DEVIlink™

DEVIlink™ CC

DEVIlink™ CC – Central Controller, is the perfect solution for the regulation of electric ﬂoor heating both for apartments, family houses and multifamily buildings.

DEVIlink™ is Danfoss Link™ App enabled, that oﬀers you the unique possibility to control your electrical heating systems from a distance via an App on your smartphone.

The DEVIlink™ CC (Central Controller) is the central brain in the DEVIlink™ system, which includes several wireless DEVIlink™ devices installed in the building. The idea of the DEVIlink™ System is to link together your heating system wirelessly and control it from one central point. The DEVIlink™ CC communicates wirelessly with all other DEVIlink™ units in the installation. A single DEVIlink™ CC can control up to 30 rooms and be connected up to totally 50 devices

Type

Beneﬁts:

• Central control of the entire house

• Minimize energy consumption

• Vacation mode

• Controlling of ON/OFF devices

• Weekly heating schedule

• WIFI connectivity Enabled for Danfoss Link™ App

Standard compliance:

• The DEVIlink™ CC is in compliance with EN 60730 and EN 300 220-2

Certiﬁcates:

Operation voltage 15 V DC ±10%

Standby power consumption Max. 2 W

Screen 3.5” TFT colour w. touch

Ambient temperature -10 to +40°C

Storage temperature -20 to +65°C

Ball pressure test temperature 75°C

Pollution degree 2 (domestic use)

Transmission frequency 868.42 MHz

Transmission range Up to 30 m

Max. repeaters in a chain 3

Transmission power Max. 1 mW

Software class A

IP class 21

Dimensions 125 x 107 x 25 mm

Weight 179 g

Types

Item no. Product name Type EAN no.

140F1135* DEVIlink™ CC Central Controller - WiFi, with PSU 5703466238967

* While on the stock

Value

Accessories

Item no. Product name Type EAN no.

014G0262*

* While on the stock

BSU DEVIlink™ CC

Battery Supply Unit 5702420110653

DEVIlink™ system units

Item no. Product name Type EAN no.

140F1136*

140F1137* DEVIlink™ FT Floor Thermostat with ELKO frame 5703466238981

140F1138* DEVIlink™ RU Repeater Unit 5703466238998

* While on the stock

See how simple it is to setup Wi-Fi on your DEVIlink system and how to pair it with the Danfoss Link™ App.

DEVIlink™ RS

Room sensor - Wireless - Battery Supply 5703466238974

Try it!

Download the

Danfoss Link™ App
