Danfoss AKS 32, AKS 33 Data sheet

Data Sheet

Pressure transmitter Type AKS 32 and AKS 33

AKS 32 and AKS 33 are pressure transmitters that measure a pressure and convert the measured value to a standard signal:

• 1 – 5 V DC or 0 – 10 V DC for AKS 32

• 4 – 20 mA for AKS 33

A robust design makes the AKS very suitable for application within a number of elds e.g.

• Air conditioning systems

• Refrigeration plant

• Process control

• Laboratories

AI309147088294en-000303

Pressure transmitter, Type AKS 32 and AKS 33

Features

Highly developed sensor technology means high pressure regulation accuracy, a very important factor in the precise and energy-economic capacity regulation of refrigeration plants.

• Fully digitally compensated, developed specially for refrigeration plants.

◦ LP: -30 – 40 °C (≤ 16 bar) ◦ HP: 0 – 80 °C (> 16 bar)

• Compatibility with all refrigerants incl. ammonia means less stock and greater application exibility

• Built-in voltage stabiliser, i.e. the AKS pressure transmitters can be powered from an unregulated voltage supply of any output within given limits

• Eective protection against moisture means that the sensor can be mounted in very harsh environments, e.g. in the suction line encapsulated in an ice block

• Robust construction gives protection against mechanical inuences such as shock, vibration and pressure surge. AKS sensors can be mounted direct on to the plant application

• No adjustment necessary. With the highly developed sensor technology and sealed gauge principle, the accuracy of the factory setting is maintained independent of variations in ambient temperature and atmospheric pressure. This is very important when ensuring evaporating pressure control in air conditioning and refrigeration applications

• EMC protection according to EU EMC-directive (CE-marked)

• UL approved

• Polarity protected inputs

• For use in zone ATEX 2 explosive atmospheres

Accuracy (incl. non-linearity, hysteresis and repeatability)

± 0.3% FS (typ.) / ± 0.8% FS (max.)

Non-linearity BFSL (conformity)

< ± 0.2% FS

Hysteresis and repeatability

≤ ± 0.1% FS

Thermal zero point shift

≤ ± 0.1% FS / 10K (typ.)

≤ ± 0.2% FS / 10K (max.)

Thermal sensitivity (span) shift

≤ ± 0.1% FS / 10K (typ.)

≤ ± 0.2% FS / 10K (max.)

Response time

< 4 ms

Max. working pressure

See ordering table

Burst pressure

min. 300 bar

Power-up time

< 50 ms

Rated output signal

4 – 20 mA

Supply voltage [UB], polarity protected

9 – 32 V DC

Supply voltage dependency

< 0.1% FS / 10 V

Output limitation

22.4 mA

Max.Load, [RL]

RL≤

UB − 9V

0.02A

[Ω]

Rated output signal (short-circuit protected)

0 – 10 V DC

Supply voltage [UB], polarity protected

15 – 32 V DC

Supply current consumption

< 8 mA

Supply voltage dependency

< 0.05% FS / 10 V

Sink / source

< 1 mA

Load resistance, R

RL ≥ 15 kΩ

Rated output signal (short-circuit protected)

1 – 5 V DC

Supply voltage [UB], polarity protected

9 – 32 V DC

Supply current consumption

< 5 mA

Supply voltage dependency

< 0.05% FS / 10 V

Sink / source

< 1 mA

Load resistance, R

RL ≥ 10 kΩ

Operating temperature range Normal

-40 – 85 °C

ATEX Zone 2

-10 – 85 °C

Media temperature range [°C]

-40 – 85 °C

Compensated temperature range

LP: -30 – 40 °C / HP: 0 – 80 °C

Transport/storage temperature range

-50 – 85 °C

EMC – Emission

EN 61000-6-3

EMC – Immunity

Electrostatic discharge Air

8 kV

EN 61000-6-2

Contact

4 kV

EN 61000-6-2

eld

10 V/m, 26 MHz – 1 GHz

EN 61000-6-2

conducted

3 V

rms

, 150 kHz – 30 MHz

EN 61000-6-2

Transient burst

4 kV (CM)

EN 61000-6-2

surge

1 kV (CM,DM)

EN 61000-6-2

Insulation resistance

> 100 MΩ at 500 V DC

Vibration stability Sinusoidal

20 g, 25 Hz – 2 kHz

IEC 60068-2-6

Random

7.5 grms , 5 Hz – 1 kHz

IEC 60068-2-34, IEC 60068-2-36

Pressure transmitter, Type AKS 32 and AKS 33

Product specication

Technical data

Table 1: Performance

Table 2: Electrical specications AKS 33, 4 – 20 mA output signal

Table 3: Electrical specications for AKS 32, 0 – 10 V DC output signal

Table 4: Electrical specications for AKS 32, 1 – 5 V DC output signal

Table 5: Environmental conditions

Shock resistance Shock

500 g / 1 ms

IEC 60068-2-27

Free fall

1 m

IEC 60068-2-32

Enclosure (depending on electrical connection)

Plug version

IP65 - IEC 60529

Cable version

IP67 - IEC 60529

Zone 2 applications

EN60079-0; EN60079-7

AKS other products can be used in end user applications employing the following ammable refrigerants: A3: R290, R600, R600a, R1270, A2L: R32, R444B, R452A/B, R454A/B/C, R455A, R1234zyef

IEC/EN 60335-2-89 (commercial refrigerating appliances) IEC/EN 60335-2-40 (electrical heat pumps, air-onditioners)

Electrical connection

EN 175301-803 plug / 2 m cable

Wetted parts, material

EN10088-1-1.4404 (AISI 316L)

Housing material

EN10088-1-1.4404 (AISI 316L)

Refr igerants

DR3, DR55, DR7, HDR110, L40, R1234yf, R1234ze, R1270, R1290, R134a, R22, R227, R23, R290, R32, R404A, R407A, R407B, R407C, R407F, R410A, R413A, R417A, R422A, R422D, R427A, R438A, R444B, R447A, R448A, R449A, R449B, R450A, R452A/B, R454A/B/C R455A, R502, R507, R513A, R600, R600a, 717 (NH3), R744 (CO2), R1270

Type code

Danfoss

60G282

Ambient temperature

-40 – 85 °C

-30 – 80 °C

Electrical connection 4 – 20 m output

Pin 1: + supply Pin 2: ÷ supply Pin 3: not used

Earth : Connected to AKS enclosure

Brown wire: + supply

Black wire: ÷ supply

Red wire: not used

Orange wire: not used

Screen: not connected to AKS enclosure

Electrical connection 0 – 5 –, 0 – 10 V output

Pin 1: + supply

Pin 2: ÷ supply/common

Pin 3: + output

Earth : Connected to AKS enclosure

Brown wire: + output

Black wire: ÷ supply/common

Rred wire: + supply

Orange wire: not used

Screen: not connected to AKS ensclosure

Pressure transmitter, Type AKS 32 and AKS 33

Table 6: Explosive atmospheres

The products for ATEX Zone 2 are applicable in refrigeration applications employing any ammable refrigerants classied as IIA – please, refer to AKS installation guide.

In ATEX Zone 2 applications at low temperatures cable and plug must be protected against impact.

Table 7: Explosive atmospheres

For other products not ATEX Zone 2 assessed, an ignition risk assessment has been conducted with reference to IEC/EN 60335-2-89 (commercial refrigerating appliances) and IEC/EN 60335-2-40 (electrical heat pumps, airconditioners).

For countries where safety standards are not an indispensable part of the safety system, Danfoss recommends the installer to seek a third-party approval of the system containing ammable refrigerant. Note: Please, follow specic selection criteria stated in the data sheet for these particular refrigerants.

Table 8: Mechanical characteristics

Electrical connections

Table 9: Electrical connections

Version with EN 175301-803 Pg 9plug

Cable version

26.5

21.8

hex 17

ø33

PR TR Ty

No.

40.5

Danfoss

60N9014_MS

Weight approx. 0.3 kg

Pressure Connection

⁄4 - 18 NPT

⁄8 A ISO 228/1

⁄4 in. are

L [mm]

161816.5

Pressure transmitter, Type AKS 32 and AKS 33

Dimension and weight

Table 10: Dimension and weight

Table 11: Dimension and weight

Operating range

Max. working pres‐

sure PB

Compensated tem‐

perature range

Code no.

EN 175301-803, plug Pg 9

[bar]

[°C]

⁄4 NPT

(1)

⁄8 A

(2)

⁄4 in. are

(3)

-1 – 6

-30 – 40

060G2000

060G2004

060G2068

-1 – 12

-30 – 40

060G2001

060G2005

060G2069

-1 – 20400 – 80

060G2002

060G2006

060G2070

-1 – 34550 – 80

060G2003

060G2071

-1 – 50

100

0 – 80

–

060G2007

060G2155

Operating range

Max. working pres‐

sure PB

Compensated tem‐

perature range

Code no.

EN 175301-803, plug Pg 9

[bar]

[°C]

⁄4 NPT

(1)

⁄8 A

(2)

⁄4 in. are

(3)

-1 – 5

-30 – 40

–

060G2038

–

-1 – 9

-30 – 40

060G2013

060G2036

060G2082

-1 – 24400 – 80

060G2014

060G2037

060G2083

-1 – 39600 – 80

060G2080

060G2079

060G2084

Operating range

Max. working

pressure PB

Compensated

temperature

range

Code no.

EN 175301-803, plug Pg 9

Cable

[bar]

[°C]

⁄4 NPT

(1)

⁄8 A

(2)

⁄4 in. are

(3)

⁄4 NPT

(1)

⁄8 A

(2)

⁄4 in. are

(3)

-1 – 533-30 – 40

060G2112

060G2108

060G2047–––-1 – 633-30 – 40

060G2100

060G2104

060G2048

–

060G2120

-1 – 933-30 – 40

060G2113

060G2111

060G2044––

060G2062

-1 – 12

-30 – 40

060G2101

060G2105

060G2049

060G2117

0 – 1640-30 – 40

060G2114

060G2109––––HP-1 – 34550 – 80

060G2103

060G2107

060G2051

060G2119

060G2065

-1 – 20400 – 80

060G2102

060G2106

060G2050

060G2118––

0 – 25400 – 80

060G2115

060G2110

060G2045

–

060G2127

060G2067

Pressure transmitter, Type AKS 32 and AKS 33

Ordering

Table 12: AKS 32, version 1 – 5 V

Table 13: AKS 32, version 0 – 10 V

Table 14: AKS 33, version 4 – 20 mA

(1)

⁄4 - 18 NPT

(2)

Thread ISO 228/1 - G

(3)

⁄16 - 20 UNF

Is also available in US-version (1 – 6 V) and with 1⁄8-27 NPT connection. Please contact Danfoss

⁄8 A (BSP)

UL recognized for sale in the USA and Canada Electrical safety

File no. E310 24, E494625

Hazardous location

File no. E227388

CE marked according to the EMC directive

2015/30/EU

Ex evaluated for Zone 2 for sale in Europe

ATEX II 3G Ex-nA IIA T3 Gc

For sale in Russia, Belarus and Kazakhstan

EAC (EurAsian conformity)

Pressure transmitter, Type AKS 32 and AKS 33

Certicates, declarations and approvals

The list contains all certicates, declarations, and approvals for this product type. Individual code number may have some or all of these approvals, and certain local approvals may not appear on the list.

Some approvals may change over time. You can check the most current status at danfoss.com or contact your local Danfoss representative if you have any questions.

Approvals

Table 15: Approvals
