Danfoss MBC 5080, MBC 5180 Data sheet

Data Sheet
Differential pressure switch Type MBC 5080 and MBC 5180
Heavy duty industry and marine applications
MBC dierential pressure switches are used in industry and marine applications where space and reliability are the most important features.
MBCs are compact pressure switches, designed according to our new block design to survive in the harsh conditions known from machine rooms onboard ships.
MBCs have high vibration resistance and feature all commonly marine approvals.
Features
• Designed for use in severe marine and industrial environments
• High vibration stability
• Part of the Danfoss block-system, consisting of MBC pressure switches, MBS pressure transmitters and MBV test-valves
• MBC 5180 with ship approvals
• Low xed hysteresis and high repeatability,
• Optimal compact design for machine building purposes
• Intended for alarm indication, shut-down, control and diagnosing in many applications ­motors, gears, thrusters, pumps, lters, compressors etc.
AI185486433551en-000601
123
Repeatability upper switch point
±0.1 bar (typ.)
Static pressure on LP-side (Pressure released totally after activating the switch point)
±0.2 bar (max.) Max. switch frequency
10/min. (0.16 Hz)
Permissible operating pressure (HP)
45 bar
Min. bursting pressure
90 bar
Lifetime Mechanical
> 400.000 cycles
Electrical at max. contact load
> 100.000 cycles
Switch
SPDT
Contact load AC15
0.5 A, 250 V
DC13
12 W, 125 V
Temperature Operation
-10 – 85 °C
Transport
-50 – 85 °C
Enclosure
IP65, EN 60529
Vibration stability
Sinusoidal
4 g, 25–00 Hz
EN 60068-2-6
Shock resistance
Shock
50 g / 6 ms
EN 60068-2-27
Pressure connection Standard
G1/4 female (ISO 228-1) or ange
Option
See specication form, page 3
Electrical connection
Plug
DIN 43650, Pg9, Pg11 or Pg 13.5
Wetted parts material
Housing
Anodized AIMgSi1, AW-6082 T6
Diaphragm
NBR
O-ring
NBR
Hole plug (ange version)
Nickel plated brass
O-ring (ange version)
NBR
Enclosure material Housing
Anodized AIMgSi1, AW-6082 T6
Plug xture
Glass lled polyamid, PA 6.6
Net weight
0.35 kg
3
1
2
3
1
2
3 2
1
Out NO
In
Out NC
Out NO
In
Out NC
Danfoss
93Z19.11
Input
Normally closed (NC)
Normally open (NO)
Connected to enclosure of pressure control
Dierential pressure switch, type MBC 5080 and MBC 5180
Product specication
Technical data
Table 1: Performance
Table 2: Electrical specications
Table 3: Environmental conditions
Table 4: Mechanical characteristics
Electrical connection
Figure 1: Electrical connection
© Danfoss | Climate Solutions | 2021.02 AI185486433551en-000601 | 2
Dierential pressure switch, type MBC 5080 and MBC 5180
Mechanical connections
Mechanical dierential
MBC standard versions are adjusted at minimum dierential range 0.3 bar.
Variation in the system pressure will not aect the dierential setting.
If the dierential is set to a high value at 0 bar system pressure, there will be a small change in the setpoint.
Example:
MBC 5080 and MBC 5180 set to 5.0 bar dierential at 0 bar system pressure will at 30 bar system pressure give alarm at approx. 34.2 bar. Dierential decreased 0.8 bar.
Our experience is that MBC 5080 and MBC 5180 often are used at a dierential setting close to minimum, where the dierential would be independent of the system pressure.
If a high dierential is needed, we recommend to make a dierential setting at the system pressure that is normal for the application.
© Danfoss | Climate Solutions | 2021.02 AI185486433551en-000601 | 3
Danfoss
93Z81.12
Upper Switch point
Lower Switch point
Lower Switch point
System pressure
Set point for ΔP
Upper Switch point
Mechanical dierence
Dierential pressure switch, type MBC 5080 and MBC 5180
Figure 2: Mechanical dierential
Adjustment
Figure 3: Mechanical dierential adjustment
© Danfoss | Climate Solutions | 2021.02 AI185486433551en-000601 | 4
Net weight: 0.35 kg
Net weight: 0.35 kg
Dierential pressure switch, type MBC 5080 and MBC 5180
Dimensions [mm] and weights [kg]
© Danfoss | Climate Solutions | 2021.02 AI185486433551en-000601 | 5
Setting range
Δp [bar]
Type no. MBC 5080 MBC 5180
Ship approved
MBC 5180
Code no.
0.3 - 5
MBC 5080-2031-1DB04
-
MBC 5080-2031-1CB04
-
MBC 5180-2031-1DB04
061B128066
(1)
MBC 5180-2031-1CB04
061B129066
Setting range
0.3 5 bar ............... 2 0
Others...................... x x
Type
NBR diaphragm........................... 3
Others............................................. x
Microswi tch
0.5 A, 250 V(AC 15)
12 W, 125 V (DC 13)................................. 1
Others.......................................................... x
Pressure connection
C B 0 4 G ¼ female D B 0 4 G ¼
female with flange connection
x x x x Others
Electrical connection
0 No plug (DIN 43650 A) 1 Pg 11 plug (DIN 43650 A) 2 Pg 13.5 plug (DIN 43650 A) 3 Pg 9 plug (DIN 43650 A) x Others
MBC 5080 ­MBC 5180 -
Dierential pressure switch, type MBC 5080 and MBC 5180
Ordering
Ordering standard types
(1)
(1)
Preferred version
Preferred version
Ordering of customized types
© Danfoss | Climate Solutions | 2021.02 AI185486433551en-000601 | 6
File name
Approval authority
EN 60947-4-1
China Compulsory Certicate, CCC
EN 60947-5-1
EN 60947-1
Dierential pressure switch, type MBC 5080 and MBC 5180
Certicates, declarations, and approvals
The list contains all certicates, declarations, and approvals for this product type. Individual code number may have some or all of these approvals, and certain local approvals may not appear on the list.
Some approvals may change over time. You can check the most current status at danfoss.com or contact your local Danfoss representative if you have any questions.
Table 5: Approvals
CE-marked in accordance with:
• LVD 2014/35/EU (EN 60947-1, EN 60947-4-1, EN 60947-5-1)
Ship approvals,Type MBC 5180:
Lloyd’s Register, LR Germanischer Lloyd, GL Registro Italiano Navale, RINA Nippon Kaiji Kyokai, NKK Det Norske Veritas, DNV China Classication Society, CCS American Bureau of Shipping, ABS Korean Register of Shipping, KR
© Danfoss | Climate Solutions | 2021.02 AI185486433551en-000601 | 7
Online support
Danfoss oers a wide range of support along with our products, including digital product information, software, mobile apps, and expert guidance. See the possibilities below.
The Danfoss Product Store
The Danfoss Product Store is your one-stop shop for everything product related—no matter where you are in the world or what area of the cooling industry you work in. Get quick access to essential information like product specs, code numbers, technical documentation, certications, accessories, and more. Start browsing at store.danfoss.com.
Find technical documentation
Find the technical documentation you need to get your project up and running. Get direct access to our ocial collection of data sheets, certicates and declarations, manuals and guides, 3D models and drawings, case stories, brochures, and much more.
Start searching now at www.danfoss.com/en/service-and-support/documentation.
Danfoss Learning
Danfoss Learning is a free online learning platform. It features courses and materials specically designed to help engineers, installers, service technicians, and wholesalers better understand the products, applications, industry topics, and trends that will help you do your job better.
Create your Danfoss Learning account for free at www.danfoss.com/en/service-and-support/learning.
Get local information and support
Local Danfoss websites are the main sources for help and information about our company and products. Find product availability, get the latest regional news, or connect with a nearby expert—all in your own language.
Find your local Danfoss website here: www.danfoss.com/en/choose-region.
Spare Parts
Get access to the Danfoss spare parts and service kit catalog right from your smartphone. The app contains a wide range of components for air conditioning and refrigeration applications, such as valves, strainers, pressure switches, and sensors.
Download the Spare Parts app for free at www.danfoss.com/en/service-and-support/downloads.
Danfoss can accept no responsibility for possible errors in catalogues, brochures and other printed material. Danfoss reserves the right to alter its products without notice. This also applies to products already on order provided that such alterations can be made without subsequential changes being necessary in specications already agreed. All trademarks in this material are property of the respective companies. Danfoss and the Danfoss logotype are trademarks of Danfoss A/S. All rights reserved.
