INSTRUCTION BOOK FOR
Model C With CSR
(Controlled Screen Return)
Pre-Installation To Open Screen
Model C with CSR (Controlled Screen Return) is a feature ofered
exclusively by Da-Lite to assist the quiet controlled return of the
screen into the case.
You Have Made A Wise Selection…
in choosing a Da-Lite projection screen, designed and
engineered to produce the sharpest, most pleasing pictures with
maximum convenience.
Wall Mounting
1. Select fasteners of proper type for wall or ceiling involved.
2. Insert fasteners through proper openings provided in back side
of end caps.
Pull down on pull bail until desired picture area is obtained. Lock
into position as on a window shade. Be sure surface is locked
before releasing.
NOTE: This screen will not lock into position in the upper portion
of its travel.
To Re-Roll Your Picture Surface
The Model C operates on the same principle as a window shade.
Pull down about 4 inches to disengage the locking dog and start
the fabric up irmly and quickly.
Large picture surfaces are heavy and will start up too slowly to
prevent the locking dog from catching unless help is provided,
so keep picture surface moving briskly.
Should the locking dog catch, pull the picture surface down
about 4 inches and start the surface up rapidly.
The CSR feature of this screen will allow the screen to stop, as
normal, in the bottom portion of its travel. The screen will not
stop in the top portion of its travel, but will continue slowly and
gently into the case.
3. Attach screen securely to studding or other solid surface - never
to plaster only.
4. MAKE SURE SCREEN IS MOUNTED LEVEL.
Ceiling Mounting
1. Heavy screw hooks may be installed into wood joists. Other
types of hooks or chain may be used for other ceilings or for
stage installations.
2. Insert hooks or chain through proper openings provided in
sides of end caps. Screen must hang so that lat back of case
is perpendicular to loor.
3. MAKE SURE SCREEN IS MOUNTED LEVEL.
To view an online Model C with CSR retraction tutorial,
please visit http://www.da-lite.com/products/product_lash/
modelc_csr/.
Protect Your Screen
Before re-rolling surface into case, examine both front and back
of surface to be sure they are free of foreign matter.
2
Suggested Methods Of Installation
For Wall
For Ceiling
Picture Surface
Use No. 6 Brackets
To Hang Behind
Beam Or Valance
Wall Mounted
Ceiling Hanging
Picture Surface
Picture Surface
Surface
Concealed
(Allow Room For Access)
Troubleshooting
Symptom Cause Solution
Screen is retracting too slowly.
Over 8 seconds retracting from
the bottom into the case.
Screen is retracting too fast.
Under 3 seconds retracting
from the bottom into the case.
Screen is retracting too slowly, and
then slams the case when adjusted
counterclockwise.
Screen does not retract.
Screen does not stay down.
The CSR adjustment is not correct.
The CSR adjustment is not correct.
The CSR unit (shock absorber) is too strong.
Retraction procedure*. Pull the screen down, and then retract irmly and quickly.
The CSR has been over adjusted
counterclockwise.
The roller tube is bent and binding. Replace the screen.
Locking procedure.
Dog is not locking.
Retract screen completely, and then rotate
CSR shaft 1/2 turn at a time counterclockwise.
Retract screen completely, and then rotate
CSR shaft 1/2 turn at a time clockwise.
Reset the CSR unit. Call Da-Lite (8006223737)
for detailed instructions.
The CSR unit is jammed. Reset or replace the CSR unit.
Call Da-Lite (8006223737) for detailed instructions.
Pull the screen down, and then slowly
retract until it locks.
Retract screen completely, and then rotate
CSR shaft 1/2 turn counterclockwise.
*To view an online Model C with CSR retraction tutorial, please visit http://www.da-lite.com/products/product_lash/modelc_csr/
3
LIMITED ONE YEAR WARRANTY ON DALITE PRESENTATION PRODUCTS
Milestone AV Technologies LLC warrants certain Da-Lite branded products to the original purchaser only, to be free from defects in
materials and workmanship for a period of one (1) year from the date of purchase by the original purchaser; provided they are properly
operated according to Da-Lite's instructions and are not damaged due to improper handling or treatment after shipment from the
factory.
This warranty does not apply to equipment showing evidence of misuse, abuse or accidental damage, or which has been tampered
with or repaired by a person other than authorized Da-Lite personnel.
Da-Lite’s sole obligation under this warranty shall be to repair or to replace (at Da-Lite’s option) the defective part of the merchandise.
Returns for service should be made to your Da-Lite dealer. If it is necessary for the dealer to return the screen or part to Da-Lite,
transportation expenses to and from Da-Lite are payable by the purchaser and Da-Lite is not responsible for damage in shipment.
To protect yourself against damage or loss in transit, insure the product and prepay all transportation expenses.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS
OR IMPLIED, INCLUDING WARRANTIES AS TO FITNESS FOR USE AND MERCHANTABILITY. Any implied warranties of itness for use,
or merchantability, that may be mandated by statute or rule of law are limited to the one (1) year warranty period. This warranty gives
you speciic legal rights, and you may also have other rights, which vary from state-to-state. TO THE MAXIMUM EXTENT PERMITTED
BY APPLICABLE LAW, NO LIABILITY IS ASSUMED FOR EXPENSES OR DAMAGES RESULTING FROM INTERRUPTION IN OPERATION
OF EQUIPMENT, OR FOR INCIDENTAL, DIRECT, OR CONSEQUENTIAL DAMAGES OF ANY NATURE.
In the event that there is a defect in materials or workmanship of a Da-Lite product, you may contact our Sales Partners at PO Box 137,
Warsaw, IN 465810137, (574) 2678101, (800) 6223737.
IMPORTANT: THIS WARRANTY SHALL NOT BE VALID AND DALITE BRANDED PRODUCTS SHALL NOT BE BOUND BY THIS
WARRANTY IF THE PRODUCT IS NOT OPERATED IN ACCORDANCE WITH THE DALITE WRITTEN INSTRUCTIONS.
Keep your sales receipt to prove the date of purchase and your original ownership.
A Milestone AV Technologies Brand
3100 North Detroit Street
Warsaw, Indiana 46582
P: 574.267.8101 or 800.622.3737
F: 574.267.7804 or 877.325.4832
E: info@da-lite.com
www.da-lite.com
DL–0273 (Rev. 1) 07.14
© 2014 Milestone AV Technologies LLC. Printed in U.S.A.
