Data Sheet
Series 45 Axial Piston Open Circuit Pump
K2 Frame
The future is here – Series 45 open circuit axial piston K2 pumps. The K2 marks the beginning of the next generation of Danfoss open circuit pumps. Designed to optimize weight, and size while offering greater flexibilities.
Improved performance
With an optimized package, the K2 responds to customer needs by significantly reducing pump weight and package size — while improving performance with increased rated pressure and higher rated speed capabilities. The result is the best combination of package size and weight on the market.
Additional features inside the housing allow for dissipation of noise and vibration, and provides improved low sound power. In combination with the one-piece iron housing and valve plate design, the K2 allows for superior sound reduction that provides a more comfortable experience for the operator and helps meet industry regulations.
Modularity and flexibility
Four unique endcap styles offer more variation to improve installation flexibility and remove significant weight from the pump. The K2 pump will use common Series 45 J, F, and E style controls, and our new Fan Drive Control for a common control style across frame sizes.
Features |
|
|
|
• |
Reduced Length up to 20% |
‒ Increased pressure of up to 50 bar |
|
|
|||
• |
Reduced Width up to 10% |
over current L and K Frames |
Comprehensive technical literature is |
• |
Reduced Weight up to 30% |
‒ Increased temperature raitings |
online at www.danfoss.com |
• |
Additional endcap variations to reduce |
‒ Increased speed ratings |
|
|
|||
• |
installation envelope |
• Proven Reliability |
|
Improved Power Density and |
‒ Common control with J, F and E |
|
|
|
Performance |
Frames making one control for all of |
|
|
|
S45 family |
|
‒ Additional control options ‒ New Fan Drive Control (FDC) ‒ New PC/LS with On/Off
© Danfoss | November 2019 |
AI00000318en-000103 | 1 |
Dimensions
S45 K2 axial (top) and radial (bottom) in mm
97.6 |
32 |
|
6.7 |
|
|
|
|
Ø 12.5 |
|
|
132.73 |
|
|
110 |
|
|
77.4 |
|
|
67.3 |
73 |
|
|
|
146 |
|
44.5 |
4.4 |
128.4 |
|
||
5.1 |
|
Ø12.5 |
|
|
|
|
|
Ø 14.3 |
73
146
Control features
97.4 |
193 |
|
|
|
25.8 |
32 |
|
80 |
|
|
175.6 |
|
193 |
138.5 |
|
112.8 |
|
100 |
|
|
20.7 |
32 |
|
80 |
166 |
|
|
|
204.2 |
|
P109101 |
Specifications
Parameter |
|
Unit |
K25C |
K30C |
K38C |
K40C |
K45C |
|
Max. displacement |
|
cm3 |
25 |
30 |
38 |
40 |
45 |
|
|
|
|
[in3] |
[1.53] |
[1.83] |
[2.32] |
[2.44] |
[3.97] |
Working pressure |
|
bar |
260 [3771] |
|
|
|
||
|
|
|
[psi] |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Rated input |
|
Min. |
min-1 |
500 |
|
|
|
|
speed |
|
|
rpm |
|
|
|
|
|
|
Cont. |
3450 |
3200 |
2900 |
3100 |
2900 |
||
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
Max. |
|
3750 |
3450 |
3050 |
3200 |
3050 |
|
|
|
|
|
|
|
|
|
Weight (axial ports) |
|
kg |
16 [35] |
|
|
|
|
|
|
|
|
[lb] |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Function type |
Pressure |
Load |
Cold |
Power |
Normally |
Normally |
12v |
24v |
|
comp. |
sensing |
start |
management |
open |
closed |
|
|
|
|
|
relief |
|
|
|
|
|
Pressure comp. only |
x |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Pressure comp/load sensing |
x |
x |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Remote PC |
x |
|
x |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Electronic on/off |
x |
|
x |
|
|
x |
x |
x |
|
|
|
|
|
|
|
|
|
Electronic dump |
x |
x |
x |
|
x |
x |
x |
x |
|
|
|
|
|
|
|
|
|
Electronic proportional |
x |
|
x |
x |
x |
x |
x |
x |
|
|
|
|
|
|
|
|
|
Fan drive control* |
x |
|
|
|
|
x |
x |
x |
* For fan drive applications only. |
|
|
|
|
|
|
|
|
