Danfoss BC 06 Technical Information
Flow Control Valves Technical Information
Velocity Fuse
BC 06
OPERATION |
This is an in-line flow limiter that closes and then provides non-compensated restricted |
|
flow when the specified flow setting is exceeded. The valve provides free reverse flow |
||
|
when operated in the opposite direction. |
|
SPECIFICATIONS |
Schematic |
Theoretical performance |
P |
C |
P |
C |
Specifications
Pressure rating |
210 bar [3000 psi] |
Rated Free Flow at 7 bar |
30 l/min |
[100 psi] |
[8 US gal/min] |
Cavity |
Consult factory |
DIMENSIONS mm [in]
|
|
49 |
|
|
|
[1.93 ] |
|
|
12 |
37 |
|
|
[0.47 ] |
[1.46 ] |
|
|
C |
P |
|
| <![if ! IE]> <![endif]>G 1/4 |
<![if ! IE]> <![endif]>G 1/4 |
||
|
ORDERING |
|
|
BC 06 - 1.0 - G - 00 - S1.5 |
|
|
||||||||
Adjustment H |
|
|
|
|
|
|
|
|
Metering orifice |
||||
INFORMATION |
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
||||||
00 |
= No factory adjustment |
|
|
|
|
|
Omit = |
No orifice |
|||||
|
|
|
|
|
|
||||||||
|
0.25 |
= 0.25 mm [ in] |
|
|
|
|
|
S0.5 |
= |
0.5 mm [ in] |
|||
|
0.5 |
= 0.5 mm [ in] |
|
|
|
|
|
S0.7 |
= |
0.7 mm [ in] |
|||
|
1.0 |
=1.0 mm [ in] |
|
|
|
|
|
S1.0 |
= |
1.0 mm [ in] |
|||
|
1.5 |
= 1.5mm [in] |
|
|
|
|
|
S1.5 |
= |
1.5 mm [ in] |
|||
|
2.0 |
= 2.0mm [in] |
|
|
|
|
|
S2.0 |
= |
2.0 mm [ in] |
|||
00 = Cartridge only |
|
L = 1/4 BSP |
|
