OPERATION MANUAL
SYSTEM Air Conditioners
MODELS
Ceilling Mounted Cassette type (Round Flow with Sensing)
FXFQ25SVM FXFQ63SVM
FXFQ32SVM FXFQ80SVM
FXFQ40SVM FXFQ100SVM
FXFQ50SVM FXFQ125SVM
3P335595-2D
Thank you for purchasing this product.
Carefully read this operation manual to ensure proper
operation.
As this operation manual is dedicated for the indoor unit,
refer to also the operation manuals attached to the outdoor
unit and the remote controller.
After reading the manual, le it away for future reference.
CONTENTS
1. SAFETY PRECAUTIONS ............................................ 1
2. NAMES AND FUNCTIONS OF PARTS ........................ 3
3. MAINTENANCE (FOR SERVICE PERSONNEL) ........ 3
1. SAFETY PRECAUTIONS
To gain full advantage of the air conditioner’s functions and to
avoid malfunction due to mishandling, please read this operation manual carefully before use.
This air conditioner comes under the term “appliances not
accessible to the general public”.
• This manual classifies the precautions into WARNINGS and CAUTIONS.
Be sure to follow all the precautions below: They are
all important for ensuring safety.
WARNING .........Indicates a potentially hazardous situa-
tion which, if not avoided, could result in
death or serious injury.
CAUTION ..........Indicates a potentially hazardous situa-
tion which, if not avoided, may result in
minor or moderate injury.
It may also be used to alert against
unsafe practices.
• After reading, keep this manual in a convenient place
so that you can refer to it whenever necessary. If the
equipment is transferred to a new user, be sure also to
hand over the manual.
WARNING
Be aware that prolonged, direct exposure to cool or
warm air from the air conditioner, or to air that is too
cool or too warm can be harmful to your physical condition and health.
When the air conditioner is malfunctioning (giving
off a burning odor, etc.), turn off the power to the air
conditioner and contact your local dealer.
Continued operation under such circumstances may
result in a failure, electric shocks or a fire.
Consult your local dealer about installation work.
Doing the work yourself may result in water leakage,
electric shocks or a fire.
Consult your local dealer regarding modification,
repair and maintenance of the air conditioner.
Improper workmanship may result in water leakage,
electric shocks or a fire.
Do not place objects, including rods, your fingers,
etc., in the air inlet or outlet.
Injury may result due to contact with the air conditioner’s
high-speed fan blades.
Beware of a fire in case of refrigerant leakage.
If the air conditioner is not operating correctly, i.e. not
generating cool or warm air, refrigerant leakage could be
the cause. Consult your local dealer for assistance. The
refrigerant used for the air conditioner is safe and nor-
mally does not leak. However, if the refrigerant leaks and
gets in contact with a naked burner, heater or cooker,
it may generate hazardous compounds. Turn off the air
conditioner and call your local dealer. Turn on the air
conditioner after the qualified service person makes sure
to confirm that the leakage is repaired.
Consult your local dealer regarding what to do in
case of refrigerant leakage.
When the air conditioner is installed in a small room,
it is necessary to take proper measures so that the
amount of any leaked refrigerant does not exceed the
concentration limit in the event of a leakage. Otherwise,
this may lead to an accident due to oxygen depletion.
Contact professional personnel about attachment
of accessories and be sure to use only accessories
specified by the manufacturer.
If a defect results from your own workmanship, it may
result in water leakage, electric shocks or a fire.
Consult your local dealer regarding relocation and
reinstallation of the air conditioner.
Improper installation work may result in leakage, electric
shocks or a fire.
Be sure to use fuses with the correct ampere reading.
Do not use improper fuses, copper or other wiring as
a substitute, as this may result in electric shocks, a fire
injury or damage to the air conditioner.
Be sure to earth the air conditioner.
Do not earth the unit to a utility piping, lightning conductor or telephone earth lead.
Imperfect earthing may result in electric shocks or a fire.
A high surge current from lightning or other sources may
cause damage to the air conditioner.
Be sure to install an earth leakage breaker.
Failure to install an earth leakage breaker may result in
electric shocks or a fire.
Consult your local dealer if the air conditioner submerges owing to a natural disaster, such as a flood
or typhoon.
Do not operate the air conditioner in that case, or other-
wise malfunction, electric shocks, or a fire may result.
Start or stop the air conditioner with the remote controller. Never use the power circuit breaker for this
purpose.
Otherwise, it may cause a fire or water leakage. Further
more, if an automatic restart control is provided against
power failure and the power is recovered, the fan will
rotate suddenly and may cause injury.
Do not use the air conditioner in the atmosphere
contaminated with oil vapor, such as cooking oil or
machine oil vapor.
Oil vapor may cause crack damage to the air conditioner,
electric shocks, or a fire.
Do not use the air conditioner in places with excessive oily smoke, such as cooking rooms, or in places
with flammable gas, corrosive gas, or metal dust.
Using the air conditioner in such places may cause a fire
or air conditioner failures.
1 3P335595-2D English
Do not use flammable materials (e.g., hairspray or
insecticide) near the air conditioner.
Do not clean the air conditioner with organic solvents such as paint thinner.
The use of organic solvents may cause crack damage to
the air conditioner, electric shocks, or a fire.
Be sure to use a dedicated power supply for the air
conditioner.
The use of any other power supply may cause heat gen
eration, a fire, or air conditioner failures.
Consult your local dealer regarding cleaning the
inside of the air conditioner.
Improper cleaning may cause breakage of plastic parts,
water leakage and other damage as well as electric
shocks.
CAUTION
Do not use the air conditioner for purposes other
than those for which it is intended.
Do not use the air conditioner for cooling precision
instru ments, food, plants, animals or works of art as this
may adversely affect the performance, quality and/or
longev ity of the object concerned.
Do not remove the outdoor unit’s outlet side grille.
The guard protects against the unit’s high-speed fan,
which may cause injury.
To avoid oxygen deficiency, ensure that the room is
adequately ventilated if equipment such as a burner
is used together with the air conditioner.
Do not place flammable sprays or operate spray containers near the air conditioner as this may result in
a fire.
Do not put flammable containers, such as spray
cans, within 1 m from the air outlet.
The containers may explode because the warm air from
the indoor or outdoor unit will affect them.
Before cleaning, be sure to stop the air conditioner
operation, turn the power circuit breaker off.
Otherwise, an electric shocks and injury may result.
To avoid electric shocks, do not operate with wet
hands.
Do not place objects that are susceptible to moisture
directly beneath the indoor or outdoor units.
Under certain conditions, condensation on the unit or
refrigerant piping, air filter dirt or drain blockage may
cause dripping, resulting in fouling or failure of the object
concerned.
Do not place appliances that produce naked flames
in places exposed to the airflow from the air conditioner as this may impair combustion of the burner.
Do not place heaters directly below the indoor unit,
as resulting heat can cause deformation.
Do not allow a child to mount on the outdoor unit or
avoid placing any object on it.
Falling or tumbling may result in injury.
Be sure that children, plants or animals are not
exposed directly to airflow from the indoor unit, as
adverse effects may ensue.
Do not wash the air conditioner with water, as this
may result in electric shocks or a fire.
Do not place water containers (flower vases, etc.) on
the indoor unit, as this may result in electric shocks
or a fire.
Do not install the air conditioner at any place where
there is a danger of flammable gas leakage.
In the event of a gas leakage, build-up of gas near the air
conditioner may result in a fire.
Carry out drain piping properly to ensure complete
drainage.
If drain piping is not carried out properly, drain will not
flow out. Then, dirt and debris may be accumulated in the
drain piping and may cause water leakage. If it occurs,
stop the air conditioner and call your local dealer for
assistance.
The appliance is not intended for use by unattended
young children or persons who are incompetent to
operate air conditioners.
It may result in injury or electric shocks.
Children should be watched so that they do not play
with the indoor unit or its remote controller.
Accidental operation by a child may result in injury or
electric shocks.
To avoid injury, do not touch the air inlet or aluminum fins of the air conditioner.
Do not place objects in direct proximity of the outdoor unit and do not let leaves and other debris
accumulate around the unit.
Leaves are a hotbed for small animals which can enter
the unit. Once in the unit, such animals can cause mal-
functions, smoke or a fire when making contact with
elec trical parts.
Do not block air inlets nor outlets.
Impaired airflow may result in insufficient performance or
trouble.
Do not let children play on or around the outdoor
unit.
If they touch the unit carelessly, injury may be caused.
Turn off the power when the air conditioner is not
used for long periods of time.
Otherwise, the air conditioner may get hot or catch on a
fire due to dust accumulation.
Never touch the internal parts of the remote controller.
Do not remove the front panel. Touching certain internal
parts will cause electric shocks and damage to the
remote controller. Please consult your local dealer about
checking and adjustment of internal parts.
Do not leave the remote controller wherever there is
a risk of wetting.
If water gets into the remote controller there is a risk of
electrical leakage and damage to electronic components.
Watch your steps at the time of air filter cleaning or
inspection.
Highplace work is required, to which utmost attention
must be paid.
If the scaffold is unstable, you may fall or topple down,
thus causing injury.
3P335595-2D English 2
2. NAMES AND FUNCTIONS OF PARTS
g
j
k
i
Remote controller (optional accesory)
a
The remote controller may not be needed depending
on the system configuration.
b Air outlet
c Horizontal blade (inside air outlet)
Refrigerant piping
Transmission wiring
Earth wiring (Note)
(Note) It is a wiring to let electricity flow from the
d
indoor unit to the earth for prevention of electric
shocks or a fire in case of emergency.
Power supply wiring
e Drain piping
Air filter (inside suction grille)
f
(Refer to “3. MAINTENANCE” on page 3)
Drain device (built-in)
g
It drains moisture in the room removed during the
cooling operation.
Suction grille
h
(Refer to “3. MAINTENANCE” on page 3)
Air outlet identification mark
(
i
Use this mark as a reference for setting the airflow
direction.
(only for BRC1E62)
Infrared floor sensor
j
It detects the average temperature of the floor
surface.
Infrared presence sensor
k
It detects whether or not someone is there by means
of four sensors corresponding to each air outlet.
f
e
d
b
c
h
a
)
3. MAINTENANCE
(FOR SERVICE PERSONNEL)
ONLY A QUALIFIED SERVICE PERSONNEL IS
ALLOWED TO PERFORM MAINTENANCE
WARNING
• Do not use flammable gas (such as hair sprays and
insecticides) near the air conditioner.
• Do not wipe the air conditioner with benzine or thinner.
It may cause cracks, electric shocks or a fire.
• Never put your fingers or rods in the air inlet, air outlet
or horizontal blade.
The fan is rotating at high speed, so you would get injured.
CAUTION
• Do not wash the air conditioner with water.
It may cause electric shocks or a fire due to leakage.
• Make sure to turn off the air conditioner when taking
care of the air conditioner and disconnect the power
supply breaker.
Unless the power supply is disconnected, it may cause
electric shocks and injuries.
• When working at a high place, give caution to your
footing.
If the scaffold is unstable, it may cause injuries due to fall
and stumbling.
NOTE
• Do not remove the air filter unless for cleaning.
It may cause failure.
• Do not attach substance (such as paper towels) other
than the specified air filter to the air inlet.
The performance may drop and cause freeze-up/water
leakage.
HOW TO CLEAN THE AIR FILTER
When the remote controller indicates “ ” or “Time to clean
filter”, clean the air filter.
• It indicates after running for a certain time.
NOTE
• You may change the time of indication “ ” or “Time to
clean filter”.
If the unit is used in a space where the air is more contaminated, ask your local dealer for solution.
Contamination Time until indication is displayed
Normal
More contaminated
• If it becomes difficult to remove contamination from the air
filter, replace the air filter.
(Air filter for replacement is an optional accessory)
1. Open the suction grille.
Simultaneously press the two knobs, slowly down the
suction grille.
2,500 hours (equivalent to one year)
1,250 hours (equivalent to a half year)
3 3P335595-2D English
2. Take out the air filter.
Carry out the work in the order mentioned below.
2
1
1 Pull the air filter end inclined downward and unhook
the hooking hole of the air filter from the projection of
the grille. (both right and left)
Air filter Hooking hole Projection
2 Lift the air filter and unhook the hooking hole of the air
filter from the projection at the grille upper part. (both
left and right)
Lift up the air filter
Projection
NOTE
• The straps may be caught when the suction grille is
closed. Before closing the suction grille, ensure that
the straps are not getting out from the side of the
suction grille.
(Good) (Wrong)
Strap
Suction
grille
Strap is getting
out from the
suction grille.
6. Turn off the indication “ ” or “Time to clean fil ter”
displayed on the remote controller after turning on
the power.
• For remote controller other than BRC1E type,
press the filter sign reset button “
” on the remote
controller to turn off the indication.
When using BRC1E type, refer to the operation
manual attached to the remote controller.
• The indication can be turned off whether in operation
or at stop.
HOW TO CLEAN THE SUCTION GRILLE
1. Open the suction grille.
Simultaneously press the two knobs, slowly down the
suction grille.
Air filter
Hooking hole Projection
3. Clean the filter.
Clean the contamination with a vacuum cleaner or wash
it with water.
If the air filter
is extremely
contaminated,
After dewatering,
dry the air filter in
the shade.
wash it with
neutral detergent
using a soft brush.
NOTE
• Do not wash the air filter with water of 50°C or higher.
It may cause decolorization and deformation.
• Do not heat the filter with a fire.
It may cause burning.
4. Attach the air filter.
• Attach the air filter in the reverse order mentioned in
the clause 2.
5. Close the suction grille.
Slowly lift the suction grille, and finally, securely fasten it
to the main body of the decoration panel, while pressing
the two knobs.
2. Remove the straps of the suction grille.
Remove the two straps from the holding parts on the
panel main body to which the straps are attached.
Strap Holding part
Strap
3. Remove the suction grille.
Open the suction grille 45° and lift it.
Then, unhook it from the place to hook. (3 places)
Place to hook
Holding
part
Hook
4. Take out the air filter.
Refer to clause 2 for “HOW TO CLEAN THE AIR
FILTER”. (Page. 4)
3P335595-2D English 4
5. Clean the suction grille.
Wash the suction grille with neutral detergent using a
soft brush and then dewater.
Detergent
When the suction grille is extremely contaminated
• Spray the detergent for a ventilating fans and ranges
directly to the suction grille, and keep it under that
condition for about 10 minutes.
After that, carefully wash the suction grille with water.
NOTE
• Do not wash the suction grille with water of 50°C or
higher.
It may cause discoloration and deformation.
• When drying the suction grille, do not heat it with fire.
It may cause burning.
6. Attach the air filter.
Refer to clause 4 for “HOW TO CLEAN THE AIR
FILTER”. (Page. 4)
7. Attach the suction grille.
Attach the suction grille in the reverse order mentioned
in the clause 3.
8. Attach the straps of the suction grille.
Attach the straps in the reverse order mentioned in the
clause 2.
9. Close the suction grille.
Refer to clause 5 for “HOW TO CLEAN THE AIR
FILTER”. (Page. 4)
HOW TO CLEAN AIR OUTLET, SUCTION GRILLE, THE
EXTERIOR AND REMOTE CONTROLLER
• Wipe them with a dry soft cloth.
• When the stain cannot be wiped off, dip the cloth in the
neutral detergent diluted with water and twist the cloth.
After wiping off stain with this cloth, wipe them with dry
cloth.
NOTE
• Do not use such as gasoline, benzine, thinner, polishing powder and liquid insecticide sold in the market.
It may cause discoloration and deformation.
• Do not wash them with water of 50°C or higher.
It may cause discolorization and deformation.
• Be careful not to damage the sensor surface.
The sensors, if damaged, may not provide correct
sensing performance.
5 3P335595-2D English
3P335595-2D
EM13A006A
(1310)
FS
Loading...
