GS26MFX
Standard Compressor
R134a
220-240V 50Hz
General
Code number |
|
|
|
|
|
107B0700 |
|
|
|
||
Approvals |
|
|
|
|
EN 60335-2-34 |
|
|||||
Compressors on pallet |
|
|
|
|
|
48 |
|
|
|
||
Application |
|
|
|
|
|
|
|
|
|
|
|
Application |
|
|
|
|
|
MBP |
|
|
|
||
Frequency |
|
Hz |
|
50 |
|
|
|
60 |
|
|
|
Evaporating temperature |
|
°C |
-20 to 7.2 |
|
|
– |
|
||||
Voltage range |
|
V |
198 - 254 |
|
|
– |
|
||||
Max. condensing temperature continuous (short) |
°C |
|
60 (70) |
|
|
– |
|
||||
Max. winding temperature continuous (short) |
°C |
125 (135) |
|
|
– |
|
|||||
Cooling requirements |
|
|
|
|
|
|
|
|
|
|
|
Frequency |
|
Hz |
|
50 |
|
|
|
60 |
|
|
|
Application |
|
|
LBP |
|
MBP |
HBP |
|
LBP |
MBP |
|
HBP |
32°C |
|
|
– |
|
F2 |
– |
|
– |
– |
|
– |
38°C |
|
|
– |
|
F2 |
– |
|
– |
– |
|
– |
43°C |
|
|
– |
|
F2 |
– |
|
– |
– |
|
– |
Remarks on application: |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Motor |
|
|
|
|
|
|
|
|
|
|
|
Motor type |
|
|
|
|
|
CSR |
|
|
|
||
LRA (rated after 4 sec. UL984), HST | LST |
A |
|
20.2 |
|
|
|
– |
|
|||
Cut in Current, HST | LST |
|
A |
|
20.2 |
|
|
|
– |
|
||
Resistance, main | start winding (25°C) |
Ω |
|
3.6 |
|
|
|
3.9 |
|
|
||
Design |
|
|
|
|
|
|
|
|
|
|
|
Displacement |
|
cm3 |
|
|
|
26.30 |
|
|
|
||
Oil quantity (type) |
|
cm3 |
|
|
900 (polyolester) |
|
|||||
Maximum refrigerant charge |
|
g |
|
|
|
2000 |
|
|
|
||
Free gas volume in compressor |
|
cm3 |
|
|
|
3350 |
|
|
|
||
Weight without electrical equipment |
kg |
|
|
|
19.1 |
|
|
|
|||
Dimensions |
|
|
|
|
|
|
|
|
|
|
|
Height |
|
mm |
A |
|
|
259 |
|
|
|
||
|
|
|
B |
|
|
247 |
|
|
|
||
|
|
|
B1 |
|
|
234 |
|
|
|
||
|
|
|
B2 |
|
|
234 |
|
|
|
||
Suction connector |
location/I.D. mm | angle |
C |
|
|
12.9 | 90° |
|
|
|
|||
|
material | comment |
|
|
Copper | Rubber plug |
|
||||||
Process connector |
location/I.D. mm | angle |
D |
|
|
6.5 | 90° |
|
|
|
|||
|
material | comment |
|
|
Copper | Rubber plug |
|
||||||
Discharge connector |
location/I.D. mm | angle |
E |
|
|
8.2 | 19° |
|
|
|
|||
|
material | comment |
|
|
Copper | Rubber plug |
|
||||||
Oil cooler connector |
location/I.D. mm | angle |
F |
|
|
|
– |
|
|
|
||
|
material | comment |
|
|
|
|
– |
|
|
|
||
Connector tolerance |
I.D. mm |
12.9±0.15, 8.2 ±0.05, 6.5 ±0.10 |
|||||||||
Remarks: |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
S |
= Static cooling normally sufficient |
|||||||||||||||||||||||||||
O |
= Oil cooling |
|||||||||||||||||||||||||||
F1 |
= Fan cooling 1.5 m/s |
|||||||||||||||||||||||||||
|
|
|
|
(compressor compartment temperature |
||||||||||||||||||||||||
|
|
|
|
equal to ambient temperature) |
||||||||||||||||||||||||
F2 |
= Fan cooling 3.0 m/s necessary |
|||||||||||||||||||||||||||
SG |
= Suction gas cooling normally sufficent |
–= not applicable in this area
Dec 2011 |
Manufactured by Secop for Danfoss - DEHC.ED.401.D2.02 / 520N0096 |
1/2 |
