Important Safety Instructions
When using your video equipment, basic safety precautions should always be followed, including the following:
1. Read and understand all instructions before using.
2. Position the cord so that it will not be tripped over, pulled, or
contact hot surfaces.
3. If an extension cord is necessary, a cord with a current rating
at least equal to that of the appliance should be used. Cords
rated for less amperage than the appliance may overheat.
Save These Instructions
4. To reduce the risk of electric shock, do not disassemble this
appliance. Contact an authorized service dealer when repair
work is required. Incorrect reassembly can cause electric
shock when the appliance is used subsequently.
5. The use of an accessory attachment not recommended by
the manufacturer may cause a risk of ire, electric shock, or
injury to persons.
Pre-Installation
1. Carefully unpack screen and remove outer wrapping from case.
2. Do not remove black tape or rubber bands from slat pocket.
3. Always handle screen in horizontal position.
Installation
There are three methods of mounting to include:
Flush against wall; Suspended from ceiling (use extension brackets); and recessed above ceiling.
Ceiling Hanging
Surface
NOTE: Under no circumstances should unit be completely sealed
in recessed installation. Allow access for service. Picture surface
is centered in case. Case extends 4" beyond surface on either end.
Do not attach anything to screen slat rod or bottom fabric pocket.
1. Make sure screen is level. Use a carpenter’s level and plumb
level.
CAUTION! Do not cut wrapping paper or tape with knife or
any sharp tool. Remove by hand.
Wall Mounted
Surface
Concealed (Allow Room For Access)
Use No. 6 Brackets
To Hang Behind
Beam or Valance
Surface
Figure 1
2. Remove tape and rubber bands from slat pocket.
3. Install electrical hook up that applies to your unit. Make sure to
review your Electrical Installation Checklists and wiring
diagrams (included) for either 120 volt switch, 220/240 volt
switch, or low voltage control.
4. Test installation by running screen up and down a few times.
Be prepared to stop screen. Standard Duty Cycle:
1 MIN. ON / 3 MIN. OFF.
Surface
ATTENTION! Ne coupez pas le papier d'emballage ou le
ruban adhésif avec un couteau ou un outil tranchant.
Retirez à la main.
2
NOTE: Must be installed in accordance with the requirements of
the Local Building Codes, the Canadian Electrical Code (CEC),
CAN/CSA C22.1 and the National Electric Code (NEC), NFPA 70.
Cosmopolitan® Electrol® Installation
¾" Diameter Hole
For Wall Installation
Motor End
4"
Overall length A = fabric width + 8".
Length B is the distance between wall
mounting holes at back of end caps and is
the fabric width + 6 ½".
A
B
Fabric Height x Width As Ordered,
Up To 12 Feet x 12 Feet
6 3⁄32"
⁄"
5 ⅞"
4"
1 ⁄"
4 ⁄"
1 ⁄"
⅜" Diameter For
Ceiling Installation
Enclosure Cover
⅞" Diameter
Knock Out
⅞" Diameter Opening
For Electrical Fittings
Surface
Figure 2
120V Wiring Diagram
NOTE: A single switch cannot be used to operate more
than one screen. Contact the factory for further
information.
To Junction Box, Mounted In Screen Case,
In Which Internal Wiring Terminates In
White, Black and Red Leads
Down
White Limit
Switch
Adjustment
Operating Switch
And Plate Furnished
With Screen (SPDT
With Center Of)
Figure 3
Rocker
Switch
Up
Of
Down
Side View
Of Switch
And Box
Black
Down Black
Common
White
Up Red
White
Red
Black With
Yellow
AC Common
AC Hot
120 V. 60 Hz. 2.5 Max. Amp
This Switch Cannot Be Used With LVC.
Wiring Enclosure Cover
In Multiple Control
Installations This
Switch Is Replaced By
The Low Voltage
Control, Operated
From Push Button
Stations.
240 Volt Wiring Diagram
For Standard Wall Switch:
Da-Lite ofers two styles of 240 volt wall
switches for standard operation. Please
see wiring diagram included in wall switch
box included with screen.
3
