Danfoss FP715Si Installation guide
MAKING MODERN LIVING POSSIBLE
FP715Si
Electronic 2-Channel Full Programmer for Heating and Hot Water with Service Interval Timer
Danfoss Heating
Installation Guide
GB
For a large print version of these instructions please call Marketing on 0845 121 7400.
®
Certification Mark
Danfoss can accept no responsibility for possible errors in catalogues, brochures, and other printed material. All trademarks in this material are property of the respective companies. Danfoss and the Danfoss logotype are trademarks of Danfoss A/S. All rights reserved.
2 |
FP715SI |
FP715Si
Electronic 2-Channel Full Programmer for Heating & Hot Water with Service Interval Timer
Index
1.0 |
Installation Overview.............................................................................. |
4 |
|
2.0 |
Product Specification.............................................................................. |
4 |
|
3.0 |
Installation |
|
|
|
3.1 |
Wiring..................................................................................................... |
5 |
|
3.2 |
DIL Switch Settings ........................................................................... |
6 |
4.0 |
Advanced Programming Options ..................................................... |
6 |
|
5.0 |
Copy Functions Explained .................................................................... |
7 |
|
6.0 |
Service Interval Timer ............................................................................. |
9 |
|
7.0 |
Wiring Conversions ......................................................................... |
10-17 |
|
Danfoss Heating |
|
3 |
|
|
|
|
1.0 Installation Overview |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
Please Note: |
|
|
|
|
|
|
|
This product should only be installed by a qualified electrician or |
|||
|
|
|
|
competent heating installer and should be in accordance with the |
|||
|
|||||||
GB |
|
|
|
current edition of the IEEE wiring regulations. |
|
||
|
|
|
|
2.0 Product Specification |
|
||
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Specification |
230V model |
|
24V model |
|
|
|
|
|
|
|
|
|
|
|
|
|
230 Vac, |
|
24 Vac, |
|
|
|
|
Power supply |
±15%, |
|
±15%, |
|
|
|
|
|
50/60 Hz |
|
50/60 Hz |
|
|
|
|
|
|
|
|
|
|
|
|
Switching action |
2 x SPDT internally linked, Type 1B |
||
|
|
|
|
|
|
|
|
|
|
|
|
Unit switch rating |
230 Vac, 3(1)A |
|
24 Vac, 3(1)A |
|
|
|
|
|
|
|
|
|
|
|
|
Battery back-up |
24 hours minimum |
||
|
|
|
|
|
|
||
|
|
|
|
Programme resolution |
± 1 minute |
||
|
|
|
|
|
|
||
|
|
|
|
Dimensions, mm (W, H, D) |
135 x 88 x 32 |
||
|
|
|
|
|
|
||
|
|
|
|
Design standard |
EN 60730-2-7 |
||
|
|
|
|
|
|
||
|
|
|
|
Control Pollution Situation |
Degree 2 |
||
|
|
|
|
|
|
|
|
|
|
|
|
Rated Impulse Voltage |
2.5 kV |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Ball Pressure Test |
75°C |
|
|
|
|
|
|
|
|
|
|
3.0 Installation
•Remove wallplate from unit by unscrewing the two screws on the bottom edge of the unit.
•From the top left hand corner of the wallplate, there must be clearances of at least 140 mm to the right, 15mm to the left, 30mm above and 100mm below in order to mount the plug-on module.
4 |
FP715SI |
•The wallplate must be securely mounted either directly to the wall using suitable wood screws or to a flush mounted 1-gang electrical accessory box using M3.5 screws.
•Cable access can either be from behind for concealed cabling, or from below for surface cabling. If surface cable is used, cut out
cable access slot on plug-on module prior to mounting. |
GB |
|
•For wiring connections refer to diagram below.
FP715 Si models are double insulated and do not require an earth connection, however a parking terminal is provided on the wallplate. This is clearly marked with an Earth symbol.
•Prior to mounting the plug-on module, DIL switches on the rear of the plug-on module must be set. See diagram on page 6 for available options.
•Mount plug-on module to wallplate by locating tabs on top of wallplate in apertures on rear of module, hinge down and press firmly to wallplate before tightening securing screws on bottom of wallplate.
3.1 Wiring
For wiring conversion tables please see pages 10-17).
Please Note:
On 24 volt models power supply must be wired to A & B on wallplate.
ELECTRONICS |
|
|
|
|
|
|
|
|
|
|
N/C |
N/O |
N/C |
N/O |
|||
N |
L |
1 |
|
2 |
|
|
3 |
4 |
230V |
|
OFF |
|
OFF |
|
ON |
ON |
|
Fused |
|
DHW |
HTG |
DHW |
HTG |
|||
3A |
|
|
|
|
|
|
|
|
Please Note:
Always switch o mains first and never fit programmer to a live wallplate.
Danfoss Heating |
5 |
3.2 DIL Switch Settings
Before mounting the unit, ensure the 4 DIL switches on the rear have been moved to the required settings.
GB
Sw.1 |
Not Used |
|
|
|
|
|
Not Used |
Sw.2 |
Gravity |
|
|
|
|
|
Pumped |
|
|
|
|
|
|||
|
|
|
|
|
|||
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
Sw.3 |
5/2 Day |
|
|
|
|
|
7 Day or 24 Hour |
Sw.4 |
7 Day |
|
|
|
|
|
24 Hour |
|
|
|
|
|
|||
|
|
|
|
|
|||
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
Tick the INSTALLER SETTING box on the inside flap label to notify user in which mode their unit is set (24hr, 5/2 day or 7 day).
INSTALLER SETTING
24 Hour
5+2 Day
7Day
4.0Advanced Programming Options
To enter advanced programming press PROG, + and DAY/HOL together and hold for 5 seconds.
Option 1 - (3 or 2 On/O s per day)
Use + or - to change between 3 or 2 on/o s each day.
3 |
2 |
3 on/o s each day (Factory setting) |
2 on/o s each day |
Option 2 - (Disable or enable auto time change)
Press NEXT, then use + or - to change between auto time change enabled to auto time change disabled.
Auto time change enabled (Factory setting) |
Auto time change disabled |
6 |
FP715SI |
