Danfoss J 75 cc, J 45 cc Service guide
MAKING MODERN LIVING POSSIBLE
Parts Manual
Open Circuit Pumps Series 45 Frame J 45-75 cc
powersolutions.danfoss.com
Parts Manual |
Series 45 Frame J 45-75cc O. C. Pumps |
|
|
Contents
2 |
AX00000064en-US | 520L0585 • Rev 0401 • June 2016 |
Parts Manual |
Series 45 Frame J 45-75cc O. C. Pumps |
|
Contents |
|
|
General Information |
Service parts identification.............................................................................................................................................. |
4 |
|
Nameplate............................................................................................................................................................................. |
4 |
|
Date code............................................................................................................................................................................... |
5 |
|
Service bulletins.................................................................................................................................................................. |
5 |
|
Procedure to identify a part............................................................................................................................................ |
5 |
|
Adobe Acrobat 2-page viewing..................................................................................................................................... |
6 |
|
Order code............................................................................................................................................................................. |
7 |
Control |
Load sensing.................................................................................................................................................................. |
8-13 |
|
Pressure compensating........................................................................................................................................... |
14-15 |
|
Remote pressure compensating.......................................................................................................................... |
16-17 |
|
Electric........................................................................................................................................................................ |
18-113 |
|
Fan drive................................................................................................................................................................... |
114-121 |
Choke orifice |
Orifice........................................................................................................................................................................ |
122-123 |
Gain orifice |
Gain orifice.............................................................................................................................................................. |
122-123 |
Input shaft |
Shaft........................................................................................................................................................................... |
124-369 |
End cap |
End cap..................................................................................................................................................................... |
124-369 |
Auxiliary mounting |
Auxiliary mounting flange................................................................................................................................. |
124-369 |
Housing/shaft seal |
Housing/shaft seal................................................................................................................................................ |
370-379 |
Displacement limiter |
Displacement limiter........................................................................................................................................... |
380-381 |
Special hardware |
Special hardware................................................................................................................................................... |
380-385 |
Displacement |
Displacement......................................................................................................................................................... |
386-391 |
Seal kit |
Overhaul seal kit............................................................................................................................................................. |
392 |
Service bulletins |
SB-2002-031 (load sense spring guide)................................................................................................................. |
393 |
|
SB-2006-005 (input shaft lip seal)............................................................................................................................ |
394 |
|
SB-2006-006 (servo piston rings)............................................................................................................................. |
395 |
|
SB-2007-047 (load sense plug assembly).............................................................................................................. |
396 |
|
SB-2008-052 (C pad mounting flange)................................................................................................................... |
397 |
|
SB-2010-002 (end cap servo bore).................................................................................................................. |
398-399 |
|
SB-2010-026 (LS and PC plug assembly)............................................................................................................... |
400 |
|
SB-2010-033 (servo piston assembly)..................................................................................................................... |
401 |
|
SB-2011-031 (overhaul seal kit)................................................................................................................................ |
402 |
|
SB-2012-011 (control/orfice)............................................................................................................................. |
403-404 |
|
SB-2012-024 (rotating group)........................................................................................................................... |
405-406 |
|
SB-2016-007 (solenoid valve adapter)................................................................................................................... |
407 |
AX00000064en-US | 520L0585 • Rev 0401 • June 2016 |
3 |
Parts Manual |
Series 45 Frame J 45-75cc O. C. Pumps |
|
|
General information
Service parts indentification
Nameplate
The following information and procedure is used to identify the module group, item number, manufacture date, part number, and part name of the parts included in the Frame J open circuit pump. The Frame J includes the 45,51, 60, 65, and 75 cc displacement pumps.
The parts listed include all parts which may be used when performing either “Minor Repairs”, “Major Repairs” or “Conversions” Frame J open circuit pumps.
Each unit will have a nameplate affixed to the housing. The nameplate will include the following information.
Model Number
The Sauer-Danfoss model number is used by the factory in manufacturing. On repeat orders, a complete unit can be ordered by the model number.
Model Code
The Sauer-Danfoss model code completely defines the specific unit and must be used when ordering parts to service this product.
Serial Number
The Sauer-Danfoss serial number is used to identify the manufacture date and the unit sequence in the build. The serial number is also used to identify the units warranty time period.
The letter code indicates the location of original manufacture (assembly). “DC” indicates the unit was originally assembled in Slovokia.
The first 2 digits indicates the year of manufacture. (“02” would indicate the unit was manufactured in 2002)
The second 2 digits indicates the calendar week of manufacture.
The last 5 digits are a sequential number used to identify a specific unit.
Model No./Ident No. |
7003022 |
Model Code |
JRR 060 B LS 28 |
|
26 NN N 3 C3N3 A6N |
|
BNN NNN NNN |
Serial No. |
A-02-34-12345 |
Made in U.S.A.
4 |
AX00000064en-US | 520L0585 • Rev 0401 • June 2016 |
Parts Manual |
Series 45 Frame J 45-75cc O. C. Pumps |
|
|
|
||||
|
|
|
|
|
|
|
|
|
General information |
|
|
|
|
|
|
|
|
Date code |
The date code is defined as the year and week of manufacture. The same item number may list more |
|||||||
|
than one part number. This indicates that there is more than one configuration for that item number. |
|||||||
|
You will see that there are different date codes for the different part numbers. Find the date code of |
|||||||
|
your unit from the nameplate to determine which service part number you need to order. |
|||||||
|
EXAMPLE: The service part desired is Item C090 |
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
Order |
|
Date |
Date |
|
|
Qty. per |
|
|
Code |
Item Begin |
End |
Part Number |
Part Name |
Model/Kit |
||
|
LB |
C090 |
98-02 |
|
4570245 |
Spool |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
C090 |
94-34 |
98-01 |
4570025 |
Spool (SB-1995-006) |
1 |
|
|
|
|
||||||
|
All units using this order code with a date code of 94-34 and up to and including 98-01, must use part |
|||||||
Service bulletins |
number “4570025”. All units with a date code of 98-02 and newer must use part number “4570245.”. |
|||||||
|
A Service Bulletin Number (SB-_ _ _ _ - _ _ _) may follow the “Part Name” of the part you desire. You |
|||||||
|
must read that Service Bulletin prior to ordering that part. The information contained in these Service |
|||||||
|
Bulletins, as of the print date of this bulletin, are included at the end of this manual. Service Bulletins |
|||||||
|
contain more detailed information such as interchangeability, what additional parts are involved, etc. |
|||||||
|
It is suggested that you add additional Service Bulletins to this manual as you recieve them. |
|||||||
Procedure to identify a part |
General |
|
|
|
|
|
|
|
|
The modular design of Series 45 units results in a simplified service parts list and part number |
|||||||
|
identification procedure. |
|
|
|
|
|||
The same item numbers are used for same part names on all units within a product type. (Example:
The lip seal - Item K020 has the same item number on all pumps.)
A part number that has another number following it in parentheses is done to make this a world wide manual. The first number is sold in Europe. The number in parentheses is sold in the United States. (Example: 016014 (9006200-0206), customers would order 9006200-0206 if ordering the part in the United States.)
Example of a Part Identification
The nameplate on a Series 45 pump has an Order Code of JRR 060B LS 28 26 NN N 3 C3N3 A6N BNN
NNN NNN. Do this to determine the part number of the drive shaft used on this pump.
1) Referring to the input shaft module in the Order Code (see page 7), the input shaft option for this pump is identified by the code C3N3 (JRR 060B LS 28 26 NN N 3 C3N3 A6N BNN NNN NNN)
2) Referring to the Service Parts List, find the shaft group.
3) Find the order code that relates to this unit, which is C3N3. 4) The shaft is item J010
5) The part number 1700520.
AX00000064en-US | 520L0585 • Rev 0401 • June 2016 |
5 |
Parts Manual |
Series 45 Frame J 45-75cc O. C. Pumps |
|
|
Adobe Acrobat 2-page viewing |
|
Abobe Acrobat 2-page |
While viewing manual in Adobe Acrobat, the following settings need to be applied to ensure proper |
viewing |
page display. |
1. With open document
2. Select “View” --> “Page Display” --> “Two Page View”
3. Select “View” --> “Page Display” --> “Show Cover Page in Two Page View”
6 |
AX00000064en-US | 520L0585 • Rev 0401 • June 2016 |
Parts Manual |
Series 45 Frame J 45-75cc O. C. Pumps |
|
|
Order code
J R
R
0
6
0
B
L
S
2 8
2
6
N
N
N
3
C
3
N
3
A
6
N
B
N
N
N
N
N
N
N
N
Frame
Rotation
Pump size (cc)
Load life
Control type
Pressure compensator setting
Load sensing setting
Torque limiter setting
Special features
Special hardware
Displacement limiter
Speed sensor
Front flange & housing ports style
Shaft seal
End cap port style
Rear auxiliary flange
Input shaft
P100 625E
Choke orifice |
|
|
|
Gain orifice |
|
|
|
AX00000064en-US | 520L0585 • Rev 0401 • June 2016 |
7 |
Parts Manual |
Series 45 Frame J 45-75cc O. C. Pumps |
|
|
Control
QC100
(AZ)
*C118 |
|
|
|
|
C114 |
|
|
|
C115 |
|
|
C138 |
C113 |
C300 |
|
|
|
|
|
*C138A |
|
C102 |
|
|
|
|
|
C134 |
|
|
C105 |
C135 |
|
|
|
C133 |
C106 |
|
|
|
|
|
|
|
|
|
C112 |
|
|
|
C104 |
|
*C200 |
C132 |
|
|
|
|
C103 |
(BA, BB &
BS)
*C118
QC100 |
|
C114 |
|
|
|
|
|
|
|
|
|
|
|
C115 |
C113 |
C300 |
|
|
|
|
|
||
|
|
|
|
|
|
|
C138 |
|
|
|
|
|
|
|
|
C102 |
|
|
*C138A |
|
|
|
C105 |
|
C134 |
|
|
|
|
|
C133 |
C106 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
C112 |
|
|
|
|
|
C104 |
|
|
|
*C200 |
C132 |
|
|
|
|
|
|
C103 |
E100 544E
Enlarged bold type item
* = included in base motor seal kit Q210 numbers are recommended part to stock for servicing.
8 |
AX00000064en-US | 520L0585 • Rev 0401 • June 2016 |
Parts Manual |
|
Series 45 Frame J 45-75cc O. C. Pumps |
|
|||
|
|
|
|
|
|
|
Control |
|
|
|
|
|
|
Common load sensing control parts |
|
|
||||
Order |
|
Date |
Date |
|
|
Qty. per |
Code |
Item |
Begin |
End |
Part Number |
Part Name |
Model/Kit |
|
C102 |
03-23 |
|
4740064 |
Set screw |
2 |
|
C103 |
03-23 |
|
327007 (9005110-4400) |
Plug |
1 |
|
C104 |
03-23 |
|
327007 (9005110-4400) |
Plug |
1 |
|
C105 |
03-23 |
|
327007 (9005110-4400) |
Plug |
1 |
|
C106 |
03-23 |
|
327007 (9005110-4400) |
Plug |
1 |
|
C113 |
03-23 |
|
4740246 |
Spring guide (SB-2002-031) |
1 |
|
C114 |
03-23 |
|
4740061 |
Spring |
1 |
|
C115 |
03-23 |
|
4740062 |
Spring |
1 |
|
C118 |
03-23 |
|
11062214 |
Adjusting plug (SB-2007-047 & SB-2010-026) |
1 |
|
C200 |
03-23 |
|
4740154 |
Seal ring |
4 |
|
C300 |
03-23 |
|
5000164 (9007315-0507) |
Screw |
4 |
Load sensing control |
|
|
|
|
||
AZ |
C112 |
03-23 |
|
4740309 |
Spool |
1 |
|
|
|
|
|
|
|
|
C132 |
03-23 |
|
1701124 |
Spool |
1 |
|
C133 |
03-23 |
|
4740247 |
Spring guide |
1 |
|
C134 |
03-23 |
|
4740051 |
Spring, outer |
1 |
|
C135 |
03-23 |
|
4740052 |
Spring, inner |
1 |
|
C138 |
03-23 |
|
11062379 |
Adjusting plug assembly |
1 |
|
C138A |
03-23 |
|
5000656 |
O-ring |
1 |
|
QC100 |
03-23 |
|
11082405 |
Control Kit (SB-2012-011) |
1 |
|
|
|
|
|
|
|
BA |
C112 |
07-03 |
|
4740309 |
Spool |
1 |
|
|
|
|
|
|
|
|
C132 |
07-03 |
|
1701124 |
Spool |
1 |
|
C133 |
07-03 |
|
4740247 |
Spring guide |
1 |
|
C134 |
07-03 |
|
4740324 |
Spring, PC heavy |
1 |
|
C138 |
07-03 |
|
1700597 |
Adjusting plug |
1 |
|
C138A |
07-03 |
|
5000656 |
O-ring |
1 |
|
QC100 |
07-03 |
|
11038636 |
Control Kit, High pressure, special (SB-2012-011) |
1 |
|
|
|
|
|
|
|
BB |
C112 |
03-23 |
|
4740309 |
Spool |
1 |
|
|
|
|
|
|
|
|
C132 |
03-23 |
|
1701124 |
Spool |
1 |
|
C133 |
03-23 |
|
4740247 |
Spring guide |
1 |
|
C134 |
03-23 |
|
4740324 |
Spring, PC heavy |
1 |
|
C138 |
03-23 |
|
1700597 |
Adjusting plug |
1 |
|
C138A |
03-23 |
|
5000656 |
O-ring |
1 |
|
QC100 |
03-23 |
|
11112211 |
Control Kit, High pressure (SB-2012-011) |
1 |
|
|
|
|
|
|
|
BS |
C112 |
11-42 |
|
1701124 |
Spool |
1 |
|
|
|
|
|
|
|
|
C132 |
11-42 |
|
1701124 |
Spool |
1 |
|
C133 |
11-42 |
|
4740247 |
Spring guide |
1 |
|
C134 |
11-42 |
|
4740324 |
Spring, PC heavy |
1 |
|
C138 |
11-42 |
|
1700597 |
Adjusting plug |
1 |
|
C138A |
11-42 |
|
5000656 |
O-ring |
1 |
|
QC100 |
11-42 |
|
11112207 |
Control Kit (SB-2012-011) |
1 |
AX00000064en-US | 520L0585 • Rev 0401 • June 2016 |
9 |
Parts Manual |
Series 45 Frame J 45-75cc O. C. Pumps |
|
|
Control
QC100
|
*C118 |
|
(LB) |
|
|
|
|
|
|
|
C114 |
|
|
|
C138 |
C115 |
C113 |
C300 |
|
|
|
|||
|
|
|
||
*C138A |
|
|
C102 |
|
|
|
|
|
|
C134 |
|
|
|
C105 |
C135 |
|
|
|
|
C133 |
C106 |
|
|
|
|
|
|
|
|
|
|
|
|
C112 |
|
|
|
|
C104 |
|
|
*C200 |
C132 |
|
|
|
|
|
C103 |
|
|
|
|
|
(LE) |
|
|
|
|
QC100 |
*C118 |
|
|
|
|
|
|
C300 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
C114 |
|
|
|
|
|
|
C115 |
|
|
|
|
|
|
C102 |
|
|
|
|
|
C113 |
|
C105 |
|
|
(LF & LG) |
|
|
|
|
QC100 |
|
|
|
C106 |
|
|
*C118 |
|
|
|
C400 |
|
|
|
C300 |
|
|
|
||
|
|
|
|
C112 |
||
|
|
|
|
|
*C200 |
|
|
|
C114 |
|
|
C104 |
|
|
|
|
|
|
||
|
|
C115 |
|
|
|
|
|
|
C102 |
|
|
|
|
|
C113 |
|
|
C105 |
|
|
|
C106 |
|
|
|
|
|
|
|
*C200 |
C112 |
|
|
|
|
|
|
C104 |
|
|
|
|
|
E100 542E |
|
|
Enlarged bold type item |
|
* = included in base motor seal kit Q210 |
numbers are recommended |
|
|
part to stock for servicing. |
|
|
|
10 |
AX00000064en-US | 520L0585 • Rev 0401 • June 2016 |
|
Parts Manual |
|
Series 45 Frame J 45-75cc O. C. Pumps |
|
|||
|
|
|
|
|
|
|
Control |
|
|
|
|
|
|
Common load sensing control parts |
|
|
||||
Order |
|
Date |
Date |
|
|
Qty. per |
Code |
Item |
Begin |
End |
Part Number |
Part Name |
Model/Kit |
|
C104 |
03-23 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
C105 |
03-23 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
C106 |
03-23 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
C113 |
03-23 |
|
4740246 |
Spring guide |
1 |
|
C114 |
03-23 |
|
4740061 |
Spring |
1 |
|
C115 |
03-23 |
|
4740062 |
Spring |
1 |
|
C118 |
03-23 |
|
11062214 |
Adjusting plug (SB-2007-047 & SB-2010-026) |
1 |
|
C200 |
03-23 |
|
4740154 |
Seal ring |
4 |
|
C300 |
03-23 |
|
5000164 (9007315-0507) |
Screw |
4 |
Load sensing control |
|
|
|
|
||
LB |
C102 |
03-23 |
|
4740064 |
Set screw |
2 |
|
|
|
|
|
|
|
|
C103 |
03-23 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
C112 |
03-23 |
|
4740309 |
Spool |
1 |
|
C132 |
03-23 |
|
1701124 |
Spool |
1 |
|
C133 |
03-23 |
|
4740247 |
Spring guide |
1 |
|
C134 |
03-23 |
|
4740051 |
Spring, outer |
1 |
|
C135 |
03-23 |
|
4740052 |
Spring, inner |
1 |
|
C138 |
03-23 |
|
11062379 |
Adjusting plug assembly |
1 |
|
C138A |
03-23 |
|
5000656 |
O-ring |
1 |
|
QC100 |
03-23 |
|
11112205 |
Control Kit (SB-2012-011) |
1 |
|
|
|
|
|
|
|
LE |
C102 |
03-23 |
|
4740064 |
Set screw |
1 |
|
|
|
|
|
|
|
|
C112 |
03-23 |
|
1701124 |
Spool |
1 |
|
C400 |
03-23 |
|
4740313 |
Edge filter plug |
1 |
|
QC100 |
03-23 |
|
4510400 |
Control kit, load sensing only, with filter (SB-2012-011) |
1 |
|
|
|
|
|
|
|
LF |
C102 |
08-21 |
|
4740064 |
Set screw |
1 |
|
|
|
|
|
|
|
|
C112 |
08-21 |
|
1701124 |
Spool |
1 |
|
QC100 |
08-21 |
|
11050069 |
Control kit, load sensing only |
1 |
|
|
|
|
|
|
|
LG |
C102 |
10-21 |
|
4740064 |
Set screw |
1 |
|
|
|
|
|
|
|
|
C112 |
10-21 |
|
11084056 |
Spool |
1 |
|
QC100 |
10-21 |
|
11106465 |
Control kit, load sensing only |
1 |
AX00000064en-US | 520L0585 • Rev 0401 • June 2016 |
11 |
Parts Manual |
|
Series 45 Frame J 45-75cc O. C. Pumps |
|
|||
Control |
|
|
|
|
|
|
|
|
|
|
(LJ & LS) |
|
|
QC100 |
|
|
*C118 |
|
|
|
|
|
|
C114 |
|
|
|
|
|
C138 |
C115 |
C113 |
C300 |
|
|
|
|
|
|||
|
|
|
|
|
||
|
|
|
|
|
|
|
|
*C138A |
|
|
|
C102 |
|
|
|
|
|
|
|
|
|
|
C134 |
|
|
|
C105 |
|
|
C135 |
|
|
|
|
|
|
C133 |
C106 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
C112 |
|
|
|
|
|
|
C104 |
|
|
|
|
*C200 |
C132 |
|
|
|
|
|
|
|
C103 |
(LY & RY)
QC100 |
*C118 |
|
C114 |
|
|
C138 |
C115 |
C113 |
C300 |
|
|||
|
|
||
|
|
|
*C138A
C134 |
|
C105 |
C135 |
C102 |
|
C133 |
|
|
|
|
|
|
C106 |
C112 |
|
|
|
|
|
C104 |
|
*C200 |
C132 |
|
|
C103 |
E100 701E
Enlarged bold type item
* = included in base motor seal kit Q210 numbers are recommended part to stock for servicing.
12 |
AX00000064en-US | 520L0585 • Rev 0401 • June 2016 |
Parts Manual |
|
Series 45 Frame J 45-75cc O. C. Pumps |
|
|||
|
|
|
|
|
|
|
Control |
|
|
|
|
|
|
Common load sensing control parts |
|
|
||||
Order |
|
Date |
Date |
|
|
Qty. per |
Code |
Item |
Begin |
End |
Part Number |
Part Name |
Model/Kit |
|
C102 |
03-23 |
|
4740064 |
Set screw |
2 |
|
C103 |
03-23 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
C104 |
03-23 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
C112 |
03-23 |
|
1701124 |
Spool |
1 |
|
C113 |
03-23 |
|
4740246 |
Spring guide (SB-2002-031) |
1 |
|
C114 |
03-23 |
|
4740061 |
Spring |
1 |
|
C115 |
03-23 |
|
4740062 |
Spring |
1 |
|
C118 |
03-23 |
|
11062214 |
Adjusting plug (SB-2007-047 & SB-2010-026) |
1 |
|
C132 |
03-23 |
|
1701124 |
Spool |
1 |
|
C133 |
03-23 |
|
4740247 |
Spring guide |
1 |
|
C134 |
03-23 |
|
4740051 |
Spring, outer |
1 |
|
C135 |
03-23 |
|
4740052 |
Spring, inner |
1 |
|
C138 |
03-23 |
|
11062379 |
Adjusting plug assembly |
1 |
|
C138A |
03-23 |
|
5000656 |
O-ring |
1 |
|
C200 |
03-23 |
|
4740154 |
Seal ring |
4 |
|
C300 |
03-23 |
|
5000164 (9007315-0507) |
Screw |
4 |
Load sensing control |
|
|
|
|
||
LJ |
C105 |
14-39 |
|
5000572 |
Plug assembly, M12 |
1 |
|
|
|
|
|
|
|
|
C106 |
14-39 |
|
5000572 |
Plug assembly, M12 |
1 |
|
QC100 |
14-39 |
|
4510444 |
Control kit, load sensing, metric |
1 |
|
|
|
|
|
|
|
LS |
C105 |
03-23 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
|
|
|
|
|
|
|
C106 |
03-23 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
QC100 |
03-23 |
|
11112208 |
Control kit, load sensing (SB-2012-011) |
1 |
|
|
|
|
|
|
|
LY |
C105 |
13-07 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
|
|
|
|
|
|
|
C106 |
13-07 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
QC100 |
13-07 |
|
11126785 |
Control kit, load sensing |
1 |
|
|
|
|
|
|
|
RY |
C105 |
15-47 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
|
|
|
|
|
|
|
C106 |
15-47 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
QC100 |
15-47 |
|
11126785 |
Control kit, load sensing |
1 |
AX00000064en-US | 520L0585 • Rev 0401 • June 2016 |
13 |
Parts Manual |
Series 45 Frame J 45-75cc O. C. Pumps |
|
|
Control
(BC)
QC100
|
C138 |
C300 |
|
|
|
|
|
C134 |
*C138A |
|
C133 |
|
C102 |
C132
*C200
C103
(PC)
QC100
C138
|
C300 |
|
|
C134 |
|
*C138A |
C135 |
|
C133 |
||
|
||
|
C102 |
C132
*C200
C103
E100 543E
* = included in base motor seal kit Q210
Enlarged bold type item numbers are recommended part to stock for servicing.
14 |
AX00000064en-US | 520L0585 • Rev 0401 • June 2016 |
Parts Manual |
|
Series 45 Frame J 45-75cc O. C. Pumps |
|
|||
|
|
|
|
|
|
|
Control |
|
|
|
|
|
|
Pressure compensating control |
|
|
|
|||
Order |
|
Date |
Date |
|
|
Qty. per |
code |
Item |
begin |
end |
Part number |
Part name |
model/kit |
BC |
C102 |
03-23 |
|
4740064 |
Set screw |
1 |
|
C103 |
03-23 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
C132 |
03-23 |
|
1701124 |
Spool |
1 |
|
C133 |
03-23 |
|
4740247 |
Spring guide (SB-2002-034) |
1 |
|
C134 |
03-23 |
|
4740324 |
Spring, PC, heavy |
1 |
|
C138 |
03-23 |
|
1700597 |
Adjusting plug |
1 |
|
C138A |
03-23 |
|
5000656 |
O-ring |
1 |
|
C200 |
03-23 |
|
4740154 |
Seal ring |
4 |
|
C300 |
03-23 |
|
5000164 (9007315-0507) |
Screw |
4 |
|
QC100 |
03-23 |
|
4510421 |
Control Kit, PC, high pressure |
1 |
|
|
|
|
|
|
|
PC |
C102 |
03-23 |
|
4740064 |
Set screw |
1 |
|
|
|
|
|
|
|
|
C103 |
03-23 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
C132 |
03-23 |
|
1701124 |
Spool |
1 |
|
C133 |
03-23 |
|
4740247 |
Spring guide (SB-2002-034) |
1 |
|
C134 |
03-23 |
|
4740051 |
Spring, outer |
1 |
|
C135 |
03-23 |
|
4740052 |
Spring, inner |
1 |
|
C138 |
03-23 |
|
11062379 |
Adjusting plug assembly |
1 |
|
C138A |
03-23 |
|
5000656 |
O-ring |
1 |
|
C200 |
03-23 |
|
4740154 |
Seal ring |
4 |
|
C300 |
03-23 |
|
5000164 (9007315-0507) |
Screw |
4 |
|
QC100 |
03-23 |
|
4510422 |
Control kit, PC |
1 |
AX00000064en-US | 520L0585 • Rev 0401 • June 2016 |
15 |
Parts Manual |
Series 45 Frame J 45-75cc O. C. Pumps |
|
|||
Control |
|
|
|
|
|
|
|
|
(BP) |
|
|
|
|
*C118 |
|
|
|
QC100 |
|
C114 |
|
|
|
|
|
|
|
|
|
|
|
C115 |
C113 |
C300 |
|
|
|
|
|
||
|
|
|
|
|
|
|
C138 |
|
|
|
|
|
|
|
|
C102 |
|
|
*C138A |
|
|
|
C105 |
|
C134 |
|
|
|
|
|
C133 |
C106 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
C112 |
|
|
|
|
|
C104 |
|
|
|
*C200 |
C132 |
|
|
|
|
|
|
C103 |
(RP)
QC100 |
*C118 |
|
|
|
|
|
C114 |
|
|
|
|
C115 |
|
|
|
C138 |
C113 |
C300 |
|
|
|
|
|
|
|
*C138A |
|
C102 |
|
|
|
|
|
|
|
C134 |
|
|
C105 |
|
C135 |
|
|
|
|
C133 |
C106 |
|
|
|
|
|
|
|
|
|
|
|
C112 |
|
|
|
|
C104 |
|
|
*C200 |
C132 |
|
|
|
|
|
C103 |
E103 216E
Enlarged bold type item
* = included in base motor seal kit Q210 numbers are recommended part to stock for servicing.
16 |
AX00000064en-US | 520L0585 • Rev 0401 • June 2016 |
Parts Manual |
|
Series 45 Frame J 45-75cc O. C. Pumps |
|
|||
|
|
|
|
|
|
|
Control |
|
|
|
|
|
|
Pressure compensating control, remote |
|
|
||||
Order |
|
Date |
Date |
|
|
Qty. per |
code |
Item |
begin |
end |
Part number |
Part name |
model/kit |
BP |
C102 |
03-23 |
|
4740064 |
Set screw |
2 |
|
C103 |
03-23 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
C104 |
03-23 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
C105 |
03-23 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
C106 |
03-23 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
C112 |
03-23 |
|
4740300 |
Spool |
1 |
|
C113 |
03-23 |
|
4740301 |
Spring guide |
1 |
|
C114 |
03-23 |
|
4740061 |
Spring |
1 |
|
C115 |
03-23 |
|
4740062 |
Spring |
1 |
|
C118 |
03-23 |
|
11062214 |
Adjusting plug (SB-2007-047 & SB-2010-026) |
1 |
|
C132 |
03-23 |
|
1701124 |
Spool |
1 |
|
C133 |
03-23 |
|
4740247 |
Spring guide |
1 |
|
C134 |
03-23 |
|
4740324 |
Spring, PC heavy |
1 |
|
C138 |
03-23 |
|
1700597 |
Adjusting plug assembly |
1 |
|
C138A |
03-23 |
|
5000656 |
O-ring |
1 |
|
C200 |
03-23 |
|
4740154 |
Seal ring |
4 |
|
C300 |
03-23 |
|
5000164 (9007315-0507) |
Screw |
4 |
|
QC100 |
03-23 |
|
11112212 |
Control Kit, remote PC, high pressure (SB-2012-011) |
1 |
|
|
|
|
|
|
|
RP |
C102 |
03-23 |
|
4740064 |
Set screw |
2 |
|
|
|
|
|
|
|
|
C103 |
03-23 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
C104 |
03-23 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
C105 |
03-23 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
C106 |
03-23 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
C112 |
03-23 |
|
4740300 |
Spool |
1 |
|
C113 |
03-23 |
|
4740301 |
Spring guide |
1 |
|
C114 |
03-23 |
|
4740061 |
Spring |
1 |
|
C115 |
03-23 |
|
4740062 |
Spring |
1 |
|
C118 |
03-23 |
|
11062214 |
Adjusting plug (SB-2007-047 & SB-2010-026) |
1 |
|
C132 |
03-23 |
|
1701124 |
Spool |
1 |
|
C133 |
03-23 |
|
4740247 |
Spring guide |
1 |
|
C134 |
03-23 |
|
4740051 |
Spring, PC outer |
1 |
|
C135 |
03-23 |
|
4740052 |
Spring, PC inner |
1 |
|
C138 |
03-23 |
|
11062379 |
Adjusting plug assembly |
1 |
|
C138A |
03-23 |
|
5000656 |
O-ring |
1 |
|
C200 |
03-23 |
|
4740154 |
Seal ring |
4 |
|
C300 |
03-23 |
|
5000164 (9007315-0507) |
Screw |
4 |
|
QC100 |
03-23 |
|
11112213 |
Control Kit, remote PC (SB-2012-011) |
1 |
AX00000064en-US | 520L0585 • Rev 0401 • June 2016 |
17 |
Parts Manual |
|
|
Series 45 Frame J 45-75cc O. C. Pumps |
|
||
Control |
|
|
|
|
|
|
|
|
|
|
(AF & AG) |
|
|
|
|
|
|
*C118 |
|
|
QC100 |
|
|
|
C114 |
C300 |
|
|
|
|
C138 |
C115 |
|
|
|
|
|
|
|
||
|
|
|
|
C113 |
|
|
|
|
|
|
|
|
|
|
*C138A |
|
|
|
C102 |
|
|
|
|
|
|
|
|
|
|
C134 |
|
|
|
|
|
|
|
C135 |
|
|
|
|
|
|
|
C133 |
|
C112 |
|
|
|
|
|
|
|
|
|
|
|
*C154 |
|
C104 |
|
C153 |
|
|
*C200 |
|
|
|
|
|
|
|
||
|
|
|
|
|
|
C132 |
|
C151 |
|
|
|
QC120 |
C103 |
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
C152 |
|
|
|
C155
QC125
QC150
E101 700E
Enlarged bold type item
* = included in base motor seal kit Q210 numbers are recommended part to stock for servicing.
18 |
AX00000064en-US | 520L0585 • Rev 0401 • June 2016 |
Parts Manual |
|
Series 45 Frame J 45-75cc O. C. Pumps |
|
|||
|
|
|
|
|
|
|
Control |
|
|
|
|
|
|
Electric on/off control |
|
|
|
|
||
Order |
|
Date |
Date |
|
|
Qty. per |
code |
Item |
begin |
end |
Part number |
Part name |
model/kit |
AF |
C102 |
03-23 |
|
4740064 |
Set screw |
2 |
|
C103 |
03-23 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
C104 |
03-23 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
C112 |
03-23 |
|
4740300 |
Spool |
1 |
|
C113 |
03-23 |
|
4740301 |
Spring guide |
1 |
|
C114 |
03-23 |
|
4740061 |
Spring |
1 |
|
C115 |
03-23 |
|
4740062 |
Spring |
1 |
|
C118 |
03-23 |
|
11062214 |
Adjusting plug assembly (SB-2010-026) |
1 |
|
C132 |
03-23 |
|
1701124 |
Spool |
1 |
|
C133 |
03-23 |
|
4740247 |
Spring guide |
1 |
|
C134 |
03-23 |
|
4740051 |
Spring, PC outer |
1 |
|
C135 |
03-23 |
|
4740052 |
Spring, PC inner |
1 |
|
C138 |
03-23 |
|
11062379 |
Adjusting plug assembly (SB-2010-026) |
1 |
|
C138A |
03-23 |
|
5000656 |
O-ring |
1 |
|
C151 |
03-23 |
|
9007315-0510 |
Screw |
4 |
|
C152 |
03-23 |
|
11150082 |
Solenoid valve adapter (SB-2016-007) |
1 |
|
C153 |
03-23 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
C154 |
03-23 |
|
4740154 |
Seal ring |
2 |
|
C155 |
03-23 |
|
1701291 |
Coil, 12 volt |
1 |
|
C200 |
03-23 |
|
4740154 |
Seal ring |
4 |
|
C300 |
03-23 |
|
5000164 (9007315-0507) |
Screw |
4 |
|
QC100 |
03-23 |
|
11112296 |
Control Kit, electric on/off, 12 volt, NO (SB-2012-011) |
1 |
|
QC120 |
03-23 |
|
11103621 |
Solenoid valve seal kit |
1 |
|
QC125 |
03-23 |
|
11104457 |
Nut |
1 |
|
QC150 |
03-23 |
|
11104461 |
Solenoid valve kit, 12 volt |
1 |
|
|
|
|
|
|
|
AG |
C102 |
03-23 |
|
4740064 |
Set screw |
2 |
|
|
|
|
|
|
|
|
C103 |
03-23 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
C104 |
03-23 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
C112 |
03-23 |
|
4740300 |
Spool |
1 |
|
C113 |
03-23 |
|
4740301 |
Spring guide |
1 |
|
C114 |
03-23 |
|
4740061 |
Spring |
1 |
|
C115 |
03-23 |
|
4740062 |
Spring |
1 |
|
C118 |
03-23 |
|
11062214 |
Adjusting plug assembly (SB-2010-026) |
1 |
|
C132 |
03-23 |
|
1701124 |
Spool |
1 |
|
C133 |
03-23 |
|
4740247 |
Spring guide |
1 |
|
C134 |
03-23 |
|
4740051 |
Spring, PC outer |
1 |
|
C135 |
03-23 |
|
4740052 |
Spring, PC inner |
1 |
|
C138 |
03-23 |
|
11062379 |
Adjusting plug assembly (SB-2010-026) |
1 |
|
C138A |
03-23 |
|
5000656 |
O-ring |
1 |
|
C151 |
03-23 |
|
9007315-0510 |
Screw |
4 |
|
C152 |
03-23 |
|
11150082 |
Solenoid valve adapter (SB-2016-007) |
1 |
|
C153 |
03-23 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
C154 |
03-23 |
|
4740154 |
Seal ring |
2 |
|
C155 |
03-23 |
|
1701291 |
Coil, 12 volt |
1 |
|
C200 |
03-23 |
|
4740154 |
Seal ring |
4 |
|
C300 |
03-23 |
|
5000164 (9007315-0507) |
Screw |
4 |
|
QC100 |
03-23 |
|
11112295 |
Control Kit, electric on/off, 12 volt, NC (SB-2012-011) |
1 |
|
QC120 |
03-23 |
|
11103621 |
Solenoid valve seal kit |
1 |
|
QC125 |
03-23 |
|
11104457 |
Nut |
1 |
|
QC150 |
03-23 |
|
11104463 |
Solenoid valve kit, 12 volt |
1 |
|
|
|
AX00000064en-US | 520L0585 • Rev 0401 • June 2016 |
19 |
||
Parts Manual |
Series 45 Frame J 45-75cc O. C. Pumps |
|
|
Control
(AH)
QC100
QC150 |
C300 |
|
|
|
|
|
|
|
|
|
|
QC125 |
C104 |
|
|
|
|
|
|
|
|
|
|
C155 |
C112 |
|
|
|
|
|
C103 |
|
C102 |
|
|
|
|
|
|
|
|
|
C132 |
|
|
|
C113 |
|
|
|
|
|
|
|
*C154 |
|
|
|
C115 |
|
|
|
|
C114 |
|
|
C149 |
|
|
|
|
|
|
|
|
|
|
QC120 |
|
|
G020 |
|
|
|
|
G030 |
|
|
|
|
|
|
|
|
|
|
C152 |
C153 |
*C200 |
|
*C118 |
|
|
|
|||
C151 |
|
|
C133 |
C135 |
|
|
|
|
|
*C138A |
|
|
|
|
|
|
|
|
|
|
|
|
C134 |
|
|
|
|
|
C138 |
E101 621E
Enlarged bold type item
* = included in base motor seal kit Q210 numbers are recommended part to stock for servicing.
20 |
AX00000064en-US | 520L0585 • Rev 0401 • June 2016 |
Parts Manual |
|
Series 45 Frame J 45-75cc O. C. Pumps |
|
|||
|
|
|
|
|
|
|
Control |
|
|
|
|
|
|
Electric proportional control |
|
|
|
|||
Order |
|
Date |
Date |
|
|
Qty. per |
code |
Item |
begin |
end |
Part number |
Part name |
model/kit |
AH |
C102 |
03-23 |
|
4740064 |
Set screw |
2 |
|
C103 |
03-23 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
C104 |
03-23 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
C112 |
03-23 |
|
1701439 |
Spool |
1 |
|
C113 |
03-23 |
|
4740301 |
Spring guide |
1 |
|
C114 |
03-23 |
|
4740061 |
Spring |
1 |
|
C115 |
03-23 |
|
4740062 |
Spring |
1 |
|
C118 |
03-23 |
|
11062214 |
Adjusting plug assembly (SB-2010-026) |
1 |
|
C132 |
03-23 |
|
1701124 |
Spool |
1 |
|
C133 |
03-23 |
|
4740247 |
Spring guide |
1 |
|
C134 |
03-23 |
|
4740051 |
Spring, PC outer |
1 |
|
C135 |
03-23 |
|
4740052 |
Spring, PC inner |
1 |
|
C138 |
03-23 |
|
11062379 |
Adjusting plug assembly (SB-2010-026) |
1 |
|
C138A |
03-23 |
|
5000656 |
O-ring |
1 |
|
C149 |
03-23 |
|
739144 |
Orifice plug, 0.8mm |
1 |
|
C151 |
03-23 |
|
9007315-0510 |
Screw |
4 |
|
C152 |
03-23 |
|
11150082 |
Solenoid valve adapter (SB-2016-007) |
1 |
|
C153 |
03-23 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
C154 |
03-23 |
|
4740154 |
Seal ring |
2 |
|
C155 |
03-23 |
|
1701291 |
Coil, 12 volt |
1 |
|
C200 |
03-23 |
|
4740154 |
Seal ring |
4 |
|
C300 |
03-23 |
|
5000164 (9007315-0507) |
Screw |
4 |
|
G020 |
12-40 |
|
739144 |
Orifice, 0.8mm (SB-2012-011) |
1 |
|
G020 |
12-40 |
|
519659 |
Orifice, 1.0mm (SB-2012-011) |
1 |
|
G030 |
12-40 |
|
518215 |
Orifice plug (SB-2012-011) |
1 |
|
QC100 |
03-23 |
|
11112221 |
Control Kit, electric prop. 12 volt, NC (SB-2012-011) |
1 |
|
QC120 |
03-23 |
|
11103621 |
Solenoid valve seal kit |
1 |
|
QC125 |
03-23 |
|
11104460 |
Nut |
1 |
|
QC150 |
03-23 |
|
11104467 |
Solenoid valve kit, 12 volt |
1 |
AX00000064en-US | 520L0585 • Rev 0401 • June 2016 |
21 |
Parts Manual |
Series 45 Frame J 45-75cc O. C. Pumps |
|
|
Control
|
|
|
(AK) |
QC100 |
|
*C118 |
|
|
|
|
|
|
|
C114 |
|
|
|
C115 |
C300 |
|
C138 |
|
|
|
|
C113 |
|
|
|
|
|
*C138A |
|
|
C102 |
C134 |
|
|
|
|
C135 |
|
|
|
|
C133 |
|
|
|
*C154 |
|
|
|
|
G020 |
C153 |
|
|
G030 |
|
|
*C200 |
|
|
|
C149 |
|
|
|
|
|
C151 |
|
|
QC120 |
|
|
|
|
|
C152 |
|
|
QC150
C112
C104
C132
C103
C155
QC125
E101 833E
* = included in base motor seal kit Q210
Enlarged bold type item numbers are recommended part to stock for servicing.
22 |
AX00000064en-US | 520L0585 • Rev 0401 • June 2016 |
Parts Manual |
|
Series 45 Frame J 45-75cc O. C. Pumps |
|
|||
|
|
|
|
|
|
|
Control |
|
|
|
|
|
|
Electric proportional control |
|
|
|
|||
Order |
|
Date |
Date |
|
|
Qty. per |
code |
Item |
begin |
end |
Part number |
Part name |
model/kit |
AK |
C102 |
06-42 |
|
4740064 |
Set screw |
2 |
|
C103 |
06-42 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
C104 |
06-42 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
C112 |
06-42 |
|
1701439 |
Spool |
1 |
|
C113 |
06-42 |
|
4740301 |
Spring guide |
1 |
|
C114 |
06-42 |
|
4740061 |
Spring |
1 |
|
C115 |
06-42 |
|
4740062 |
Spring |
1 |
|
C118 |
06-42 |
|
11062214 |
Adjusting plug assembly (SB-2010-026) |
1 |
|
C132 |
06-42 |
|
1701124 |
Spool |
1 |
|
C133 |
06-42 |
|
4740247 |
Spring guide |
1 |
|
C134 |
06-42 |
|
4740051 |
Spring, PC outer |
1 |
|
C135 |
06-42 |
|
4740052 |
Spring, PC inner |
1 |
|
C138 |
06-42 |
|
11062379 |
Adjusting plug assembly (SB-2010-026) |
1 |
|
C138A |
06-42 |
|
5000656 |
O-ring |
1 |
|
C149 |
06-42 |
|
739144 |
Orifice plug, 0.8mm |
1 |
|
C151 |
06-42 |
|
9007315-0510 |
Screw |
4 |
|
C152 |
06-42 |
|
11150082 |
Solenoid valve adapter (SB-2016-007) |
1 |
|
C153 |
06-42 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
C154 |
06-42 |
|
4740154 |
Seal ring |
2 |
|
C155 |
06-42 |
|
1701563 |
Coil, 24 volt |
1 |
|
C200 |
06-42 |
|
4740154 |
Seal ring |
4 |
|
C300 |
06-42 |
|
5000164 (9007315-0507) |
Screw |
4 |
|
G020 |
12-40 |
|
739144 |
Orifice, 0.8mm (SB-2012-011) |
1 |
|
G020 |
12-40 |
|
519659 |
Orifice, 1.0mm (SB-2012-011) |
1 |
|
G030 |
12-40 |
|
518215 |
Orifice plug (SB-2012-011) |
1 |
|
QC100 |
06-42 |
|
11112291 |
Control Kit, electric prop. 24 volt, NC (SB-2012-011) |
1 |
|
QC120 |
06-42 |
|
11103621 |
Solenoid valve seal kit |
1 |
|
QC125 |
06-42 |
|
11104460 |
Nut |
1 |
|
QC150 |
06-42 |
|
11104468 |
Solenoid valve kit, 24 volt |
1 |
AX00000064en-US | 520L0585 • Rev 0401 • June 2016 |
23 |
Parts Manual |
Series 45 Frame J 45-75cc O. C. Pumps |
|
|
Control
(AL)
QC100
QC150 |
C300 |
|
|
|
|
|
|
|
|
|
|
QC125 |
C104 |
|
|
|
|
|
|
|
|
|
|
C155 |
C112 |
|
|
|
|
|
C103 |
|
C102 |
|
|
|
|
|
|
|
|
|
C132 |
|
|
|
C113 |
|
|
|
|
|
|
|
*C154 |
|
|
|
C115 |
|
|
|
|
C114 |
|
|
C149 |
|
|
|
|
|
|
|
|
|
|
QC120 |
|
|
G020 |
|
|
|
|
G030 |
|
|
|
|
|
|
|
|
|
|
C152 |
C153 |
*C200 |
|
*C118 |
|
|
|
|||
C151 |
|
|
C133 |
C135 |
|
|
|
|
|
*C138A |
|
|
|
|
|
|
|
|
|
|
|
|
C134 |
|
|
|
|
|
C138 |
E101 621E
* = included in base motor seal kit Q210
Enlarged bold type item numbers are recommended part to stock for servicing.
24 |
AX00000064en-US | 520L0585 • Rev 0401 • June 2016 |
Parts Manual |
|
Series 45 Frame J 45-75cc O. C. Pumps |
|
|||
|
|
|
|
|
|
|
Control |
|
|
|
|
|
|
Electric proportional control |
|
|
|
|||
Order |
|
Date |
Date |
|
|
Qty. per |
code |
Item |
begin |
end |
Part number |
Part name |
model/kit |
AL |
C102 |
08-20 |
|
4740064 |
Set screw |
2 |
|
C103 |
08-20 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
C104 |
08-20 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
C112 |
08-20 |
|
1701439 |
Spool |
1 |
|
C113 |
08-20 |
|
4740301 |
Spring guide |
1 |
|
C114 |
08-20 |
|
4740061 |
Spring |
1 |
|
C115 |
08-20 |
|
4740062 |
Spring |
1 |
|
C118 |
08-20 |
|
11062214 |
Adjusting plug assembly (SB-2010-026) |
1 |
|
C132 |
08-20 |
|
1701124 |
Spool |
1 |
|
C133 |
08-20 |
|
4740247 |
Spring guide |
1 |
|
C134 |
08-20 |
|
4740051 |
Spring, PC outer |
1 |
|
C135 |
08-20 |
|
4740052 |
Spring, PC inner |
1 |
|
C138 |
08-20 |
|
11062379 |
Adjusting plug assembly (SB-2010-026) |
1 |
|
C138A |
08-20 |
|
5000656 |
O-ring |
1 |
|
C149 |
08-20 |
|
739144 |
Orifice plug, 0.8mm |
1 |
|
C151 |
08-20 |
|
9007315-0510 |
Screw |
4 |
|
C152 |
08-20 |
|
11150082 |
Solenoid valve adapter (SB-2016-007) |
1 |
|
C153 |
08-20 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
C154 |
08-20 |
|
4740154 |
Seal ring |
2 |
|
C155 |
08-20 |
|
1701563 |
Coil, 24 volt |
1 |
|
C200 |
08-20 |
|
4740154 |
Seal ring |
4 |
|
C300 |
08-20 |
|
5000164 (9007315-0507) |
Screw |
4 |
|
G020 |
12-40 |
|
739144 |
Orifice, 0.8mm (SB-2012-011) |
1 |
|
G020 |
12-40 |
|
519659 |
Orifice, 1.0mm (SB-2012-011) |
1 |
|
G030 |
12-40 |
|
518215 |
Orifice plug (SB-2012-011) |
1 |
|
QC100 |
08-20 |
|
11112218 |
Control Kit, electric prop. 24 volt, NC (SB-2012-011) |
1 |
|
QC120 |
08-20 |
|
11103621 |
Solenoid valve seal kit |
1 |
|
QC125 |
08-20 |
|
11104460 |
Nut |
1 |
|
QC150 |
08-20 |
|
11104468 |
Solenoid valve kit, 24 volt |
1 |
AX00000064en-US | 520L0585 • Rev 0401 • June 2016 |
25 |
Parts Manual |
Series 45 Frame J 45-75cc O. C. Pumps |
|
|||
Control |
|
|
|
|
|
|
QC100 |
(AN) |
|
|
|
|
|
|
|
|
|
|
|
C300 |
|
|
|
|
QC150 |
|
|
|
|
QC125 |
C104 |
|
|
|
|
|
|
|
|
||
|
C155 |
C112 |
|
|
|
|
C103 |
|
C102 |
|
|
|
|
|
|
||
|
|
C132 |
|
|
C113 |
|
|
|
|
|
|
|
|
*C154 |
|
|
C115 |
|
|
|
|
C114 |
|
|
|
|
|
|
|
|
|
|
|
|
*C118 |
|
QC120 |
|
|
|
|
|
C152 |
|
C153 |
*C200 |
|
|
|
|
|
|
|
|
C151 |
|
|
C133 |
|
|
|
|
|
C135 |
*C138A |
|
|
|
|
|
C134 |
|
|
|
|
|
C138 |
E101 622E
* = included in base motor seal kit Q210
Enlarged bold type item numbers are recommended part to stock for servicing.
26 |
AX00000064en-US | 520L0585 • Rev 0401 • June 2016 |
Parts Manual |
|
Series 45 Frame J 45-75cc O. C. Pumps |
|
|||
|
|
|
|
|
|
|
Control |
|
|
|
|
|
|
Electric on/off control |
|
|
|
|
||
Order |
|
Date |
Date |
|
|
Qty. per |
code |
Item |
begin |
end |
Part number |
Part name |
model/kit |
AN |
C102 |
05-26 |
|
4740064 |
Set screw |
2 |
|
C103 |
05-26 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
C104 |
05-26 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
C112 |
05-26 |
|
4740300 |
Spool |
1 |
|
C113 |
05-26 |
|
4740301 |
Spring guide |
1 |
|
C114 |
05-26 |
|
4740061 |
Spring |
1 |
|
C115 |
05-26 |
|
4740062 |
Spring |
1 |
|
C118 |
05-26 |
|
11062214 |
Adjusting plug assembly (SB-2010-026) |
1 |
|
C132 |
05-26 |
|
1701124 |
Spool |
1 |
|
C133 |
05-26 |
|
4740247 |
Spring guide |
1 |
|
C134 |
05-26 |
|
4740051 |
Spring, PC outer |
1 |
|
C135 |
05-26 |
|
4740052 |
Spring, PC inner |
1 |
|
C138 |
05-26 |
|
11062379 |
Adjusting plug assembly (SB-2010-026) |
1 |
|
C138A |
05-26 |
|
5000656 |
O-ring |
1 |
|
C151 |
05-26 |
|
9007315-0510 |
Screw |
4 |
|
C152 |
05-26 |
|
11150082 |
Solenoid valve adapter (SB-2016-007) |
1 |
|
C153 |
05-26 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
C154 |
05-26 |
|
4740154 |
Seal ring |
2 |
|
C155 |
05-26 |
|
1701291 |
Coil, 12 volt |
1 |
|
C200 |
05-26 |
|
4740154 |
Seal ring |
4 |
|
C300 |
05-26 |
|
5000164 (9007315-0507) |
Screw |
4 |
|
QC100 |
05-26 |
|
11112229 |
Control Kit, electric on/off 12 volt, NO (SB-2012-011) |
1 |
|
QC120 |
05-26 |
|
11103621 |
Solenoid valve seal kit |
1 |
|
QC125 |
05-26 |
|
11104457 |
Nut |
1 |
|
QC150 |
05-26 |
|
11104461 |
Solenoid valve kit, 12 volt |
1 |
AX00000064en-US | 520L0585 • Rev 0401 • June 2016 |
27 |
Parts Manual |
Series 45 Frame J 45-75cc O. C. Pumps |
|
|
Control
(AR)
QC100
C300
QC150
QC125 |
C104 |
|
|
C155 |
C112 |
C103 |
C102 |
|
C132
C113
*C154
C115
C114
*C118
QC120
C152 |
C153 |
*C200 |
|
|
|
C151 |
|
C133 |
C135 |
*C138A |
C134
C138
E101 622E
Enlarged bold type item
* = included in base motor seal kit Q210 numbers are recommended part to stock for servicing.
28 |
AX00000064en-US | 520L0585 • Rev 0401 • June 2016 |
Parts Manual |
|
Series 45 Frame J 45-75cc O. C. Pumps |
|
|||
|
|
|
|
|
|
|
Control |
|
|
|
|
|
|
Electric on/off control |
|
|
|
|
||
Order |
|
Date |
Date |
|
|
Qty. per |
code |
Item |
begin |
end |
Part number |
Part name |
model/kit |
AR |
C102 |
05-26 |
|
4740064 |
Set screw |
2 |
|
C103 |
05-26 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
C104 |
05-26 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
C112 |
05-26 |
|
4740300 |
Spool |
1 |
|
C113 |
05-26 |
|
4740301 |
Spring guide |
1 |
|
C114 |
05-26 |
|
4740061 |
Spring |
1 |
|
C115 |
05-26 |
|
4740062 |
Spring |
1 |
|
C118 |
05-26 |
|
11062214 |
Adjusting plug assembly (SB-2010-026) |
1 |
|
C132 |
05-26 |
|
1701124 |
Spool |
1 |
|
C133 |
05-26 |
|
4740247 |
Spring guide |
1 |
|
C134 |
05-26 |
|
4740051 |
Spring, PC outer |
1 |
|
C135 |
05-26 |
|
4740052 |
Spring, PC inner |
1 |
|
C138 |
05-26 |
|
11062379 |
Adjusting plug assembly (SB-2010-026) |
1 |
|
C138A |
05-26 |
|
5000656 |
O-ring |
1 |
|
C151 |
05-26 |
|
9007315-0510 |
Screw |
4 |
|
C152 |
05-26 |
|
11150082 |
Solenoid valve adapter (SB-2016-007) |
1 |
|
C153 |
05-26 |
|
327007 (9005110-4400) |
Plug assembly |
1 |
|
C154 |
05-26 |
|
4740154 |
Seal ring |
2 |
|
C155 |
05-26 |
|
1701291 |
Coil, 12 volt |
1 |
|
C200 |
05-26 |
|
4740154 |
Seal ring |
4 |
|
C300 |
05-26 |
|
5000164 (9007315-0507) |
Screw |
4 |
|
QC100 |
05-26 |
|
11112220 |
Control Kit, electric on/off 12 volt, NC (SB-2012-011) |
1 |
|
QC120 |
05-26 |
|
11103621 |
Solenoid valve seal kit |
1 |
|
QC125 |
05-26 |
|
11104457 |
Nut |
1 |
|
QC150 |
05-26 |
|
11104463 |
Solenoid valve kit, 12 volt |
1 |
AX00000064en-US | 520L0585 • Rev 0401 • June 2016 |
29 |
Parts Manual |
|
|
Series 45 Frame J 45-75cc O. C. Pumps |
|
||
Control |
|
|
|
|
|
|
|
|
|
|
|
(AT) |
|
|
|
|
|
*C118 |
|
|
QC100 |
|
|
|
C114 |
C300 |
|
|
|
|
C138 |
C115 |
|
|
|
|
|
|
|
||
|
|
|
|
C113 |
|
|
|
|
|
|
|
|
|
|
*C138A |
|
|
|
C102 |
|
|
|
|
|
|
|
|
|
|
C134 |
|
|
|
|
|
|
|
C135 |
|
|
|
|
|
|
|
C133 |
|
C112 |
|
|
|
|
|
|
|
|
|
|
|
*C154 |
|
C104 |
|
C153 |
|
|
*C200 |
|
|
|
|
|
|
|
||
|
|
|
|
|
|
C132 |
|
C151 |
|
|
|
QC120 |
C103 |
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
C152 |
|
|
|
C155
QC125
QC150
E101 700E
Enlarged bold type item
* = included in base motor seal kit Q210 numbers are recommended part to stock for servicing.
30 |
AX00000064en-US | 520L0585 • Rev 0401 • June 2016 |
Loading...
