Danfoss H1B 75cc Service guide

Download
Parts Manual
Series 90 Axial Piston Pumps
Size 75cc
www.danfoss.com
Parts Manual
Series 90 75cc Axial Piston Pump
Revision history Table of revisions
Date Changed Rev
February 2022 Updated various part numbers, added missing part numbers from seal kit 0601
July 2020 Changed document number from 'AX00000091' to 'AX152886482206' and updated part
0501
2 | © Danfoss | February 2022 AX152886482206en-000601
Parts Manual
Series 90 75cc Axial Piston Pump

Contents

General information
Service parts identification........................................................................................................................................................... 7
Nameplate...........................................................................................................................................................................................7
Date code............................................................................................................................................................................................ 8
About service bulletins...................................................................................................................................................................8
Procedure to identify a part..........................................................................................................................................................8
Regional part numbers............................................................................................................................................................. 8
Example of a part identification (S90 75cc)....................................................................................................................... 8
Adobe Acrobat 2-page viewing..................................................................................................................................................9
Order code........................................................................................................................................................................................10
Common parts and special hardware
S90P 75cc common parts............................................................................................................................................................11
Special hardware EAB-EBA......................................................................................................................................................... 15
Special hardware EBC, EBE..........................................................................................................................................................17
Special hardware EDC-EDI.......................................................................................................................................................... 19
Special hardware EEB, EEG..........................................................................................................................................................21
Special hardware EEH...................................................................................................................................................................23
Special hardware EFC-EFL...........................................................................................................................................................27
Special hardware EFP....................................................................................................................................................................29
Special hardware EFR................................................................................................................................................................... 33
Special hardware EHA-EKB......................................................................................................................................................... 37
Special hardware ELA................................................................................................................................................................... 39
Special hardware ELB....................................................................................................................................................................43
Special hardware ELC................................................................................................................................................................... 47
Special hardware FAA-FAK.........................................................................................................................................................51
Special hardware FAL, FAN.........................................................................................................................................................53
Special hardware FAP-FAU.........................................................................................................................................................55
Special hardware FAX, FAY.........................................................................................................................................................57
Special hardware FAZ-FBG......................................................................................................................................................... 59
Special hardware FCF, FHP......................................................................................................................................................... 61
Special hardware GAA-GBT........................................................................................................................................................63
Special hardware GBU..................................................................................................................................................................65
Special hardware GBX-GCP........................................................................................................................................................ 69
Special hardware GCR-GCU........................................................................................................................................................71
Special hardware GDE-GFP.........................................................................................................................................................73
Special hardware GFS-GFZ......................................................................................................................................................... 75
Special hardware GHT-GMA.......................................................................................................................................................77
Special hardware GMC.................................................................................................................................................................79
Special hardware GMD.................................................................................................................................................................83
Special hardware GME................................................................................................................................................................. 87
Special hardware GTA-PEA.........................................................................................................................................................91
Special hardware PEB-PGB......................................................................................................................................................... 93
Displacement
Displacement limitation 1-4.......................................................................................................................................................95
Displacement limitation 7...........................................................................................................................................................97
Displacement limitation 8, B......................................................................................................................................................99
Displacement limitation D....................................................................................................................................................... 101
Displacement limitation F........................................................................................................................................................ 103
Displacement limitation H....................................................................................................................................................... 105
Displacement limitation L........................................................................................................................................................ 107
Displacement limitation............................................................................................................................................................109
End cap
End cap H-6R.................................................................................................................................................................................111
End cap 60-67............................................................................................................................................................................... 113
End cap 6U, 6W.............................................................................................................................................................................115
End cap 1-81..................................................................................................................................................................................117
End cap 82, 8W............................................................................................................................................................................. 119
End cap 80-8V (built in Germany)..........................................................................................................................................121
©
Danfoss | February 2022 AX152886482206en-000601 | 3
Parts Manual
Series 90 75cc Axial Piston Pump
Contents
Charging system
Charging system C-F.................................................................................................................................................................. 123
Charging system L, N..................................................................................................................................................................125
Charging system S, Y..................................................................................................................................................................127
Auxiliary mounting
Auxiliary mounting AB and AC...............................................................................................................................................129
Aux mounting AH-BA.................................................................................................................................................................131
Aux mounting BB-V.................................................................................................................................................................... 133
Aux mounting BD........................................................................................................................................................................135
Aux mounting BE, BF..................................................................................................................................................................137
Aux mounting BH-BP................................................................................................................................................................. 139
Aux mounting BR.........................................................................................................................................................................141
Aux mounting BT-CK..................................................................................................................................................................143
Aux mounting CK........................................................................................................................................................................ 145
Auxiliary mounting CP, CR....................................................................................................................................................... 147
Aux mounting CT-CV..................................................................................................................................................................149
Aux mounting CW.......................................................................................................................................................................151
Aux mounting CX-NN................................................................................................................................................................ 153
Charge pressure setting
Charge pressure setting............................................................................................................................................................155
Shaft
Shaft C6-SA.................................................................................................................................................................................... 157
Shaft G2, J8, K2............................................................................................................................................................................. 159
Shaft T1-TJ......................................................................................................................................................................................161
Control
Control CA-DD..............................................................................................................................................................................163
Control EA, EG...............................................................................................................................................................................165
Control EP, EX................................................................................................................................................................................167
Control FA-FD............................................................................................................................................................................... 169
Control FG, FH...............................................................................................................................................................................171
Control FK-FN................................................................................................................................................................................173
Control HF-HS............................................................................................................................................................................... 175
Control HU-JC............................................................................................................................................................................... 177
Control K0-K7................................................................................................................................................................................179
Control KA-KC............................................................................................................................................................................... 181
Control KD-KH...............................................................................................................................................................................183
Control KK-KP................................................................................................................................................................................185
Control KT.......................................................................................................................................................................................187
Control KY, LB................................................................................................................................................................................189
Control LC, LE................................................................................................................................................................................191
Control LG, LK............................................................................................................................................................................... 193
Control LL, LN................................................................................................................................................................................195
Control LS, LT................................................................................................................................................................................ 197
Control M1, M2.............................................................................................................................................................................199
Control M3..................................................................................................................................................................................... 201
Control M7, M8.............................................................................................................................................................................203
Control MA, MB............................................................................................................................................................................ 205
Control MC, MD............................................................................................................................................................................207
Control ME, MG............................................................................................................................................................................ 209
Control MH, MJ.............................................................................................................................................................................211
Control MK, ML.............................................................................................................................................................................213
Control MN.....................................................................................................................................................................................215
Control MR, MS.............................................................................................................................................................................217
Control MT, MV.............................................................................................................................................................................219
Control MW....................................................................................................................................................................................221
Control MX, MY.............................................................................................................................................................................223
Control NA, NC..............................................................................................................................................................................225
4 | © Danfoss | February 2022 AX152886482206en-000601
Parts Manual
Series 90 75cc Axial Piston Pump
Contents
Control NE...................................................................................................................................................................................... 227
Control NU..................................................................................................................................................................................... 229
Control PA, PB...............................................................................................................................................................................231
Control PE.......................................................................................................................................................................................233
Control PF, PG...............................................................................................................................................................................235
Control PH, PJ................................................................................................................................................................................237
Control RR, RS................................................................................................................................................................................239
Control RU......................................................................................................................................................................................241
Control SA, SB, SD, SE.................................................................................................................................................................243
Control SC.......................................................................................................................................................................................245
Filtration
Filtration 3-J...................................................................................................................................................................................247
Filtration L, P..................................................................................................................................................................................249
Filtration R-X..................................................................................................................................................................................251
High pressure protection
High pressure regulation 1-7...................................................................................................................................................253
High pressure regulation A-F.................................................................................................................................................. 255
High pressure regulation G-M.................................................................................................................................................257
High pressure regulation N, P................................................................................................................................................. 259
High pressure regulation R, S..................................................................................................................................................261
High pressure regulation U, W................................................................................................................................................263
High pressure regulation X, Y..................................................................................................................................................265
Orifice
Orifice 01-24.................................................................................................................................................................................. 267
Orifice 25-34.................................................................................................................................................................................. 271
Orifice 48-49.................................................................................................................................................................................. 275
Orifice 50-76.................................................................................................................................................................................. 277
Orifice 78-A7..................................................................................................................................................................................281
Orifice A8-C4..................................................................................................................................................................................285
Orifice C5-G8................................................................................................................................................................................. 289
Orifice G8-P1..................................................................................................................................................................................293
Orifice Z1, Z3................................................................................................................................................................................. 297
overhaul seal kit
Seal kit..............................................................................................................................................................................................299
Service bulletin
SB-1988-009...................................................................................................................................................................................300
SB-1988-016...................................................................................................................................................................................302
SB-1988-023...................................................................................................................................................................................304
SB-1989-002...................................................................................................................................................................................306
SB-1989-003...................................................................................................................................................................................306
SB-1989-006...................................................................................................................................................................................308
SB-1989-023...................................................................................................................................................................................310
SB-1992-003...................................................................................................................................................................................312
SB-1992-011...................................................................................................................................................................................314
SB-1993-001...................................................................................................................................................................................315
SB-1993-015...................................................................................................................................................................................318
SB-1994-017...................................................................................................................................................................................320
SB-1994-018...................................................................................................................................................................................321
SB-1994-36.....................................................................................................................................................................................323
SB-1995-003...................................................................................................................................................................................324
SB-1995-012...................................................................................................................................................................................325
SB-1995-025...................................................................................................................................................................................327
SB-1996-009...................................................................................................................................................................................329
SB-1998-066...................................................................................................................................................................................330
SB-1998-041...................................................................................................................................................................................332
SB-1998-073...................................................................................................................................................................................334
©
Danfoss | February 2022 AX152886482206en-000601 | 5
Parts Manual
Series 90 75cc Axial Piston Pump
Contents
SB-1999-009...................................................................................................................................................................................336
SB-1999-019...................................................................................................................................................................................338
SB-1999-041...................................................................................................................................................................................339
SB-1999-065...................................................................................................................................................................................341
SB-2000-022...................................................................................................................................................................................343
SB-2000-041...................................................................................................................................................................................345
SB-2002-050...................................................................................................................................................................................346
SB-2004-012...................................................................................................................................................................................347
SB-2005-007...................................................................................................................................................................................348
SB-2005-011...................................................................................................................................................................................350
SB-2007-027...................................................................................................................................................................................351
SB-2007-051...................................................................................................................................................................................353
SB-2007-055...................................................................................................................................................................................355
SB-2009-073...................................................................................................................................................................................357
SB-2013-011...................................................................................................................................................................................359
SB-2015-005...................................................................................................................................................................................360
SB-2017-033...................................................................................................................................................................................361
6 | © Danfoss | February 2022 AX152886482206en-000601
Made in U. S. A.
Serial No.
A-01-26-23456
Model Code
Model No./Ident No.
90 L 075 EP 1
NN 60 S 3 S1 D
03 GBA 35 35 24
9521216
Parts Manual
Series 90 75cc Axial Piston Pump

General information

Service parts identification

The following information and procedure is used to identify the module group, item number, manufacture date, part number, and part name of the parts included in the .
The parts listed include all parts which may be used when performing either “Minor Repairs”, “Major Repairs” or “Conversions” on the .

Nameplate

Each unit will have a nameplate affixed to the housing. The nameplate of the will include the following information:
Model code
The Danfoss model code completely defines the specific unit and must be used when ordering parts to service this product.
Model/material number
The Danfoss model number (also known as material number) is used by the factory in manufacturing. On repeat orders, a complete unit can be ordered by the model number.
Serial number
The Danfoss serial number is used to identify the manufacture date and the unit sequence in the build. The serial number is also used to identify the units warranty time period.
The letter code indicates the location of original manufacture (assembly). The first number (2 digits) indicates the year of manufacture. The second number (2 digits) indicates the
calendar week of manufacture. The third number (5 digits) is a sequential number used to identify a specific unit.
©
Danfoss | February 2022 AX152886482206en-000601 | 7
Parts Manual
Series 90 75cc Axial Piston Pump
General information

Date code

The date code is defined as the year and week of manufacture. The same item number may list more than one part number. This indicates that there is more than one configuration for that item number. You will see that there are different date codes for the different part numbers. Find the date code of your unit from the nameplate to determine which service part number you need to order.
Example: The service part desired is item G30
Order Code Item Date Begin Date End Part Number Part Name Qty. per
80 G30 89-17 8000243 End cap gasket 1
All units using this order code with a date code prior to 89-17 must use part number “8000151.” All units with a date code of 89-17 and newer must use part number “8000243.”

About service bulletins

A Service Bulletin Number (SB-_ _ _ _ - _ _ _) may follow the “Part Name” of the part you desire. You must read that Service Bulletin prior to ordering that part. The information contained in these Service Bulletins, as of the print date of this bulletin, are included at the end of this manual. Service Bulletins contain more detailed information such as interchangeability, what additional parts are involved, etc. It is suggested that you add additional Service Bulletins to this manual as you receive them.
G30 89-16 8000151 End cap gasket
(SB-1995-006)
Model/Kit
1

Procedure to identify a part

The modular design of this product results in a simplified service parts list and part number identification procedure.
The same item numbers are used for same part names on all units within a product type. A part number that has another number following it in parentheses is done to make this a world wide manual.

Regional part numbers

Some part numbers are region specific and should be ordered accordingly. As an example, the part number (example: 314583 (9008000-0118) will be used. The first number is sold
in Germany. The number in parentheses is sold in the United States. Customers would order 9008000-0118 if ordering the part in the United States.

Example of a part identification (S90 75cc)

The nameplate on a Series 90 pump has an Order Code of 90L075 EP 1 NN 60 S 3 S1 D 03 GBA 35 35 24. Use the following procedures to determine the part number of the drive shaft used on this pump.
1. Referring to the input shaft module in the Order Code, the input shaft option for this pump is identified by the code “S1. (90L075 EP 1 NN 60 S 3 S1 D 03 GBA 35 35 24).
2. Referring to the Service Parts List, find the shaft group. Next find the order code that relates to this unit, which is “S1”. The shaft is found to be item L100 and part number 8100264.
8 | © Danfoss | February 2022 AX152886482206en-000601
Parts Manual
Series 90 75cc Axial Piston Pump
General information

Adobe Acrobat 2-page viewing

While viewing manual in Adobe Acrobat, the following settings need to be applied to ensure proper page display.
1. Select “View” → “Page Display” → “Two Page View”
2. Select “View” → “Page Display” → “Show Cover Page in Two Page View”
©
Danfoss | February 2022 AX152886482206en-000601 | 9
9
0
L
5
0
7
E
P
1
C
D
6
S 1
3
0
S
0 3
D
2 4
5
B A
G
5 3
3
Series
Displacement
Pressure regulation
Auxiliary mounting pad
End cap
Control
Filtration
Displacement limitation
Shaft
Charging system
Control orifice
M P J G N F L H T W Y Z K
Special hardware features
High pressure setting port A
High pressure setting port B
Charge pressure setting
Rotation
Parts Manual
Series 90 75cc Axial Piston Pump
General information

Order code

10 | © Danfoss | February 2022 AX152886482206en-000601
B50
B50
B72
L50
*L25
L70
L60
L40
B70
B80
L10
L20
QB30
*E40
*E60
*E50
E90
E70
E10
D55
D10
F20
D65
D70
D50
D80
D85
M14
D75
QD50
*B90
*B90
B82
E30
E22
E20
E80
E24
D55
D10
F20
D95
D60
D65
D70
D50
D80
D85
M14
D75
QD50
Swashplate
design prior
to 05-48
Leveler design
99-28 thru 06-26
E20
E30
E80
E24
B10
Parts Manual
Series 90 75cc Axial Piston Pump

Common parts and special hardware

S90P 75cc common parts

Parts configuration
©
Danfoss | February 2022 AX152886482206en-000601 | 11
* Included in base pump seal kit Q210
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Common parts
Item Date Begin Date End Part Number Part Name Qty. per
B10 05-49 11001300 Housing (SB-2005-007 on page 348) 1 B50 87-02 9004800-3708 Pin 2 B70 87-02 140644 (9005110-5600) Plug assembly 1 B72 87-02 140644 (9005110-5600) Plug assembly 1 B80 87-02 664524 (9005110-9000) Plug assembly 1 B82 92-19 140644 (9005110-5600) Plug assembly (SB-1992-003 on page 312) 1 B90 87-02 9803390 Control filter screen 3 D10 05-49 519046 Servo arm (SB-2005-007 on page 348) 1 D10 88-16 05-48 8100499 Servo arm assembly (SB-1993-015 on page 318) 1 D50 05-49 11000688 Swashplate (SB-2005-007 on page 348) 1 D50 88-16 05-48 8100367 Swashplate 1 D55 05-49 519150 Screw (SB-2005-007 on page 348) 1 D55 87-02 05-48 666032 (9007276-0107) Screw 1 D60 87-02 05-48 8800669 Swashplate guide 1 D65 87-02 9007375-0044 Screw (SB-1992-011 on page 314) 1 D70 87-02 9009625-0146 Washer 1 D75 87-02 9004875-0098 Spiral head pin 1 D80 87-02 693929 (8100506) Cage locator link (SB-1994-017 on page 320) 1 D85 01-26 8801235 Pin (SB-2004-012 on page 347) 1 D85 87-02 01-25 8801135 Pin (SB-1998-018) 1 D95 87-02 05-48 8100035 Spring (SB-2005-007 on page 348) 1 E10 05-49 11001286 Side cover (SB-2005-007 on page 348) 1 E10 95-50 05-48 501572 Side cover (SB-1995-025 on page 327) 1 E20 98-14 11042018 Leveler (SB-1999-009 on page 336) 1 E22 06-27 517935 Spring seat 2 E22 99-28 06-26 none E22 98-14 99-27 517935 Spring seat (SB-1999-009 on page 336) 2 E24 92-06 8801225 Shim (SB-2000-041 on page 345) 2 E30 99-28 11056531 Guide post (SB-2009-073 on page 357) 2 E30 95-50 99-27 8000510 Guide post (SB-1999-009 on page 336) 2 E30 87-02 95-49 8510098 Side cover kit (SB-1995-025 on page 327) 1 E40 87-02 505412 (9003509-0008) Seal nut 2 E50 87-02 517377 O-ring 1 E60 87-02 517228 (5000206) Screw (SB-1994-018 on page 321) 6 E70 87-02 664524 (9005110-9000) Plug assembly 1 E80 87-02 334987 (11062691) Spring 2 E90 95-50 513888 Insert assembly (SB-1995-025 on page 327 &
SB-1999-041 on page 339)
F20 88-16 11116313 Slider block (SB-1988-009 on page 300 &
SB-2015-005 on page 360)
Model/Kit
1
1
Part numbers continue to the next 2 pages.
12 | © Danfoss | February 2022 AX152886482206en-000601
B50
B50
B72
L50
*L25
L70
L60
L40
B70
B80
L10
L20
QB30
*E40
*E60
*E50
E90
E70
E10
D55
D10
F20
D65
D70
D50
D80
D85
M14
D75
QD50
*B90
*B90
B82
E30
E22
E20
E80
E24
D55
D10
F20
D95
D60
D65
D70
D50
D80
D85
M14
D75
QD50
Swashplate
design prior
to 05-48
Leveler design
99-28 thru 06-26
E20
E30
E80
E24
B10
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Parts configuration
©
Danfoss | February 2022 AX152886482206en-000601 | 13
* Included in base pump seal kit Q210
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Common parts
Item Date Begin Date End Part Number Part Name Qty. per
L10 87-02 5000505 Roller bearing 1 L20 87-02 9006300-0156 Retaining ring 1 L25 87-02 519671 Seal carrier assembly (SB-2005-007 on page 348) 1 L40 87-02 519666 Lip seal (SB-2005-007 on page 348) 1 L50 87-02 684621 (9004104-1530) O-ring 1 L60 87-02 516767 Retainer plate 1 L70 87-02 041160 (9007314-0605) Screw 3 QB30 87-02 05-48 676841 (8700048) Cradle bearing assembly (SB-2005-007 on page
348)
QB30 05-49 11131108 Cradle bearing assembly (SB-2005-007 on page
348)
QD50 05-49 8100984 Swashplate assembly (SB-2005-007 on page 348) 1 QD50 88-16 05-48 8100376 Swashplate assembly (SB-1988-009 on page 300) 1
Model/Kit
1
1
14 | © Danfoss | February 2022 AX152886482206en-000601
C80
C06
*C70
C40
C50
C30
C20
QC04
E82
E82
B83
*QB83
C80
C06
*C70
C40
C50
C30
C20
QC04
B83
*QB83
(EAB, EAS, EAV & EBE)
(EAC, EBA & EBC)
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
S90P 75cc special hardware EAB-EBA
Parts configuration
©
Danfoss | February 2022 AX152886482206en-000601 | 15
Generic speed sensors shown.
* Included in base pump seal kit Q210
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Common parts
Item Date Begin Date End Part Number Part Name Qty. per
C20 87-02 708230 Piston assembly (SB-1988-023 on page 304) 9 C30 87-02 11067350 Slipper guide 1 C40 88-22 334391 (8100294) Slipper guide bearing (SB-1988-016 on page 302) 2 C50 88-22 11065865 Spacer (SB-1988-016 on page 302 & SB-1998-041
on page 332)
C65 88-22 98-47 Obsolete Washer (SB-1988-016 on page 302 & SB-1998-041
on page 332)
C70 88-22 314419 (9007276-0114) Screw (SB-1988-016 on page 302 & SB-1998-041
on page 332)
QB83 98-14 085043 (9004201-3700) O-ring 1
Order code: EAB
B83 98-14 KPPG12508 Speed sensor 1 C06 98-14 11094260 (11011714) Cylinder block assembly, with speed ring 1 C80 98-14 518008 Valve plate 1 E82 98-14 11062703 Spring 2 QC04 98-14 8510366 Cylinder block kit, with speed ring 1
Model/Kit
4
4
4
Order code: EAC
B83 98-14 KPPG12508 Speed sensor 1 C06 98-14 11094260 (11011714) Cylinder block assembly, with speed ring 1 C80 98-14 518805 Valve plate 1 QC04 98-14 8510366 Cylinder block kit, with speed ring 1
Order code: EAS
B83 98-14 KPPG12508 Speed sensor 1 C06 98-14 11094260 (11011714) Cylinder block assembly, with speed ring 1 C80 98-14 518008 Valve plate 1 E82 98-14 360842 Spring 2 QC04 98-14 8510366 Cylinder block kit, with speed ring 1
Order code: EAV
B83 06-12 12-35 11046858 Speed sensor 1 C06 06-12 12-35 11094260 (11011714) Cylinder block assembly, with speed ring 1 C80 06-12 12-35 518008 Valve plate 1 E82 06-12 12-35 11062703 Spring 2 QC04 06-12 12-35 8510366 Cylinder block kit, with speed ring 1
Order code: EBA
B83 04-26 KPPG13408 Speed sensor 1 C06 04-26 11094260 (11011714) Cylinder block assembly, with speed ring 1 C80 04-26 518924 Valve plate 1 QC04 04-26 8510366 Cylinder block kit, with speed ring 1
16 | © Danfoss | February 2022 AX152886482206en-000601
C80
C06
*C70
C40
C50
C30
C20
QC04
E82
E82
B83
*QB83
C80
C06
*C70
C40
C50
C30
C20
QC04
B83
*QB83
(EAB, EAS, EAV & EBE)
(EAC, EBA & EBC)
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
S90P 75cc special hardware EBC, EBE
Parts configuration
©
Danfoss | February 2022 AX152886482206en-000601 | 17
Generic speed sensors shown.
* Included in base pump seal kit Q210
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Common parts
Item Date Begin Date End Part Number Part Name Qty. per
C20 87-02 708230 Piston assembly (SB-1988-023 on page 304) 9 C30 87-02 11067350 Slipper guide 1 C40 88-22 334391 (8100294) Slipper guide bearing (SB-1988-016 on page 302) 2 C50 88-22 11065865 Spacer (SB-1988-016 on page 302 & SB-1998-041
on page 332)
C65 88-22 98-47 Obsolete Washer (SB-1988-016 on page 302 & SB-1998-041
on page 332)
C70 88-22 314419 (9007276-0114) Screw (SB-1988-016 on page 302 & SB-1998-041
on page 332)
QB83 98-14 085043 (9004201-3700) O-ring 1
Order code: EBC
B83 04-26 KPPG13408 Speed sensor 1 C06 04-26 11094260 (11011714) Cylinder block assembly, with speed ring 1 C80 04-26 518805 Valve plate 1 QC04 04-26 8510366 Cylinder block kit, with speed ring 1
Model/Kit
4
4
4
Order code: EBE
B83 94-30 KPPG15408 Speed sensor 1 C06 04-26 11094260 (11011714) Cylinder block assembly, with speed ring 1 C80 94-30 518805 Valve plate 1 E82 98-14 11062703 Spring 2 QC04 04-26 8510366 Cylinder block kit, with speed ring 1
18 | © Danfoss | February 2022 AX152886482206en-000601
C80
C06
*C70
C40
C50
C30
C20
QC04
E82
E82
B83
*QB83
C80
C06
*C70
C40
C50
C30
C20
QC04
B83
*QB83
B83
(EDC)
(EEB & EEG)
(EDF, EDH & EDI)
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
S90P 75cc special hardware EDC-EDI
Parts configuration
©
Danfoss | February 2022 AX152886482206en-000601 | 19
Generic speed sensors shown.
* Included in base pump seal kit Q210
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Common parts
Item Date Begin Date End Part Number Part Name Qty. per
C20 87-02 708230 Piston assembly (SB-1988-023 on page 304) 9 C30 87-02 11067350 Slipper guide 1 C40 88-22 334391 (8100294) Slipper guide bearing (SB-1988-016 on page 302) 2 C50 88-22 11065865 Spacer (SB-1988-016 on page 302 & SB-1998-041
on page 332)
C65 88-22 98-47 Obsolete Washer (SB-1988-016 on page 302 & SB-1998-041
on page 332)
C70 88-22 314419 (9007276-0114) Screw (SB-1988-016 on page 302 & SB-1998-041
on page 332)
QB83 98-14 085043 (9004201-3700) O-ring 1
Order code: EDC
B83 94-34 KPPG13408 Speed sensor 1 C06 94-34 11094260 (11011714) Cylinder block assembly, with speed ring 1 C80 94-34 518925 Valve plate, CW 1 C80 94-34 518926 Valve plate, CCW 1 E82 94-34 11062703 Spring 2 QC04 94-34 8510366 Cylinder block kit, with speed ring 1
Model/Kit
4
4
4
Order code: EDF
B83 94-34 12-35 11046858 Speed sensor 1 C06 94-34 12-35 11094260 (11011714) Cylinder block assembly, with speed ring 1 C80 97-14 12-35 518008 Valve plate 1 QC04 94-34 12-35 8510366 Cylinder block kit, with speed ring 1
Order code: EDH
B83 99-17 12-36 KPPG15408 Speed sensor 1 C06 99-17 12-36 11094260 (11011714) Cylinder block assembly, with speed ring 1 C80 99-17 12-36 518007 Valve plate 1 QC04 99-17 12-36 8510366 Cylinder block kit, with speed ring 1
Order code: EDI
B83 00-17 12-36 KPPG15408 Speed sensor 1 C06 00-17 12-36 11094260 (11011714) Cylinder block assembly, with speed ring 1 C80 00-17 12-36 518925 Valve plate, CW 1 C80 00-17 12-36 518926 Valve plate, CCW 1 QC04 00-17 12-36 8510366 Cylinder block kit, with speed ring 1
20 | © Danfoss | February 2022 AX152886482206en-000601
C80
C06
*C70
C40
C50
C30
C20
QC04
E82
E82
B83
*QB83
C80
C06
*C70
C40
C50
C30
C20
QC04
B83
*QB83
B83
(EDC)
(EEB & EEG)
(EDF, EDH & EDI)
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
S90P 75cc special hardware EEB, EEG
Parts configuration
©
Danfoss | February 2022 AX152886482206en-000601 | 21
Generic speed sensors shown.
* Included in base pump seal kit Q210
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Common parts
Item Date Begin Date End Part Number Part Name Qty. per
C20 87-02 708230 Piston assembly (SB-1988-023 on page 304) 9 C30 87-02 11067350 Slipper guide 1 C40 88-22 334391 (8100294) Slipper guide bearing (SB-1988-016 on page 302) 2 C50 88-22 11065865 Spacer (SB-1988-016 on page 302 & SB-1998-041
on page 332)
C65 88-22 98-47 Obsolete Washer (SB-1988-016 on page 302 & SB-1998-041
on page 332)
C70 88-22 314419 (9007276-0114) Screw (SB-1988-016 on page 302 & SB-1998-041
on page 332)
QB83 98-14 085043 (9004201-3700) O-ring 1
Order code: EEB
B83 99-17 140644 (9005110-5600) Plug assembly 1 C06 99-17 11094260 (11011714) Cylinder block assembly, with speed ring 1 C80 99-17 518008 Valve plate 1 QC04 99-17 8510366 Cylinder block kit, with speed ring 1
Model/Kit
4
4
4
Order code: EEG
B83 00-17 140644 (9005110-5600) Plug assembly 1 C06 00-17 11094260 (11011714) Cylinder block assembly, with speed ring 1 C80 00-17 518925 Valve plate, CW 1 C80 00-17 518926 Valve plate, CCW 1 QC04 00-17 8510366 Cylinder block kit, with speed ring 1
22 | © Danfoss | February 2022 AX152886482206en-000601
B100
E30
E22
E20
E80
E24
B94
D65
D10
D50
D86
D87
D75
D70
F20
B92
B84
*C70
C40
C50
C30
C20
QC04
C80
C06
B83
QD50
B72
L50
*L25
L70
L60
L40
B70
B80
L10
L20
B50
B50
QB30
*E40
*E60
*E50
E90
E70
E10
D55
D80
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
S90P 75cc special hardware EEH
Parts configuration
* Included in base pump seal kit Q210
©
Danfoss | February 2022 AX152886482206en-000601 | 23
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Order code: EEH
Item Date Begin Date End Part Number Part Name Qty. per
B50 05-20 12-36 9004800-3708 Pin 2 B70 05-20 12-36 140644 Plug assembly 1 B72 05-20 12-36 140644 Plug assembly 1 B80 05-20 12-36 664524 (9005110-9000) Plug assembly 1 B83 05-20 12-36 140644 Plug assembly 1 B84 05-20 12-36 11040532 Plug assembly 1 B92 05-20 12-36 11040532 Plug assembly 1 B94 05-20 12-36 11040532 Plug assembly 1 B100 05-20 12-36 11117294 Housing assembly 1 C06 05-20 12-36 11094260 (11011714) Cylinder block assembly, with speed ring 1 C20 05-20 12-36 708230 Piston assembly 9 C30 05-20 12-36 11067350 Slipper guide 1 C40 05-20 12-36 334391 (8100294) Slipper guide bearing 2 C50 05-20 12-36 11065865 Spacer 4 C70 05-20 12-36 314419 (9007276-0114) Screw 4 C80 05-20 12-36 518008 Valve plate 1 D10 05-20 12-36 519046 Servo arm 1 D50 05-20 12-36 11104315 Swashplate 1 D55 05-20 12-36 519150 Screw 1 D70 05-20 12-36 9009625-0146 Washer 1 D75 05-20 12-36 9004875-0098 Spiral head pin 1 D80 05-20 12-36 693929 (8100506) Cage locator link 1 D86 05-20 12-36 9004800-1908 Pin 1 D87 05-20 12-36 11040532 Plug assembly 1 E10 05-20 12-36 11001286 Side cover 1 E20 05-20 12-36 11042018 Leveler 1 E22 05-20 12-36 517935 Spring seat 2 E24 05-20 12-36 8801225 Shim 2 E30 05-20 12-36 11056531 Guide post 2 E40 05-20 12-36 505412 (9003509-0008) Seal nut 2 E50 05-20 12-36 517377 O-ring 1 E60 05-20 12-36 517228 (5000206) Screw 6 E70 05-20 12-36 664524 (9005110-9000) Plug assembly 1 E80 05-20 12-36 334987 Spring 2 E90 05-20 12-36 513888 Insert assembly 1 F20 05-20 12-36 11116313 Slider block (SB-1988-009 on page 300 &
SB-2015-005 on page 360)
Model/Kit
1
Part numbers continue to the next 2 pages.
24 | © Danfoss | February 2022 AX152886482206en-000601
B100
E30
E22
E20
E80
E24
B94
D65
D10
D50
D86
D87
D75
D70
F20
B92
B84
*C70
C40
C50
C30
C20
QC04
C80
C06
B83
QD50
B72
L50
*L25
L70
L60
L40
B70
B80
L10
L20
B50
B50
QB30
*E40
*E60
*E50
E90
E70
E10
D55
D80
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Parts configuration
* Included in base pump seal kit Q210
©
Danfoss | February 2022 AX152886482206en-000601 | 25
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Order code: EEH
Item Date Begin Date End Part Number Part Name Qty. per
L10 05-20 12-36 5000505 Roller bearing 1 L20 05-20 12-36 9006300-0156 Retaining ring 1 L25 05-20 12-36 519671 Seal carrier assembly 1 L40 05-20 12-36 519666 Lip seal (SB-2005-007 on page 348) 1 L50 05-20 12-36 684621 (9004104-1530) O-ring 1 L60 05-20 12-36 516767 Retainer plate 1 L70 05-20 12-36 041160 (9007314-0605) Screw 3 QB30 05-20 12-36 11131108 Cradle bearing assembly 1 QC04 05-20 12-36 8510366 Cylinder block kit, with speed ring 1 QD50 05-20 12-36 11192313 Swashplate assembly (SB-2017-033 on page 361) 1
Model/Kit
26 | © Danfoss | February 2022 AX152886482206en-000601
C80
C06
*C70
C40
C50
C30
C20
QC04
E82
E82
B83
*QB83
C80
C06
*C70
C40
C50
C30
C20
QC04
B83
*QB83
(EFD & EFG)
(EFC, EFI & EFL)
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
S90P 75cc special hardware EFC-EFL
Parts configuration
©
Danfoss | February 2022 AX152886482206en-000601 | 27
Generic speed sensors shown.
* Included in base pump seal kit Q210
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Common parts
Item Date Begin Date End Part Number Part Name Qty. per
C20 87-02 708230 Piston assembly (SB-1988-023 on page 304) 9 C30 87-02 11067350 Slipper guide 1 C40 88-22 334391 (8100294) Slipper guide bearing (SB-1988-016 on page 302) 2 C50 88-22 11065865 Spacer (SB-1988-016 on page 302 & SB-1998-041
on page 332)
C65 88-22 98-47 Obsolete Washer (SB-1988-016 on page 302 & SB-1998-041
on page 332)
C70 88-22 314419 (9007276-0114) Screw (SB-1988-016 on page 302 & SB-1998-041
on page 332)
QB83 98-14 085043 (9004201-3700) O-ring 1
Order code: EFC
B83 94-34 KPPG156 Speed sensor 1 C06 94-34 11094260 (11011714) Cylinder block assembly, with speed ring 1 C80 94-34 518805 Valve plate 1 QC04 94-34 8510366 Cylinder block kit, with speed ring
Model/Kit
4
4
4
Order code: EFD
B83 04-49 12-36 KPPG156 Speed sensor 1 C06 94-34 12-36 11094260 (11011714) Cylinder block assembly, with speed ring 1 C80 04-49 12-36 518008 Valve plate 1 E82 04-49 12-36 360842 Spring 2 QC04 94-34 12-36 8510366 Cylinder block kit, with speed ring
Order code: EFG
B83 04-49 12-36 KPPG156 Speed sensor 1 C06 94-34 12-36 11094260 (11011714) Cylinder block assembly, with speed ring 1 C80 04-49 12-36 518925 Valve plate, CW 1 E82 04-49 12-36 360842 Spring 2 QC04 94-34 12-36 8510366 Cylinder block kit, with speed ring 1
Order code: EFI
B83 04-49 KPPG156 Speed sensor 1 C06 94-34 11094260 (11011714) Cylinder block assembly, with speed ring 1 C80 04-49 518925 Valve plate, CW 1 C80 04-49 518926 Valve plate, CCW 1 QC04 94-34 8510366 Cylinder block kit, with speed ring
Order code: EFL
B83 04-49 12-36 KPPG156 Speed sensor 1 C06 94-34 12-36 11094260 (11011714) Cylinder block assembly, with speed ring 1 C80 04-49 12-36 518007 Valve plate 1 QC04 94-34 12-36 8510366 Cylinder block kit, with speed ring 1
28 | © Danfoss | February 2022 AX152886482206en-000601
B100
E30
E22
E20
E80
E24
B94
D86
D87
B92
B84
*C70
C40
C50
C30
C20
QC04
C80
C06
B72
L50
*L25
L70
L60
L40
B70
B80
L10
L20
B50
B50
*E40
*E60
*E50
E90
E70
E10
B83
*QB83
QB30
D65
D10
D50
D75
D70
F20
QD50
D55
D80
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
S90P 75cc special hardware EFP
Parts configuration
Generic speed sensor shown.
* Included in base pump seal kit Q210
©
Danfoss | February 2022 AX152886482206en-000601 | 29
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Order code: EFP
Item Date Begin Date End Part Number Part Name Qty. per
B50 05-34 9004800-3708 Pin 2 B70 05-34 140644 Plug assembly 1 B72 05-34 140644 Plug assembly 1 B80 05-34 664524 (9005110-9000) Plug assembly 1 B83 05-34 KPPG156 Speed sensor assembly 1 B84 05-34 11040532 Plug assembly 1 B92 05-34 11040532 Plug assembly 1 B94 05-34 11040532 Plug assembly 1 B100 05-34 11117294 Housing assembly 1 C06 05-34 11094260 (11011714) Cylinder block assembly, with speed ring 1 C20 05-34 708230 Piston assembly 9 C30 05-34 11067350 Slipper guide 1 C40 05-34 334391 (8100294) Slipper guide bearing 2 C50 05-34 11065865 Spacer 4 C70 05-34 314419 (9007276-0114) Screw 4 C80 05-34 518925 Valve plate, CW 1 C80 05-34 518926 Valve plate, CCW 1 D10 05-34 519046 Servo arm 1 D50 05-34 11104315 Swashplate 1 D55 05-34 519150 Screw 1 D70 05-34 9009625-0146 Washer 1 D75 05-34 9004875-0098 Spiral head pin 1 D80 05-34 693929 (8100506) Cage locator link 1 D86 05-34 9004800-1908 Pin 1 D87 05-34 11040532 Plug assembly 1 E10 05-34 11001286 Side cover 1 E20 05-34 11042018 Leveler 1 E22 05-34 517935 Spring seat 2 E24 05-34 8801225 Shim 2 E30 05-34 11056531 Guide post 2 E40 05-34 505412 (9003509-0008) Seal nut 2 E50 05-34 517377 O-ring 1 E60 05-34 517228 (5000206) Screw 6 E70 05-34 664524 (9005110-9000) Plug assembly 1 E80 05-34 334987 Spring 2 E90 05-34 513888 Insert assembly 1 F20 05-34 11116313 Slider block (SB-2015-005 on page 360) 1
Model/Kit
Part numbers continue to the next 2 pages.
30 | © Danfoss | February 2022 AX152886482206en-000601
B100
E30
E22
E20
E80
E24
B94
D86 D87
B92
B84
*C70
C40
C50
C30
C20
QC04
C80
C06
B72
L50
*L25
L70
L60
L40
B70
B80
L10
L20
B50
B50
*E40
*E60
*E50
E90
E70
E10
B83
*QB83
QB30
D65
D10
D50
D75
D70
F20
QD50
D55
D80
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Parts configuration
©
Danfoss | February 2022 AX152886482206en-000601 | 31
Generic speed sensor shown.
* Included in base pump seal kit Q210
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Order code: EFP
Item Date Begin Date End Part Number Part Name Qty. per
L10 05-34 5000505 Roller bearing 1 L20 05-34 9006300-0156 Retaining ring 1 L25 05-34 519671 Seal carrier assembly 1 L40 05-34 519666 Lip seal (SB-2005-007 on page 348) 1 L50 05-34 684621 (9004104-1530) O-ring 1 L60 05-34 516767 Retainer plate 1 L70 05-34 041160 (9007314-0605) Screw 3 QB30 05-34 11131108 Cradle bearing assembly 1 QB83 05-34 085043 (9004201-3700) O-ring 1 QC04 05-34 8510366 Cylinder block kit, with speed ring 1 QD50 05-34 11192313 Swashplate assembly (SB-2017-033 on page 361) 1
Model/Kit
32 | © Danfoss | February 2022 AX152886482206en-000601
B100
B94
D86 D87
B92
B84
*C70
C40
C50
C30
C20
QC04
C80
C06
B72
L50
*L25
L70
L60
L40
B70
B80
L10
L20
B50
B50
QB30
*E40
*E60
*E50
E90
E70
E10
E82
E20
E22
E80
E24
E30
B83
*QB83
D65
D10
D50
D75
D70
F20
QD50
D55
D80
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
S90P 75cc special hardware EFR
Parts configuration
Generic speed sensor shown.
* Included in base pump seal kit Q210
©
Danfoss | February 2022 AX152886482206en-000601 | 33
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Order code: EFR
Item Date Begin Date End Part Number Part Name
B50 06-18 9004800-3708 Pin 2 B70 06-18 140644 Plug assembly 1 B72 06-18 140644 Plug assembly 1 B80 06-18 664524 (9005110-9000) Plug assembly 1 B83 06-18 KPPG156 Speed sensor assembly 1 B84 06-18 11040532 Plug assembly 1 B92 06-18 11040532 Plug assembly 1 B94 06-18 11040532 Plug assembly 1 B100 06-18 11117294 Housing assembly 1 C06 06-18 11094260 (11011714) Cylinder block assembly, with speed ring 1 C20 06-18 708230 Piston assembly 9 C30 06-18 11067350 Slipper guide 1 C40 06-18 334391 (8100294) Slipper guide bearing 2 C50 06-18 11065865 Spacer 4 C70 06-18 314419 (9007276-0114) Screw 4 C80 06-18 518008 Valve plate 1 D10 06-18 519046 Servo arm 1 D50 06-18 11104315 Swashplate 1 D55 06-18 519150 Screw 1 D70 06-18 9009625-0146 Washer 1 D75 06-18 9004875-0098 Spiral head pin 1 D80 06-18 693929 (8100506) Cage locator link 1 D86 06-18 9004800-1908 Pin 1 D87 06-18 11040532 Plug assembly 1 E10 06-18 11001286 Side cover 1 E20 06-18 11042018 Leveler 1 E22 06-18 517935 Spring seat 2 E24 06-18 8801225 Shim 2 E30 06-18 11056531 Guide post 2 E40 06-18 505412 (9003509-0008) Seal nut 2 E50 06-18 517377 O-ring 1 E60 06-18 517228 (5000206) Screw 6 E70 06-18 664524 (9005110-9000) Plug assembly 1 E80 06-18 334987 Spring 2 E82 06-18 360842 Spring 2 E90 06-18 513888 Insert assembly 1 F20 06-18 11116313 Slider block (SB-2015-005 on page 360) 1
Qty. per Model/Kit
Part numbers continue to the next 2 pages.
34 | © Danfoss | February 2022 AX152886482206en-000601
B100
B94
D86 D87
B92
B84
*C70
C40
C50
C30
C20
QC04
C80
C06
B72
L50
*L25
L70
L60
L40
B70
B80
L10
L20
B50
B50
QB30
*E40
*E60
*E50
E90
E70
E10
E82
E20
E22
E80
E24
E30
B83
*QB83
D65
D10
D50
D75
D70
F20
QD50
D55
D80
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Parts configuration
Generic speed sensor shown.
©
Danfoss | February 2022 AX152886482206en-000601 | 35
* Included in base pump seal kit Q210
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Order code: EFR
Item Date Begin Date End Part Number Part Name Qty. per
L10 06-18 5000505 Roller bearing 1 L20 06-18 9006300-0156 Retaining ring 1 L25 06-18 519671 Seal carrier assembly 1 L40 06-18 519666 Lip seal (SB-2005-007 on page 348) 1 L50 06-18 684621 (9004104-1530) O-ring 1 L60 06-18 516767 Retainer plate 1 L70 06-18 041160 (9007314-0605) Screw 3 QB30 06-18 11131108 Cradle bearing assembly 1 QB83 06-18 085043 (9004201-3700) O-ring 1 QC04 06-18 8510366 Cylinder block kit, with speed ring 1 QD50 06-18 11192313 Swashplate assembly (SB-2017-033 on page 361) 1
Model/Kit
36 | © Danfoss | February 2022 AX152886482206en-000601
C80
C06
*C70
C40
C50
C30
C20
QC04
E82
E82
B83
*QB83
C80
C06
*C70
C40
C50
C30
C20
QC04
B83
*QB83
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
S90P 75cc special hardware EAA-EKB
Parts configuration
©
Danfoss | February 2022 AX152886482206en-000601 | 37
Generic speed sensors shown.
* Included in base pump seal kit Q210
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Common parts
Item Date Begin Date End Part Number Part Name Qty. per
C20 87-02 708230 Piston assembly 9 C30 87-02 11067350 Slipper guide 1 C40 88-22 334391 (8100294) Slipper guide bearing 2 C50 88-22 11065865 Spacer 4 C70 88-22 314419 (9007276-0114) Screw 4 QB83 98-14 085043 (9004201-3700) O-ring 1
Order code: EHA
B83 00-42 KPPG16408 Speed sensor 1 C06 00-42 11094260 (11011714) Cylinder block assembly, with speed ring 1 C80 00-42 518805 Valve plate 1 QC04 00-42 8510366 Cylinder block kit, with speed ring 1
Model/Kit
Order code: EKA
B83 99-31 KPPG16719 Speed sensor 1 C06 99-31 11094260 (11011714) Cylinder block assembly, with speed ring 1 C80 99-31 518805 Valve plate 1 QC04 99-31 8510366 Cylinder block kit, with speed ring 1
Order code: EKB
B83 01-13 12-36 KPPG156 Speed sensor 1 C06 01-13 12-36 11094260 (11011714) Cylinder block assembly, with speed ring 1 C80 01-13 12-36 518925 Valve plate, CW 1 E82 01-13 12-36 360842 Spring 2 QC04 01-13 12-36 8510366 Cylinder block kit, with speed ring 1
38 | © Danfoss | February 2022 AX152886482206en-000601
B100
E30
E22
E20
E80
E24
B94
D86 D87
B92
B84
*C70
C40
C50
C30
C20
QC04
C80
C06
B72
L50
*L25
L70
L60
L40
B70
B80
L10
L20
B50
B50
*E40
*E60
*E50
E90
E70
E10
B83
*QB83
QB30
D65
D10
D50
D75
D70
F20
QD50
D55
D80
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
S90P 75cc special hardware ELA
Parts configuration
Generic speed sensor shown.
* Included in base pump seal kit Q210
©
Danfoss | February 2022 AX152886482206en-000601 | 39
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Order code: ELA
Item Date Begin Date End Part Number Part Name Qty. per
B50 01-03 9004800-3708 Pin 2 B70 01-03 140644 Plug assembly 1 B72 01-03 140644 Plug assembly 1 B80 01-03 664524 (9005110-9000) Plug assembly 1 B83 01-03 KPPG13403 Speed sensor assembly 1 B84 01-03 11040532 Plug assembly 1 B92 01-03 11040532 Plug assembly 1 B94 01-03 11040532 Plug assembly 1 B100 01-03 11117294 Housing assembly 1 C06 01-03 11094260 (11011714) Cylinder block assembly, with speed ring 1 C20 01-03 708230 Piston assembly 9 C30 01-03 11067350 Slipper guide 1 C40 01-03 334391 (8100294) Slipper guide bearing 2 C50 01-03 11065865 Spacer 4 C70 01-03 314419 (9007276-0114) Screw 4 C80 01-03 518008 Valve plate 1 D10 01-03 519046 Servo arm 1 D50 01-03 11104315 Swashplate 1 D55 01-03 519150 Screw 1 D70 01-03 9009625-0146 Washer 1 D75 01-03 9004875-0098 Spiral head pin 1 D80 01-03 693929 (8100506) Cage locator link 1 D86 01-03 9004800-1908 Pin 1 D87 01-03 11040532 Plug assembly 1 E10 01-03 11001286 Side cover 1 E20 01-03 11042018 Leveler 1 E22 01-03 517935 Spring seat 2 E24 01-03 8801225 Shim 2 E30 01-03 11056531 Guide post 2 E40 01-03 505412 (9003509-0008) Seal nut 2 E50 01-03 517377 O-ring 1 E60 01-03 517228 (5000206) Screw 6 E70 01-03 664524 (9005110-9000) Plug assembly 1 E80 01-03 334987 Spring 2 E90 01-03 513888 Insert assembly 1 F20 01-03 11116313 Slider block 1
Model/Kit
Part numbers continue to the next 2 pages.
40 | © Danfoss | February 2022 AX152886482206en-000601
B100
E30
E22
E20
E80
E24
B94
D86 D87
B92
B84
*C70
C40
C50
C30
C20
QC04
C80
C06
B72
L50
*L25
L70
L60
L40
B70
B80
L10
L20
B50
B50
*E40
*E60
*E50
E90
E70
E10
B83
*QB83
QB30
D65
D10
D50
D75
D70
F20
QD50
D55
D80
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Parts configuration
©
Danfoss | February 2022 AX152886482206en-000601 | 41
Generic speed sensor shown.
* Included in base pump seal kit Q210
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Order code: ELA
Item Date Begin Date End Part Number Part Name Qty. per
L10 01-03 5000505 Roller bearing 1 L20 01-03 9006300-0156 Retaining ring 1 L25 01-03 519671 Seal carrier assembly 1 L40 01-03 519666 Lip seal (SB-2005-007 on page 348) 1 L50 01-03 684621 (9004104-1530) O-ring 1 L60 01-03 516767 Retainer plate 1 L70 01-03 041160 (9007314-0605) Screw 3 QB30 01-03 11131108 Cradle bearing assembly 1 QB83 01-03 085043 (9004201-3700) O-ring 1 QC04 01-03 8510366 Cylinder block kit, with speed ring 1 QD50 01-03 11192313 Swashplate assembly (SB-2017-033 on page 361) 1
Model/Kit
42 | © Danfoss | February 2022 AX152886482206en-000601
B100
E30
E22
E20
E80
E24
B94
D86 D87
B92
B84
*C70
C40
C50
C30
C20
QC04
C80
C06
B72
L50
*L25
L70
L60
L40
B70
B80
L10
L20
B50
B50
*E40
*E60
*E50
E90
E70
E10
B83
*QB83
QB30
D65
D10
D50
D75
D70
F20
QD50
D55
D80
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
S90P 75cc special hardware ELB
Parts configuration
Generic speed sensor shown.
* Included in base pump seal kit Q210
©
Danfoss | February 2022 AX152886482206en-000601 | 43
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Order code: ELB
Item Date Begin Date End Part Number Part Name Qty. per
B50 04-03 9004800-3708 Pin 2 B70 04-03 140644 Plug assembly 1 B72 04-03 140644 Plug assembly 1 B80 04-03 664524 (9005110-9000) Plug assembly 1 B83 04-03 KPPG13403 Speed sensor assembly 1 B84 04-03 11040532 Plug assembly 1 B92 04-03 11040532 Plug assembly 1 B94 04-03 11040532 Plug assembly 1 B100 04-03 11117294 Housing assembly 1 C06 04-03 11094260 (11011714) Cylinder block assembly, with speed ring 1 C20 04-03 708230 Piston assembly 9 C30 04-03 11067350 Slipper guide 1 C40 04-03 334391 (8100294) Slipper guide bearing 2 C50 04-03 11065865 Spacer 4 C70 04-03 314419 (9007276-0114) Screw 4 C80 04-03 518925 Valve plate, CW 1 D10 04-03 519046 Servo arm 1 D50 04-03 11104315 Swashplate 1 D55 04-03 519150 Screw 1 D70 04-03 9009625-0146 Washer 1 D75 04-03 9004875-0098 Spiral head pin 1 D80 04-03 693929 (8100506) Cage locator link 1 D86 04-03 9004800-1908 Pin 1 D87 04-03 11040532 Plug assembly 1 E10 04-03 11001286 Side cover 1 E20 04-03 11042018 Leveler 1 E22 04-03 517935 Spring seat 2 E24 04-03 8801225 Shim 2 E30 04-03 11056531 Guide post 2 E40 04-03 505412 (9003509-0008) Seal nut 2 E50 04-03 517377 O-ring 1 E60 04-03 517228 (5000206) Screw 6 E70 04-03 664524 (9005110-9000) Plug assembly 1 E80 04-03 334987 Spring 2 E90 04-03 513888 Insert assembly 1 F20 04-03 11116313 Slider block 1
Model/Kit
Part numbers continue to the next 2 pages.
44 | © Danfoss | February 2022 AX152886482206en-000601
B100
E30
E22
E20
E80
E24
B94
D86 D87
B92
B84
*C70
C40
C50
C30
C20
QC04
C80
C06
B72
L50
*L25
L70
L60
L40
B70
B80
L10
L20
B50
B50
*E40
*E60
*E50
E90
E70
E10
B83
*QB83
QB30
D65
D10
D50
D75
D70
F20
QD50
D55
D80
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Parts configuration
©
Danfoss | February 2022 AX152886482206en-000601 | 45
Generic speed sensor shown.
* Included in base pump seal kit Q210
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Order code: ELB
Item Date Begin Date End Part Number Part Name Qty. per
L10 04-03 5000505 Roller bearing 1 L20 04-03 9006300-0156 Retaining ring 1 L25 04-03 519671 Seal carrier assembly 1 L40 04-03 519666 Lip seal (SB-2005-007 on page 348) 1 L50 04-03 684621 (9004104-1530) O-ring 1 L60 04-03 516767 Retainer plate 1 L70 04-03 041160 (9007314-0605) Screw 3 QB30 04-03 11131108 Cradle bearing assembly 1 QB83 04-03 085043 (9004201-3700) O-ring 1 QC04 04-03 8510366 Cylinder block kit, with speed ring 1 QD50 04-03 11192313 Swashplate assembly (SB-2017-033 on page 361) 1
Model/Kit
46 | © Danfoss | February 2022 AX152886482206en-000601
B100
E30
E22
E20
E80
E24
B94
D86 D87
B92
B84
*C70
C40
C50
C30
C20
QC04
C80
C06
B72
L50
*L25
L70
L60
L40
B70
B80
L10
L20
B50
B50
*E40
*E60
*E50
E90
E70
E10
B83
*QB83
QB30
D65
D10
D50
D75
D70
F20
QD50
D55
D80
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
S90P 75cc special hardware ELC
Parts configuration
Generic speed sensor shown.
* Included in base pump seal kit Q210
©
Danfoss | February 2022 AX152886482206en-000601 | 47
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Order code: ELC
Item Date Begin Date End Part Number Part Name Qty. per
B50 04-18 9004800-3708 Pin 2 B70 04-18 140644 Plug assembly 1 B72 04-18 140644 Plug assembly 1 B80 04-18 664524 (9005110-9000) Plug assembly 1 B83 04-18 KPPG15408 Speed sensor assembly 1 B84 04-18 11040532 Plug assembly 1 B92 04-18 11040532 Plug assembly 1 B94 04-18 11040532 Plug assembly 1 B100 04-18 11117294 Housing assembly 1 C06 04-18 11094260 (11011714) Cylinder block assembly, with speed ring 1 C20 04-18 708230 Piston assembly 9 C30 04-18 11067350 Slipper guide 1 C40 04-18 334391 (8100294) Slipper guide bearing 2 C50 04-18 11065865 Spacer 4 C70 04-18 314419 (9007276-0114) Screw 4 C80 04-18 518925 Valve plate, CW 1 D10 04-18 519046 Servo arm 1 D50 04-18 11104315 Swashplate 1 D55 04-18 519150 Screw 1 D70 04-18 9009625-0146 Washer 1 D75 04-18 9004875-0098 Spiral head pin 1 D80 04-18 693929 (8100506) Cage locator link 1 D86 04-18 9004800-1908 Pin 1 D87 04-18 11040532 Plug assembly 1 E10 04-18 11001286 Side cover 1 E20 04-18 11042018 Leveler 1 E22 04-18 517935 Spring seat 2 E24 04-18 8801225 Shim 2 E30 04-18 11056531 Guide post 2 E40 04-18 505412 (9003509-0008) Seal nut 2 E50 04-18 517377 O-ring 1 E60 04-18 517228 (5000206) Screw 6 E70 04-18 664524 (9005110-9000) Plug assembly 1 E80 04-18 334987 Spring 2 E90 04-18 513888 Insert assembly 1 F20 04-18 11116313 Slider block 1
Model/Kit
Part numbers continue to the next 2 pages.
48 | © Danfoss | February 2022 AX152886482206en-000601
B100
E30
E22
E20
E80
E24
B94
D86 D87
B92
B84
*C70
C40
C50
C30
C20
QC04
C80
C06
B72
L50
*L25
L70
L60
L40
B70
B80
L10
L20
B50
B50
*E40
*E60
*E50
E90
E70
E10
B83
*QB83
QB30
D65
D10
D50
D75
D70
F20
QD50
D55
D80
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Parts configuration
©
Danfoss | February 2022 AX152886482206en-000601 | 49
Generic speed sensor shown.
* Included in base pump seal kit Q210
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Order code: ELC
Item Date Begin Date End Part Number Part Name Qty. per
L10 04-18 5000505 Roller bearing 1 L20 04-18 9006300-0156 Retaining ring 1 L25 04-18 519671 Seal carrier assembly 1 L40 04-18 519666 Lip seal (SB-2005-007 on page 348) 1 L50 04-18 684621 (9004104-1530) O-ring 1 L60 04-18 516767 Retainer plate 1 L70 04-18 041160 (9007314-0605) Screw 3 QB30 04-18 11131108 Cradle bearing assembly 1 QB83 04-18 085043 (9004201-3700) O-ring 1 QC04 04-18 8510366 Cylinder block kit, with speed ring 1 QD50 04-18 11192313 Swashplate assembly (SB-2017-033 on page 361) 1
Model/Kit
50 | © Danfoss | February 2022 AX152886482206en-000601
C80
*C70
C40
C50
C30
C20
QC04
E82
E82
B83
C05
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
S90P 75cc special hardware FAA-FAK
Parts configuration
* Included in base pump seal kit Q210
©
Danfoss | February 2022 AX152886482206en-000601 | 51
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Common parts
Item Date Begin Date End Part Number Part Name Qty. per
C20 87-02 708230 Piston assembly 9 C30 87-02 11067350 Slipper guide 1 C40 88-22 334391 (8100294) Slipper guide bearing 2 C50 88-22 11065865 Spacer 4 C70 88-22 314419 (9007276-0114) Screw 4
Order code: FAA
B83 94-14 140644 Plug assembly 1 C05 94-14 519253 (11025822) Cylinder block assembly 1 C80 94-14 518924 Valve plate 1 E82 94-14 360842 (11062703) Spring 2 QC04 94-14 8510365 Cylinder block kit 1
Model/Kit
Order code: FAB
B83 94-14 140644 Plug assembly 1 C05 94-14 519253 (11025822) Cylinder block assembly 1 C80 94-14 518923 Valve plate 1 E82 94-14 360842 (11062703) Spring 2 QC04 94-14 8510365 Cylinder block kit 1
Order code: FAC
B83 94-14 140644 Plug assembly 1 C05 94-14 519253 (11025822) Cylinder block assembly 1 C80 94-14 518008 Valve plate 1 E82 94-14 360842 (11062703) Spring 2 QC04 94-14 8510365 Cylinder block kit 1
Order code: FAD
B83 96-05 140644 Plug assembly 1 C05 96-05 519253 (11025822) Cylinder block assembly 1 C80 96-05 518805 Valve plate 1 E82 96-05 360842 (11062703) Spring 2 QC04 96-05 8510365 Cylinder block kit 1
Order code: FAK
B83 98-51 140644 Plug assembly 1 C05 98-51 519253 (11025822) Cylinder block assembly 1 C80 98-51 518805 Valve plate 1 E82 98-51 360842 (11062703) Spring 2 QC04 98-51 8510365 Cylinder block kit 1
52 | © Danfoss | February 2022 AX152886482206en-000601
C80
*C70
C40
C50
C30
C20
QC04
E82
E82
B83
C05
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
S90P 75cc special hardware FAL, FAN
Parts configuration
* Included in base pump seal kit Q210
©
Danfoss | February 2022 AX152886482206en-000601 | 53
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Common parts
Item Date Begin Date End Part Number Part Name Qty. per
C20 87-02 708230 Piston assembly 9 C30 87-02 11067350 Slipper guide 1 C40 88-22 334391 (8100294) Slipper guide bearing 2 C50 88-22 11065865 Spacer 4 C70 88-22 314419 (9007276-0114) Screw 4
Order code: FAL
B83 94-14 140644 Plug assembly 1 C05 94-14 519253 (11025822) Cylinder block assembly 1 C80 94-14 518923 Valve plate 1 E82 94-14 360842 (11062703) Spring 2 QC04 94-14 8510365 Cylinder block kit 1
Model/Kit
Order code: FAN
B83 13-41 140644 Plug assembly 1 C05 13-41 519253 (11025822) Cylinder block assembly 1 C80 13-41 518924 Valve plate 1 E82 13-41 360842 (11062703) Spring 2 QC04 13-41 8510365 Cylinder block kit 1
54 | © Danfoss | February 2022 AX152886482206en-000601
C80
*C70
C40
C50
C30
C20
QC04
E82
E82
B83
C05
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
S90P 75cc special hardware FAP-FAU
Parts configuration
* Included in base pump seal kit Q210
©
Danfoss | February 2022 AX152886482206en-000601 | 55
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Common parts
Item Date Begin Date End Part Number Part Name Qty. per
C20 87-02 708230 Piston assembly 9 C30 87-02 11067350 Slipper guide 1 C40 88-22 334391 (8100294) Slipper guide bearing 2 C50 88-22 11065865 Spacer 4 C70 88-22 314419 (9007276-0114) Screw 4
Order code: FAP
B83 94-14 140644 Plug assembly 1 C05 94-14 519253 (11025822) Cylinder block assembly 1 C80 94-14 518925 Valve plate, CW 1 C80 94-14 518926 Valve plate, CCW 1 E82 94-14 360842 (11062703) Spring 2 QC04 94-14 8510365 Cylinder block kit 1
Model/Kit
Order code: FAQ
B83 94-14 140644 Plug assembly 1 C05 94-14 519253 (11025822) Cylinder block assembly 1 C80 94-14 518925 Valve plate, CW 1 E82 94-14 360842 (11062703) Spring 2 QC04 94-14 8510365 Cylinder block kit 1
Order code: FAR
B83 94-14 140644 Plug assembly 1 C05 94-14 519253 (11025822) Cylinder block assembly 1 C80 94-14 510723 Valve plate 1 E82 94-14 360842 (11062703) Spring 2 QC04 94-14 8510365 Cylinder block kit 1
Order code: FAS
B83 97-03 140644 Plug assembly 1 C05 97-03 519253 (11025822) Cylinder block assembly 1 C80 97-03 518008 Valve plate 1 E82 97-03 360842 (11062703) Spring 2 QC04 97-03 8510365 Cylinder block kit 1
Order code: FAU
B83 98-37 140644 Plug assembly 1 C05 98-37 519253 (11025822) Cylinder block assembly 1 C80 98-37 518805 Valve plate 1 E82 98-37 360842 (11062703) Spring 2 QC04 98-37 8510365 Cylinder block kit 1
56 | © Danfoss | February 2022 AX152886482206en-000601
C80
*C70
C40
C50
C30
C20
QC04
E82
E82
B83
C05
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
S90P 75cc special hardware FAX, FAY
Parts configuration
* Included in base pump seal kit Q210
©
Danfoss | February 2022 AX152886482206en-000601 | 57
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Common parts
Item Date Begin Date End Part Number Part Name Qty. per
C20 87-02 708230 Piston assembly 9 C30 87-02 11067350 Slipper guide 1 C40 88-22 334391 (8100294) Slipper guide bearing 2 C50 88-22 11065865 Spacer 4 C70 88-22 314419 (9007276-0114) Screw 4
Order code: FAX
B83 01-07 140644 Plug assembly 1 C05 01-07 519253 (11025822) Cylinder block assembly 1 C80 01-07 510723 Valve plate 1 E82 01-07 360842 (11062703) Spring 2 QC04 01-07 8510365 Cylinder block kit 1
Model/Kit
Order code: FAY
B83 06-03 140644 Plug assembly 1 C05 06-03 519253 (11025822) Cylinder block assembly 1 C80 06-03 518805 Valve plate 1 E82 06-03 360842 (11062703) Spring 2 QC04 06-03 8510365 Cylinder block kit 1
58 | © Danfoss | February 2022 AX152886482206en-000601
C80
*C70
C40
C50
C30
C20
QC04
E82
E82
B83
C05
C80
*C70
C40
C50
C30
C20
QC04
E82
E82
B83
C05
W1CN
W3CN
B2CN
(FAZ)
(FAY, FBA, FBC, FCF & FHP)
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
S90P 75cc special hardware FAZ-FBG
Parts configuration
©
Danfoss | February 2022 AX152886482206en-000601 | 59
* Included in base pump seal kit Q210
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Common parts
Item Date Begin Date End Part Number Part Name Qty. per
C20 87-02 708230 Piston assembly 9 C30 87-02 11067350 Slipper guide 1 C40 88-22 334391 (8100294) Slipper guide bearing 2 C50 88-22 11065865 Spacer 4 C70 88-22 314419 (9007276-0114) Screw 4
Order code: FAZ
B2CN 05-06 775312 Set screw 1 B83 05-06 140644 Plug assembly 1 C05 05-06 519253 (11025822) Cylinder block assembly 1 C80 05-06 518008 Valve plate 1 E82 05-06 360842 (11062703) Spring 2 QC04 05-06 8510365 Cylinder block kit 1 W1CN 05-06 723726 Connector 1 W3CN 05-06 574095 Cap 1
Model/Kit
Order code: FBA
B83 06-12 140644 Plug assembly 1 C05 06-12 519253 (11025822) Cylinder block assembly 1 C80 06-12 518008 Valve plate 1 E82 06-12 360842 (11062703) Spring 2 QC04 06-12 8510365 Cylinder block kit 1
Order code: FBC
B83 06-12 140644 Plug assembly 1 C05 06-12 519253 (11025822) Cylinder block assembly 1 C80 06-12 518805 Valve plate 1 E82 06-12 360842 (11062703) Spring 2 QC04 06-12 8510365 Cylinder block kit 1
Order code: FBG
B83 06-16 140644 Plug assembly 1 C05 06-16 519253 (11025822) Cylinder block assembly 1 C80 06-16 518805 Valve plate 1 E82 06-16 360842 (11062703) Spring 2 QC04 06-16 8510365 Cylinder block kit 1
60 | © Danfoss | February 2022 AX152886482206en-000601
C80
*C70
C40
C50
C30
C20
QC04
E82
E82
B83
C05
C80
*C70
C40
C50
C30
C20
QC04
E82
E82
B83
C05
W1CN
W3CN
B2CN
(FAZ)
(FAY, FBA, FBC, FCF & FHP)
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
S90P 75cc special hardware FCF, FHP
Parts configuration
©
Danfoss | February 2022 AX152886482206en-000601 | 61
* Included in base pump seal kit Q210
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Common parts
Item Date Begin Date End Part Number Part Name Qty. per
C20 87-02 708230 Piston assembly 9 C30 87-02 11067350 Slipper guide 1 C40 88-22 334391 (8100294) Slipper guide bearing 2 C50 88-22 11065865 Spacer 4 C70 88-22 314419 (9007276-0114) Screw 4
Order code: FCF
B83 11-19 140644 Plug assembly 1 C05 11-19 519253 (11025822) Cylinder block assembly 1 C80 11-19 518805 Valve plate 1 E82 11-19 360842 (11062703) Spring 2 QC04 11-19 8510365 Cylinder block kit 1
Model/Kit
Order code: FHP
B83 12-40 140644 Plug assembly 1 C05 12-40 519253 (11025822) Cylinder block assembly 1 C80 12-40 518805 Valve plate 1 E82 12-40 360842 (11062703) Spring 2 QC04 12-40 8510365 Cylinder block kit 1
62 | © Danfoss | February 2022 AX152886482206en-000601
B83
C80
*C70
C40
C50
C30
C20
QC04
C05
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
S90P 75cc special hardware GAA-GBT
Parts configuration
* Included in base pump seal kit Q210
©
Danfoss | February 2022 AX152886482206en-000601 | 63
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Common parts
Item Date Begin Date End Part Number Part Name Qty. per
C20 87-02 708230 Piston assembly 9 C30 87-02 11067350 Slipper guide 1 C40 88-22 334391 (8100294) Slipper guide bearing 2 C50 88-22 11065865 Spacer 4 C70 88-22 314419 (9007276-0114) Screw 4
Order code: GAA
B83 94-14 140644 Plug assembly 1 C05 94-14 519253 (11025822) Cylinder block assembly 1 C80 94-14 344911 Valve plate 1 QC04 94-14 8510365 Cylinder block kit 1
Order code: GBA
B83 87-02 140644 Plug assembly 1 C05 87-02 519253 (11025822) Cylinder block assembly 1 C80 87-02 518805 Valve plate 1 QC04 87-02 8510365 Cylinder block kit 1
Model/Kit
Order code: GBE
B83 98-06 140644 Plug assembly 1 C05 98-06 519253 (11025822) Cylinder block assembly 1 C80 98-06 518805 Valve plate 1 QC04 98-06 8510365 Cylinder block kit 1
Order code: GBJ
B83 98-06 140644 Plug assembly 1 C05 98-06 519253 (11025822) Cylinder block assembly 1 C80 98-06 518805 Valve plate 1 QC04 98-06 8510365 Cylinder block kit 1
Order code: GBS
B83 98-06 140644 Plug assembly 1 C05 98-06 519253 (11025822) Cylinder block assembly 1 C80 98-06 518805 Valve plate 1 QC04 98-06 8510365 Cylinder block kit 1
Order code: GBT
B83 98-02 140644 Plug assembly 1 C05 98-02 519253 (11025822) Cylinder block assembly 1 C80 98-02 518805 Valve plate 1 QC04 98-02 8510365 Cylinder block kit 1
64 | © Danfoss | February 2022 AX152886482206en-000601
B100
E30
E22
E20
E80
E24
B94
D86
D87
B92
B84
*C70
C40
C50
C30
C20
QC04
C80
B72
L50
*L25
L70
L60
L40
B70
B80
L10
L20
B50
B50
QB30
*E40
*E60
*E50
E90
E70
E10
B83
C05
D65
D10
D50
D75
D70
F20
QD50
D55
D80
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
S90P 75cc special hardware GBU
Parts configuration
* Included in base pump seal kit Q210
©
Danfoss | February 2022 AX152886482206en-000601 | 65
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Order code: GBU
Item Date Begin Date End Part Number Part Name Qty. per
B50 06-18 9004800-3708 Pin 2 B70 06-18 140644 Plug assembly 1 B72 06-18 140644 Plug assembly 1 B80 06-18 664524 (9005110-9000) Plug assembly 1 B83 06-18 140644 Plug assembly 1 B84 06-18 11040532 Plug assembly 1 B92 06-18 11040532 Plug assembly 1 B94 06-18 11040532 Plug assembly 1 B100 06-18 11117294 Housing assembly 1 C05 06-18 519253 (11025822) Cylinder block assembly 1 C20 06-18 708230 Piston assembly 9 C30 06-18 11067350 Slipper guide 1 C40 06-18 334391 (8100294) Slipper guide bearing 2 C50 06-18 11065865 Spacer 4 C70 06-18 314419 (9007276-0114) Screw 4 C80 06-18 518805 Valve plate 1 D10 06-18 519046 Servo arm 1 D50 06-18 11104315 Swashplate 1 D55 06-18 519150 Screw 1 D70 06-18 9009625-0146 Washer 1 D75 06-18 9004875-0098 Spiral head pin 1 D80 06-18 693929 (8100506) Cage locator link 1 D86 06-18 9004800-1908 Pin 1 D87 06-18 11040532 Plug assembly 1 E10 06-18 11001286 Side cover 1 E20 06-18 11042018 Leveler 1 E22 06-18 517935 Spring seat 2 E24 06-18 8801225 Shim 2 E30 06-18 11056531 Guide post 2 E40 06-18 505412 (9003509-0008) Seal nut 2 E50 06-18 517377 O-ring 1 E60 06-18 517228 (5000206) Screw 6 E70 06-18 664524 (9005110-9000) Plug assembly 1 E80 06-18 334987 Spring 2 E90 06-18 513888 Insert assembly 1 F20 06-18 11116313 Slider block 1
Model/Kit
Part numbers continue to the next 2 pages.
66 | © Danfoss | February 2022 AX152886482206en-000601
B100
E30
E22
E20
E80
E24
B94
D86
D87
B92
B84
*C70
C40
C50
C30
C20
QC04
C80
B72
L50
*L25
L70
L60
L40
B70
B80
L10
L20
B50
B50
QB30
*E40
*E60
*E50
E90
E70
E10
B83
C05
D65
D10
D50
D75
D70
F20
QD50
D55
D80
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Parts configuration
* Included in base pump seal kit Q210
©
Danfoss | February 2022 AX152886482206en-000601 | 67
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Order code: GBU
Item Date Begin Date End Part Number Part Name Qty. per
L10 06-18 5000505 Roller bearing 1 L20 06-18 9006300-0156 Retaining ring 1 L25 06-18 519671 Seal carrier assembly 1 L40 06-18 519666 Lip seal (SB-2005-007 on page 348) 1 L50 06-18 684621 (9004104-1530) O-ring 1 L60 06-18 516767 Retainer plate 1 L70 06-18 041160 (9007314-0605) Screw 3 QB30 06-18 11131108 Cradle bearing assembly 1 QC04 06-18 8510365 Cylinder block kit 1 QD50 06-18 11192313 Swashplate assembly (SB-2017-033 on page 361) 1
Model/Kit
68 | © Danfoss | February 2022 AX152886482206en-000601
B83
C80
*C70
C40
C50
C30
C20
QC04
C05
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
S90P 75cc special hardware GBX-GCP
Parts configuration
* Included in base pump seal kit Q210
©
Danfoss | February 2022 AX152886482206en-000601 | 69
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Common parts
Item Date Begin Date End Part Number Part Name Qty. per
C20 87-02 708230 Piston assembly 9 C30 87-02 11067350 Slipper guide 1 C40 88-22 334391 (8100294) Slipper guide bearing 2 C50 88-22 11065865 Spacer 4 C70 88-22 314419 (9007276-0114) Screw 4
Order code: GBX
B83 08-42 140644 Plug assembly 1 C05 08-42 519253 (11025822) Cylinder block assembly 1 C80 08-42 518805 Valve plate 1 QC04 08-42 8510365 Cylinder block kit 1
Order code: GCA
B83 98-14 140644 Plug assembly 1 C05 98-14 519253 (11025822) Cylinder block assembly 1 C80 98-14 518008 Valve plate 1 QC04 98-14 8510365 Cylinder block kit 1
Model/Kit
Order code: GCB
B83 98-14 140644 Plug assembly 1 C05 98-14 519253 (11025822) Cylinder block assembly 1 C80 98-14 518008 Valve plate 1 QC04 98-14 8510365 Cylinder block kit 1
Order code: GCC
B83 98-06 140644 Plug assembly 1 C05 98-06 519253 (11025822) Cylinder block assembly 1 C80 98-06 518008 Valve plate 1 QC04 98-06 8510365 Cylinder block kit 1
Order code: GCJ
B83 14-20 140644 Plug assembly 1 C05 14-20 519253 (11025822) Cylinder block assembly 1 C80 14-20 518805 Valve plate 1 QC04 14-20 8510365 Cylinder block kit 1
Order code: GCP
B83 98-06 140644 Plug assembly 1 C05 98-06 519253 (11025822) Cylinder block assembly 1 C80 98-06 518008 Valve plate 1 QC04 98-06 8510365 Cylinder block kit 1
70 | © Danfoss | February 2022 AX152886482206en-000601
B83
C80
*C70
C40
C50
C30
C20
QC04
C05
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
S90P 75cc special hardware GCR-GCU
Parts configuration
* Included in base pump seal kit Q210
©
Danfoss | February 2022 AX152886482206en-000601 | 71
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Common parts
Item Date Begin Date End Part Number Part Name Qty. per
C20 87-02 708230 Piston assembly 9 C30 87-02 11067350 Slipper guide 1 C40 88-22 334391 (8100294) Slipper guide bearing 2 C50 88-22 11065865 Spacer 4 C70 88-22 314419 (9007276-0114) Screw 4
Order code: GCR
B83 98-06 140644 Plug assembly 1 C05 98-06 519253 (11025822) Cylinder block assembly 1 C80 98-06 518805 Valve plate 1 QC04 98-06 8510365 Cylinder block kit 1
Order code: GCS
B83 98-06 140644 Plug assembly 1 C05 98-06 519253 (11025822) Cylinder block assembly 1 C80 98-06 518008 Valve plate 1 QC04 98-06 8510365 Cylinder block kit 1
Model/Kit
Order code: GCU
B83 98-06 140644 Plug assembly 1 C05 98-06 519253 (11025822) Cylinder block assembly 1 C80 98-06 518008 Valve plate 1 QC04 98-06 8510365 Cylinder block kit 1
72 | © Danfoss | February 2022 AX152886482206en-000601
B83
C80
*C70
C40
C50
C30
C20
QC04
C05
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
S90P 75cc special hardware GDE-GFP
Parts configuration
* Included in base pump seal kit Q210
©
Danfoss | February 2022 AX152886482206en-000601 | 73
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Common parts
Item Date Begin Date End Part Number Part Name Qty. per
C20 87-02 708230 Piston assembly 9 C30 87-02 11067350 Slipper guide 1 C40 88-22 334391 (8100294) Slipper guide bearing 2 C50 88-22 11065865 Spacer 4 C70 88-22 314419 (9007276-0114) Screw 4
Order code: GDE
B83 06-12 140644 Plug assembly 1 C05 06-12 519253 (11025822) Cylinder block assembly 1 C80 06-12 518805 Valve plate 1 QC04 06-12 8510365 Cylinder block kit 1
Order code: GFD
B83 06-12 140644 Plug assembly 1 C05 06-12 519253 (11025822) Cylinder block assembly 1 C80 06-12 518805 Valve plate 1 QC04 06-12 8510365 Cylinder block kit 1
Model/Kit
Order code: GFH
B83 06-12 140644 Plug assembly 1 C05 06-12 519253 (11025822) Cylinder block assembly 1 C80 06-12 518805 Valve plate 1 QC04 06-12 8510365 Cylinder block kit 1
Order code: GFJ
B83 06-12 140644 Plug assembly 1 C05 06-12 519253 (11025822) Cylinder block assembly 1 C80 06-12 518805 Valve plate 1 QC04 06-12 8510365 Cylinder block kit 1
Order code: GFK
B83 06-12 140644 Plug assembly 1 C05 06-12 519253 (11025822) Cylinder block assembly 1 C80 06-12 518805 Valve plate 1 QC04 06-12 8510365 Cylinder block kit 1
Order code: GFP
B83 06-12 140644 Plug assembly 1 C05 06-12 519253 (11025822) Cylinder block assembly 1 C80 06-12 518925 Valve plate, CW 1 QC04 06-12 8510365 Cylinder block kit 1
74 | © Danfoss | February 2022 AX152886482206en-000601
B83
C80
*C70
C40
C50
C30
C20
QC04
C05
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
S90P 75cc special hardware GFS-GFZ
Parts configuration
* Included in base pump seal kit Q210
©
Danfoss | February 2022 AX152886482206en-000601 | 75
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Common parts
Item Date Begin Date End Part Number Part Name Qty. per
C20 87-02 708230 Piston assembly 9 C30 87-02 11067350 Slipper guide 1 C40 88-22 334391 (8100294) Slipper guide bearing 2 C50 88-22 11065865 Spacer 4 C70 88-22 314419 (9007276-0114) Screw 4
Order code: GFS
B83 06-12 140644 Plug assembly 1 C05 06-12 519253 (11025822) Cylinder block assembly 1 C80 06-12 518805 Valve plate 1 QC04 06-12 8510365 Cylinder block kit 1
Order code: GFW
B83 06-12 140644 Plug assembly 1 C05 06-12 519253 (11025822) Cylinder block assembly 1 C80 06-12 518008 Valve plate 1 QC04 06-12 8510365 Cylinder block kit 1
Model/Kit
Order code: GFZ
B83 06-12 140644 Plug assembly 1 C05 06-12 519253 (11025822) Cylinder block assembly 1 C80 06-12 518805 Valve plate 1 QC04 06-12 8510365 Cylinder block kit 1
76 | © Danfoss | February 2022 AX152886482206en-000601
B83
C80
*C70
C40
C50
C30
C20
QC04
C05
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
S90P 75cc special hardware GHT-GMA
Parts configuration
* Included in base pump seal kit Q210
©
Danfoss | February 2022 AX152886482206en-000601 | 77
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Common parts
Item Date Begin Date End Part Number Part Name Qty. per
C20 87-02 708230 Piston assembly 9 C30 87-02 11067350 Slipper guide 1 C40 88-22 334391 (8100294) Slipper guide bearing 2 C50 88-22 11065865 Spacer 4 C70 88-22 314419 (9007276-0114) Screw 4
Order code: GHT
B83 06-12 140644 Plug assembly 1 C05 06-12 519253 (11025822) Cylinder block assembly 1 C80 06-12 518008 Valve plate 1 QC04 06-12 8510365 Cylinder block kit 1
Order code: GLA
B83 98-18 140644 Plug assembly 1 C05 98-18 519253 (11025822) Cylinder block assembly 1 C80 98-18 518925 Valve plate, CW 1 C80 98-18 518926 Valve plate, CCW 1 QC04 98-18 8510365 Cylinder block kit 1
Model/Kit
Order code: GLS
B83 98-18 140644 Plug assembly 1 C05 98-18 519253 (11025822) Cylinder block assembly 1 C80 98-18 518925 Valve plate, CW 1 C80 98-18 518926 Valve plate, CCW 1 QC04 98-18 8510365 Cylinder block kit 1
Order code: GMA
B83 97-41 140644 Plug assembly 1 C05 97-41 519253 (11025822) Cylinder block assembly 1 C80 97-41 518007 Valve plate 1 QC04 97-41 8510365 Cylinder block kit 1
78 | © Danfoss | February 2022 AX152886482206en-000601
B100
E30
E22
E20
E80
E24
B94
D86
D87
B92
B84
*C70
C40
C50
C30
C20
QC04
C80
B72
L50
*L25
L70
L60
L40
B70
B80
L10
L20
B50
B50
QB30
*E40
*E60
*E50
E90
E70
E10
B83
C05
D65
D10
D50
D75
D70
F20
QD50
D55
D80
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
S90P 75cc special hardware GMC
Parts configuration
* Included in base pump seal kit Q210
©
Danfoss | February 2022 AX152886482206en-000601 | 79
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Order code: GMC
Item Date Begin Date End Part Number Part Name Qty. per
B50 03-48 9004800-3708 Pin 2 B70 03-48 140644 Plug assembly 1 B72 03-48 140644 Plug assembly 1 B80 03-48 664524 (9005110-9000) Plug assembly 1 B83 03-48 140644 Plug assembly 1 B84 03-48 11040532 Plug assembly 1 B92 03-48 11040532 Plug assembly 1 B94 03-48 11040532 Plug assembly 1 B100 03-48 11117294 Housing assembly 1 C05 03-48 519253 (11025822) Cylinder block assembly 1 C20 03-48 708230 Piston assembly 9 C30 03-48 11067350 Slipper guide 1 C40 03-48 334391 (8100294) Slipper guide bearing 2 C50 03-48 11065865 Spacer 4 C70 03-48 314419 (9007276-0114) Screw 4 C80 03-48 518007 Valve plate 1 D10 03-48 519046 Servo arm 1 D50 03-48 11104315 Swashplate 1 D55 03-48 519150 Screw 1 D70 03-48 9009625-0146 Washer 1 D75 03-48 9004875-0098 Spiral head pin 1 D80 03-48 693929 (8100506) Cage locator link 1 D86 03-48 9004800-1908 Pin 1 D87 03-48 11040532 Plug assembly 1 E10 03-48 11001286 Side cover 1 E20 03-48 11042018 Leveler 1 E22 03-48 517935 Spring seat 2 E24 03-48 8801225 Shim 2 E30 03-48 11056531 Guide post 2 E40 03-48 505412 (9003509-0008) Seal nut 2 E50 03-48 517377 O-ring 1 E60 03-48 517228 (5000206) Screw 6 E70 03-48 664524 (9005110-9000) Plug assembly 1 E80 03-48 334987 Spring 2 E90 03-48 513888 Insert assembly 1 F20 03-48 11116313 Slider block 1
Model/Kit
Part numbers continue to the next 2 pages.
80 | © Danfoss | February 2022 AX152886482206en-000601
B100
E30
E22
E20
E80
E24
B94
D86
D87
B92
B84
*C70
C40
C50
C30
C20
QC04
C80
B72
L50
*L25
L70
L60
L40
B70
B80
L10
L20
B50
B50
QB30
*E40
*E60
*E50
E90
E70
E10
B83
C05
D65
D10
D50
D75
D70
F20
QD50
D55
D80
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Parts configuration
* Included in base pump seal kit Q210
Item Date Begin Date End Part Number Part Name Qty. per
L10 03-48 5000505 Roller bearing 1 L20 03-48 9006300-0156 Retaining ring 1
©
Danfoss | February 2022 AX152886482206en-000601 | 81
Model/Kit
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
(continued)
Item Date Begin Date End Part Number Part Name Qty. per
L25 03-48 519671 Seal carrier assembly 1 L40 03-48 519666 Lip seal (SB-2005-007 on page 348) 1 L50 03-48 684621 (9004104-1530) O-ring 1 L60 03-48 516767 Retainer plate 1 L70 03-48 041160 (9007314-0605) Screw 3 QB30 03-48 11131108 Cradle bearing assembly 1 QC04 03-48 8510365 Cylinder block kit 1 QD50 03-48 11192313 Swashplate assembly (SB-2017-033 on page 361) 1
Model/Kit
82 | © Danfoss | February 2022 AX152886482206en-000601
B100
E30
E22
E20
E80
E24
B94
D86
D87
B92
B84
*C70
C40
C50
C30
C20
QC04
C80
B72
L50
*L25
L70
L60
L40
B70
B80
L10
L20
B50
B50
QB30
*E40
*E60
*E50
E90
E70
E10
B83
C05
D65
D10
D50
D75
D70
F20
QD50
D55
D80
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
S90P 75cc special hardware GMD
Parts configuration
* Included in base pump seal kit Q210
©
Danfoss | February 2022 AX152886482206en-000601 | 83
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Order code: GMD
Item Date Begin Date End Part Number Part Name Qty. per
B50 03-48 9004800-3708 Pin 2 B70 03-48 140644 Plug assembly 1 B72 03-48 140644 Plug assembly 1 B80 03-48 664524 (9005110-9000) Plug assembly 1 B83 03-48 140644 Plug assembly 1 B84 03-48 11040532 Plug assembly 1 B92 03-48 11040532 Plug assembly 1 B94 03-48 11040532 Plug assembly 1 B100 03-48 11117294 Housing assembly 1 C05 03-48 519253 (11025822) Cylinder block assembly 1 C20 03-48 708230 Piston assembly 9 C30 03-48 11067350 Slipper guide 1 C40 03-48 334391 (8100294) Slipper guide bearing 2 C50 03-48 11065865 Spacer 4 C70 03-48 314419 (9007276-0114) Screw 4 C80 03-48 518925 Valve plate, CW 1 D10 03-48 519046 Servo arm 1 D50 03-48 11104315 Swashplate 1 D55 03-48 519150 Screw 1 D70 03-48 9009625-0146 Washer 1 D75 03-48 9004875-0098 Spiral head pin 1 D80 03-48 693929 (8100506) Cage locator link 1 D86 03-48 9004800-1908 Pin 1 D87 03-48 11040532 Plug assembly 1 E10 03-48 11001286 Side cover 1 E20 03-48 11042018 Leveler 1 E22 03-48 517935 Spring seat 2 E24 03-48 8801225 Shim 2 E30 03-48 11056531 Guide post 2 E40 03-48 505412 (9003509-0008) Seal nut 2 E50 03-48 517377 O-ring 1 E60 03-48 517228 (5000206) Screw 6 E70 03-48 664524 (9005110-9000) Plug assembly 1 E80 03-48 334987 Spring 2 E90 03-48 513888 Insert assembly 1 F20 03-48 11116313 Slider block 1
Model/Kit
Part numbers continue to the next 2 pages.
84 | © Danfoss | February 2022 AX152886482206en-000601
B100
E30
E22
E20
E80
E24
B94
D86
D87
B92
B84
*C70
C40
C50
C30
C20
QC04
C80
B72
L50
*L25
L70
L60
L40
B70
B80
L10
L20
B50
B50
QB30
*E40
*E60
*E50
E90
E70
E10
B83
C05
D65
D10
D50
D75
D70
F20
QD50
D55
D80
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Parts configuration
* Included in base pump seal kit Q210
©
Danfoss | February 2022 AX152886482206en-000601 | 85
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Order code: GMD
Item Date Begin Date End Part Number Part Name Qty. per
L10 03-48 5000505 Roller bearing 1 L20 03-48 9006300-0156 Retaining ring 1 L25 03-48 519671 Seal carrier assembly 1 L40 03-48 519666 Lip seal (SB-2005-007 on page 348) 1 L50 03-48 684621 (9004104-1530) O-ring 1 L60 03-48 516767 Retainer plate 1 L70 03-48 041160 (9007314-0605) Screw 3 QB30 03-48 11131108 Cradle bearing assembly 1 QC04 03-48 8510365 Cylinder block kit 1 QD50 03-48 11192313 Swashplate assembly (SB-2017-033 on page 361) 1
Model/Kit
86 | © Danfoss | February 2022 AX152886482206en-000601
B100
E30
E22
E20
E80
E24
B94
D86
D87
B92
B84
*C70
C40
C50
C30
C20
QC04
C80
B72
L50
*L25
L70
L60
L40
B70
B80
L10
L20
B50
B50
QB30
*E40
*E60
*E50
E90
E70
E10
B83
C05
D65
D10
D50
D75
D70
F20
QD50
D55
D80
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
S90P 75cc special hardware GME
Parts configuration
* Included in base pump seal kit Q210
©
Danfoss | February 2022 AX152886482206en-000601 | 87
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Order code: GME
Item Date Begin Date End Part Number Part Name Qty. per
B50 03-48 9004800-3708 Pin 2 B70 03-48 140644 Plug assembly 1 B72 03-48 140644 Plug assembly 1 B80 03-48 664524 (9005110-9000) Plug assembly 1 B83 03-48 140644 Plug assembly 1 B84 03-48 11040532 Plug assembly 1 B92 03-48 11040532 Plug assembly 1 B94 03-48 11040532 Plug assembly 1 B100 03-48 11117294 Housing assembly 1 C05 03-48 519253 (11025822) Cylinder block assembly 1 C20 03-48 708230 Piston assembly 9 C30 03-48 11067350 Slipper guide 1 C40 03-48 334391 (8100294) Slipper guide bearing 2 C50 03-48 11065865 Spacer 4 C70 03-48 314419 (9007276-0114) Screw 4 C80 03-48 518008 Valve plate 1 D10 03-48 519046 Servo arm 1 D50 03-48 11104315 Swashplate 1 D55 03-48 519150 Screw 1 D70 03-48 9009625-0146 Washer 1 D75 03-48 9004875-0098 Spiral head pin 1 D80 03-48 693929 (8100506) Cage locator link 1 D86 03-48 9004800-1908 Pin 1 D87 03-48 11040532 Plug assembly 1 E10 03-48 11001286 Side cover 1 E20 03-48 11042018 Leveler 1 E22 03-48 517935 Spring seat 2 E24 03-48 8801225 Shim 2 E30 03-48 11056531 Guide post 2 E40 03-48 505412 (9003509-0008) Seal nut 2 E50 03-48 517377 O-ring 1 E60 03-48 517228 (5000206) Screw 6 E70 03-48 664524 (9005110-9000) Plug assembly 1 E80 03-48 334987 Spring 2 E90 03-48 513888 Insert assembly 1 F20 03-48 11116313 Slider block 1
Model/Kit
Part numbers continue to the next 2 pages.
88 | © Danfoss | February 2022 AX152886482206en-000601
B100
E30
E22
E20
E80
E24
B94
D86
D87
B92
B84
*C70
C40
C50
C30
C20
QC04
C80
B72
L50
*L25
L70
L60
L40
B70
B80
L10
L20
B50
B50
QB30
*E40
*E60
*E50
E90
E70
E10
B83
C05
D65
D10
D50
D75
D70
F20
QD50
D55
D80
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Parts configuration
* Included in base pump seal kit Q210
©
Danfoss | February 2022 AX152886482206en-000601 | 89
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Order code: GME
Item Date Begin Date End Part Number Part Name Qty. per
L10 03-48 5000505 Roller bearing 1 L20 03-48 9006300-0156 Retaining ring 1 L25 03-48 519671 Seal carrier assembly 1 L40 03-48 519666 Lip seal (SB-2005-007 on page 348) 1 L50 03-48 684621 (9004104-1530) O-ring 1 L60 03-48 516767 Retainer plate 1 L70 03-48 041160 (9007314-0605) Screw 3 QB30 03-48 11131108 Cradle bearing assembly 1 QC04 03-48 8510365 Cylinder block kit 1 QD50 03-48 11192313 Swashplate assembly (SB-2017-033 on page 361) 1
Model/Kit
90 | © Danfoss | February 2022 AX152886482206en-000601
C80
C06
*C70
C40
C50
C30
C20
QC04
B83
*QB83
C80
*C70
C40
C50
C30
C20
QC04
B83
C05
(GTA, HCA, JAA, JCA, JCB,
PGA & PGB)
(PEA & PEB)
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
S90P 75cc special hardware GTA-PEA
Parts configuration
* Included in base pump seal kit Q210
©
Danfoss | February 2022 AX152886482206en-000601 | 91
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Common parts
Item Date Begin Date End Part Number Part Name Qty. per
C20 87-02 708230 Piston assembly 9 C30 87-02 11067350 Slipper guide 1 C40 88-22 334391 (8100294) Slipper guide bearing 2 C50 88-22 11065865 Spacer 4 C70 88-22 314419 (9007276-0114) Screw 4
Order code: GTA
B83 98-18 140644 Plug assembly 1 C05 98-18 519253 (11025822) Cylinder block assembly 1 C80 98-18 518805 Valve plate 1 QC04 98-18 8510365 Cylinder block kit 1
Order code: HCA
B83 98-18 140644 Plug assembly 1 C05 98-18 519253 (11025822) Cylinder block assembly 1 C80 98-18 518924 Valve plate 1 QC04 98-18 8510365 Cylinder block kit 1
Model/Kit
Order code: JAA
B83 97-41 140644 Plug assembly 1 C05 97-41 519253 (11025822) Cylinder block assembly 1 C80 97-41 518924 Valve plate 1 QC04 97-41 8510365 Cylinder block kit 1
Order code: JCA
B83 08-12 140644 Plug assembly 1 C05 08-12 519253 (11025822) Cylinder block assembly 1 C80 08-12 518805 Valve plate 1 QC04 08-12 8510365 Cylinder block kit 1
Order code: PEA
B83 07-04 KPPG156 Speed sensor assembly 1 C06 07-04 11094260 (11011714) Cylinder block assembly with speed ring 1 C80 07-04 518805 Valve plate 1 QB83 07-04 085043 (9004201-3700) O-ring 1 QC04 07-04 8510366 Cylinder block kit with speed ring 1
92 | © Danfoss | February 2022 AX152886482206en-000601
C80
C06
*C70
C40
C50
C30
C20
QC04
B83
*QB83
C80
*C70
C40
C50
C30
C20
QC04
B83
C05
(GTA, HCA, JAA, JCA, JCB,
PGA & PGB)
(PEA & PEB)
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
S90P 75cc special hardware PEB-PGB
Parts configuration
* Included in base pump seal kit Q210
©
Danfoss | February 2022 AX152886482206en-000601 | 93
Parts Manual
Series 90 75cc Axial Piston Pump
Common parts and special hardware
Common parts
Item Date Begin Date End Part Number Part Name Qty. per
C20 87-02 708230 Piston assembly 9 C30 87-02 11067350 Slipper guide 1 C40 88-22 334391 (8100294) Slipper guide bearing 2 C50 88-22 11065865 Spacer 4 C70 88-22 314419 (9007276-0114) Screw 4
Order code: PEB
B83 07-07 KPPG156 Speed sensor assembly 1 C06 07-07 11094260 (11011714) Cylinder block assembly with speed ring 1 C80 07-07 518925 Valve plate, CW 1 C80 07-07 518926 Valve plate, CCW 1 QB83 07-07 085043 (9004201-3700) O-ring 1 QC04 07-07 8510366 Cylinder block kit with speed ring 1
Model/Kit
Order code: PGA
B83 07-04 140644 Plug assembly 1 C05 07-04 519253 (11025822) Cylinder block assembly 1 C80 07-04 518805 Valve plate 1 QC04 07-04 8510365 Cylinder block kit 1
Order code: PGB
B83 07-07 140644 Plug assembly 1 C05 07-07 519253 (11025822) Cylinder block assembly 1 C80 07-07 518925 Valve plate, CW 1 C80 07-07 518926 Valve plate, CCW 1 QC04 07-07 8510365 Cylinder block kit 1
94 | © Danfoss | February 2022 AX152886482206en-000601
(*F50)
(*F40)
F205
F211
(*F12)
F10
(*F11)
(*F11)
(*F12)
F111
(*F40)
(*F50)
F105
*F212
F213
(*F50)
(*F40)
F205
F211
F111
(*F40)
(*F50)
*F112
F113
F105
Parts Manual
Series 90 75cc Axial Piston Pump

Displacement

S90P 75cc displacement limitation 1-4
Parts configuration
* Included in overhaul seal kit Q210
( ) Not available individually
©
Danfoss | February 2022 AX152886482206en-000601 | 95
Parts Manual
Series 90 75cc Axial Piston Pump
Displacement
Common parts
Item Date Begin Date End Part Number Part Name Qty. per
F10 88-16 11041752 Servo piston assembly (SB-1988-009 on page 300
& SB-2000-022 on page 343)
F111 87-02 378083 (9007210-0804) Screw 3 F211 87-02 378083 (9007210-0804) Screw 3
Order code: 1
F105 87-02 11059759 (11055763) Servo cylinder assembly 1 F112 87-02 505412 (9003509-0008) Seal nut 1 F113 87-02 5000747 Set screw, M8 x45mm (SB-2000-022 on page 343) 1 F205 87-02 11059760 (11055761) Servo cylinder assembly 1
Order code: 2
F105 87-02 11059760 (11055761) Servo cylinder assembly 1 F205 87-02 11059759 (11055763) Servo cylinder assembly 1 F212 87-02 505412 (9003509-0008) Seal nut 1 F213 87-02 5000747 Set screw, M8 x45mm (SB-2000-022 on page 343) 1
Model/Kit
1
Order code: 3
F105 87-02 11059760 (11055761) Servo cylinder assembly 1 F205 87-02 11059760 (11055761) Servo cylinder assembly 1
Order code: 4
F105 87-02 11059759 (11055763) Servo cylinder assembly 1 F112 87-02 505412 (9003509-0008) Seal nut 1 F113 87-02 5000747 Set screw, M8 x45mm (SB-2000-022 on page 343) 1 F205 87-02 11059759 (11055763) Servo cylinder assembly 1 F212 87-02 505412 (9003509-0008) Seal nut 1 F213 87-02 5000747 Set screw, M8 x45mm (SB-2000-022 on page 343) 1
96 | © Danfoss | February 2022 AX152886482206en-000601
F017
F015
F023
F016
F018
F019
F020
F021
F022
F100
(*F12)
F10
(*F11)
(*F11)
(*F12)
(*F50)
(*F40)
F205
F211
F105
F111
*F124
(*F40)
(*F50)
Parts Manual
Series 90 75cc Axial Piston Pump
Displacement
S90P 75cc displacement limitation 7
Parts configuration
* Included in base pump seal kit Q210
( ) Not available individually
©
Danfoss | February 2022 AX152886482206en-000601 | 97
Parts Manual
Series 90 75cc Axial Piston Pump
Displacement
Order code: 7
Item Date Begin Date End Part Number Part Name Qty. per
F10 98-14 11041755 Servo piston assembly 1 F015 98-14 346395 Screw 1 F016 98-14 507092 Spring guide 1 F017 98-14 346320 Servo spring housing 1 F018 98-14 346254 Spring 1 F019 98-14 507093 Spring guide 1 F020 98-14 346379 Retaining ring 1 F021 98-14 787887 Castle nut 1 F022 98-14 336800 Nut 1 F023 98-14 11140220 Adjusting screw 1 F100 98-14 515310 (8100932) Servo assembly 1 F105 98-14 11060187 (11055767) Servo cylinder assembly, automotive control 1 F111 98-14 746651 (393595) Screw 3 F124 98-14 336826 Seal nut 1 F205 98-14 11059760 (11055761) Servo cylinder assembly, non-adjustable 1 F211 98-14 378083 (9007210-0804) Screw 3
Model/Kit
98 | © Danfoss | February 2022 AX152886482206en-000601
(*F50)
(*F40)
F205
F211
*F224
F017
F015
F023
F016
F018
F019
F021
F022
F020
F200
(*F12)
F10
F111
F105
(*F11)
(*F12)
(*F11)
F111
(*F40)
(*F50)
*F112
F113
F105
(*F40)
(*F50)
(8)
(B)
Parts Manual
Series 90 75cc Axial Piston Pump
Displacement
S90P 75cc displacement limitation 8, B
Parts configuration
* Included in overhaul seal kit Q210
( ) No available individually
©
Danfoss | February 2022 AX152886482206en-000601 | 99
Parts Manual
Series 90 75cc Axial Piston Pump
Displacement
Common parts
Item Date Begin Date End Part Number Part Name Qty. per
F10 98-14 11041755 Servo piston assembly 1 F015 98-14 346395 Screw 1 F016 98-14 507092 Spring guide 1 F017 98-14 346320 Servo spring housing 1 F019 98-14 507093 Spring guide 1 F020 98-14 346379 Retaining ring 1 F021 98-14 787887 Castle nut 1 F022 98-14 336800 Nut 1 F023 98-14 11140220 Adjusting screw 1 F111 98-14 378083 (9007210-0804) Screw 3 F205 98-14 11060187 (11055767) Servo cylinder assembly 1 F211 98-14 746651 (393595) Screw 3 F224 98-14 336826 Seal nut 1
Model/Kit
Order code: 8
F018 98-14 346262 Spring 1 F105 98-14 11059759 (11055763) Servo cylinder assembly 1 F112 98-14 505412 (9003509-0008) Seal nut 1 F113 98-14 5000747 Set screw, M8 x 45mm (SB-2000-022 on page
343)
F200 98-14 515324 (8100932) Servo assembly 1
Order code: B
F018 98-14 346254 Spring 1 F105 98-14 11059760 (11055761) Servo cylinder assembly 1 F200 98-14 515310 (8100932) Servo assembly 1
1
100 | © Danfoss | February 2022 AX152886482206en-000601
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
