Dahua X54A5L User Manual

Pro Series | X54A5L

Pro

1080p H.265 HDCVI Penta-brid DVR

32-Channel H.265 1.5U HDCVI Digital Video Recorder

• Embedded Processor

• Smart H.265+ and Smart H.264+ Dual Codec

• Dual-stream Recording

• 5 M-N (1296 x 1944) at 20 fps Maximum Recording Resoluon

• 32 HDCVI, AHD, TVI, CVBS or IP Channels

• Up to 8 MP per IP Channel

• 128 Mbps Incoming Bandwidth

• Built-in Smart Search

• Spot Monitor Output on HDMI 2

• Intelligent Video System

• Four (4) SATA HDD Ports, up to 10 TB per Hard Disk Drive

• Five-year Warranty*

System Overview

The X54A Series HDCVI DVR oers 1080p recording on each HDCVI
channel and a host of advanced features and funcons. The X54A takes
advantage of HDCVI technology for easy integraon into exisng video
surveillance systems while leveraging exisng networks, cabling, and
cameras. Penta-brid access technology seamlessly records video from
HDCVI, AHD, TVI, CVBS, and IP sources simultaneously.

The X54A ulizes the Smart H.265+ Codec to signicantly improve
encoding eciency and to reduce bandwidth and storage costs. This
recorder is the ideal soluon for acvely monitoring and recording video
feeds in a wide range of applicaons including public venues, retail
stores, transportaon hubs and access ways, personal property and
homes, and educaonal instuons.

Camera Connecons

Record and monitor video from analog/HDCVI camera inputs and IP
camera inputs simultaneously. The X54A series supports a maximum of
32 channels, with up to 32 channels of HDCVI/AHD/TVI/CVBS/IP inputs.
The exibility of the HDCVI DVR allows all 32 channels to record input
from IP cameras, or from a combinaon of input from analog and IP
sources (not to exceed the maximum number of analog cameras allowed
per recorder).

Flexible Recording

The HDCVI DVR oers a variety of congurable recording opons
and schedule that saves HDD space and acve monitoring me. The
recorder monitors incoming video and can be programmed to record
if moon is detected or if an alarm is triggered. The recorder can also
be programmed to record on a schedule or at dierent intervals. The
recording opons and schedules can be set for each individual camera or
copied to all cameras.

4K

HDMI

P2P

Series

H.265

Smart H.264+

32CH

Plug&Play

Funcons

Smart H.265+

Smart H.265+ is the opmized implementaon of the H.265 codec that
uses a scene-adapve encoding strategy, dynamic GOP, dynamic ROI,
exible mul-frame reference structure and intelligent noise reducon to
deliver high-quality video without straining the network. Smart H.265+
technology reduces bit rate and storage requirements by up to 90%
when compared to the H.264 video compression standard.

HDCVI/AHD/TVI/CVBS Auto-detect

The HDCVI DVR automacally recognizes the incoming signals of each
aached camera without any setup, making installaon easy and
operaon convenient.

Intelligent Video System (IVS)

With built-in IVS analycs on up to 16 channels, the HDCVI DVR delivers
intelligent funcons to monitor a scene for Tripwire violaons, intrusion
detecon, and abandoned or missing objects. A device with IVS quickly
and accurately responds to monitoring events in a specic area.

Face Detecon

The HDCVI DVR oers Face Detecon of the rst analog channel. This
technology detects and captures a snapshot of a human face in a dened
area within a scene.

Smart Fan Design

The HDCVI DVR automacally turns on or turns o the fan according
to the CPU temperature. This funcon reduces fan noise and helps to
conserve electricity.

Smart Search

Smart Search allows an operator to specify a region in the playback video
to search for a moon detecon event, saving me and manpower.

us.dahuasecurity.com

*Warranty applies to products sold through an authorized Dahua Dealer.

Pro Series | X54A5L

Technical Specicaon

System

Main Processor

Operating System

Embedded Processor

Embedded LINUX

Interface

Analog Camera Input

Preview Ability

HDCVI

AHD

TVI

CVBS

IP Camera Input

Audio

Two-way Talk

32 Channels, BNC

Channels 1 and 2:

• 5 M-N (1296 x 1944) at 20 fps or

• 4 M-N (1280 x 1440) at 30 fps

Channels 3 to 32:

• 4 M-N (1280 x 1440) at 30 fps

5 MP, 4 MP, 1080p, 720p

5 MP, 4 MP, 1080p, 720p

5 MP, 4 MP, 1080p, 720p

NTSC

32 Channels, each channel up to 8 MP
(The recording rate is dependent on the maximum
resolution and frame rate of the connected IP
camera.)

Input: Four (4) Channels, BNC
Output: One (1) Channel, BNC

Input: One (1) Microphone, BNC
Output: One (1) Speaker, BNC

Recording

Compression

Recording Resolution

Record Rate

Main Stream

Sub Stream

Maximum Incoming Bandwidth

Bit Rate

Record Mode

Record Interval

Audio Compression

Audio Sample Rate

Audio Bit Rate

Smart H.265+, H.265, Smart H.264+, H.264

5 M-N (1296 x 1944), 4 M-N (1280 x 1440), 1080p,
1080N, 720p, 960H, D1, CIF

Channel 1:

• 5 M-N (1296 x 1944)
at 20 fps

Channels 2 to 32:

• 4 M-N (1280 x 1440)
at 7 fps

D1 or CIF at 15 fps

128 Mbps

32 Kbps to 6144 Kbps per Channel

Manual, Schedule (Regular, Continuous),
MD (Video Detection: Motion Detection, Video Loss,
Tampering), Alarm, Stop

1 to 60 minutes (default: 60 minutes),
Pre-record: 1 s to 30 s,
Post-record: 10 s to 300 s

AAC (first channel only), G.711A, G.711U, PCM

8 KHz, 16 bits per Channel

64 Kbps per Channel

Channels 1 and 2:

• 5 M-N (1296 x 1944)
at 10 fps

Channels 3 to 32:

• 4 M-N (1280 x 1440)
at 15 fps

Display

Interface

Native Output
Resolution

HDMI 1

HDMI 2/VGA

Maximum Decoding

Multi-screen Display

On-screen Display

1. The M-N resoluon refers to technology that allows a 1080p HDCVI DVR to accept a video signal from a 5 MP
or a 4 MP camera by sampling every other pixel on a horizontal line from the camera. The resulng recording
resoluons are: 5 M-N: 1296 x 1944; 4 M-N: 1280 x 1440.

Two (2) HDMI, One (1) VGA, One (1) BNC

3840 x 2160, 2560 x 1440, 1920 x 1080, 1280 x 1024,
1280×720

1920 x 1080, 1280 x 1024, 1280 x 720

16 Channels of 4 M-N at 15 fps
8 Channels of 4 M-N at 30 fps
1 Channel of 6 MP at 30 fps

1/4/8/9/16/25/36

Camera Title, Time, Video Loss, Camera Lock,
Motion Detection, Recording

Network

Interface

Network Function

Maximum User Access

Mobile Operating
System

Interoperability

One (1) RJ45 (1000 Mbps) Port

HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP,
DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server,
P2P, IP Search (Supports Dahua IP cameras, DVRs, NVS)

128 Users

IOS, Android

ONVIF 16.12, CGI Conformant

Video Detecon and Alarm

Trigger Events

Video Detection

Alarm Input

Relay Output

Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot,
Buzzer and Screen Tips

Motion Detection, MD Zones: 396 (22 × 18),
Video Loss, Tampering and Diagnosis

16 Channels

Six (6) Channels

Playback and Backup

Playback

Search Mode

Playback Function

Backup Mode

1/4/9/16

Time/Date, Alarm, MD and Exact Search
(accurate to 1 second)

Play, Pause, Stop, Rewind, Fast Play, Slow Play, Next
File, Previous File, Next Camera, Previous Camera, Full
Screen, Repeat, Shuffle, Backup Selection, and Digital
Zoom

USB Device/Network

Storage

Internal HDD

Four (4) SATA Ports, up to 10 TB capacity for each disk

Auxiliary Interface

USB

RS232

RS485

RS422

One (1) USB 2.0 Port and Two (2) USB 3.0 Ports

One (1) Port for PC Communication and Keyboard

One (1) Port for PTZ Control

One (1) port for PTZ Control

Electrical

Power Supply

Power Consumption

100 VAC to 240 VAC, 50/60 Hz

< 35 W

Construcon

Dimensions

Net Weight

Gross Weight

Installation

1.5U, 440.0 mm x 417.0 mm x 76.0 mm
(17.30 in. x 16.40 in. x 3.0 in.)

5.0 kg (11.0 lb), without HDD

7.0 kg (15.43 lb)

Desktop or Rack-mount

Environmental

Operating Conditions

Storage Conditions

–10° C to +55° C (+14° F to +131° F), 10% to 90% RH

–20° C to +70° C (–4° F to +158° F), 0% to 90% RH

us.dahuasecurity.com

440.0 mm

76.0 mm

Pro Series | X54A5L

཰ ཱཱིི ུ ཱུྲྀཷླྀ

ཹེ

Cercaons

Safety

Electromagnetic
Compatibility (EMC)

Immunity

UL 60950-1
EN 60950-1, IEC 60950-1

FCC Part 15 Subpart B ICES 003 Issue 6
EN 55032
EN 50130
EN 61000-3-2
EN 61000-3-3

EN 55024 : 2010

Intelligence

The IVS features are operational only when the additional IP channel feature is not active.
The HDCVI DVR supports only IVS or the additional IP channel inputs, both features cannot
be in use simultaneously.
IVS triggers an alarm and takes a defined action for the following events:

Premium Features

Channels 1 through 16: Support Tripwire and Intrusion Detection
Channels 1 and 2: Additionally support Abandoned/Missing Object Detection

Tripwire

Intrusion

Abandoned/Missing
Object

Advanced Feature

Available on Analog Channel 1
(feature not available if an IP camera is connected as Camera 1)

Face Detection

A target crosses a user-defined line.

A target enters or exits a defined perimeter.

A target leaves an object in designated area, or a target
removes an object from the same designated area.

Detects and captures a snapshot of a human face in a
defined area within a scene.

Ordering Informaon

Typ e Part Number Description

32 Analog/IP Inputs, 1080p Penta-brid,
16 Alarm Inputs, 6 Alarm Outputs, 1.5U HDCVI Digital
Video Recorder, No Pre-installed HDD

32 Analog/IP Inputs, 1080p Penta-brid,
16 Alarm Inputs, 6 Alarm Outputs, 1.5U HDCVI Digital
Video Recorder, 2 TB

32 Analog/IP Inputs, 1080p Penta-brid,
16 Alarm Inputs, 6 Alarm Outputs, 1.5U HDCVI Digital
Video Recorder, 4 TB

32 Analog/IP Inputs, 1080p Penta-brid,
16 Alarm Inputs, 6 Alarm Outputs, 1.5U HDCVI Digital
Video Recorder, 8 TB

32 Analog/IP Inputs, 1080p Penta-brid,
16 Alarm Inputs, 6 Alarm Outputs, 1.5U HDCVI Digital
Video Recorder, 10 TB

Penta-brid
HDCVI DVR

X54A5L

X54A5L2

X54A5L4

X54A5L8

X54A5L10

Dimensions (mm/in.)

(17.30 in.)

70.0 mm

(2.76 in.)

416.70 mm
(16.41 in.)

405.0 mm
(15.94 in.)

Rear Panel

ཻོཽ

1 Microphone OUT, BNC x 1 8 VGA OUT

2 Microphone IN, BNC x 1 9 Power Input

3 Video OUT, BNC x 1 10 Video IN, BNC x 32

4 Audio OUT, BNC x 1 11 RS232 Port

5 Audio IN, BNC x 4 12 eSATA P or t

6 Alarm I/O, RS 485, RS422 13 USB 3.0 x 2

7 Network Port 14 HDMI 1 and HDMI 2 OUT

(3.0 in.)

Rev: 001.007

© 2021 Dahua Technology USA. All rights reserved. Design and specicaons are subject to change without noce.
