DALI Sound Hub operation manual
DALI SOUND HUB
MANUAL
CONTENS
1.0 Unpacking...........................3
2.0 DALI Sound Hub Buttons Overview ........4
3.0 DALI Sound Hub Connections Overview ....5
4.0 Getting Started .......................6
5.0 Speaker Pairing ......................7
5.1 On The Speaker..........................8
5.2 Finalizing The Pairing......................9
6.0 Connections ........................10
7.0 Plug-In Modules .....................11
8.0 Volume Control ......................12
9.0 Mute ..............................13
10.0 Auto Sensing / Auto Power On .........14
11.0 Display And LED Dimming ............15
12.0 Bluetooth Functions .................16
12.1 Bluetooth Connection Release .............16
12.2 Bluetooth Name........................17
12.3 Bluetooth Remote Reconnect..............18
13.0 Individual Speaker Volume Adjust ......19
14.0 Factory Reset ......................20
14.1 Light Factory Reset .....................20
14.2 Complete Factory Reset..................21
15.0 Firmware Update ...................22
16.0 Cleaning ..........................23
17.0 Disposal ..........................24
2
1.0 UNPACKING
QUICK SET-UP GUIDE
DALI SOUND HUB
Be careful not to damage the contents when unpacking the parts.
Check that all parts are included in the cardboard box. Keep the packaging
materials in case your product needs to be relocated or serviced.
3
2.0 DALI SOUND HUB BUTTONS OVERVIEW
Mute Source Select Volume ControlOn/Off
Optical In BluetoothOptical In (TV)
4
Coxial In
RCA InAUX In
3.0 DALI SOUND HUB CONNECTIONS OVERVIEW
RCA In
PLUG-IN MODULE
Output
L R L R
SUB OUT
Pre Out Power In USB Power Out /
Input
Sub Out
AUX In Coaxial In Optical In Optical In (TV)
LINK
RCA IN
AUX IN
CONNECT
COAXIALPRE OUT
OPTICAL IN OPTICAL IN USB POWER/
PLUG-IN MODULE
POWER
15V 2.8A
SERVICE
Service
5
4.0 GETTING STARTED
1. Insert the two AAA batteries into the Sound Hub remote control.
2. Assemble the Sound Hub power supply with the matching plug
for your country and connect it to the Sound Hub and the wall
outlet.
3. Turn on the Sound Hub by pressing the On/Off button on the
front of the unit.
Note: The Bluetooth remote control will connect to the Sound Hub
within 30 seconds after the Sound Hub is first turned on.
2 3
1
6
5.0 SPEAKER PAIRING
Make sure the Sound Hub is connected to mains
power and is turned on (See 4.0 Getting Started).
Connect the speakers to mains power and turn them
on (See speaker manual for further details).
To pair the Sound Hub with compatible speakers,
initiate the pairing process by pressing the LINK &
CONNECT button on the back of the Sound Hub.
When the Sound Hub is ready to pair with the
speakers, the position display on top of the Sound
Hub will light up, and the volume display will run in
a circle.
7
5.1 ON THE SPEAKER
Go to the first speaker and press the LINK & CONNECT button on the rear of
the speaker.
When the speaker has paired up with the Sound Hub it will play a short sound.
The position display on the rear of the speaker, next to the LINK & CONNECT
button, will blink indicating that you now can set the speaker position.
Press the LINK & CONNECT button again until the wanted position is marked
in the position display on the rear of the speaker. The position changes every
time the LINK & CONNECT button is pressed.
When the correct position is shown on the rear position display, move on
to the next speaker.
Repeat 5.1 for all speakers that need to be paired with the Sound Hub.
8
