Da-Lite 93882 Instructions

INSTRUCTION BOOK FOR

Picture King

®

Setting Up Your ScreenImportant Parts Of Your Da-Lite Screen

(When ordering parts, please specify screen model and size.)

1 2 3

19

18

17

16

15

4

12

11

5

6

7

8

9

10

1. Hold screen vertically with tripod just above loor.
With toe, press straight down on toe release plate.
Tripod legs will glide open.

2. Pull out Black Locking Knob at top of bottom tube.

3. Raise extension tube to irst position, and then swing
case to horizontal position.

4. Raise screen surface and pull bail over hanger.
If Keystone Eliminator is to be used, (1) simply grasp the
knurled tip which protrudes slightly above the hanger; (2) pull
straight up; (3) then lay in a horizontal position over the
hanger, and place the pull bail on it.

5. Release Black Locking Knob and fabric tension lock
lever on handle.

6. Holding extension tube with one hand and releasing
Black Locking Knob with other, raise extension tube to
desired position.

7. The case position may be changed by pulling out the
Black Locking Knob located on the handle.

8. When case at desired position, lock into place by
pressing down on the fabric tension lock lever.

14

1) Slat

2) Saddle

3) Pull Bail

4) Hanger Hook

5) Picture Surface

6) Extension Tube

7) Black Locking Knob

8) Bottom Tube

9) Handle

10) Roller

11) Tripod

13

12) Leg Bracket

13) Toe Release &
Leg Lock

14) Leg Shoes

15) Fabric Tension
Lock Lever

16) End Cap

17) Screen Case

18) Black Locking Knob

19) Slat Caps

Using Screen In Lowest Position

Follow steps 1 through 3 above.

a. Raise locking lever on left side of handle.

b. Release black knob and lower case.

c. Holding bottom tube, raise extension tube until

it locks into desired position.
