danfoss | Climate Solutions | 2022.03 AI309034611216zh-000201 | 5

DIN 3852-E G ¼ 垫圈 DIN 3869-14
MBS 1700 与 MBS 1750 型压力传感器
订货
Table 8: 插头; Pg 9 (EN 175301-803-A)
(1)
(1)
相对 / 表压
相对 / 表压
Table 9: 插头; Pg 9 (EN 175301-803-A)
(1)
(1)
密封表压
密封表压
© Danfoss | Climate Solutions | 2022.03 AI309034611216zh-000201 | 6

MBS 1700 与 MBS 1750 型压力传感器
证书、声明和认证
该列表包含该产品类型的所有证书、声明和认证。各个代号可能具有部分或全部认证,某些当地认证可能不会
显示在列表中。
一些认证可能会随时间而改变。如有任何疑问,请访问 danfoss.com 查看最新状态或联系您当地的丹佛斯代表。
Table 10: 有效认证
